Page 20: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 21 ● Anti-lock brake system ● SRS airbag system ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation. High voltage parts and cables on the hybrid vehicles emit approximately the...
Page 22 ● Usage of data collected through Safety Connect (U.S. mainland only) If your Toyota has Safety Connect and if you have subscribed to those ser- vices, please refer to the Safety Connect Telematics Subscription Service Agreement for information on data collected and its usage.
Page 23 Event data recorder This vehicle is equipped with an event data recorder (EDR). The main pur- pose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.
Page 24 ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehicle) is obtained • In response to an official request by the police, a court of law or a govern- ment agency •...
Page 25 CAUTION General precautions while driving ■ Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.
Page 26 In the event that your vehicle must be disposed of, the hybrid battery (traction battery) must be disposed of by your Toyota dealer or a qualified service shop. If the hybrid battery (traction battery) is not disposed of properly, it may cause electric shock that can result in death or serious injury.
Page 27 This is a warning against something which, if ignored, may cause damage to the vehicle or its equipment. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
Page 28 PRIUS v_OM_OM47840U_(U)
Page 29: Before Driving
Before driving 1-1. Hybrid system 1-4. Adjustable components (seats, mirrors, steering Hybrid system features ..30 wheel) Hybrid system precautions ...... 36 Front seats ......84 Energy monitor/ Rear seats......88 consumption screen..42 Head restraints....93 Hybrid vehicle driving Seat belts ......
Page 30: Hybrid System Hybrid System Features
1-1. Hybrid system Hybrid system features Your vehicle is a hybrid vehicle. It has characteristics different from conventional vehicles. Be sure you are closely familiar with the char- acteristics of your vehicle, and operate with care. The hybrid system combines the use of a gasoline engine and an electric motor (traction motor) according to driving conditions, improving fuel efficiency and reducing exhaust emissions.
Page 31 1-1. Hybrid system When stopped/during start off ■ The gasoline engine stops when the vehicle is stopped. During start off, the electric motor (traction motor) drives the vehicle. At slow speeds or when traveling down a gentle slope, the engine is stopped and the electric motor (traction motor) is used.
Page 32 1-1. Hybrid system Vehicle proximity notification system When driving with the gasoline engine stopped, a sound, which changes in accordance with the driving speed, will be played in order to warn people nearby of the vehicle’s approach. The sound will stop when the vehicle speed exceeds approximately 15 mph (25 km/h).
Page 33 After the 12-volt battery has discharged or has been changed or ■ removed The gasoline engine may not stop even if the vehicle is running on the hybrid battery (traction battery). If this continues for a few days, contact your Toyota dealer. PRIUS v_OM_OM47840U_(U)
Page 34 1-1. Hybrid system Sounds and vibrations specific to a hybrid vehicle ■ There may be no engine sounds or vibration even though the vehicle is able to move. For safety, apply the parking brake and make sure to shift the shift position to P when parked.
Page 35 Maintenance, repair, recycling, and disposal ■ Contact your Toyota dealer regarding maintenance, repair, recycling and dis- posal. Do not dispose of the vehicle yourself. PRIUS v_OM_OM47840U_(U)
Page 36: Hybrid System Precautions
1-1. Hybrid system Hybrid system precautions Take care when handling the hybrid system, as it contains a high voltage system (about 650V at maximum) as well as parts that become extremely hot when the hybrid system is operating. Obey the caution labels attached to the vehicle. Air conditioning compressor Hybrid battery (traction bat- tery)
Page 37 If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact your Toyota dealer. PRIUS v_OM_OM47840U_(U)
Page 38 ■ volt battery is disconnected The hybrid system may not start. In that case, try to start the system again. If the “READY” indicator does not come on, contact your Toyota dealer. Running out of fuel ■ When the vehicle has run out of fuel and the hybrid system cannot be started, refuel the vehicle with at least enough gasoline to make the low fuel level warning light (P.
Page 39 1-1. Hybrid system CAUTION High voltage precautions ■ The vehicle has high voltage DC and AC systems as well as a 12-volt sys- tem. DC and AC high voltage is very dangerous and can cause severe burns and electric shock that may result in death or serious injury. ●...
Page 40 1-1. Hybrid system CAUTION Road accident cautions ■ If your vehicle is involved in an accident, observe the following precautions to reduce the risk of death or serious injury: ● Stop the vehicle in a safe place to prevent subsequent accidents. While depressing the brake pedal, apply the parking brake, shift the shift position to P and turn the hybrid system off.
Page 41 ● Do not carry large amounts of water such as water cooler bottles in the vehicle. If water spills onto the hybrid battery (traction battery), the battery may be damaged. Have the vehicle inspected by your Toyota dealer. PRIUS v_OM_OM47840U_(U)
Page 42: Energy Monitor/Consumption Screen
1-1. Hybrid system Energy monitor/consumption screen You can view the status of your hybrid system on the Display Audio system screen or the navigation system screen. Display Audio system screen or navigation system screen Energy monitor Displays the flow of energy as it changes in accordance with driving conditions.
Page 43 1-1. Hybrid system Condition Display When the vehicle is powered by the electric motor (traction motor) When the vehicle is powered by both the gasoline engine and the electric motor (traction motor) When the vehicle is powered by the gasoline engine PRIUS v_OM_OM47840U_(U)
Page 44 1-1. Hybrid system Condition Display When the vehicle is charging the hybrid battery (traction battery) When there is no energy flow Full Hybrid battery (traction battery) status These images are examples only, and may vary slightly from actual conditions. PRIUS v_OM_OM47840U_(U)
Page 45 1-1. Hybrid system Navigation system STEP Press “INFO APPS” or “INFO”. STEP Touch “Fuel Consumption” on the “Information” screen. If the “Trip Information” or “Past Record” screen displayed, touch “Energy”. PRIUS v_OM_OM47840U_(U)
Page 46 1-1. Hybrid system Condition Display When the vehicle is powered by the electric motor (traction motor) When the vehicle is powered by both the gasoline engine and the electric motor (traction motor) When the vehicle is powered by the gasoline engine PRIUS v_OM_OM47840U_(U)
Page 47 1-1. Hybrid system Condition Display When the vehicle is charging the hybrid battery (traction battery) When there is no energy flow Full Hybrid battery (traction battery) status These images are examples only, and may vary slightly from actual conditions. PRIUS v_OM_OM47840U_(U)
Page 48 1-1. Hybrid system Trip information screen Display Audio system Press “CAR”. If the “Energy Monitor” or “History” screen is displayed, touch “Trip Infor- mation”. Fuel consumption in the past 15 minutes Displays the average vehicle speed since the hybrid system was started Displays the elapsed time since the hybrid system was...
Page 49 1-1. Hybrid system Navigation system STEP Press “INFO APPS” or “INFO”. STEP Touch “Fuel Consumption” on the “Information” screen. If the “Energy Monitor” screen is displayed, touch “Fuel Consump- tion”. If the “Past Record” screen is displayed, touch “Trip Information”. Fuel consumption in the past 15 minutes Regenerated energy in the...
Page 50 1-1. Hybrid system Past record screen Display Audio system Press “CAR”. If the “Energy Monitor” or “Trip Information” screen is displayed, touch “History”. Best past fuel consumption Average fuel consumption Displays a maximum of 5 past record of the total average fuel consumption.
Page 51 1-1. Hybrid system Resetting the consumption data ■ Display Audio system Selecting “Clear” on the “Trip Information” screen will reset the fuel con- sumption and the regenerated energy for the past 15 minutes. Selecting “Clear” on the “History” screen will reset the past records and best past fuel consumption.
Page 52: Hybrid Vehicle Driving Tips
1-1. Hybrid system Hybrid vehicle driving tips For economical and ecological driving, pay attention to the following points: Using Eco drive mode ■ When using Eco drive mode, the torque corresponding to the accelerator pedal depression amount can be generated more smoothly than it is in normal conditions.
Page 53 1-1. Hybrid system Air conditioning on/off ■ Switch the air conditioning ( ) to off when it is not needed. Doing so can help control excessive gasoline consumption. In summer: In high temperatures, use the recirculated air mode. Doing so will help to reduce the burden on the air conditioner and reduce fuel consumption as well.
Page 54: 1-2. Key Information
1-2. Key information Keys The following keys are provided with the vehicle. Electronic keys • Operating the smart key system (P. 57) • Operating wireless remote control function (P. 72) Mechanical keys Key number plate Using the mechanical key To take out the mechanical key, push the release button and take the key out.
Page 55 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a mechanical key is lost, a new key can be made at your Toyota dealer using the key number plate. (P. 478) When riding in an aircraft ■...
Page 56 Toyota dealer. When a vehicle key is lost ■ If the key remains lost, the risk of vehicle theft increases significantly. Visit your Toyota dealer immediately with all remaining electronic keys that was provided with your vehicle. PRIUS v_OM_OM47840U_(U)
Page 57: 1-3. Opening, Closing And Locking The Doors
1-3. Opening, closing and locking the doors Smart key system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) Unlocks and locks the side doors (P. 58) Unlocks and locks the back door (P.
Page 58 1-3. Opening, closing and locking the doors Unlocking and locking the doors Front door handles (including front passenger door handle if equipped with entry function) Grip the handle to unlock the doors. Make sure to touch the sensor on the back of the handle. The doors cannot be unlocked for 3 seconds after the doors are locked.
Page 59 1-3. Opening, closing and locking the doors Back door (vehicles with entry function of front and back doors) Press the unlock button to unlock all the doors. The doors cannot be unlocked for 3 seconds after the doors are locked. Press the lock button to lock all the doors.
Page 60 1-3. Opening, closing and locking the doors Antenna location and effective range Antenna location ■ Vehicles with entry function of driver’s door Antennas outside the cabin Antennas inside the cabin Antenna inside the luggage compartment Vehicles with entry function of front and back doors Antennas outside the cabin Antennas inside the cabin Antenna inside the luggage...
Page 61 1-3. Opening, closing and locking the doors Effective range (areas within which the electronic key is ■ detected) Vehicles with entry function of driver’s door When locking or unlocking the doors The system can be operated when the electronic key is within about 2.3 ft.
Page 62 1-3. Opening, closing and locking the doors Operation signals ■ A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) When the door cannot be locked by the lock sensor on the upper part ■...
Page 63 1-3. Opening, closing and locking the doors Alarms and warning lights ■ A combination of exterior and interior alarms as well as warning lights are used to prevent theft of the vehicle and accidents resulting from erroneous operation. Take appropriate measures depending on which warning light comes on.
Page 64 1-3. Opening, closing and locking the doors Alarm Situation Correction procedure The “POWER” switch was turned to ACCESSORY mode while the driver’s Close the driver’s door was open (or the door, or turn the driver’s door was opened “POWER” switch off while the “POWER”...
Page 65 1-3. Opening, closing and locking the doors Conditions affecting operation ■ The smart key system, wireless remote control and immobilizer system use weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system, wireless remote control and immobilizer system from operating properly.
Page 66 1-3. Opening, closing and locking the doors Note for the entry function ■ ● Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 67 1-3. Opening, closing and locking the doors Note for locking the doors ■ ● Touching the door lock sensor while wearing gloves may delay or prevent lock operation. Remove the gloves and touch the lock sensor again. ● When the lock operation is performed using the lock sensor, recognition signals will be shown up to two consecutive times.
Page 68 1-3. Opening, closing and locking the doors Note for the unlocking function ■ ● A sudden approach to the effective range or door handle may prevent the doors from being unlocked. In this case, return the door handle to the original position and check that the doors unlock before pulling the door handle again.
Page 69 1-3. Opening, closing and locking the doors If the smart key system does not operate properly ■ ● Locking and unlocking the doors: Use the mechanical key. (P. 479) Starting the hybrid system: P. 480 ● Electronic key battery depletion ■...
Page 70 1-3. Opening, closing and locking the doors Certification for the smart key system ■ For vehicles sold in the U.S.A. FCC ID: NI4TMLF8-2 FCC ID: HYQ14ACX FCC ID: HYQ14ADF FCC ID: HYQ13CZD FCC ID: HYQ13CZE NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 71 (P. 60) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of the emitted radio waves.
Page 72: Wireless Remote Control
1-3. Opening, closing and locking the doors Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle. Locks all the doors Unlocks all the doors Pressing the button unlocks the driver’s door. Pressing the button again within 3 seconds unlocks the other doors.
Page 73 1-3. Opening, closing and locking the doors Panic mode ■ When is pressed for longer than about one second, an alarm will sound intermittently and the vehicle lights will flash to deter any person from trying to break into or damage your vehicle. To stop the alarm, press any button on the electronic key.
Page 74: Side Doors
1-3. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the entry function, wireless remote control or door lock switch. Entry function ■ P. 57 Wireless remote control ■ P. 72 Door lock switch ■...
Page 75 1-3. Opening, closing and locking the doors Locking the front doors from the outside without a key STEP Move the inside lock button to the lock position. STEP Close the door. The door cannot be locked if the “POWER” switch is in ACCESSORY or ON mode, or the electronic key is left inside the vehicle.
Page 76 1-3. Opening, closing and locking the doors Automatic door locking and unlocking systems The following functions can be set or canceled: Function Operation Shift position linked Shifting the shift position out of P locks all door locking function doors. Shift position linked Shifting the shift position to P unlocks all door unlocking function doors.
Page 77 1-3. Opening, closing and locking the doors Shift the shift position to P or N, STEP and press and hold the door lock switch ( ) for about 5 seconds then release. The shift position corresponding to the desired function to be set are shown as follows.
Page 78 1-3. Opening, closing and locking the doors CAUTION To prevent an accident ■ Observe the following precautions while driving the vehicle. Failure to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. ●...
Page 79: Back Door
1-3. Opening, closing and locking the doors Back door The back door can be locked/unlocked and opened by the following procedures. Locking and unlocking the back door ■ Entry function P. 57 Wireless remote control P. 72 Door lock switch P.
Page 80 1-3. Opening, closing and locking the doors Luggage compartment light ■ The luggage compartment light turns on when the back door is opened with the luggage compartment light switch on. If the back door opener is inoperative ■ The back door can be unlocked from the inside. Remove the cover.
Page 81 1-3. Opening, closing and locking the doors CAUTION Caution while driving ■ ● Keep the back door closed while driving. If the back door is left open, it may hit near-by objects while driving or lug- gage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
Page 82 1-3. Opening, closing and locking the doors CAUTION Operating the back door ■ Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in death or serious injury. ● Remove any heavy loads, such as snow and ice, from the back door before opening it.
Page 83 If a bicycle carrier or similar heavy object is attached to the back door, it may suddenly shut again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genuine Toyota part is recommended. NOTICE Back door damper stays ■...
Page 84: Adjustable Components (Seats, Mirrors, Steering Wheel)
1-4. Adjustable components (seats, mirrors, steering wheel) Front seats Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (for driver’s side) Lumbar support adjustment switch (for driver’s side) : If equipped PRIUS v_OM_OM47840U_(U)
Page 85 1-4. Adjustable components (seats, mirrors, steering wheel) Flattening the seatbacks Before flattening the seatbacks ■ STEP Stop the vehicle in a safe place. Apply the parking brake firmly and shift the shift position to P. (P. 188)  STEP Slide the rear seats as far back as possible. ( P.
Page 86 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION Seat adjustment ■ ● To reduce the risk of sliding under the lap belt during a collision, do not recline the seat more than necessary. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen, or your neck may contact the shoulder belt, increasing the risk of death or serious injury in the event of an accident.
Page 87 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION ● Do not drive with luggage or passengers on the flattened seats. ● Do not allow children to enter the luggage compartment. ● After flattening, gently rock the seats to ensure they are firmly in place. ●...
Page 88: Rear Seats
1-4. Adjustable components (seats, mirrors, steering wheel) Rear seats Seatback angle adjustment lever Seat position adjustment lever PRIUS v_OM_OM47840U_(U)
Page 89 1-4. Adjustable components (seats, mirrors, steering wheel) Before folding down the seatbacks STEP Park the vehicle in a safe place. Apply the parking brake firmly and shift the shift position to P. (P. 188) STEP Adjust the position of the front seat and the angle of the seat- ...
Page 90 1-4. Adjustable components (seats, mirrors, steering wheel) Adjusting the position of the driver’s side seat back and forward ■ The driver’s side seat can be slid forward further than the front passenger’s side seat, thus easing the loading and unload- ing of luggage into and from the luggage compartment.
Page 91 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION When folding the seatbacks down ■ Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not fold the seatbacks down while driving. ● Stop the vehicle on level ground, set the parking brake and shift the shift position to P.
Page 92 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION After returning the seatback to the upright position ■ Observe the following precautions. Failure to do so may result in death or serious injury. ● Make sure that the seatback is securely locked in position by lightly push- ing it back and forth.
Page 93: Head Restraints
1-4. Adjustable components (seats, mirrors, steering wheel) Head restraints Head restraints are provided for all seats. Pull the head restraints up. Down Press hold lock release button when lowering the head restraint. Lock release button Removing the head restraints ■ Pull the head restraint up while pressing the lock release button.
Page 94 1-4. Adjustable components (seats, mirrors, steering wheel) Adjusting the height of the head restraints (front seats) ■ Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears. Adjusting the rear center seat head restraint ■...
Page 95: Seat Belts
1-4. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. Correct use of the seat belts ■ ● Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
Page 96 1-4. Adjustable components (seats, mirrors, steering wheel) Fastening the seat belt (rear center seat) ■ Press the plate to release, and STEP pull out the seat belt. Connect by inserting plate B STEP Plate B into buckle B until a click sound is heard.
Page 97 1-4. Adjustable components (seats, mirrors, steering wheel) Releasing the seat belt (rear center seat) ■ Press the release button on STEP buckle A and release the belt. Release button Buckle A Use plate A etc. to push the STEP button on buckle B, and Plate B uncouple plate B.
Page 98 1-4. Adjustable components (seats, mirrors, steering wheel) Stow the buckle B. STEP Buckle B Adjusting the seat belt shoulder anchor height (front seats) ■ Push the seat belt shoulder anchor down while pressing the release button. Push the seat belt shoulder anchor up.
Page 99 1-4. Adjustable components (seats, mirrors, steering wheel) Seat belt comfort guide (rear center seat) If the shoulder belt sits close to a person’s neck, use the seat belt comfort guide. Pull the comfort guide from the STEP seatback pocket. Slide the belt past the slot of the STEP guide.
Page 100 1-4. Adjustable components (seats, mirrors, steering wheel) Seat belt pretensioners (front seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt when the vehicle is subjected to certain types of severe frontal or side collision.
Page 101 1-4. Adjustable components (seats, mirrors, steering wheel) Emergency locking retractor (ELR) ■ The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
Page 102 Seat belt extender ■ If your seat belts cannot be fastened securely because they are not long enough, personalized seat belt extender is available from your Toyota dealer free of charge. PRIUS v_OM_OM47840U_(U)
Page 103 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 104 ● If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Toyota dealer. Adjustable shoulder anchor ■ Always make sure the shoulder belt is positioned across the center of your shoulder.
Page 105 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there’s no obvious damage.
Page 106 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION Using a seat belt extender ■ ● Do not wear the seat belt extender if you can fasten the seat belt without the extender. ● Do not use the seat belt extender when installing a child restraint system because the belt will not securely hold the child restraint system, increas- ing the risk of death or serious injury in the event of an accident.
Page 107: Steering Wheel
1-4. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and STEP push the lever down. Adjust to the ideal position by STEP moving the steering wheel horizontally and vertically.
Page 108: Inside Rear View Mirror
1-4. Adjustable components (seats, mirrors, steering wheel) Inside rear view mirror Glare from the headlights of vehicles behind can be reduced by using the following functions: Manual anti-glare inside rear view mirror Normal position Anti-glare position Auto anti-glare inside rear view mirror In “AUTO”...
Page 109 1-4. Adjustable components (seats, mirrors, steering wheel) Adjusting the height of rear view mirror (vehicles with manual anti-glare inside rear view mirror) Adjust the height of the rear view mirror by moving it up and down. To prevent sensor error (vehicles with auto anti-glare inside rear view ■...
Page 110: Outside Rear View Mirrors
1-4. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted using the switch. To select a mirror to adjust, STEP press the switch. Left Right To adjust the mirror, press the STEP switch. Right Down Left Folding the mirrors...
Page 111 1-4. Adjustable components (seats, mirrors, steering wheel) Mirror angle can be adjusted when ■ The “POWER” switch is in ACCESSORY or ON mode. When the mirrors are fogged up ■ Turn on the mirror defoggers to defog the mirrors. (P. 293) CAUTION When driving the vehicle ■...
Page 112: Opening And Closing The Windows Power Windows
1-5. Opening and closing the windows Power windows The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing Opening One-touch opening : To stop the window partway, operate the switch in the oppo- site direction.
Page 113 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after perform- ing the above procedure correctly, have the vehicle inspected by your Toyota dealer. PRIUS v_OM_OM47840U_(U)
Page 114 1-5. Opening and closing the windows CAUTION Closing the windows ■ Observe the following precautions. Failing to do so may result in death or serious injury. ● Check to make sure that all passengers do not have any part of their body in a position where it could be caught when a window is being operated.
Page 115: 1-6. Refueling
1-6. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: Before refueling the vehicle ■ Turn the “POWER” switch off and close all the doors and win- dows. Opening the fuel tank cap ■...
Page 116 1-6. Refueling Closing the fuel tank cap After refueling, turn the fuel tank cap until you hear a click. Once the cap is released, it will turn slightly in the opposite direction. Fuel types ■ Use unleaded gasoline. (Octane rating 87 [Research Octane Number 91] or higher) Fuel tank capacity ■...
Page 117 When replacing the fuel tank cap ■ Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 118 1-6. Refueling NOTICE Refueling ■ Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the emission control system to operate abnormally or damaging fuel system components or the vehicle’s painted surface. PRIUS v_OM_OM47840U_(U)
Page 119: Theft Deterrent System Immobilizer System
1-7. Theft deterrent system Immobilizer system The vehicle’s keys have built-in transponder chips that prevent the hybrid system from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. The indicator light flashes after the “POWER”...
Page 120 1-7. Theft deterrent system Certifications for the immobilizer system ■ For vehicles sold in the U.S.A. FCC ID: NI4TMIMB-1 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 121 1-7. Theft deterrent system NOTICE To ensure the system operates correctly ■ Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guar- anteed. PRIUS v_OM_OM47840U_(U)
Page 122: Safety Information Correct Driving Posture
1-8. Safety information Correct driving posture Drive with a good posture as follows: Sit upright and well back in the seat. (P. 84) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
Page 123 1-8. Safety information CAUTION While driving ■ ● Do not adjust the position of the driver’s seat. Doing so could cause the driver to lose control of the vehicle. ● Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
Page 124: Srs Airbags
1-8. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. SRS front airbags SRS driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
Page 125 1-8. Safety information SRS side and curtain shield airbags SRS side airbags Can help protect the torso of the front seat occupants SRS curtain shield airbags Can help protect primarily the head of occupants in the outer seats PRIUS v_OM_OM47840U_(U)
Page 126 1-8. Safety information SRS airbag system components Front impact sensors Side impact sensors (rear) Side impact sensors (front Front passenger’s seat belt door) buckle switch Front passenger airbag Driver’s seat belt buckle switch “AIR BAG ON” and “AIR BAG OFF” indicator lights Driver’s seat position sensor SRS warning light Driver airbag...
Page 127 1-8. Safety information Your vehicle is equipped with ADVANCED AIRBAGS designed based on the US motor vehicle safety standards (FMVSS208). The airbag sensor assembly (ECU) controls airbag deployment based on infor- mation obtained from the sensors etc. shown in the system compo- nents diagram above.
Page 128 1-8. Safety information SRS airbag deployment conditions (SRS front airbags) ■ ● The SRS front airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approxi- mately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 129 1-8. Safety information Conditions under which the SRS airbags may deploy (inflate), other ■ than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. ●...
Page 130 1-8. Safety information Types of collisions that may not deploy the SRS airbags ■ (SRS side and curtain shield airbags) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Page 131 1-8. Safety information When to contact your Toyota dealer ■ In the following cases, contact your Toyota dealer as soon as possible. ● Any of the SRS airbags has been inflated. ● The front of the vehicle is damaged or...
Page 132 1-8. Safety information CAUTION SRS airbag precautions ■ Observe the following precautions regarding the SRS airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly.
Page 133 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 134 1-8. Safety information CAUTION SRS airbag precautions ■ ● Do not sit on the edge of the seat or lean against the dashboard. ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger.
Page 135 1-8. Safety information CAUTION SRS airbag precautions ■ ● Do not attach anything to or lean any- thing against areas such as the dash- board, steering wheel pad and lower portion of the instrument panel. These items can become projectiles when the SRS driver, front passenger and knee airbags deploy.
Page 136 If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. ● Do not place anything, such as a cushion, on the front passenger’s seat.
Page 137 Modification and disposal of SRS airbag system components ■ Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury. ●...
Page 138: Front Passenger Occupant Classification System
1-8. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for the front passenger.
Page 139 1-8. Safety information Condition and operation in the front passenger occupant classification system Adult ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights ON” Indicator/ SRS warning light warning light Front passenger’s seat belt reminder light Flashing Front passenger airbag Side airbag on the front passenger seat Devices...
Page 140 1-8. Safety information Unoccupied ■ “AIR BAG ON” and “AIR BAG OFF” Not illuminated indicator lights Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag in the front passen- ger side Devices...
Page 141 1-8. Safety information : The system judges a person of adult size as an adult. When a smaller adult sits in the front passenger seat, the system may rec- ognize him/her as a child depending on his/her physique and pos- ture.
Page 142 1-8. Safety information CAUTION Front passenger occupant classification system precautions ■ Observe the following precautions regarding front passenger occupant clas- sification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger’s seat belt plate has not been left inserted into the buckle before someone sits in the front passenger seat.
Page 143 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the rear seat should not contact the front seatbacks.
Page 144: Child Restraint Systems
1-8. Safety information Child restraint systems A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 145 1-8. Safety information Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child. Rear facing  Infant seat/convertible seat Forward facing  Convertible seat Booster seat PRIUS v_OM_OM47840U_(U)
Page 146 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 147 1-8. Safety information CAUTION Child restraint precautions ■ ● Never install a rear-facing child restraint system on the front passenger seat even if the “AIR BAG OFF” indicator light is illuminated. In the event of an accident, the force of the rapid inflation of the front passenger airbag can cause death or serious injury to the child if the rear-facing child restraint system is installed on the front passenger seat.
Page 148 1-8. Safety information CAUTION When children are in the vehicle ■ Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death.
Page 149: Installing Child Restraints
1-8. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Chil- dren) system.
Page 150 1-8. Safety information Anchor brackets (for top tether strap) An anchor bracket is provided for each rear seat. Installation with LATCH system Adjusting the angle of the seat- STEP back. While pulling the lever, fold the seatback forward and then back to the 1st lock position (most upright position) until it locks into place.
Page 151 1-8. Safety information Open the fasteners on the lower STEP part of the seatback. Type A Latch the hooks of the lower STEP straps onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor.
Page 152 1-8. Safety information Type B Latch the buckles onto the STEP LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor. For owners in Canada: The symbol on a child restraint system indicates the presence of a lower connector system.
Page 153 1-8. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear facing Infant seat/convertible seat ■ Adjusting the angle of the seat- STEP back. While pulling the lever, fold the seatback forward and then back to the 1st lock position (most upright position) until it locks into place.
Page 154 1-8. Safety information Fully extend the shoulder belt STEP and then allow it to retract slightly in order to activate the ALR lock mode. Lock mode allows the seat belt to retract only. While pushing the child restraint STEP system down into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place.
Page 155 1-8. Safety information Forward-facing Convertible seat ■ Adjusting the angle of the seat- STEP back. While pulling the lever, fold the seatback forward and then back to the 1st lock position (most upright position) until it locks into place. Place the child restraint system STEP on the seat facing the front of the vehicle.
Page 156 1-8. Safety information Fully extend the shoulder belt STEP and then allow it to retract slightly in order to activate the ALR lock mode. Lock mode allows the seat belt to retract only. While pushing the child restraint STEP system into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place.
Page 157 1-8. Safety information Booster seat ■ Adjusting the angle of the seat- STEP back. While pulling the lever, fold the seatback forward and then back to the 1st lock position (most upright position) until it locks into place. Place the booster seat on the STEP seat facing the front of the vehi- cle.
Page 158 1-8. Safety information Removing a child restraint installed with a seat belt Press the buckle release button and fully retract the seat belt. Child restraint systems with a top tether strap Secure the child restraint system STEP using the seat belt or the LATCH anchors, and adjust the head restraint to the upmost position.
Page 159 1-8. Safety information Outside only: Adjust the head STEP restraint to the downmost posi- tion. Laws and regulations pertaining to anchors ■ The LATCH system conforms to FMVSS225 or CMVSS210.2. Child restraint systems conforming to FMVSS213 or CMVSS213 specifica- tions can be used. This vehicle is designed to conform to the SAE J1819.
Page 160 1-8. Safety information CAUTION When installing a child restraint system ■ Follow the directions given in the child restraint system installation manual and fix the child restraint system securely in place. If the child restraint system is not correctly fixed in place, the child or other passengers may be seriously injured or even killed in the event of sudden braking, sudden swerving or an accident.
Page 161 1-8. Safety information CAUTION When installing a child restraint system ■ ● When installing a child restraint system in the rear center seat, adjust both seat cushions to the same position and align both seatbacks at the same angle. The seatbacks must be adjusted to the same angle. Otherwise, the child restraint system cannot be securely restrained and this may cause death or serious injuries in the event of sudden braking, sudden swerving or an accident.
Page 162 1-8. Safety information CAUTION Do not use a seat belt extender ■ If a seat belt extender is used when installing a child restraint system, the seat belt will not securely hold the child restraint system, which could cause death or serious injury to the child or other passengers in the event of sud- den braking, sudden swerving or an accident.
Page 163: When Driving
When driving 2-1. Driving procedures 2-2. Instrument cluster Driving the vehicle.... 164 Gauges and meters ..197 Power (ignition) switch ..175 Indicators and warning lights ......208 EV drive mode ....182 Hybrid transmission ..185 2-3. Operating the lights and Turn signal lever ....
Page 164: 2-1. Driving Procedures
2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing: Starting the hybrid system ■ P. 175 Driving ■ STEP With the brake pedal depressed, shift the shift position to D. (P. 185) Check that the shift position indicator shows D.
Page 165 Breaking in your new Toyota ■ To extend the life of the vehicle, observing the following precautions is rec- ommended: ●...
Page 166 2-1. Driving procedures Operating your vehicle in a foreign country ■ Comply with the relevant vehicle registration laws and confirm the availability of the correct fuel. (P. 498) For efficient use ■ ● Shift the shift position to D when driving. In the N position, the gasoline engine operates but electricity cannot be generated.
Page 167 Large amounts of exhaust in the vehi- cle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immediately. PRIUS v_OM_OM47840U_(U)
Page 168 2-1. Driving procedures CAUTION ● Do not shift the shift position to P while the vehicle is moving. Doing so can damage the transmission and may result in a loss of vehicle control. ● Do not shift the shift position to R while the vehicle is moving forward. Doing so can damage the transmission and may result in a loss of vehicle control.
Page 169 If you hear a squealing or scraping noise (brake pad wear limit indica- ■ tors) Have your Toyota dealer check and replace the brake pads as soon as pos- sible. Rotor damage may result if the pads are not replaced when needed.
Page 170 2-1. Driving procedures CAUTION When the vehicle is stopped ■ ● Do not depress the accelerator pedal unnecessarily. If the vehicle is in any shift position other than P or N, the vehicle may accelerate suddenly and unexpectedly, causing an accident. ●...
Page 171 2-1. Driving procedures CAUTION ● Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle when it is in the sun. Doing so may result in the following: • Gas may leak from a cigarette lighter or spray can, and may lead to a fire.
Page 172 The exhaust system should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
Page 173 2-1. Driving procedures NOTICE When driving the vehicle ■ ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain driving torque. ● Do not use the accelerator pedal or depress the accelerator and brake pedals at the same time to hold the vehicle on a hill.
Page 174 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
Page 175: Power (Ignition) Switch
2-1. Driving procedures Power (ignition) switch Performing the following operations when carrying the electronic key on your person starts the hybrid system or changes “POWER” switch modes. Starting the hybrid system ■ STEP Check that the parking brake is set. STEP Firmly depress the brake pedal.
Page 176 2-1. Driving procedures STEP Check that the “READY” indicator is on. If the “READY” indicator changes from a flashing light to a solid light and the buzzer sounds, the hybrid system is starting nor- mally. The vehicle will not move when the “READY” indicator is off. The vehicle can move when the “READY”...
Page 177 2-1. Driving procedures Changing “POWER” switch modes ■ Modes can be changed by pressing the “POWER” switch with the brake pedal released. (The mode changes each time the switch is pressed.) The emergency flashers can be used. ACCESSORY mode Some electrical components such as the audio system can be used.
Page 178 2-1. Driving procedures Auto power off function ■ If the vehicle is left in ACCESSORY mode for more than 20 minutes or ON mode (the hybrid system is not operating) for more than an hour with the shift position in P, the “POWER” switch will automatically turn off. However, this function cannot entirely prevent the 12-volt battery from discharging.
Page 179 ■ If the “READY” indicator does not come on when you press the “POWER” switch with the shift position in P and the brake pedal depressed, contact your Toyota dealer immediately. If the hybrid system is malfunctioning ■ P. 445 If the electronic key battery is depleted ■...
Page 180 ■ The “POWER” switch will not be able to be turned off. In such a case, the switch can be turned off after applying the parking brake. Have the vehicle inspected by your Toyota dealer immediately. Meter display ■ When the “POWER” switch is turned off, each display will extinguish as fol- lows.
Page 181 Symptoms indicating a malfunction with the “POWER” switch ■ If the “POWER” switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction. Con- tact your Toyota dealer immediately. PRIUS v_OM_OM47840U_(U)
Page 182: Ev Drive Mode
2-1. Driving procedures EV drive mode In EV drive mode, the electric motor (traction motor), powered by the hybrid battery (traction battery), is used to drive the vehicle. This mode allows you to drive in residential areas late at night, or in indoor parking lots etc.
Page 183 2-1. Driving procedures Situations in which EV drive mode cannot be turned on ■ It may not be possible to turn EV drive mode on in the following situations. If it cannot be turned on, a buzzer will sound to inform the driver. ●...
Page 184 2-1. Driving procedures Automatic cancelation of EV drive mode ■ When driving in EV drive mode, the gasoline engine may automatically restart in the following situations. When EV drive mode is canceled, a buzzer will sound and the EV drive mode indicator will flash and go off. ●...
Page 185: Hybrid Transmission
2-1. Driving procedures Hybrid transmission Select a shift position appropriate for the driving conditions. Shifting the shift lever ■ Shift lever Operate the shift lever gently and ensure correct shifting operation. When shifting to the D or R positions, move the shift lever along the shift gate.
Page 186 2-1. Driving procedures Shift position indicator The position of the frame on the shift position indicator changes in accordance with the current shift position. When any shift position other than D or B is selected, the arrow toward B and B position indicator disappears from the shift position indicator. When selecting the shift position, make sure that the shift position has been changed to the desired position by checking the shift position indica- tor provided on the instrument cluster.
Page 187 2-1. Driving procedures Selecting a driving mode ■ The following modes can be selected to suit driving conditions: Eco drive mode The torque generated in response to accelerator pedal depres- sion will lessen compared to normal, and air conditioning opera- tion (heating/cooling) will be restrained, thus suiting driving with improved fuel efficiency.
Page 188 2-1. Driving procedures P position switch When shifting the shift position to P ■ Fully stop the vehicle and set the parking brake, and then press the P position switch. When shift position changed to P, the switch indicator comes on. Check that the P position is illumi- nated on the shift position indica- tor.
Page 189 2-1. Driving procedures Operation of the air conditioning system in Eco drive mode ■ Eco drive mode controls the heating/cooling operations and fan speed of the air conditioning system to enhance fuel efficiency. (P. 187) To improve air conditioning performance, adjust the fan speed or turn off Eco drive mode. For the shift positions ■...
Page 190 2-1. Driving procedures ● Situations where the shift position will automatically change to N: • When the P position switch is pressed while the vehicle is running. • When an attempt is made to select the R position by moving the shift lever when the vehicle is moving forward.
Page 191 2-1. Driving procedures About engine braking ■ When shift position B is selected, releasing the accelerator pedal will apply engine braking. ● When the vehicle is driven at high speeds, compared to ordinary gaso- line-fueled vehicles, the engine braking deceleration is felt less than that of other vehicles.
Page 192 For the shift lever ■ Do not remove the shift lever knob or use anything but a genuine Toyota shift lever knob. Also, do not hang anything on the shift lever. Doing so could prevent the shift lever from returning to position, causing unexpected accidents to occur when the vehicle is in motion.
Page 193 If any of the following situations occurs, P position control system malfunc- tions are possible. Immediately stop the vehicle in a safe place on level ground, apply the park- ing brake, and then contact your Toyota dealer. ● When the “P LOCK MALFUNCTION WHEN PARKING, PARK IN FLAT PLACE AND APPLY PARKING BRAKE SECURELY”...
Page 194: Turn Signal Lever
2-1. Driving procedures Turn signal lever The turn signal lever can be used to show the following intention of the driver: Right turn Left turn Lane change to the right (push and hold the lever partway) The right hand signals will flash until you release the lever.
Page 195: Parking Brake
2-1. Driving procedures Parking brake To set the parking brake, fully depress the parking brake pedal with your left foot while U.S.A. depressing the brake pedal with your right foot. (Depressing the pedal again Canada releases the parking brake.) Parking brake engaged warning buzzer ■...
Page 196: Horn
2-1. Driving procedures Horn To sound the horn, press on or close to the mark. After adjusting the steering wheel ■ Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (P.
Page 197: 2-2. Instrument Cluster
2-2. Instrument cluster Gauges and meters The units used on the trip information display etc. may differ depending on the target region. The following gauges and meters and display illuminate when the “POWER” switch is in ON mode: Hybrid System Indicator Hybrid System Indicator represents the hybrid system power output and regenerative charging.
Page 198 2-2. Instrument cluster Trip information display Displays fuel consumption, driving range, etc. Odometer and trip meter display Odometer: Displays the total distance that the vehicle has been driven. Trip meter: Displays the distance the vehicle has been driven since the meter was last reset. Trip meters “A” and “B”...
Page 199 2-2. Instrument cluster MPH or km/h button The speed units can be selected MPH or km/h. Press the button to switch the display between MPH and km/h. Instrument panel light control The brightness of the instrument panel lights can be adjusted by turn- ing the dial.
Page 200 2-2. Instrument cluster Changing the display Switches between odometer and trip meter displays. When the trip meter is displayed, pressing and holding the “TRIP” button will reset the trip meter. When you reset the trip meter, the average fuel consumption will be reset as well.
Page 201 2-2. Instrument cluster Trip information display Current fuel consumption ■ Displays the instant fuel consumption. Average fuel consumption ■ The average fuel consumption is displayed on both the odometer and the trip meter. • While the odometer is being displayed, or when the odometer/trip meter are not being displayed, the average fuel consumption from the last reset will be displayed.
Page 202 2-2. Instrument cluster Cruising range ■ Displays the estimated maximum distance that can be driven with the quantity of fuel remain- ing. • This distance is computed based on your average fuel consumption. As a result, the actual distance that can be driven may differ from that displayed.
Page 203 2-2. Instrument cluster Hybrid System Indicator Hybrid System Indicator displays the hybrid system operating condi- tion and provides Eco-friendly driving assistance in accordance with the driving conditions and the acceleration. Names and meaning of each icons ■ Eco Driving Indicator Light Turns on when the vehicle is driven in Eco-friendly.
Page 204 2-2. Instrument cluster As shown below, the driving conditions of the vehicle can be con- firmed by checking the status of the indicator. Hybrid System Indicator status Display Charge area: Shows regenerative charging. (P. 31) Eco area: Shows that the vehicle is driven in Eco-friendly. Hybrid Eco area: Shows that gasoline engine power is not being used very often.
Page 205 2-2. Instrument cluster Changing Hybrid System Indicator settings The items displayed on Hybrid System Indicator can be changed by operating the “DISP” button. Stop the vehicle in a place in which the operation can be safely carried out, apply the parking brake, and shift the shift position to P.
Page 206 2-2. Instrument cluster STEP Press and hold the “DISP” button for 1 second or more to complete the setup. If setup is not completed by pressing and holding the “DISP” button for 1 second or more, or if nothing is operated within approximately 10 seconds, the screen will return and the settings will be lost.
Page 207 2-2. Instrument cluster Engine speed ■ On hybrid vehicles, engine speed is precisely controlled in order to help improve fuel efficiency and reduce exhaust emissions etc. There are times when the engine speed that is displayed may differ even when vehicle operation and driving conditions are the same. Brightness of the instrument panel light ■...
Page 208: Indicators And Warning Lights
2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster inform the driver of the status of the vehicle’s various systems. Instrument cluster Some indicators and the units used on the trip information display etc.
Page 209 2-2. Instrument cluster Indicators ■ The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator Eco Driving Indicator (P. 194) Light (P. 203) Headlight indicator “ECO MODE” (P. 213) indicator (P. 187) (U.S.A.) Tail light indicator Power mode indicator (P.
Page 210 Have the vehicle inspected by your Toyota dealer. : The light flashes to indicate that the system is operating.
Page 211: Warning Lights
There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer.
Page 212 Have the vehicle inspected by your Toyota dealer immediately if this occurs.
Page 213: 2-3. Operating The Lights And Windshield Wipers
2-3. Operating the lights and windshield wipers Headlight switch The headlights can be operated manually or automatically. Turning the end of the lever turns on the lights as follows: U.S.A. (type A) The daytime running lights turn on. side marker, parking, tail, license plate, daytime run- ning lights and instru-...
Page 214 2-3. Operating the lights and windshield wipers U.S.A. (type B) The headlights, park- ing lights, daytime running lights and so on turn on and off automatically (when the “POWER” switch is in ON mode). side marker, parking, tail, license plate, daytime run- ning lights and instru- ment panel lights turn The headlights and...
Page 215 2-3. Operating the lights and windshield wipers Canada The daytime running lights turn on. side marker, parking, tail, license plate, daytime run- ning lights and instru- ment panel lights turn The headlights and all the lights listed above (except day- time running lights) turn on.
Page 216 2-3. Operating the lights and windshield wipers Turning on the high beam headlights With the headlights on, push the lever away from you to turn on the high beams. Pull the lever toward you to the center position to turn the high beams off.
Page 217 2-3. Operating the lights and windshield wipers Headlight control sensor (if equipped) ■ The sensor may not function properly if an object is placed on the sensor, or any- thing that blocks the sensor is affixed to the windshield. Doing so interferes with the sensor detecting the level of ambient light and may cause the automatic headlight sys- tem to malfunction.
Page 218 2-3. Operating the lights and windshield wipers Automatic headlight leveling system (if equipped) ■ The level of the headlights is automatically adjusted according to the number of passengers and the loading condition of the vehicle to ensure that the headlights do not interfere with other road users. Customization ■...
Page 219: Fog Light Switch
2-3. Operating the lights and windshield wipers  Fog light switch The fog lights secure excellent visibility in difficult driving condi- tions, such as in rain and fog. Type A Turns the fog lights Turns the fog lights  : If equipped PRIUS v_OM_OM47840U_(U)
Page 220 2-3. Operating the lights and windshield wipers Type B Turns the fog lights Turns the fog lights Fog lights can be used when ■ The headlights are on in low beam. NOTICE To prevent 12-volt battery discharge ■ Do not leave the lights on longer than necessary when the hybrid system is off.
Page 221: Windshield Wipers And Washer
2-3. Operating the lights and windshield wipers Windshield wipers and washer When intermittent windshield wiper operation is selected, wiper intervals can be also adjusted. The wiper operation is selected by moving the lever as follows. Type A Intermittent wind- shield wiper opera- tion speed wind-...
Page 222 2-3. Operating the lights and windshield wipers Increases the intermittent windshield wiper frequency Decreases the intermittent windshield wiper frequency Washer/wiper dual opera- tion The wipers will automatically operate a couple of times after the washer squirts. If the headlights are on, the headlight cleaner will operate once.
Page 223 2-3. Operating the lights and windshield wipers Type B Intermittent wind- shield wiper opera- tion speed wind- shield wiper opera- tion High speed wind- shield wiper opera- tion Temporary operation PRIUS v_OM_OM47840U_(U)
Page 224 2-3. Operating the lights and windshield wipers Increases the intermittent windshield wiper frequency Decreases the intermittent windshield wiper frequency Washer/wiper dual opera- tion The wipers will automatically operate a couple of times after the washer squirts. If the headlights are on, the headlight cleaner will operate once.
Page 225 Do not operate the switch continually as the washer fluid pump may over- heat. When a nozzle becomes blocked ■ In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. To prevent 12-volt battery discharge ■...
Page 226: Rear Window Wiper And Washer
2-3. Operating the lights and windshield wipers Rear window wiper and washer Turning the end of the lever turns on the rear window wiper and washer as follows: Type A Intermittent window wiper operation Normal window wiper operation Washer/wiper dual operation Washer/wiper dual...
Page 227 2-3. Operating the lights and windshield wipers Type B Intermittent window wiper operation Normal window wiper operation Washer/wiper dual operation Washer/wiper dual operation The rear window wiper and washer can be operated when ■ The “POWER” switch is in ON mode. If no washer fluid sprays ■...
Page 228: Headlight Cleaner Switch
2-3. Operating the lights and windshield wipers  Headlight cleaner switch Washer fluid can be sprayed on the headlights. Press the switch to clean the headlights. The headlight cleaners can be operated when ■ The “POWER” switch is in ON mode and the headlight switch is turned on. Windshield washer linked operation ■...
Page 229: Using Other Driving Systems Cruise Control
2-4. Using other driving systems  Cruise control Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicators Cruise control switch Setting the vehicle speed ■ Press the “ON-OFF” button to STEP activate the cruise control. Cruise control indicator will come on.
Page 230 2-4. Using other driving systems Adjusting the set speed ■ To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 231 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. PRIUS v_OM_OM47840U_(U)
Page 232 2-4. Using other driving systems CAUTION To avoid operating the cruise control by mistake ■ Switch the cruise control off using the “ON-OFF” button when not in use. Situations unsuitable for cruise control ■ Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 233: Dynamic Radar Cruise Control
2-4. Using other driving systems  Dynamic radar cruise control Dynamic radar cruise control supplements conventional cruise con- trol with a vehicle-to-vehicle distance control. In vehicle-to-vehicle distance control mode, the vehicle automatically accelerates or decelerates in order to maintain a set following distance from vehi- cles ahead.
Page 234 2-4. Using other driving systems Setting the vehicle speed (vehicle-to-vehicle distance con- ■ trol mode) Press the “ON-OFF” button to STEP activate the cruise control. Radar cruise control indicator will come on. Press the button again to deactivate the cruise control. Accelerate or decelerate the STEP vehicle to the desired speed,...
Page 235 2-4. Using other driving systems Adjusting the set speed ■ To change the set speed, operate the lever until the desired set speed is displayed. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 236 2-4. Using other driving systems Changing the vehicle-to-vehicle distance ■ Pressing the button changes Preceding vehicle mark vehicle-to-vehicle dis- tance as follows: Long Medium Short The vehicle-to-vehicle distance is set automatically to long mode when the “POWER” switch is turned to ON mode. If a vehicle is running ahead of you, the preceding vehicle mark will also be displayed.
Page 237 2-4. Using other driving systems Canceling and resuming the speed control ■ Pulling the lever toward you cancels the cruise control. The speed setting is also can- celed when the brakes are applied. Pushing lever resumes the cruise control and returns vehicle speed to the set speed.
Page 238 2-4. Using other driving systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 400 ft. (120 m) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suit- able following distance from the vehicle ahead.
Page 239 2-4. Using other driving systems Example of constant speed cruising When there are no vehicles ahead The vehicle travels at the speed set by the driver. The desired vehicle-to- vehicle distance can also be set by operating the vehicle-to-vehicle dis- tance control.
Page 240 2-4. Using other driving systems Approach warning When your vehicle is too close to a vehicle ahead, and sufficient automatic deceleration via the cruise control is not possible, the dis- play will flash and the buzzer will sound to alert the driver. An exam- ple of this would be if another driver cuts in front of you while you are following a vehicle.
Page 241 2-4. Using other driving systems Press the “ON-OFF” button to activate the cruise control. Press the button again to deacti- vate the cruise control. Switch to constant speed con- trol mode. (Push the lever forward and hold for approximately 1 sec- ond.) Cruise control indicator will come When in constant speed control...
Page 242 The windshield wipers are operating at high speed (when the wiper switch is set to the high speed windshield wiper operation position). If vehicle-to-vehicle distance control driving is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Toyota dealer. PRIUS v_OM_OM47840U_(U)
Page 243 2-4. Using other driving systems Automatic cancelation of constant speed control ■ The cruise control will stop maintaining the vehicle speed in the following sit- uations: ● Actual vehicle speed is more than approximately 10 mph (16 km/h) below the set vehicle speed. At this time, the memorized set speed is not retained.
Page 244 (yellow) system. Fix each problem in accordance with the correction procedure, and check that the system is operating normally. If the warning code persists even after fixing, have the vehicle inspected by your Toyota dealer. PRIUS v_OM_OM47840U_(U)
Page 245 2-4. Using other driving systems Certification ■ For vehicles sold in the U.S.A. FCC ID: HYQDNMWR005 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 246 2-4. Using other driving systems CAUTION Before using dynamic radar cruise control ■ Do not overly rely on vehicle-to-vehicle distance control. Be aware of the set speed. If automatic deceleration/acceleration is not appropriate, adjust the vehicle speed, as well as the distance between your vehicle and vehicles ahead by applying the brakes etc.
Page 247 2-4. Using other driving systems CAUTION To avoid inadvertent cruise control activation ■ Switch the cruise control off using the “ON-OFF” button when not in use. Situations unsuitable for dynamic radar cruise control ■ Do not use dynamic radar cruise control in any of the following situations. Doing so may result in inappropriate speed control and could cause an acci- dent resulting in death or serious injury.
Page 248 2-4. Using other driving systems CAUTION When the sensor may not be correctly detecting the vehicle ahead ■ Apply the brakes as necessary when any of the following types of vehicles are in front of you. As the sensor may not be able to correctly detect these types of vehicles, the approach warning (P.
Page 249 2-4. Using other driving systems CAUTION Handling the radar sensor ■ Observe the following to ensure the cruise control system can function effec- tively. Otherwise, the system may not function correctly and could result in an acci- dent. ● Keep the sensor and grille cover clean at all times. Clean the sensor and grille cover with a soft cloth so you do not mark or damage them.
Page 250: Driving Assist Systems
2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ABS (Anti-lock Brake System) ■...
Page 251 2-4. Using other driving systems When the TRAC/VSC systems are operating The slip indicator light will flash while the TRAC/VSC systems are operating. Sounds and vibrations caused by the ABS, brake assist, VSC and ■ TRAC ● A sound may be heard from the engine compartment when the hybrid system is started, just after the vehicle begins to move, if the brake pedal is depressed forcefully or repeatedly, or 1-2 minutes after the hybrid sys- tem is stopped.
Page 252 2-4. Using other driving systems Reduced effectiveness of the EPS system ■ The effectiveness of the EPS system is reduced to prevent the system from overheating when there is frequent steering input over an extended period of time. The steering wheel may feel heavy as a result. Should this occur, refrain from excessive steering input or stop the vehicle and turn the hybrid system off.
Page 253 The ABS and VSC systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. Handling of tires and the suspension ■...
Page 254: Hill-Start Assist Control
2-4. Using other driving systems Hill-start assist control Hill-start assist control helps to prevent the vehicle from rolling backwards when starting on an incline or slippery slope. To engage hill-start assist con- trol, further depress the brake pedal when the vehicle is stopped completely.
Page 255 • The brake pedal is depressed again. • The brake pedal has been depressed for more than approximately 3 minutes. If the slip indicator light comes on ■ It may indicate a malfunction in the system. Contact your Toyota dealer. CAUTION Hill-start assist control ■ ●...
Page 256: Pcs (Pre-Collision System)
2-4. Using other driving systems  PCS (Pre-Collision System) When the radar sensor detects possibility of a frontal collision, the pre-collision systems such as the brakes and seat belts are automat- ically engaged to lessen impact to occupants as well as vehicle dam- age.
Page 257 2-4. Using other driving systems Disabling pre-collision braking Pre-collision braking enabled Pre-collision braking disabled The “PCS” warning light will turn on when pre-collision braking is disabled. Radar sensor The radar sensor detects vehi- cles or other obstacles on or near the road ahead and deter- mines whether a collision is imminent based on the position, speed, and heading of the obsta-...
Page 258 2-4. Using other driving systems The pre-collision system is operational when ■ ● Pre-collision seat belts (operating conditions A): • Vehicle speed is greater than about 19 mph (30 km/h). • The system detects sudden braking or skidding. • The front occupants are wearing a seat belt. ●...
Page 259 2-4. Using other driving systems Conditions that may trigger the system even if there is no possibility of ■ a collision ● When there is an object by the roadside at the entrance to a curve ● When passing an oncoming vehicle on a curve ●...
Page 260 2-4. Using other driving systems Situations in which the pre-collision system does not function properly ■ The system may not function effectively in situations such as the following: ● On roads with sharp bends or uneven surfaces ● If a vehicle suddenly moves in front of your vehicle, such as at an inter- section ●...
Page 261 2-4. Using other driving systems Certification ■ For vehicles sold in the U.S.A. FCC ID: HYQDNMWR005 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 262 2-4. Using other driving systems CAUTION Limitations of the pre-collision system ■ Do not overly rely on the pre-collision system. Always drive safely, taking care to observe your surroundings and checking for any obstacles or other road hazards. Failure to do so may cause an accident resulting in death or serious injury. Cautions regarding the assist contents of the system ■...
Page 263 2-4. Using other driving systems CAUTION When the sensor may not be correctly detecting the vehicle ahead ■ Apply the brakes as necessary in any of the following situations. ● When water or snow thrown up by the surrounding vehicles hinders the functioning of the sensor ●...
Page 264: 2-5. Driving Information
2-5. Driving information Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load: ● Stow cargo and luggage in the luggage compartment whenever possible. ● Be sure all items are secured in place. ●...
Page 265 Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. (P. 270) Toyota does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing. PRIUS v_OM_OM47840U_(U)
Page 266 2-5. Driving information Calculation formula for your vehicle Cargo capacity Total load capacity (vehicle capacity weight) (P. 496) When 2 people with the combined weight of A lb. (kg) are riding in your vehicle, which has a total load capacity (vehicle capacity weight) of B lb.
Page 267 2-5. Driving information CAUTION Things that must not be carried in the luggage compartment ■ The following things may cause a fire if loaded in the luggage compart- ment: ● Receptacles containing gasoline ● Aerosol cans Storage precautions ■ Observe the following precautions. Failure to do so may result in death or serious injury.
Page 268 2-5. Driving information CAUTION ● Secure all items in the occupant compartment, as they may shift and injure someone during sudden braking, sudden swerving or an acci- dent. ● When you fold down the rear seats, long items should not be place directly behind the front seats.
Page 269 2-5. Driving information NOTICE If luggage is loaded on the roof (vehicles with a panoramic roof) ■ Observe the following precautions. Failure to observe them could lead to the roof rack being damaged or deformed, or the roof rack falling off. ●...
Page 270: Vehicle Load Limits
Seating capacity means the maximum number of occupants whose estimated average weight is 150 lb. (68 kg) per person. Towing capacity ■ Toyota does not recommend towing a trailer with your vehicle. Cargo capacity ■ Cargo capacity may increase or decrease depending on the weight and the number of occupants.
Page 271: Winter Driving Tips
2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. Pre-winter preparations ■ ● Use fluids that are appropriate to the prevailing outside tem- peratures.
Page 272 2-5. Driving information When driving the vehicle ■ Accelerate the vehicle slowly and drive at a reduced speed suit- able to the road conditions. When parking the vehicle ■ Park the vehicle and shift the shift position to P and block the wheel under the vehicle without setting the parking brake.
Page 273 2-5. Driving information Tire chain installation ■ Observe the following precautions when installing and removing chains: ● Install and remove tire chains in a safe location. ● Install tire chains on the front tires only. Do not install tire chains on the rear tires.
Page 274 NOTICE Repairing or replacing snow tires ■ Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 275: Trailer Towing
Trailer towing Toyota does not recommend towing a trailer with your vehicle. Toyota also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicycle, etc. Your vehicle is not designed for trailer towing or for the use of tow hitch mounted carriers.
Page 276: Dinghy Towing
2-5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE To avoid serious damage to your vehicle ■ Do not tow your vehicle with the four wheels on the ground. PRIUS v_OM_OM47840U_(U)
Page 277: Interior Features
Interior features 3-1. Using the air conditioning 3-2. Using the audio system system and defogger Audio system types..294 Automatic air 3-3. Using the interior lights conditioning system ..278 Using the steering wheel Interior lights list ....299 climate remote control •...
Page 278: Using The Air Conditioning System And Defogger Automatic Air Conditioning System
3-1. Using the air conditioning system and defogger Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Temperature setting display Fan speed display Air outlet display Micro dust and pollen filter button Outside temperature display...
Page 279 3-1. Using the air conditioning system and defogger Switching functions and changing settings STEP Slide left and right to select the function. The function currently being set up will be surrounded by a frame. The arrows displayed at the sides of the frame indicate the direc- tions in which the frame can be moved.
Page 280 3-1. Using the air conditioning system and defogger Using automatic air conditioning system STEP Press The air conditioning system begins to operate. Air outlets and fan speed are automatically adjusted according to the temper- ature setting. : When is pressed, the current temperature setting display ) will be automatically selected.
Page 281 3-1. Using the air conditioning system and defogger Adjusting the settings manually Basic setting ■ Adjusting the fan speed STEP Slide to the right to select the fan speed display STEP Turn to the clockwise to increase the fan speed, or counterclockwise to decrease.
Page 282 3-1. Using the air conditioning system and defogger Adjusting the temperature setting STEP Slide to the left or right to select the temperature set- ting display ( STEP Turn to the clockwise to raise the temperature, or counterclockwise to lower. Changing the air outlets STEP Slide...
Page 283 3-1. Using the air conditioning system and defogger Air flows to the upper body and feet. Air flows to the feet. Air flows to the feet and the windshield defogger operates. PRIUS v_OM_OM47840U_(U)
Page 284 3-1. Using the air conditioning system and defogger Switching between outside air and recirculated air modes ■ Press The mode switches between recirculated air mode and outside air mode each time the button is pressed. The indicator on turn on when the recirculated air mode is selected.
Page 285 3-1. Using the air conditioning system and defogger Micro dust and pollen filter button Operates micro dust and pollen filter on/off. Outside air mode switches to recirculated air mode. Pollen is removed from the air and the air flows to the upper part of the body.
Page 286 3-1. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets Adjusting the position of the air outlets ■ Center outlets Direct air flow to the left or right, up or down. Front side outlets Direct air flow to the left or right, up or down.
Page 287 3-1. Using the air conditioning system and defogger Opening and closing the air outlets ■ Center outlets Open the vent. Close the vent. Move the knob in the direction of the printed arrow until a click is heard. Front side outlets Open the vent.
Page 288 3-1. Using the air conditioning system and defogger Using automatic mode ■ Fan speed is adjusted automatically according to the temperature setting and ambient conditions. As a result, the following may occur: ● Immediately after is pressed, the fan may stop for a while until warm or cool air is ready to flow.
Page 289 3-1. Using the air conditioning system and defogger Window defogger feature ■ Recirculated air mode may automatically switch to outside air mode in situa- tions where the windows need to be defogged. Micro dust and pollen filter ■ ● In order to prevent the windshield from fogging up when the outside air is cold, the following may occur: •...
Page 290 3-1. Using the air conditioning system and defogger When outside air temperature is below 32 F (0 C) ■ The cooling and dehumidification function may not operate even when is pressed. Air conditioning odors ■ ● During use, various odors from inside and outside the vehicle may enter into and accumulate in the air conditioning system.
Page 291: Using The Steering Wheel Climate Remote Control Switches
3-1. Using the air conditioning system and defogger Using the steering wheel climate remote control switches Some air conditioning features can be controlled using the switches on the steering wheel. Temperature control Outside air or recirculated air mode Adjusting the temperature setting Press “”...
Page 292 3-1. Using the air conditioning system and defogger When changing the temperature setting using the steering switches ■ The temperature will change, however the position of the selection frame on the air conditioning display will remain the same. CAUTION To reduce the risk of an accident ■...
Page 293: Rear Window And Outside Rear View Mirror Defogger Switch
3-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defogger switch Defoggers are used to defog the rear window, and to remove rain- drops, dew and frost from the outside rear view mirrors. Turns the rear window and outside rear view mirror defog- gers on/off The defoggers will automati-...
Page 294: 3-2. Using The Audio System
3-2. Using the audio system Audio system types Vehicles with Display Audio system Type A Type B Refer to the “DISPLAY AUDIO SYSTEM OWNER’S MANUAL”. PRIUS v_OM_OM47840U_(U)
Page 295 3-2. Using the audio system Vehicles with a navigation system Canada Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”. Steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. For details, refer to the “DISPLAY AUDIO SYSTEM OWNER’S MANUAL”...
Page 296 3-2. Using the audio system ® About Bluetooth (vehicles with Display Audio system) ■ Bluetooth is a registered trade mark of Bluetooth SIG, Inc. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Panasonic Corpo- ration is under license.
Page 297 3-2. Using the audio system CAUTION Properly shielded a grounded cables and connectors must be used for con- nection to host computer and / or peripherals in order to meet FCC emission limits. This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
Page 298 3-2. Using the audio system CAUTION Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that neces- sary for successful communication.
Page 299: 3-3. Using The Interior Lights
3-3. Using the interior lights Interior lights list Rear interior light (P. 300) Front interior/personal lights (P. 300, 301) “POWER” switch lighting Shift lever lighting Foot lights (if equipped) Front door courtesy lights PRIUS v_OM_OM47840U_(U)
Page 300: Interior Lights
3-3. Using the interior lights Interior lights Interior lights Front (vehicles without panoramic roof) Turns the lights off Turns the door position on Turns the lights on Front (vehicles with panoramic roof) Turns the lights off Turns the door position on Turns the lights on Rear The light will turn on/off in con-...
Page 301: Personal Lights
3-3. Using the interior lights Personal lights Personal lights Vehicles without panoramic roof Turns the light on/off Vehicles with panoramic roof Turns the light on/off PRIUS v_OM_OM47840U_(U)
Page 302 3-3. Using the interior lights Personal lights Illuminated entry system ■ The lights automatically turn on/off according to “POWER” switch mode, the presence of the electronic key, whether the doors are locked/unlocked, and whether the doors are opened/closed. To prevent 12-volt battery discharge ■...
Page 303: 3-4. Using The Storage Features
3-4. Using the storage features List of storage features Card holder Auxiliary boxes Cup holders Glove boxes Door pockets Bottle holders Console box PRIUS v_OM_OM47840U_(U)
Page 304 3-4. Using the storage features CAUTION Items that should not be left in the storage spaces ■ Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: ●...
Page 305: Glove Boxes
3-4. Using the storage features Glove boxes Glove boxes Upper glove box Pull up the lever. Lower glove box Pull up the lever. Glove box light (lower glove box only) ■ The glove box light turns on when the tail lights are on. CAUTION Caution while driving ■...
Page 306: Console Box
3-4. Using the storage features Console box Console box Push the button to open the lid. The lid can be opened by pushing either the front or rear button. Tray in the console box ■ The tray slides forward/backward and can be removed.
Page 307: Cup Holders
3-4. Using the storage features Cup holders Cup holders Front passenger’s side Push the lid. Center console (front) Type A Type B Pull out the lid. Center console (rear) Open the lid and adjust the holder. When closing, stow the holder before closing the lid.
Page 308 3-4. Using the storage features Cup holders The type B cup holder on the center console (front side) ■ The cup holder can be used store small objects if the inner tray is removed. CAUTION Items unsuitable for the cup holder ■...
Page 309: Bottle Holders
3-4. Using the storage features Bottle holders Bottle holders Front doors Rear doors When using the bottle holder ■ ● When storing a bottle, close the cap. ● The bottle may not be stored depending on its size or shape. NOTICE Items that should not be stowed in the bottle holders ■...
Page 310: Auxiliary Boxes
3-4. Using the storage features Auxiliary boxes Auxiliary boxes Type A (if equipped) Press in the lid. This box is useful for temporarily storing sunglasses and similar small items. Type B CAUTION Caution while driving (type A) ■ Keep the auxiliary box closed when not in use. In the event of sudden brak- ing or sudden swerving, an accident may occur due to an occupant being struck by an open auxiliary box or the items stored inside.
Page 311: Door Pockets
3-4. Using the storage features Door pockets and card holder Door pockets Front Rear Card holder PRIUS v_OM_OM47840U_(U)
Page 312: 3-5. Other Interior Features
3-5. Other interior features Sun visors To set the visor in the for- ward position, flip it down. To set the visor in the side position, flip down, unhook, and swing it to the side. PRIUS v_OM_OM47840U_(U)
Page 313: Vanity Mirrors
3-5. Other interior features Vanity mirrors Slide the cover to open. The light turns on when the cover is opened. NOTICE To prevent 12-volt battery discharge ■ Do not leave the vanity lights on for extended periods while the hybrid sys- tem is off.
Page 314: Clock
3-5. Other interior features Clock Adjusts the hours Adjusts the minutes Rounds nearest hour : e.g. 1:00 to 1:29 1:00 1:30 to 1:59 2:00 The clock is displayed when ■ The “POWER” switch is in ON mode. After turning the “POWER” switch off ■...
Page 315: Power Outlets
3-5. Other interior features Power outlets The power outlets can be used for 12 V accessories that run on less than 10 A. Front Open the cover. Rear (if equipped) Open the cover. The power outlets can be used when ■...
Page 316 3-5. Other interior features NOTICE To avoid damaging the power outlets ■ Close the power outlet lid when the power outlet is not in use. Foreign objects or liquids that enter the power outlet may cause a short cir- cuit. To prevent blown fuse ■...
Page 317: Seat Heaters
3-5. Other interior features  Seat heaters Heats the left front seat Heats the right front seat The indicator light comes on. The seat heaters can be used when ■ The “POWER” switch is in ON mode. When not in use ■...
Page 318 3-5. Other interior features CAUTION Burns ■ ● Use caution when seating the following persons in a seat with the seat heater on to avoid the possibility of burns: • Babies, small children, the elderly, the sick and the physically chal- lenged •...
Page 319: Armrest
3-5. Other interior features  Armrest Pull the armrest down for use. NOTICE To prevent damage to the armrest ■ Do not place too much strain on the armrest.  : If equipped PRIUS v_OM_OM47840U_(U)
Page 320: Panoramic Roof Shades
3-5. Other interior features  Panoramic roof shades Use the overhead switches to open or close the panoramic roof shades. Open Close : To stop partway, press the switch lightly. The panoramic roof shades can be operated when ■ The “POWER” switch is in ON mode. ...
Page 321 If the panoramic roof shades continue to close but then re-open slightly even after performing the above procedure correctly, have the vehicle inspected by your Toyota dealer. Customization ■ The door lock linked automatic close function can be disabled.
Page 322 3-5. Other interior features CAUTION When closing the panoramic roof shades ■ Observe the following precautions. Failing to do so may result in death or serious injury. ● Check to make sure that all passengers do not have any part of their bodies in a position where they could be caught when the panoramic roof shades are being operated.
Page 323 3-5. Other interior features NOTICE Panoramic roof ■ The panoramic roof is made of resin. Follow these precautions to prevent damage to the roof. ● When cleaning the roof, use a mild soap and a soft cloth or sponge to remove dirt, then wash clean with plenty of water.
Page 324: Assist Grips
3-5. Other interior features Assist grips An assist grip installed on the ceiling can be used to support your body while sitting on the seat. CAUTION Assist grip ■ Do not use the assist grip when getting in or out of the vehicle or rising from your seat.
Page 325: Floor Mats
3-5. Other interior features Floor mats Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks STEP (clips) into the floor mat eye- lets.
Page 326 When installing the driver’s floor mat ■ ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
Page 327: Luggage Compartment Features
3-5. Other interior features Luggage compartment features Cargo hooks ■ Raise the hook to use. The cargo hooks are provided for securing loose items. Deck board ■ Pull the lever upward to lift the deck board. When using the auxiliary box on the front of the vehi- cle, fold and pick up the deck board and move it...
Page 328 3-5. Other interior features Auxiliary boxes ■ Center Lift the center deck board. Side Lift the center deck board and then lift the side deck boards. Lift the side deck board from the front side of the vehicle to prevent hitting the cargo hook. Behind the rear seats Umbrellas (less than 30 in.
Page 329 3-5. Other interior features Luggage cover (if equipped) ■ Pull out the luggage cover and secure it to the hook brackets. Attach the hooks to the head restraints. Installing the luggage cover Set the holder of one side into the installation position, then install both holders from below with the cover in its contracted state.
Page 330 3-5. Other interior features Stowing the luggage cover Lift the center deck board and STEP remove the side deck boards. Fold inwards together with the STEP head restraint installation hooks and secure. Then, stow in the auxiliary boxes. CAUTION When the cargo hooks are not in use ■...
Page 331: Garage Door Opener
3-5. Other interior features  Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, secu- rity systems, and other devices. ® The garage door opener (HomeLink Universal Transceiver) is manufac- ®...
Page 332 3-5. Other interior features ® Programming HomeLink ■ Point the remote control trans- STEP mitter for the device 1 to 3 in. (25 ® to 75 mm) from the HomeLink buttons. ® Keep the HomeLink indicator light in view while programming. Press and hold one of the STEP ®...
Page 333 3-5. Other interior features ® Test the HomeLink operation by STEP pressing the newly programmed button. ® If a HomeLink button has been programmed for a garage door, check to see if the garage door opens and closes. If the garage door does not operate, see if your garage transmitter is of the rolling code type.
Page 334 3-5. Other interior features Programming a rolling code system (for U.S.A. owners) ■ If your device is rolling code equipped, follow the steps under the ® heading “Programming HomeLink ” before proceeding with the steps listed below. STEP Locate the training button on the ceiling mounted garage door opener motor.
Page 335 HomeLink buttons. Programming other devices ■ To program other devices such as home security systems, home door locks and lighting, contact your Toyota dealer for assistance. Reprogramming a button ■ ® The individual HomeLink buttons cannot be erased but can be reprogrammed.
Page 336 3-5. Other interior features ® Operating HomeLink ® ® Press the appropriate HomeLink button. The HomeLink indicator light should come on. ® The HomeLink compatible transceiver in your vehicle continues to send a signal for up to 20 seconds as long as the button is pressed. ®...
Page 337 3-5. Other interior features Before programming ■ ● Install a new battery in the remote control transmitter. ● The battery side of the remote control transmitter must be pointed away ® from the HomeLink button. Certification for the garage door opener ■...
Page 338 3-5. Other interior features CAUTION When programming a garage door or other remote control device ■ The garage door or other device may operate, so ensure people and objects are out of danger to prevent potential harm. Conforming to federal safety standards ■...
Page 339: Safety Connect
Telematics Subscription Service Agreement and its Terms and Conditions, as in effect and amended from time to time, a current copy of which is available at Toyota.com. All use of the Safety Con- nect service is subject to such then-applicable Terms and Condi- tions.
Page 340 After you have signed the Telematics Subscription Service Agreement and are enrolled, you can begin receiving services. A variety of subscription terms is available for purchase. Contact your Toyota dealer, call 1-800-25-TOYOTA (1-800-255-3987) or push the “SOS” button in your vehicle for further subscription details.
Page 341 Safety Connect. ● Safety Connect is available beginning Fall 2009 on select Toyota models. Contact with the Safety Connect response center is dependent upon the telematics device being in operative condition, cellular connection avail- ability, and GPS satellite signal reception, which can limit the ability to reach the response center or receive emergency service support.
Page 342 ● Green indicator light flashing = Safety Connect call in process ● Red indicator light (except at vehicle start-up) = System malfunc- tion (contact your Toyota dealer) ● No indicator light (off) = Safety Connect service not active Safety Connect services Automatic Collision Notification ■...
Page 343 After fil- ing a police report, call the Safety Connect response center at 1- 800-25-TOYOTA (1-800-255-3987) and follow the prompts for Safety Connect to initiate this service. In addition to assisting law enforcement with recovery of a stolen...
Page 344 3-5. Other interior features Safety information for Safety Connect Important! Read this information before using Safety Connect. Exposure to radio frequency signals ■ The Safety Connect system installed in your vehicle is a low-power radio transmitter and receiver. It receives and also sends out radio frequency (RF) signals.
Page 345 3-5. Other interior features Certification for Safety Connect ■ FCC ID: O9EGTM1 FCC ID: O6Y-CDMRF101 FCC ID: N7NGTM2 NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 346 3-5. Other interior features PRIUS v_OM_OM47840U_(U)
Page 347 Maintenance and care 4-1. Maintenance and care Cleaning and protecting the vehicle exterior..348 Cleaning and protecting the vehicle interior..352 4-2. Maintenance Maintenance requirements ....355 General maintenance..358 Emission inspection and maintenance (I/M) programs......362 4-3. Do-it-yourself maintenance Do-it-yourself service precautions ....
Page 348: Cleaning And Protecting The Vehicle Exterior
4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 349 4-1. Maintenance and care Note for a smart key system ■ If the door handle becomes wet while the electronic key is within the effec- tive range, the door may lock and unlock repeatedly. Place the key in a posi- tion 6 ft.
Page 350 4-1. Maintenance and care NOTICE To prevent paint deterioration and corrosion on the body and compo- ■ nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 351 4-1. Maintenance and care NOTICE To prevent damage to the panoramic roof (if equipped) ■ Observe the following precautions. Otherwise, the surface of the panoramic roof may be damaged, or the deterioration of the coating may be acceler- ated. ● Before washing the vehicle, remove any dust, sand or other foreign matter using water.
Page 352: Cleaning And Protecting The Vehicle Interior
4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior ■ Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
Page 353 4-1. Maintenance and care Caring for leather areas ■ Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. Shampooing the carpets ■ There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 354 4-1. Maintenance and care NOTICE Cleaning detergents ■ ● Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
Page 355: Maintenance Maintenance Requirements
Toyota recommends the following maintenance: General maintenance ■ General maintenance should be performed on a daily basis. This can be done by yourself or by a Toyota dealer. Scheduled maintenance ■ Scheduled maintenance should be performed at specified inter- vals according to the maintenance schedule.
Page 356 It is recommended that genuine Toyota parts be used for repairs to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 357 4-2. Maintenance CAUTION If your vehicle is not properly maintained ■ Improper maintenance could result in serious damage to the vehicle and possible serious injury or death. Handling of the 12-volt battery ■ ● Engine exhaust, some of its constituents, and a wide variety of automobile components contain or emit chemicals known to the State of California to cause cancer and birth defects and other reproductive harm.
Page 358: General Maintenance
Booklet” “Owner’s Manual Supplement/Scheduled Maintenance Guide”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items Check points Is the brake fluid at the correct...
Page 359: Luggage Compartment
4-2. Maintenance Luggage compartment Items Check points 12-volt battery Check the connections. (P. 384) Vehicle interior Items Check points • The accelerator pedal should Accelerator pedal move smoothly (without uneven pedal effort or catching). • When parked on a slope and the Hybrid transmission “Park”...
Page 360 4-2. Maintenance Items Check points • Do the head restraints move Head restraints smoothly and lock securely? • Do the indicators and buzzers Indicators/buzzers function properly? Lights • Do all the lights come on? • Does the parking brake pedal move smoothly? Parking brake •...
Page 361: Vehicle Exterior
4-2. Maintenance Vehicle exterior Items Check points Doors • Do the doors operate smoothly? • Does the engine hood lock sys- Engine hood tem work properly? • There should not be any signs of Fluid leaks fluid leakage after the vehicle has been parked.
Page 362: Emission Inspection And Maintenance (I/M) Programs
The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test in the following situa- ■...
Page 363: Do-It-Yourself Maintenance Do-It-Yourself Service Precautions
Brake fluid level (P. 380) • Rag or paper towel • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology For the U.S.A.:...
Page 364 4-3. Do-it-yourself maintenance Items Parts and tools • “Toyota Genuine Motor Oil” or equivalent Engine oil level (P. 373) • Rag or paper towel • Funnel (used only for adding engine oil) • Fuse with same amperage rating Fuses (P. 409) as original •...
Page 365 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. When working on the engine compartment ■ ● Make sure that the indicator on the “POWER”...
Page 366: Hood
4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release STEP lever. The hood will pop up slightly. Pull up the auxiliary catch STEP lever and lift the hood. PRIUS v_OM_OM47840U_(U)
Page 367 4-3. Do-it-yourself maintenance Hold the hood open by insert- STEP ing the supporting rod into either of the slots. Use the upper slots to open the hood normally, or use the lower slots when the hood needs to be opened wide. CAUTION Pre-driving check ■...
Page 368 4-3. Do-it-yourself maintenance NOTICE When closing the hood ■ Be sure to return the support rod to its clip before closing the hood. Closing the hood without returning the support rod properly could cause the hood to bend. PRIUS v_OM_OM47840U_(U)
Page 369: Positioning A Floor Jack
4-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement (such as under rear suspension etc.) may damage your vehicle or cause injury. Front ■ Rear ■ PRIUS v_OM_OM47840U_(U)
Page 370 4-3. Do-it-yourself maintenance CAUTION When raising your vehicle ■ Make sure to observe the following precautions to reduce the possibility of death or serious injury: ● Lift up the vehicle using a floor jack such as the one shown in the illustra- tion.
Page 371 4-3. Do-it-yourself maintenance CAUTION ● Do not raise the vehicle while someone is in the vehicle. ● When raising the vehicle, do not place any object on top of or underneath the floor jack. ● When raising the vehicle, do not set the Rear suspension floor jack under the rear suspension.
Page 372: Engine Compartment
4-3. Do-it-yourself maintenance Engine compartment Engine coolant reservoir Brake fluid reservoir (P. 377) (P. 380) Engine oil level dipstick Fuse box (P. 409) (P. 373) Radiator (P. 379) Engine oil filler cap Condenser (P. 379) (P. 374) Electric cooling fans Power control unit coolant Washer fluid tank (P.
Page 373 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil ■ STEP Park the vehicle on level ground. After warming up the engine and turning off the hybrid system, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 374 4-3. Do-it-yourself maintenance Flat dipstick Normal Excessive The shape of the dipstick may dif- fer depending on the type of vehi- cle or engine. Non-flat dipstick Normal Excessive The shape of the dipstick may dif- fer depending on the type of vehi- cle or engine.
Page 375 4-3. Do-it-yourself maintenance Make sure to check the oil type and prepare the items needed before adding oil. P. 500 Engine oil selection Oil quantity 1.6 qt. (1.5 L, 1.3 Imp.qt.) (Low  Full) Items Clean funnel STEP Remove the oil filler cap by turning it counterclockwise. STEP Add engine oil slowly, checking the dipstick.
Page 376 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
Page 377 4-3. Do-it-yourself maintenance Coolant The coolant level is satisfactory if it is between the full (“FULL” or “F”) and low (“LOW” or “L”) lines on the reservoir when the hybrid system is cold. Engine coolant reservoir Reservoir cap “FULL” line “LOW”...
Page 378 ■ Visually check the radiator, hoses, engine/power control unit coolant reser- voir caps, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. CAUTION When the hybrid system is hot ■...
Page 379 Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. CAUTION When the hybrid system is hot ■...
Page 380 4-3. Do-it-yourself maintenance Brake fluid Checking fluid level ■ The brake fluid level should be between the “MAX” and “MIN” lines on the tank. Adding fluid ■ Push the tab in and lift the cover off. Make sure to check the fluid type and prepare the necessary item. Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items...
Page 381 4-3. Do-it-yourself maintenance Brake fluid can absorb moisture from the air ■ Excess moisture in the brake fluid can cause a dangerous loss of braking efficiency. Use only newly opened brake fluid. CAUTION When filling the reservoir ■ Take care as brake fluid can harm your hands and eyes and damage painted surfaces.
Page 382 4-3. Do-it-yourself maintenance Washer fluid Open the lid. STEP Check the washer fluid level on STEP the level gauge. “NORMAL” “LOW” If the washer fluid level is at STEP “LOW”, add washer fluid. PRIUS v_OM_OM47840U_(U)
Page 383 4-3. Do-it-yourself maintenance CAUTION When adding washer fluid ■ Do not add washer fluid when the hybrid system is hot or operating as washer fluid contains alcohol and may catch fire if spilled on the engine etc. NOTICE Do not use any fluid other than washer fluid ■...
Page 384: 12-Volt Battery
4-3. Do-it-yourself maintenance 12-volt battery Location ■ The 12-volt battery is located in the right-hand side of lug- gage compartment. Removing the 12-volt battery cover ■ STEP Open the center deck board and remove the right side deck board. (P. 327) STEP Remove the center auxiliary box.
Page 385 4-3. Do-it-yourself maintenance Exterior ■ Make sure that the 12-volt battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals Hold-down clamp Before recharging ■ When recharging, the 12-volt battery produces hydrogen gas which is flam- mable and explosive.
Page 386 Restart the hybrid system, depress the brake pedal, and confirm that it is possible to shift into each shift position. If the system will not start even after multiple attempts at all methods above, contact your Toyota dealer. CAUTION Chemicals in the 12-volt battery ■...
Page 387 ■ Use a 12-volt battery designed for this vehicle. Failure to do so may cause gas (hydrogen) to enter the passenger compartment, causing a fire or explo- sion. For replacement of the 12-volt battery, contact your Toyota dealer. PRIUS v_OM_OM47840U_(U)
Page 388 4-3. Do-it-yourself maintenance CAUTION When disconnecting the 12-volt battery ■ Do not disconnect the negative (-) termi- nal on the body side as shown. The dis- connected negative (-) terminal may touch the positive (+) terminal, which may cause a short and result in death or seri- ous injury.
Page 389: Tires
Tire rotation ■ Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota recom- mends that tire rotation is Front carried out at the same inter- val as tire inspection. Do not fail to initialize the tire...
Page 390 ID codes must be registered in the tire pressure warn- ing computer and the tire pressure warning system must be initial- ized. Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (P. 392) PRIUS v_OM_OM47840U_(U)
Page 391 4-3. Do-it-yourself maintenance Initializing the tire pressure warning system The tire pressure warning system must be initialized in the fol- ■ lowing circumstances: ● When rotating front and rear tires which have different tire infla- tion pressures ● When changing the tire size When the tire pressure warning system is initialized, the current tire inflation pressure is set as the benchmark pressure.
Page 392 The tire pressure warning valve and transmitter is equipped with a unique ID code. When replacing a tire pressure warning valve and transmitter, it is necessary to register the ID code. Have the ID code registered by your Toyota dealer. PRIUS v_OM_OM47840U_(U)
Page 393 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage. If you are not sure, consult with your Toyota dealer. Replacing tires and wheels ■ If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly.
Page 394 4-3. Do-it-yourself maintenance Tire types ■ ● Summer tires Summer tires are high-speed performance tires best suited to highway driving under dry conditions. Since summer tires do not have the same traction performance as snow tires, summer tires are inadequate for driving on snow-covered or icy roads.
Page 395 Initialization can be completed in a few minutes. However, in the follow- ing cases, the settings have not been recorded and the system will not operate properly. If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. ●...
Page 396 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 397 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 398: Tire Inflation Pressure
4-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure ■ The recommended cold tire inflation pressure and tire size are displayed on the tire and loading information label. (P. 504) PRIUS v_OM_OM47840U_(U)
Page 399 4-3. Do-it-yourself maintenance Inspection and adjustment procedure ■ Tire valve Tire pressure gauge STEP Remove the tire valve cap. STEP Press the tip of the tire pressure gauge onto the tire valve. STEP Read the pressure using the gauge gradations. STEP If the tire inflation pressure is not at the recommended level, adjust the pressure.
Page 400 Reduced driving comfort and tire life ● Reduced safety ● Damage to the drive train If a tire needs frequent inflating, have it checked by your Toyota dealer. Instructions for checking tire inflation pressure ■ When checking tire inflation pressure, observe the following: ●...
Page 401 4-3. Do-it-yourself maintenance CAUTION Proper inflation is critical to save tire performance ■ Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury: ● Excessive wear ● Uneven wear ●...
Page 402: Wheels
● Bent wheels that have been straightened Aluminum wheel precautions ■ ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 403 4-3. Do-it-yourself maintenance When replacing wheels ■ The wheels of your vehicle are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advance warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, tire pressure warning valves and trans- mitters must be installed.
Page 404 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 405: Air Conditioning Filter
4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method ■ STEP Turn the “POWER” switch off. Open the glove box and STEP remove the filter exchange cover. Remove the filter cover. STEP Slide and pull out the filter.
Page 406 4-3. Do-it-yourself maintenance Replacement method ■ Replace it with a new one. The “UP” marks shown on the filter should be pointing up. Checking interval ■ Inspect and replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required.
Page 407: Electronic Key Battery
4-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: ■ ● Flathead screwdriver ● Lithium battery CR1632 Replacing the battery ■ Take out the mechanical key. STEP Remove the cover.
Page 408 4-3. Do-it-yourself maintenance Use a CR1632 lithium battery ■ ● Batteries can be purchased at your Toyota dealer, local electrical appli- ance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manufacturer. ●...
Page 409: Checking And Replacing Fuses
4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. STEP Turn the “POWER” switch off. STEP Open the fuse box cover. Engine compartment Push the tab in and lift the lid off.
Page 410 4-3. Do-it-yourself maintenance STEP Remove the fuse. Only type A fuse can be removed using the pullout tool. STEP Check if the fuse is blown. Type A Normal fuse Blown fuse Replace the blown fuse with a new fuse of an appropriate amperage rating.
Page 411 4-3. Do-it-yourself maintenance Type B Normal fuse Blown fuse Replace the blown fuse with a new fuse of an appropriate amperage rating. The amper- age rating can be found on the fuse box lid. Type C Normal fuse Blown fuse Replace the blown fuse with a new fuse of an appropriate amperage rating.
Page 412 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings Engine compartment ■ FUSE Ampere Circuit Air conditioning system Electric cooling fans Electric cooling fans S-HORN No circuit ENG W/P Cooling system ABS MAIN 7.5A Anti-lock brake system NO.2 H-LP CLN Headlight cleaner P position control system, trans- P-CON MTR mission...
Page 413 4-3. Do-it-yourself maintenance FUSE Ampere Circuit P position control system, trans- P CON MAIN 7.5A mission 7.5A Power management system ECU-B2 7.5A Smart key system MAYDAY MAYDAY ECU-B3 Air conditioning system TURN & HAZ Turn signal lights Multiport fuel injection system/ ETCS sequential multiport fuel injection system...
Page 414 4-3. Do-it-yourself maintenance FUSE Ampere Circuit MIR HTR Outside rear view mirror defoggers RAD NO.1 Audio system, navigation system Door courtesy lights, personal lights, interior lights, front foot DOME lights, vanity lights, inside rear view mirror, garage door opener, overhead console Smart key system, multiplex com- munication system, personal ECU-B...
Page 415 4-3. Do-it-yourself maintenance Left side instrument panel ■ 9 10 15 16 17 18 23 24 25 26 27 28 29 30 20 21 ITO43P133 FUSE Ampere Circuit Power outlets Multiplex communication system, outside rear view mirrors, driver ECU-ACC support system, audio system, navigation system PWR OUTLET Power outlets...
Page 416 4-3. Do-it-yourself maintenance FUSE Ampere Circuit Stop lights, high mounted stop- light, brake system, driver support STOP system, vehicle proximity notifica- tion system P FR DOOR Power windows D FR DOOR Power windows DOOR RR Power windows DOOR RL Power windows S/ROOF Panoramic roof shades Electric cooling fans, multiplex...
Page 417 4-3. Do-it-yourself maintenance FUSE Ampere Circuit Windshield wipers 7.5A Gauges and meters Brake system, driver support sys- tem, multiport fuel injection sys- tem/sequential multiport fuel injection system, SRS airbag sys- tem, occupant detection system (ECU and sensors), smart key system Air conditioning system, emer- gency flashers, seat heaters, transmission, P position switch,...
Page 418 The fuses are designed to blow, protecting the wiring harness from damage. When replacing light bulbs ■ Toyota recommends that you use genuine Toyota products designed for this vehicle. Because certain bulbs are connected to circuits designed to prevent overload, non-genuine parts or parts not designed for this vehicle may be unusable.
Page 419 4-3. Do-it-yourself maintenance NOTICE Before replacing fuses ■ Have the cause of electrical overload determined and repaired by your Toyota dealer as soon as possible. PRIUS v_OM_OM47840U_(U)
Page 420: Light Bulbs
You may replace the following bulbs by yourself. The difficulty level of replacement varies depending on the bulb. As there is a danger that components may be damaged, we recommend that replacement is carried out by your Toyota dealer. Preparing for light bulb replacement ■...
Page 421 4-3. Do-it-yourself maintenance Rear bulb locations ■ Rear turn signal light License plate lights Back-up light PRIUS v_OM_OM47840U_(U)
Page 422 4-3. Do-it-yourself maintenance Replacing light bulbs Headlight low beams (halogen headlights) ■ STEP Turn the bulb base counterclock- wise. Unplug connector while STEP pressing the lock release. Replace the light bulb, and install STEP the bulb base. Align the 3 tabs on the light bulb with the mounting, and insert.
Page 423 4-3. Do-it-yourself maintenance Turn and secure the bulb base. STEP Shake the bulb base gently to check that it is not loose, turn the headlights on once and visually confirm that no light is leaking through the mounting. Daytime running lights and headlight high beams ■...
Page 424 4-3. Do-it-yourself maintenance Unplug connector while STEP pressing the lock release. Replace the light bulb, and install STEP the bulb base. Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the bulb base. STEP Shake the bulb base gently to check that it is not loose, turn the...
Page 425 4-3. Do-it-yourself maintenance Parking lights ■ STEP Turn the bulb base counterclockwise. Vehicles with halogen headlights Vehicles with LED headlights Remove the light bulb. STEP STEP When installing, reverse the steps listed. PRIUS v_OM_OM47840U_(U)
Page 426 4-3. Do-it-yourself maintenance Front side marker lights ■ STEP Turn the bulb base counterclockwise. Vehicles with halogen headlights Vehicles with LED headlights Remove the light bulb. STEP STEP When installing, reverse the steps listed. PRIUS v_OM_OM47840U_(U)
Page 427 4-3. Do-it-yourself maintenance Fog lights (if equipped) ■ Remove the fender liner bolts STEP and pull down the fender liner. Unplug connector while STEP pressing the lock release. PRIUS v_OM_OM47840U_(U)
Page 428 4-3. Do-it-yourself maintenance Turn the bulb base counterclock- STEP wise. STEP When installing, reverse the steps listed. PRIUS v_OM_OM47840U_(U)
Page 429 4-3. Do-it-yourself maintenance Front turn signal lights ■ STEP Remove the fender liner bolts and pull down the fender liner. (P. 427) Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP ITO43P144 STEP When installing, reverse the steps listed. PRIUS v_OM_OM47840U_(U)
Page 430 4-3. Do-it-yourself maintenance Rear turn signal lights and back-up lights ■ Open the back door and remove STEP the cover. To prevent damage, cover the tip of the screwdriver with a rag. Turn the bulb base counterclock- STEP wise. Rear turn signal light Back-up light Remove the light bulb.
Page 431 4-3. Do-it-yourself maintenance License plate lights ■ Open the back door and remove STEP the cover. To prevent damage, cover the tip of the screwdriver with a rag. Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP ITO43P150 STEP When installing, reverse the steps listed.
Page 432 The headlight low beams (LED type), stop lights, tail lights, rear side marker lights and high mounted stoplight consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced.
Page 433 4-3. Do-it-yourself maintenance CAUTION Replacing light bulbs ■ ● Be sure to stop the hybrid system and turn off the lights. Do not attempt to replace the bulb immediately after turning off the lights. The bulbs become very hot and may cause burns. ●...
Page 434 4-3. Do-it-yourself maintenance PRIUS v_OM_OM47840U_(U)
Page 435: When Trouble Arises
When trouble arises 5-1. Essential information Emergency flashers ..436 If your vehicle needs to be towed ......437 If you think something is wrong ......443 5-2. Steps to take in an emergency If a warning light turns on or a warning buzzer sounds ......
Page 436: Essential Information Emergency Flashers
5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, press the switch once again. NOTICE To prevent 12-volt battery discharge ■...
Page 437: If Your Vehicle Needs To Be Towed
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
Page 438 5-1. Essential information Emergency towing If a tow truck is not available in an emergency, your vehicle may be temporarily towed using a cable or chain secured to the emergency towing eyelet(s). This should only be attempted on hard surfaced roads for short distances at under 18 mph (30 km/h).
Page 439 5-1. Essential information Installing towing eyelets Remove the eyelet cover using a STEP flathead screwdriver. To prevent damage, cover the tip of the screwdriver with a rag. Insert the towing eyelet into the STEP hole and tighten partially by hand. Tighten down the towing eyelet STEP securely using a wheel nut...
Page 440 5-1. Essential information Towing with a sling-type truck Do not tow with a sling-type truck to prevent body damage. Towing with a wheel-lift type truck From the front Release the parking brake. From the rear Use a towing dolly under the front wheels.
Page 441 5-1. Essential information Using a flat bed truck If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45. Do not overly tighten the tie downs or the vehicle may be damaged. Before emergency towing ■...
Page 442 5-1. Essential information CAUTION Caution while towing ■ ● Use extreme caution when towing the vehicle. Avoid sudden starts or erratic driving maneuvers which place excessive stress on the emergency towing eyelets and the cables or chains. Always be cautious of the surroundings and other vehicles while towing. ●...
Page 443: If You Think Something Is Wrong
5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ■ ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 444: Steps To Take In An Emergency If A Warning Light Turns On Or A Warning Buzzer Sounds
If a light comes on or flashes, but then goes off, this does not necessarily indicate a malfunction in the system. However, if this continues to occur, have the vehicle inspected by your Toyota dealer. Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous.
Page 445 Stop the vehicle immediately. The following warning indicates the possibility of damage to the vehi- cle that may lead to an accident. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Charging system warning light Indicates a malfunction in the vehicle’s charging system...
Page 446 5-2. Steps to take in an emergency Have the vehicle inspected by your Toyota dealer immediately. Failure to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately.
Page 447 5-2. Steps to take in an emergency Warning light Warning light/Details Pre-collision system warning light Indicates a malfunction in the pre-collision system The warning light will operate as follows, even when the system is not malfunctioning: • The light will flash quickly when the system is operating. (P.
Page 448 5-2. Steps to take in an emergency Warning light Warning light/Details Parking lock system warning message (warning buzzer) Indicates a malfunction in the P position control system when the vehicle is stopped • In this situation, there is a possibility that the parking (U.S.A) lock mechanism will not work.
Page 449 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light goes off. Warning light Warning light/Details Correction procedure P position request indicator light (warning buzzer) Because recharging The amount of charge remain- is not possible when...
Page 450 5-2. Steps to take in an emergency Warning light Warning light/Details Correction procedure • Check the grille and Pre-collision system warning the sensor and clean light them if they are dirty. Indicates that the PCS is not • In case of overheat- currently functional because ing, the system will (Turns on)
Page 451 • Flat tire (P. 462) inflation pressure is adjusted, have the system checked by your Toyota dealer. When the light comes on after blinking for 1 minute: Have the system Malfunction in the tire pres- checked by your sure warning system Toyota dealer.
Page 452 5-2. Steps to take in an emergency : Refer to the separate “Scheduled Maintenance Guide” or “Owner’s Manual Supplement” for the maintenance interval applicable to your vehicle. : Open door warning buzzer: The open door warning buzzer sounds to alert one or more of the doors is not fully closed (with the vehicle having reached a speed of 3 mph [5km/h]).
Page 453 The malfunction indicator lamp will go off after several driving trips. If the malfunction indicator lamp does not go off even after several trips, con- tact your Toyota dealer as soon as possible. When the tire pressure warning light comes on ■...
Page 454 If there is a lot of snow or ice on the vehicle, particularly around the wheels or wheel housings ● If non-genuine Toyota wheels are used (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ●...
Page 455 If both the ABS and the brake system warning lights remain on ■ Stop your vehicle in a safe place immediately and contact your Toyota dealer. The vehicle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
Page 456 Check the tires. If a tire is flat, change it with the spare tire and have the flat tire repaired by the nearest Toyota dealer. ● Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you could lose control of the steering wheel or the brakes.
Page 457 5-2. Steps to take in an emergency CAUTION As an added safety feature, your vehicle has been equipped with a tire pressure monitoring system (TPMS-tire pressure warning system) that illuminates a low tire pressure telltale (tire pressure warning light) when one or more of your tires is significantly under-inflated.
Page 458 5-2. Steps to take in an emergency CAUTION TPMS (tire pressure warning system) malfunctions may occur for a vari- ety of reasons, including the installation of replacement or alternate tires or wheels on the vehicle that prevent the TPMS (tire pressure warning system) from functioning properly.
Page 459 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light turn off. Interior Exterior Warning Details Correction procedure buzzer buzzer light The electronic key is not detected Start the hybrid sys- when an attempt...
Page 460 5-2. Steps to take in an emergency Interior Exterior Warning Correction Details buzzer buzzer light procedure Driving has been started without the Confirm the location  Once correct electronic of the electronic key. key inside the vehicle. The electronic key was carried out- side the vehicle and a door other...
Page 461 5-2. Steps to take in an emergency Interior Exterior Warning Correction Details buzzer buzzer light procedure An attempt was made to exit the vehicle with the Turn the “POWER” Contin- electronic key and  switch off and lock the lock the doors uous doors again.
Page 462: If You Have A Flat Tire
5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare tire provided. Before jacking up the vehicle ■ ● Stop the vehicle on a hard, flat surface. ●...
Page 463 5-2. Steps to take in an emergency Taking out the jack Open the deck board and move STEP it toward the front of the vehicle. Remove the left side deck board STEP and then remove the center aux- iliary boxes. Take out the jack.
Page 464 5-2. Steps to take in an emergency Taking out the spare tire Unload the tool holder from the vehicle and loosen the center fastener that secures the spare tire. CAUTION Service plug ■ Be careful not to hit the service plug when loading or unloading the tool holder or the spare tire.
Page 465 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 466 5-2. Steps to take in an emergency Turn the tire jack portion “A” by STEP hand until the notch of the jack is in contact with the jack point. The jack point guides are located under the rocker panel. They indicate the jack point positions.
Page 467 5-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- STEP ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 468 5-2. Steps to take in an emergency Replacing an aluminum wheel with a steel wheel (including a compact spare tire) Tighten the nuts until the tapered Tapered portion portion comes into loose contact with the disc wheel seat. Disc wheel seat Replacing an aluminum wheel with an aluminum wheel Turn the nut washers until they...
Page 469 5-2. Steps to take in an emergency Firmly tighten each wheel nut STEP two or three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) For vehicles with 16 inch wheels, STEP reinstall the wheel ornament. Align the cutout of the wheel ornament with the valve stem as shown.
Page 470 5-2. Steps to take in an emergency Stowing the flat tire For vehicles with a 17-inch STEP wheel: Before stowing the flat tire, remove the center wheel ornament by pushing from the reverse side. Place the flat tire on the deck STEP board, and pass the belt through the lower-right cargo hook and...
Page 471 5-2. Steps to take in an emergency Pass the belt through the buckle STEP and secure the tire firmly. Check that the belt is securely held by the buckle. The belt cannot be fastened securely if the buckle is facing the wrong direction.
Page 472 5-2. Steps to take in an emergency CAUTION When using the compact spare tire ■ ● Remember that the spare tire provided is specifically designed for use with your vehicle. Do not use your spare tire on another vehicle. ● Do not use more than one spare tire simultaneously.
Page 473 5-2. Steps to take in an emergency CAUTION Speed limit when using the compact spare tire ■ Do not drive at speeds in excess of 50 mph (80 km/h) when a compact spare tire is installed on the vehicle. The compact spare tire is not designed for driving at high speeds. Failure to observe this precaution may lead to an accident causing death or seri- ous injury.
Page 474 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install the wheel nuts with the tapered ends facing inward.
Page 475 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 476: If The Hybrid System Will Not Start
5-2. Steps to take in an emergency If the hybrid system will not start Reasons for the hybrid system not starting vary depending on the situation. Check the following and perform the appropriate proce- dure: The hybrid system will not start even though the correct ■...
Page 477 ● One or both of the 12-volt battery terminals may be discon- nected. ● The 12-volt battery may be discharged. (P. 481) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function...
Page 478: If You Lose Your Keys
5-2. Steps to take in an emergency If you lose your keys New genuine keys can be made by your Toyota dealer using the other key and the key number stamped on your key number plate. PRIUS v_OM_OM47840U_(U)
Page 479: If The Electronic Key Does Not Operate Properly
5-2. Steps to take in an emergency If the electronic key does not operate properly If communication between the electronic key and vehicle is inter- rupted (P. 65) or the electronic key cannot be used because the battery is depleted, the smart key system and wireless remote con- trol cannot be used.
Page 480 5-2. Steps to take in an emergency Starting the hybrid system STEP Depress the brake pedal. Touch the Toyota emblem side of STEP electronic “POWER” switch. If any of the doors is opened or closed while the key is being...
Page 481: If The 12-Volt Battery Is Discharged
The following procedures may be used to start the hybrid system if the vehicle’s 12-volt battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your vehicle by follow- ing the steps below.
Page 482 5-2. Steps to take in an emergency STEP Connect the jumper cables according to the following procedure: Connect a positive jumper cable clamp to the exclusive jump starting terminal on your vehicle. Connect the clamp on the other end of the positive cable to the positive (+) battery terminal on the second vehicle.
Page 483 ON mode. STEP Make sure the “READY” indicator comes on. If the indicator light does not come on, contact your Toyota dealer. STEP Once the hybrid system has started, remove the jumper cables in the exact reverse order from which they were con- nected.
Page 484 5-2. Steps to take in an emergency Starting the hybrid system when the 12-volt battery is discharged ■ The hybrid system cannot be started by push-starting. To prevent 12-volt battery discharge ■ ● Turn off the headlights and the audio system while the hybrid system is off.
Page 485 5-2. Steps to take in an emergency CAUTION Avoiding 12-volt battery fires or explosions ■ Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the 12-volt battery: ● Make sure each jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any other than the intended terminal.
Page 486 CAUTION After recharging the 12-volt battery ■ Have the 12-volt battery inspected at your Toyota dealer as soon as possi- ble. If the 12-volt battery is deteriorating, continued use may cause the 12-volt battery to emit a malodorous gas, which may be detrimental to the health of passengers.
Page 487: If Your Vehicle Overheats
Carefully lift the hood. After the hybrid system has STEP cooled down sufficiently, inspect the hoses and radiator core (radiator) for any leaks. Radiator Cooling fans If a large amount of coolant leaks, immediately contact your Toyota dealer. PRIUS v_OM_OM47840U_(U)
Page 488 (The fans may not operate in freezing temperatures.) STEP If the fans are not operating: Stop the hybrid system immediately and contact your Toyota dealer. If the fans are operating: Have the vehicle inspected at the nearest Toyota dealer. PRIUS v_OM_OM47840U_(U)
Page 489 Start the hybrid system and check for the instrument cluster. If the hybrid system overheat warning light does not turn off: Stop the hybrid system and contact your Toyota dealer. If the hybrid system overheat warning light does not come on: Have the vehicle inspected at the nearest Toyota dealer.
Page 490 5-2. Steps to take in an emergency CAUTION To prevent an accident or injury when inspecting under the hood of ■ your vehicle ● If steam is seen coming from under the hood, do not open the hood until the steam has subsided. The engine compartment may be very hot, caus- ing serious injuries such as burns.
Page 491: If The Vehicle Becomes Stuck
5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: STEP Set the parking brake and shift the shift position to P. Stop the hybrid system.
Page 492 5-2. Steps to take in an emergency NOTICE To avoid damage to the hybrid transmission and other components ■ ● Avoid spinning the wheels and depressing the accelerator pedal more than necessary. ● If the vehicle remains stuck even after these procedures are performed, the vehicle may require towing to be freed.
Page 493: If Your Vehicle Has To Be Stopped In An Emergency
5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: STEP Steadily step on the brake pedal with both feet and firmly...
Page 494 5-2. Steps to take in an emergency CAUTION If the hybrid system has to be turned off while driving ■ Power assist for the steering wheel will be lost, making the steering wheel heavier to turn. Decelerate as much as possible before turning off the hybrid system.
Page 495: Vehicle Specifications
Vehicle specifications 6-1. Specifications Maintenance data (fuel, oil level, etc.) ..496 Fuel information ....507 Tire information ....510 6-2. Customization Customizable features ..525 6-3. Initialization Items to initialize ....531 PRIUS v_OM_OM47840U_(U)
Page 496: Maintenance Data (Fuel, Oil Level, Etc.)
6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weight Overall length 181.7 in. (4615 mm) Overall width 69.9 in. (1775 mm) 62.0 in. (1575 mm) Overall height 63.0 in. (1600 mm) Wheelbase 109.4 in. (2780 mm) 60.6 in. (1540 mm) Front 60.2 in.
Page 497 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 498 6-1. Specifications Engine number ■ The engine number is stamped on the engine block as shown. Engine Model 1.8 L 4-cylinder (2ZR-FXE) Type 4-cylinder in line, 4-cycle, gasoline 3.17  3.48 in. (80.5  88.3 mm) Bore and stroke Displacement 109.7 cu.in.
Page 499: Lubrication System
6-1. Specifications Electric motor (Traction motor) Type Permanent magnet motor Maximum output 60 kW Maximum torque 153 ft•lbf (207 N•m, 21.1 kgf•m) Hybrid battery (traction battery) Type Nickel-Metal hydride battery Voltage 7.2 V/module Capacity 6.5 Ah (3HR) Quantity 28 modules Overall voltage 201.6 V Lubrication system...
Page 500 6-1. Specifications Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil Recommended viscosity: SAE 0W-20...
Page 501 Power control 2.9 qt. (2.7 L, 2.4 Imp.qt.) unit Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non- Coolant type silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technol- Do not use plain water alone.
Page 502: Ignition System
6-1. Specifications Ignition system Spark plug Make DENSO SC20HR11 0.043 in. (1.1 mm) NOTICE Iridium-tipped spark plugs ■ Use only iridium-tipped spark plugs. Do not adjust the spark plug gap. Electrical system 12-volt battery Fully charged 12.5 V or over 11.0 ...
Page 503 If replacement is necessary, contact your Toyota dealer. NOTICE Transmission fluid type ■ Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle. Brakes Pedal clearance 2.94 in.
Page 504 6-1. Specifications Steering Free play Less than 1.2 in. (30 mm) Tires and wheels Type A Tire size P205/60R16 91V Front tire Tire inflation pressure 35 psi (240 kPa, 2.4 kgf/cm or bar) (Recommended cold tire Rear tire inflation pressure) 33psi (230 kPa, 2.3 kgf/cm or bar) 16 ...
Page 505 6-1. Specifications Compact spare tire Tire size T135/70D17 102M Spare tire inflation pressure (Recommended cold tire 60 psi (420 kPa, 4.2 kgf/cm or bar) inflation pressure) 17  4T Wheel size Wheel nut torque 76 ft • lbf (103 N • m, 10.5 kgf • m) PRIUS v_OM_OM47840U_(U)
Page 506 6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Halogen headlights Low beam High beam LED headlights High beam Fog lights Front turn signal lights WY21W Exterior Front side marker lights Parking lights Rear turn signal lights WY21W Back-up lights W21W License plate lights Personal/interior lights...
Page 507: Fuel Information
In very few cases, driveability problems may be caused by the brand of gas- oline you are using. If driveability problems persist, try changing the brand of gasoline. If this does not correct the problem, consult your Toyota dealer. Gasoline quality standards ■...
Page 508 ■ Some gasoline contains an octane enhancing additive called MMT (Methyl- cyclopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected. The malfunction indicator lamp on the instrument cluster may come on. If this happens, contact your Toyota dealer for service.
Page 509 6-1. Specifications If your engine knocks ■ ● Consult your Toyota dealer. ● You may occasionally notice light knocking for a short time while acceler- ating or driving uphill. This is normal and there is no need for concern. NOTICE Notice on fuel quality ■...
Page 510: Tire Information
6-1. Specifications Tire information Typical tire symbols Full-size tire Compact spare tire Tire size (P. 513) DOT and Tire Identification Number (TIN) (P. 512) Location of treadwear indicators (P. 389) PRIUS v_OM_OM47840U_(U)
Page 511 6-1. Specifications Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire. Summer tires or all season tires (P. 394) An all season tire has “M+S” on the sidewall. A tire not marked “M+S”...
Page 512 6-1. Specifications Typical DOT and Tire Identification Number (TIN) DOT symbol Tire Identification Number (TIN) Tire manufacturer’s identifica- tion mark Tire size code Manufacturer’s optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year : The DOT symbol certifies that the tire conforms to applicable Federal...
Page 513 6-1. Specifications Tire size Typical tire size information ■ The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits) Speed symbol...
Page 514 6-1. Specifications Tire section names Bead Sidewall Shoulder Tread Belt Inner liner Reinforcing rubber Carcass Rim lines Bead wires Chafer PRIUS v_OM_OM47840U_(U)
Page 515 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. DOT quality grades ■...
Page 516 6-1. Specifications Traction AA, A, B, C ■ The traction grades, from highest to lowest, are AA, A, B and C, and they represent the tire’s ability to stop on wet pavement as measured under controlled conditions on specified government test surfaces of asphalt and concrete.
Page 517 6-1. Specifications Glossary of tire terminology Tire related term Meaning Tire pressure when the vehicle has been Cold tire inflation pres- parked for three hours or more, or has not sure been driven more than 1 mile or 1.5 km under that condition The maximum cold inflated pressure to which a Maximum inflation...
Page 518 6-1. Specifications Tire related term Meaning 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 that weight follows Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below The combined weight of installed regular pro- duction options weighing over 5 lb.
Page 519 6-1. Specifications Tire related term Meaning The load on an individual tire that is determined Vehicle maximum load by distributing to each axle its share of the on the tire maximum loaded vehicle weight, and dividing by two The load on an individual tire that is determined by distributing to each axle its share of curb Vehicle normal load weight, accessory weight, and normal occu-...
Page 520 6-1. Specifications Tire related term Meaning Cord The strands forming the plies in the tire The parting of cords from adjacent rubber com- Cord separation pounds Any parting within the tread, sidewall, or inner- Cracking liner of the tire extending to cord material A pneumatic tire with an inverted flange tire and rim system in which the rim is designed with rim flanges pointed radially inward and the...
Page 521 6-1. Specifications Tire related term Meaning (a) The sidewall that contains a whitewall, bears white lettering, or bears manufac- turer, brand, and/or model name molding that is higher or deeper than the same Intended outboard molding on the other sidewall of the tire, or sidewall (b) The outward facing sidewall of an asym- metrical tire that has a particular side that...
Page 522 6-1. Specifications Tire related term Meaning The linear distance between the exteriors of the sidewalls of an inflated tire, including eleva- Overall width tions due to labeling, decorations, or protective bands or ribs A tire intended for use on passenger cars, mul- tipurpose passenger vehicles, and trucks, that Passenger car tire have a gross vehicle weight rating (GVWR) of...
Page 523 6-1. Specifications Tire related term Meaning The linear distance between the exteriors of the sidewalls of an inflated tire, excluding ele- Section width vations due to labeling, decoration, or protec- tive bands That portion of a tire between the tread and Sidewall bead The parting of the rubber compound from the...
Page 524 6-1. Specifications Tire related term Meaning Tread separation Pulling away of the tread from the tire carcass The projections within the principal grooves Treadwear indicators designed to give a visual indication of the (TWI) degrees of wear of the tread The fixture used to hold the wheel and tire Wheel-holding fixture assembly securely during testing...
Page 525: Customization Customizable Features
Toyota dealer. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer for further details. Customizable features Vehicles with a Display Audio system: Settings that can be...
Page 526 6-2. Customization Custom- Default Item Function ized setting setting Smart key Smart key system system Select doors to Driver’s (P. 57) All doors – unlock door Wireless remote – – control Driver’s door unlocked All doors Unlocking in 1-step, unlocked Wireless operation all doors...
Page 527 6-2. Customization Custom- Default set- Item Function ized ting setting Driver’s door unlocked in All doors Unlocking using 1-step, all unlocked in – a key doors 1-step unlocked in 2-step Speed-detecting automatic door lock function Door lock (P. 74, Shifting the shift 479) position to any position other...
Page 528 6-2. Customization Custom- Default set- Item Function ized ting setting Time elapsed before lights turn 15 seconds – seconds 30 seconds Operation when the doors are – – unlocked Operation after the “POWER” – – switch turned Illumination Operation when (P.
Page 529 6-2. Customization Custom- Default set- Item Function ized ting setting Sensor sensitiv- ity for darkening the brightness of the meter, navi- gation system -2 to +2 – – and instrument panel depend- ing on the out- side brightness Meter and instrument Sensor sensitiv- panel...
Page 530 6-2. Customization Custom- Default set- Item Function ized ting setting Operates when the “POWER” switch is turned off and the doors Panoramic are locked from roof shades inside or outside door lock- the vehicle using linked auto- the wireless – –...
Page 531: Initialization Items To Initialize
6-3. Initialization Items to initialize The following items must be initialized for normal system operation after such cases as the 12-volt battery being reconnected, or mainte- nance being performed on the vehicle. Item When to initialize Reference Maintenance data After the maintenance is performed P.
Page 532 6-3. Initialization PRIUS v_OM_OM47840U_(U)
Page 533: For Owners
For owners Reporting safety defects for U.S. owners ....534 Seat belt instructions for Canadian owners (in French) ..... 535 SRS airbag instructions for Canadian owners (in French) ..... 538 PRIUS v_OM_OM47840U_(U)
Page 534: Reporting Safety Defects For U.s. Owners
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 535: Seat Belt Instructions For Canadian Owners (In French)
Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. PRIUS v_OM_OM47840U_(U)
Page 536 PRIUS v_OM_OM47840U_(U)
Page 537 PRIUS v_OM_OM47840U_(U)
Page 538: Srs Airbag Instructions For Canadian Owners (In French)
SRS airbag instructions for Canadian owners (in French) PRIUS v_OM_OM47840U_(U)
Page 539 PRIUS v_OM_OM47840U_(U)
Page 540 PRIUS v_OM_OM47840U_(U)
Page 541 PRIUS v_OM_OM47840U_(U)
Page 542 PRIUS v_OM_OM47840U_(U)
Page 543 PRIUS v_OM_OM47840U_(U)
Page 544 PRIUS v_OM_OM47840U_(U)
Page 545 PRIUS v_OM_OM47840U_(U)
Page 546 PRIUS v_OM_OM47840U_(U)
Page 547 PRIUS v_OM_OM47840U_(U)
Page 548 PRIUS v_OM_OM47840U_(U)
Page 549: Index
Index Abbreviation list ..... 550 Alphabetical index....552 What to do if......562 Vehicles with a Display Audio system: For details of equipment related to the Display Audio system, such as the audio system, refer to the “DISPLAY AUDIO SYSTEM OWNER’S MANUAL”. Vehicles with a navigation system: For details of equipment related to the navigation sys- tem and touch screen, such as the audio systems, refer...
Page 550: Abbreviation List
Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Air Conditioning Anti-lock Brake System Automatic Locking Retractor APGS Advanced Parking Guidance System Child Restraint System DISP Display Economy/Ecology Electronic Control Unit Event Data Recorder Emergency Locking Retractor Electric Power Steering Electric Vehicle GAWR Gross Axle Weight Ratings Global Positioning System GVWR...
Page 551 Abbreviation list ABBREVIATIONS MEANING On Board Diagnostics Pre-Collision System Power Supplemental Restraint System Tire Identification Number TPMS Tire Pressure Monitoring (Warning) System TRAC Traction Control Treadwear Indicator Vehicle Identification Number Vehicle Stability Control PRIUS v_OM_OM47840U_(U)
Page 552: Alphabetical Index
Alphabetical index Alphabetical index Antenna ........354 Anti-lock brake system ... 250 Air conditioning filter....405 Armrest ........319 Automatic air conditioning Assist grips ......324 system ........278 ABS ...........250 Audio input Air conditioning filter....405 Audio remote control switches Air conditioning system Audio system Audio/video system Air conditioning filter....405...
Page 553 Alphabetical index ® Bluetooth Child safety Bottle holders ......309 Airbag precautions ....132 Brake Back door precautions ....81 Fluid........503 Child restraint system....144 Parking brake ....... 195 Child-protectors.......75 Brake assist ......250 How your child should wear Break-in tips ......165 the seat belt ......102 Brightness control Installing child restraints..149...
Page 554 Alphabetical index Daytime running light Eco drive mode switch.... 187 system ........216 Electric power steering ... 250 Deck board .......327 Electronic key Defogger If the electronic key does Rear window ......293 not operate properly ... 479 Side mirrors......293 Replacing battery ....407 Dimensions.......496 Emergency, in case of Dinghy towing ......276...
Page 555 Alphabetical index Engine Floor mats.........325 Fluid Accessory mode....177 Compartment......372 Brake........503 Hood........366 Washer........382 Fog lights How to start the hybrid system........ 175 Replacing light bulbs .....420 Identification number .... 497 Switch........219 If the hybrid system will not Wattage.........506 Foot lights.........299 start ........
Page 556 Alphabetical index Garage door opener....331 I/M test ........362 Gauges........197 Identification Glove boxes......305 Engine........498 Vehicle ........497 Ignition switch......175 Hands-free system Illuminated entry system..299 (for cellular phone) Immobilizer system ....119 Hazard lights Indicator lights ......208 Switch........436 Initialization Head restraints Items to initialize ....
Page 557 Alphabetical index License plate lights Meter Replacing light bulbs .... 420 Instrument panel light Wattage ........ 506 control .........199 Light bulbs Meters ........197 Replacing ......420 Speed unit select button..199 Wattage ........ 506 Trip information display ..201 Lights Micro dust and pollen filter ..285 Microphone ......339 Emergency flasher...
Page 558 Alphabetical index Panoramic roof Safety Connect......339 Seat belt reminder light... 451 Sun shade ......320 Seat belts Washing precautions.....351 Parking brake ......195 Adjusting the seat belt.....98 Parking lights Automatic Locking Retractor Switch........213 (ALR) ........101 PCS..........256 Child restraint system Personal lights installation......
Page 559 Alphabetical index Seats Steering wheel Adjustment ...... 84, 88 Adjustment ......107 Adjustment Audio switches Storage feature......303 precautions ....86, 91 Stuck Child seats/child restraint system installation....149 If your vehicle becomes Cleaning ....... 352 stuck ........491 Sun visors.........312 Flattening seatbacks ....85 Sunshade Folding down the seatbacks......
Page 560 Alphabetical index Tail lights Tonneau cover ......329 Tools ......... 462 Switch........213 Talk switch Total load capacity ....270 Telephone switch Towing Theft deterrent system Dinghy towing ....... 276 Immobilizer system ....119 Emergency towing ....438 Tire inflation pressure .....398 Trailer towing ......
Page 561 Alphabetical index Warning buzzers Warning message Brake system......444 Parking lock system ....448 Washer Open door ......450 Seat belt reminder ....451 Checking .......382 Warning lights Preparing and checking Anti-lock brake system before winter .......271 (ABS) ......... 446 Switch........221 Washing and waxing ....348 Automatic headlight Weight...
Page 562: What To Do If
What to do if... What to do if... If you have a flat tire A tire punctures P. 462 P. 476 If the hybrid system will not start P. 119 Immobilizer system The hybrid system does not start If the 12-volt battery is P.
Page 563 What to do if... ■ Warning lights Brake system warning Malfunction indicator light (red indicator) lamp P. 444 P. 446 Charging system SRS warning light warning light P. 445 P. 446 Low engine oil pressure “ABS” warning light warning light P.
Page 564 What to do if... Radar cruise control indicator light* Pre-collision system warning light* P. 447 P. 448 Slip indicator light P position request indicator light P. 447 P. 449 Brake system warning light (yellow indicator) Hybrid system overheat warning light P.
Page 565 What to do if... PRIUS v_OM_OM47840U_(U)
Page 566 What to do if... PRIUS v_OM_OM47840U_(U)
Page 567 What to do if... PRIUS v_OM_OM47840U_(U)
Page 568: Gas Station Information
Engine oil capacity qt. (L, Imp.qt.)  (Drain and refill  With filter 4.4 (4.2, 3.7) reference) Without filter 4.1 (3.9, 3.4 Toyota Genuine Motor Oil or equivalent Engine oil type Oil grade: ILSAC GF-5 multigrade engine oil P. 499 PRIUS v_OM_OM47840U_(U)

Toyota 2014 Prius Owner's Manual

1 Before Driving

Hybrid System Hybrid System Features

1-2. Key Information

1-3. Opening, Closing and Locking the Doors

Adjustable Components (Seats, Mirrors, Steering Wheel)

Opening and Closing the Windows Power Windows

1-6. Refueling

Theft Deterrent System Immobilizer System

Safety Information Correct Driving Posture

2 When Driving

2-1. Driving Procedures

2-2. Instrument Cluster

2-3. Operating the Lights and Windshield Wipers

Using Other Driving Systems Cruise Control

2-5. Driving Information

3 Interior Features

Using the Air Conditioning System and Defogger Automatic Air Conditioning System

3-2. Using the Audio System

3-3. Using the Interior Lights

3-4. Using the Storage Features

3-5. Other Interior Features

Maintenance Maintenance Requirements

Do-It-Yourself Maintenance Do-It-Yourself Service Precautions

5 When Trouble Arises

Essential Information Emergency Flashers

Steps to Take in an Emergency if a Warning Light Turns on or a Warning Buzzer Sounds

6 Vehicle Specifications

6-1. Specifications

Customization Customizable Features

Initialization Items to Initialize

7 For Owners

Index

Abbreviation List

Alphabetical Index

What to Do if

Quick Links

Related Manuals for Toyota 2014 Prius

Summary of Contents for Toyota 2014 Prius
