1/35 S-65 Stalinetz Engine Upgrade Set
contains 1 highly detailed and accurate set
Reel assembly for weasels, jeeps, other vehicles and diorama
39
resin parts
27
PE parts
wire needed for assembly
Decals for 2 tractors (Russian and German service)
instructions and references on CD
Keep safety rules when working with resin.
For safety reasons, and due to the complexity of construction,
this kit is recommended only for advanced modellers.
The kit contains small parts, keep it out of the reach of children.
Glue and paints not included
No.35405
WWW.LZmodels.com
Made in EU
glue and paints not included
suitable for advanced modellers
keep safety rules for work with resin
Advertisement
Related Manuals for LZ Models 35405
Summary of Contents for LZ Models 35405
- Page 1 1/35 S-65 Stalinetz Engine Upgrade Set No.35405 WWW.LZmodels.com Made in EU contains 1 highly detailed and accurate set Reel assembly for weasels, jeeps, other vehicles and diorama resin parts glue and paints not included PE parts suitable for advanced modellers...
- Page 4 Fit the front corners...
- Page 5 The middle gap meets the edge of the engine block...
- Page 6 Fit the opposite bolt heads and secure with C/A glue...
- Page 7 Mind correct position...
- Page 8 0.6mm wire A11 should have 4 tiny holes about 0,3mm for wiring that can be done to get nice detail - check the link at last page to find a great walkaround, which provides perfect reference for ultra detailing Rods A9 are slightly longer to avoid possible resin and mold shrinkage, cut the tops to the length required, glue them one by one on the top, set them exactly vertically and glue the base...
- Page 9 glue A12 - dry fit the engine in its place, put the front on B6 beam , then the edge marked with arrow should be about 0,5mm lower than top of the kit part E2 - set engine perfectly vertically with E2, put A12 in place and glue it to the engine block A1...
- Page 10 Mind correct position...
- Page 11 glue Dry fit engine once again in the frame, the edge marked with arrow should be about 0,5mm lower than top of the kit part E1 - set engine perfectly vertically with E2, put A13 in place and glue it to the engine block A1. Join A4 with A13 and glue it together with A1, make sure the A4 is in line vertically with oil pan edge here Assembly and position of A28...
- Page 13 0,8mm wire 0,5mm wire...
- Page 15 cut bottoms of A31 in slight angle and assembly like shown in pictures...
- Page 16 Glue here Glue here Dry fit A18 - you might need to sand a bit where arrow shows - to place it between end of A17 and kit part E3 - see next page. You might also need to use hot water to adjust and shape some pipes - resin cures few days, and they could get warped slightly in package during transport.
- Page 17 secure with glue then add A30 You might need to cut ends of A24 or A18 or both to fit them properly with A30. Pipes a tiny bit longer - some could prefer to drill holes for pipes in A30 to make assembly easier...
- Page 20 PE 4...
- Page 21 0,5mm wire...
- Page 22 PE 6 Small piece of 0,3mm wire can be used to make lever handles...
- Page 23 Remove plastic where shown - otherwise you wont be able to assemble top cover, then put engine in its place and secure with glue. Finally assemble the top cover - or leave it away, if you want - in any case use kit parts D7, D9, F21 and completed B2+B3+F1, and glue them on where they belong - see kit instructions - through cover holes - or straight on the engine parts B2+B3+F1 on the top of A20, D9 on A16, F21 on the right top end of A15 if you are not using the top cover.
- Page 24 1mm wire with flattened ends PE 8 1mm wire with flattened ends...
- Page 25 remove pins PE9 L and R Replace kit parts G5,G6,G11,G12 by PE - mind left and right pieces PE10 L and R...
- Page 26 Wire needed is supplied in the set LZ models will offer soon resin radiator with correct letters to replace this one in the kit LZ models will soon also offer upgrade conversion set to build up gas powered S65 tractor...
