Page 1 TABLE OF CONTENTS Information on the hybrid system and adjusting and op- Before driving erating features such as door locks, mirrors, and steer- ing column When driving Driving, stopping and safe-driving information Interior Air conditioning and audio systems, as well as other in- features terior features for a comfortable driving experience Maintenance...
Page 2: Table Of Contents
TABLE OF CONTENTS Index 1-4. Adjustable components Before driving (seats, mirrors, steering wheel) Front seats......101 1-1. Hybrid system Rear seats ......104 Hybrid system features ..32 Head restraints ....107 Hybrid system precautions ... 38 Seat belts......111 Energy monitor/ Steering wheel....
Page 3 2-4. Using other driving systems When driving Cruise control ..... 268 Dynamic radar cruise control ......272 2-1. Driving procedures LKA (Lane-Keeping Driving the vehicle....182 Assist) ......289 Power (ignition) switch ..194 Driving assist systems..300 EV drive mode ....201 Hill-start assist control ..
Page 4 TABLE OF CONTENTS Index 3-3. Using the interior lights Interior features Interior lights list....357 • Front interior lights.... 358 • Personal lights ....359 3-1. Using the air conditioning • Rear interior light ....359 system and defogger 3-4. Using the storage features Air conditioning system ..
Page 5 Maintenance and care When trouble arises 4-1. Maintenance and care 5-1. Essential information Cleaning and protecting Emergency flashers.... 490 the vehicle exterior.... 402 If your vehicle needs Cleaning and protecting to be towed....... 491 the vehicle interior..... 405 If you think something is wrong......
Page 6 TABLE OF CONTENTS Index Vehicle specifications For owners 6-1. Specifications Reporting safety defects for U.S. owners....606 Maintenance data (fuel, Seat belt instructions oil level, etc.) ....566 for Canadian owners Fuel information ....577 (in French) ......607 Tire information ....581 SRS airbag instructions for Canadian owners 6-2.
Page 7 PRIUS_OM_OM47857U_DVD_(U)
Page 8 Pictorial index Exterior  Moon roof with Solar Panel P. 129 Outside rear view mirrors Windshield wipers P. 260 P. 124 Hood P. 419 Front turn signal lights P. 213  Daytime running lights Fog lights P. 258 (for the U.S.A.) P.
Page 9 Back door P. 95 Rear window defoggers P. 350 Rear window wiper P. 264 Fuel filler door P. 134 License plate lights P. 252 Side doors P. 89 Camera Tires Rear turn signal lights ●Rotation P. 443 P. 213 ●Replacement P.
Page 10 Pictorial index Interior Head restraints P. 107 Seat belts P. 111 SRS front passenger airbag P. 142  Cup holders P. 364 Glove boxes P. 362  Armrest P. 375 Rear seats P. 104 SRS side airbags P. 142 Front seats P.
Page 11 Sun visors P. 368 Front interior/personal lights P. 359 Microphone P. 393 Assist grips P. 376 Rear interior light P. 359 SRS curtain shield airbags P. 142 Vanity mirrors P. 369  “SOS” button P. 393  Moon roof switch P.
Page 12 Pictorial index Interior Window lock switch P. 126 Door lock switch P. 89 Inside lock button P. 89 Power window switches P. 126 PRIUS_OM_OM47857U_DVD_(U)
Page 13 AUX port/USB port P. 356 Console box P. 363 Power outlet P. 371 Cup holders P. 364 : Refer to “DISPLAY AUDIO SYSTEM OWNER’S MANUAL” or “NAVIGATION SYSTEM OWNER’S MANUAL”. PRIUS_OM_OM47857U_DVD_(U)
Page 14 Pictorial index Interior  Seat heater switches P. 373 Power outlet P. 371 Auxiliary box P. 367 PRIUS_OM_OM47857U_DVD_(U)
Page 15 Pictorial index Instrument panel Windshield wipers and washer switch P. 260 SRS driver airbag P. 142 Rear window wiper and Horn P. 215 washer switch P. 264 Headlight switch P. 252 Gauges and meters P. 216 Turn signal lever Multi-information display P.
Page 16 Pictorial index Instrument panel Outside rear view mirror switches P. 124  Headlight cleaner switch P. 267  Ventilation switch P. 343 Instrument panel light control dial P. 219 Hood lock release lever P. 419 PRIUS_OM_OM47857U_DVD_(U)
Page 17 “TRIP” button P. 226, 230 Climate remote control switches P. 341 Audio remote “DISP” button P. 226 1, 2 control switches  1, 2 Talk switch Cruise control switch P. 268 Dynamic radar cruise control  1, 2 Telephone switches switch P.
Page 18 Pictorial index Instrument panel Clock adjustment buttons P. 232 MPH or km/h button P. 218  Head-up display switches P. 245 Power (ignition) switch P. 194 PRIUS_OM_OM47857U_DVD_(U)
Page 19 Air conditioning system P. 330 Rear window and outside rear view mirror defoggers switch P. 350 Emergency flasher switch P. 490 EV drive mode switch P. 201 Eco drive mode switch P. 206 Power mode switch P. 206 Shift lever P.
Page 20 Pictorial index Luggage compartment Luggage compartment light P. 96  Luggage cover P. 382 Auxiliary box Cargo hooks P. 379 P. 381 PRIUS_OM_OM47857U_DVD_(U)
Page 21  : If equipped PRIUS_OM_OM47857U_DVD_(U)
Page 22: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 23 ● Anti-lock brake system ● SRS airbag system ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation. High voltage parts and cables on the hybrid vehicles emit approximately the...
Page 24 ● Usage of data collected through Safety Connect (U.S. mainland only) If your Toyota has Safety Connect and if you have subscribed to those ser- vices, please refer to the Safety Connect Telematics Subscription Service Agreement for information on data collected and its usage.
Page 25 Event data recorder This vehicle is equipped with an event data recorder (EDR). The main pur- pose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.
Page 26 ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehicle) is obtained • In response to an official request by the police, a court of law or a govern- ment agency.
Page 27 CAUTION General precautions while driving ■ Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.
Page 28 In the event that your vehicle must be disposed of, the hybrid battery (traction battery) must be disposed of by your Toyota dealer or a qualified service shop. If the hybrid battery (traction battery) is not disposed of properly, it may cause electric shock that can result in death or serious injury.
Page 29 This is a warning against something which, if ignored, may cause damage to the vehicle or its equipment. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
Page 30 PRIUS_OM_OM47857U_DVD_(U)
Page 31: Before Driving
Before driving 1-1. Hybrid system 1-4. Adjustable components (seats, mirrors, steering Hybrid system features ..32 wheel) Hybrid system precautions ...... 38 Front seats ....... 101 Energy monitor/ Rear seats......104 consumption screen..44 Head restraints....107 Hybrid vehicle driving Seat belts ......
Page 32: Hybrid System Hybrid System Features
1-1. Hybrid system Hybrid system features Your vehicle is a hybrid vehicle. It has characteristics different from conventional vehicles. Be sure you are closely familiar with the char- acteristics of your vehicle, and operate with care. The hybrid system combines the use of a gasoline engine and an electric motor (traction motor) according to driving conditions, improving fuel efficiency and reducing exhaust emissions.
Page 33 1-1. Hybrid system When stopped/during start off ■ The gasoline engine stops when the vehicle is stopped. During start off, the electric motor (traction motor) drives the vehicle. At slow speeds or when traveling down a gentle slope, the engine is stopped and the electric motor (traction motor) is used.
Page 34 1-1. Hybrid system Vehicle proximity notification system When driving with the gasoline engine stopped, a sound, which changes in accordance with the driving speed, will be played in order to warn people nearby of the vehicle’s approach. The sound will stop when the vehicle speed exceeds approximately 15 mph (25 km/h).
Page 35 After the 12-volt battery has discharged or has been changed or ■ removed The gasoline engine may not stop even if the vehicle is running on the hybrid battery (traction battery). If this continues for a few days, contact your Toyota dealer. PRIUS_OM_OM47857U_DVD_(U)
Page 36 1-1. Hybrid system Sounds and vibrations specific to a hybrid vehicle ■ There may be no engine sounds or vibration even though the vehicle is able to move. For safety, apply the parking brake and make sure to shift the shift position to P when parked.
Page 37 Maintenance, repair, recycling, and disposal ■ Contact your Toyota dealer regarding maintenance, repair, recycling and dis- posal. Do not dispose of the vehicle yourself. PRIUS_OM_OM47857U_DVD_(U)
Page 38: Hybrid System Precautions
1-1. Hybrid system Hybrid system precautions Take care when handling the hybrid system, as it contains a high voltage system (about 650V at maximum) as well as parts that become extremely hot when the hybrid system is operating. Obey the caution labels attached to the vehicle. Air conditioning compressor Service plug High voltage cables (orange)
Page 39 If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact your Toyota dealer. Hybrid warning message A message is automatically displayed when a malfunction occurs in the hybrid system or an improper operation is attempted.
Page 40 ■ volt battery is disconnected The hybrid system may not start. In that case, try to start the system again. If the “READY” indicator does not come on, contact your Toyota dealer. Running out of fuel ■ When the vehicle has run out of fuel and the hybrid system cannot be started, refuel the vehicle with at least enough gasoline to make the low fuel level warning light (P.
Page 41 1-1. Hybrid system CAUTION High voltage precautions ■ The vehicle has high voltage DC and AC systems as well as a 12-volt sys- tem. DC and AC high voltage is very dangerous and can cause severe burns and electric shock that may result in death or serious injury. ●...
Page 42 1-1. Hybrid system CAUTION Road accident cautions ■ If your vehicle is involved in an accident, observe the following precautions to reduce the risk of death or serious injury: ● Stop the vehicle in a safe place to prevent subsequent accidents. While depressing the brake pedal, apply the parking brake, shift the shift position to P and turn the hybrid system off.
Page 43 Do not carry large amounts of water such as water cooler bottles in the vehicle. If water spills onto the hybrid battery (traction battery), the battery may be damaged. Have the vehicle inspected by your Toyota dealer. ● If the rear seat belt becomes separated from the guide (P. 105), it could obstruct the hybrid battery (traction battery) air vent.
Page 44: Energy Monitor/Consumption Screen
1-1. Hybrid system Energy monitor/consumption screen You can view the status of your hybrid system on the Display Audio system screen, the navigation system screen or the multi-informa- tion display. Display Audio system screen or navigation system screen Multi-information display Energy monitor Displays the flow of energy as it changes in accordance with driving conditions.
Page 45 1-1. Hybrid system Condition Display When the vehicle is powered by the electric motor (traction motor) When the vehicle is powered by both the gasoline engine and the electric motor (traction motor) When the vehicle is powered by the gasoline engine PRIUS_OM_OM47857U_DVD_(U)
Page 46 1-1. Hybrid system Condition Display When the vehicle is charging the hybrid battery (traction battery) When there is no energy flow Full Hybrid battery (traction battery) status These images are examples only, and may vary slightly from actual conditions. PRIUS_OM_OM47857U_DVD_(U)
Page 47 1-1. Hybrid system Navigation system STEP Press “INFO APPS” or “INFO”. STEP Touch “Fuel Consumption” on the “Information” screen. If the “Consumption” screen is displayed, touch “Energy”. PRIUS_OM_OM47857U_DVD_(U)
Page 48 1-1. Hybrid system Condition Display When the vehicle is powered by the electric motor (traction motor) When the vehicle is powered by both the gasoline engine and the electric motor (traction motor) When the vehicle is powered by the gasoline engine PRIUS_OM_OM47857U_DVD_(U)
Page 49 1-1. Hybrid system Condition Display When the vehicle is charging the hybrid battery (traction battery) When there is no energy flow Full Hybrid battery (traction battery) status These images are examples only, and may vary slightly from actual conditions. PRIUS_OM_OM47857U_DVD_(U)
Page 50 1-1. Hybrid system Multi-information display Press the “DISP” button to dis- play the energy monitor. Names and meaning of each icons ■ Gasoline engine Hybrid battery (traction bat- tery) Electric motor (traction motor) Condition Display When the vehicle is powered by the electric motor (traction motor) When the vehicle is powered by...
Page 51 1-1. Hybrid system Condition Display When the vehicle is powered by the gasoline engine When the vehicle is charging the hybrid battery (traction battery) When there is no energy flow Full Hybrid battery (traction battery) status These images are examples only, and may vary slightly from actual conditions. PRIUS_OM_OM47857U_DVD_(U)
Page 52 1-1. Hybrid system Consumption screen Display Audio system Press “CAR”. If the “Energy Monitor” screen is displayed, touch “Consumption”. Fuel consumption in the past 30 minutes Cruising range (P. 57) Regenerated energy in the past 30 minutes One symbol indicates 30 Wh. Up to 4 symbols are shown.
Page 53 1-1. Hybrid system Multi-information display Press the “DISP” button to dis- play the 5-minute or 1-minute fuel consumption display. Press and hold the “DISP” button to switch between 5-minute and 1-minute fuel consumption dis- plays. The display will alternate with each press of the button.
Page 54 1-1. Hybrid system EV indicator Eco Driving Indicator Light Average speed Average fuel consumption/eco savings Use the displayed average fuel consumption as a reference. : P. 226 :The current amount since the trip meter was reset will be displayed. These functions can be reset by pressing and holding the “TRIP”...
Page 55 1-1. Hybrid system Monthly fuel consumption record/Eco savings record (multi- information display only) Press the “DISP” button to dis- play the monthly fuel consump- tion record savings record. Press and hold the “DISP” button to switch the display between monthly fuel consumption record and eco savings record.
Page 56 1-1. Hybrid system Eco savings record display By setting the fuel consumption for comparison and the gasoline price beforehand (P. 233), when the actual fuel consumption is less than the fuel consumption for comparison, the difference is calculated and the amount of money saved or spent is displayed : The displayed amount is intended only as a guide and may differ from the actual amount.
Page 57 1-1. Hybrid system Resetting the consumption data ■ Display Audio system Selecting “Clear” on the “Consumption” screen will reset the fuel consump- tion and the regenerated energy for the past 30 minutes. Selecting “Yes” on the following screen will confirm resetting of all the data. Navigation system Selecting “Clear”...
Page 58: Hybrid Vehicle Driving Tips
1-1. Hybrid system Hybrid vehicle driving tips For economical and ecological driving, pay attention to the following points: Using Eco drive mode ■ When using Eco drive mode, the torque corresponding to the accelerator pedal depression amount can be generated more smoothly than it is in normal conditions.
Page 59 1-1. Hybrid system Air conditioning on/off ■ Switch the air conditioning ( ) to off when it is not needed. Doing so can help control excessive gasoline consumption. In summer: In high temperatures, use the recirculated air mode. Doing so will help to reduce the burden on the air conditioner and reduce fuel consumption as well.
Page 60: 1-2. Key Information
1-2. Key information Keys The following keys are provided with the vehicle. Electronic keys • Operating the smart key system (P. 63, 81) • Operating wireless remote control function (P. 87) • Operating the Remote Air Conditioning System (P. 346) Mechanical keys Key number plate : If equipped...
Page 61 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a mechanical key is lost, a new key can be made at your Toyota dealer using the key number plate. (P. 547) When riding in an aircraft ■...
Page 62 Take your vehicle with all the electronic keys provided with your vehicle to your Toyota dealer. When a vehicle key is lost ■ If the key remains lost, the risk of vehicle theft increases significantly. Visit your Toyota dealer immediately with all remaining electronic keys that was provided with your vehicle. PRIUS_OM_OM47857U_DVD_(U)
Page 63: 1-3. Opening, Closing And Locking The Doors
1-3. Opening, closing and locking the doors Smart key system (with entry function) The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) Unlocks and locks the side doors (P.
Page 64 1-3. Opening, closing and locking the doors Unlocking and locking the doors Front door handles (including front passenger door handle if equipped with entry function) Grip the driver’s door handle to unlock the door. Grip the passen- ger’s door handle to unlock all the doors.
Page 65 1-3. Opening, closing and locking the doors Back door (vehicles with entry function of front and back doors) Press the unlock button to unlock all the doors. The doors cannot be unlocked for 3 seconds after the doors are locked. Press the lock button to lock all the doors.
Page 66 1-3. Opening, closing and locking the doors Antenna location and effective range Antenna location ■ Vehicles with entry function of driver’s door Antennas outside cabin Antennas inside cabin Vehicles with entry function of front and back doors Antennas outside the cabin Antennas inside the cabin Antenna outside the luggage compartment...
Page 67 1-3. Opening, closing and locking the doors Effective range (areas within which the electronic key is ■ detected) Vehicles with entry function of driver’s door When locking or unlocking the door The system can be operated when the electronic key is within about 2.3 ft.
Page 68 1-3. Opening, closing and locking the doors Operation signals ■ A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) When the door cannot be locked by the lock sensor on the upper part ■...
Page 69 1-3. Opening, closing and locking the doors Alarms and warning lights ■ A combination of exterior and interior alarms as well as warning lights are used to prevent theft of the vehicle and accidents resulting from erroneous operation. Take appropriate measures in response to any warning message shown on the multi-information display.
Page 70 1-3. Opening, closing and locking the doors Alarm Situation Correction procedure The “POWER” switch was turned to ACCESSORY mode while the driver’s Interior alarm Turn the “POWER” door was open (or the pings continu- switch off and close driver’s door was opened ously the driver’s door while the “POWER”...
Page 71 1-3. Opening, closing and locking the doors Alarm Situation Correction procedure The electronic key has a Replace the electronic low battery key battery An attempt was made to Interior alarm start the hybrid system Start the hybrid sys- pings once without the electronic key tem with the elec- being present, or the elec-...
Page 72 1-3. Opening, closing and locking the doors Security feature ■ If a door is not opened within approximately 60 seconds after the vehicle is unlocked, the security feature automatically locks the vehicle again. Switching the door unlock function ■ It is possible to set which doors the entry function unlocks. STEP Turn the “POWER”...
Page 73 1-3. Opening, closing and locking the doors Battery-saving function ■ The battery-saving function will be activated in order to prevent the elec- tronic key battery and the 12-volt battery from being discharged while the vehicle is not in operation for a long time. ●...
Page 74 1-3. Opening, closing and locking the doors Conditions affecting operation ■ The smart key system, wireless remote control and immobilizer system use weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system, wireless remote control and immobilizer system from operating properly.
Page 75 1-3. Opening, closing and locking the doors Note for the entry function ■ ● Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 76 1-3. Opening, closing and locking the doors Note for locking the doors ■ ● Touching the door lock sensor while wearing gloves may delay or prevent lock operation. Remove the gloves and touch the lock sensor again. ● When the lock operation is performed using the lock sensor, recognition signals will be shown up to two consecutive times.
Page 77 1-3. Opening, closing and locking the doors Note for the unlocking function ■ ● A sudden approach to the effective range or door handle may prevent the doors from being unlocked. In this case, return the door handle to the original position and check that the doors unlock before pulling the door handle again.
Page 78 1-3. Opening, closing and locking the doors If the smart key system does not operate properly ■ ● Locking and unlocking the doors: Use the mechanical key. (P. 548) Starting the hybrid system: P. 549 ● Electronic key battery depletion ■...
Page 79 1-3. Opening, closing and locking the doors Certification for the smart key system ■ For vehicles sold in the U.S.A. FCC ID: NI4TMLF8-2 FCC ID: HYQ14ACX FCC ID: HYQ14ADF FCC ID: HYQ13CZD FCC ID: HYQ13CZE NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 80 (P. 66) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of the emitted radio waves.
Page 81: Smart Key System (Without Entry Function)
1-3. Opening, closing and locking the doors Smart key system (without entry function) Starting and stopping the hybrid system can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) PRIUS_OM_OM47857U_DVD_(U)
Page 82 1-3. Opening, closing and locking the doors Antenna location and effective range Antenna location ■ Antennas inside cabin Effective range (areas within which the electronic key is ■ detected) When starting the hybrid system or changing “POWER” switch modes The system can be operated when the electronic key is inside the vehicle.
Page 83 1-3. Opening, closing and locking the doors Conditions affecting operation ■ P. 74 Electronic key battery depletion ■ P. 78 To operate the system properly ■ Make sure to carry the electronic key when operating the system. Depending on the position and holding condition of the electronic key, the key may not be detected correctly and the system may not operate properly.
Page 84 1-3. Opening, closing and locking the doors Alarms and warning indicators ■ A combination of exterior and interior alarms are used to prevent theft of the vehicle and unforeseeable accidents resulting from erroneous operation. Take appropriate measures in response to any warning message shown on the multi-information display.
Page 85 1-3. Opening, closing and locking the doors Alarm Situation Correction procedure The electronic key has a Replace the electronic low battery key battery An attempt was made to Interior alarm start the hybrid system Start the hybrid sys- pings once without the electronic key tem with the elec- being present, or the elec-...
Page 86 1-3. Opening, closing and locking the doors Certification for the smart key system ■ P. 79 CAUTION Caution regarding interference with electronic devices ■ P. 80 PRIUS_OM_OM47857U_DVD_(U)
Page 87: Wireless Remote Control
1-3. Opening, closing and locking the doors Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle. Locks all the doors Check to see that all the side doors and back door are securely locked.
Page 88 1-3. Opening, closing and locking the doors Panic mode ■ When is pressed for longer than about one second, an alarm will sound intermittently and the vehicle lights will flash to deter any person from trying to break into or damage your vehicle. To stop the alarm, press any button on the electronic key.
Page 89: Side Doors
1-3. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the entry function, wireless remote control or door lock switch. Entry function (if equipped) ■ P. 63 Wireless remote control ■ P. 87 Door lock switch ■...
Page 90 1-3. Opening, closing and locking the doors Locking the front doors from the outside without a key STEP Move the inside lock button to the lock position. STEP Close the door. The door cannot be locked if the “POWER” switch is in ACCESSORY or ON mode, or the electronic key is left inside the vehicle.
Page 91 1-3. Opening, closing and locking the doors Automatic door locking and unlocking systems The following functions can be set or canceled: Function Operation Shift position linked Shifting the shift position out of P locks all door locking function doors. Shift position linked Shifting the shift position to P unlocks all door unlocking function doors.
Page 92 1-3. Opening, closing and locking the doors Shift the shift position to P or N, STEP and press and hold the door lock switch ( ) for about 5 seconds then release. The shift position corresponding to the desired function to be set are shown as follows.
Page 93 1-3. Opening, closing and locking the doors Using the mechanical key ■ The doors can also be locked and unlocked with the mechanical key. (P. 548) If a wrong key is used ■ The key cylinder rotates freely to isolate inside mechanism. Customization ■...
Page 94 1-3. Opening, closing and locking the doors CAUTION To prevent an accident ■ Observe the following precautions while driving the vehicle. Failure to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. ●...
Page 95: Back Door
1-3. Opening, closing and locking the doors Back door The back door can be locked/unlocked and opened by the following procedures. Locking and unlocking the back door ■ Entry function P. 63 Wireless remote control P. 87 Door lock switch P.
Page 96: Prius_Om_Om47857U_Dvd_(U
1-3. Opening, closing and locking the doors Luggage compartment light ■ The luggage compartment light turns on when the back door is opened with the luggage compartment light switch on. If the back door opener is inoperative ■ The back door can be unlocked from the inside. STEP Open the center deck board.
Page 97: Prius_Om_Om47857U_Dvd_(U
1-3. Opening, closing and locking the doors CAUTION Caution while driving ■ ● Keep the back door closed while driving. If the back door is left open, it may hit near-by objects while driving or lug- gage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
Page 98: Prius_Om_Om47857U_Dvd_(U
1-3. Opening, closing and locking the doors CAUTION Operating the back door ■ Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in death or serious injury. ● Remove any heavy loads, such as snow and ice, from the back door before opening it.
Page 99: Prius_Om_Om47857U_Dvd_(U
If a bicycle carrier or similar heavy object is attached to the back door, it may suddenly shut again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genuine Toyota part is recommended. PRIUS_OM_OM47857U_DVD_(U)
Page 100 Do not touch the damper stay rod with gloves or other fabric items. ● Damper stays Do not attach any accessories other than genuine Toyota parts to the back door. ● Do not place your hand on the damper stay or apply lateral forces to it.
Page 101: Adjustable Components (Seats, Mirrors, Steering Wheel)
1-4. Adjustable components (seats, mirrors, steering wheel) Front seats Manual seat (if equipped) Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (for driver’s side) PRIUS_OM_OM47857U_DVD_(U)
Page 102 1-4. Adjustable components (seats, mirrors, steering wheel) Power seat (if equipped for driver’s seat) Seat position adjustment switch Seatback angle adjustment switch Seat cushion (front) angle adjustment switch Vertical height adjustment switch Lumbar support adjustment switch Active head restraints When the occupant’s lower back presses against the seatback during a rear-end collision, the head restraint moves slightly for-...
Page 103 1-4. Adjustable components (seats, mirrors, steering wheel) Active head restraints ■ Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may make the inner struc- ture of the head restraint appear. This does not indicate a problem. During rear-end collision...
Page 104: Rear Seats
1-4. Adjustable components (seats, mirrors, steering wheel) Rear seats The seatbacks can be folded down. Before folding down the seatbacks STEP Park the vehicle in a safe place. Apply the parking brake firmly and shift the shift position to P. (P.
Page 105 1-4. Adjustable components (seats, mirrors, steering wheel) Folding down the seatbacks Fold the seatback down while pushing the lock release button. To return the rear seatbacks to their original positions, lift them up until they lock. Remove the seat belt from the guide ■...
Page 106 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION When folding the seatbacks down ■ Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not fold the seatbacks down while driving. ● Stop the vehicle on level ground, set the parking brake and shift the shift position to P.
Page 107: Head Restraints
1-4. Adjustable components (seats, mirrors, steering wheel) Head restraints Head restraints are provided for all seats. Front seats Pull the head restraints up. Down Push and hold the lock release button when lowering the head Lock restraint. release button Rear center seat Down Pull up or push down the head restraint while pressing the...
Page 108 1-4. Adjustable components (seats, mirrors, steering wheel) Removing the head restraints ■ Front and rear center seats Pull the head restraint up while pressing the lock release button. Lock release button Foldable type rear outside seats Pull the head restraint up while pressing the lock release buttons.
Page 109 1-4. Adjustable components (seats, mirrors, steering wheel) Installing the head restraints ■ Front and rear center seats Align the head restraint with the installa- tion holes and push it down to the lock position. Lock Press and hold the lock release button release when lowering the head restraint.
Page 110 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION Head restraint precautions ■ Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. ● Use the head restraints designed for each respective seat. ●...
Page 111: Seat Belts
1-4. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. Correct use of the seat belts ■ ● Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
Page 112 1-4. Adjustable components (seats, mirrors, steering wheel) Adjusting the seat belt shoulder anchor height (front seats) ■ Push the seat belt shoulder anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
Page 113 1-4. Adjustable components (seats, mirrors, steering wheel) Pre-collision seat belts (front seats of vehicles with pre-collision system) If the system determines that a collision is unavoidable, the front seat belts will retract before the collision. (P. 307) Emergency locking retractor (ELR) ■...
Page 114 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 115 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION Pregnant women ■ Obtain medical advice and wear the seat belt in the proper way. (P. 111) Women who are pregnant should position the lap belt as low as possible over the hips in the same manner as other occu- pants.
Page 116 ● If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Toyota dealer. Adjustable shoulder anchor ■ Always make sure the shoulder belt is positioned across the center of your shoulder.
Page 117 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there’s no obvious damage.
Page 118 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION Using a seat belt extender ■ ● Do not wear the seat belt extender if you can fasten the seat belt without the extender. ● Do not use the seat belt extender when installing a child restraint system because the belt will not securely hold the child restraint system, increas- ing the risk of death or serious injury in the event of an accident.
Page 119: Steering Wheel
1-4. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and STEP push the lever down. Adjust to the ideal position by STEP moving the steering wheel horizontally and vertically.
Page 120: Inside Rear View Mirror
1-4. Adjustable components (seats, mirrors, steering wheel) Inside rear view mirror The rear view mirror’s position can be adjusted to enable sufficient confirmation of the rear view in accordance with the driver’s seating posture. Adjusting the height of rear view mirror Adjust the height of the rear view mirror by moving it up and down.
Page 121 1-4. Adjustable components (seats, mirrors, steering wheel) Auto anti-glare inside rear view mirror (without garage door opener) Responding to the level of brightness of the headlights of vehicles behind, the reflected light is automatically reduced. Changing automatic anti-glare function mode ON/OFF When the automatic anti-glare function is in ON mode, the indi-...
Page 122 1-4. Adjustable components (seats, mirrors, steering wheel) To prevent sensor error (vehicles with auto anti-glare inside rear view ■ mirror) Without garage door opener To ensure that the sensors operate prop- erly, do not touch or cover them. With garage door opener CAUTION Caution while driving ■...
Page 123 1-4. Adjustable components (seats, mirrors, steering wheel) NOTICE Rear view mirror adjustment (vehicles with LKA [Lane-Keeping Assist]) ■ To ensure that the LKA operates properly, make sure that it does not block the LKA camera sensor. ITO24P134 PRIUS_OM_OM47857U_DVD_(U)
Page 124: Outside Rear View Mirrors
1-4. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted using the switch. To select a mirror to adjust, STEP press the switch. Left Right To adjust the mirror, press the STEP switch. Right Down Left Folding the mirrors...
Page 125 1-4. Adjustable components (seats, mirrors, steering wheel) Mirror angle can be adjusted when ■ The “POWER” switch is in ACCESSORY or ON mode. When the mirrors are fogged up (vehicles with outside rear view mirror ■ defoggers) The outside rear view mirrors can be cleared using the mirror defoggers. Turn on the rear window defogger to turn on the outside rear view mirror defoggers.
Page 126: Opening And Closing The Windows And Moon Roof Power Windows
1-5. Opening and closing the windows and moon roof Power windows The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: One-touch closing Closing One-touch opening Opening : To stop the window partway, operate the switch in the oppo- site direction.
Page 127 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after perform- ing the above procedure correctly, have the vehicle inspected by your Toyota dealer. PRIUS_OM_OM47857U_DVD_(U)
Page 128 1-5. Opening and closing the windows and moon roof Customization ■ The one-touch closing operation can be disabled, except for the driver’s seat. (Customizable features P. 596) CAUTION Closing the windows ■ Observe the following precautions. Failing to do so may result in death or serious injury. ●...
Page 129: Moon Roof With Solar Panel
1-5. Opening and closing the windows and moon roof  Moon roof with Solar Panel Use the overhead switches to open, close, and tilt the moon roof up and down. Tilt up/down ■ Tilt up Push and hold “OPEN” and then release.
Page 130 1-5. Opening and closing the windows and moon roof Open/close ■ Open Push and hold “OPEN” at the tilt position then release. Lightly push on either side of the switch stops the moon roof partway. The moon roof stops slightly before the fully open position to reduce the wind noise.
Page 131 After this, to make the automatic opening function and jam protection func- tion available again, press and hold the “OPEN” switch until the moon roof opens fully and then closes slightly. If the functions do not activate, contact your Toyota dealer. PRIUS_OM_OM47857U_DVD_(U)
Page 132 1-5. Opening and closing the windows and moon roof CAUTION Opening the moon roof ■ Observe the following precautions. Failing to do so may cause death or serious injury. ● Do not allow any passengers to put their hands or heads outside the vehi- cle while it is moving.
Page 133 1-5. Opening and closing the windows and moon roof NOTICE To prevent damage to the moon roof ■ ● Before opening, make sure that there are no foreign objects such as stones or ice around the opening. ● Do not hit the face or edge of the moon roof with hard objects. ●...
Page 134: 1-6. Refueling
1-6. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: Before refueling the vehicle ■ ● Turn the “POWER” switch off and close all the doors and win- dows. ● Confirm the type of fuel. (P. 135) Opening the fuel tank cap ■...
Page 135 1-6. Refueling Closing the fuel tank cap After refueling, turn the fuel tank cap until you hear a click. Once the cap is released, it will turn slightly in the opposite direction. Fuel types ■ Use unleaded gasoline. (Octane rating 87 [Research Octane Number 91] or higher) Gasoline price setting screen ■...
Page 136 Do not top off the fuel tank When replacing the fuel tank cap ■ Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 137 1-6. Refueling NOTICE Refueling ■ Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the emission control system to operate abnormally or damaging fuel system components or the vehicle’s painted surface. PRIUS_OM_OM47857U_DVD_(U)
Page 138: Theft Deterrent System Immobilizer System
1-7. Theft deterrent system Immobilizer system The vehicle’s keys have built-in transponder chips that prevent the hybrid system from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. This system is designed to help prevent vehicle theft but does not guarantee absolute security against all vehicle thefts.
Page 139 1-7. Theft deterrent system Certifications for the immobilizer system ■ For vehicles sold in the U.S.A. FCC ID: NI4TMIMB-1 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 140: Safety Information Correct Driving Posture
1-8. Safety information Correct driving posture Drive with a good posture as follows: Sit upright and well back in the seat. (P. 101) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
Page 141 1-8. Safety information CAUTION While driving ■ ● Do not adjust the position of the driver’s seat. Doing so could cause the driver to lose control of the vehicle. ● Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
Page 142: Srs Airbags
1-8. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. SRS front airbags SRS driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
Page 143 1-8. Safety information SRS side and curtain shield airbags SRS side airbags Can help protect the torso of the front seat occupants SRS curtain shield airbags Can help protect primarily the head of occupants in the outer seats PRIUS_OM_OM47857U_DVD_(U)
Page 144 1-8. Safety information SRS airbag system components Front passenger airbag Side impact sensors (front) “AIR BAG ON” and “AIR BAG Seat belt pretensioners and OFF” indicator lights force limiters Side airbags Driver’s seat belt buckle switch Curtain shield airbags Driver’s seat position sensor Front passenger occupant classification system (ECU Driver’s knee airbag...
Page 145 1-8. Safety information Your vehicle is equipped with ADVANCED AIRBAGS designed based on the US motor vehicle safety standards (FMVSS208). The airbag sensor assembly (ECU) controls airbag deployment based on infor- mation obtained from the sensors etc. shown in the system compo- nents diagram above.
Page 146 1-8. Safety information SRS airbag deployment conditions (SRS front airbags) ■ ● The SRS front airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approxi- mately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 147 1-8. Safety information Conditions under which the SRS airbags may deploy (inflate), other ■ than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. ●...
Page 148 Vehicle rollover When to contact your Toyota dealer ■ In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. ● Any of the SRS airbags has been inflated. ● The front of the vehicle is damaged or...
Page 149 1-8. Safety information ● A portion of a door is damaged or deformed, or the vehicle was involved in an accident that was not severe enough to cause the SRS side and cur- tain shield airbags to inflate. ● The pad section of the steering wheel, dashboard near the front passenger air- bag or lower portion of the driver’s side instrument panel is scratched, cracked,...
Page 150 1-8. Safety information CAUTION SRS airbag precautions ■ Observe the following precautions regarding the SRS airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly.
Page 151 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 152 1-8. Safety information CAUTION SRS airbag precautions ■ ● Do not sit on the edge of the seat or lean against the dashboard. ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger.
Page 153 1-8. Safety information CAUTION SRS airbag precautions ■ ● Do not attach anything to or lean any- thing against areas such as the dash- board, steering wheel pad and lower portion of the instrument panel. These items can become projectiles when the SRS driver, front passenger and knee airbags deploy.
Page 154 If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. ● Do not place anything, such as a cushion, on the front passenger’s seat.
Page 155 Modification and disposal of SRS airbag system components ■ Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury. ●...
Page 156: Front Passenger Occupant Classification System
1-8. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for the front passenger.
Page 157 1-8. Safety information Condition and operation in the front passenger occupant classification system Adult ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights ON” Indicator/ SRS warning light warning light Front passenger’s seat belt reminder light Flashing Front passenger airbag Side airbag on the front passenger seat Devices...
Page 158 1-8. Safety information Unoccupied ■ “AIR BAG ON” and “AIR BAG OFF” Not illuminated indicator lights Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Devices Activated Curtain shield airbag in the front passen- ger side...
Page 159 1-8. Safety information : The system judges a person of adult size as an adult. When a smaller adult sits in the front passenger seat, the system may rec- ognize him/her as a child depending on his/her physique and pos- ture.
Page 160 1-8. Safety information CAUTION Front passenger occupant classification system precautions ■ Observe the following precautions regarding front passenger occupant clas- sification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger’s seat belt plate has not been left inserted into the buckle before someone sits in the front passenger seat.
Page 161 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the rear seat should not contact the front seatbacks.
Page 162: Child Restraint Systems
1-8. Safety information Child restraint systems A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 163 1-8. Safety information Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child. Rear facing  Infant seat/convertible seat Forward facing  Convertible seat Booster seat PRIUS_OM_OM47857U_DVD_(U)
Page 164 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 165 1-8. Safety information CAUTION Child restraint precautions ■ ● Never install a rear-facing child restraint system on the front passenger seat even if the “AIR BAG OFF” indicator light is illuminated. In the event of an accident, the force of the rapid inflation of the front passenger airbag can cause death or serious injury to the child if the rear-facing child restraint system is installed on the front passenger seat.
Page 166 1-8. Safety information CAUTION When children are in the vehicle ■ Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death.
Page 167: Installing Child Restraints
1-8. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Chil- dren) system.
Page 168 1-8. Safety information Installation with LATCH system STEP Widen the gap between the seat cushion and seatback slightly. Type A Latch the hooks of the lower STEP straps onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor.
Page 169 1-8. Safety information Type B Latch the buckles onto the STEP LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor. For owners in Canada: The symbol on a child restraint system indicates the presence of a lower connector system.
Page 170 1-8. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear facing Infant seat/convertible seat ■ Place the child restraint system STEP on the rear seat facing the rear of the vehicle. Run the seat belt through the STEP child restraint system and insert the plate into the buckle.
Page 171 1-8. Safety information While pushing the child restraint STEP system down into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 172 1-8. Safety information Fully extend the shoulder belt STEP and then allow it to retract slightly in order to activate the ALR lock mode. Lock mode allows the seat belt to retract only. While pushing the child restraint STEP system into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place.
Page 173 1-8. Safety information Booster seat ■ Place the child restraint system STEP on the seat facing the front of the vehicle. Sit the child in the child restraint STEP system. Fit the seat belt to the child restraint system according to the manufacturer’s instruc- tions and insert the plate into the buckle.
Page 174 1-8. Safety information Removing a child restraint installed with a seat belt Press the buckle release button and fully retract the seat belt. Child restraint systems with a top tether strap STEP Secure the child restraint system using a seat belt or the LATCH anchors, and do the following.
Page 175 1-8. Safety information Non-foldable type outside seats Remove the head restraint. Center seat Adjust the head restraint to the upmost position. PRIUS_OM_OM47857U_DVD_(U)
Page 176 1-8. Safety information Open the anchor bracket cover, STEP latch the hook onto the anchor bracket and tighten the top tether strap. Make sure the top tether strap is securely latched. STEP Outside only: Do the following. Foldable type Adjust the head restraint to the downmost position.
Page 177 1-8. Safety information Laws and regulations pertaining to anchors ■ The LATCH system conforms to FMVSS225 or CMVSS210.2. Child restraint systems conforming to FMVSS213 or CMVSS213 specifica- tions can be used. This vehicle is designed to conform to the SAE J1819. CAUTION When installing a booster seat ■...
Page 178 1-8. Safety information CAUTION When installing a child restraint system ■ ● Only put a forward-facing child restraint system on the front seat when unavoid- able. When installing a forward-facing child restraint system on the front passenger seat, move the seat as far back as pos- sible even if the “AIR BAG OFF”...
Page 179 1-8. Safety information CAUTION Do not use a seat belt extender ■ If a seat belt extender is used when installing a child restraint system, the seat belt will not securely hold the child restraint system, which could cause death or serious injury to the child or other passengers in the event of sud- den braking, sudden swerving or an accident.
Page 180 1-8. Safety information PRIUS_OM_OM47857U_DVD_(U)
Page 181: When Driving
When driving 2-1. Driving procedures 2-3. Operating the lights and windshield wipers Driving the vehicle.... 182 Headlight switch....252 Power (ignition) switch ..194 Fog light switch ....258 EV drive mode ....201 Windshield wipers Hybrid transmission ..204 and washer ....
Page 182: 2-1. Driving Procedures
2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing: Starting the hybrid system ■ P. 194 Driving ■ STEP With the brake pedal depressed, shift the shift position to D. (P. 204) Check that the shift position indicator shows D.
Page 183 Breaking in your new Toyota ■ To extend the life of the vehicle, observing the following precautions is rec- ommended: ●...
Page 184 2-1. Driving procedures Operating your vehicle in a foreign country ■ Comply with the relevant vehicle registration laws and confirm the availability of the correct fuel. (P. 568) For efficient use ■ ● Shift the shift position to D when driving. In the N position, the gasoline engine operates but electricity cannot be generated.
Page 185 2-1. Driving procedures CAUTION When starting the vehicle ■ Always keep your foot on the brake pedal while stopped with the hybrid sys- tem operating. This prevents the vehicle from creeping. When driving the vehicle ■ ● Do not drive if you are unfamiliar with the location of the brake and accel- erator pedals to avoid depressing the wrong pedal.
Page 186 Large amounts of exhaust in the vehi- cle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immediately. ●...
Page 187 2-1. Driving procedures CAUTION ● Do not adjust the positions of the steering wheel, the seat, or the inside or outside rear view mirrors while driving. Doing so may result in a loss of vehicle control that can cause accidents, resulting in death or serious injury.
Page 188 If you hear a squealing or scraping noise (brake pad wear limit indica- ■ tors) Have your Toyota dealer check and replace the brake pads as soon as pos- sible. Rotor damage may result if the pads are not replaced when needed.
Page 189 2-1. Driving procedures CAUTION ● If the vehicle is stopped on an incline, in order to prevent accidents caused by the vehicle rolling forward or backward, always depress the brake pedal and securely apply the parking brake as needed. ● Avoid revving or racing the engine.
Page 190 The exhaust system should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
Page 191 2-1. Driving procedures CAUTION When taking a nap in the vehicle ■ Always turn the hybrid system off. Otherwise, if you accidentally move the shift lever or depress the accelerator pedal, this could cause an accident or fire due to hybrid system overheating. Additionally, if the vehicle is parked in a poorly ventilated area, exhaust gases may collect and enter the vehicle, leading to death or a serious health hazard.
Page 192 2-1. Driving procedures NOTICE When driving the vehicle ■ ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain driving torque. ● Do not use the accelerator pedal or depress the accelerator and brake pedals at the same time to hold the vehicle on a hill.
Page 193 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
Page 194: Power (Ignition) Switch
2-1. Driving procedures Power (ignition) switch Performing the following operations when carrying the electronic key on your person starts the hybrid system or changes “POWER” switch modes. Starting the hybrid system ■ STEP Check that the parking brake is set. STEP Firmly depress the brake pedal.
Page 195 2-1. Driving procedures STEP Check that the “READY” indicator is on. If the “READY” indicator changes from a flashing light to a solid light and the buzzer sounds, the hybrid system is starting nor- mally. The vehicle will not move when the “READY” indicator is off. The vehicle can move when the “READY”...
Page 196 2-1. Driving procedures Changing “POWER” switch modes ■ Modes can be changed by pressing the “POWER” switch with the brake pedal released. (The mode changes each time the switch is pressed.) The emergency flashers can be used. ACCESSORY mode Some electrical components such as the audio system can be used.
Page 197 Wait until the “READY” indicator has illuminated. Conditions affecting operation ■ P. 74 Notes for the entry function ■ P. 75 If the hybrid system does not start ■ The immobilizer system may not have been deactivated. (P. 138) Contact your Toyota dealer. PRIUS_OM_OM47857U_DVD_(U)
Page 198 ■ If the “READY” indicator does not come on when you press the “POWER” switch with the shift position in P and the brake pedal depressed, contact your Toyota dealer immediately. If the hybrid system is malfunctioning ■ P. 501 If the electronic key battery is depleted ■...
Page 199 ■ The “POWER” switch will not be able to be turned off. In such a case, the switch can be turned off after applying the parking brake. Have the vehicle inspected by your Toyota dealer immediately. Ending display ■ When the “POWER” switch is turned off, each of the following will be dis- played on the multi-information display, and will extinguish after approxi- mately 30 seconds.
Page 200 “POWER” switch is off. Symptoms indicating a malfunction with the “POWER” switch ■ If the “POWER” switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction. Con- tact your Toyota dealer immediately. PRIUS_OM_OM47857U_DVD_(U)
Page 201: Ev Drive Mode
2-1. Driving procedures EV drive mode In EV drive mode, the electric motor (traction motor), powered by the hybrid battery (traction battery), is used to drive the vehicle. This mode allows you to drive in residential areas late at night, or in indoor parking lots etc.
Page 202 2-1. Driving procedures Situations in which EV drive mode cannot be turned on ■ It may not be possible to turn EV drive mode on in the following situations. If it cannot be turned on, a buzzer will sound and a message will be shown on the multi-information display.
Page 203 2-1. Driving procedures Automatic cancelation of EV drive mode ■ When driving in EV drive mode, the gasoline engine may automatically restart in the following situations. When EV drive mode is canceled, a buzzer will sound and the EV drive mode indicator will flash and go off. ●...
Page 204: Hybrid Transmission
2-1. Driving procedures Hybrid transmission Select a shift position appropriate for the driving conditions. Shifting the shift lever ■ Shift lever Operate the shift lever gently and ensure correct shifting operation. When shifting to the D or R positions, move the shift lever along the shift gate.
Page 205 2-1. Driving procedures Shift position indicator The position of the frame on the shift position indicator changes in accordance with the current shift position. When any shift position other than D or B is selected, the arrow toward B and B position indicator disappear from the shift position indicator. When selecting the shift position, make sure that the shift position has been changed to the desired position by checking the shift position indica- tor provided on the instrument cluster.
Page 206 2-1. Driving procedures Selecting a driving mode ■ The following modes can be selected to suit driving conditions: Eco drive mode Suitable for improving the fuel economy, because the torque cor- responding to the accelerator pedal depression amount can be generated more smoothly than it is in normal conditions and the operation of the air conditioning system (heating/cooling) will be minimized.
Page 207 2-1. Driving procedures P position switch When shifting the shift position to P ■ Fully stop the vehicle and set the parking brake, and then press the P position switch. When shift position changed to P, the indicator comes Check that the P position is illumi- nated on the shift position indica- tor.
Page 208 2-1. Driving procedures Operation of the air conditioning system in Eco drive mode ■ Eco drive mode controls the heating/cooling operations and fan speed of the air conditioning system to enhance fuel efficiency. (P. 206) To improve air conditioning performance, adjust the fan speed or turn off Eco drive mode. For the shift positions ■...
Page 209 2-1. Driving procedures ● Situations where the shift position will automatically change to N: • When the P position switch is pressed while the vehicle is running. • When an attempt is made to select the R position by moving the shift lever when the vehicle is moving forward.
Page 210 2-1. Driving procedures About engine braking ■ When shift position B is selected, releasing the accelerator pedal will apply engine braking. ● When the vehicle is driven at high speeds, compared to ordinary gaso- line-fueled vehicles, the engine braking deceleration is felt less than that of other vehicles.
Page 211 For the shift lever ■ Do not remove the shift lever knob or use anything but a genuine Toyota shift lever knob. Also, do not hang anything on the shift lever. Doing so could prevent the shift lever from returning to position, causing unexpected accidents to occur when the vehicle is in motion.
Page 212 If any of the following situations occurs, P position control system malfunc- tions are possible. Immediately stop the vehicle in a safe place on level ground, apply the park- ing brake, and then contact your Toyota dealer. ● When the “P LOCK MALFUNCTION” warning message appears on the multi-information display.
Page 213: Turn Signal Lever
2-1. Driving procedures Turn signal lever The turn signal lever can be used to show the following intention of the driver: Right turn Left turn Lane change to the right (push and hold the lever partway) The right hand signals will flash until you release the lever.
Page 214: Parking Brake
2-1. Driving procedures Parking brake To set the parking brake, fully depress the parking brake pedal with your left foot while U.S.A. Canada depressing the brake pedal with your right foot. (Depressing the pedal again releases the parking brake.) Parking brake engaged warning buzzer ■...
Page 215: Horn
2-1. Driving procedures Horn To sound the horn, press on or close to the mark. After adjusting the steering wheel ■ Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (P.
Page 216: Instrument Cluster
2-2.Instrument cluster Gauges and meters The units used on the display may differ depending on the target region. The following gauges and meters and display illuminate when the “POWER” switch is in ON mode: Fuel gauge Displays the quantity of fuel remaining in the tank. Speedometer Displays the vehicle speed.
Page 217 2-2. Instrument cluster Touch tracer display (if equipped) When the audio control switches, climate control switches, “DISP” button or “TRIP” button of the steering wheel are touched, the touch tracer display will appear in front of the gauges, with the touched button highlighted to allow the driver to identify the button that is being operated.
Page 218 2-2. Instrument cluster MPH or km/h button The speed units can be selected MPH or km/h. Press the button to switch the display between MPH and km/h. PRIUS_OM_OM47857U_DVD_(U)
Page 219 2-2. Instrument cluster Instrument panel light control The brightness of the instrument panel lights can be adjusted by turn- ing the dial. Brighter Darker Brightness of the instrument panel light ■ If the headlight switch is turned on while the surrounding area is dark, the instrument panel lights will dim.
Page 220 2-2. Instrument cluster CAUTION To prevent an accident ■ Do not place anything or attach a sticker Instrument cluster in front of the instrument cluster. The item may obscure or obstruct the display, or could reflect off the display, possibly causing an accident.
Page 221: Indicators And Warning Lights
2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and instrument panel inform the driver of the status of the vehicle’s vari- ous systems. For the purpose of explanation, the following illustration displays all indicators and warning lights illuminated.
Page 222 2-2. Instrument cluster Indicators ■ The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator “ECO MODE” (P. 213) indicator (P. 206) Headlight indicator Power mode indicator (P. 252) (P. 206) (U.S.A.) Tail light indicator Cruise control indicator (P.
Page 223 Have the vehicle inspected by your Toyota dealer. : The light flashes to indicate that the system is operating.
Page 224: Warning Lights
There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer.
Page 225: Multi-Information Display
2-2. Instrument cluster Multi-information display The multi-information display presents the driver with a variety of driving-related data, including the clock. ● Energy monitor (P. 44) ● Hybrid System Indicator (P. 226) ● 5-minute/1-minute fuel consumption (P. 52) ● Monthly fuel consumption record/eco savings record (P. 55) ●...
Page 226 2-2. Instrument cluster Switching the display To switch the display, press “DISP” button. On vehicles with touch tracer dis- play, the steering switches opera- tion status is displayed on the instrument cluster for confirma- tion purposes. (P. 217) To switch the odometer, trip meter and distance to empty, press “TRIP”...
Page 227 2-2. Instrument cluster Names and meaning of each icons ■ Hybrid battery (traction bat- tery) status (P. 50) EV indicator The EV indicator comes on when the vehicle is driven using only the electric motor (traction motor) or the gasoline engine is stopped. Eco Driving Indicator Light Turns on when the vehicle is driven in Eco-friendly.
Page 228 2-2. Instrument cluster Reading Hybrid System Indicator ■ Charge area Eco area Power area Hybrid Eco area As shown below, the driving conditions of the vehicle can be con- firmed by checking the status of the indicator bar. PRIUS_OM_OM47857U_DVD_(U)
Page 229 2-2. Instrument cluster Hybrid System Indicator Charge area: Shows regenerative charging. (P. 34) Hybrid Eco area: Shows that gasoline engine power is not being used very often. Eco area: Shows that the vehicle is driven in Eco-friendly. Power area: Shows that the driving power is more than the upper limit of Eco driving (during full power driving etc.).
Page 230 2-2. Instrument cluster Odometer/trip meter/distance to empty Switching the display ■ The display changes as follows each time the “TRIP” button is pressed. Also, if the button is kept pressed down while the trip meter is being displayed, the trip meter will be reset to 0.
Page 231 2-2. Instrument cluster Display items ■ ● Odometer Displays the total distance the vehicle has been driven. ● Trip meter Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and display different dis- tances independently.
Page 232 2-2. Instrument cluster Clock The clock can be adjusted by pressing the buttons. Adjusts the hours. Adjusts the minutes. Rounds to the nearest hour. : e.g. 1:00 to 1:29 1:00 1:30 to 1:59 2:00 Setting up the displays Press the “DISP” button until the STEP “SETTINGS”...
Page 233 2-2. Instrument cluster Setting the gasoline price ■ Select “GASOLINE PRICE”. STEP Press and hold the “DISP” button to enter the setting mode. Select gasoline price by pressing STEP the “DISP” or “TRIP” button. Press and hold the button to change the amount continuously.
Page 234 2-2. Instrument cluster Switching the fuel consumption display ■ Select “FUEL CONSU. DISP.”. STEP Press and hold the “DISP” button to enter the setting mode. Select “CONSUMP.” or “ECO STEP SAVINGS”. Press and hold the “DISP” button to finish setting. PRIUS_OM_OM47857U_DVD_(U)
Page 235 2-2. Instrument cluster Setting the comparison consumption ■ Select “COMP. CONSUMP- STEP TION”. Press and hold the “DISP” button to enter the setting mode. Select the comparison consump- STEP tion by pressing the “DISP” or “TRIP” button. Press and hold the button to change the amount continuously.
Page 236 2-2. Instrument cluster Setting the calendar ■ Select “CALENDAR”. STEP Press and hold the “DISP” button to enter the setting mode. Select the date by pressing the STEP “DISP” or “TRIP” button. Press and hold the button to change the date continuously. If neither button is operated for approximately 5 seconds, the set- ting will be changed and the...
Page 237 2-2. Instrument cluster Switching the EV indicator and Eco Driving Indicator Light ■ activated or deactivated Select “EV/ECO”. STEP Press and hold the “DISP” button to enter the setting mode. Select “ON” or “OFF”. STEP Press and hold the “DISP” button to finish setting.
Page 238 2-2. Instrument cluster Switching the steering switch operation display on/off (if ■ equipped) Select “STEERING SWITCH”. STEP Press and hold the “DISP” button to enter the setting mode. Select “ON” or “OFF”. STEP Press and hold the “DISP” button to finish setting. PRIUS_OM_OM47857U_DVD_(U)
Page 239 2-2. Instrument cluster Selecting 12h/24h clock display ■ Select “CLOCK”. STEP Press and hold the “DISP” button to enter the setting mode. Select “12h” or “24h”. STEP Press and hold the “DISP” button to finish setting. PRIUS_OM_OM47857U_DVD_(U)
Page 240 2-2. Instrument cluster Selecting the language ■ Select “LANGUAGE”. STEP Press and hold the “DISP” button to enter the setting mode. Select the language you want to STEP read. Press and hold the “DISP” button to set the language. PRIUS_OM_OM47857U_DVD_(U)
Page 241 2-2. Instrument cluster Turning off the multi-information display ■ Select “SCREEN OFF”. STEP Press and hold the “DISP” button to enter the setting mode. Select “OFF”. STEP Press and hold the “DISP” button to turn off the multi-information display. To re-display the multi-information display, press the “DISP”...
Page 242 2-2. Instrument cluster System check display ■ After switching the “POWER” switch to ON mode, “welcome to PRIUS” is dis- played while system operation checked. When the system check is com- plete, the normal screen will return. Ending display ■ P.
Page 243 2-2. Instrument cluster Driving in Eco drive mode ■ The multi-information display will automatically switch the display to Hybrid System Indicator, regardless of which display is currently being shown. (P. 226) Touch tracer display (if equipped) ■ ● The touch tracer display can be set to not display even if the steering switches are touched.
Page 244 2-2. Instrument cluster Vacuum fluorescent display ■ Small spots or light spots may appear on the display. This phenomenon is characteristic of vacuum fluorescent displays, and there is no problem to continue using the display. NOTICE Steering switches ■ To prevent damage to the steering switches, observe the following precau- tions.
Page 245: Head-Up Display
2-2. Instrument cluster  Head-up display The head-up display can be used to project vehicle speed and other information onto the windshield. Head-up display Display brightness will change automatically according to the brightness of the surrounding area. (Head-up display) main switch Turn-by-turn navigation switch (if equipped)
Page 246 2-2. Instrument cluster Head-up display contents ■ ● Speedometer Displays the vehicle speed. ● Hybrid System Indicator Provides assistance for Eco-friendly driving. ● Turn-by-turn navigation Displays a notification of upcoming intersections during navigation system route guidance. (P. 249) ● Dynamic radar cruise control Displays the approach warning.
Page 247 2-2. Instrument cluster Switching the head-up display Display items can be switched by pressing the “HUD” main switch. Speedometer Displays the vehicle speed. Speedometer and Hybrid Sys- tem Indicator Displays Hybrid System Indicator under the speedometer. (P. 226) When on, the indicator light on the “HUD”...
Page 248 2-2. Instrument cluster Setting up the display Setting the brightness ■ The brightness of the display is automatically adjusted in accor- dance with the brightness of the surrounding environment. How- ever, the brightness can also be manually adjusted in 5 stages. Darker Brighter The brightness can be manually...
Page 249 2-2. Instrument cluster Turn-by-turn navigation display (if equipped) When the vehicle approaches an intersection, the direction the vehicle should go is guided by the arrow. When the vehicle approaches an intersection, the route guidance will start and the distance* to the intersection will also be dis- played.
Page 250 2-2. Instrument cluster When driving on snowy roads or in other bright environments ■ When the highest level of brightness has been reached, the display can be made even brighter by pressing and holding “” on the brightness control button. Pressing “”...
Page 251 2-2. Instrument cluster CAUTION Before using the head-up display ■ Check that the position and brightness of the head-up display image does not interfere with safe driving. Incorrect adjustment of the image’s position or brightness may obstruct the driver’s view and lead to an accident, resulting in death or serious injury.
Page 252: 2-3. Operating The Lights And Windshield Wipers
2-3. Operating the lights and windshield wipers Headlight switch The headlights can be operated manually or automatically. Turning the end of the lever turns on the lights as follows: Type A The headlights, park- ing lights and so on turn on and off auto- matically (when the “POWER”...
Page 253 2-3. Operating the lights and windshield wipers Type B The daytime running lights turn on. side marker, parking, tail, license plate, daytime run- ning lights and instru- ment panel lights turn The headlights and all the lights listed above turn on. The daytime running lights turn off.
Page 254 2-3. Operating the lights and windshield wipers Type C The daytime running lights turn on. side marker, parking, tail, license plate, daytime run- ning lights and instru- ment panel lights turn The headlights and all the lights listed above (except day- time running lights) turn on.
Page 255 2-3. Operating the lights and windshield wipers Turning on the high beam headlights With the headlights on, push the lever away from you to turn on the high beams. Pull the lever toward you to the center position to turn the high beams off.
Page 256 2-3. Operating the lights and windshield wipers Headlight control sensor (if equipped) ■ The sensor may not function properly if an object is placed on the sensor, or any- thing that blocks the sensor is affixed to the windshield. Doing so interferes with the sensor detecting the level of ambient light and may cause the automatic headlight sys- ITO23P105...
Page 257 2-3. Operating the lights and windshield wipers Automatic headlight leveling system (if equipped) ■ The level of the headlights is automatically adjusted according to the number of passengers and the loading condition of the vehicle to ensure that the headlights do not interfere with other road users. Customization ■...
Page 258: Fog Light Switch
2-3. Operating the lights and windshield wipers  Fog light switch The fog lights secure excellent visibility in difficult driving condi- tions, such as in rain and fog. Type A Turns the fog lights Turns the fog lights  : If equipped PRIUS_OM_OM47857U_DVD_(U)
Page 259 2-3. Operating the lights and windshield wipers Type B Turns the fog lights Turns the fog lights Fog lights can be used when ■ The headlights are on in low beam. NOTICE To prevent 12-volt battery discharge ■ Do not leave the lights on longer than necessary when the hybrid system is off.
Page 260: Windshield Wipers And Washer
2-3. Operating the lights and windshield wipers Windshield wipers and washer When intermittent windshield wiper operation is selected, wiper intervals can be also adjusted. The wiper operation is selected by moving the lever as follows. Type A Intermittent wind- shield wiper opera- tion speed wind-...
Page 261 2-3. Operating the lights and windshield wipers Washer/wiper dual opera- tion The wipers will automatically operate a couple of times after the washer squirts. If the headlights are on, the headlight cleaner will operate once. Type B Intermittent wind- shield wiper opera- tion speed wind-...
Page 262 2-3. Operating the lights and windshield wipers Increases the intermittent windshield wiper frequency Decreases the intermittent windshield wiper frequency Washer/wiper dual opera- tion The wipers will automatically operate a couple of times after the washer squirts. If the headlights are on, the headlight cleaner will operate once.
Page 263 Do not operate the switch continually as the washer fluid pump may over- heat. When a nozzle becomes blocked ■ In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. To prevent 12-volt battery discharge ■...
Page 264: Rear Window Wiper And Washer
2-3. Operating the lights and windshield wipers Rear window wiper and washer Turning the end of the lever turns on the rear window wiper and washer as follows: Type A Intermittent window wiper operation Normal window wiper operation Washer/wiper dual operation Washer/wiper dual...
Page 265 2-3. Operating the lights and windshield wipers Type B Intermittent window wiper operation Normal window wiper operation Washer/wiper dual operation Washer/wiper dual operation The rear window wiper and washer can be operated when ■ The “POWER” switch is in ON mode. If no washer fluid sprays ■...
Page 266 2-3. Operating the lights and windshield wipers NOTICE When the rear window is dry ■ Do not use the wiper, as it may damage the rear window. When the washer fluid tank is empty ■ Do not operate the switch continually as the washer fluid pump may over- heat.
Page 267: Headlight Cleaner Switch
2-3. Operating the lights and windshield wipers  Headlight cleaner switch Washer fluid can be sprayed on the headlights. Press the switch to clean the headlights. The headlight cleaners can be operated when ■ The “POWER” switch is in ON mode and the headlight switch is turned on. If equipped, the headlight switch is in the “AUTO”...
Page 268: Using Other Driving Systems Cruise Control
2-4. Using other driving systems  Cruise control Use the cruise control to maintain a set speed without depressing the accelerator pedal. Cruise control switch Indicators Setting the vehicle speed ■ Press the “ON-OFF” button to STEP activate the cruise control. Cruise control indicator will come on.
Page 269 2-4. Using other driving systems Adjusting the set speed ■ To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 270 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. PRIUS_OM_OM47857U_DVD_(U)
Page 271 2-4. Using other driving systems CAUTION To avoid operating the cruise control by mistake ■ Switch the cruise control off using the “ON-OFF” button when not in use. Situations unsuitable for cruise control ■ Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 272: Dynamic Radar Cruise Control
2-4. Using other driving systems  Dynamic radar cruise control Dynamic radar cruise control supplements conventional cruise con- trol with a vehicle-to-vehicle distance control. In vehicle-to-vehicle distance control mode, the vehicle automatically accelerates or decelerates in order to maintain a set following distance from vehi- cles ahead.
Page 273 2-4. Using other driving systems Setting the vehicle speed (vehicle-to-vehicle distance con- ■ trol mode) Press the “ON-OFF” button to STEP activate the cruise control. Radar cruise control indicator will come on. Press the button again to deactivate the cruise control. Accelerate or decelerate the STEP vehicle to the desired speed,...
Page 274 2-4. Using other driving systems Adjusting the set speed ■ To change the set speed, operate the lever until the desired set speed is displayed. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 275 2-4. Using other driving systems Changing the vehicle-to-vehicle distance ■ Pressing the button changes Preceding vehicle mark vehicle-to-vehicle dis- tance as follows: Long Medium Short The vehicle-to-vehicle distance is set automatically to long mode when the “POWER” switch is turned to ON mode. If a vehicle is running ahead of you, the preceding vehicle mark will also be displayed.
Page 276 2-4. Using other driving systems Canceling and resuming the speed control ■ Pulling the lever toward you cancels the cruise control. The speed setting is also can- celed when the brakes are applied. Pushing lever resumes the cruise control and returns vehicle speed ITO24P127 to the set speed.
Page 277 2-4. Using other driving systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 400 ft. (120 m) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suit- able following distance from the vehicle ahead.
Page 278 2-4. Using other driving systems Example of constant speed cruising When there are no vehicles ahead The vehicle travels at the speed set by the driver. The desired vehicle-to- vehicle distance can also be set by operating the vehicle-to-vehicle dis- tance control.
Page 279 2-4. Using other driving systems Approach warning When your vehicle is too close to a vehicle ahead, and sufficient automatic deceleration via the cruise control is not possible, the dis- play will flash and the buzzer will sound to alert the driver. An exam- ple of this would be if another driver cuts in front of you while you are following a vehicle.
Page 280 2-4. Using other driving systems Selecting conventional constant speed control mode Constant speed control mode differs from vehicle-to-vehicle distance control mode. When constant speed mode is selected, your vehicle will maintain a set speed regardless of whether or not there are other vehicles in the lane ahead.
Page 281 2-4. Using other driving systems If the “POWER” switch is turned off and then turned to ON mode again, the vehicle will automati- cally return to vehicle-to-vehicle distance control mode. Adjusting the speed setting: P. 274 Canceling resuming speed setting: P. 276 Dynamic radar cruise control can be set when ■...
Page 282 If vehicle-to-vehicle distance control driving is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Toyota dealer. Automatic cancelation of constant speed control ■...
Page 283 2-4. Using other driving systems Radar sensor and grille cover ■ Always keep the sensor and grille cover clean to ensure that the vehicle-to- vehicle distance control operates properly. (Some obstructions, such as snow, ice and plastic objects, cannot be detected by the obstruction sensor.) Dynamic radar cruise control (vehicle-to-vehicle distance control mode) will be canceled if dirt is detected.
Page 284 2-4. Using other driving systems Certification ■ For vehicles sold in the U.S.A. FCC ID: HYQDNMWR004 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 285 2-4. Using other driving systems CAUTION Before using dynamic radar cruise control ■ Do not overly rely on vehicle-to-vehicle distance control. Be aware of the set speed. If automatic deceleration/acceleration is not appropriate, adjust the vehicle speed, as well as the distance between your vehicle and vehicles ahead by applying the brakes etc.
Page 286 2-4. Using other driving systems CAUTION To avoid inadvertent cruise control activation ■ Switch the cruise control off using the “ON-OFF” button when not in use. Situations unsuitable for dynamic radar cruise control ■ Do not use dynamic radar cruise control in any of the following situations. Doing so may result in inappropriate speed control and could cause an acci- dent resulting in death or serious injury.
Page 287 2-4. Using other driving systems CAUTION When the sensor may not be correctly detecting the vehicle ahead ■ Apply the brakes as necessary when any of the following types of vehicles are in front of you. As the sensor may not be able to correctly detect these types of vehicles, the approach warning (P.
Page 288 If the sensor moves even slightly off position, the system may become inaccurate or malfunction. If the sensor or surrounding area is subject to a strong impact, always have the area inspected and adjusted by your Toyota dealer. ● Do not disassemble the sensor.
Page 289: Lka (Lane-Keeping Assist)
2-4. Using other driving systems  LKA (Lane-Keeping Assist) While driving on a freeway or motor highway that has lane markers and no sharp curves, the system recognizes the lanes using a cam- era located above the inside rear view mirror as a sensor to assist the driver with staying in the lane.
Page 290 2-4. Using other driving systems Functions included in the LKA Lane departure warning function If the system judges that the vehicle may deviate from its lane, it alerts the driver using beeping, screen displays and a sensory warning given via the steering wheel. : A slight steering torque is applied for a short period of time in the direc- tion of the center of the lane.
Page 291 2-4. Using other driving systems Turning the LKA system on Press the “LKA” switch to acti- vate the system. “LKA” indicator will come on. Press the switch again to turn the LKA system off. The LKA system will revert to off each time the power switch is turned to ON mode.
Page 292 2-4. Using other driving systems Operating conditions for each function Lane departure warning function ■ ● When the vehicle speed is approximately 30 mph (48 km/h) or more ● When the lane width is more than approximately 9.1 ft. (2.8 m) ●...
Page 293 2-4. Using other driving systems Indication on the multi-information display When the LKA system is on, the lane line display and steering wheel display are shown. Lane keeping assist function operation indication Steering wheel displayed: Indicates that the function is cur- rently operating.
Page 294 2-4. Using other driving systems Temporary cancelation of the LKA system functions ■ If any of the following occurs, the LKA system functions will be temporarily canceled. The functions will resume after the necessary operating conditions have returned. ● The steering wheel is turned as far as necessary to cause the vehicle to change lanes.
Page 295 2-4. Using other driving systems No-handed driving warning ■ If the steering wheel is not operated for approximately 15 seconds on a straight road or approximately 5 seconds on a curve, the buzzer will beep twice, indicators on the multi-information display will flash, and the lane keeping assist function will be temporarily canceled.
Page 296 2-4. Using other driving systems ● When the lane markers are yellow (These may be more difficult for the system to recognize compared to white markers.) ● When the lane markers are broken, “Botts’ dots”, “Raised pavement marker” or stones ●...
Page 297 2-4. Using other driving systems CAUTION Before using the LKA system ■ Do not rely solely on the LKA system. The LKA system does not drive the vehicle automatically, nor does it reduce the amount of care you need to take.
Page 298 Do not modify the sun visor or replace it with anything other than a genu- ine Toyota product. ● If your windshield needs repairs, contact your Toyota dealer. Camera sensor (P. 289) ■ Observe the following to ensure that the LKA system functions correctly.
Page 299 When cleaning the inside of the windshield, be careful not to get any glass cleaner etc. on the lens. Also, do not touch the lens. For lens repair, contact your Toyota dealer. ● Do not change the installation position or direction of the camera sensor or remove it.
Page 300: Driving Assist Systems
2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ABS (Anti-lock Brake System) ■...
Page 301 2-4. Using other driving systems Hill-start assist control ■ P. 305 PCS (Pre-Collision System) (if equipped) ■ P. 307 When the TRAC/VSC/ABS systems are operating The slip indicator light will flash while the TRAC/VSC/ABS sys- tems are operating. PRIUS_OM_OM47857U_DVD_(U)
Page 302 2-4. Using other driving systems Sounds and vibrations caused by the ABS, brake assist, VSC and ■ TRAC ● A sound may be heard from the engine compartment when the hybrid system is started, just after the vehicle begins to move, if the brake pedal is depressed forcefully or repeatedly, or 1-2 minutes after the hybrid sys- tem is stopped.
Page 303 2-4. Using other driving systems CAUTION The ABS does not operate effectively when ■ ● The limits of tire gripping performance have been exceeded (such as excessively worn tires on a snow covered road). ● The vehicle hydroplanes while driving at high speed on wet or slick road. Stopping distance when the ABS is operating may exceed that of nor- ■...
Page 304 The ABS and VSC systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. Handling of tires and the suspension ■...
Page 305: Hill-Start Assist Control
2-4. Using other driving systems Hill-start assist control Hill-start assist control helps to prevent the vehicle from rolling backwards when starting on an incline or slippery slope. To engage hill-start assist con- trol, further depress the brake pedal when the vehicle is stopped completely.
Page 306 • The brake pedal is depressed again. • The brake pedal has been depressed for more than approximately 3 minutes. If the slip indicator light comes on ■ It may indicate a malfunction in the system. Contact your Toyota dealer. CAUTION Hill-start assist control ■ ●...
Page 307: Pcs (Pre-Collision System)
2-4. Using other driving systems  PCS (Pre-Collision System) When the radar sensor detects possibility of a frontal collision, the pre-collision systems such as the brakes and seat belts are automat- ically engaged to lessen impact as well as vehicle damage. Pre-collision seat belts (front seat belts only) ■...
Page 308 2-4. Using other driving systems Disabling pre-collision braking Pre-collision braking enabled Pre-collision braking disabled The “PCS” warning light will turn on when pre-collision braking is disabled. Radar sensor The radar sensor detects vehi- cles or other obstacles on or near the road ahead and deter- mines whether a collision is imminent based on the position, speed, and heading of the obsta-...
Page 309 2-4. Using other driving systems The pre-collision system is operational when ■ ● Pre-collision seat belts (operating conditions A): • Vehicle speed is greater than about 19 mph (30 km/h). • The system detects sudden braking or skidding. • The front occupants are wearing a seat belt. ●...
Page 310 2-4. Using other driving systems Conditions that may trigger the system even if there is no possibility of ■ a collision ● When there is an object by the roadside at the entrance to a curve ● When passing an oncoming vehicle on a curve ●...
Page 311 2-4. Using other driving systems Obstacles not detected ■ The sensor cannot detect plastic obstacles such as traffic cones. There may also be occasions when the sensor cannot detect pedestrians, animals, bicycles, motorcycles, trees, or snowdrifts. Situations in which the pre-collision system does not function properly ■...
Page 312 2-4. Using other driving systems Certification ■ For vehicles sold in the U.S.A. FCC ID: HYQDNMWR004 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 313 2-4. Using other driving systems CAUTION Limitations of the pre-collision system ■ Do not overly rely on the pre-collision system. Always drive safely, taking care to observe your surroundings and checking for any obstacles or other road hazards. Failure to do so may cause an accident resulting in death or serious injury. Cautions regarding the assist contents of the system ■...
Page 314 If the sensor moves even slightly off position, the system may become inaccurate or malfunction. If the sensor or surrounding area is subject to a strong impact, always have the area inspected and adjusted by your Toyota dealer. ● Do not disassemble the sensor.
Page 315: 2-5. Driving Information
2-5. Driving information Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load: ● Stow cargo and luggage in the luggage compartment whenever possible. ● Be sure all items are secured in place. ●...
Page 316 Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. (P. 320) Toyota does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing. PRIUS_OM_OM47857U_DVD_(U)
Page 317 2-5. Driving information Calculation formula for your vehicle Cargo capacity Total load capacity (vehicle capacity weight) (P. 566) When 2 people with the combined weight of A lb. (kg) are riding in your vehicle, which has a total load capacity (vehicle capacity weight) of B lb.
Page 318 2-5. Driving information CAUTION Things that must not be carried in the luggage compartment ■ The following things may cause a fire if loaded in the luggage compart- ment: ● Receptacles containing gasoline ● Aerosol cans Storage precautions ■ Observe the following precautions. Failure to do so may result in death or serious injury.
Page 319 2-5. Driving information CAUTION ● Secure all items in the occupant compartment, as they may shift and injure someone in the event of an accident or sudden braking. ● When you fold down the rear seats, long items should not be place directly behind the front seats.
Page 320: Vehicle Load Limits
Seating capacity means the maximum number of occupants whose estimated average weight is 150 lb. (68 kg) per person. TWR (Trailer Weight Rating) ■ Toyota does not recommend towing a trailer with your vehicle. Cargo capacity ■ Cargo capacity may increase or decrease depending on the weight and the number of occupants.
Page 321: Winter Driving Tips
2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. Pre-winter preparations ■ ● Use fluids that are appropriate to the prevailing outside tem- peratures.
Page 322 2-5. Driving information Before driving the vehicle ■ Perform the following according to the driving conditions: ● Do not try to forcibly open a window or move a wiper that is frozen. Pour warm water over the frozen area to melt the ice. Wipe away the water immediately to prevent it from freezing.
Page 323 2-5. Driving information Selecting tire chains Vehicles with 17-inch tires Use the correct tire chain size when mounting the tire chains. Chain size is regulated for each tire size. Side chain: 0.12 in. (3.0 mm) 1.18 in. (30.0 mm) 0.39 in. (10.0 mm) Cross chain: 0.16 in.
Page 324 2-5. Driving information Tire chain installation ■ Observe the following precautions when installing and removing chains: ● Install and remove tire chains in a safe location. ● Install tire chains on the front tires only. Do not install tire chains on the rear tires.
Page 325 NOTICE Repairing or replacing snow tires ■ Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 326: Trailer Towing
Trailer towing Toyota does not recommend towing a trailer with your vehicle. Toyota also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicycle, etc. Your vehicle is not designed for trailer towing or for the use of tow hitch mounted carriers.
Page 327: Dinghy Towing
2-5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE To avoid serious damage to your vehicle ■ Do not tow your vehicle with the four wheels on the ground. PRIUS_OM_OM47857U_DVD_(U)
Page 328 2-5. Driving information PRIUS_OM_OM47857U_DVD_(U)
Page 329: Interior Features
Interior features 3-1. Using the air conditioning 3-2. Using the audio system system and defogger Audio system types..351 Air conditioning system ..330 Using the AUX port/USB port......... 356 Using the steering wheel climate remote control 3-3. Using the interior lights switches ......
Page 330: Using The Air Conditioning System And Defogger Air Conditioning System
3-1. Using the air conditioning system and defogger Air conditioning system Airflow and outlets are automatically adjusted according to the tem- perature setting. Outside temperature display (P. 370) Fan speed Temperature Air outlet control button control button display Windshield Temperature Fan speed defogger button setting display...
Page 331 3-1. Using the air conditioning system and defogger Using the automatic mode STEP Press The air conditioning system will begin to operate. Air outlets and fan speed are automatically adjusted according to the temperature set- ting. STEP Press “▲” to increase the temperature and “▼” to decrease the temperature on the Adjusting the settings Changing the cooling and dehumidification function...
Page 332 3-1. Using the air conditioning system and defogger Changing the air outlets ■ Press The air outlets switch each time the button is pressed. Air flows to the upper body. ITO31P105 Air flows to the upper body and feet. PRIUS_OM_OM47857U_DVD_(U)
Page 333 3-1. Using the air conditioning system and defogger Mainly air flows to the feet. Air flows to the feet and the windshield defogger operates. Switching between outside air and recirculated air modes ■ Press The modes switches between (recycles air inside the vehicle) (introduces air from outside the vehicle) modes each time the button is pressed.
Page 334 3-1. Using the air conditioning system and defogger Defogging the windshield Press The air conditioning system con- trol operates automatically. Recirculated air mode will auto- matically switch to outside air mode. Micro dust and pollen filter Press Outside air mode switches to recirculated air mode. Pollen is removed from the air and the air flows to the upper part of the body.
Page 335 3-1. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets Adjusting the air outlets ■ Center outlets Direct air flow to the left or right, up or down. Right and left side outlets Direct air flow to the left or right, up or down.
Page 336 3-1. Using the air conditioning system and defogger Opening and closing the air outlets ■ Center outlets Open the vent. Close the vent. Move the knob in the direction of the printed arrow until a click is heard. Right and left side outlets Open the vent.
Page 337 3-1. Using the air conditioning system and defogger Using the automatic mode ■ Fan speed is adjusted automatically in accordance with the temperature set- ting and ambient conditions. As a result, the following may occur. ● Immediately after is pressed, the fan may stop for a while until warm or cool air is ready to flow.
Page 338 (For scheduled maintenance information, refer to the “Owner’s Manual Sup- plement/ Scheduled Maintenance Guide”.) When inspecting, cleaning and replacing the air conditioning filter, contact your Toyota dealer. PRIUS_OM_OM47857U_DVD_(U)
Page 339 3-1. Using the air conditioning system and defogger If air flow from the vents decreases dramatically ■ The filter may be clogged. Contact your Toyota dealer. Operation of the air conditioning system in Eco drive mode ■ In the Eco drive mode, the air conditioning system is controlled as follows to prioritize fuel efficiency: ●...
Page 340 3-1. Using the air conditioning system and defogger CAUTION To prevent the windshield from fogging up ■ Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 341: Using The Steering Wheel Climate Remote Control Switches
3-1. Using the air conditioning system and defogger Using the steering wheel climate remote control switches Some air conditioning features can be controlled using the switches on the steering wheel. Temperature control Outside air or recirculated air mode Adjusting the temperature setting Press “”...
Page 342 3-1. Using the air conditioning system and defogger When operating the steering switches (vehicles with touch tracer dis- ■ play) ● The steering switches operation status is displayed on the instrument cluster for confirmation purposes. (P. 217) ● Settings are shown on the multi-infor- mation display when the steering switch is operated.
Page 343: Solar Ventilation System
3-1. Using the air conditioning system and defogger  Solar Ventilation System The Solar Ventilation System uses energy provided by solar panel built into the roof to operate a fan contained within the air condition- ing system, allowing ventilation of the vehicle interior when the vehi- cle is parked in direct sunlight.
Page 344 3-1. Using the air conditioning system and defogger Operating conditions ■ The Solar Ventilation System may not operate under the following circum- stances due to a lack of power from the solar panel: ● Low amount of sunlight ● Ever when a part of the solar panel is cast by a shadow. ●...
Page 345 3-1. Using the air conditioning system and defogger CAUTION Solar Ventilation System precautions ■ ● Do not use the system if people are inside the vehicle. The Solar Ventilation System is not intended to ensure the performance of the air conditioning system. Do not leave children or pets in the vehicle. The temperature of the interior will remain high, possibly resulting in heat- stroke, dehydration, or even death.
Page 346: Remote Air Conditioning System
3-1. Using the air conditioning system and defogger  Remote Air Conditioning System The Remote Air Conditioning System uses electrical energy stored in the hybrid battery (traction battery) and allows the air conditioning to be operated by remote control. Before leaving the vehicle ■...
Page 347 3-1. Using the air conditioning system and defogger Using the Remote Air Conditioning System effectively ■ Efficiency can be increased by using the system in conjunction with the Solar Ventilation System. (P. 343) When leaving the vehicle ■ ● Check that the headlights are switched to either off or “AUTO”. ●...
Page 348 3-1. Using the air conditioning system and defogger Security feature ■ Any unlocked doors will be automatically locked when the system is operat- ing. The buzzer will beep and the emergency flashers flash when the doors have been locked or the system has been turned off. (The doors locked: Once;...
Page 349 3-1. Using the air conditioning system and defogger CAUTION Precautions for the Remote Air Conditioning System ■ ● Do not use the system if people are in the vehicle. • Even when the system is in use, the internal temperature may still reach a high level due to features such as the automatic shut-off.
Page 350: Rear Window And Outside Rear View Mirror Defoggers Switch
3-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers switch Defoggers are used to defog the rear window, and to remove rain- drops, dew and frost from the outside rear view mirrors (if equipped). Turns the rear window and outside rear view mirror defog- gers on/off...
Page 351: 3-2. Using The Audio System
3-2. Using the audio system Audio system types Vehicles with Display Audio system Type A Type B Refer to the “DISPLAY AUDIO SYSTEM OWNER’S MANUAL”. PRIUS_OM_OM47857U_DVD_(U)
Page 352 3-2. Using the audio system Vehicles with a navigation system Canada Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”. Steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. For details, refer to the “DISPLAY AUDIO SYSTEM OWNER’S MANUAL”...
Page 353 3-2. Using the audio system ® About Bluetooth (vehicles with Display Audio system) ■ Bluetooth is a registered trade mark of Bluetooth SIG, Inc. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Panasonic Corpo- ration is under license.
Page 354 3-2. Using the audio system CAUTION Properly shielded a grounded cables and connectors must be used for con- nection to host computer and / or peripherals in order to meet FCC emission limits. This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
Page 355 3-2. Using the audio system CAUTION Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equi- valent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
Page 356: Using The Aux Port/Usb Port
3-2. Using the audio system Using the AUX port/USB port This port can be used to connect a portable audio device and listen to it through the vehicle’s speakers. STEP Open the console box lid. (P. 363) Connect the portable audio STEP device.
Page 357: 3-3. Using The Interior Lights
3-3. Using the interior lights Interior lights list Rear interior light (P. 359) Front interior/personal lights (P. 358) Shift lever lighting “POWER” switch lighting Foot lights (if equipped) Front door courtesy lights PRIUS_OM_OM47857U_DVD_(U)
Page 358: Front Interior Lights
3-3. Using the interior lights Front interior lights Front interior lights Type A Turns the lights off Turns the door position on Turns the lights on Type B Turns the lights off Turns the door position on Turns the lights on PRIUS_OM_OM47857U_DVD_(U)
Page 359: Personal Lights
3-3. Using the interior lights Personal lights and rear interior light Personal lights Type A Turns the lights on/off Type B Turns the lights on/off Rear interior light The light will turn on/off in con- junction with the front interior lights Turns the light on ITO34P111...
Page 360 3-3. Using the interior lights Rear interior light Illuminated entry system ■ The lights automatically turn on/off according to “POWER” switch mode, the presence of the electronic key, whether the doors are locked/unlocked, and whether the doors are opened/closed. To prevent 12-volt battery discharge ■...
Page 361: 3-4. Using The Storage Features
3-4. Using the storage features List of storage features Bottle holders Auxiliary boxes Glove boxes Cup holders Console box CAUTION Items that should not be left in the storage spaces ■ Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: ●...
Page 362: Glove Boxes
3-4. Using the storage features Glove boxes Glove boxes Upper glove box Push the button. Lower glove box Push the button. Glove box light (lower glove box only) ■ The glove box light turns on when the tail lights are on. CAUTION While driving ■...
Page 363: Console Box
3-4. Using the storage features Console box Console box Pull up the lever to release the lock. Lift the console box lid to open. CAUTION While driving ■ Keep the console box closed when not is use. In the event of sudden brak- ing or sudden swerving, an accident may occur due to an occupant being struck by the open console box or the items stored inside.
Page 364: Cup Holders
3-4. Using the storage features Cup holders Cup holders Front (type A) Lift the lid. Front (type B) Rear (if equipped) Pull down the armrest. ITO35P113 PRIUS_OM_OM47857U_DVD_(U)
Page 365 3-4. Using the storage features Cup holders CAUTION Items unsuitable for the cup holder ■ Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of sudden braking, sudden swerving or an accident and cause injury.
Page 366: Bottle Holders
3-4. Using the storage features Bottle holders Bottle holders ITO35P121 CAUTION Items unsuitable for the bottle holder ■ Do not place anything other than pet bottles in the bottle holders. Other items may be thrown out of the holders in the event of sudden braking, sudden swerving or an accident and cause injury.
Page 367: Auxiliary Boxes
3-4. Using the storage features Auxiliary boxes Auxiliary boxes Type A Type B (if equipped) Push the lid. The overhead console is useful temporarily storing small items. CAUTION While driving ■ Do not leave the overhead console open. Items may fall out and cause injury. Maximum storage weight ■...
Page 368: 3-5. Other Interior Features
3-5. Other interior features Sun visors To set the visor in the for- ward position, flip it down. To set the visor in the side position, flip down, unhook, and swing it to the side. ITO36P101 PRIUS_OM_OM47857U_DVD_(U)
Page 369: Vanity Mirrors
3-5. Other interior features Vanity mirrors Slide the cover to open. The light turns on when the cover is opened. ITO36P103 NOTICE To prevent 12-volt battery discharge ■ Do not leave the vanity lights on for extended periods while the hybrid sys- tem is off.
Page 370: Outside Temperature Display
When stopped, or driving at low speeds (less than 16 mph [25 km/h]) ● When the outside temperature has changed suddenly (at the entrance/ exit of a garage, tunnel, etc.) When -- is displayed ■ The system may be malfunctioning. Take your vehicle to your Toyota dealer. PRIUS_OM_OM47857U_DVD_(U)
Page 371: Power Outlets
3-5. Other interior features Power outlets The power outlets can be used for 12 V accessories that run on less than 10 A. Instrument panel Open the cover. Rear console box Open the cover. The power outlets can be used when ■...
Page 372 3-5. Other interior features NOTICE To avoid damaging the power outlets ■ Close the power outlet lid when the power outlet is not in use. Foreign objects or liquids that enter the power outlet may cause a short cir- cuit. To prevent blown fuse ■...
Page 373: Seat Heaters
3-5. Other interior features  Seat heaters Heats the left front seat Heats the right front seat The indicator light comes on. Press the button again to turn off the seat heater. The indicator light turns off. The seat heaters can be used when ■...
Page 374 3-5. Other interior features CAUTION Burns ■ ● Use caution when seating the following persons in a seat with the seat heater on to avoid the possibility of burns: • Babies, small children, the elderly, the sick and the physically chal- lenged •...
Page 375: Armrest
3-5. Other interior features  Armrest Pull the armrest down for use. ITO36P111 NOTICE To prevent damage to the armrest ■ Do not place too much strain on the armrest.  : If equipped PRIUS_OM_OM47857U_DVD_(U)
Page 376: Assist Grips
3-5. Other interior features Assist grips An assist grip installed on the ceiling can be used to support your body while sitting on the seat. CAUTION Assist grip ■ Do not use the assist grip when getting in or out of the vehicle or rising from your seat.
Page 377: Floor Mats
3-5. Other interior features Floor mats Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks STEP (clips) into the floor mat eye- lets.
Page 378 When installing the driver’s floor mat ■ ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
Page 379: Luggage Compartment Features
3-5. Other interior features Luggage compartment features Cargo hooks ■ Raise the hook to use. The cargo hooks are provided for securing loose items. Deck boards ■ Center (type A) When using the auxiliary box, lift the center deck board. PRIUS_OM_OM47857U_DVD_(U)
Page 380 3-5. Other interior features Center (type B) When using the auxiliary box, STEP turn knob “UNLOCK” position and open the lid. Lift the center deck board to STEP remove it. Side Lift the side deck board to remove it. PRIUS_OM_OM47857U_DVD_(U)
Page 381 3-5. Other interior features Auxiliary boxes ■ Center (type A) Center (type B) Side PRIUS_OM_OM47857U_DVD_(U)
Page 382 3-5. Other interior features Luggage cover (if equipped) ■ Pull out the luggage cover and secure it to the hook brackets. Removing the luggage cover Lift it up. PRIUS_OM_OM47857U_DVD_(U)
Page 383 3-5. Other interior features Stowing the luggage cover (vehicles with center auxiliary box type B only) Remove the side deck board and STEP open the center deck board. Adjust the cover so that “TOP” is STEP facing up. STEP Replace the side deck board and the center deck board. PRIUS_OM_OM47857U_DVD_(U)
Page 384 3-5. Other interior features CAUTION When the cargo hooks are not in use ■ To avoid injury, always return the cargo hooks to their stowed positions. Caution while driving ■ Keep the lid of each storage spaces closed while driving. In the event of sud- den braking or sudden swerving, an accident may occur due to an occupant being struck by an open auxiliary box or the items stored inside.
Page 385: Garage Door Opener
3-5. Other interior features  Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, secu- rity systems, and other devices. ® The garage door opener (HomeLink Universal Transceiver) is manufac- ®...
Page 386 3-5. Other interior features ® Programming HomeLink ■ Point the remote control trans- STEP mitter for the device 1 to 3 in. (25 ® to 75 mm) from the HomeLink buttons. ® Keep the HomeLink indicator light in view while programming. Press and hold one of the STEP ®...
Page 387 3-5. Other interior features ® Test the HomeLink operation by STEP pressing the newly programmed button. ® If a HomeLink button has been programmed for a garage door, check to see if the garage door opens and closes. If the garage door does not operate, see if your garage transmitter is of the rolling code type.
Page 388 3-5. Other interior features Programming a rolling code system (for U.S.A. owners) ■ If your device is rolling code equipped, follow the steps under the ® heading “Programming HomeLink ” before proceeding with the steps listed below. STEP Locate the training button on the ceiling mounted garage door opener motor.
Page 389 HomeLink buttons. Programming other devices ■ To program other devices such as home security systems, home door locks and lighting, contact your Toyota dealer for assistance. Reprogramming a button ■ ® The individual HomeLink buttons cannot be erased but can be reprogrammed.
Page 390 3-5. Other interior features ® Operating HomeLink ® ® Press the appropriate HomeLink button. The HomeLink indicator light should come on. ® The HomeLink compatible transceiver in your vehicle continues to send a signal for up to 20 seconds as long as the button is pressed. ®...
Page 391 3-5. Other interior features Before programming ■ ● Install a new battery in the remote control transmitter. ● The battery side of the remote control transmitter must be pointed away ® from the HomeLink button. Certification for the garage door opener ■...
Page 392 3-5. Other interior features CAUTION When programming a garage door or other remote control device ■ The garage door or other device may operate, so ensure people and objects are out of danger to prevent potential harm. Conforming to federal safety standards ■...
Page 393: Safety Connect
Telematics Subscription Service Agreement and its Terms and Conditions, as in effect and amended from time to time, a current copy of which is available at Toyota.com. All use of the Safety Con- nect service is subject to such then-applicable Terms and Condi- tions.
Page 394 After you have signed the Telematics Subscription Service Agreement and are enrolled, you can begin receiving services. A variety of subscription terms is available for purchase. Contact your Toyota dealer, call 1-800-25-TOYOTA (1-800-255-3987) or push the “SOS” button in your vehicle for further subscription details.
Page 395 Safety Connect. ● Safety Connect is available beginning Fall 2009 on select Toyota models. Contact with the Safety Connect response center is dependent upon the telematics device being in operative condition, cellular connection avail- ability, and GPS satellite signal reception, which can limit the ability to reach the response center or receive emergency service support.
Page 396 ● Green indicator light flashing = Safety Connect call in process ● Red indicator light (except at vehicle start-up) = System malfunc- tion (contact your Toyota dealer) ● No indicator light (off) = Safety Connect service not active Safety Connect services Automatic Collision Notification ■...
Page 397 After fil- ing a police report, call the Safety Connect response center at 1- 800-25-TOYOTA (1-800-255-3987) and follow the prompts for Safety Connect to initiate this service. In addition to assisting law enforcement with recovery of a stolen...
Page 398 3-5. Other interior features Safety information for Safety Connect Important! Read this information before using Safety Connect. Exposure to radio frequency signals ■ The Safety Connect system installed in your vehicle is a low-power radio transmitter and receiver. It receives and also sends out radio frequency (RF) signals.
Page 399 3-5. Other interior features Certification for Safety Connect ■ FCC ID: O6Y-CDMRF101 FCC ID: XOECDMRF101B FCC ID: N7NGTM2 NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 400 3-5. Other interior features PRIUS_OM_OM47857U_DVD_(U)
Page 401 Maintenance and care 4-1. Maintenance and care Cleaning and protecting the vehicle exterior..402 Cleaning and protecting the vehicle interior..405 4-2. Maintenance Maintenance requirements ....408 General maintenance..411 Emission inspection and maintenance (I/M) programs......415 4-3. Do-it-yourself maintenance Do-it-yourself service precautions ....
Page 402: Cleaning And Protecting The Vehicle Exterior
4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 403 4-1. Maintenance and care Note for a smart key system ■ If the door handle becomes wet while the electronic key is within the effec- tive range, the door may lock and unlock repeatedly. Place the key in a posi- tion 6 ft.
Page 404 4-1. Maintenance and care NOTICE To prevent paint deterioration and corrosion on the body and compo- ■ nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 405: Cleaning And Protecting The Vehicle Interior
4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior ■ Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
Page 406 4-1. Maintenance and care Caring for leather areas ■ Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. Shampooing the carpets ■ There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 407 4-1. Maintenance and care NOTICE Cleaning detergents ■ ● Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
Page 408: Maintenance Maintenance Requirements
It is recommended that genuine Toyota parts be used for repairs to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 409 STEP Keep pressing the button until the trip meter indicates “000000” and the multi-information display indicates that the reset is complete. Allow inspection and repairs to be performed by a Toyota dealer ■ ● Toyota technicians are well-trained specialists and are kept up to date with the latest service information.
Page 410 4-2. Maintenance CAUTION If your vehicle is not properly maintained ■ Improper maintenance could result in serious damage to the vehicle and possible serious injury or death. Handling of the 12-volt battery ■ ● Engine exhaust, some of its constituents, and a wide variety of automobile components contain or emit chemicals known to the State of California to cause cancer and birth defects and other reproductive harm.
Page 411: General Maintenance
Booklet” “Owner’s Manual Supplement/Scheduled Maintenance Guide”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items Check points Is the brake fluid at the correct...
Page 412: Vehicle Interior
4-2. Maintenance Luggage compartment Items Check points 12-volt battery Check the connections. (P. 437) Vehicle interior Items Check points • The accelerator pedal should Accelerator pedal move smoothly (without uneven pedal effort or catching). • When parked on a slope and the Hybrid transmission “Park”...
Page 413 4-2. Maintenance Items Check points • Do the head restraints move Head restraints smoothly and lock securely? • Do the indicators and buzzers Indicators/buzzers function properly? Lights • Do all the lights come on? • Does the parking brake pedal move smoothly? Parking brake •...
Page 414: Vehicle Exterior
4-2. Maintenance Vehicle exterior Items Check points Doors • Do the doors operate smoothly? • Does the engine hood lock sys- Engine hood tem work properly? • There should not be any signs of Fluid leaks fluid leakage after the vehicle has been parked.
Page 415: Emission Inspection And Maintenance (I/M) Programs
The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test in the following situa- ■...
Page 416: Do-It-Yourself Maintenance Do-It-Yourself Service Precautions
Brake fluid level (P. 433) • Rag or paper towel • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology For the U.S.A.:...
Page 417 4-3. Do-it-yourself maintenance Items Parts and tools • “Toyota Genuine Motor Oil” or equivalent Engine oil level (P. 426) • Rag or paper towel • Funnel (used only for adding engine oil) • Fuse with same amperage rating Fuses (P. 462) as original •...
Page 418 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. When working on the engine compartment ■ ● Make sure that the indicator on the “POWER”...
Page 419: Hood
4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release STEP lever. The hood will pop up slightly. Pull up the auxiliary catch STEP lever and lift the hood. PRIUS_OM_OM47857U_DVD_(U)
Page 420 4-3. Do-it-yourself maintenance Hold the hood open by insert- STEP ing the supporting rod into either of the slots. Use the forward slot to open the hood normally, or use the rearward slot when the hood needs to be opened wide. CAUTION Pre-driving check ■...
Page 421 4-3. Do-it-yourself maintenance NOTICE When closing the hood ■ Be sure to return the support rod to its clip before closing the hood. Closing the hood without returning the support rod properly could cause the hood to bend. PRIUS_OM_OM47857U_DVD_(U)
Page 422: Positioning A Floor Jack
4-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement (such as under rear suspension etc.) may damage your vehicle or cause injury. Front ■ Rear ■ ITO43P106 PRIUS_OM_OM47857U_DVD_(U)
Page 423 4-3. Do-it-yourself maintenance CAUTION When raising your vehicle ■ Make sure to observe the following precautions to reduce the possibility of death or serious injury: ● Lift up the vehicle using a floor jack such as the one shown in the illustra- tion.
Page 424 4-3. Do-it-yourself maintenance CAUTION ● Do not raise the vehicle while someone is in the vehicle. ● When raising the vehicle, do not place any object on top of or underneath the floor jack. ● When raising the vehicle, do not set the Rear suspension floor jack under the rear suspension.
Page 425: Engine Compartment
4-3. Do-it-yourself maintenance Engine compartment Engine coolant reservoir Brake fluid reservoir (P. 430) (P. 433) Engine oil level dipstick Fuse box (P. 462) (P. 426) Radiator (P. 432) Engine oil filler cap Condenser (P. 432) (P. 427) Electric cooling fans Power control unit coolant Washer fluid tank (P.
Page 426 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil ■ STEP Park the vehicle on level ground. After warming up the engine and turning off the hybrid system, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 427 4-3. Do-it-yourself maintenance Flat dipstick Normal Excessive The shape of the dipstick may dif- fer depending on the type of vehi- cle or engine. Non-flat dipstick Normal Excessive The shape of the dipstick may dif- fer depending on the type of vehi- cle or engine.
Page 428 4-3. Do-it-yourself maintenance Make sure to check the oil type and prepare the items needed before adding oil. P. 570 Engine oil selection Oil quantity 1.6 qt. (1.5 L, 1.3 Imp.qt.) (Low  Full) Items Clean funnel STEP Remove the oil filler cap by turning it counterclockwise. STEP Add engine oil slowly, checking the dipstick.
Page 429 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
Page 430 4-3. Do-it-yourself maintenance Coolant The coolant level is satisfactory if it is between the full (“FULL” or “F”) and low (“LOW” or “L”) lines on the reservoir when the hybrid system is cold. Engine coolant reservoir Reservoir cap “FULL” line “LOW”...
Page 431 ■ Visually check the radiator, hoses, engine/power control unit coolant reser- voir caps, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. CAUTION When the hybrid system is hot ■...
Page 432 Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. CAUTION When the hybrid system is hot ■...
Page 433 4-3. Do-it-yourself maintenance Brake fluid Checking fluid level ■ The brake fluid level should be between the “MAX” and “MIN” lines on the tank. Adding fluid ■ Push the tab in and lift the cover off. Make sure to check the fluid type and prepare the necessary item. Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items...
Page 434 4-3. Do-it-yourself maintenance Brake fluid can absorb moisture from the air ■ Excess moisture in the brake fluid can cause a dangerous loss of braking efficiency. Use only newly opened brake fluid. CAUTION When filling the reservoir ■ Take care as brake fluid can harm your hands and eyes and damage painted surfaces.
Page 435 4-3. Do-it-yourself maintenance Washer fluid Open the lid. STEP Check the washer fluid level on STEP the level gauge. “NORMAL” “LOW” If the washer fluid level is at STEP “LOW”, add washer fluid. PRIUS_OM_OM47857U_DVD_(U)
Page 436 4-3. Do-it-yourself maintenance CAUTION When adding washer fluid ■ Do not add washer fluid when the hybrid system is hot or operating as washer fluid contains alcohol and may catch fire if spilled on the engine etc. NOTICE Do not use any fluid other than washer fluid ■...
Page 437: 12-Volt Battery
4-3. Do-it-yourself maintenance 12-volt battery Location ■ The 12-volt battery is located in the right-hand side of lug- gage compartment. Removing the 12-volt battery cover ■ STEP Open the center deck board. (P. 379) STEP Remove the center auxiliary box. (P. 381) Remove the side deck board STEP and 12-volt battery cover.
Page 438 4-3. Do-it-yourself maintenance Exterior ■ Make sure that the 12-volt battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals Hold-down clamp Before recharging ■ When recharging, the 12-volt battery produces hydrogen gas which is flam- mable and explosive.
Page 439 ● Restart the hybrid system, depress the brake pedal, and confirm that it is possible to shift into each shift position. If the system will not start even after multiple attempts at all methods above, contact your Toyota dealer. PRIUS_OM_OM47857U_DVD_(U)
Page 440 4-3. Do-it-yourself maintenance CAUTION Chemicals in the 12-volt battery ■ The 12-volt battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the 12-volt battery: ●...
Page 441 When replacing the 12-volt battery ■ Use a 12-volt battery designed for this vehicle. Failure to do so may cause gas (hydrogen) to enter the passenger compartment, causing a fire or explo- sion. For replacement of the 12-volt battery, contact your Toyota dealer. PRIUS_OM_OM47857U_DVD_(U)
Page 442 4-3. Do-it-yourself maintenance CAUTION When disconnecting the 12-volt battery ■ Do not disconnect the negative (-) termi- nal on the body side as shown. The dis- connected negative (-) terminal may touch the positive (+) terminal, which may cause a short and result in death or seri- ous injury.
Page 443: Tires
Tire rotation ■ Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota recom- mends that tire rotation is Front carried out at the same inter- val as tire inspection. Do not fail to initialize the tire...
Page 444 ID codes must be registered in the tire pressure warn- ing computer and the tire pressure warning system must be initial- ized. Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (P. 446) PRIUS_OM_OM47857U_DVD_(U)
Page 445 4-3. Do-it-yourself maintenance Initializing the tire pressure warning system The tire pressure warning system must be initialized in the fol- ■ lowing circumstances: ● When rotating front and rear tires which have different tire infla- tion pressures ● When changing the tire size When the tire pressure warning system is initialized, the current tire inflation pressure is set as the benchmark pressure.
Page 446 The tire pressure warning valve and transmitter is equipped with a unique ID code. When replacing a tire pressure warning valve and transmitter, it is necessary to register the ID code. Have the ID code registered by your Toyota dealer. PRIUS_OM_OM47857U_DVD_(U)
Page 447 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage. If you are not sure, consult with your Toyota dealer. Replacing tires and wheels ■ If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly.
Page 448 4-3. Do-it-yourself maintenance Maximum load of tire ■ Check that the maximum load of the replacement tire is greater than 1/2 of the Gross Axle Weight Ratings (GAWR) of either the front axle or the rear axle, whichever is greater. For the GAWR, see the Certification Label.
Page 449 Initialization can be completed in a few minutes. However, in the follow- ing cases, the settings have not been recorded and the system will not operate properly. If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. ●...
Page 450 4-3. Do-it-yourself maintenance Tire pressure warning system certification ■ For vehicles sold in the U.S.A. MODEL/FCC IDs: Transmitter: PAXPMV107J Receiver: HYQ13BDE NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 451 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 452 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 453: Tire Inflation Pressure
4-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure ■ The recommended cold tire inflation pressure and tire size are displayed on the tire and loading information label. (P. 575) PRIUS_OM_OM47857U_DVD_(U)
Page 454 4-3. Do-it-yourself maintenance Inspection and adjustment procedure ■ Tire valve Tire pressure gauge ITO43P117 STEP Remove the tire valve cap. STEP Press the tip of the tire pressure gauge onto the tire valve. STEP Read the pressure using the gauge gradations. STEP If the tire inflation pressure is not at the recommended level, adjust the pressure.
Page 455 Reduced driving comfort and tire life ● Reduced safety ● Damage to the drive train If a tire needs frequent inflating, have it checked by your Toyota dealer. Instructions for checking tire inflation pressure ■ When checking tire inflation pressure, observe the following: ●...
Page 456 4-3. Do-it-yourself maintenance CAUTION Proper inflation is critical to save tire performance ■ Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury: ● Excessive wear ● Uneven wear ●...
Page 457: Wheels
● Bent wheels that have been straightened Aluminum wheel precautions ■ ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 458 4-3. Do-it-yourself maintenance When replacing wheels ■ The wheels of your vehicle are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advance warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, tire pressure warning valves and trans- mitters must be installed.
Page 459 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 460: Electronic Key Battery
4-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: ■ ● Flathead screwdriver ● Lithium battery CR1632 Replacing the battery ■ Take out the mechanical key. STEP Remove the cover.
Page 461 4-3. Do-it-yourself maintenance Use a CR1632 lithium battery ■ ● Batteries can be purchased at your Toyota dealer, local electrical appli- ance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manufacturer. ●...
Page 462: Checking And Replacing Fuses
4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. STEP Turn the “POWER” switch off. Vehicles with Solar Ventilation System: Turn the Solar Ventilation System off and make sure not to operate the Remote Air Condi- tioning System.
Page 463 4-3. Do-it-yourself maintenance STEP Remove the fuse. Only type A fuse can be removed using the pullout tool. STEP Check if the fuse is blown. Type A Normal fuse Blown fuse Replace the blown fuse with a new fuse of an appropriate amperage rating.
Page 464 4-3. Do-it-yourself maintenance Type B Normal fuse Blown fuse Replace the blown fuse with a new fuse of an appropriate amperage rating. The amper- age rating can be found on the fuse box lid. Type C Normal fuse Blown fuse Replace the blown fuse with a new fuse of an appropriate amperage rating.
Page 465 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings Engine compartment ■ FUSE Ampere Circuit Air conditioning system Electric cooling fans Electric cooling fans S-HORN No circuit ENG W/P Cooling system ABS MAIN 7.5A Anti-lock brake system NO.2 H-LP CLN Headlight cleaner P position control system, trans- P-CON MTR mission...
Page 466 4-3. Do-it-yourself maintenance FUSE Ampere Circuit 7.5A Power management system ECU-B2 7.5A Smart key system, hybrid system MAYDAY MAYDAY ECU-B3 Air conditioning system TURN & HAZ Turn signal lights Multiport fuel injection system/ ETCS sequential multiport fuel injection system ABS MAIN Anti-lock brake system NO.1 H-LP LH LO...
Page 467 4-3. Do-it-yourself maintenance FUSE Ampere Circuit MIR HTR Outside rear view mirror defoggers RAD NO.1 Audio system, navigation system Door courtesy lights, luggage compartment light, personal light, DOME interior light, foot lights, vanity lights, inside rear view mirror, garage door opener Smart key system, personal lights, ECU-B 7.5A...
Page 468 4-3. Do-it-yourself maintenance Left side instrument panel ■ 9 10 15 16 17 18 23 24 25 26 27 28 29 30 20 21 ITO43P133 FUSE Ampere Circuit Power outlets Multiplex communication system, outside rear view mirrors, driver support system, audio system, ECU-ACC navigation system, advanced parking guidance system, head-up...
Page 469 4-3. Do-it-yourself maintenance FUSE Ampere Circuit P FR DOOR Power windows D FR DOOR Power windows DOOR RR Power windows DOOR RL Power windows S/ROOF Moon roof Electric cooling fans, multiplex ECU-IG NO.1 communication system, vehicle proximity notification system Driver support system, Pre-Colli- sion System, LKA system, inside rear view mirror, garage door opener, yaw rate &...
Page 470 4-3. Do-it-yourself maintenance FUSE Ampere Circuit RR WIP Rear window wiper and washer Windshield wipers 7.5A Gauges and meters Brake system, driver support sys- tem, multiport fuel injection sys- tem/sequential multiport fuel injection system, SRS airbag sys- tem, front passenger occupant classification system (ECU and sensors), power management sys- tem, smart key system, front pas-...
Page 471 The fuses are designed to blow, protecting the wiring harness from damage. When replacing light bulbs ■ Toyota recommends that you use genuine Toyota products designed for this vehicle. Because certain bulbs are connected to circuits designed to prevent overload, non-genuine parts or parts not designed for this vehicle may be unusable.
Page 472 4-3. Do-it-yourself maintenance NOTICE Before replacing fuses ■ Have the cause of electrical overload determined and repaired by your Toyota dealer as soon as possible. PRIUS_OM_OM47857U_DVD_(U)
Page 473: Light Bulbs
You may replace the following bulbs by yourself. The difficulty level of replacement varies depending on the bulb. As there is a danger that components may be damaged, we recommend that replacement is carried out by your Toyota dealer. Preparing for light bulb replacement ■...
Page 474 4-3. Do-it-yourself maintenance Rear bulb locations ■ Rear turn signal light License plate lights Back-up light Replacing light bulbs Headlight low beams (halogen headlights) ■ STEP Turn the bulb base counterclock- wise. PRIUS_OM_OM47857U_DVD_(U)
Page 475 4-3. Do-it-yourself maintenance Unplug connector while STEP pressing the lock release. ITO43P163 Replace the light bulb, and install STEP the bulb base. Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the bulb base. STEP Shake the bulb base gently to check that it is not loose, turn the...
Page 476 4-3. Do-it-yourself maintenance Headlight high beams (including daytime running lights for ■ Canada) STEP Turn the bulb base counterclockwise. Vehicles with halogen headlights Vehicles with LED headlights Unplug connector while STEP pressing the lock release. ITO43P165 PRIUS_OM_OM47857U_DVD_(U)
Page 477 4-3. Do-it-yourself maintenance Replace the light bulb, and install STEP the bulb base. Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the bulb base. STEP Shake the bulb base gently to check that it is not loose, turn the headlights on once and visually confirm that no light is leaking through the mounting.
Page 478 4-3. Do-it-yourself maintenance Parking lights (halogen headlights) ■ Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP ITO43P167 STEP When installing, reverse the steps listed. PRIUS_OM_OM47857U_DVD_(U)
Page 479 4-3. Do-it-yourself maintenance Front side marker lights ■ STEP Turn the bulb base counterclockwise. Vehicles with halogen headlights Vehicles with LED headlights Remove the light bulb. STEP ITO43P167 STEP When installing, reverse the steps listed. PRIUS_OM_OM47857U_DVD_(U)
Page 480 4-3. Do-it-yourself maintenance Fog lights (if equipped) ■ Remove the fender liner bolt and STEP clip and pull down the fender liner. Unplug connector while STEP pressing the lock release. Turn the bulb base counterclock- STEP wise. PRIUS_OM_OM47857U_DVD_(U)
Page 481 4-3. Do-it-yourself maintenance STEP When installing, reverse the steps listed. After installing the bulb base, shake the bulb base gently to check that it is not loose. Insert the clip. PRIUS_OM_OM47857U_DVD_(U)
Page 482 4-3. Do-it-yourself maintenance Front turn signal lights ■ STEP Remove the fender liner bolt and clip and pull down the fender liner. (P. 480) For the U.S.A. Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP PRIUS_OM_OM47857U_DVD_(U)
Page 483 4-3. Do-it-yourself maintenance For Canada Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP ITO43P144 STEP When installing, reverse the steps listed. Insert the clip. PRIUS_OM_OM47857U_DVD_(U)
Page 484 4-3. Do-it-yourself maintenance Rear turn signal lights and back-up lights ■ Open the back door and remove STEP the cover. To prevent damage, cover the tip of the screwdriver with a rag. Turn the bulb base counterclock- STEP wise. Rear turn signal light Back-up light Remove the light bulb.
Page 485 4-3. Do-it-yourself maintenance License plate lights ■ Open the back door and remove STEP the cover. To prevent damage, cover the tip of the screwdriver with a rag. Turn the bulb base counterclock- STEP wise. ITO43P149 Remove the light bulb. STEP ITO43P150 STEP...
Page 486 (except for Canada) consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced.
Page 487 4-3. Do-it-yourself maintenance CAUTION Replacing light bulbs ■ ● Be sure to stop the hybrid system and turn off the lights. Do not attempt to replace the bulb immediately after turning off the lights. The bulbs become very hot and may cause burns. ●...
Page 488 4-3. Do-it-yourself maintenance PRIUS_OM_OM47857U_DVD_(U)
Page 489: When Trouble Arises
When trouble arises 5-1. Essential information Emergency flashers ..490 If your vehicle needs to be towed ....491 If you think something is wrong ......498 5-2. Steps to take in an emergency If a warning light turns on or a warning buzzer sounds ....
Page 490: Essential Information Emergency Flashers
5-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.
Page 491: If Your Vehicle Needs To Be Towed
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
Page 492 5-1. Essential information Emergency towing If a tow truck is not available in an emergency, your vehicle may be temporarily towed using a cable or chain secured to the emergency towing eyelet(s). This should only be attempted on hard surfaced roads for short distances at under 18 mph (30 km/h).
Page 493 5-1. Essential information Installing towing eyelets Remove the eyelet cover using a STEP flathead screwdriver. To prevent damage, cover the tip of the screwdriver with a rag. Insert the towing eyelet into the STEP hole and tighten partially by hand. Tighten down the towing eyelet STEP securely using a wheel nut...
Page 494 5-1. Essential information Towing with a sling-type truck Do not tow with a sling-type truck to prevent body damage. Towing with a wheel-lift type truck From the front Release the parking brake. From the rear Use a towing dolly under the front wheels.
Page 495 5-1. Essential information Using a flat bed truck If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45. Do not overly tighten the tie downs or the vehicle may be damaged. Before emergency towing ■...
Page 496 5-1. Essential information CAUTION Caution while towing ■ ● Use extreme caution when towing the vehicle. Avoid sudden starts or erratic driving maneuvers which place excessive stress on the emergency towing eyelets and the cables or chains. Always be cautious of the surroundings and other vehicles while towing. ●...
Page 497 5-1. Essential information NOTICE To prevent damaging the vehicle ■ When raising the vehicle, ensure adequate ground clearance for towing at the opposite end of the raised vehicle. Without adequate clearance, the vehicle could be damaged while being towed. To prevent causing serious damage to the hybrid transmission when ■...
Page 498: If You Think Something Is Wrong
5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ■ ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 499: Steps To Take In An Emergency If A Warning Light Turns On Or A Warning Buzzer Sounds
If a light comes on or flashes, but then goes off, this does not necessarily indicate a malfunction in the system. However, if this continues to occur, have the vehicle inspected by your Toyota dealer. Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous.
Page 500 Stop the vehicle immediately. The following warning indicates the possibility of damage to the vehi- cle that may lead to an accident. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Charging system warning light Indicates a malfunction in the vehicle’s charging system...
Page 501 5-2. Steps to take in an emergency Have the vehicle inspected by your Toyota dealer immediately. Failure to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately.
Page 502 5-2. Steps to take in an emergency Warning light Warning light/Details Pre-collision system warning light Indicates a malfunction in the pre-collision system The warning light will operate as follows, even when the system is not malfunctioning: • The light will flash quickly when the system is operating. (P.
Page 503 5-2. Steps to take in an emergency Warning light Warning light/Details Automatic headlight leveling system warning light Indicates a malfunction in the automatic headlight level- ing system (If equipped) Cruise control indicator Indicates a malfunction in the cruise control/dynamic (Flashes) radar cruise control (If equipped) Radar cruise control indicator...
Page 504 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light goes off. Correction Warning light Warning light/Details procedure Open door warning light (warning buzzer) Check that all the Indicates that a door is doors are closed.
Page 505 • Flat tire (P. 530) tion pressure is adjusted, have the system checked by your Toyota dealer. When the light comes on after blinking for 1 minute: Have the system Malfunction in the tire checked by your pressure warning sys- Toyota dealer.
Page 506 5-2. Steps to take in an emergency : Open door warning buzzer: The open door warning buzzer sounds to alert one or more of the doors is not fully closed (with the vehicle having reached a speed of 3 mph [5 km/h]). : Seat belt warning buzzer: The driver’s and front passenger’s seat belts reminder sounds to alert the driver and front passenger that his or her seat belt is not fastened.
Page 507 The malfunction indicator lamp will go off after several driving trips. If the malfunction indicator lamp does not go off even after several trips, con- tact your Toyota dealer as soon as possible. When the tire pressure warning light comes on ■...
Page 508 If there is a lot of snow or ice on the vehicle, particularly around the wheels or wheel housings ● If non-genuine Toyota wheels are used (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ●...
Page 509 If both the ABS and the brake system warning lights remain on ■ Stop your vehicle in a safe place immediately and contact your Toyota dealer. The vehicle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
Page 510 Check the tires. If a tire is flat, change it with the spare tire and have the flat tire repaired by the nearest Toyota dealer. ● Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you could lose control of the steering wheel or the brakes.
Page 511 5-2. Steps to take in an emergency CAUTION As an added safety feature, your vehicle has been equipped with a tire pressure monitoring system (TPMS-tire pressure warning system) that illuminates a low tire pressure telltale (tire pressure warning light) when one or more of your tires is significantly under-inflated.
Page 512 5-2. Steps to take in an emergency CAUTION TPMS (tire pressure warning system) malfunctions may occur for a vari- ety of reasons, including the installation of replacement or alternate tires or wheels on the vehicle that prevent the TPMS (tire pressure warning system) from functioning properly.
Page 513: If A Warning Message Is Displayed
If any of the warning light turns on again after performing the fol- lowing actions, contact your Toyota dealer. PRIUS_OM_OM47857U_DVD_(U)
Page 514 A buzzer sounds and a warning message is shown on the multi-infor- mation display. The following warnings indicate the possibility of dam- age to the vehicle that may lead to an accident. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning message Details Indicates an abnormal engine oil pressure.
Page 515 Have the vehicle inspected immediately. Failure to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning message Details Indicates a malfunction in the LED headlight system.
Page 516 5-2. Steps to take in an emergency Warning message Details Indicates a malfunction in the pre-collision system. (Flashes) A buzzer also sounds. (If equipped) Indicates a malfunction in the radar cruise control sys- tem. A buzzer also sounds. (Flashes) Press the “ON-OFF” button once to deactivate the system, and then press the button again to reacti- vate the system.
Page 517 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning message turns off. Correction Warning message Details procedure Indicates that all maintenance according to the driven dis- tance on the maintenance schedule should be per-...
Page 518 5-2. Steps to take in an emergency Correction Warning message Details procedure • Check the grille • Indicates that the pre-collision and the sensor and system is not currently func- clean them if they tional because the grille or the are dirty.
Page 519 5-2. Steps to take in an emergency Correction Warning message Details procedure Indicates that there is a high possibility of a frontal collision, or that the pre-collision braking function is operating. Slow the vehicle by A buzzer also sounds. applying the At the same time, (Flashes brakes.
Page 520 5-2. Steps to take in an emergency Correction Warning message Details procedure Indicates that the LKA (Lane- Keeping Assist) is suspended • The camera sensor tempera- Restart the LKA ture is higher than the opera- after driving for a tion temperature range. while.
Page 521 5-2. Steps to take in an emergency Correction Warning message Details procedure When stopping the vehicle for a long period of time, shift The hybrid battery (traction the shift position to battery) is low. P. The hybrid bat- A buzzer also sounds. tery (traction bat- (Flashes) tery) cannot be...
Page 522 5-2. Steps to take in an emergency Correction Warning message Details procedure To shift the shift Pressed the P position switch position to P, stop while the vehicle is running. the vehicle com- The shift position automati- pletely and press cally changed to N.
Page 523 5-2. Steps to take in an emergency Warning message in radar cruise mode (if equipped) ■ In the following cases, the warning message may not be displayed even if vehicle-to-vehicle distance decreases: ● When your vehicle and the vehicle ahead are traveling at the same speed or the vehicle ahead is traveling more quickly than your vehicle.
Page 524 5-2. Steps to take in an emergency Have the malfunction repaired immediately. After taking the specified steps to correct the suspected problem, check that the warning message and light turn off. Interior Exterior Correction Warning message Details buzzer buzzer procedure The electronic Confirm key is not...
Page 525 5-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure The driver’s door is opened and closed Turn the while the elec- “POWER” tronic key is out- switch to side the OFF or detection range Once 3 times confirm...
Page 526 5-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure The electronic key has been taken outside Turn the the vehicle and “POWER” the doors have switch to Contin- been locked Once OFF and uous without first lock the...
Page 527 5-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure An attempt to lock the doors has been made using the smart key system while the elec- tronic key is inside the vehi- cle. (vehicles Take the with entry func- electronic...
Page 528 5-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure The driver’s door is opened and closed while the elec- • Shift the tronic key is out- shift posi- side the tion to P. Contin- Contin- detection range...
Page 529 5-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure The elec- tronic key  P. 548 Once does not operate (Flashes) properly. Next time when starting the Power hybrid system, increase the turned off engine speed due to ...
Page 530: If You Have A Flat Tire
5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. Before jacking up the vehicle ■ ● Stop the vehicle on a hard, flat surface. ● Set the parking brake. ●...
Page 531 5-2. Steps to take in an emergency Taking out the jack STEP Remove the center deck board and center auxiliary box. Type A Pull the strap up to open the cen- ter deck board, lift up the center auxiliary box, and unload it from the vehicle.
Page 532 5-2. Steps to take in an emergency Remove the jack handle. STEP Unhook the tightening strap. After storing the jack, make sure it is securely held by the tightening strap. Taking out the spare tire Loosen the center fastener that secures the spare tire.
Page 533 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 534 5-2. Steps to take in an emergency STEP Slightly loosen the wheel nuts (one turn). ITO52P108 Turn the tire jack portion “A” by STEP hand until the notch of the jack is in contact with the jack point. Raise the vehicle until the tire is STEP slightly raised off the ground.
Page 535 5-2. Steps to take in an emergency Remove all the wheel nuts and STEP the tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid scratching the wheel surface. ITO52P114 Installing the spare tire Remove any dirt or foreign mat- STEP...
Page 536 5-2. Steps to take in an emergency Replacing an aluminum wheel with a compact spare tire Tighten the nuts until the tapered Tapered portion portion comes into loose contact with the disc wheel seat. Disc wheel seat Replacing an aluminum wheel with an aluminum wheel Turn the nut washers until they Disc wheel come into contact with the disc...
Page 537 5-2. Steps to take in an emergency Lower the vehicle. STEP ITO52P119 Firmly tighten each nut two or STEP three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) ITO52P120 Vehicles with wheel ornament, STEP reinstall the wheel ornament.
Page 538 5-2. Steps to take in an emergency Stowing the flat tire For vehicles with a 17-inch STEP wheel: Before stowing the flat tire, remove the center wheel ornament by pushing from the reverse side. ITO52P123 Place the flat tire on the deck STEP board, and pass the belt through the lower-right cargo hook and...
Page 539 5-2. Steps to take in an emergency Pass the belt through the buckle STEP and secure the tire firmly. Check that the belt is securely held by the buckle. The belt cannot be fastened securely if the buckle is facing the wrong direction.
Page 540 5-2. Steps to take in an emergency If you have a flat front tire on a road covered with snow or ice ■ Install the compact spare tire on one of the rear wheels of the vehicle. Perform the following steps and fit tire chains to the front tires: STEP Replace a rear tire with the compact spare tire.
Page 541 5-2. Steps to take in an emergency CAUTION When the compact spare tire is attached ■ The vehicle speed may not be correctly detected, and the following sys- tems may not operate correctly: ● ABS & Brake assist ● ● TRAC ●...
Page 542 5-2. Steps to take in an emergency CAUTION Using the tire jack ■ Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. Observe the following precautions: ● Do not use the tire jack for any purpose other than replacing tires or installing and removing tire chains.
Page 543 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install the wheel nuts with the tapered ends facing inward.
Page 544 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 545: If The Hybrid System Will Not Start
5-2. Steps to take in an emergency If the hybrid system will not start Reasons for the hybrid system not starting vary depending on the situation. Check the following and perform the appropriate proce- dure: The hybrid system will not start even though the correct ■...
Page 546 ● One or both of the 12-volt battery terminals may be discon- nected. ● The 12-volt battery may be discharged. (P. 550) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function...
Page 547: If You Lose Your Keys
5-2. Steps to take in an emergency If you lose your keys New genuine keys can be made by your Toyota dealer using the other key and the key number stamped on your key number plate. PRIUS_OM_OM47857U_DVD_(U)
Page 548: If The Electronic Key Does Not Operate Properly
5-2. Steps to take in an emergency If the electronic key does not operate properly If communication between the electronic key and vehicle is inter- rupted (P. 74) or the electronic key cannot be used because the battery is depleted, the smart key system and wireless remote con- trol cannot be used.
Page 549 5-2. Steps to take in an emergency Starting the hybrid system STEP Depress the brake pedal. Touch the Toyota emblem side of STEP electronic “POWER” switch. If any of the doors is opened or closed while the key is being...
Page 550: If The 12-Volt Battery Is Discharged
The following procedures may be used to start the hybrid system if the vehicle’s 12-volt battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your vehicle by follow- ing the steps below.
Page 551 5-2. Steps to take in an emergency STEP Connect the jumper cables according to the following procedure: Connect a positive jumper cable clamp to the exclusive jump starting terminal on your vehicle. Connect the clamp on the other end of the positive cable to the positive (+) battery terminal on the second vehicle.
Page 552 ON mode. STEP Make sure the “READY” indicator comes on. If the indicator light does not come on, contact your Toyota dealer. STEP Once the hybrid system has started, remove the jumper cables in the exact reverse order from which they were con- nected.
Page 553 5-2. Steps to take in an emergency Starting the hybrid system when the 12-volt battery is discharged ■ The hybrid system cannot be started by push-starting. To prevent 12-volt battery discharge ■ ● Turn off the headlights and the audio system while the hybrid system is off.
Page 554 5-2. Steps to take in an emergency CAUTION Avoiding 12-volt battery fires or explosions ■ Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the 12-volt battery: ● Make sure each jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any other than the intended terminal.
Page 555 CAUTION After recharging the 12-volt battery ■ Have the 12-volt battery inspected at your Toyota dealer as soon as possi- ble. If the 12-volt battery is deteriorating, continued use may cause the 12-volt battery to emit a malodorous gas, which may be detrimental to the health of passengers.
Page 556: If Your Vehicle Overheats
If you do not see steam: Carefully lift the hood. After the hybrid system has STEP cooled down sufficiently, inspect the hoses and radiator core (radiator) for any leaks. Radiator Cooling fans If a large amount of coolant leaks, immediately contact your Toyota dealer. PRIUS_OM_OM47857U_DVD_(U)
Page 557 (The fans may not operate in freezing temperatures.) STEP If the fans are not operating: Stop the hybrid system immediately and contact your Toyota dealer. If the fans are operating: Have the vehicle inspected at the nearest Toyota dealer. PRIUS_OM_OM47857U_DVD_(U)
Page 558 (radiator) for any leaks. Radiator Cooling fans If a large amount of coolant leaks, immediately contact your Toyota dealer. The coolant level is satisfactory if STEP it is between the “F” and “L” lines on the reservoir.
Page 559 Start the hybrid system and check for the multi-information display. If the message does not disappear: Stop the hybrid system and contact your Toyota dealer. If the message is not displayed: Have the vehicle inspected at the nearest Toyota dealer.
Page 560 5-2. Steps to take in an emergency CAUTION To prevent an accident or injury when inspecting under the hood of ■ your vehicle ● If steam is seen coming from under the hood, do not open the hood until the steam has subsided. The engine compartment may be very hot, caus- ing serious injuries such as burns.
Page 561: If The Vehicle Becomes Stuck
5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: STEP Set the parking brake and shift the shift position to P. Stop the hybrid system.
Page 562 5-2. Steps to take in an emergency NOTICE To avoid damage to the hybrid transmission and other components ■ ● Avoid spinning the wheels and depressing the accelerator pedal more than necessary. ● If the vehicle remains stuck even after these procedures are performed, the vehicle may require towing to be freed.
Page 563: If Your Vehicle Has To Be Stopped In An Emergency
5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: STEP Steadily step on the brake pedal with both feet and firmly...
Page 564 5-2. Steps to take in an emergency CAUTION If the hybrid system has to be turned off while driving ■ Power assist for the steering will be lost, making the steering wheel heavier to turn. Decelerate as much as possible before turning off the hybrid system. PRIUS_OM_OM47857U_DVD_(U)
Page 565: Vehicle Specifications
Vehicle specifications 6-1. Specifications Maintenance data (fuel, oil level, etc.) ....566 Fuel information ....577 Tire information ....581 6-2. Customization Customizable features ..596 6-3. Initialization Items to initialize ....603 PRIUS_OM_OM47857U_DVD_(U)
Page 566: Maintenance Data (Fuel, Oil Level, Etc.)
6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weight Overall length 176.4 in. (4480 mm) Overall width 68.7 in. (1745 mm) 58.7 in. (1490 mm) Overall height 59.3 in. (1505 mm) Wheelbase 106.3 in. (2700 mm) 60.0 in. (1525 mm) Front 59.6 in.
Page 567 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 568 6-1. Specifications Engine number ■ The engine number is stamped on the engine block as shown. Engine Model 1.8 L 4-cylinder (2ZR-FXE) Type 4-cylinder in line, 4-cycle, gasoline 3.17  3.48 in. (80.5  88.3 mm) Bore and stroke Displacement 109.7 cu.in.
Page 569: Lubrication System
6-1. Specifications Electric motor (Traction motor) Type Permanent magnet motor Maximum output 60 kW Maximum torque 153 ft•lbf (207 N•m, 21.1 kgf•m) Hybrid battery (traction battery) Type Nickel-Metal hydride battery Voltage 7.2 V/module Capacity 6.5 Ah (3HR) Quantity 28 modules Overall voltage 201.6 V Lubrication system...
Page 570 6-1. Specifications Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil Recommended viscosity: SAE 0W-20...
Page 571 6-1. Specifications How to read oil container label: The International Lubricant Specification Advisory Committee (ILSAC) Certification Mark is added to some oil containers to help you select the oil you should use. PRIUS_OM_OM47857U_DVD_(U)
Page 572: Cooling System
Power control 2.2 qt. (2.1 L, 1.8 Imp.qt.) unit Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non- Coolant type silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technol- Do not use plain water alone.
Page 573: Electrical System
If replacement is necessary, contact your Toyota dealer. NOTICE Transmission fluid type ■ Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle. PRIUS_OM_OM47857U_DVD_(U)
Page 574 6-1. Specifications Brakes Pedal clearance 3.03 in. (77 mm) Min. 0.04  0.24 in. (1.0  6.0 mm) Pedal free play Brake pad wear limit 0.04 in. (1.0 mm) Parking brake lining wear limit 0.04 in. (1.0 mm) 8 11 clicks Parking brake pedal travel Fluid type SAE J1703 or FMVSS No.
Page 575 6-1. Specifications Tires and wheels Type A Tire size P195/65R15 89S Front tire Tire inflation pressure 35 psi (240 kPa, 2.4 kgf/cm or bar) (Recommended cold tire Rear tire inflation pressure) 33 psi (230 kPa, 2.3 kgf/cm or bar) 15  6J Wheel size Wheel nut torque 76 ft•lbf (103 N•m, 10.5 kgf•m)
Page 576 6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Halogen headlights Low beam High beam 9005 LED headlights High beam 9005 Fog lights Front turn signal lights WY21W Exterior Front side marker lights Parking lights (halogen headlights) Rear turn signal lights WY21W Back-up lights W21W...
Page 577: Fuel Information
In very few cases, driveability problems may be caused by the brand of gas- oline you are using. If driveability problems persist, try changing the brand of gasoline. If this does not correct the problem, consult your Toyota dealer. PRIUS_OM_OM47857U_DVD_(U)
Page 578 EPA’s lowest additives con- centration program. ● Toyota strongly recommends the use of Top Tier Detergent Gasoline. For more information on Top Tier Detergent Gasoline and a list of marketers, please go to the official website www.toptiergas.com.
Page 579 ■ Some gasoline contains an octane enhancing additive called MMT (Methyl- cyclopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected. The malfunction indicator lamp on the instrument cluster may come on. If this happens, contact your Toyota dealer for service.
Page 580 6-1. Specifications NOTICE Notice on fuel quality ■ ● Do not use improper fuels. If improper fuels are used, the engine will be damaged. ● Do not use leaded gasoline. Leaded gasoline can cause damage to your vehicle’s three-way catalytic converters causing the emission control system to malfunction.
Page 581: Tire Information
6-1. Specifications Tire information Typical tire symbols Full-size tire Compact spare tire ITO61P105 Tire size (P. 584) DOT and Tire Identification Number (TIN) (P. 583) Location of treadwear indicators (P. 443) PRIUS_OM_OM47857U_DVD_(U)
Page 582 6-1. Specifications Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire. Summer tires or all season tires (P. 448) An all season tire has “M+S” on the sidewall. A tire not marked “M+S”...
Page 583 6-1. Specifications Typical DOT and Tire Identification Number (TIN) DOT symbol Tire Identification Number (TIN) Tire manufacturer’s identifica- tion mark Tire size code Manufacturer’s optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year : The DOT symbol certifies that the tire conforms to applicable Federal...
Page 584 6-1. Specifications Tire size Typical tire size information ■ The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code ITO61P106 (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits) Speed symbol...
Page 585 6-1. Specifications Tire section names Bead Sidewall Shoulder Tread Belt Inner liner Reinforcing rubber Carcass Rim lines Bead wires Chafer PRIUS_OM_OM47857U_DVD_(U)
Page 586 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. DOT quality grades ■...
Page 587 6-1. Specifications Traction AA, A, B, C ■ The traction grades, from highest to lowest, are AA, A, B and C, and they represent the tire’s ability to stop on wet pavement as measured under controlled conditions on specified government test surfaces of asphalt and concrete.
Page 588 6-1. Specifications Glossary of tire terminology Tire related term Meaning Tire pressure when the vehicle has been Cold tire inflation pres- parked for three hours or more, or has not sure been driven more than 1 mile or 1.5 km under that condition The maximum cold inflated pressure to which a Maximum inflation...
Page 589 6-1. Specifications Tire related term Meaning 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 that weight follows Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below The combined weight of installed regular pro- duction options weighing over 5 lb.
Page 590 6-1. Specifications Tire related term Meaning The load on an individual tire that is determined Vehicle maximum load by distributing to each axle its share of the on the tire maximum loaded vehicle weight, and dividing by two The load on an individual tire that is determined by distributing to each axle its share of curb Vehicle normal load weight, accessory weight, and normal occu-...
Page 591 6-1. Specifications Tire related term Meaning Cord The strands forming the plies in the tire The parting of cords from adjacent rubber com- Cord separation pounds Any parting within the tread, sidewall, or inner- Cracking liner of the tire extending to cord material A pneumatic tire with an inverted flange tire and rim system in which the rim is designed with rim flanges pointed radially inward and the...
Page 592 6-1. Specifications Tire related term Meaning (a) The sidewall that contains a whitewall, bears white lettering, or bears manufac- turer, brand, and/or model name molding that is higher or deeper than the same Intended outboard molding on the other sidewall of the tire, or sidewall (b) The outward facing sidewall of an asym- metrical tire that has a particular side that...
Page 593 6-1. Specifications Tire related term Meaning The linear distance between the exteriors of the sidewalls of an inflated tire, including eleva- Overall width tions due to labeling, decorations, or protective bands or ribs A tire intended for use on passenger cars, mul- tipurpose passenger vehicles, and trucks, that Passenger car tire have a gross vehicle weight rating (GVWR) of...
Page 594 6-1. Specifications Tire related term Meaning The linear distance between the exteriors of the sidewalls of an inflated tire, excluding ele- Section width vations due to labeling, decoration, or protec- tive bands That portion of a tire between the tread and Sidewall bead The parting of the rubber compound from the...
Page 595 6-1. Specifications Tire related term Meaning Tread separation Pulling away of the tread from the tire carcass The projections within the principal grooves Treadwear indicators designed to give a visual indication of the (TWI) degrees of wear of the tread The fixture used to hold the wheel and tire Wheel-holding fixture assembly securely during testing...
Page 596: Customization Customizable Features
Toyota dealer. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer for further details. Customizable features Vehicles with a Display Audio system: Settings that can be...
Page 597 6-2. Customization Custom- Default Item Function ized setting setting Smart key Smart key system system Select doors to Driver’s (P. 63) All doors unlock door Wireless remote – – control Driver’s door unlocked in All doors Unlocking 1-step, all unlocked Wireless operation doors...
Page 598 6-2. Customization Custom- Default Item Function ized setting setting Operation signals – (Emergency flashers) Level 1 to 6 Operation Smart key signals Level 7 system (Buzzers) (P. 63) and wireless remote Time elapsed control before (P. 87) automatic door lock function is 60 seconds –...
Page 599 6-2. Customization Custom- Default Item Function ized setting setting Driver’s door unlocked in All doors Unlocking using 1-step, all unlocked in – a key doors 1-step unlocked in 2-step Speed-detecting automatic door lock function Door lock (P. 89, Shifting the shift 548) position to any position other...
Page 600 6-2. Customization Custom- Default Item Function ized setting setting The one-touch Power closing operation windows – – except for (P. 126) driver’s seat Time elapsed before lights turn 15 seconds – seconds 30 seconds Operation when the doors are – –...
Page 601 6-2. Customization Custom- Default Item Function ized setting setting Sensor sensitiv- ity for darkening the brightness of the meter, navi- gation system -2 to +2 – – and instrument panel depend- ing on the out- side brightness Meter and instrument Sensor sensitiv- panel ity for returning...
Page 602 6-2. Customization Custom- Default Item Function ized setting setting Push once Operation using Push twice Push and Push and “A/C” button on hold for 0.8 – – hold for 2.4 the wireless seconds seconds remote control Remote Air Condition- Push once ing System Push and (P.
Page 603: Initialization Items To Initialize
6-3. Initialization Items to initialize The following items must be initialized for normal system operation after such cases as the 12-volt battery being reconnected, or mainte- nance being performed on the vehicle. Item When to initialize Reference Maintenance data After the maintenance is performed P.
Page 604 6-3. Initialization PRIUS_OM_OM47857U_DVD_(U)
Page 605: For Owners
For owners Reporting safety defects for U.S. owners ....606 Seat belt instructions for Canadian owners (in French) ..... 607 SRS airbag instructions for Canadian owners (in French) ..... 609 PRIUS_OM_OM47857U_DVD_(U)
Page 606: Reporting Safety Defects For U.s. Owners
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 607: Seat Belt Instructions For Canadian Owners (In French)
Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. PRIUS_OM_OM47857U_DVD_(U)
Page 608 PRIUS_OM_OM47857U_DVD_(U)
Page 609: Srs Airbag Instructions For Canadian Owners (In French)
SRS airbag instructions for Canadian owners (in French) PRIUS_OM_OM47857U_DVD_(U)
Page 610 PRIUS_OM_OM47857U_DVD_(U)
Page 611 PRIUS_OM_OM47857U_DVD_(U)
Page 612 PRIUS_OM_OM47857U_DVD_(U)
Page 613 PRIUS_OM_OM47857U_DVD_(U)
Page 614 PRIUS_OM_OM47857U_DVD_(U)
Page 615 PRIUS_OM_OM47857U_DVD_(U)
Page 616 PRIUS_OM_OM47857U_DVD_(U)
Page 617 PRIUS_OM_OM47857U_DVD_(U)
Page 618 PRIUS_OM_OM47857U_DVD_(U)
Page 619 PRIUS_OM_OM47857U_DVD_(U)
Page 620 PRIUS_OM_OM47857U_DVD_(U)
Page 621: Index
Index Abbreviation list ..... 622 Alphabetical index....624 What to do if......635 Vehicles with a Display Audio system: For details of equipment related to the Display Audio system, such as the audio system, refer to the “DISPLAY AUDIO SYSTEM OWNER’S MANUAL”. Vehicles with a navigation system: For details of equipment related to the navigation sys- tem and touch screen, such as the audio systems, refer...
Page 622: Abbreviation List
Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Air Conditioning Anti-lock Brake System Automatic Locking Retractor APGS Advanced Parking Guidance System Child Restraint System DISP Display Economy/Ecology Electronic Control Unit Event Data Recorder Emergency Locking Retractor Electric Power Steering Electric Vehicle GAWR Gross Axle Weight Ratings Global Positioning System GVWR...
Page 623 Abbreviation list ABBREVIATIONS MEANING On Board Diagnostics Pre-Collision System Power Supplemental Restraint System Tire Identification Number TPMS Tire Pressure Monitoring (Warning) System TRAC Traction Control Treadwear Indicator Vehicle Identification Number Vehicle Stability Control PRIUS_OM_OM47857U_DVD_(U)
Page 624: Alphabetical Index
Alphabetical index Alphabetical index Antenna ........404 Anti-lock brake system ... 300 Automatic air conditioning Armrest ........375 system ........330 ABS ...........300 Assist grips ......376 Active head restraint ....102 Audio input ......356 Air conditioning system Audio remote control switches Automatic air conditioning Audio system...
Page 625 Alphabetical index Back door Camera Care Back door ....... 95 Smart key system....63 Exterior........402 Wireless remote control..87 Interior ........405 Back-up lights Seat belts ......406 Cargo capacity ......320 Replacing light bulbs .... 473 Cargo hooks ......379 Wattage ........ 576 Battery CD player Chains ........323...
Page 626 Alphabetical index Child safety Daytime running light system ........255 Airbag precautions ....150 Deck board ....... 379 Back door precautions ....97 Defogger Child restraint system....162 Child-protectors.......90 Rear window ......350 How your child should wear Side mirrors......350 Dimensions ......566 the seat belt ......113 Dinghy towing ......327 Installing child restraints..167...
Page 627 Alphabetical index Eco drive mode switch ... 206 Engine Electric power steering... 300 Accessory mode....196 Electronic key Compartment ......425 If the electronic key does not Hood........419 operate properly....548 How to start the hybrid Replacing battery ....460 system ........194 Emergency, in case of Identification number.....567 If a warning buzzer...
Page 628 Alphabetical index Floor mats.........377 Garage door opener ....385 Fluid Gauges........216 Glove boxes ......362 Brake........574 Washer........435 Fog lights Hands-free system Replacing light bulbs .....473 (for cellular phone) Switch........258 Hazard lights Wattage.........576 Switch ........490 Foot lights.........357 Head restraints Front fog lights Adjustment ......
Page 629 Alphabetical index I/M test........415 Lane-Keeping Assist ....289 Identification Language ........240 License plate lights Engine ........568 Vehicle........567 Replacing light bulbs .....473 Ignition switch ......194 Wattage.........576 Illuminated entry system ..357 Light bulbs Immobilizer system....138 Replacing ......473 Indicator lights ......
Page 630 Alphabetical index Maintenance Outside temperature display ........370 Do-it-yourself Overheating......556 maintenance .......416 General maintenance....411 Maintenance data....566 Parking brake ......214 Maintenance requirements..408 Parking lights Maintenance data.....409 Switch ........252 Meter PCS ........... 307 Instrument panel light Personal lights control .........219 Switch ........
Page 631 Alphabetical index Replacing Seats Electronic key battery ... 460 Adjustment ....101, 104 Fuses........462 Adjustment Light bulbs ......473 precautions ....103, 106 Tires ........530 Child seats/child restraint Reporting safety defects for system installation ....167 U.S. owners ......606 Cleaning ........405 Folding down the Safety Connect ......
Page 632 Alphabetical index Steering wheel Tail lights Adjustment ......119 Switch ........252 Talk switch Audio switches Storage feature......361 Telephone switch Stuck Theft deterrent system If your vehicle becomes Immobilizer system ....138 Tire inflation pressure ..... 453 stuck ........561 Sun visors.........368 Tire information Switch Glossary........
Page 633 Alphabetical index Tonneau cover......382 Warning buzzers Tools......... 530 Brake system ......499 Touch tracer display ....217 Open door ......504 Total load capacity....320 Seat belt reminder....504 Towing Warning lights Dinghy towing....... 327 Anti-lock brake system Emergency towing....492 (ABS) ........501 Trailer towing......
Page 634 Alphabetical index Warning messages ....513 Washer Checking .......435 Preparing and checking before winter .......321 Switch........260 Washing and waxing ....402 Weight Cargo capacity ......320 Load limits ......320 Weight ........566 Wheels ........457 Window glasses .......126 Window lock switch....126 Windows Power windows .....126 Rear window defogger ..350 Washer........260 Windshield wipers ....260...
Page 635: What To Do If
What to do if... What to do if... If you have a flat tire A tire punctures P. 530 P. 545 If the hybrid system will not start P. 138 Immobilizer system The hybrid system does not start If the 12-volt battery is P.
Page 636 What to do if... ■ Warning lights Master warning light ABS warning light P. 505 Brake system warning light (red indicator) P. 501 Electric power steering system warning light P. 499 P. 501 Charging system Pre-collision system warning light warning light P.
Page 637 What to do if... Radar cruise control Driver’s belt reminder indicator light P. 503 light P. 504 LKA (Lane-Keeping Tire pressure warning Assist) indicator light light P. 502 P. 505 Open door warning light P. 504 Front passenger’s seat Low fuel level warning belt reminder light P.
Page 638 What to do if... PRIUS_OM_OM47857U_DVD_(U)
Page 639 What to do if... PRIUS_OM_OM47857U_DVD_(U)
Page 640: Gas Station Information
Engine oil capacity qt. (L, Imp.qt.)  (Drain and refill  With filter 4.4 (4.2, 3.7) reference) Without filter 4.1 (3.9, 3.4 Toyota Genuine Motor Oil or equivalent Engine oil type Oil grade: ILSAC GF-5 multigrade engine oil P. 569 PRIUS_OM_OM47857U_DVD_(U)
