  • Page 1 OWNER’S MANUAL XVS1100S XVS1100AS 5YS-28199-20...
  • Page 3 In addition, the many tips given in this manual will help keep your motorcycle in the best possible con- dition. If you have any further questions, do not hesitate to contact your Yamaha dealer. The Yamaha team wishes you many safe and pleasant rides. So, remember to put safety first!

  • Page 4: Important Manual Information

    This manual should be considered a permanent part of this motorcycle and should remain with it even if the motorcycle is subsequently sold. Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most current product information available at the time of printing, there may be minor discrepancies between your motorcycle and this manual.
  • Page 5 IMPORTANT MANUAL INFORMATION EAU10200 XVS1100S/XVS1100AS OWNER’S MANUAL ©2003 by Yamaha Motor Co., Ltd. 1st edition, June 2003 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS SAFETY INFORMATION ....1-1 Adjusting the shock absorber Final gear oil ........ 6-10 Location of important labels ....1-5 assembly ........3-16 Cleaning the air filter element ..6-11 Luggage strap holders ....3-18 Adjusting the carburetors ..... 6-12 DESCRIPTION ........2-1 Sidestand ........
  • Page 7 TABLE OF CONTENTS Checking and lubricating the brake and clutch levers .....6-24 Checking and lubricating the sidestand ........6-25 Lubricating the rear suspension ...6-25 Checking the front fork ....6-25 Checking the steering ....6-26 Checking the wheel bearings ..6-27 Battery ..........6-27 Replacing the fuses ......6-28 Replacing the headlight bulb ..6-30 Replacing a turn signal light bulb or the tail/brake light bulb ..6-31...

  • Page 8: Safety Information

    SAFETY INFORMATION EAU10250 AND/OR WHEN MADE NECES- • Ride where other motorists can SARY BY MECHANICAL CONDI- see you. Avoid riding in another MOTORCYCLES SINGLE TIONS. motorist’s blind spot. TRACK VEHICLES. THEIR SAFE USE Many motorcycle accidents in- AND OPERATION ARE DEPENDENT Safe riding volve inexperienced operators.
  • Page 9 Modifications made to this motorcycle other motorists can see you. the single most critical factor in the pre- not approved by Yamaha, or the re- The posture of the operator and vention or reduction of head injuries. moval of original equipment, may ren- passenger is important for proper Always wear an approved helmet.
  • Page 10 Since Yamaha cannot should be kept to a minimum. XVS1100 200 kg (441 lb) / XVS1100A test all other accessories that may be •...
  • Page 11 SAFETY INFORMATION Gasoline and exhaust gas • Do not park the motorcycle on a GASOLINE IS HIGHLY FLAMMA- slope or soft ground, otherwise it BLE: may fall over. • Always turn the engine off when • Do not park the motorcycle near refueling.

  • Page 12: Location Of Important Labels

    SAFETY INFORMATION EAU10381 Location of important labels Please read the following important labels carefully before operating this vehicle. 3HP-21568-E0...

  • Page 13: Description

    DESCRIPTION EAU32220 Left view XVS1100 1. Shift pedal (page 3-8) 2. Fuel cock (page 3-11) 3. Shock absorber assembly spring preload adjusting ring (page 3-16) 4. Helmet holder (page 3-14) 5. Storage compartment (page 3-15) 6. Owner’s tool kit (page 6-1) 7.
  • Page 14 DESCRIPTION XVS1100A 1. Shift pedal (page 3-8) 2. Fuel cock (page 3-11) 3. Shock absorber assembly spring preload adjusting ring (page 3-16) 4. Helmet holder (page 3-14) 5. Storage compartment (page 3-15) 6. Owner’s tool kit (page 6-1) 7. Fuse box (page 6-28) 8.

  • Page 15: Right View

    DESCRIPTION EAU32230 Right view XVS1100 1. Battery (page 6-27) 2. Main fuse (page 6-28) 3. Main switch/steering lock (page 3-2) 4. Air filter element (page 6-11) 5. Brake pedal (page 3-9)
  • Page 16 DESCRIPTION XVS1100A 1. Battery (page 6-27) 2. Main fuse (page 6-28) 3. Main switch/steering lock (page 3-2) 4. Air filter element (page 6-11) 5. Brake pedal (page 3-9)

  • Page 17: Controls And Instruments

    DESCRIPTION EAU10430 Controls and instruments 1. Clutch lever (page 3-7) 2. Left handlebar switches (page 3-6) 3. Starter (choke) lever (page 3-12) 4. Speedometer unit (page 3-5) 5. Fuel tank cap (page 3-9) 6. Right handlebar switches (page 3-6) 7. Throttle grip (page 6-13) 8.

  • Page 18: Instrument And Control Functions

    Do not expose any key to exces- a Yamaha dealer to have them re-reg- sively high temperatures. istered. Do not use the key with the red Do not place any key close to bow for driving.

  • Page 19: Main Switch/Steering Lock (Xvs1100)

    INSTRUMENT AND CONTROL FUNCTIONS EAU10460 EAU10471 EAU10480 Main switch/steering lock Main switch/steering lock ON (XVS1100) All electrical systems are supplied with (XVS1100) (XVS1100A) power, and the headlight, meter lighting and taillight come on, and the engine can be started. The key cannot be re- moved.
  • Page 20 INSTRUMENT AND CONTROL FUNCTIONS To lock the steering To unlock the steering EAU10920 (Parking) (XVS1100A) The steering is locked, the taillight and auxiliary light are on, and the hazard light can be turned on, but all other electrical systems are off. The key can be removed.

  • Page 21: Indicator And Warning Lights

    This warning light comes on or flashes high beam of the headlight is switched when an electrical circuit monitoring the engine is defective. When this occurs, have a Yamaha dealer check the self- diagnosis system. EAU11120 Oil level warning light “...

  • Page 22: Speedometer Unit

    If the immobilizer system is de- Yamaha dealer and have the stan- fective, the indicator light will start flash- dard keys re-registered. ing a pattern when the key is turned to “ON”.

  • Page 23: Handlebar Switches

    INSTRUMENT AND CONTROL FUNCTIONS tance that can be traveled with a full EAU12342 Right (XVS1100A) Handlebar switches tank of fuel. This information will enable you to plan future fuel stops. Left 1. Engine stop switch “ ” 2. Hazard switch “ ”...

  • Page 24: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS position. To cancel the turn signal EAU12730 EAU12820 Hazard switch “ ” (XVS1100A) Clutch lever lights, push the switch in after it has re- With the key in the “ON” or “ ” posi- turned to the center position. tion, use this switch to turn on the haz- ard light (simultaneous flashing of all EAU12500...

  • Page 25: Shift Pedal (Xvs1100)

    INSTRUMENT AND CONTROL FUNCTIONS EAU12870 EAU12880 EAU12890 Shift pedal (XVS1100) Shift pedal (XVS1100A) Brake lever 1. Shift pedal 1. Shift pedal 1. Brake lever The shift pedal is located on the left The shift pedal is located on the left The brake lever is located at the right side of the engine and is used in com- side of the engine and is used in com-...

  • Page 26: Brake Pedal

    INSTRUMENT AND CONTROL FUNCTIONS EAU12941 EAU13120 2. Turn the key counterclockwise to Brake pedal Fuel tank cap the original position, remove it, and then close the lock cover. XVS1100 NOTE: The fuel tank cap cannot be installed unless the key is in the lock. In addition, the key cannot be removed if the cap is not properly installed and locked.

  • Page 27: Fuel

    Avoid spilling fuel on the hot en- as well as to the exhaust system. gine. Your Yamaha engine has been de- signed to use regular unleaded gaso- line with a research octane number of 91 or higher. If knocking (or pinging) oc-...

  • Page 28: Fuel Cock

    INSTRUMENT AND CONTROL FUNCTIONS EAU13550 This indicates reserve. With the fuel Fuel cock cock lever in this position, the fuel re- The fuel cock supplies fuel from the serve is made available. Turn the fuel tank to the carburetors while also filter- cock lever to this position if you run out ing it.

  • Page 29: Starter (Choke) Lever

    INSTRUMENT AND CONTROL FUNCTIONS EAU13610 EAU14211 Starter (choke) lever “ ” Seats (XVS1100) Passenger seat To remove the passenger seat Remove the nut, and then pull the pas- senger seat up. 1. Projection 2. Seat holder 1. Starter (choke) lever “ ”...

  • Page 30: Seats (Xvs1100A)

    INSTRUMENT AND CONTROL FUNCTIONS 2. Install the seat bracket and bolts. EAU14200 Seats (XVS1100A) 3. Install the passenger seat. NOTE: Passenger seat Make sure that the seats are properly secured before riding. To remove the passenger seat Remove the bolt, and then pull the pas- senger seat up.

  • Page 31: Helmet Holder

    INSTRUMENT AND CONTROL FUNCTIONS To install the rider seat EAU14281 Helmet holder 1. Insert the projections on the front of the rider seat into the holders as XVS1100 shown, place the seat in the origi- nal position, and then install the bolt.

  • Page 32: Storage Compartment

    INSTRUMENT AND CONTROL FUNCTIONS To lock the helmet holder, place it in the EAU14481 Storage compartment original position, and then remove the The storage compartment is located on key. the left side of the vehicle. EWA10160 WARNING To open the storage compartment Never ride with a helmet attached to 1.

  • Page 33: Adjusting The Shock Absorber Assembly

    INSTRUMENT AND CONTROL FUNCTIONS EAU14871 3. Pull the ignitor unit panel out to the Adjusting the shock absorber right. assembly The shock absorber assembly is locat- ed under the rider seat and is equipped with a spring preload adjusting ring. ECA10100 CAUTION: Never attempt to turn an adjusting...
  • Page 34 INSTRUMENT AND CONTROL FUNCTIONS XVS1100A XVS1100 Spring preload setting: Minimum (soft): Standard: XVS1100 3 XVS1100A 4 Maximum (hard): XVS1100 7 XVS1100A 9 6. Install the mudguard and ignitor unit panel by installing the quick 1. Quick fastener 1. Spring preload adjusting ring fasteners.

  • Page 35: Luggage Strap Holders

    Do not deform or damage the gas cylinder in any way, as this will result in poor damping per- formance. Always have a Yamaha dealer 1. Quick fastener (after removal) service the shock absorber. 2. Quick fastener (before installation) 1. Luggage strap holder 7.

  • Page 36: Sidestand

    INSTRUMENT AND CONTROL FUNCTIONS EAU15300 below and have a Yamaha dealer re- EAU15311 Sidestand Ignition circuit cut-off system pair it if it does not function proper- The sidestand is located on the left side The ignition circuit cut-off system (com- of the frame.
  • Page 37 5. Push the start switch. Does the engine start? The neutral switch may be defective. The motorcycle should not be ridden until checked by a Yamaha dealer. With the engine still running: 6. Move the sidestand up. 7. Keep the clutch lever pulled.

  • Page 38: Pre-Operation Checks

    PRE-OPERATION CHECKS EAU15591 The condition of a vehicle is the owner’s responsibility. Vital components can start to deteriorate quickly and unexpectedly, even if the vehicle remains unused (for example, as a result of exposure to the elements). Any damage, fluid leakage or loss of tire air pressure could have serious consequences.

  • Page 39: Pre-Operation Check List

    Final gear oil • Check vehicle for oil leakage. 6-10 • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check lever free play. • Adjust if necessary. Front brake • Check brake pads for wear.
  • Page 40 • Make sure that operation is smooth. • Check cable free play. Throttle grip 6-13, 6-23 • If necessary, have Yamaha dealer adjust cable free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 6-23 •...

  • Page 41: Operation And Important Riding Points

    Become thoroughly familiar system to enable starting, one of the Yamaha dealer check the electrical cir- with all operating controls and following conditions must be met: cuit. their functions before riding. The transmission is in the neutral Consult a Yamaha dealer re- position.

  • Page 42: Starting And Warming Up A Cold Engine (Xvs1100A)

    NOTE: sufficient engine oil, have a estand up. Yamaha dealer check the elec- The engine is warm when it responds EWA10290 normally to the throttle with the starter trical circuit.
  • Page 43 6. After starting the engine, move the should be on, otherwise have a then check the warning light starter (choke) back halfway. Yamaha dealer check the electrical cir- again. If the warning light does ECA11130 cuit. not come on when turning the CAUTION: key to “ON”, or if it does not go...

  • Page 44: Starting A Warm Engine

    OPERATION AND IMPORTANT RIDING POINTS EAU16640 EAU16671 Shifting gears lets you control the Starting a warm engine Shifting amount of engine power available for Follow the same procedure as for start- starting off, accelerating, climbing hills, XVS1100 ing a cold engine with the exception etc.

  • Page 45: Tips For Reducing Fuel Consumption

    OPERATION AND IMPORTANT RIDING POINTS and drive train, which are not EAU16800 EAU16841 Tips for reducing fuel Engine break-in designed withstand consumption There is never a more important period shock of forced shifting. in the life of your engine than the period Fuel consumption depends largely on between 0 and 1600 km (1000 mi).

  • Page 46: Parking

    CAUTION: touch them. If any engine trouble should occur Do not park on a slope or on soft during the engine break-in period, ground, otherwise the vehicle immediately have a Yamaha dealer may overturn. check the vehicle.

  • Page 47: Periodic Maintenance And Minor Repair

    Yamaha dealer certain maintenance work correctly. do it for you. NOTE: If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.

  • Page 48: Periodic Maintenance And Lubrication Chart

    The annual checks must be performed every year, except if a kilometer-based maintenance is performed in- stead. From 50000 km, repeat the maintenance intervals starting from 10000 km. Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills. ODOMETER READING (× 1000 km)
  • Page 49 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING (× 1000 km) ANNUAL ITEM CHECK OR MAINTENANCE JOB CHECK √ √ √ √ √ • Check for cracks or damage. 9 * Brake hoses • Replace. Every 4 years • Check runout, spoke tightness and for damage. √...
  • Page 50 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING (× 1000 km) ANNUAL ITEM CHECK OR MAINTENANCE JOB CHECK • Check starter (choke) operation. √ √ √ √ √ √ 22 * Carburetors • Adjust engine idling speed and synchronization. • Change. √...
  • Page 51 PERIODIC MAINTENANCE AND MINOR REPAIR • Replace the brake hoses every four years and if cracked or damaged.

  • Page 52: Removing And Installing The Panel

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU18750 EAU19551 Removing and installing the Checking the spark plugs panel The spark plugs are important engine components, which are easy to check. Since heat and deposits will cause any spark plug to slowly erode, the spark plugs should be removed and checked in accordance with the periodic mainte- nance and lubrication chart.
  • Page 53 Do not attempt to diagnose such problems yourself. Instead, have a Yamaha dealer check the vehicle. 3. Check each spark plug for elec- trode erosion and excessive car- bon or other deposits, and replace 1.

  • Page 54: Engine Oil

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU19822 NOTE: Engine oil NOTE: If a torque wrench is not available when The engine oil should be between the The engine oil level should be checked installing a spark plug, a good estimate minimum and maximum level marks. before each ride.
  • Page 55 Oil change quantity: If the oil level warning light flickers 3.00 L (3.17 US qt) (2.64 Imp.qt) or remains on, immediately turn the engine off and have a Yamaha dealer ECA11620 CAUTION: check the vehicle. In order to prevent clutch slip- 7.

  • Page 56: Final Gear Oil

    If any 3. Install the final gear oil drain bolt, NOTE: leakage is found, have a Yamaha deal- and then tighten it to the specified The oil level should be at the brim of the er check and repair the vehicle.

  • Page 57: Cleaning The Air Filter Element

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU20670 ECA10480 Cleaning the air filter element CAUTION: The air filter element should be cleaned Make sure that the air filter ele- as follows at the intervals specified in ment is properly seated in the the periodic maintenance and lubrica- air filter case.

  • Page 58: Adjusting The Carburetors

    Therefore, most carbu- checked and, if necessary, adjusted as retor adjustments should be left to a follows at the intervals specified in the Yamaha dealer, who has the neces- periodic maintenance and lubrication sary professional knowledge and expe- chart.

  • Page 59: Adjusting The Throttle Cable Free Play

    Yamaha dealer at the intervals specified in the periodic Tire air pressure maintenance and lubrication chart. The tire air pressure should be checked and, if necessary, adjusted before each ride.
  • Page 60 LOAD YOUR VEHICLE. Make sure in it, or if the sidewall is cracked, con- Tire air pressure (measured on cold that the total weight of the cargo, rid- tact a Yamaha dealer immediately and tires): er, passenger, and accessories have the tire replaced.

  • Page 61: Tires (Xvs1100A)

    Yamaha Motor Co., Ltd. The tire air pressure must be ad- justed in accordance with the riding speed and with the total weight of rider, passenger, car- go, and accessories approved for this model.
  • Page 62 Because loading has an enormous in it, or if the sidewall is cracked, con- impact on the handling, braking, performance and safety characteris- tact a Yamaha dealer immediately and tics of your motorcycle, you should have the tire replaced. keep the following precautions in Minimum tire tread depth (front and mind.

  • Page 63: Spoke Wheels (Xvs1100)

    If any dam- excessively worn tires. Besides proved this model age is found, have a Yamaha Yamaha Motor Co., Ltd. being illegal, operating the vehi- dealer replace the wheel. Do not cle with excessively worn tires...

  • Page 64: Cast Wheels (Xvs1100A)

    The wheel rims should be checked for cracks, bends, warpage or damage before each ride. If any damage is found, have a Yamaha dealer replace the wheel. Do not attempt even the smallest repair to the wheel. A deformed or cracked 1.

  • Page 65: Adjusting The Brake Lever Free Play

    If the specified free play cannot be ob- play tained as described above or if the clutch does not operate correctly, have a Yamaha dealer check the internal clutch mechanism. 1. Locknut 2. Brake lever free play adjusting screw 1. Loosen the locknut at the brake le- 1.

  • Page 66: Adjusting The Brake Pedal Position

    Periodically check the ish the braking performance, brake pedal position and, if necessary, which may result in loss of con- have a Yamaha dealer adjust it. trol and an accident. EWA10690 WARNING A soft or spongy feeling in the brake pedal can indicate the presence of air in the hydraulic system.

  • Page 67: Adjusting The Rear Brake Light Switch

    If a brake pad has worn to the point that the wear indicator groove has almost disappeared, have a Yamaha dealer replace the brake pads as a set. 1. Rear brake light switch 2. Rear brake light switch adjusting nut 1.

  • Page 68: Checking The Brake Fluid Level

    However, if the Use only the recommended quality brake fluid level goes down sud- 1. Minimum level mark brake fluid, otherwise the rubber denly, have a Yamaha dealer Rear brake seals may deteriorate, causing check the cause. leakage and poor braking perfor- mance.

  • Page 69: Changing The Brake Fluid

    EAU23100 EAU23110 Changing the brake fluid Checking and lubricating the Checking and lubricating the Have a Yamaha dealer change the cables throttle grip and cable brake fluid at the intervals specified in The operation of all control cables and The operation of the throttle grip should...

  • Page 70: Checking And Lubricating The Brake And Shift Pedals

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU23131 EAU23140 Recommended lubricant: Checking and lubricating the Checking and lubricating the Lithium-soap-based grease (all-pur- brake and shift pedals brake and clutch levers pose grease) The operation of the brake and clutch levers should be checked before each ride, and the lever pivots should be lu- bricated if necessary.

  • Page 71: Checking And Lubricating The Sidestand

    2. While applying the front brake, If the sidestand does not move up push down hard on the handlebars and down smoothly, have a Yamaha several times to check if the front dealer check or repair it. fork compresses and rebounds smoothly.

  • Page 72: Checking The Steering

    Securely support the vehicle so that fork does not operate smoothly, there is no danger of it falling over. have a Yamaha dealer check or re- pair it. 2. Hold the lower ends of the front fork legs and try to move them for- ward and backward.

  • Page 73: Checking The Wheel Bearings

    If there is play in the wheel burns. Avoid any contact with hub or if the wheel does not turn skin, eyes or clothing and al- smoothly, have a Yamaha dealer check ways shield your eyes when the wheel bearings. working near batteries. In case of contact, administer the fol- lowing FIRST AID.

  • Page 74: Replacing The Fuses

    To charge the battery for the individual circuits, is located in- battery damage. Have a Yamaha dealer charge the bat- side the storage compartment. (See To charge a sealed-type (MF) tery as soon as possible if it seems to page 3-15.)
  • Page 75 PERIODIC MAINTENANCE AND MINOR REPAIR XVS1100A 2. Remove quick fasteners 4. Turn the key to “OFF” and turn off shown by pushing the center in the electrical circuit in question. with a screwdriver, then pulling the 5. Remove the blown fuse, and then fastener out.

  • Page 76: Replacing The Headlight Bulb

    If the headlight bulb 7. If the fuse immediately blows burns out, replace it as follows. again, have a Yamaha dealer 1. Remove the headlight unit by re- check the electrical system. moving the screws.

  • Page 77: Replacing A Turn Signal Light Bulb Or The Tail/Brake Light Bulb

    6. Install the headlight unit by install- 4. Place a new headlight bulb into po- ing the screws. sition, and then secure it with the 7. Have a Yamaha dealer adjust the headlight beam if necessary. bulb holder. ECA10660 CAUTION:...

  • Page 78: Supporting The Motorcycle

    PERIODIC MAINTENANCE AND MINOR REPAIR XVS1100A EAU24350 a jack either under each side of the Supporting the motorcycle frame in front of the rear wheel or under Since this model is not equipped with a each side of the swingarm. centerstand, follow these precautions when removing the front and rear wheel or performing other maintenance...

  • Page 79: Troubleshooting

    However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 80: Troubleshooting Chart

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good.

  • Page 81: Motorcycle Care And Storage

    MOTORCYCLE CARE AND STORAGE EAU26060 ucts onto seals, gaskets and wheel thinner, fuel (gasoline), rust re- Care axles. Always rinse the dirt and de- movers or inhibitors, brake flu- While the open design of a motorcycle greaser off with water. id, antifreeze or electrolyte.
  • Page 82 MOTORCYCLE CARE AND STORAGE After normal use ECA10790 5. Touch up minor paint damage CAUTION: Remove dirt with warm water, a mild caused by stones, etc. detergent, and a soft, clean sponge, 6. Wax all painted surfaces. Do not use warm water since it in- and then rinse thoroughly with clean 7.

  • Page 83: Storage

    Always store your motorcycle in a cool, NOTE: into the fuel tank. dry place and, if necessary, protect it Consult a Yamaha dealer for advice on 4. Fill up the fuel tank and add fuel against dust with a porous cover. what products to use.
  • Page 84 MOTORCYCLE CARE AND STORAGE EWA10950 than 30 °C (90 °F)]. For more in- WARNING formation on storing the battery, To prevent damage or injury from see page 6-27. sparking, make sure to ground the NOTE: spark plug electrodes while turning Make any necessary repairs before the engine over.

  • Page 85: Specifications

    SPECIFICATIONS Dimensions: Compression ratio: Air filter: 8.30 :1 Overall length: Air filter element: Starting system: XVS1100 2405 mm (94.7 in) Dry element Electric starter XVS1100A 2460 mm (96.9 in) Fuel: Lubrication system: Overall width: Recommended fuel: Wet sump XVS1100 895 mm (35.2 in) Unleaded gasoline only Engine oil: XVS1100A 945 mm (37.2 in)
  • Page 86 SPECIFICATIONS Transmission type: Manufacturer/model: Rear: Constant mesh 5-speed XVS1100 BRIDGESTONE/EXEDRA L309 XVS1100 225 kPa (33 psi) (2.25 Operation: XVS1100A BRIDGESTONE/EXEDRA kgf/cm²) Left foot operation G703 XVS1100A 250 kPa (36 psi) (2.50 Gear ratio: Rear tire: kgf/cm²) 1st: Loading condition: Type: 40/17 (2.353) XVS1100 90–200 kg (198–441 lb) XVS1100 With tube...
  • Page 87 SPECIFICATIONS Rear brake: Bulb voltage, wattage x quantity: Carburetor heater fuse: 15.0 A Type: Headlight: 12 V, 60 W/55.0 W × 1 Backup fuse: Single disc brake XVS1100 5.0 A Operation: Tail/brake light: 12 V, 5 W/21.0 W × 1 XVS1100A 10.0 A Right foot operation Recommended fluid:...

  • Page 88: Consumer Information

    Yamaha EAU26400 Vehicle identification number dealer or for reference in case the vehi- cle is stolen.

  • Page 89: Motorcycle Noise Regulation (For Australia)

    1. Model label The model label is affixed to the frame under the rider seat. (See page 3-12.) Record the information on this label in the space provided. This information will be needed when ordering spare parts from a Yamaha dealer.
  • Page 90 INDEX Fuel cock ..........3-11 Parking ............5-6 Fuel consumption, tips for reducing..5-5 Part locations .......... 2-1 Air filter element, cleaning..... 6-11 Fuel tank cap .......... 3-9 Pass switch ..........3-6 Fuses, replacing ........6-28 Periodic maintenance and lubrication Battery........... 6-27 chart.............
  • Page 91 INDEX Throttle grip and cable, checking and lubricating ........6-23 Tires (XVS1100) ........6-13 Tires (XVS1100A)......... 6-15 Tool kit ............ 6-1 Troubleshooting........6-33 Troubleshooting chart ......6-34 Turn signal indicator light......3-4 Turn signal light bulb or tail/brake light bulb, replacing ......6-31 Turn signal switch........
  • Page 94 YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2003.07-0.3×1 CR...
