Manual for
Design :
Brinkmann Audio
Im Himmelreich 13
88147 Achberg
Germany
Tel.: 08380 / 981195
Fax: 08380 / 981233
www.brinkmann-audio.com
h.b.@brinkmann-audio.com
Legal regulation of the European Community :
This amplifier had been designed and testet according to the guidelines IEC55013 and
IEC55020, and it meets the safety requirements IEC60065.
Informations for safety :
The preamplifier CALVIN is only to be used in dry rooms with an average temperature and
is only allowed for 220-240V, 50Hz alternating current.
The power supply is only to be connected to sockets with
Please connect or disconnect only when the amplifier is not connected to the mains.
The amplifier is not switched off in the stand-by modus.
Always disconnect the amplifier from the mains when it is not used for a longer period of
time ( during holidays etc. )!
Never lift or remove the glass plate while the amplifier is connected to the mains!
Attention, dangerous voltage!
Repairs, modifications etc. are only to be carried out by the company
by specially authorized workshops! Please allow some time before lifting the glass plate, so
high voltages can reduce.
Always keep the amplifier away from wet, heat and open fire. Don't expose it to the blazing
sun! Never place receptacles with fluids on the amplifier.
brinkmann
brinkmann
brinkmann
brinkmann
Preamplifier CALVIN
Service :
Ing.-Büro R. Klatt-Milsmann
Deppendorfer Str. 151
33793 Bielefeld
Germany
Tel.: 05203 / 883033
Fax: 05203 / 883034
R.Klatt-Milsmann@gmx.de
brinkmann
itself or
Advertisement
Table of Contents
Related Manuals for Brinkmann CALVIN
Summary of Contents for Brinkmann CALVIN
- Page 1 IEC55020, and it meets the safety requirements IEC60065. Informations for safety : The preamplifier CALVIN is only to be used in dry rooms with an average temperature and is only allowed for 220-240V, 50Hz alternating current. The power supply is only to be connected to sockets with Please connect or disconnect only when the amplifier is not connected to the mains.
- Page 2 All inputs, the rec-output and the asymmetrical output are Cynch-(RCA)-sockets. Remote control : The purchase of the CALVIN preamplifier includes the remote control. It features three push buttons for the functions (left to right) volume down, mute and volume up, for the volume...
- Page 3 The sensor for the remote control is positioned beneath the glass plate in the front of the amplifier; for an impeccable function of the sensor it is essential to keep the glass plate clear of objects or immediately adjacent shelves etc. on top of the amplifier. To change batteries, please unscrew the remote control at its back side, pull out the battery compartment and replace the empty batteries by two new ones of the type AA according to the illustration in the compartment.
- Page 4 120 x 80 x 160 mm Weight with psu : ca. 8 kg Granit plate : 420 x 30 x 310 mm Weight granit plate : ca. 8 kg brinkmann Im Himmelreich 13 88147 Achberg Germany tel: 08380 981185 fax: 08380 981233 mail: info@brinkmann-audio.com...
