Page 1 TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column. When driving Driving, stopping and safe-driving information. Interior fea- Air conditioning and audio systems, as well as other in- tures terior features for a comfortable driving experience. Maintenance Cleaning and protecting your vehicle, performing do-it- and care...
Page 2: For Your Information
A wide variety of non-genuine spare parts and accessories for Toyota vehicles are currently available on the market. You should know that these parts are not covered by Toyota warranty and that Toyota is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 3 ● Anti-lock brake system ● SRS airbag system ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of a mobile two-way radio system. Vehicle data recordings Your Toyota is equipped with several sophisticated computers that will record data, such as: •...
Page 4 Event data recorder This vehicle is equipped with an event data recorder (EDR). The main pur- pose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.
Page 5 ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehicle) is obtained • In response to an official request by the police, a court of law or a govern- ment agency •...
Page 6 CAUTION ■ General precautions while driving Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.
Page 7 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
Page 8 Pictorial index Exterior Headlights (high beam) and daytime running lights P. 159, 161 Headlights (low beam) P. 159 ∗ Windshield wipers P. 165 Moon roof P. 73 Hood P. 351 Outside rear view mirrors P. 69 Front side marker lights P.
Page 9 Fuel filler door P. 77 Trunk P. 47 Doors P. 41 Tires ●Rotation P. 371 ●Replacement P. 436 Rear turn signal lights P. 146 ●Inflation pressure P. 480 ●Information P. 485 Stop/tail and rear side marker lights P. 159 ∗ : If equipped...
Page 10 Pictorial index Interior Cup holders P. 315 Head restraints P. 56 Parking brake lever P. 147 Seat belts P. 58 SRS driver airbag P. 86 Power window ∗ Auxiliary boxes P. 318 switches P. 71 SRS front passenger airbag P. 86 Glove box P.
Page 11 ∗ Personal lights P. 310 ∗ ∗ Microphone P. 284 Personal/interior lights SRS curtain shield airbags P. 86 P. 311 ∗ Interior light P. 310 Auxiliary boxes P. 318 ∗ Compass P. 331 Anti-glare inside rear view mirror P. 67 Assist grips P.
Page 12: Table Of Contents
Pictorial index Instrument panel Gauges and meters P. 149 Headlight switch P. 159 Multi-information display P. 156 Turn signal lever P. 146 ∗ Fog light switch P. 163 Windshield wiper and washer switch P. 165 Clock P. 323 Emergency flasher Hood lock release Horn P.
Page 13 Automatic air conditioning system Rear window and outside rear view mirror defogger ∗ ∗ switch /rear window defogger switch P. 219 Air conditioning system P. 206 ∗ ∗ AUX port P. 274 Seat heater switches ∗ AUX port/USB port P. 327 P.
Page 14 Pictorial index Instrument panel VSC/TRAC off switch Outside rear view P. 172 mirror switches P. 69 Auxiliary boxes P. 318...
Page 15 Type A ∗ Talk switch ∗ Telephone switch Audio remote control ∗ switches P. 276 ∗ Cruise control switch P. 168 Engine (ignition) switch (vehicles without smart ∗ key system) P. 135 Engine (ignition) switch (vehicles with smart ∗ key system) P.
Page 16: Instrument Panel
Pictorial index Instrument panel Type B ∗ Talk switch ∗ Audio remote control Telephone switch switches P. 276 ∗ Cruise control switch P. 168 Engine (ignition) switch P. 135 ∗ : If equipped : Refer to “Display Audio System Owner’s Manual”.
Page 17 1-1. Key information Keys The following keys are provided with the vehicle. Vehicles with smart key system Electronic keys • Operating the smart key system (→P. 25) • Operating wireless remote control function (→P. 36) Mechanical keys Key number plate Vehicles without smart key system (type A) Master keys Operating the wireless remote...
Page 18 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer using the key number plate. (→P. 451) ■...
Page 19 1-1. Key information NOTICE ■ To prevent key damage ● Do not subject the keys to strong shocks, expose them to high tempera- tures by placing them in direct sunlight, or get them wet. ● Do not expose the keys to electromagnetic materials or attach any mate- rial that blocks electromagnetic waves to the key surface.
Page 20 1-2. Opening, closing and locking the doors and trunk ∗ Smart key system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) Electronic key Electronic key Electronic key...
Page 21 1-2. Opening, closing and locking the doors and trunk Unlocking and locking the doors (front door handles only) Grip the driver's door handle to unlock the door. Grip the passen- ger's door handle to unlock all the doors.* Make sure to touch the sensor on the back of the handle.
Page 22 1-2. Opening, closing and locking the doors and trunk Antenna location and effective range ■ Antenna location Antennas outside the cabin Antenna outside the trunk Antenna inside the trunk Antennas inside the cabin...
Page 23 1-2. Opening, closing and locking the doors and trunk ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 2.3 ft. (0.7 m) of either of the outside front door handles.
Page 24 1-2. Opening, closing and locking the doors and trunk ■ Operation signals A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) ■ Conditions affecting operation The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system and wireless remote control from operating properly.
Page 25 1-2. Opening, closing and locking the doors and trunk ■ Switching the door unlock function It is possible to set which doors the entry function unlocks. STEP Turn the “ENGINE START STOP” switch OFF. STEP When the indicator on the key surface is off, press and hold , or for approximately 5 seconds while...
Page 26 1-2. Opening, closing and locking the doors and trunk ■ Electronic key battery depletion ● The standard battery life is 1 to 2 years. ● The battery becomes depleted even if the electronic key is not used because the key always receives radio waves. If the smart key system or the wireless remote control function does not operate, or the detection area becomes smaller, the battery may be depleted.
Page 27 1-2. Opening, closing and locking the doors and trunk ● Do not leave the electronic key on top of the instrument panel or near the door pockets when exiting the vehicle. Depending on the radio wave reception conditions, it may be detected by the antenna outside the cabin and the door will become lockable from the outside, possibly trapping the electronic key inside the vehicle.
Page 28 1-2. Opening, closing and locking the doors and trunk ● When an alarm sounds: Take appropriate measures according to the following table. Alarm Situation Correction procedure Tried to lock the doors Retrieve the elec- using the entry function tronic key from the while the electronic key is vehicle and lock the Exterior alarm...
Page 29 ■ When the electronic key battery is fully depleted →P. 388 ■ Customization that can be configured at Toyota dealer It is possible to deactivate the smart key system, etc. (Customizable features →P. 497) ■ Certification for the smart key system For vehicles sold in the U.S.A.
Page 30 (→P. 27) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves.
Page 31 1-2. Opening, closing and locking the doors and trunk ∗ Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle from outside the vehicle. Vehicles with smart key system Locks all doors Unlocks doors Pressing the button unlocks the driver’s door.
Page 32 1-2. Opening, closing and locking the doors and trunk ■ Operation signals Doors: A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) Trunk: A buzzer sounds to indicate that the trunk has been unlocked. ■...
Page 33 1-2. Opening, closing and locking the doors and trunk ■ Key battery depletion Vehicles with smart key system →P. 31 Vehicles without smart key system If the wireless remote control function does not operate, the battery may be depleted. Replace the battery when necessary. (→P. 389) ■...
Page 34 1-2. Opening, closing and locking the doors and trunk ■ Customization that can be configured at Toyota dealer Settings (e.g. trunk unlocking function) can be changed. (Customizable features →P. 497) ■ Certification for wireless remote control (vehicles with smart key sys- tem) For vehicles sold in the U.S.A.
Page 35 1-2. Opening, closing and locking the doors and trunk ■ Certification for wireless remote control (vehicles without smart key system ⎯ type A) FCC IDs: GQ4-29T GQ4-36R IC IDs: 1470A-10T 1470A-8R MADE IN USA This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada.
Page 36 1-2. Opening, closing and locking the doors and trunk Doors The vehicle can be locked and unlocked using the entry function, wireless remote control, key or door lock switch. ■ Entry function (vehicles with smart key system) →P. 25 ■ Wireless remote control (if equipped) →P.
Page 37 1-2. Opening, closing and locking the doors and trunk ■ Inside lock button Locks the door Unlocks the door The front doors can be opened by pulling the inside handle even if the lock buttons are in the lock position. Rear door child-protector lock The door cannot be opened from inside the vehicle when the locks...
Page 38 1-2. Opening, closing and locking the doors and trunk Automatic door locking and unlocking systems (vehicles with power door lock system) The following functions can be set or cancelled: Function Operation Shift position linked Shifting the shift lever out of P locks all door locking function doors.
Page 39 1-2. Opening, closing and locking the doors and trunk ■ Setting and canceling the functions To switch between set and canceled, follow the procedure below: STEP Vehicles with smart key system: Close all the doors and switch the “ENGINE START STOP” switch to IGNITION ON mode.
Page 40 Vehicles without smart key system The key is in the engine switch and either of the front door is open. ■ Customization that can be configured at Toyota dealer Settings (e.g. unlocking function using a key) can be changed. (Customizable features →P. 497)
Page 41 1-2. Opening, closing and locking the doors and trunk CAUTION ■ To prevent an accident Observe the following precautions while driving the vehicle. Failing to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. ●...
Page 42 1-2. Opening, closing and locking the doors and trunk Trunk The trunk can be opened using the entry function, wireless remote control, key or trunk opener. ■ Opening the trunk from inside the vehicle Release the trunk lid. ■ Opening the trunk from outside the vehicle Entry function (vehicles with smart key system) →P.
Page 43 1-2. Opening, closing and locking the doors and trunk Trunk opener cancelling system To protect luggage stored in the trunk against theft, do the following procedure. Turn the master key (vehicles without smart key system) or mechanical key (vehicles with smart key system) counterclock- wise to lock the trunk opener fea- ture.
Page 44 1-2. Opening, closing and locking the doors and trunk CAUTION ■ Caution while driving ● Before driving the vehicle, make sure that the trunk lid is fully closed. If the trunk lid is not fully closed, it may open unexpectedly while driving, caus- ing an accident.
Page 45 ● Do not attach any accessories other than genuine Toyota parts to the trunk lid. Such additional weight on the trunk lid may cause the lid to suddenly shut again after it is opened.
Page 46 1-3. Adjustable components (seats, mirrors, steering wheel) Front seats Power seat (driver's side only) Seat position switch Seatback angle switch Seat cushion (front) angle switch Vertical height adjustment switch Lumbar support switch...
Page 47 1-3. Adjustable components (seats, mirrors, steering wheel) Manual seat Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (driver’s side only) Active head restraints When occupant’s back presses against the seatback during a rear-end collision, the head restraint moves slightly for- ward to help reduce the risk of whiplash on the seat occupant.
Page 48 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Active head restraints Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may appear the head restraint inner structure. These do not indicate problems. During rear-end collision...
Page 49 1-3. Adjustable components (seats, mirrors, steering wheel) Rear seats ■ Before folding down the rear seat Stow the rear outside seat belt buckles and move the rear center seat belt buckle as shown. ■ Folding down rear seatbacks Pull the seatback lever in the trunk for the seatback you wish to fold down.
Page 50 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ After returning the seatback to the upright position Observe the following precautions. Failure to do so may result in death or serious injury. ● Make sure the seatback is securely locked by pressing forward and rear- ward on the top of the seatback.
Page 51 1-3. Adjustable components (seats, mirrors, steering wheel) Head restraints Head restraints are provided for all seats. Front seats Pull the head restraints up. Down Push the head restraint down while pushing the lock release button. Lock release button Rear seats Pull the head restraints up.
Page 52 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Installing the head restraints Align the head restraint with the installa- tion holes and push it down to the lock position. Press and hold the lock release button when lowering the head restraint. ■...
Page 53 1-3. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. ■ Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
Page 54 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Adjusting the height of the belt (front seats) Push the seat belt shoulder anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
Page 55 1-3. Adjustable components (seats, mirrors, steering wheel) Buckle, position and release the STEP seat belt. Seat belt pretensioners (front seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt when the vehicle is subjected to certain types of severe frontal collision.
Page 56 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Emergency locking retractor (ELR) The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
Page 57 Toyota dealer free of charge. ■ Rear outside seat belt Use the seat belt after passing it through the guide if the seat belt comes free from...
Page 58 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 59 ● Ensure that the belt and tab are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 60 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ Using a seat belt comfort guide ● Make sure the belt is not twisted and that it lies flat. The elastic cord must be behind the belt and the guide must be on the front. ●...
Page 61 1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and STEP press the lever down. Adjust to the ideal position by STEP moving the steering wheel horizontally and vertically.
Page 62 1-3. Adjustable components (seats, mirrors, steering wheel) Anti-glare inside rear view mirror Glare from the headlights of vehicles behind can be reduced by using the following functions. Manual anti-glare inside rear view mirror Normal position Anti-glare position Auto anti-glare inside rear view mirror In automatic mode, sensors are used to detect the headlights of vehicles behind and the reflected light is automatically reduced.
Page 63 1-3. Adjustable components (seats, mirrors, steering wheel) Adjusting the height of rear view mirror Adjust the height of the rear view mirror by moving it up and down. ■ To prevent sensor error (vehicles with auto anti-glare inside rear view mirror) To ensure that the sensors operate prop- erly, do not touch or cover them.
Page 64 1-3. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted using the switch. Select a mirror to adjust. STEP Left Right Adjust the mirror. STEP Right Down Left Folding back the mirrors Push backward to fold the mir- rors.
Page 65 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Mirror angle can be adjusted when Vehicles with smart key system The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode. Vehicles without smart key system The engine switch is in the “ACC” or “ON” position. ■...
Page 66 1-4. Opening and closing the windows and moon roof ∗ Power windows The power windows can be opened and closed using the following switches. Closing Opening One-touch opening (driver’s window only) To stop the window partway, operate the switch in the oppo- site direction.
Page 67 1-4. Opening and closing the windows and moon roof ■ The power windows can be operated when Vehicles with smart key system The “ENGINE START STOP” switch is in IGNITION ON mode. Vehicles without smart key system The engine switch is in the “ON” position. ■...
Page 68 1-4. Opening and closing the windows and moon roof ∗ Moon roof Use the overhead switches to open, close, and tilt the moon roof up and down. ■ Opening and closing Open* The moon roof stops slightly before the fully open position to reduce wind noise.
Page 69 1-4. Opening and closing the windows and moon roof ■ The moon roof can be operated when Vehicles with smart key system The “ENGINE START STOP” switch is in IGNITION ON mode. Vehicles without smart key system The engine switch is in the “ON” position. ■...
Page 70 Check to make sure that the moon roof is completely closed and then release the switch. If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by your Toyota dealer.
Page 71 1-4. Opening and closing the windows and moon roof CAUTION ■ Opening the moon roof Observe the following precautions. Failing to do so may cause death or serious injury. ● Do not allow any passengers to put their hands or heads outside the vehi- cle while it is moving.
Page 72 1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. ■ Before refueling the vehicle Vehicles with smart key system Turn the “ENGINE START STOP” switch OFF and ensure that all the doors and windows are closed. Vehicles without smart key system Turn the engine switch OFF and ensure that all the doors and windows are closed.
Page 73 1-5. Refueling Hang the fuel tank cap on the STEP back of the fuel filler door. Closing the fuel tank cap When replacing the fuel tank cap, turn it until a clicking sound is heard. After releasing your hand, the cap will turn slightly to the opposite direction.
Page 74 This may cause static electricity to build up, resulting in a possible ignition hazard. ■ When replacing the fuel cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 75 1-5. Refueling NOTICE ■ Refueling Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the exhaust systems to operate abnormally or damaging fuel system components or the vehicle's painted surface.
Page 76 1-6. Theft deterrent system Engine immobilizer system The vehicle's keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle's on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. Vehicles with smart key sys- The indicator light flashes after the “ENGINE START STOP”...
Page 77 1-6. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type engine immobilizer system. ■ Conditions that may cause the system to malfunction ● If the key is in contact with a metallic object ● If the key is in close proximity to or touching a key to the security system (key with a built-in transponder chip) of another vehicle ■...
Page 78 1-6. Theft deterrent system NOTICE ■ To ensure the system operates correctly Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed.
Page 79 1-7. Safety information Correct driving posture Drive in a good posture as follows: Sit upright and well back in the seat. (→P. 51) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
Page 80 1-7. Safety information CAUTION ■ While driving ● Do not adjust the position of the driver's seat while driving. Doing so could cause the driver to lose control of the vehicle. ● Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
Page 81 1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag and front passenger airbag Can help protect the head and chest of the driver and front pas-...
Page 82 1-7. Safety information Airbag system components Front airbag sensors SRS warning light Front passenger occupant Front passenger’s seat belt classification system (ECU buckle switch and sensors) Airbag sensor assembly Door sensors Curtain shield airbag sen- Front passenger airbag sors Side airbags Driver airbag Seat belt pretensioners and Driver’s seat belt buckle...
Page 83 1-7. Safety information Your vehicle is equipped with ADVANCED AIRBAGS designed based on the US motor vehicle safety standards (FMVSS208). The airbag sensor assembly (ECU) controls airbag deployment based on infor- mation obtained from the sensors etc. shown in the system compo- nents diagram above.
Page 84 1-7. Safety information ■ SRS airbag deployment conditions (front airbags) ● The SRS front airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approxi- mately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 85 1-7. Safety information ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. ●...
Page 86 1-7. Safety information ■ Types of collisions that may not deploy the SRS side airbags and cur- tain shield airbags The SRS side airbags and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a col- lision to the side of the vehicle body other than the passenger compartment.
Page 87 1-7. Safety information ■ When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ● The front of the vehicle is damaged or...
Page 88 1-7. Safety information CAUTION ■ SRS airbag precautions Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly. The SRS airbags are supplemental devices to be used with the seat belts.
Page 89 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are the safest for infants and children.
Page 90 1-7. Safety information CAUTION ■ SRS airbag precautions ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger. ● Do not drive the vehicle while the driver or passenger has items resting on their knees.
Page 91 Wash off any residue as soon as possible to prevent skin irritation. ● If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer.
Page 92 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 93 1-7. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for the front passenger.
Page 94 1-7. Safety information Conditions and operation of the front passenger occupant classification system ■ Adult “PASSENGER AIR BAG ON” and “PASSENGER “PASSENGER AIR BAG OFF” indicator lights AIR BAG ON” Indicator/ SRS warning light warning light Front passenger’s seat belt reminder light Flashing Front passenger airbag Side airbag on the front...
Page 95 1-7. Safety information ■ Unoccupied “PASSENGER AIR BAG ON” and Not illuminated “PASSENGER AIR BAG OFF” indicator lights Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seats Devices Activated Curtain shield airbag in the front...
Page 96 1-7. Safety information : Never install a rear-facing child restraint system on the front pas- senger seat. A forward-facing child restraint system should only be installed on the front passenger seat when it is unavoidable. (→P. 103) : In case the indicator is not illuminated, consult this manual as for installing the child restraint system properly.
Page 97 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the rear seat should not contact the front seatbacks.
Page 98 1-7. Safety information Child restraint systems A child restraint system for a small child or baby must be properly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of U.S.A. and Canada now require the use of child restraint systems.
Page 99 1-7. Safety information Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child. Rear facing ⎯ Infant seat/convertible seat Forward facing ⎯ Convertible seat Booster seat...
Page 100 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 101 1-7. Safety information CAUTION ■ Child restraint precautions ● Do not use the seat belt extender when installing a child restraint system on the front or rear passenger seat. If installing a child restraint system with the seat belt extender connected to the seat belt, the seat belt will not securely hold the child restraint system, which could cause death or seri- ous injury to the child or other passengers in the event of a sudden stop, sudden swerve or accident.
Page 102 1-7. Safety information Installing child restraints Follow the child restraint system manufacturer's instructions. Firmly secure child restraints to the rear seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Chil- dren) system.
Page 103 1-7. Safety information Installation with LATCH system Rear right seat only: Slide the STEP rear center seat belt to the side to prevent it from getting pinched in the lower anchorage. Type A STEP Widen the gap between the seat cushion and seatback slightly.
Page 104 1-7. Safety information Type B STEP Widen the gap between the seat cushion and seatback slightly. STEP Latch the buckles onto the LATCH anchors. STEP If the child restraint has a top tether strap, the top tether strap should be latched onto tether strap anchors.
Page 105 1-7. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear facing ⎯ Infant seat/convertible seat ■ Place the child seat on the rear STEP seat facing the rear of the vehi- cle. Run the seat belt through the STEP child seat and insert the plate into the buckle.
Page 106 1-7. Safety information While pushing the child seat STEP down into the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 107 1-7. Safety information While pushing the child seat into STEP the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 108 1-7. Safety information Removing a child restraint installed with a seat belt Push the release button and fully retract the seat belt.
Page 109 1-7. Safety information Child restraint systems with a top tether strap Outside Secure the child restraint using a STEP seat belt or the lower anchors, and remove the head restraint. Open the anchor bracket cover, STEP latch the hook onto the anchor bracket and tighten the top tether strap.
Page 110 1-7. Safety information Center Secure the child restraint using a STEP seat belt or the lower anchors, and lock the head restraint in place at the lowest position. Open the anchor bracket cover, STEP latch the hook onto the anchor bracket and tighten the top tether strap.
Page 111 1-7. Safety information CAUTION ■ When installing a booster seat Do not fully extend the shoulder belt to prevent the belt from going to ALR lock mode: (→P. 61) ALR mode causes the belt to tighten only which could cause injury or dis- comfort to the child.
Page 112 1-7. Safety information CAUTION ■ When installing a child restraint system ● When a booster seat is installed, always ensure that the shoulder belt is positioned across the center of the child's shoulder. The belt should be kept away from the child's neck, but not so that it could fall off the child's shoulder.
Page 113 1-7. Safety information...
Page 114 2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. ■ Starting the engine →P. 131, 135 ■ Driving Automatic transmission STEP With the brake pedal depressed, shift the shift lever to D. (→P.
Page 115 2-1. Driving procedures ■ Parking the vehicle Automatic transmission STEP With the shift lever in D, depress the brake pedal. STEP Set the parking brake. (→P. 147) STEP Shift the shift lever to P. (→P. 139) When parking on a hill, if necessary, block the wheels. STEP Vehicles with smart key system: Turn the “ENGINE START STOP”...
Page 116: Tires
2-1. Driving procedures Starting on a steep uphill Automatic transmission STEP Firmly set the parking brake and shift the shift lever to D. STEP Gently depress the accelerator pedal. STEP Release the parking brake. Manual transmission STEP With the parking brake firmly set and the clutch pedal fully depressed, shift the shift lever to 1.
Page 117 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or when- ever the parking brake shoes and/or drum are replaced. Have your Toyota dealer perform the bedding down.
Page 118 If the smell of exhaust is noticed inside the vehicle, open the windows and check that the trunk is closed. Large amounts of exhaust in the vehicle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immedi- ately.
Page 119 2-1. Driving procedures CAUTION ● On vehicles with an automatic transmission, do not shift the shift lever to P while the vehicle is moving. Doing so can damage the transmission and may result in a loss of vehicle control. ● Do not shift the shift lever to R while the vehicle is moving forward.
Page 120 2-1. Driving procedures CAUTION ● Do not drive in excess of the speed limit. Even if the legal speed limit per- mits it, do not drive over 85 mph (140 km/h) unless your vehicle has high- speed capability tires. Driving over 85 mph (140 km/h) may result in tire failure, loss of control and possible injury.
Page 121 2-1. Driving procedures CAUTION ● Avoid revving or racing the engine. Running the engine at high speed while the vehicle is stopped may cause the exhaust system to overheat, which could result in a fire if combustible material is nearby. ■...
Page 122 The exhaust should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
Page 123 2-1. Driving procedures NOTICE ■ When driving the vehicle ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain driving torque. Manual transmission ● Do not shift gears unless the clutch pedal is fully depressed. After shifting, do not release the clutch abruptly.
Page 124 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage can result if the pads are not replaced when needed.
Page 125 2-1. Driving procedures Engine (ignition) switch (vehicles with smart key system) Performing the following operations when carrying the electronic key on your person starts the engine or changes “ENGINE START STOP” switch modes. ■ Starting the engine STEP Check that the parking brake is set. STEP Check that the shift lever is set in P.
Page 126 2-1. Driving procedures ■ Changing “ENGINE START STOP” switch mode Modes can be changed by pressing the “ENGINE START STOP” switch with the brake pedal released. (The mode changes each time the switch is pressed.) OFF* The emergency flashers can be used.
Page 127 ■ When the “ENGINE START STOP” switch indicator flashes in amber The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ Auto power OFF function If the vehicle is left in ACCESSORY mode for more than an hour with the shift lever in P, the “ENGINE START STOP”...
Page 128 2-1. Driving procedures CAUTION ■ When starting the engine Always start the engine while sitting in the driver's seat. Do not depress the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. ■...
Page 129 2-1. Driving procedures Engine (ignition) switch (vehicles without smart key system) ■ Starting the engine Automatic transmission STEP Check that the parking brake is set. STEP Check that the shift lever is set in P. STEP Sit in the driver’s seat and firmly depress the brake pedal. STEP Turn the engine switch to the “START”...
Page 130 2-1. Driving procedures ■ Changing engine switch position “LOCK” The steering wheel is locked and the key can be removed. (Vehicles with an automatic transmission: The key can be removed only when the shift lever is in P.) “ACC” Some electrical components such as the audio system can be used.
Page 131 2-1. Driving procedures ■ Steering lock release When starting the engine, the engine switch may seem stuck in the “LOCK” position. To free it, turn the key while turn- ing the steering wheel slightly in either direction. ■ If the engine does not start The engine immobilizer system may not have been deactivated.
Page 132 2-1. Driving procedures NOTICE ■ To prevent battery discharge Do not leave the key in the “ACC” or “ON” position for long periods if the engine is not running. ■ When starting the engine ● 2.4 L 4-cylinder (2AZ-FE) engine: Do not crank for more than 30 seconds at a time.
Page 133 2-1. Driving procedures ∗ Automatic transmission Select a shift position appropriate for the driving conditions. ■ Shifting the shift lever Standard type Vehicles with smart key system: While the “ENGINE START STOP” switch is in IGNITION ON mode, depress the brake pedal and move the shift lever. Vehicles without smart key system: While the engine switch is in “ON”...
Page 134 2-1. Driving procedures Multi-mode type While the engine switch is in “ON” position, depress the brake pedal and move the shift lever.
Page 135 2-1. Driving procedures ■ Shift position uses Function Shift position Standard type Multi-mode type Parking the vehicle or starting the engine Reversing Neutral Normal driving S mode driving (→P. 142) Position for engine braking Position for more powerful engine braking Position for maximum engine braking : Shifting to the D position allows the system to select a gear suitable...
Page 136 2-1. Driving procedures Changing shift ranges in S mode (multi-mode type) Shift the shift lever to the S position and operate the shift lever. Upshifting Downshifting The initial shift range in S mode is set automatically to 5 or 4. How- ever, the initial shift range may be set to 3 if AI-SHIFT has operated while the shift lever was in the D position.
Page 137 2-1. Driving procedures ■ Shift ranges and their functions Shift range Function A gear between 1 and 5 is automatically selected according to vehicle speed and driving conditions. A gear between 1 and 4 is automatically selected according to vehicle speed and driving conditions. A gear between 1 and 3 is automatically selected according to vehicle speed and driving conditions.
Page 138 If the “S” indicator does not come on even after shifting the shift lever to S (multi-mode type) This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the vehicle will operate as if the shift lever is in D.) ■...
Page 139 2-1. Driving procedures ∗ Manual transmission ■ Shifting the shift lever Fully depress the clutch pedal before operating shift lever, and then release the clutch pedal slowly. ■ Maximum allowable speeds Observe the following maximum allowable speeds in each gear when maxi- mum acceleration is necessary.
Page 140 2-1. Driving procedures Turn signal lever Right turn Left turn Move and hold the lever partway to signal a lane change. The right hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change.
Page 141 2-1. Driving procedures Parking brake U.S.A. Canada Sets the parking brake Fully set the parking brake while depressing the brake pedal. Releases the parking brake Slightly raise the lever and lower it completely while pressing the but- ton. ■ Usage in winter time See “Winter driving tips”...
Page 142 2-1. Driving procedures Horn To sound the horn, press on or close to the mark. ■ After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (→P.
Page 143 2-2. Instrument cluster Gauges and meters Type A Type B...
Page 144 2-2. Instrument cluster Tachometer Displays the engine speed in revolutions per minute. Speedometer Displays the vehicle speed. Fuel gauge Displays the quantity of fuel remaining in the tank. Low fuel level warning light →P. 426 Odometer/trip meter/instrument panel light control and trip meter reset button Switches between odometer and trip meter displays.
Page 145 2-2. Instrument cluster Instrument panel light control The brightness of the instrument panel lights can be adjusted. Darker Brighter NOTICE ■ To prevent damage to the engine and its components ● Do not let the indicator needle of the tachometer enter the red zone, which indicates the maximum engine speed.
Page 146 2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. ■ Instrument cluster Type A Type B...
Page 147 2-2. Instrument cluster ■ Center panel...
Page 148 There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer for details. : The light flashes to indicate that the system is operating.
Page 149 Have the vehicle inspected by your Toyota dealer immediately if this occurs.
Page 150 2-2. Instrument cluster Multi-information display The multi-information display presents the driver with a variety of driving-related data, including the outside temperature. ● Outside temperature dis- play Indicates the outside tempera- ture. ● Trip information Displays driving range, fuel consumption and other cruis- ing-related information.
Page 151 2-2. Instrument cluster ● Average fuel consumption Displays the average fuel consumption since the function was reset. • The function can be reset by pressing the display button for longer than one second when the aver- age fuel consumption is displayed. •...
Page 152 2-2. Instrument cluster ● Elapsed time Displays the elapsed time since the engine was started or since the function was reset. The function can be reset by pressing the display but- ton for longer than one second when the elapsed time is displayed.
Page 153 2-3. Operating the lights and wipers Headlight switch Type A daytime run- ning lights turn on. side marker, parking, tail, license plate, daytime run- ning lights instrument panel lights turn on. The headlights and all lights listed above (except daytime run- ning lights) turn on.
Page 154 2-3. Operating the lights and wipers Type B daytime run- ning lights turn on. side marker, parking, tail, license plate, daytime run- ning lights instrument panel lights turn on. The headlights and all lights listed above (except daytime run- ning lights) turn on. Turning on the high beam headlights With the headlights on, push the lever forward to turn on the...
Page 155 2-3. Operating the lights and wipers ■ Daytime running light system ● To make your vehicle more visible to other drivers, the headlights turn on automatically whenever the engine is started and the parking brake is released. ● Compared to turning on the headlights, the daytime running light system offers greater durability and consumes less electricity, so it can help improve fuel economy.
Page 156 2-3. Operating the lights and wipers NOTICE ■ To prevent battery discharge Do not leave the lights on longer than necessary when the engine is not run- ning.
Page 157 2-3. Operating the lights and wipers ∗ Fog light switch The fog lights improve visibility in difficult driving conditions, such as in rain or fog. They can be turned on only when the headlights are on low beam. Type A Front fog lights on ∗...
Page 158 2-3. Operating the lights and wipers Type B Front fog lights on...
Page 159 2-3. Operating the lights and wipers Windshield wipers and washer Wiper intervals can be adjusted for intermittent operation. Type A Intermittent wind- shield wiper opera- tion speed wind- shield wiper opera- tion High speed wind- shield wiper opera- tion Temporary operation Increases the intermittent windshield wiper frequency* Decreases the intermittent...
Page 160 2-3. Operating the lights and wipers Wash/wipe operation Wipers operate automatically. Type B Intermittent wind- shield wiper opera- tion speed wind- shield wiper opera- tion High speed wind- shield wiper opera- tion Temporary operation Increases the intermittent windshield wiper frequency* Decreases the intermittent windshield wiper frequency* *: The interval adjuster may not...
Page 161 Damage to the washer fluid pump may be caused if the lever is pulled toward you and held continually. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged.
Page 162 2-4. Using other driving systems ∗ Cruise control Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicators Cruise control switch ■ Setting the vehicle speed STEP Press the “ON-OFF” button to activate the cruise control. Cruise control indicator will come on.
Page 163 2-4. Using other driving systems ■ Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 164 2-4. Using other driving systems ■ Canceling and resuming the constant speed control Pulling the lever toward you cancels the constant speed control. The speed setting is also can- celed when the brakes are applied or the clutch pedal (manual transmission only) is depressed.
Page 165 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. CAUTION ■...
Page 166 2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ■...
Page 167 2-4. Using other driving systems To disable TRAC and/or VSC If the vehicle gets stuck in fresh snow or mud, TRAC and VSC may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it. ■...
Page 168 • The brake pedal may move down slightly after ABS is activated. ■ If the slip indicator light comes on There is a malfunction in the TRAC and VSC systems. Contact your Toyota dealer and have your Toyota inspected. ■...
Page 169 In addition, make sure that the tires are inflated to the recom- mended tire pressure level. The ABS and VSC system will not function correctly if different tires are fitted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause the system to malfunction.
Page 170 2-5. Driving information Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load. ● Stow cargo and luggage in the trunk whenever possible. Be sure all items are secured in place. ● Be careful to keep the vehicle level. Placing the weight as far for- ward as possible helps maintain vehicle balance.
Page 171 2-5. Driving information (6)If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. (→P. 185) Calculation formula for your vehicle Cargo capacity Total load capacity (vehicle...
Page 172 2-5. Driving information As shown in the above example, if the number of occupants increases, the cargo and luggage load will be reduced by an amount that equals the increased weight due to the additional occupants. In other words, if an increase in the number of occupants causes an excess of the total load capacity (combined weight of occupants plus cargo and luggage load), you must reduce the cargo and luggage on your vehicle.
Page 173 2-5. Driving information CAUTION ■ Storage precautions Observe the following precautions. Failing to do so may result in death or serious injury. ● To prevent cargo and luggage from sliding forward during braking, do not stack anything in the enlarged trunk. Keep cargo and luggage low, as close to the floor as possible.
Page 174 150 lb. (68 kg) per person. ■ Trailer weight rating 2.4 L 4-cylinder (2AZ-FE) engine: →P. 189, 470 1.8 L 4-cylinder (2ZR-FE) engine: Toyota does not recommend towing a trailer with your vehicle. ■ Cargo capacity Cargo capacity may increase or decrease depending on the weight and the number of occupants.
Page 175 2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. ■ Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tem- peratures.
Page 176 2-5. Driving information ■ When driving the vehicle Accelerate the vehicle slowly and drive at a reduced speed suit- able to road conditions. ■ When parking the vehicle Park the vehicle and move the shift lever to P (automatic trans- mission), 1 or R (manual transmission) without setting the park- ing brake.
Page 177 2-5. Driving information Regulations on the use of snow chains ● Regulations regarding the use of tire chains vary according to loca- tion and type of road. Always check local regulations before install- ing chains. ● Install the chains on the front tires. ●...
Page 178 NOTICE ■ Repairing or replacing snow tires Request repairs of and obtain replacement snow tires from Toyota dealers or legitimate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 179 To tow a trailer safely, use extreme care and drive the vehicle in accordance with your trailer’s characteristics and operating condi- tions. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Contact your Toyota dealer for further information about additional requirements such as towing kits, etc.
Page 180 2-5. Driving information ■ GVWR (Gross Vehicle Weight Rating) The maximum allowable gross vehicle weight. The gross vehicle weight is the total weight of the vehicle. When towing a trailer, it is the sum of the vehicle weight (including the occupants, cargo and any optional equipment installed on the vehicle) and the tongue weight.
Page 181 2-5. Driving information ■ TWR (Trailer Weight Rating) The maximum allowable gross (With brakes) trailer weight. The gross trailer weight is the sum of the trailer weight and the weight of the cargo in the trailer. TWR is calculated assuming base vehicle with one driver, one front passenger, towing package (if available), hitch and hitch sys-...
Page 182 2-5. Driving information ■ Tongue Weight The load placed on the trailer hitch ball. (→P. 190) Weight limits ● The gross trailer weight must never exceed 1500 lbs (680 kg). Automatic transmission ● The gross combination weight must never exceed 4797 lbs (2176 kg).
Page 183 2-5. Driving information GCWR, TWR and Unbraked TWR Confirm that the gross trailer weight, gross combination weight, gross vehicle weight, gross axle weight and tongue weight are all within the limits. ■ GCWR Automatic transmission 4797 lb. (2176 kg) Manual transmission 4732 lb.
Page 184 2-5. Driving information Trailer Tongue Weight ● A recommended tongue weight varies in accordance with the types of trailers or towing as described below. ● To ensure the recommended values shown below, the trailer must be loaded by referring to the following instructions. •...
Page 185 Toyota hitch/bracket for your vehicle. For details, contact your Toyota dealer. ● If you wish to install a trailer hitch, contact your Toyota dealer. ● Use only a hitch that conforms to the gross trailer weight require- ment of your vehicle.
Page 186 ● Speed limits for towing a trailer vary by state or province. Do not exceed the posted towing speed limit. ● Toyota recommends that the vehicle-trailer speed limit is 65 mph (104 km/h) on a flat, straight, dry road. Do not exceed this limit, the posted towing speed limit or the speed limit for your trailer as set forth in your trailer owner’s manual, whichever is lowest.
Page 187 2-5. Driving information ● Avoid jerky starts or sudden acceleration. ● Avoid jerky steering and sharp turns, and slow down before mak- ing a turn. ● Note that when making a turn, the trailer wheels will be closer than the vehicle wheels to the inside of the turn. Compensate by making a wider than normal turning radius.
Page 188 2-5. Driving information ● Due to the added load of the trailer, your vehicle’s engine may overheat on hot days (at temperatures over 85°F [30°C]) when driving up a long or steep grade. If the engine coolant temperature gauge indicates overheating, immediately turn off the air condition- ing (if in use), pull your vehicle off the road and stop in a safe spot.
Page 189 2-5. Driving information ■ Matching trailer ball height to trailer coupler height No matter which class of tow hitch applies, for a more safe trailer hookup, the trailer ball setup must be the proper height for the coupler on the trailer. Coupler Trailer ball ■...
Page 190 Break-in schedule If your vehicle is new or equipped with any new power train components (such as an engine, transmission, differential or wheel bearing), Toyota rec- ommends that you do not tow a trailer until the vehicle has been driven for over 500 miles (800 km).
Page 191 2-5. Driving information ■ If trailer sway occurs One or more factors (crosswinds, passing vehicles, rough roads, etc.) can adversely affect handling of your vehicle and trailer, causing instability. ● If trailer swaying occurs: • Firmly grip the steering wheel. Steer straight ahead. Do not try to control trailer swaying by turning the steering wheel.
Page 192 2-5. Driving information CAUTION ■ To avoid accident or injury ● Do not exceed the TWR, unbraked TWR, GCWR, GVWR or GAWR. ● Adjust the tongue weight within the appropriate range. Place heavier loads as close to the trailer axle as possible. ●...
Page 193 NOTICE ■ When installing a trailer hitch Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. ■ Do not directly splice trailer lights Do not directly splice trailer lights.
Page 194 Toyota also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicycle, etc. Your Toyota is not designed for trailer towing or for the use of tow hitch mounted carriers.
Page 195 2-5. Driving information Dinghy towing (automatic transmission) Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with four wheels on the ground.
Page 196 2-5. Driving information Dinghy towing (manual transmission) Your vehicle can be dinghy towed in a forward direction (with 4 wheels on the ground) behind a motor home. Towing your vehicle with 4 wheels on the ground To prevent damage to your vehicle, perform the following procedures before towing.
Page 197 2-5. Driving information NOTICE ■ Dinghy towing direction Do not tow the vehicle backwards. Doing so may cause serious damage. ■ To prevent the steering from locking Ensure the engine switch is in the “ACC” position.
Page 198 3-1. Using the air conditioning system and defogger ∗ Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Temperature control Automatic mode Windshield defogger Air conditioning ON/OFF switch Air intake mode switch Fan speed Temperature setting display Fan speed display...
Page 199 3-1. Using the air conditioning system and defogger Adjusting the settings ■ Adjusting the temperature setting Press “∧” to increase the temperature and “∨” to decrease the tem- perature on ■ Adjusting the fan speed Press “∧” (increase) or “∨” (decrease) on The fan speed is shown on the display.
Page 200 3-1. Using the air conditioning system and defogger Air flows to the upper body and feet. : Some models Mainly air flows to the feet. : Some models Air flows to the feet and the windshield defogger operates. Recirculated air mode will auto- matically switch to outside air mode.
Page 201 3-1. Using the air conditioning system and defogger Defogging the windshield Defogging The air conditioning system oper- ates automatically. Recirculated air mode will auto- matically switch to outside air mode. It is not possible to return to recirculated air mode when the switch is on.
Page 202 3-1. Using the air conditioning system and defogger ■ Using the automatic mode Fan speed is adjusted automatically in accordance with the temperature set- ting and ambient conditions. As a result, the following may occur. ● Immediately after is pressed, the fan may stop for a while until warm or cool air is ready to flow.
Page 203 3-1. Using the air conditioning system and defogger ■ Air conditioning odors ● During use, various odors from inside and outside the vehicle may enter into and accumulate in the air conditioning system. This may then cause odor to be emitted from the vents. ●...
Page 204 3-1. Using the air conditioning system and defogger ∗ Manual air conditioning system Heater Air outlet selection dial Temperature control dial Fan speed control dial Air intake mode switch ∗ : If equipped...
Page 205 3-1. Using the air conditioning system and defogger Air conditioning system Air outlet selection dial Temperature control dial Fan speed control dial Air intake mode switch Air conditioning ON/OFF switch Adjusting the settings ■ Adjusting the temperature setting (heater) Turn the temperature control dial clockwise to increase the temper- ature.
Page 206 3-1. Using the air conditioning system and defogger ■ Adjusting the fan speed Turn the fan speed control dial clockwise (increase) or counter- clockwise (decrease). Set the dial to “0” to turn the fan off. ■ Selecting the air outlets Set the air outlet selection dial to an appropriate position.
Page 207 3-1. Using the air conditioning system and defogger Mainly air flows to the feet. : Some models Air flows to the feet and the windshield defogger operates. The air intake is automatically switched to outside air mode. It is not possible to return to recircu- lated air mode when the switch is : Some models Air flows to the windshield and...
Page 208 3-1. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets Center outlets Direct air flow to the left or right, up or down. Right and left side outlets Direct air flow to the left or right, up or down.
Page 209 3-1. Using the air conditioning system and defogger ■ For quick cooling (vehicles with air conditioning system) Turn the temperature control dial to the “MAX A/C” position and select the recirculated air mode. ■ For quick clearing of the windshield and side windows (vehicles with air conditioning system) Press to turn the air conditioning on.
Page 210 3-1. Using the air conditioning system and defogger CAUTION ■ To prevent the windshield from fogging up Do not set the air outlet selection dial to during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 211 3-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers Clear the rear window using the defogger. Vehicles with automatic air conditioning system On/off The defoggers will automati- cally turn off after approxi- mately 15 minutes. Vehicles with manual air conditioning system On/off The defoggers will automati-...
Page 212 3-2. Using the audio system Audio system types Without Display Audio system Type A: CD player and AM/FM radio Type B: CD player and AM/FM radio...
Page 213 3-2. Using the audio system Title Page Using the radio P. 233 Using the CD player P. 237 Playing back MP3 and WMA discs P. 244 Operating an iPod P. 253 Operating a USB memory P. 262 Optimal use of the audio system P.
Page 214 3-2. Using the audio system Type D...
Page 215 3-2. Using the audio system ■ Using cellular phones Interference may be heard through the audio system's speakers if a cellular phone is being used inside or close to the vehicle while the audio system is operating. ® ■ About Bluetooth The Bluetooth wordmark and logo are owned by Bluetooth SIG.
Page 216 3-2. Using the audio system CAUTION ■ U.S.A. and Canada (type A: without Display Audio system) ● Part 15 of the FCC Rules FCC Warning: Any unauthorized changes or modifications to this equipment will void the user’s authority to operate this device. This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
Page 217 3-2. Using the audio system CAUTION ■ U.S.A. (type B: without Display Audio system) FCC ID: ACJ932PTA184 FCC WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
Page 218 3-2. Using the audio system CAUTION ■ U.S.A. (type C: with Display Audio system) This device complies with Part 15 of FCC Rules and Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device.
Page 219 3-2. Using the audio system CAUTION ■ U.S.A. (type D: with Display Audio system) FCC ID: ACJ932CQ-US70G0 This device complies with Part 15 of FCC Rules and Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device.
Page 220 3-2. Using the audio system CAUTION ● Laser products • Do not take this unit apart or attempt to make any changes yourself. This is an intricate unit that uses a laser pickup to retrieve information from the surface of compact discs. The laser is carefully shielded so that its rays remain inside the cabinet.
Page 221 3-2. Using the audio system CAUTION ■ Canada (type C: with Display Audio system) This device complies with Part 15 of FCC Rules and Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device.
Page 222 3-2. Using the audio system CAUTION ■ Canada (type B and type D) This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device.
Page 223 3-2. Using the audio system CAUTION This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment and meets RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low levels of RF energy that it deemed to comply without maximum permissive exposure evaluation (MPE).
Page 224 3-2. Using the audio system NOTICE ■ To prevent battery discharge Do not leave the audio system on longer than necessary when the engine is off. ■ To avoid damaging the audio system Take care not to spill drinks or other fluids over the audio system.
Page 225 3-2. Using the audio system Using the radio Type A Power Volume Adjusting the frequency Station selector Displays text message Scanning for receivable stations Seeking the frequency AM/FM mode buttons Type B Adjusting the Power Volume frequency or selecting items Station selector Seeking the frequency...
Page 226 3-2. Using the audio system Setting station presets Type A ∧ STEP Search for desired stations by turning or pressing “ ” or “∨” on STEP Press and hold a button (from ) until you hear a beep. Type B ∧...
Page 227 3-2. Using the audio system Switching the display Type A Press Each time is pressed, the display changes in the following order: Title (song/program title) → Name (artist name/feature)/Title (song/pro- gram title). Type B Press If the text continues past the end of the display, “ ”...
Page 228 3-2. Using the audio system ■ Certifications for the radio tuner This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 229 3-2. Using the audio system Using the CD player Type A Power Volume Displays text message CD eject Playback Repeat play Selecting a track, fast-forwarding Random playback and rewinding Search playback Type B Selecting a Power Volume CD eject Random playback track or displays track list Reverse...
Page 230 3-2. Using the audio system Loading CDs Insert a CD. Ejecting CDs Press and remove the CD. Selecting a track Type A ∧ Press “ ” to move up or “∨” to move down using until the desired track number is displayed. Type B ∧...
Page 231 3-2. Using the audio system Selecting a track from a track list (type B) STEP Press The track list will be displayed. STEP Turn and press to select a track. To return to the previous display, press (BACK). Scanning tracks STEP Press The first ten seconds of each track will be played.
Page 232 3-2. Using the audio system Switching the display Type A Press Each time is pressed, the display changes in the following order: Track no./Elapsed time → CD title → Track name. Type B Press Track title, Artist name and Disc title are shown on the display. To return to the previous display, press (BACK).
Page 233 “WAIT” or “PLEASE WAIT”: Operation has stopped due to a high tempera- ture inside the player. Wait for a while and then press . If the CD still cannot be played back, contact your Toyota dealer. ■ Discs that can be used Discs with the marks shown below can be used.
Page 234 3-2. Using the audio system NOTICE ■ CDs and adapters that cannot be used Do not use the following types of CDs, 3 in. (8 cm) CD adapters or Dual Discs. Doing so may damage the CD player and/or the CD insert/eject function. ●...
Page 235 3-2. Using the audio system NOTICE ■ CD player precautions Failure to follow the precautions below may result in serious damage to the CDs or the player itself. ● Do not insert anything other than CDs into the CD slot. ●...
Page 236 3-2. Using the audio system Playing back MP3 and WMA discs Type A Power Volume Selecting a folder Disc eject Selecting a file Playback Search playback Repeat play Random playback Selecting a file, Displays text message fast-forwarding and rewinding Type B Selecting a file Power Volume...
Page 237 3-2. Using the audio system Loading and ejecting MP3 and WMA discs →P. 238 Selecting and scanning a folder Type A ■ Selecting folders one at a time Press “∧” or “∨” on to select the desired folder. ■ Scanning the first file of all the folders STEP Press and hold until you hear a beep.
Page 238 3-2. Using the audio system ■ Returning to the first folder Press and hold ) until you hear a beep. ■ Scanning a folder STEP Press and hold until you hear a beep. The first 10 seconds of the first file in the each folder will be played. STEP When the desired folder is reached, press again.
Page 239 3-2. Using the audio system Random playback Type A ■ Playing files from a particular folder in random order Press (RAND). To cancel, press the button once more. ■ Playing all of the files on a disc in random order Press and hold (RAND) until you hear a beep.
Page 240 3-2. Using the audio system Switching the display Type A Press Each time is pressed, the display changes in the following order: Folder no./File no./Elapsed time → Folder name → File name → Album title (MP3 only) → Track title → Artist name. Type B Press Track title, Artist name and Album title (MP3 only) are shown on the dis-...
Page 241 “WAIT” or “PLEASE WAIT” (type A): Operation has stopped due to a high temperature inside the player. Wait for a while and then press Contact your Toyota dealer if the CD still cannot be played. “ERROR” (type B): This indicates a problem either in the CD or inside the player.
Page 242 3-2. Using the audio system ■ MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
Page 243 3-2. Using the audio system ● Compatible disc formats The following disc formats can be used. • Disc formats: CD-ROM Mode 1 and Mode 2 CD-ROM XA Mode 2, Form 1 and Form 2 • File formats: ISO9660 Level 1, Level 2, (Romeo, Joliet) MP3 and WMA files written in any format other than those listed above may not play correctly, and their file names and folder names may not be displayed correctly.
Page 244 3-2. Using the audio system ● Extensions If the file extensions .mp3 and .wma are used for files other than MP3 and WMA files, they will be mistakenly recognized and played as MP3 and WMA files. This may result in large amounts of interference and damage to the speakers.
Page 245 3-2. Using the audio system ∗ Operating an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. ■ Connecting an iPod Open the cover and connect STEP an iPod using an iPod cable. Turn on the power of the iPod if it is not turned on.
Page 246 3-2. Using the audio system ■ Control panel Adjusting sound quality and volume balance Power Volume Shuffle playback Selecting an iPod Repeat play iPod menu menu/song or mode Reverse displays song list Fast-forward Selecting a track Playback Displays text message...
Page 247 3-2. Using the audio system Selecting a play mode STEP Press (MENU) to select iPod menu mode. STEP Turning clockwise changes the play mode in the fol- lowing order: “Playlists”→“Artists”→“Albums”→“Songs”→“Podcasts”→“Genres” →“Composers”→“Audiobooks” STEP Press to select the desired play mode. ■ Play mode list First Second...
Page 248 3-2. Using the audio system ■ Selecting a list STEP Turn to display the first selection list. STEP Press to select the desired item. Pressing the knob changes to the second selection list. STEP Repeat the same procedure to select the desired item. To return to the previous selection list, press (BACK).
Page 249 3-2. Using the audio system Fast-forwarding and reversing songs To fast-forward or reverse, press ) or Shuffle playback Pressing (RDM) changes modes in the following order: Track shuffle → Album shuffle → Off Repeat play Press (RPT) To cancel, press (RPT) again.
Page 250 3-2. Using the audio system ■ About iPod ● “Made for iPod” and “Made for iPhone” mean that an electronic acces- sory has been designed to connect specifically to iPod, or iPhone, respectively, and has been certified by the developer to meet Apple per- formance standards.
Page 251 3-2. Using the audio system ■ Error messages “iPod ERROR”: This indicates that the data in the iPod cannot be read. “ERROR 3”: This indicates that the iPod may be malfunctioning. “ERROR 4”: This indicates that an overcurrent error has occurred. “ERROR 5”: This indicates that an iPod communication error has occurred.
Page 252 3-2. Using the audio system ■ Compatible models ® ® ® ® ® The following iPod , iPod nano , iPod classic , iPod touch and iPhone devices can be used with this system. ● Made for • iPod touch (4th generation) •...
Page 253 3-2. Using the audio system NOTICE ■ To prevent damage to iPod ● Do not leave iPod in the vehicle. The temperature inside the vehicle may become high, resulting in damage to the iPod. ● Do not push down on or apply unnecessary pressure to the iPod while it is connected as this may damage the iPod or its terminal.
Page 254 3-2. Using the audio system ∗ Operating a USB memory Connecting a USB memory enables you to enjoy music from the vehicle speakers. ■ Connecting a USB memory Open the cover and connect a STEP USB memory. Turn on the power of the USB memory if it is not turned on.
Page 255 3-2. Using the audio system ■ Control panel Power Volume Random playback Selecting a file Repeat play or displays folder list Selecting a track Playback Search playback Selecting a folder, fast-forwarding and rewinding Displays text message...
Page 256 3-2. Using the audio system Selecting a folder ■ Selecting folders one at a time To select the desired folder, press ) or ■ Selecting a folder and file from a folder list STEP Press The folder list will be displayed. STEP Turn and press to select a folder and a file.
Page 257 3-2. Using the audio system Scanning files STEP Press The first 10 seconds of all files in the folder will be played. STEP When the desired file is reached, press again. Fast-forwarding and reversing files →P. 257 Random playback Pressing (RDM) changes modes in the following order: Folder random →...
Page 258 3-2. Using the audio system ■ USB memory functions ● Depending on the USB memory that is connected to the system, the device itself may not be operable and certain functions may not be avail- able. If the device is inoperable or a function is unavailable due to a mal- function (as opposed to a system specification), disconnecting the device and reconnecting it once again may resolve the problem.
Page 259 3-2. Using the audio system ● MP3 and WMA files MP3 (MPEG Audio LAYER 3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
Page 260 3-2. Using the audio system ● ID3 and WMA tags ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3, 2.4 ID3 tags.
Page 261 3-2. Using the audio system NOTICE ■ To prevent damage to USB memory ● Do not leave USB memory in the vehicle. The temperature inside the vehi- cle may become high, resulting in damage to the player. ● Do not push down on or apply unnecessary pressure to the USB memory while it is connected as this may damage the USB memory or its terminal.
Page 262 3-2. Using the audio system Optimal use of the audio system Type A Adjusting the sound quality and ASL Type B Menu button Adjusting the sound quality and ASL...
Page 263 3-2. Using the audio system Using the audio control function ■ Changing sound quality modes Type A Pressing selects the mode to be changed in the following order. “BAS”→“TRE”→“FAD”→“BAL”→“ASL” Type B STEP Press STEP Turn to select “Sound Setting”. STEP Press STEP Turn...
Page 264 3-2. Using the audio system Type A Mode Sound qual- Turn to the Turn to the Level displayed ity mode left right “BAS” Bass* -5 to 5 High “TRE” Treble* -5 to 5 Front/rear Shifts to “FAD” volume R7 to F7 Shifts to rear front balance...
Page 265 3-2. Using the audio system ■ Adjusting the Automatic Sound Levelizer (ASL) When “ASL” is selected, turning to the right changes the amount of “ASL” in the order of “LOW”, “MID” and “HIGH”. Turning to the left turns “ASL” off. ASL automatically adjusts the volume and tone quality according to vehi- cle speed.
Page 266 3-2. Using the audio system Using the AUX port This port can be used to connect a portable audio device and listen to it through the vehicle’s speakers. STEP Open the cover and connect the portable audio device. Type A Type B...
Page 267 3-2. Using the audio system Type A Press STEP Type B Press STEP ■ Operating portable audio devices connected to the audio system The volume can be adjusted using the vehicle's audio controls. All other adjustments must be made on the portable audio device itself. ■...
Page 268 3-2. Using the audio system ∗ Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Type A Volume Radio mode: Selects radio stations CD mode: Selects tracks and files (MP3 and WMA) iPod mode: Selects songs ∗...
Page 269 3-2. Using the audio system Type B Volume Radio mode: Selects radio stations CD mode: Selects tracks and files (MP3 and WMA) iPod mode: Selects songs ∗ USB memory mode Selects folders and files ∗ ® Bluetooth audio mode Selects an album and tracks Turns the power on, selects audio source...
Page 270 3-2. Using the audio system Adjusting the volume Press “+” on to increase the volume and “-” to decrease the volume. Press and hold to continue increasing or decreasing the volume. Silencing a sound Press and hold To cancel, press and hold again.
Page 271 3-2. Using the audio system Selecting a track/file or song STEP Press to select CD, iPod, USB memory or ® Bluetooth audio mode. STEP Press “∧” or “∨” on to select the desired track/file or song. Selecting a folder or album STEP Press to select CD, USB memory or...
Page 272 ® 3-3. Using the Bluetooth audio system ® ∗ Bluetooth audio/phone ■ ® Bluetooth audio ® The Bluetooth audio system enables you to enjoy music played on a portable digital audio player (portable player) from the vehi- cle speakers via wireless communication. ®...
Page 273 ® 3-3. Using the Bluetooth audio system ■ When transferring ownership of the vehicle Be sure to initialize the system to prevent personal data from being improp- erly accessed. (→P. 301) ■ ® About Bluetooth Bluetooth is a registered trademark of Bluetooth SIG.
Page 274 ® 3-3. Using the Bluetooth audio system NOTICE ■ ® To prevent damage to Bluetooth device ® Do not leave Bluetooth device in the vehicle. The temperature inside the vehicle may become high, resulting in damage to the device.
Page 275 ® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio/phone ■ Audio unit ® Bluetooth connection con- dition If “BT” is not displayed, the ® Bluetooth audio/phone cannot be used. Display A message, name, number, etc. is displayed. Lower-case characters and special characters cannot be displayed.
Page 276 ® 3-3. Using the Bluetooth audio system ■ Steering wheel switches →P. 276 ■ Microphone Vehicles with moon roof Vehicles without moon roof...
Page 277 ® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio/phone for the first time ® Before using the Bluetooth audio/phone, it is necessary to register a ® Bluetooth device in the system. Follow the procedure below to reg- ister (pair) a device: STEP Press...
Page 278 ® 3-3. Using the Bluetooth audio system ® Menu list of the Bluetooth audio/phone First menu Second menu Third menu Operation details Registering a “BT Pairing” ® Bluetooth device Listing the registered “List Phone” cellular phones Listing the registered “List Audio” portable players “Passkey”...
Page 279 ® 3-3. Using the Bluetooth audio system First menu Second menu Third menu Operation details “Add contacts” Adding a new number Registering a speed “Add SD” dial “Delete Call Deleting a number History” stored in the call history “Phonebook” Deleting a number “Delete stored in the contacts”...
Page 280 ® 3-3. Using the Bluetooth audio system ® Operating a Bluetooth enabled portable player Power Volume Selecting an album, fast-forwarding and rewinding Repeat play Random playback Selecting items Selecting a track Playback Search playback Playback/Pause Displays text message Selecting an album Press ) or ) to select the desired album.
Page 281 ® 3-3. Using the Bluetooth audio system Scanning tracks STEP Press The first 10 seconds of all tracks in the album will be played. STEP When the desired track is reached, press again. Playing and pausing tracks Press ) to play or pause a track. Fast-forwarding and reversing tracks →P.
Page 282 ® 3-3. Using the Bluetooth audio system ® ■ Bluetooth audio system functions Depending on the portable player that is connected to the system, certain functions may not be available.
Page 283 3-4. Using the hands-free phone system (for cellular phone) Making a phone call To enter the “PHONE” mode, press the off-hook switch. ■ Making a phone call ● Dialing by selecting a name ● Speed dialing ● Dialing by entering the number ●...
Page 284 3-4. Using the hands-free phone system (for cellular phone) Dialing by selecting a name STEP Select “Phonebook” using STEP Select the desired name using and press the off-hook switch. By pressing (Add S. Dial) and one of the speed dial buttons (from ) while the desired name is selected, it can be registered as a speed dial.
Page 285 3-4. Using the hands-free phone system (for cellular phone) Dialing from call histories STEP Select “All calls”, “Missed calls”, “Incoming calls” or “Outgoing calls” using STEP Select a desired number using and press the off-hook switch. The following operations can be performed: ●...
Page 286 3-4. Using the hands-free phone system (for cellular phone) Operations during a call ● Transferring a call A call can be transferred between the cellular phone and system while dialing, receiving a call, or during a call. Use one of the fol- lowing methods: a.
Page 287 3-4. Using the hands-free phone system (for cellular phone) Adjusting the ringtone volume when receiving a call Change the ringtone volume using To decrease the volume: Turn counterclockwise. To increase the volume: Turn clockwise. ■ When talking on the phone ●...
Page 288 3-4. Using the hands-free phone system (for cellular phone) Using the “SET UP” menu (“Bluetooth” menu) ® Registering a Bluetooth device in the system allows the system to function. The following functions can be used for registered devices: ■ Functions and operation procedures STEP Press and select “Bluetooth”...
Page 289 3-4. Using the hands-free phone system (for cellular phone) Registering a portable player Select “Pairing” using , and perform the procedure for regis- tering a portable player. (→P. 285) Listing the registered cellular phones Select “List Phone” using . The list of registered cellular phones will be displayed.
Page 290 3-4. Using the hands-free phone system (for cellular phone) Listing the registered portable players Select “List Audio” using . The list of registered portable play- ers will be displayed. ● Connecting the registered portable player to the audio system STEP Select the name of the portable player to be connected using STEP...
Page 291 3-4. Using the hands-free phone system (for cellular phone) Changing the passkey STEP Select “Passkey” using STEP Select a 4 to 8-digit passkey using Input the number 1 digit at a time. STEP When the entire number to be registered as a passkey has been input, press again.
Page 292 3-4. Using the hands-free phone system (for cellular phone) Displaying the device status Select “Bluetooth info” using ● Displaying the device name Select “Device Name” using ● Displaying the device address Select “Device Address” using Setting the automatic connection confirmation display to on or off If the “Display Setting”...
Page 293 3-4. Using the hands-free phone system (for cellular phone) Initialization Select “Initialize” using ● Initializing the sound settings Select “Sound setting” using and press (YES). For details about sound settings (→P. 270) ● Initializing the device information Select “Car Device Info” using and press (YES).
Page 294 3-4. Using the hands-free phone system (for cellular phone) Using the “SET UP” menu (“Phone” menu) ■ Functions and operation procedures To enter the menu of each function, press and follow the steps below using ● Adding a new phone number 1.
Page 295 3-4. Using the hands-free phone system (for cellular phone) Adding a new phone number Select “Add contacts” using ● Transferring all contacts from the cellular phone Select “Overwrite all contacts” using and press (YES). ● Transferring one contact from the cellular phone Select “Add one contact”...
Page 296 3-4. Using the hands-free phone system (for cellular phone) Deleting call histories Select “Delete Call History” using ● Deleting outgoing call history STEP Select “Outgoing Calls” using STEP Select the desired phone number using and press (YES). To delete all outgoing call history data, press (ALL) and then press (YES).
Page 297 3-4. Using the hands-free phone system (for cellular phone) ● Deleting missed call history STEP Select “Missed Calls” using STEP Select the desired phone number using and press (YES). To delete all missed call history data, press (ALL) and then press (YES).
Page 298 3-4. Using the hands-free phone system (for cellular phone) Deleting a registered phone number STEP Select “Delete contacts” using STEP Select the desired phone number using and press (YES). To delete all of the registered phone numbers, select “All delete” using and press (YES).
Page 299 3-4. Using the hands-free phone system (for cellular phone) Setting ringtone volume STEP Select “Ringtone Volume” using STEP Change the ringtone volume. To decrease the volume: Turn counterclockwise. To increase the volume: Turn clockwise. Setting ringtone STEP Select “Ringtone” using STEP Using , select a ringtone (1 - 3).
Page 300 3-5. Using the interior lights Interior lights list Interior light (→P. 310) Personal lights or personal/interior lights (→P. 310, 311) “ENGINE START STOP” switch light (vehicles with smart key system)
Page 301 “DOOR” position, the lights will go off automatically after 20 minutes. ■ Customization that can be configured at Toyota dealer Settings (e.g. The time elapsed before lights turn off) can be changed. (Customizable features →P. 497)
Page 302 3-5. Using the interior lights Interior light and personal lights Interior light “DOOR” position Personal lights (vehicles without moon roof) On/off...
Page 303 3-5. Using the interior lights Personal/interior lights Personal/interior lights (vehicles with moon roof) ■ Interior lights “DOOR” position ■ Personal lights On/off...
Page 304 3-6. Using the storage features List of storage features Auxiliary boxes Glove box Bottle holders Cup holders Console box CAUTION ■ Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: ●...
Page 305 3-6. Using the storage features Glove box and console box Glove box Pull up the lever. CAUTION ■ Caution while driving Keep the glove box closed. In the event of sudden braking or sudden swerv- ing, an accident may occur due to an occupant being struck by the open glove box or the items stored inside.
Page 306 3-6. Using the storage features Console box Type B Lift the lid while pulling the lever. Lift the lid and tray. Lift the lid. Pull the tray up to open the box. ■ When using the console box lid as an armrest (type B only) If necessary, the console box lid can slide forward.
Page 307 3-6. Using the storage features Cup holders Cup holders Front Rear Pull the lid to open.
Page 308 3-6. Using the storage features Cup holders ■ Adjusting the size of the cup holder (front) Remove the cup holder insert. STEP Change the cup holder insert position. STEP ■ Cup holder insert (front) The cup holder insert may be removed for cleaning.
Page 309 3-6. Using the storage features Cup holders CAUTION ■ Items unsuitable for the cup holder Do not place anything other than cups or beverage cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 310 3-6. Using the storage features Auxiliary boxes Auxiliary boxes Type A Pull up the lever. Type B (if equipped) Pull the lid. Type C (vehicles with moon roof) Push the lid.
Page 311 3-6. Using the storage features Auxiliary boxes Type D Pull up the lever. CAUTION ■ Caution while driving Keep the auxiliary boxes closed. Injuries may result in the event of an accident or sudden braking. ■ Items unsuitable for storing (type C only) Do not store items heavier than 0.4 lb.
Page 312 3-6. Using the storage features Bottle holders Bottle holders Front Rear CAUTION ■ Items unsuitable for the bottle holder Do not place anything other than pet bottles in the bottle holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 313 3-7. Other interior features Sun visors Forward position: Flip down. Side position: Flip down, unhook, and swing to the side.
Page 314 3-7. Other interior features Vanity mirrors Slide the cover.
Page 315 3-7. Other interior features Clock Adjusts the hour Adjusts the minutes ■ The clock is displayed when Vehicles with smart key system The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode. Vehicles without smart key system The engine switch is in the “ACC” or “ON” position. ■...
Page 316 3-7. Other interior features ∗ Ashtray Pull the lid to open. Pull the ashtray to remove. CAUTION ■ When not in use Keep the ashtray closed. Injuries may result in the event of sudden braking, sudden swerving or an accident. ■...
Page 317 3-7. Other interior features ∗ Cigarette lighter Pull the lid to open, and push the cigarette lighter down. The cigarette lighter will pop up when it is ready for use. ■ The cigarette lighter can be used when Vehicles with smart key system The “ENGINE START STOP”...
Page 318 3-7. Other interior features ∗ Power outlet The power outlet can be used for 12 V accessories that run on less than 10 A. ■ The power outlet can be used when Vehicles with smart key system The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode.
Page 319 3-7. Other interior features ∗ Seat heaters Heats the driver’s seat Heats the front passenger’s seat The indicator light is on while the seat heater is operating. Push the switch once again to turn off the seat heater. ■ The seat heaters can be used when Vehicles with smart key system The “ENGINE START STOP”...
Page 320 3-7. Other interior features NOTICE ■ To prevent seat heater damage Do not put unevenly weighted objects on the seat and do not stick sharp objects (needles, nails, etc.) into the seat. ■ To prevent battery discharge Turn the switches off when the engine is not running.
Page 321 3-7. Other interior features Assist grips An assist grip installed on the ceiling can be used to support your body while sitting on the seat. CAUTION ■ Assist grip Do not use the assist grip when getting in or out of the vehicle or rising from your seat.
Page 322 When installing the driver's floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver's seat. ●...
Page 323 3-7. Other interior features ∗ Compass The compass on the inside rear view mirror indicates the direction in which the vehicle is heading. ■ Operation To turn the compass on or off, press and hold “AUTO” for 3 seconds. ■ Displays and directions Display Direction...
Page 324 3-7. Other interior features Calibrating the compass The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies according to the geographic position of the vehicle. If you cross over a map boundary shown in the illustration, the compass will deviate.
Page 325 3-7. Other interior features ■ Circling calibration STEP Stop the vehicle in a place where it is safe to drive in a circle. Press and hold “AUTO” for 9 STEP seconds. C appears on the compass dis- play. Drive the vehicle at 5 mph STEP (8 km/h) or less in a circle until a direction is displayed.
Page 326 3-7. Other interior features CAUTION ■ While driving the vehicle Do not adjust the display. Be sure to adjust the display only when the vehicle is stopped. ■ When doing the circling calibration Be sure to secure a wide space, and watch out for people and vehicles in the neighborhood.
Page 327 4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 328 4-1. Maintenance and care ■ Bumpers Do not scrub with abrasive cleaners. CAUTION ■ Caution about the exhaust pipe Exhaust gasses cause the exhaust pipe to become quite hot. When washing the vehicle, be careful not to touch the pipe until it has cooled sufficiently, as touching a hot exhaust pipe can cause burns.
Page 329 4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle's interior and keep it in top condition: ■ Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
Page 330 4-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle's interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 331 4-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use organic substances such as benzene or gasoline, acidic or alkaline solutions, dye, bleach or other detergent. Doing so may discolor the vehicle interior or cause streaks or damage to painted surfaces. ●...
Page 332 It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 333 Continue to press and hold the button until the trip meter displays 000000. ■ Allow inspection and repairs to be performed by a Toyota dealer ● Toyota technicians are well-trained specialists and are kept up to date with the latest service information. They are well informed about the operations of all systems on your vehicle.
Page 334 Booklet” “Owner’s Manual Supplement/Scheduled Maintenance Guide”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items Check points Check the connections. Battery (→P.
Page 335 4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven Accelerator pedal pedal effort or catching)? • Can the vehicle be held securely Automatic transmission “Park” on an incline with the shift lever in mechanism • Moves smoothly? •...
Page 336 4-2. Maintenance Vehicle exterior Items Check points Doors/trunk • Operate smoothly? Engine hood • The lock system works properly? • Is there any leakage after park- Fluid leaks ing? • Inflation pressure is correct? • Tire surfaces not worn or dam- aged? Tires •...
Page 337 If the malfunction indicator lamp comes on The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. ■...
Page 338 Brake fluid level (→P. 364) • Rag or paper towel • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology.
Page 339 4-3. Do-it-yourself maintenance Items Parts and tools • Fuse with same amperage rating Fuses (→P. 392) as original Radiator and condenser ⎯ (→P. 364) • Tire pressure gauge Tire inflation pressure (→P. 379) • Compressed air source • Water washer fluid containing Washer fluid (→P.
Page 340 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury observe the following precautions. ■ When working on the engine compartment ● Keep hands, clothing, and tools away from the moving fan and engine drive belt.
Page 341 4-3. Do-it-yourself maintenance NOTICE ■ If you remove the air cleaner Driving with the air cleaner removed may cause excessive engine wear due to dirt in the air. Also, a backfire could cause a fire in the engine compart- ment.
Page 342 4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. STEP The hood will pop up slightly. Lift the auxiliary catch lever STEP and lift the hood. Hold the hood open by insert- STEP ing the supporting rod into the slot.
Page 343 4-3. Do-it-yourself maintenance CAUTION ■ Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. ■...
Page 344 4-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury. ■ Front 1.8 L 4-cylinder (2ZR-FE) engine 2.4 L 4-cylinder (2AZ-FE) engine ■...
Page 345 4-3. Do-it-yourself maintenance Set the jack attachment on the STEP floor jack with the “FOR- WARD” facing towards the front of the vehicle, and place the jack. Front of vehicle Before raising the vehicle, STEP make sure that the floor jack is positioned so that the jack point fits securely inside the groove on the jack attach-...
Page 346 4-3. Do-it-yourself maintenance CAUTION ■ When raising your vehicle Make sure to observe the following to reduce the possibility of death or seri- ous injury. ● Lift up the vehicle using a floor jack such as the one shown in the illustra- tion.
Page 347 4-3. Do-it-yourself maintenance Engine compartment 1.8 L 4-cylinder (2ZR-FE) engine Engine coolant reservoir Battery (→P. 367) (→P. 363) Radiator (→P. 364) Engine oil filler cap Electric cooling fan (→P. 360) Condenser (→P. 364) Brake fluid reservoir Engine oil level dipstick (→P.
Page 348 4-3. Do-it-yourself maintenance 2.4 L 4-cylinder (2AZ-FE) engine Engine coolant reservoir Fuse box (→P. 392) (→P. 363) Battery (→P. 367) Engine oil filler cap Radiator (→P. 364) (→P. 360) Electric cooling fans Engine oil level dipstick Condenser (→P. 364) (→P. 358) Washer fluid tank (→P.
Page 349 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil STEP Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 350 4-3. Do-it-yourself maintenance Flat dipstick type Normal Excessive The shape of the dipstick may differ depending on the type of vehicle or engine. Non-flat dipstick Normal Excessive The shape of the dipstick may differ depending on the type of vehicle or engine. STEP Wipe the dipstick and reinsert it fully.
Page 351 4-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 352 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
Page 353 4-3. Do-it-yourself maintenance NOTICE ■ To prevent serious engine damage Check the oil level on a regular basis. ■ When replacing the engine oil ● Be careful not to spill engine oil on the vehicle components. ● Avoid overfilling, as the engine could be damaged. ●...
Page 354 If the coolant level drops within a short time after replenishing Visually check the radiator, hoses, coolant reservoir cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. ■...
Page 355 Radiator and condenser Check the radiator and condenser and remove any foreign objects. If any of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION ■...
Page 356 4-3. Do-it-yourself maintenance ■ Adding fluid Make sure to check the fluid type and prepare the necessary items. Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items Clean funnel Slide and lift up the rubber strip STEP to partly remove it as shown.
Page 357 4-3. Do-it-yourself maintenance ■ Brake fluid can absorb moisture from the air Excess moisture in the fluid can cause a dangerous loss of braking effi- ciency. Use only newly opened brake fluid. CAUTION ■ When filling the reservoir Take care because brake fluid can harm your hands or eyes and damage painted surfaces.
Page 358 4-3. Do-it-yourself maintenance Battery Check the battery as follows. ■ Battery exterior Make sure that the battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals Hold-down clamp Ground cable ■ Before recharging When recharging, the battery produces hydrogen gas which is flammable and explosive.
Page 359 4-3. Do-it-yourself maintenance CAUTION ■ Chemicals in the battery A battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the battery: ●...
Page 360 4-3. Do-it-yourself maintenance NOTICE ■ When recharging the battery Never recharge the battery while the engine is running. Also, be sure all accessories are turned off. Washer fluid If any washer does not work or the low windshield washer fluid level warning light comes on (if equipped), the washer tank may be empty.
Page 361 4-3. Do-it-yourself maintenance NOTICE ■ Do not use any fluid other than washer fluid Do not use soapy water or engine antifreeze instead of washer fluid. Doing so may cause streaking on the vehicle’s painted surfaces. ■ Diluting washer fluid Dilute washer fluid with water as necessary.
Page 362 ■ The tire pressure warning system (U.S.A. only) Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. (→P. 426) The compact spare tire is not equipped with the tire pressure warning valve and transmitters.
Page 363 Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (→P. 373) Initializing the tire pressure warning system The tire pressure warning system must be initialized when changing the tire size.
Page 364 The tire pressure warning valve and transmitter is equipped with a unique ID code. When replacing a tire pressure warning valve and transmitter, it is necessary to register the ID code of tire pressure warning valve and transmitter. Have the ID code registered by your Toyota dealer.
Page 365 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly.
Page 366 4-3. Do-it-yourself maintenance ■ Low profile tires (vehicles with 17-inch tires) Generally, low profile tires will wear more rapidly and tire grip perfor- mance will be reduced on snowy and/or icy roads when compared to standard tires. Be sure to use snow tires or tire chains on snowy and/or icy roads and drive carefully at a speed appropriate for road and weather conditions.
Page 367 Initialization can be completed in a few minutes. However, in the follow- ing cases, the settings have not been recorded and the system will not operate properly. If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. ●...
Page 368 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 369 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 370 4-3. Do-it-yourself maintenance Tire inflation pressure ■ Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (→P. 480) Type A Type B...
Page 371 4-3. Do-it-yourself maintenance ■ Inspection and adjustment procedure Tire valve Tire pressure gauge STEP Remove the tire valve cap. STEP Press the tip of the tire pressure gauge onto the tire valve. STEP Read the pressure using the graduations of the gauge. STEP If the tire inflation pressure is not at the recommended level adjust the pressure.
Page 372 Reduced driving comfort and tire life ● Reduced safety ● Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ●...
Page 373 4-3. Do-it-yourself maintenance CAUTION ■ Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. ● Excessive wear ● Uneven wear ●...
Page 374 ● Bent wheels that have been straightened ■ Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 375 4-3. Do-it-yourself maintenance ■ When replacing wheels The wheels of your Toyota, except for the compact spare tire, are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advanced warning in the event of a loss in tire inflation pressure.
Page 376 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 377 4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. ■ Removal method STEP Vehicles with smart key system: Turn the “ENGINE START STOP” switch OFF. Vehicles without smart key system: Turn the engine switch OFF.
Page 378 4-3. Do-it-yourself maintenance ■ Replacement method Remove the air conditioning filter and replace it with a new one. The “↑UP” marks shown on the filter should be pointing up. ■ Checking interval Replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required.
Page 379 4-3. Do-it-yourself maintenance Key battery Replace the battery with a new one if it is discharged. ■ You will need the following items: ● Flathead screwdriver (To prevent damage to the key, cover the tip of the screwdriver with a rag.) ●...
Page 380 4-3. Do-it-yourself maintenance Remove the depleted battery. STEP Insert a new battery with the “+” terminal facing up. ■ Replacing the battery (vehicles without smart key system) Remove the cover. STEP Remove the module. STEP...
Page 381 4-3. Do-it-yourself maintenance Type A Open the case cover using a STEP flathead screwdriver pro- tected with tape etc. and remove the depleted battery. Insert a new battery (CR2025) with the “+” terminal facing up. Type B Open the case cover using a STEP coin protected with tape etc.
Page 382 Vehicles with smart key system: CR1632 Vehicles without smart key system: CR2025 (Type A), CR2016 (Type B) ● Batteries can be purchased at your Toyota dealer, jewelers, or camera stores. ● Replace only with the same or equivalent type recommended by your Toyota dealer.
Page 383 4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. STEP Vehicles with smart key system: Turn the “ENGINE START STOP”...
Page 384 4-3. Do-it-yourself maintenance Driver’s side instrument panel Remove the instrument panel. STEP After a system failure, see “Fuse layout and amperage rat- ings” (→P. 396) for details about which fuse to check. Take out the pullout tool. STEP Only type A fuse can be removed using the pullout tool.
Page 385 4-3. Do-it-yourself maintenance STEP Check if the fuse has blown. Type A Normal fuse Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. Type B Normal fuse Blown fuse Replace it with one of an appropriate amperage rating.
Page 386 4-3. Do-it-yourself maintenance Type C Normal fuse Blown fuse Contact your Toyota dealer. Type D Normal fuse Blown fuse Contact your Toyota dealer.
Page 387 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings ■ Engine compartment Fuse Ampere Circuit CDS FAN 30 A Electric cooling fan(s) RDI FAN 40 A Electric cooling fan(s) Anti-lock brake system, vehicle sta- ABS NO. 3 30 A bility control system Anti-lock brake system, vehicle sta- ABS NO.
Page 388 4-3. Do-it-yourself maintenance Fuse Ampere Circuit GLOW* 80 A No circuit 50 A EFI MAIN, HORN, IG2 H-LP LH LO, H-LP RH LO, H-LP H-LP MAIN 50 A LH HI, H-LP RH HI EFI NO. 2 10 A Emission control system Multiport fuel injection system/ EFI NO.
Page 389 4-3. Do-it-yourself maintenance Fuse Ampere Circuit MAYDAY* 10 A No circuit SPARE 10 A Spare fuse SPARE 30 A Spare fuse SPARE 20 A Spare fuse Multiport fuel injection system/ EFI MAIN 20 A sequential multiport fuel injection system, EFI NO. 1, EFI NO. 2 HORN 10 A Horn...
Page 390 4-3. Do-it-yourself maintenance ■ Under the driver’s side instrument panel Fuse Ampere Circuit 40 A Rear window defogger, MIR HTR PWR SEAT 30 A Power seat Parking lights, tail lights, license plate lights, front side marker lights, TAIL 10 A multiport fuel injection system/ sequential multiport fuel injection system, instrument cluster lights...
Page 391 4-3. Do-it-yourself maintenance Fuse Ampere Circuit POWER 30 A Power windows SEAT HTR 15 A Seat heater HTR-IG 10 A Air conditioning system WIPER 25 A Windshield wipers WASHER 15 A Windshield washer Automatic transmission, main body ECU, electric power steering, elec- tric cooling fan(s), shift lock control ECU-IG NO.
Page 392 Never use a fuse of a higher amperage rating than indicated, or use any other object in place of a fuse. ● Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix. This can cause extensive damage or even fire.
Page 393 You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
Page 394 4-3. Do-it-yourself maintenance ■ Rear bulb locations Rear turn signal lights Back-up lights Stop/tail and rear side License plate lights marker lights...
Page 395 4-3. Do-it-yourself maintenance Replacing light bulbs ■ Headlight low beams Turn the bulb base counterclock- STEP wise. Unplug the bulb while depress- STEP ing the lock release. ■ Headlight high beams and daytime running lights Turn the bulb base counterclock- STEP wise.
Page 396 4-3. Do-it-yourself maintenance Unplug the bulb while depress- STEP ing the lock release. ■ Front fog lights (if equipped) Remove the fender liner bolts STEP and clip. Partly remove the fender liner. STEP...
Page 397 4-3. Do-it-yourself maintenance Unplug the bulb while depress- STEP ing the lock release. Turn the bulb base counterclock- STEP wise.
Page 398 4-3. Do-it-yourself maintenance ■ Front turn signal/parking lights and front side marker lights STEP Turn the steering wheel away from the side being worked on. This will move the tire to provide more room. STEP Remove the fender liner bolts and clips. Partly remove the fender liner.
Page 399 4-3. Do-it-yourself maintenance Turn the bulb base counterclock- STEP wise. Front side marker light Front turn signal/parking light Remove the light bulb. STEP Front side marker light Front turn signal/parking light...
Page 400 4-3. Do-it-yourself maintenance ■ Stop/tail and rear side marker lights, and rear turn signal lights STEP Open the trunk lid. Remove the luggage trim cover STEP clips. Partly remove the luggage trim cover. Turn the bulb base counterclock- STEP wise. Stop/tail and rear side marker light Rear turn signal light...
Page 401 4-3. Do-it-yourself maintenance ■ Back-up light Open the trunk lid and remove STEP the cover. Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP...
Page 402 Remove the light bulb. STEP ■ LED high mounted stoplight The high mounted stoplight consists of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced.
Page 403 4-3. Do-it-yourself maintenance ■ Condensation build-up on the inside of the lens Contact your Toyota dealer for more information in the following situations. Temporary condensation build-up on the inside of the headlight lens does not indicate a malfunction. ● Large drops of water have built up on the inside of the lens.
Page 404 4-3. Do-it-yourself maintenance CAUTION ■ Replacing light bulbs ● Turn off the headlights. Do not attempt to replace the bulb immediately after turning off the headlights. The bulbs become very hot and may cause burns. ● Do not touch the glass portion of the light bulb with bare hands. Hold the bulb by the plastic or metal portion.
Page 405 4-3. Do-it-yourself maintenance...
Page 406 5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, press the switch once again. NOTICE ■ To prevent battery discharge Do not leave the emergency flashers on longer than necessary when the engine is not running.
Page 407 If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
Page 408 5-1. Essential information Emergency towing If a tow truck is not available, in an emergency your vehicle may be temporarily towed using a cable or chain secured to the emergency towing eyelet. This should only be attempted on hard surfaced roads for short distances at low speeds.
Page 409 5-1. Essential information ■ Emergency towing procedure STEP Release the parking brake. STEP Shift the shift lever to N. STEP Vehicles with smart key system Turn the “ENGINE START STOP” switch to ACCESSORY (engine off) or IGNITION ON (engine running) mode. Vehicles without smart key system Turn the engine switch to the “ACC”...
Page 410 5-1. Essential information Towing with a sling-type truck NOTICE ■ To prevent body damage Do not tow with a sling-type truck, either from the front or rear. Towing with a wheel-lift type truck from the front Release the parking brake. NOTICE ■...
Page 411 5-1. Essential information Towing with a wheel-lift type truck from the rear Automatic transmission: Use a towing dolly under the front wheels. Manual transmission: We recom- mend to use a towing dolly under the front wheels. When not using a towing dolly, turn the engine switch to the “ACC”...
Page 412 5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. ■ Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 413 Inspect the ground under the vehicle. If you find that fuel has leaked on to the ground, the fuel system has been damaged and is in need of repair. Do not restart the engine. Have the vehi- cle checked and repaired by your Toyota dealer.
Page 414 Stop the vehicle immediately. The following warning indicates the possibility of damage to the vehi- cle that may lead to an accident. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Charging system warning light Indicates a malfunction in the vehicle’s charging system.
Page 415 Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning light Warning light/Details Malfunction indicator lamp Indicates a malfunction in: (U.S.A.)
Page 416 If it is, tighten it securely. The malfunction indicator lamp will go off after taking several driving trips. If the malfunction indicator lamp does not go off even after several trips, con- tact your Toyota dealer as soon as possible. CAUTION ■...
Page 417 5-2. Steps to take in an emergency Warning light Warning light/Details Correction procedure Driver’s seat belt reminder light (warning buzzer) Fasten the seat belt. (on the instru- Warns the driver to fasten ment cluster) his/her seat belt. Front passenger’s seat belt reminder light (warning buzzer) Fasten the seat belt.
Page 418 • Flat tire (→P. 436) (U.S.A.) pressure is adjusted, have the system checked by your Toyota dealer. When the light comes on after blinking for 1 minute: Have the system checked Malfunction in the tire by your Toyota dealer.
Page 419 5-2. Steps to take in an emergency ■ SRS warning light This warning light system monitors the airbag sensor assembly, front airbag sensors, side and curtain shield airbag sensors, curtain shield airbag sen- sors, door sensors, driver's seat position sensor, driver's seat belt buckle switch, front passenger occupant classification system (ECU and sensors), “PASSENGER AIR BAG ON”...
Page 420 If there is a lot of snow or ice on the vehicle, in particular around the wheels or wheel housings. ● If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ●...
Page 421 If the tire pressure warning light frequently comes on after blinking for 1 minute when the “ENGINE START STOP” switch or engine switch is turned ON, have it checked by your Toyota dealer. ■ Customization that can be configured at Toyota dealer The vehicle speed linked seat belt reminder buzzer can be disabled.
Page 422 5-2. Steps to take in an emergency CAUTION ■ Maintenance of the tires Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
Page 423 5-2. Steps to take in an emergency CAUTION Your vehicle has also been equipped with a TPMS (tire pressure warning system) malfunction indicator to indicate when the system is not operat- ing properly. The TPMS (tire pressure warning system) malfunction indi- cator is combined with the low tire pressure telltale (tire pressure warning light).
Page 424 5-2. Steps to take in an emergency Follow the correction procedures. (vehicles with smart key system) After taking the specified steps to correct the suspected problem, check that the warning light turns off. Interior Exterior Warning Correction Warning light/Details buzzer buzzer light procedure...
Page 425 5-2. Steps to take in an emergency Interior Exterior Warning Correction Warning light/Details light procedure buzzer buzzer Smart key system warning light • Shift the shift Indicates that the driver’s door lever to P. has been opened or closed • Confirm the Conti n uous Continuous with the shift lever not in P, the...
Page 426 5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. ■ Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ● Set the parking brake. ●...
Page 427 5-2. Steps to take in an emergency Taking out the jack Remove the luggage floor cover. STEP Tighten STEP Loosen...
Page 428 5-2. Steps to take in an emergency Taking out the spare tire Remove the luggage floor cover. STEP Remove the tool tray. STEP Loosen the center fastener that STEP secures the spare tire.
Page 429 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP Wheel Flat tire chock positions Behind the Left- rear right- hand hand side side tire Front Behind the Right- rear left- hand hand side side tire In front of Left-...
Page 430 5-2. Steps to take in an emergency Slightly loosen the wheel nuts STEP (one turn). Turn the tire jack portion “A” by STEP hand until the notch of the jack is in contact with the jack point. The jack point guides are located under the rocker panel.
Page 431 5-2. Steps to take in an emergency Raise the vehicle until the tire is STEP slightly raised off the ground. Remove all the wheel nuts and STEP the tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid scratching the wheel surface.
Page 432 5-2. Steps to take in an emergency STEP Install the tire and loosely tighten each wheel nut by hand by approximately the same amount. Replacing a steel wheel with a compact spare tire Tighten the nuts until the tapered Tapered portion portion comes into loose contact with the disc wheel seat.
Page 433 5-2. Steps to take in an emergency Firmly tighten each nut two or STEP three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) STEP Stow the flat tire, tire jack and all tools. ■...
Page 434 5-2. Steps to take in an emergency CAUTION ■ Using the tire jack Improper use of the tire jack may lead to death or serious injuries due to the vehicle suddenly falling off the jack. ● Do not use the tire jack for any purpose other than replacing tires or installing and removing tire chains.
Page 435 5-2. Steps to take in an emergency CAUTION ■ Replacing a flat tire ● Do not attach a heavily damaged wheel ornament, as it may fly off the wheel while the vehicle is moving. ● Failure to follow these precautions could cause the wheel nuts to loosen and the tire to fall off, resulting in death or serious injury.
Page 436 ■ When replacing the tires When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly.
Page 437 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and...
Page 438 5-2. Steps to take in an emergency If the engine will not start If the engine still does not start after following the correct starting procedure (→P. 131, 135) or releasing the steering lock (→P. 133, 137), confirm the following points. ■...
Page 439 ● There may be a malfunction in the steering lock system (vehi- cles with smart key system). Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function (vehicles with smart key system) When the engine does not start, the following steps can be used as an interim measure to start the engine if the “ENGINE START STOP”...
Page 440 (a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
Page 441 5-2. Steps to take in an emergency If you lose your keys New genuine keys can be made by your Toyota dealer. For vehicles with the smart key system, bring the other key and the key number stamped on the key number plate. For vehicles without the smart key system, bring a master key and the key number stamped on the key number plate.
Page 442 5-2. Steps to take in an emergency If the electronic key does not operate properly (vehicles with smart key system) If communication between the electronic key and the vehicle is inter- rupted (→P. 29) or the electronic key cannot be used because the battery is depleted, the smart key system and wireless remote con- trol cannot be used.
Page 443 5-2. Steps to take in an emergency Starting the engine STEP Shift the shift lever to P and apply the brakes. Touch the Toyota emblem side of STEP electronic “ENGINE START STOP” switch. An alarm will sound to indicate that the start function cannot detect the electronic key that is touched to the “ENGINE START...
Page 444 5-2. Steps to take in an emergency ■ Stopping the engine Shift the shift lever to P and press the “ENGINE START STOP” switch as you normally do when stopping the engine. ■ Replacing the key battery As the above procedure is a temporary measure, it is recommended that the electronic key battery be replaced immediately when the battery is depleted.
Page 445 You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your Toyota following the steps below. 1.8 L 4-cylinder (2ZR-FE) engine Remove the engine cover.
Page 446 5-2. Steps to take in an emergency STEP Connecting the jumper cables Positive (+) battery terminal on your vehicle Positive (+) battery terminal on the second vehicle Negative (-) battery terminal on the second vehicle Connect the jumper cable to ground on your vehicle as shown in the illustration.
Page 447 Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. 2.4 L 4-cylinder (2AZ-FE) engine...
Page 448 Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. ■ Avoiding a discharged battery ●...
Page 449 5-2. Steps to take in an emergency CAUTION ■ Avoiding battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery. ● Make sure the jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any part other than the intended termi- nal.
Page 450 5-2. Steps to take in an emergency NOTICE ■ To prevent damage to the vehicle Do not pull- or push-start the vehicle, because the catalytic converter may overheat and become a fire hazard. ■ When handling jumper cables Be careful that the jumper cables do not become tangled in the cooling fans or any of the belts when connecting or disconnecting them.
Page 451 Wait until the temperature of the engine (shown on the instrument cluster) begins to fall and then stop the engine. If the fans are not operating: Stop the engine and call your Toyota dealer. After the engine has cooled STEP STEP...
Page 452 Water can be used in an emer- gency if engine coolant is (→ unavailable. P. 477 Have the vehicle checked at the nearest Toyota dealer as soon as possible. ■ Overheating If you observe the following, your vehicle may be overheating.
Page 453 5-2. Steps to take in an emergency NOTICE ■ When adding engine coolant Wait until the engine has cooled down before adding engine coolant. When adding coolant, do so slowly. Adding cool coolant to a hot engine too quickly can cause damage to the engine.
Page 454 5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. STEP Stop the engine. Set the parking brake and put the shift lever in P (automatic transmission) or N (manual transmis- sion).
Page 455 5-2. Steps to take in an emergency NOTICE ■ To avoid damaging the transmission and other components ● Avoid spinning the wheels and do not rev the engine. ● If the vehicle remains stuck after trying these procedures, the vehicle may require towing to be freed.
Page 456 5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: STEP Steadily step on the brake pedal with both feet and firmly...
Page 457 5-2. Steps to take in an emergency Vehicles with a smart key sys- STEP tem: Stop the engine by press- ing and holding the “ENGINE START STOP” switch for 3 consecutive seconds or more. Press and hold for 3 seconds or more STEP Stop the vehicle in a safe place by the road.
Page 458 5-2. Steps to take in an emergency...
Page 459 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 460 6-1. Specifications Type A On some models, this number is stamped under the front passen- ger seat. Type B On some models, this number is stamped under the front passen- ger seat. This number is also on the Certi- fication Label on the driver’s side center pillar.
Page 461 6-1. Specifications ■ Engine number The engine number is stamped on the engine block as shown. 1.8 L 4-cylinder (2ZR-FE) engine 2.4 L 4-cylinder (2AZ-FE) engine...
Page 462 6-1. Specifications Engine 1.8 L 4-cylinder (2ZR-FE) engine Model 2ZR-FE engine Type 4 cylinder in line, 4 cycle, gasoline 3.17 × 3.48 in. (80.5 × 88.3 mm) Bore and stroke Displacement 109.7 cu.in. (1798 cm Drive belt tension* 143 ± 22 lbf (650 ± 100 N, 65 ± 10 kgf) Valve clearance (engine cold) Intake Automatic adjustment...
Page 463 6-1. Specifications 2.4 L 4-cylinder (2AZ-FE) engine Model 2AZ-FE engine Type 4 cylinder in line, 4 cycle, gasoline 3.48 × 3.78 in. (88.5 × 96.0 mm) Bore and stroke Displacement 144.1 cu.in. (2362 cm Drive belt tension Automatic adjustment Valve clearance (engine cold) 0.007 ⎯...
Page 464 6-1. Specifications ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC multigrade engine oil Recommended viscosity: 1.8 L 4-cylinder (2ZR-FE) engine...
Page 465 6-1. Specifications 2.4 L 4-cylinder (2AZ-FE) engine SAE 5W-20 or SAE 0W-20 SAE 5W-20 or 0W-20 engine oil may be used. However, SAE 0W-20 is the best choice for good fuel economy and good starting in cold weather. Outside temperature Oil viscosity (0W-20 is explained here as an example): •...
Page 466 (Reference) 2.4 L 4-cylinder (2AZ-FE) engine 6.0 qt. (5.7 L, 5.0 Imp. qt.) Use either of the following. • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non-silicate, Coolant type non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
Page 467 Please be aware that depending on the particular characteristics of the gear oil used or the operating conditions, idle sound, shift feeling and/or fuel effi- ciency may be different or affected. Toyota recommends to use “TOYOTA Genuine Manual Transmission Gear Oil LV” to achieve optimal performance.
Page 468 Toyota Genuine ATF WS NOTICE ■ Automatic transmission fluid type Using automatic transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle.
Page 469 6-1. Specifications Steering Free play Less than 1.2 in. (30 mm) Tires and wheels Type A Tire size P195/65R15 89S, T135/80R16 101M Tire inflation pressure Front: 30 psi (210 kPa, 2.1 kgf/cm or bar) (Recommended cold tire Rear: 30 psi (210 kPa, 2.1 kgf/cm or bar) inflation pressure) Spare: 60 psi (420 kPa, 4.2 kgf/cm...
Page 470 6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights Low beam 9006 High beam 9005 Front side marker ⎯ lights Front turn signal/park- 3457NAK 28/8 ing lights Exterior Front fog lights ⎯ (if equipped) ⎯ Rear turn signal lights Stop/tail and rear side 7443 21/5...
Page 471 ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada. ■ Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. ■...
Page 472 10% ethanol). (85% ethanol) ● If you use gasohol in your Toyota, be sure that it has an octane rating no lower than 87. ● Toyota does not recommend the use of gasoline containing methanol.
Page 473 Toyota does not recommend gasoline containing MMT Some gasoline contains octane enhancing additive called MMT (Methylcy- clopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected.
Page 474 6-1. Specifications Tire information Typical tire symbols Full-size tire Compact spare tire Tire size (→P. 488) DOT and Tire Identification Number (TIN) (→P. 487) Uniform tire quality grading For details, see “Uniform Tire Quality Grading” that follows. Location of treadwear indicators (→P.
Page 475 6-1. Specifications Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire. Radial tires or bias-ply tires A radial tire has “RADIAL” on the sidewall. A tire not marked “RADIAL”...
Page 476 6-1. Specifications Typical DOT and Tire Identification Number (TIN) DOT symbol Tire Identification Number (TIN) Tire manufacturer's identifica- tion mark Tire size code Manufacturer's optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year : The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.
Page 477 6-1. Specifications Tire size ■ Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 or 3 digits) Speed symbol...
Page 478 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Requirements in addition to these grades.
Page 479 6-1. Specifications ■ Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a speci- fied government test course. For example, a tire graded 150 would wear one and a half (1-1/2) times as well on the government course as a tire graded 100.
Page 480 6-1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either sepa- rately or in combination, can cause heat buildup and possible tire fail- ure.
Page 481 6-1. Specifications Tire related term Meaning 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 that weight follows Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below The combined weight of installed regular pro- duction options weighing over 5 lb.
Page 482 6-1. Specifications Tire related term Meaning The surface area of the rim not covered by the Weather side inflated tire The part of the tire that is made of steel wires, Bead wrapped or reinforced by ply cords and that is shaped to fit the rim A breakdown of the bond between components Bead separation...
Page 483 6-1. Specifications Tire related term Meaning The parting of the innerliner from cord material Innerliner separation in the carcass (a) The sidewall that contains a whitewall, bears white lettering, or bears manufac- turer, brand, and/or model name molding that is higher or deeper than the same Intended outboard molding on the other sidewall of the tire, or sidewall...
Page 484 6-1. Specifications Tire related term Meaning A layer of rubber-coated parallel cords A parting of rubber compound between adja- Ply separation cent plies A mechanical device made of rubber, chemi- cals, fabric and steel or other materials, that, Pneumatic tire when mounted on an automotive wheel, pro- vides the traction and contains the gas or fluid that sustains the load...
Page 485 6-1. Specifications Tire related term Meaning That portion of a tire that comes into contact Tread with the road A tread section running circumferentially Tread rib around a tire Tread separation Pulling away of the tread from the tire carcass The projections within the principal grooves Treadwear indicators designed to give a visual indication of the...
Page 486 Your vehicle includes a variety of electronic features that can be per- sonalized to your preferences. Programming these preferences requires specialized equipment and may be performed by your Toyota dealer. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer. Customized Item Function Default setting...
Page 487 6-2. Customization Customized Item Function Default setting setting Wireless remote control Driver's door unlocked in one All doors Unlocking operation step, all doors unlocked in one unlocked in two step steps Automatic door lock function to be activated if door is not opened after being unlocked Time elapsed before 30 seconds...
Page 488 6-2. Customization Customized Item Function Default setting setting Driver's door unlocked in one All doors Unlocking using a key step, all doors unlocked in one unlocked in two step steps Speed-detecting auto- matic door lock function (vehicles with smart key Door lock system) (vehicles...
Page 489 6-2. Customization Customized Item Function Default setting setting Time elapsed before 7.5 seconds lights turn off (vehicles 15 seconds with power door lock 30 seconds system) Operation when the doors are unlocked (vehicles with power door lock system) Illumination Vehicles with smart key →...
Page 490 6-3. Initialization Items to initialize The following items must be initialized for normal system operation in cases such as after maintenance is performed on the vehicle. Item When to initialize Reference Maintenance data After the maintenance is performed P. 342 (U.S.A.
Page 491 6-3. Initialization...
Page 492 If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 493 Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation correcte des ceintures de sécurité...
Page 494 Guide confort de ceinture de sécurité (sièges arrière latéraux) Si la sangle diagonale est proche du cou d’une personne, utilisez le guide confort de la ceinture de sécurité. Sortez le guide confort de la ÉTAPE pochette. Glissez la ceinture dans la fente ÉTAPE du guide.
Page 495 ■ Ceinture de sécurité latérale arrière Si la ceinture de sécurité est sortie de son guide, repassez-la dedans avant de l'utiliser. Entretien et soin ■ Ceintures de sécurité Nettoyez avec un chiffon ou une éponge humectée d'eau savonneuse tiède. Vérifiez régulièrement que les ceintures ne sont pas effilochées, entaillées ou exagérément usées.
Page 496 SRS airbag instructions for Canadian owners (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instructions in English. Airbags frontaux Airbag conducteur et passager avant Participent à...
Page 497 Composition du système d’airbags Capteurs d’airbag avant Témoin d'alerte SRS Système de classification Contacteur de boucle de l'occupant siège ceinture sécurité passager avant (ECU et passager avant capteurs) Boîtier électronique Capteurs de porte d’airbags Airbag passager avant Capteurs airbags rideau Airbags latéraux Airbag conducteur Prétensionneurs...
Page 498 Votre véhicule est équipé de ADVANCED AIRBAGS conçus selon les normes de sécurité américaines applicables aux véhicules à moteur (FMVSS208). Le boîtier électronique (ECU) des sacs de sécurité gonflables régule le déploiement de ces derniers sur la base des informations qu'il reçoit des capteurs, etc. indiqués ci-dessus dans le schéma illustrant les composants du système.
Page 499 ATTENTION ■ Précautions avec les airbags SRS Respectez les précautions suivantes concernant les airbags. Autrement, des blessures graves, voire mortelles, pourraient s'ensuivre. ● Le conducteur et tous les passagers à bord du véhicule doivent porter leur ceinture de sécurité correctement. Les airbags SRS sont des dispositifs de protection complémentaires aux ceintures de sécurité.
Page 500 ATTENTION ■ Précautions avec les airbags SRS ● Si vous attachez une rallonge de ceinture de sécurité aux boucles de ceinture de sécurité avant, mais pas au pêne de la ceinture de sécurité, les airbags SRS frontaux détectent que le conducteur et le passager avant ont attaché...
Page 501 être grièvement blessés ou tués par le déploiement d'un airbag. Installez dans un siège de sécurité enfant les enfants trop jeunes pour pouvoir utiliser la ceinture de sécurité. Toyota recommande vivement que les nourrissons et les jeunes enfants soient installés sur le siège arrière du véhicule et convenablement attachés.
Page 502 ATTENTION ■ Précautions avec les airbags SRS ● Ne laissez pas un enfant rester debout devant l’airbag SRS passager avant ou bien s'asseoir sur les genoux du passager avant. ● Ne conduisez pas le véhicule lorsque le conducteur ou le passager avant a quelque chose de posé...
Page 503 ATTENTION ■ Précautions avec les airbags SRS ●Ne rien fixer aux portes, à la vitre du pare-brise, aux vitres latérales, aux montants avant et arrière, au rail latéral de toit et à la poignée de maintien. ●Ne suspendez crochets à vêtements aucun cintre nu ni aucun objet dur.
Page 504 Toyota. ■ Modification et mise au rebut des éléments du système d’airbags SRS Consultez impérativement votre concessionnaire Toyota si vous avez besoin d'intervenir sur votre véhicule ou de procéder à l'une des modifications suivantes.
Page 505 Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Air Conditioning Anti-lock Brake System Accessory Automatic Locking Retractor Child Restraint System Electronic Control Unit Event Data Recorder Emergency Locking Retractor Electric Power Steering GAWR Gross Axle Weight Rating GCWR Gross Combination Weight Rating GVWR Gross Vehicle Weight Rating Emission inspection and maintenance...
Page 506 Abbreviation list ABBREVIATIONS MEANING TRAC Traction Control Trailer Weight Rating Vehicle Identification Number Vehicle Stability Control...
Page 507 Alphabetical index Alphabetical index A/C........206, 212 Audio system ABS ...........172 Antenna......... 235 Air conditioning filter....386 Audio input ......274 Air conditioning system AUX port ....... 274 Air conditioning filter....386 CD player/changer ....237 Automatic air conditioning iPod........253 system ........206 MP3/WMA disc .....
Page 508 Alphabetical index Care Child safety Exterior ......... 336 Airbag precautions ....93 Interior ........338 Battery precautions ..368, 459 Seat belts ......339 Child restraint system....103 Cargo capacity ......176 Child-protectors.......42 CD changer ......237 How your child should wear CD player ......... 237 the seat belt ......62 Chains ........
Page 509 Alphabetical index Daytime running light Electric power steering ... 172 system ........161 Electronic key Defogger If your electronic key Rear window ......219 battery is discharged ..452 Side mirror......219 Emergency flashers Dimension.........470 Switch ........416 Dinghy towing ....201, 202 Emergency, in case of Display If a warning light turns on..
Page 510 Alphabetical index Engine Floor mat........330 Compartment......356 Fluid Engine switch ....131, 135 Brake........364 Hood........351 Washer........369 How to start the Fog lights engine ......131, 135 Replacing light bulbs .....402 Identification number .... 470 Switch........163 If the engine will not start..448 Wattage.........481 Ignition switch....
Page 511 Alphabetical index Gas station information...532 Jack Gauges........149 Positioning a floor jack ..353 Glove box........313 Vehicle-equipped jack... 436 Jack handle ......436 Hands-free phone system (for cellular phone) ....280 Keyless entry ......36 Hazard lights Keys Switch........416 Electronic key......22 Head restraints Engine switch....
Page 512 Alphabetical index Maintenance Parking brake ......147 Do-it-yourself Parking lights maintenance ...... 347 Replacing light bulbs .....402 General maintenance ... 343 Switch........159 Maintenance data....470 Wattage.........481 Maintenance requirements... 341 Personal lights Manual air conditioning Switch........310 system ........212 Wattage.........481 Manual transmission Personal/interior lights Manual transmission ....
Page 513 Alphabetical index Seat belts Side mirror Adjusting the seat belt.....58 Adjusting and folding....69 Automatic Locking Smart key system Retractor .......61 Entry function ......25 Child restraint system Starting the engine....131 installation......107 Spare tire Cleaning and maintaining Inflation pressure ....379 the seat belts ......339 Storage location ....
Page 514 Alphabetical index Tachometer......149 Tools .........436 Tail lights Total load capacity....180 Replacing light bulbs .... 402 Towing Switch........159 Dinghy towing....201, 202 Wattage ........ 481 Emergency towing....418 Theft deterrent system Trailer towing....185, 200 Engine immobilizer system..81 TRAC .........172 Tire inflation pressure .... 379 Traction control......172 Tire information Trip information .......156...
Page 515 Alphabetical index Warning buzzers Windows Brake system ......424 Power windows .......71 Downshifting......143 Rear window defogger ..219 Seat belt reminder....426 Washer........165 Warning lights Windshield wipers ....165 Anti-lock brake system ..425 Wireless remote control key Brake assist system ....425 Replacing the battery ....
Page 516 What to do if... What to do if... If you have a flat tire A tire punctures P. 436 P. 81 Engine immobilizer system P. 448 If the engine will not start The engine does not start If the electronic key does not oper- P.
Page 517 What to do if... Type A Type B...
Page 518: Warning Lights
What to do if... ■Warning lights Brake system warning Tire pressure warning light light P. 426 Low windshield washer fluid level warning light P. 424 P. 426 Electric power steering Charging system warn- warning light ing light P. 424 P. 425 Slip indicator Low engine oil pressure light...
Page 519: Gas Station Information
2.4 L 4-cylinder qt. (L, Imp. qt.) refill (2AZ-FE) With filter 4.0 (3.8, 3.3) reference) engine Without filter 3.8 (3.6, 3.2) “Toyota Genuine Motor Oil” or equivalent Engine oil type Oil grade: ILSAC multigrade engine oil Recommended viscosity: P. 474...

Toyota 2013 Corolla Owner's Manual

Quick Links

TABLE OF CONTENTS

Related Manuals for Toyota 2013 Corolla

Summary of Contents for Toyota 2013 Corolla

Page 2: For Your Information

Page 12: Table Of Contents

Page 16: Instrument Panel

Page 116: Tires

Page 518: Warning Lights

Page 519: Gas Station Information

Table of Contents
