Drive chain slack

The drive chain slack should be
checked before each ride and adjusted
if necessary.
To check the drive chain slack
1. Place the motorcycle on the side-
stand.
TIP
When checking and adjusting the drive
chain slack, there should be no weight
on the motorcycle.
2. Shift the transmission into the neu-
tral position.
3. Move the rear wheel by pushing
the motorcycle to locate the tight-
est portion of the drive chain, and
then measure the drive chain slack
as shown.
Drive chain slack:
30.0–45.0 mm (1.18–1.77 in)
PERIODIC MAINTENANCE AND ADJUSTMENT
EAU22760
EAU22773
1. Drive chain slack
4. If the drive chain slack is incorrect,
adjust it as follows.
To adjust the drive chain slack
1. Loosen the axle nut and the lock-
nut on each side of the swingarm.
1. Drive chain slack adjusting bolt
2. Locknut
3. Alignment marks
4. Axle nut
5. Drive chain puller
EAU39055
2. To tighten the drive chain, turn the
7-27
1 2 3
4
5
drive chain slack adjusting bolt on
each side of the swingarm in direc-
tion (a). To loosen the drive chain,
turn the adjusting bolt on each side
of the swingarm in direction (b),
and then push the rear wheel for-
ward. NOTICE: Improper drive
chain slack will overload the en-
gine as well as other vital parts
of the motorcycle and can lead
to chain slippage or breakage.
