TABLE OF CONTENTS

1

Before driving

2

When driving

Interior

3

features

Maintenance

4

and care

When trouble

5

arises

Vehicle

6

specifications

For U.S.

7

owners

Index

LC200_OM_OM60L09U_(U)

Adjusting and operating features such as door locks,

mirrors, and steering column

Driving, stopping and safe-driving information

Air conditioning and audio systems, as well as other in-

terior features for a comfortable driving experience

Cleaning and protecting your vehicle, performing do-it-

yourself maintenance, and maintenance information

What to do if the vehicle needs to be towed, gets a flat

tire, or is involved in an accident

Detailed vehicle information

Reporting safety defects for U.S. owners

Alphabetical listing of information contained in this

manual

1

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the 2014 Land Cruiser and is the answer not in the manual?

Questions and answers

Summary of Contents for Toyota 2014 Land Cruiser

Page 1 TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column When driving Driving, stopping and safe-driving information Interior Air conditioning and audio systems, as well as other in- features terior features for a comfortable driving experience Maintenance Cleaning and protecting your vehicle, performing do-it- and care...
Page 2: Table Of Contents
TABLE OF CONTENTS Index For vehicles with a navigation system, refer to the “Navigation System Owner’s Manual” for information regarding the equipment listed below. • Navigation system • Audio/video system • Air conditioning • Rear view monitor system • Climate control 1-4.
Page 3 2-4. Using other driving systems When driving Cruise control ..... 210 Dynamic radar cruise control ......214 2-1. Driving procedures Intuitive parking assist ..229 Driving the vehicle....154 Four-wheel drive system ..240 Engine (ignition) switch ..166 Crawl Control (with Turn Automatic transmission..
Page 4 TABLE OF CONTENTS Index ® 3-3. Using the Bluetooth Interior features audio system ® Bluetooth audio system ..402 ® Using the Bluetooth 3-1. Using the air conditioning audio system ....406 system and defogger ® Operating a Bluetooth Front air conditioning enabled portable system......
Page 5 3-6. Using the storage features Maintenance and care List of storage features ..466 • Glove box......467 • Console box...... 468 4-1. Maintenance and care • Overhead console..... 469 Cleaning and protecting • Cup holders ...... 470 the vehicle exterior ... 512 •...
Page 6 TABLE OF CONTENTS Index When trouble arises Vehicle specifications 5-1. Essential information 6-1. Specifications Emergency flashers ... 600 Maintenance data (fuel, oil level, etc.) ... 668 If your vehicle needs to be towed ......601 Fuel information....678 If you think something Tire information....
Page 7 LC200_OM_OM60L09U_(U)
Page 8 Pictorial index Exterior Moon roof P. 97 Outside rear view mirrors P. 90 Windshield wipers P. 202 Side turn signal lights P. 176 Hood P. 528 Fog lights P. 201 Headlights and daytime running lights P. 196 Parking lights P. 196 Front side marker lights P.
Page 9 Rear window defogger P. 351 Back door P. 51 Rear window wiper Stop/tail lights P. 196 P. 208  Roof luggage carrier P. 301 Fuel filler door P. 101 Side doors P. 46 License plate lights Tires P. 196 ●Rotation P.
Page 10 Pictorial index Interior Head restraint P. 72 Seat belt P. 76 SRS driver airbag P. 113 Power window switch P. 93 SRS front passenger airbag P. 113 Ashtray P. 482 Floor mat Armrest P. 491 P. 493 Rear seats P. 59 Front seats P.
Page 11 SRS curtain shield airbags P. 113 Personal lights P. 464 Interior light P. 463 Rear seat entertainment Personal lights P. 464 system Interior light P. 463 Assist grips P. 492 Interior light P. 463 Moon roof switches P. 97  “SOS”...
Page 12 Pictorial index Interior Driving position memory switches P. 68 Door lock switch P. 46 Inside lock button P. 46 ITYPC005 Power window switches P. 93 Window lock switch P. 93 LC200_OM_OM60L09U_(U)
Page 13 Power outlet P. 485 Cigarette lighter P. 484 Ashtray P. 482 Shift lever P. 171 Front seat heater/ventilator switch P. 489 ECT switch P. 172 Crawl Control switch P. 245 Multi-terrain Select mode select switch P. 251 Shift lock override button P.
Page 14 Pictorial index Instrument panel Headlight switch P. 196 Turn signal lever P. 176 Fog light switch P. 201 Gauges and meters P. 179 Multi-information display P. 189 Windshield wipers and washer switch P. 202 Rear window wiper and washer switch P.
Page 15 Without navigation system Clock P. 479 Front passenger’s seat belt Front passenger AIR BAG reminder light P. 611 ON and AIR BAG OFF indicator P. 129 Security indicator light P. 105, 107 Audio system P. 353 Emergency flasher switch P. 600 Outside temperature display P.
Page 16: Navigation System
Pictorial index Instrument panel With navigation system Clock Outside temperature display P. 480 Front passenger AIR BAG ON and AIR BAG OFF indicator P. 129 Front passenger’s seat belt reminder light P. 611 Navigation system Air conditioning system Security indicator light P.
Page 17 Talk switch P. 429 Audio remote controls Telephone switches P. 429 (steering switches) P. 398 Vehicles with a dynamic radar cruise control: Horn P. 178 DISP switch P. 190 Cruise control switch P. 210, 214  Vehicle-to-vehicle distance button P. 214 ...
Page 18 Pictorial index Instrument panel  VIEW switch P. 257 Engine (ignition) switch P. 166 Four-wheel drive control switch P. 240 LC200_OM_OM60L09U_(U)
Page 19 Headlight leveling dial P. 198 Outside rear view mirror control switches P. 90 Instrument panel light control knob P. 182 Odometer/trip meter display change button P. 179 Tilt and telescopic steering control switch P. 86 Intuitive parking assist switch P. 229 Center differential lock/unlock switch P.
Page 20 Pictorial index Luggage compartment Head restraint angle lever P. 72 Seatback handles P. 63 Tools P. 635 Power outlet P. 485 Seatback angle lever P. 59 Warning reflector holder P. 496 LC200_OM_OM60L09U_(U)
Page 21 LC200_OM_OM60L09U_(U)
Page 22: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 23 ● Dynamic radar cruise control system ● Anti-lock brake system ● SRS airbag system ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of a mobile two-way radio system. LC200_OM_OM60L09U_(U)
Page 24 ● Usage of data collected through Safety Connect (U.S. mainland only) If your Toyota has Safety Connect and if you have subscribed to those ser- vices, please refer to the Safety Connect Telematics Subscription Service Agreement for information on data collected and its usage.
Page 25 Event data recorder This vehicle is equipped with an event data recorder (EDR). The main pur- pose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.
Page 26 ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehicle) is obtained • In response to an official request by the police, a court of law or a govern- ment agency •...
Page 27 CAUTION ■ General precautions while driving Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.
Page 28 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
Page 29: Before Driving
Before driving 1-1. Key information 1-4. Opening and closing the windows and Keys ........30 moon roof Power windows ....93 1-2. Opening, closing and locking the doors Moon roof......97 Smart key system ....32 1-5. Refueling Wireless remote control ..44 Opening the fuel tank Side doors......
Page 30: 1-1. Key Information
1-1. Key information Keys The following keys are provided with the vehicle. Electronic keys • Operating the smart key system (P. 32) • Operating wireless remote control function (P. 44) Mechanical keys Key number plate Using the mechanical key Take out the mechanical key. After using the mechanical key, store it in the electronic key.
Page 31 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made at your Toyota dealer using the key number plate. (P. 652) ■...
Page 32: 1-2. Opening, Closing And Locking The Doors
1-2. Opening, closing and locking the doors Smart key system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) Locks and unlocks the doors (P. 33) Locks and unlocks the doors (P.
Page 33 Press the lock button to lock the doors. Pressing and holding the button closes the windows and moon roof. (This setting must be cus- tomized at your Toyota dealer.) Back door Press the unlock button to unlock the doors. The door cannot be unlocked for 3 seconds after the door is locked.
Page 34 1-2. Opening, closing and locking the doors Press the lock button to lock the doors. Antenna location and effective range ■ Antenna location Antennas outside cabin Antennas inside cabin Antenna outside luggage com- partment LC200_OM_OM60L09U_(U)
Page 35 1-2. Opening, closing and locking the doors ■ Effective range (areas within which the electronic key is detected) When locking or unlock- ing the doors The system can be oper- ated when the electronic key is within about 2.3 ft. (0.7 m) of an outside door handle.
Page 36 1-2. Opening, closing and locking the doors ■ Operation signals A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) ■ Conditions affecting operation The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system and wireless remote control from operating properly.
Page 37 1-2. Opening, closing and locking the doors ■ Switching the door unlock function It is possible to set which doors the entry function unlocks. STEP Turn the “ENGINE START STOP” switch OFF. STEP When the indicator on the key surface is turned off, press and hold for approximately 5 seconds while pressing the key.
Page 38 1-2. Opening, closing and locking the doors ■ Battery-saving function In the following circumstances, the entry function is disabled in order to pre- vent the vehicle and electronic key batteries from discharging. ● When the entry function has not been used for 2 weeks or more ●...
Page 39 1-2. Opening, closing and locking the doors ■ Note for the smart key system ● Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 40 1-2. Opening, closing and locking the doors ■ Security feature If a door is not opened within approximately 60 seconds after the vehicle is unlocked, the security feature automatically locks the vehicle again. ■ Alarms and warning indicators A combination of exterior and interior alarms as well as warnings displayed on the multi-information display are used to prevent theft of the vehicle and unforeseeable accidents resulting from erroneous operation.
Page 41 1-2. Opening, closing and locking the doors Alarm Situation Correction procedure When the “ENGINE START STOP” switch is in IGNITION ON or ACCES- Shift the shift lever to Interior alarm SORY mode, an attempt “P” and turn the sounds continu- was made to open the “ENGINE START ously...
Page 42 1-2. Opening, closing and locking the doors Alarm Situation Correction procedure The driver’s door was closed after the key was Turn the “ENGINE carried outside the vehicle, START STOP” switch and the “ENGINE START OFF and close the STOP” switch was not driver’s door again Interior alarm turned OFF...
Page 43 (P. 34) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of the emitted radio waves. Then, consult your doctor to see if you should disable the entry function.
Page 44: Wireless Remote Control
Opens the windows and moon roof (press and hold) Sounds alarm (press and hold) (P. 107) : This setting must be custom- ized at your Toyota dealer. ■ Operation signals ● Doors: A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked.
Page 45 1-2. Opening, closing and locking the doors ■ Alarm Using the wireless remote control to lock the door will set the alarm system. (P. 107) ■ Electronic key battery depletion P. 653 ■ If the wireless remote control does not operate properly ●...
Page 46: Side Doors
1-2. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the smart key system, wireless remote control or door lock switch. ■ Entry function P. 32 ■ Wireless remote control P. 44 ■ Door lock switch Locks all doors Unlocks all doors...
Page 47 1-2. Opening, closing and locking the doors Locking the driver’s door from the outside without a key STEP Move the inside lock button to the lock position. STEP Close the door. The door cannot be locked if the “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode, or the electronic key is left inside the vehicle.
Page 48 1-2. Opening, closing and locking the doors Automatic door locking and unlocking systems The following functions can be set or canceled: Function Operation Shift position linked Shifting the shift lever out of “P” locks all door locking function doors. Shift position linked Shifting the shift lever to “P”...
Page 49 1-2. Opening, closing and locking the doors Shift lever Driver’s door lock Function position switch position Shift position linked door lock- ing function “P” Shift position linked door unlocking function Speed linked door locking func- tion “N” Driver’s door linked door unlock- ing function When the setting or canceling operation is complete, all doors are locked and then unlocked.
Page 50 1-2. Opening, closing and locking the doors CAUTION ■ To prevent an accident Observe the following precautions while driving the vehicle. Failing to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. ●...
Page 51: Back Door
1-2. Opening, closing and locking the doors Back door The back door can be locked/unlocked and opened by the following procedures. ■ Locking and unlocking the back door Door lock switch P. 46 Entry function P. 32 Wireless remote control P.
Page 52 1-2. Opening, closing and locking the doors When closing the back door ● Make sure that the lower side of the back door is closed before closing the upper side of the back door. ● Lower the back door using the back door handle, and make sure to push the back door down from the outside to close...
Page 53 1-2. Opening, closing and locking the doors ■ If the back door opener is inoperative The back door can be operated from the inside. Remove the cover on the back door trim. STEP Use a cloth to prevent scratches. Remove the screw and cover. STEP Push the lever for the back door motor, STEP...
Page 54 1-2. Opening, closing and locking the doors CAUTION ■ While driving ● Keep the back door closed while driving. If the back door is left open, it may hit near-by objects while driving or lug- gage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
Page 55 1-2. Opening, closing and locking the doors CAUTION ■ Operating the back door Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in death or serious injury. ● Remove any heavy loads, such as snow and ice, from the back door before opening it.
Page 56 If a bicycle carrier or similar heavy object is attached to the back door, it may suddenly shut again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genuine Toyota part is recommended. NOTICE ■...
Page 57: Adjustable Components (Seats, Mirrors, Steering Wheel)
1-3. Adjustable components (seats, mirrors, steering wheel) Front seats Seat position fore/aft control switch Seatback angle control switch Seat cushion (front) angle control switch Vertical height control switch Lumbar support control switch (driver’s side only) Active head restraint When the occupant’s lower back presses against the seatback during a rear-end collision, the head restraint moves slightly for-...
Page 58 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Active head restraint Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may make the inner struc- ture of the head restraint appear. This does not indicate a problem. During rear-end collision...
Page 59: Rear Seats
1-3. Adjustable components (seats, mirrors, steering wheel) Rear seats Second seat Seatback angle adjustment lever Seat position adjustment lever Third seat LC200_OM_OM60L09U_(U)
Page 60 1-3. Adjustable components (seats, mirrors, steering wheel) Tumbling the second seats and third seat entry STEP For easy access to the third seat, perform in “Tumbling the second seats”. (P. 61) ■ Before tumbling the second seats Stow the seat belt buckles and STEP lower the head restraints to the lowest position.
Page 61 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Tumbling the second seats Fold down the seatback while STEP pulling seatback angle adjustment lever, and swing the whole seat up and forward. Hook the holding strap to the STEP assist grip and secure the seat by pulling its free end.
Page 62 1-3. Adjustable components (seats, mirrors, steering wheel) Remove the seat hook covers STEP from the back of the seat cush- ion, and install them on the seat hooks. When returning the second seat to its original position, remove the seat hook covers from the floor and install them in the back of the ITY13C025 seat cushion.
Page 63 1-3. Adjustable components (seats, mirrors, steering wheel) Folding up the third seats ■ Before folding up the third seats Stow the seat belts buckles. STEP ITY13C018 STEP Stow the center head restraint in the seatback. (P. 75) Pass the outer seat belts through STEP the seat belt hangers and secure the seat belt plates.
Page 64 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Folding up the third seats Fold down the head restraints STEP while pulling the head restraint angle lever. ITY13C022 Push the seatback angle levers STEP and fold the third seatbacks. Pull the seat leg lock release STEP levers.
Page 65 1-3. Adjustable components (seats, mirrors, steering wheel) Secure the seats by the strikers. STEP Remove the seat hook covers STEP from the back of the seat cush- ion, and install them on the seat hooks. ITY13C030 ■ Returning the third seats Remove the seat hook covers STEP from the floor and install them...
Page 66 1-3. Adjustable components (seats, mirrors, steering wheel) Secure the seats by the strikers. STEP Pull the handle and raise the STEP seatbacks. Fix the handle securely in its orig- inal position after use. Raise the head restraints. STEP LC200_OM_OM60L09U_(U)
Page 67 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ Seat adjustment Do not recline the seat more than necessary when the vehicle is in motion, to reduce the risk of sliding under the lap belt. If the seat is too reclined, during an accident the lap belt may slide past the hips and apply restraint forces directly to the abdomen or your neck may contact the shoulder belt, increasing the risk of death or serious injury.
Page 68: Driving Position Memory System
1-3. Adjustable components (seats, mirrors, steering wheel) Driving position memory system Your preferred driving position (the position of the driver’s seat, steering wheel and outside rear view mirrors) can be entered into the computer’s memory and recalled with the touch of a button. It is also possible to set this function to activate automatically when the doors are unlocked.
Page 69 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Recalling the memorized position Check that the shift lever is set in “P”. STEP Turn the “ENGINE START STOP” switch to IGNITION ON mode. Press button “1”, “2” or “3” to STEP recall the desired position.
Page 70 1-3. Adjustable components (seats, mirrors, steering wheel) To prevent unintended triggering of the alarm, open and close a door once after a driving position has been recorded. (If a door is not opened within 60 seconds after is pressed, the doors will be locked again and the alarm will automatically be set.) In case that the alarm is triggered, immediately stop the alarm.
Page 71 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Canceling the linked door unlock operation STEP Turn the “ENGINE START STOP” switch to OFF after closing the driver’s door. STEP Using the wireless remote control: While pressing “SET” button, press button on the wireless remote control until the signal beeps.
Page 72: Head Restraints
1-3. Adjustable components (seats, mirrors, steering wheel) Head restraints Head restraints are provided for all seats. Front seats Vertical adjustment Down Push the head restraint up or down while pressing the lock release button. Lock release button Angle adjustment Second seats Vertical adjustment Pull the head restraint up.
Page 73 1-3. Adjustable components (seats, mirrors, steering wheel) Third outboard seats To fold Pull the head restraint angle lever to fold the head restraint. ITY13C040 ■ Adjusting the height of the head restraints Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears.
Page 74 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Removing the head restraints Front seats Push a flathead screwdriver into the slot. STEP The slot is located on the right side of the right head restraint anchor. STEP While pressing in the flathead screwdriver, pull up the head restraint.
Page 75 1-3. Adjustable components (seats, mirrors, steering wheel) Third outboard seats Push a flathead screwdriver into the slot. STEP The slot is located on the left side of the left head restraint anchor. ITY13C035 STEP While pressing in the flathead screwdriver, pull up the head restraint.
Page 76: Seat Belts
1-3. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. ■ Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
Page 77 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Fastening and releasing the third center seat belt Pull out the tab STEP ITY13C120 Push tab B into buckle B until STEP a clicking sound is heard Tab B Buckle B Push tab A into buckle A until STEP a clicking sound is heard Tab A...
Page 78 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Releasing and storing the third center seat belt Push the release button on STEP buckle A Buckle A Push either the mechanical STEP key or tab A into buckle B When releasing and storing the seat belt, hold the belt while winding it back gently Buckle B...
Page 79 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Adjusting the height of the belt (front and second outboard seats) Down Move the height adjuster up and down as needed until you hear a click. ITY13C055 Seat belt pretensioners (front and second outboard seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt...
Page 80 1-3. Adjustable components (seats, mirrors, steering wheel) Pre-collision seat belts (front seats of vehicles with pre-collision system) Brake-linked pre-collision system If the system determines that emergency braking is being per- formed or the vehicle is out of control, the front seat belts will retract.(P.
Page 81 ■ Seat belt extender If your seat belts cannot be fastened securely because they are not long enough, personalized seat belt extender is available from your Toyota dealer free of charge. ITY13C060 LC200_OM_OM60L09U_(U)
Page 82 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION Observe the following precautions to reduce the risk of injury in the event of sudden braking, sudden swerving or an accident. Failing to do so may cause death or serious injury. ■ Wearing a seat belt ●...
Page 83 ● If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Toyota dealer. ■ Adjustable shoulder anchor Always make sure the shoulder belt is positioned across the center of your shoulder.
Page 84 ● Do not attempt to install, remove, modify, disassemble or dispose of a seat belt. Have any necessary repairs carried out by your Toyota dealer. Inap- propriate handling of the pretensioner may cause it to activate or operate improperly and may cause death or serious injury.
Page 85 1-3. Adjustable components (seats, mirrors, steering wheel) NOTICE ■ When using a seat belt extender When releasing the seat belt, press on the buckle release button on the extender, not on the seat belt. This helps prevent damage to the vehicle interior and the extender itself. LC200_OM_OM60L09U_(U)
Page 86: Steering Wheel
1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position while the “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode. Down Toward the driver Away from the driver Auto tilt away When “ENGINE...
Page 87 1-3. Adjustable components (seats, mirrors, steering wheel) ■ One-touch adjustment of the steering position A desired steering position can be entered to memory and recalled automat- ically by the driving position memory. (P. 68) CAUTION ■ While driving Do not adjust the steering wheel. Doing so may cause the driver to mishandle the vehicle and an accident, resulting in death or serious injury.
Page 88: Inside Rear View Mirror
1-3. Adjustable components (seats, mirrors, steering wheel) Inside rear view mirror The rear view mirror’s position can be adjusted to enable sufficient confirmation of the rear view in accordance with the driver’s seating posture. Adjusting the height of the rear view mirror Adjust the height of the rear view mirror by moving it up and down.
Page 89 1-3. Adjustable components (seats, mirrors, steering wheel) ■ To prevent sensor error To ensure correct functioning of the sen- sors, do not touch or cover the sensors. CAUTION ■ While driving Do not adjust the position of the mirror. Doing so may lead to mishandling of the vehicle and an accident, or result- ing in death or serious injury.
Page 90: Outside Rear View Mirrors
1-3. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted. Select a mirror to adjust STEP Left Right Adjust the mirror STEP Right Down Left Folding back the mirrors Press the switch Pressing again will extended the mirrors.
Page 91 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Mirror angle can be adjusted when The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode. ■ When the mirrors are fogged up The outside rear view mirrors can be cleared using the mirror defoggers. Turn on the rear window defogger to turn on the outside rear view mirror defoggers.
Page 92 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ While driving Observe the following precautions. Failing to do so may result in losing control of the vehicle and cause an acci- dent, resulting in death or serious injury. ● Do not adjust the mirrors. ●...
Page 93: Opening And Closing The Windows And Moon Roof Power Windows
1-4. Opening and closing the windows and moon roof Power windows The power windows can be opened and closed using the following switches. Closing One-touch closing Opening One-touch opening :To stop the window partway, operate the switch in the opposite direction. Lock switch Press the switch down to lock passenger window switches.
Page 94 The “ENGINE START STOP” switch is in IGNITION ON mode. ■ Door lock linked window operation The following functions can be used if customized at your Toyota dealer. ● The power windows can be opened and closed using the mechanical key.
Page 95 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after performing the above procedure correctly, have the vehicle inspected by your Toyota dealer. ■ Customization Settings (e.g.
Page 96 1-4. Opening and closing the windows and moon roof CAUTION ■ Closing the windows Observe the following precautions. Failing to do so may result in death or serious injury. ● Check to make sure that all passengers do not have any part of their body in a position where it could be caught when a window is being operated.
Page 97: Moon Roof
1-4. Opening and closing the windows and moon roof Moon roof Use the overhead switches to open, close, and tilt the moon roof up and down. ■ Opening and closing Open Stops just before it is opened fully. Press the switch again to fully open.
Page 98 The “ENGINE START STOP” switch is in IGNITION ON mode. ■ Door lock linked moon roof operation The following functions can be used if customized at your Toyota dealer. ● The moon roof can be opened and closed using the mechanical key.
Page 99 Check to make sure that the moon roof is com- pletely closed and then release the switch. If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by your Toyota dealer. LC200_OM_OM60L09U_(U)
Page 100 1-4. Opening and closing the windows and moon roof ■ Moon roof open warning buzzer The buzzer sounds and message is shown on the multi-information display in the instrument panel when the “ENGINE START STOP” switch is turned OFF and the driver’s door is opened with the moon roof open. ■...
Page 101: 1-5. Refueling
1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. ■ Before refueling the vehicle ● Turn the “ENGINE START STOP” switch OFF and ensure that all the doors and windows are closed. ●...
Page 102 1-5. Refueling Closing the fuel tank cap When replacing the fuel tank cap, turn it until a clicking sound is heard. After releasing your hand, the cap will turn slightly to the opposite direction. ■ Fuel types Use unleaded gasoline (Octane Rating 87 [Research Octane Number 91] or higher) LC200_OM_OM60L09U_(U)
Page 103 ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Failure to do so may cause a fire or other incident which may result in death or serious injury.
Page 104 1-5. Refueling NOTICE ■ Refueling Do not spill fuel during refueling. Failing to do so may damage the vehicle, such as causing the exhaust sys- tems to operate abnormally or damaging fuel system components or the vehicle’s painted surface. LC200_OM_OM60L09U_(U)
Page 105: Theft Deterrent System Engine Immobilizer System
1-6. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. Vehicles with navigation system The indicator light flashes after the “ENGINE START STOP”...
Page 106 1-6. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type engine immobilizer system. ■ Conditions that may cause the system to malfunction ● If the key is in contact with a metallic object. ● If the key is in close proximity to or touching a key to the security system (key with a built-in transponder chip) of another vehicle.
Page 107: Alarm
1-6. Theft deterrent system Alarm The system sounds the alarm and flashes lights when forcible entry is detected. ■ Triggering of the alarm The alarm is triggered in the following situations when the alarm is set: ● A locked door is unlocked or opened in any way other than by using the smart key system, the wireless remote control or using the mechanical key.
Page 108 1-6. Theft deterrent system ■ Deactivating or stopping the alarm Do one of the following to deactivate or stop the alarm. ● Unlock the doors. ● Turn the “ENGINE START STOP” switch to ACCESSORY or IGNITION ON mode, or start the engine. (The alarm will be deactivated or stopped after a few seconds.) ■...
Page 109 1-6. Theft deterrent system ■ Triggering of the alarm The alarm may be triggered in the following situations. (Stopping the alarm deactivates the alarm system.) ● A person inside the vehicle opens a door or hood. ● The battery is recharged or replaced when the vehicle is locked.
Page 110 1-6. Theft deterrent system ■ When the battery is disconnected Be sure to cancel the alarm system. If the battery is disconnected before canceling the alarm, the system may be triggered when the battery is reconnected. ■ Alarm-operated door lock ●...
Page 111: Safety Information Correct Driving Posture
1-7. Safety information Correct driving posture Drive with a good posture as follows: Sit upright and well back in the seat. (P. 57) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
Page 112 1-7. Safety information CAUTION ■ While driving ● Do not adjust the position of the driver’s seat. Doing so could cause the driver to lose control of the vehicle. ● Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
Page 113: Srs Airbags
1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
Page 114 1-7. Safety information Side and curtain shield airbags Side airbags Can help protect the torso of the front and second outboard seat occupants. Curtain shield airbags Can help protect primarily the head of front seat occupants, sec- ond and third outboard seat occupants. LC200_OM_OM60L09U_(U)
Page 115 1-7. Safety information Airbag system components Front passenger occupant Side airbags classification system (ECU & (second outboard seats) sensors) Driver airbag Knee airbags Driver’s seat position sensor Curtain shield airbags Driver’s seat belt buckle Front passenger airbag switch “AIR BAG ON” and “AIR BAG Safing sensor (rear) OFF”...
Page 116 1-7. Safety information Your vehicle is equipped with ADVANCED AIRBAGS designed based on the US motor vehicle safety standards (FMVSS208). The airbag sensor assembly (ECU) controls airbag deployment based on infor- mation obtained from the sensors etc. shown in the system compo- nents diagram above.
Page 117 1-7. Safety information ■ SRS airbag deployment conditions (SRS front airbags) ● The SRS front airbag will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approxi- mately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 118 1-7. Safety information ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. ●...
Page 119 1-7. Safety information ■ Types of collisions that may not deploy the SRS airbag (side and curtain shield airbags) The SRS side airbag and curtain shield airbag may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Page 120 1-7. Safety information ■ When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ● The front of the vehicle is damaged or...
Page 121 1-7. Safety information ● The pad section of the steering wheel, dashboard near the front passenger air- bag or lower portion of the instrument panel is scratched, cracked or other- wise damaged. ITY17C016 ● The surface of the seats with the side airbag is scratched, cracked, or other- wise damaged.
Page 122 1-7. Safety information CAUTION ■ SRS airbag precautions Observe the following precautions regarding the SRS airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly.
Page 123 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 124 1-7. Safety information CAUTION ■ SRS airbag precautions ● Do not sit on the edge of the seat or lean against the dashboard. ITY17C021 ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger.
Page 125 1-7. Safety information CAUTION ■ SRS airbag precautions ● Do not attach anything to or lean any- thing against areas such as the dash- board or steering wheel pad or lower portion of the instrument panel. These items can become projectiles when SRS driver, front passenger and knee airbags deploy.
Page 126 Wash off any residue as soon as possible to prevent skin irritation. ● If the areas where the SRS airbags are stored, such as the steering wheel pad and front, center and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. LC200_OM_OM60L09U_(U)
Page 127 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbag may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 128 1-7. Safety information Deactivating the curtain shield airbags in a vehicle rollover ON/OFF (hold for a few sec- onds) The RSCA OFF indicator turns on (only when the “ENGINE START STOP” switch is in IGNITION ON mode.) The roll sensing function for the curtain shield airbags and seat belt pretensioners will turn back on automatically each time the...
Page 129: Front Passenger Occupant Classification System
1-7. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for front passenger. SRS warning light AIR BAG OFF indicator light AIR BAG ON indicator light...
Page 130 1-7. Safety information Condition and operation in the front passenger occupant classi- fication system ■ Adult AIR BAG ON and AIR BAG OFF “AIR BAG indicator lights ON” Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Flashing Front passenger airbag and knee airbag Side airbag in the front passenger seat...
Page 131 1-7. Safety information ■ Unoccupied AIR BAG ON and AIR BAG OFF Not illumi- indicator lights nated Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Front passenger airbag and knee airbag Deactivated Side airbag in the front passenger seat Devices Activated Curtain shield airbag...
Page 132 1-7. Safety information ■ System malfunction AIR BAG ON and AIR BAG OFF “AIR BAG indicator lights OFF” Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Front passenger airbag and knee airbag Deactivated Side airbag in the front passenger seat Devices Curtain shield airbag Activated...
Page 133 1-7. Safety information CAUTION ■ Front passenger occupant classification system precautions Observe the following precautions regarding front passenger occupant clas- sification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger’s seat belt tab has not been left inserted into the buckle before someone sits in the front passenger seat.
Page 134 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction in the detection system. In this case, contact your Toyota dealer immediately. ● Do not use a seat accessory, such as a cushion or seat cover, that covers the seat cushion surface.
Page 135: Child Restraint Systems
1-7. Safety information Child restraint systems A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. now require the use of child restraint systems.
Page 136 1-7. Safety information Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child. Rear facing—Infant seat/convertible seat Forward facing—Convertible seat Booster seat LC200_OM_OM60L09U_(U)
Page 137 1-7. Safety information ■ When installing the child restraint system on the front passenger seat When you have to use a child restraint system on the front passenger seat, adjust the following: ● The seatback to the most upright posi- tion ●...
Page 138 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 139 1-7. Safety information CAUTION ■ Child restraint precautions ● Do not use the seat belt extender when installing a child restraint system on the front or rear passenger seat. If installing a child restraint system with the seat belt extender connected to the seat belt, the seat belt will not securely hold the child restraint system, which could cause death or seri- ous injury to the child or other passengers in the event of a sudden stop, sudden swerve or accident.
Page 140: Installing Child Restraints
1-7. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure the child restraints using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Chil- dren) system.
Page 141 1-7. Safety information Installation with LATCH system Fold the seatback forward and STEP then adjust it as upright as possi- ble. Take off the covers between the STEP seat cushion and seatback, then confirm position LATCH anchors below the sym- bol in the seatback.
Page 142 1-7. Safety information Type A STEP Latch the hooks of the lower straps onto the LATCH anchors. STEP If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor. ITY17C124 Type B STEP...
Page 143 1-7. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing  Infant seat/convertible seat ■ Fold the seatback while pulling STEP the seatback angle lever. Return the seatback and secure it at the first lock position. (P.
Page 144 1-7. Safety information Fully extend the shoulder belt STEP and then allow it to retract slightly in order to activate the ALR lock mode. Lock mode allows the seat belt to retract only. While pushing the child restraint STEP system down into the seat, allow the shoulder belt to retract until the child restraint system is securely in place.
Page 145 1-7. Safety information Forward-facing Convertible seat ■ Fold the seatback while pulling STEP the seatback angle lever. Return the seatback and secure it at the first lock position. (P. 59) Place the child restraint system STEP on the second or third seat fac- ing the front of the vehicle.
Page 146 1-7. Safety information Fully extend the shoulder strap STEP and then allow it to retract slightly into the ALR lock mode. Lock mode allows the seat belt to retract only. While pushing the child restraint STEP system into the seat, allow the shoulder belt to retract until the child restraint system is securely in place.
Page 147 1-7. Safety information ■ Booster seat Fold the seatback while pulling STEP the seatback angle lever. Return the seatback and secure it at the first lock position. (P. 59) Place the child restraint system STEP on the seat facing the front of the vehicle.
Page 148 1-7. Safety information Removing a child restraint system installed with a seat belt Press the buckle release button and fully retract the seat belt. Child restraint systems with a top tether strap STEP Secure the child restraint system using a seat belt or LATCH anchors, and do the following.
Page 149 1-7. Safety information STEP Open the anchor bracket cover, latch the hook onto the anchor bracket and tighten the top tether strap. Outside Make sure the top tether strap is securely latched. Center Outside only: Adjust the head STEP restraint to the downmost posi- tion.
Page 150 1-7. Safety information ■ Laws and regulations pertaining to anchorages The LATCH system conforms to FMVSS225. Child restraint systems conforming to FMVSS213 specifications can be used. This vehicle is designed to conform to the SAE J1819. CAUTION ■ When installing a booster seat Do not fully extend the shoulder belt to prevent the belt from going to ALR lock mode: (P.
Page 151 1-7. Safety information CAUTION ■ When installing a child restraint system Follow the directions given in the child restraint system installation manual and fix the child restraint system securely in place. If the child restraint system is not correctly fixed in place, the child or other passengers may be seriously injured or even killed in the event of sudden braking, sudden swerving or an accident.
Page 152 1-7. Safety information CAUTION ■ When installing a child restraint system ● Ensure that the belt and tab are securely locked and the seat belt is not twisted. ● Shake the child restraint left and right, and forward and back to ensure that it has been securely installed.
Page 153: When Driving
When driving 2-1. Driving procedures 2-4. Using other driving systems Driving the vehicle.... 154 Cruise control....210 Engine (ignition) switch......166 Dynamic radar cruise control ......214 Automatic transmission....171 Intuitive parking assist..229 Turn signal lever ....176 Four-wheel drive system ......
Page 154: 2-1. Driving Procedures
2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. ■ Starting the engine (P. 166) ■ Driving STEP With the brake pedal depressed, shift the shift lever to “D”. (P. 171) STEP Release the parking brake.
Page 155 ● When the brake pedal is depressed while power mode is selected (P. 172) ■ Breaking in your new Toyota To extend the life of the vehicle, the following precautions are recommended to observe: ● For the first 200 miles (300 km): Avoid sudden stops.
Page 156 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or when- ever the parking brake shoes and/or drums are replaced. Have your Toyota dealer perform the bedding down operation.
Page 157 Large amounts of exhaust in the vehi- cle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immediately. LC200_OM_OM60L09U_(U)
Page 158 2-1. Driving procedures CAUTION ● Do not shift the shift lever to “P” while the vehicle is moving. Doing so can damage the transmission and may result in a loss of vehicle control. ● Do not shift the shift lever to “R” while the vehicle is moving forward. Doing so can damage the transmission and may result in a loss of vehicle control.
Page 159 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have your Toyota dealer check and replace the brake pads as soon as pos- sible. Rotor damage may result if the pads are not replaced when needed.
Page 160 2-1. Driving procedures CAUTION ■ When the vehicle is stopped ● Do not race the engine. If the vehicle is in any gear other than “P” or “N”, the vehicle may acceler- ate suddenly and unexpectedly, and may cause an accident. ●...
Page 161 2-1. Driving procedures CAUTION ■ When the vehicle is parked ● Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle when it is in the sun. Failure to do so may result in the following: •...
Page 162 The exhaust should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
Page 163 2-1. Driving procedures CAUTION ■ When braking the vehicle ● When the brakes are wet, drive more cautiously. Braking distance increases when the brakes are wet, and may cause one side of the vehicle to brake differently than the other side. Also the parking brake may not securely hold the vehicle.
Page 164 2-1. Driving procedures NOTICE ■ While driving the vehicle ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain driving torque. ● Do not use the accelerator pedal or depress accelerator and brake pedals together to hold the vehicle on a hill.
Page 165 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following. ● Brake function ●...
Page 166: Engine (Ignition) Switch
2-1. Driving procedures Engine (ignition) switch Performing the following operations when carrying the electronic key on your person starts the engine or changes “ENGINE START STOP” switch modes. ■ Starting the engine STEP Check that the parking brake is set. STEP Check that the shift lever is set in “P”.
Page 167 2-1. Driving procedures ■ Changing “ENGINE START STOP” switch mode Modes can be changed by pressing the “ENGINE START STOP” switch with the brake pedal released. (The mode changes each time the switch is pressed.) Emergency flashers can be used. ACCESSORY mode Some electrical components such as the audio system can...
Page 168 ■ If the engine does not start The engine immobilizer system may not have been deactivated. (P. 105) Contact your Toyota dealer. ■ When the “ENGINE START STOP” switch indicator flashes in amber The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately.
Page 169 2-1. Driving procedures ■ Auto power off function If the vehicle is left in ACCESSORY mode for more than 20 minutes with the shift lever in P, the “ENGINE START STOP” switch will automatically turn off. However, this function cannot entirely prevent battery discharge. Do not leave the vehicle with the “ENGINE START STOP”...
Page 170 ● Do not race a cold engine. ● If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by your Toyota dealer immediately. ■ Symptoms indicating a malfunction with the “ENGINE START STOP” switch If the “ENGINE START STOP” seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction.
Page 171: Automatic Transmission
2-1. Driving procedures Automatic transmission Select a shift position appropriate for the driving conditions. ■ Shifting the shift lever While the “ENGINE START STOP” switch is in IGNITION ON mode, depress the brake pedal and move the shift lever. ■ Shift position uses Shift position Function...
Page 172 2-1. Driving procedures ■ Selecting a driving mode The following patterns can be selected to suit current driving and operating conditions. Power mode For powerful acceleration and driving mountainous regions. Normal mode For normal driving. Second start mode For starting on slippery road surfaces, such as on snow.
Page 173 2-1. Driving procedures Changing shift ranges in “S” mode Shift the shift lever to the “S” position and operate the shift lever. Upshifting Downshifting The initial shift range in “S” mode is automatically set to “5” or “4” according to the vehicle’s speed. However, the initial shift range may be set to “3”...
Page 174 2-1. Driving procedures ■ Shift ranges and their functions ● Automatically selecting gears between 1 and 6 according to vehicle speed and driving conditions. But, the gear is limited according to selected shift range. ● You can choose from 6 levels of engine braking force. ●...
Page 175 If the “S” indicator does not come on even after shifting the shift lever to “S” This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the vehicle will operate as if the shift lever is in “D”.) ■...
Page 176: Turn Signal Lever
2-1. Driving procedures Turn signal lever Right turn Left turn Move and hold the lever partway to signal a lane change The right hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change The left hand signal will flash until you release the lever.
Page 177: Parking Brake
2-1. Driving procedures Parking brake Sets the parking brake Fully set the parking brake while depressing the brake pedal. Releases the parking brake Slightly raise the lever and lower it completely while press- ing the button. ■ Usage in winter time P.
Page 178: Horn
2-1. Driving procedures Horn To sound the horn, press on or close to the mark. LC200_OM_OM60L09U_(U)
Page 179: 2-2. Instrument Cluster
2-2. Instrument cluster Gauges and meters Tachometer Displays the engine speed in revolutions per minute Engine coolant temperature gauge Displays the engine coolant temperature Fuel gauge Displays the quantity of fuel remaining in the tank Speedometer Displays the vehicle speed Voltmeter Displays the charge state Multi-information display...
Page 180 2-2. Instrument cluster Odometer and trip meter Odometer: Displays the total distance the vehicle has been driven Trip meter: Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and display different distances independently.
Page 181 2-2. Instrument cluster Eco Driving Indicator Light customization Eco Driving Indicator Light can activated or deactivated. While the odometer is being dis- STEP played, press and hold the odometer/trip meter display change button to display the Eco Driving Indicator Light customi- zation screen.
Page 182 2-2. Instrument cluster Instrument panel light control The brightness of the instrument panel lights can be adjusted. Darker Brighter ■ The meters and display illuminate when The “ENGINE START STOP” switch is in IGNITION ON mode. ■ The brightness of the instrument panel lights When the tail lights are turned on, the meter’s brightness will be reduced slightly unless the meter brightness level adjustment is set to the brightest setting.
Page 183 When the oil pressure drops even though the engine oil amount has not decreased, or if the oil pressure does not increase when engine oil is added, contact your Toyota dealer, as there may be a problem with the lubrication system.
Page 184: Indicators And Warning Lights
2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. For the purpose of explanation, the following illustration displays all indicators and warning lights illuminated.
Page 185 2-2. Instrument cluster Center panel (vehicles with navigation system) Center panel (vehicles without navigation system) LC200_OM_OM60L09U_(U)
Page 186 2-2. Instrument cluster ■ Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator Eco Driving Indicator (P. 176) Light (P. 156) Roll sensing of curtain Headlight high beam shield airbags off indica- indicator (P.
Page 187 There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer. : The light flashes to indicate that the system is operating.
Page 188 Have the vehicle inspected by your Toyota dealer immediately if this occurs. LC200_OM_OM60L09U_(U)
Page 189: Multi-Information Display
● Tire inflation pressure (P. 190) ● Intuitive parking assist -sensor display (P. 229) Automatically displayed when using toyota parking assist-sensor. ● Dynamic radar cruise control display (if equipped) (P. 214) Automatically displayed when using dynamic radar cruise control. LC200_OM_OM60L09U_(U)
Page 190 2-2. Instrument cluster ● Multi-terrain Select display (P. 251) ● Crawl Control display (P. 245) ● Shift position and shift range (P. 171) Displays the selected shift position or selected shift range. ● Warning messages (P. 619) Automatically displayed when a malfunction occurs in one of the vehi- cle’s system.
Page 191 2-2. Instrument cluster ■ Average fuel consumption after refueling Displays the average fuel consumption since the vehicle was last refueled Use the displayed average fuel consumption as a reference. ■ Current fuel consumption Displays the current rate of fuel consump- tion ■...
Page 192 2-2. Instrument cluster ■ Average vehicle speed Displays the average vehicle speed since the engine was started or the function was reset The function can be reset by pressing the “DISP” switch for longer than 1 second when the average vehicle speed is displayed. ■...
Page 193 2-2. Instrument cluster ■ Turn-by-turn navigation setting screen (vehicles with a navi- gation system) The turn-by-turn navigation can be set to on or off. The function can be activated or deactivated by pressing the “DISP” switch for longer than 1 second when turn-by-turn navigation setting screen is displayed.
Page 194 2-2. Instrument cluster ■ System check display After turning the “ENGINE START STOP” switch to IGNITION ON mode, “LAND CRUISER” is displayed while system operation is checked. When the system check is complete, the normal screen will return. ■ Turn-by-turn navigation (vehicles with navigation system) The turn-by-turn navigation appears only while route guidance of the navigation system is being performed.
Page 195 2-2. Instrument cluster CAUTION ■ The information display at low temperatures Allow the interior of the vehicle to warm up before using the information dis- play. At extremely low temperatures, the information display monitor may respond slowly, and display changes may be delayed. For example, there is a lag between the driver’s shifting and the new gear number appearing on the display.
Page 196: 2-3. Operating The Lights And Wipers
2-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. daytime run- ning lights turn on. side marker, parking, tail, license plate, daytime run- ning lights instrument panel lights turn on. The headlights and all lights listed above (except daytime run- ning lights) turn on.
Page 197 2-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever forward to turn on the high beams. Pull the lever back to the center position to turn the high beams off. Pull the lever toward you to turn on the high beams.
Page 198 2-3. Operating the lights and wipers Manual headlight leveling dial The level of the headlights can be adjusted according to the number of passengers and the loading condition of the vehicle. Raises the level of the head- lights Lowers the level of the head- lights ■...
Page 199 2-3. Operating the lights and wipers ■ Daytime running light system ● To make your vehicle more visible to other drivers, the headlights turn on automatically (at a reduced intensity) whenever the engine is started and the parking brake is released. Daytime running lights are not designed for use at night.
Page 200 2-3. Operating the lights and wipers ■ Automatic light off system ● When the headlights are on: The headlights and tail lights turn off 30 sec- onds after a door is opened and closed if the “ENGINE START STOP” switch has been switched to ACCESSORY or OFF mode. ●...
Page 201: Fog Light Switch
2-3. Operating the lights and wipers Fog light switch The fog lights assist visibility in difficult driving conditions, such as in rain or fog. The fog lights can be used when the headlights are on low beam. Turns the fog lights Turns the fog lights LC200_OM_OM60L09U_(U)
Page 202: Windshield Wipers And Washer
2-3. Operating the lights and wipers Windshield wipers and washer Intermittent windshield wipers with interval adjuster The wiper operation is selected by moving the lever as follows. When intermittent windshield wiper operation is selected, the wiper interval can be also adjusted. Intermittent wind- shield wiper opera-...
Page 203 2-3. Operating the lights and wipers Increases the intermittent windshield wiper frequency Decreases the intermittent windshield wiper frequency Washer/wiper dual opera- tion The wipers will automatically operate a couple of times after the washer squirts. LC200_OM_OM60L09U_(U)
Page 204 2-3. Operating the lights and wipers Rain-sensing windshield wipers When “AUTO” is selected, the wipers will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain volume. When “AUTO” is selected, the sensor sensitivity can be adjusted as follows by turning the switch ring: Rain-sensing wiper operation (“AUTO”)
Page 205 2-3. Operating the lights and wipers Increases the sensitivity Decreases the sensitivity Washer/wiper dual opera- tion The wipers will automatically operate a couple of times after the washer squirts. LC200_OM_OM60L09U_(U)
Page 206 2-3. Operating the lights and wipers ■ The windshield wiper and washer can be operated when The “ENGINE START STOP” switch is in IGNITION ON mode. ■ Effects of vehicle speed on wiper operation (vehicles with rain-sensing windshield wipers) Vehicle speed affects the wiper operation when the washer is being used (delay until drip prevention wiper sweep occurs) even when the wipers are not in “AUTO”...
Page 207 2-3. Operating the lights and wipers CAUTION ■ Caution regarding the use of windshield wipers in “AUTO” mode (vehi- cles with rain-sensing windshield wipers) The windshield wipers may operate unexpectedly if the sensor is touched or the windshield is subject to vibration in “AUTO” mode. Take care that your fingers or anything else do not become caught in the windshield wipers.
Page 208: Rear Window Wiper And Washer
2-3. Operating the lights and wipers Rear window wiper and washer Intermittent window wiper operation Normal window wiper operation Washer/wiper dual operation Washer/wiper dual operation ■ The rear window wiper and washer can be operated when The “ENGINE START STOP” switch is in IGNITION ON mode. NOTICE ■...
Page 209: Headlight Cleaner Switch
2-3. Operating the lights and wipers  Headlight cleaner switch Washer fluid can be sprayed on the headlights. Press the switch to clean the headlights. ITY23C039 ■ The headlight cleaner can be operated when The “ENGINE START STOP” switch is in IGNITION ON mode and the head- light switch is turned on.
Page 210: Using Other Driving Systems Cruise Control
2-4. Using other driving systems  Cruise control Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicators Cruise control switch ■ Setting the vehicle speed STEP Press the “ON-OFF” button to activate the cruise control. Cruise control indicator will come on.
Page 211 2-4. Using other driving systems ■ Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 212 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. LC200_OM_OM60L09U_(U)
Page 213 2-4. Using other driving systems CAUTION ■ To avoid operating the cruise control by mistake Switch the cruise control off using the “ON-OFF” button when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 214: Dynamic Radar Cruise Control
2-4. Using other driving systems  Dynamic radar cruise control Dynamic radar cruise control supplements conventional cruise con- trol with a vehicle-to-vehicle distance control. In vehicle-to-vehicle distance control mode, the vehicle automatically accelerates or decelerates in order to maintain a set following distance from vehi- cles ahead.
Page 215 2-4. Using other driving systems ■ Setting the vehicle speed (vehicle-to-vehicle distance con- trol mode) Press the “ON-OFF” button to STEP activate the cruise control. Dynamic radar cruise control indicator will come on. Press the button again to deactivate the cruise control. Accelerate or decelerate the STEP vehicle to the desired speed,...
Page 216 2-4. Using other driving systems ■ Adjusting the set speed To change the set speed, operate the lever until the desired set speed is displayed. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 217 2-4. Using other driving systems ■ Changing the vehicle-to-vehicle distance Pressing the button changes Preceding vehicle mark vehicle-to-vehicle dis- tance as follows: Long Medium Short The vehicle-to-vehicle distance is set automatically to long mode when “ENGINE START STOP” switch is turned to IGNITION ON mode.
Page 218 2-4. Using other driving systems ■ Canceling and resuming the speed control Pulling the lever toward you cancels the cruise control. The speed setting is also can- celed when the brakes are applied. Pushing lever resumes the cruise control ITI24C010c and returns vehicle speed to the set speed.
Page 219 2-4. Using other driving systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 400 ft. (120 m) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suit- able following distance from the vehicle ahead.
Page 220 2-4. Using other driving systems Example of follow-up cruising When following a vehicle driving slower than the set speed The system continues follow-up cruising while adjusting for changes in the speed of the vehicle ahead in order to maintain the vehicle-to-vehicle dis- tance set by the driver.
Page 221 2-4. Using other driving systems Selecting conventional constant speed control mode Constant speed control mode differs from vehicle-to-vehicle distance control mode. When constant speed control mode is selected, your vehicle will maintain a set speed regardless of whether or not there are other vehicles in the lane ahead.
Page 222 The switching operation continues for 5 seconds or more after the center differential lock switch has been operated. If vehicle-to-vehicle distance control driving is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Toyota dealer. LC200_OM_OM60L09U_(U)
Page 223 2-4. Using other driving systems ■ Automatic cancelation of constant speed control The cruise control will stop maintaining the vehicle speed in the following sit- uations: ● Actual vehicle speed is more than approximately 10 mph (16 km/h) below the set vehicle speed. At this time, the memorized set speed is not retained.
Page 224 2-4. Using other driving systems ■ Certification FCC ID: HYQDNMWR005 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 225 2-4. Using other driving systems CAUTION ■ Before using dynamic radar cruise control Do not overly rely on vehicle-to-vehicle distance control. Be aware of the set speed. If automatic deceleration/acceleration is not appropriate, adjust the vehicle speed, as well as the distance between your vehicle and vehicles ahead by applying the brakes, etc.
Page 226 2-4. Using other driving systems CAUTION ■ Situations unsuitable for dynamic radar cruise control Do not use dynamic radar cruise control in any of the following situations. Doing so may result in inappropriate speed control and could cause an acci- dent resulting in death or serious injury.
Page 227 2-4. Using other driving systems CAUTION ■ When the radar sensor may not be correctly detecting the vehicle ahead Apply the brakes as necessary when any of the following types of vehicles are in front of you. As the sensor may not be able to correctly detect these types of vehicles, the approach warning ( ...
Page 228 If the sensor moves even slightly off position, the system may malfunction. If the sensor or surrounding area is subject to a strong impact, always have the area inspected and adjusted by your Toyota dealer. ● Do not disassemble the sensor.
Page 229: Intuitive Parking Assist
2-4. Using other driving systems Intuitive parking assist The distance from your vehicle to nearby obstacles when parallel parking or maneuvering into a garage is measured by the sensors and communicated via the multi-information display, touch screen and a buzzer. Always check the surrounding area when using this system.
Page 230 Rear center sensor detec- tion ■ Touch screen (vehicles with a navigation system) When the rear view monitor, Toyota parking assist moni- tor or Multi-terrain Monitor is not displayed The graphic is automatically displayed when an obstacle is detected. The screen can be set so that the graphic is not displayed.
Page 231 2-4. Using other driving systems Sensor detection display, obstacle distance ■ Corner sensors Multi- Touch screen Approximate information distance to obstacle Insert display display Front: 1.6 ft. (50 cm) to 1.2 ft. (37.5 cm) Rear: 2.0 ft. (60 cm) to (continuous) (blinking) (continuous)
Page 232 2-4. Using other driving systems ■ Rear center sensors Approximate distance Multi-information Touch screen to obstacle display (insert display) 4.9 ft. (150 cm) to 2.6 ft. (80 cm) (blinking slowly) (continuous) 2.6 ft. (80 cm) to 2.1 ft. (65 cm) (blinking) (continuous) 2.1 ft.
Page 233 2-4. Using other driving systems ■ Buzzer operation and distance to an obstacle A beep sounds when the corner sensors and rear center sensors are operating. ● The buzzer beeps faster as the vehicle approaches an obstacle. When the vehicle comes within the following distance of the obsta- cle, the buzzer sounds continuously: •...
Page 234 2-4. Using other driving systems Detection range of the sensors Approximately 2.0 ft. (60 cm) Approximately 4.9 ft. (150 cm) Approximately 1.6 ft. (50 cm) The diagram shows the detection range of the sensors. Note that the sensors cannot detect obsta- cles that are extremely close to the vehicle.
Page 235 Alert volume setting Display on/off Alert distance setting Make sure to save after chang- ing settings. ■ Alert volume setting The alert volume can be adjusted. STEP Touch “1” to “5” on the “TOYOTA Park Assist settings”. STEP Touch “Save”. LC200_OM_OM60L09U_(U)
Page 236 ■ Intuitive parking assist display When an obstacle is detected while the rear view monitor system, Toyota parking assist monitor or Multi-terrain Monitor is in use, the warning indicator will appear in the top right of the screen even if the display setting has been set to off.
Page 237 • The area directly under the bumpers is not detected. • If obstacles draw too close to the sensor. • A non-genuine Toyota suspension (lowered suspension etc.) is installed. • People may not be detected if they are wearing certain types of cloth- ing.
Page 238 2-4. Using other driving systems ● The shape of the obstacle may prevent the sensor from detecting it. Pay particular attention to the following obstacles: • Wires, fences, ropes, etc. • Cotton, snow and other materials that absorb sound waves •...
Page 239 When using intuitive parking assist In the following situations, the system may not function correctly due to a sensor malfunction etc. Have the vehicle checked by your Toyota dealer. ● A beep does not sound when you turn the main switch on.
Page 240: Four-Wheel Drive System
2-4. Using other driving systems Four-wheel drive system Use the four-wheel drive control switch and center differential lock/ unlock switch to select the following transfer and center differential modes. ■ Four-wheel drive control switch “H4” (high speed position) Normal driving on all types of roads.
Page 241 2-4. Using other driving systems Shifting between “H4”and “L4” ■ Shifting from “H4” to “L4” STEP Stop the vehicle completely. STEP Shift the shift lever to “N”. STEP Push and turn the four-wheel drive control switch fully clock- wise. Maintain this condition until the low speed four-wheel drive indica- tor light turns on.
Page 242 2-4. Using other driving systems ■ The four-wheel drive control switch can be operated when ● The “ENGINE START STOP” switch is in IGNITION ON mode. ● The shift lever is in the “N” position. ● The vehicle is stopped completely. ■...
Page 243 In this case, you may not be able to shift between “H4” and “L4”, and the center differential lock may not be operable. Have the vehicle inspected by your Toyota dealer immediately. LC200_OM_OM60L09U_(U)
Page 244 2-4. Using other driving systems CAUTION ■ While driving Never move the four-wheel drive control switch if the wheels have lost trac- tion. Doing so may cause an accident resulting in death or serious injury. ■ When the vehicle is parked If the shift lever is moved before the low speed four-wheel drive indicator turns on/off, the transfer mode may not be shifted completely.
Page 245: Crawl Control (With Turn Assist Function)
2-4. Using other driving systems Crawl Control (with Turn Assist function) Allows travel on extremely rough off-road surfaces at a fixed low speed without pressing the accelerator or brake pedal. Minimizes loss of traction or vehicle slip when driving on slippery road sur- faces, allowing for stable driving.
Page 246 2-4. Using other driving systems ■ Speed modes The following table shows some typical terrains and the recommended speed modes. Mode Road condition Rock, mogul (downhill) and gravel (downhill) Lo-Med Mogul (uphill) Snow, mud, gravel (uphill), sand, Med-Hi dirt, mogul (uphill) and grass ■...
Page 247 2-4. Using other driving systems When the system is turned off Crawl Control Press the ON/OFF switch while Crawl Control is operating. If the switch is turned off, the slip indicator and the Turn Assist indicator will go off (if the Turn Assist function is in use), the Crawl Control indicator will flash until the system has turned off completely, and a message stating that Crawl Control has been turned off will be dis- played on the multi-information display for several seconds.
Page 248 2-4. Using other driving systems ■ The Crawl Control and Turn Assist function can be operated when Crawl Control ● The engine is running. ● The shift lever is in any gear other than “P” or “N”. ● The four-wheel drive control switch is in “L4”. ●...
Page 249 2-4. Using other driving systems ■ Function limitations Crawl Control ● In the following situations, brake control can be used to drive downhill at a constant speed. However, engine control is not available when driving uphill at a constant speed. •...
Page 250 2-4. Using other driving systems ■ Sounds and vibrations caused by the Crawl Control system ● A sound may be heard from the engine compartment when the engine is started or just after the vehicle begins to move. This sound does not indi- cate that a malfunction has occurred in Crawl Control system.
Page 251: Multi-Terrain Select
2-4. Using other driving systems Multi-terrain Select Multi-terrain Select is a system that assists drivability in off-road sit- uations. Select a mode that most closely matches the type of terrain on which you are driving from among 5 modes. Brake control can be optimized in accordance with the selected mode.
Page 252 2-4. Using other driving systems ■ Selectable modes A mode which matches the road conditions can be selected from among the following 5 modes. MUD & SAND LOOSE ROCK MOGUL ROCK & DIRT ROCK Mode Road Conditions Suitable for muddy roads, sandy roads, snow-covered roads, dirt MUD &...
Page 253 2-4. Using other driving systems ■ Multi-terrain Select control starting conditions When all of the following conditions are satisfied, the Multi-ter- rain Select indicator will come on, the mode select screen will be displayed on the multi-information display, and Multi-terrain Select control will begin.
Page 254 2-4. Using other driving systems Statement on the multi-information display Mode selection Display the Multi-terrain Select mode. The display switches in accor- dance with the pressing of the DISP switch (P. 190) or the conditions of each system. Mode status Display the name of the selected mode.
Page 255 After a short time, the message on the multi-information display will go off, and you will be able to use Multi-terrain Select. ■ When there is a malfunction in the system The slip indicator light will come on. Have the vehicle inspected by your Toyota dealer immediately. LC200_OM_OM60L09U_(U)
Page 256 2-4. Using other driving systems CAUTION ■ When using the Multi-terrain Select Observe the following precautions to avoid an accident that could result in death or serious injuries: ● There is a chance that the selected mode may not be the most appropriate in terms of road conditions such as pitch, slipperiness, undulation, etc.
Page 257: Multi-Terrain Monitor
2-4. Using other driving systems  Multi-terrain Monitor The Multi-terrain Monitor displays the vehicle surroundings when driving at low speeds, thus assisting off-road driving and helping the driver to check the vehicle surroundings. ● By pressing the VIEW switch, the display can be shown, or the display image can be changed between the front screen, wide view front &...
Page 258 Side-rear simultaneous display monitor ● When the shift lever is in “R” If the shift lever is shifted to “R”, the rear monitor (Toyota park- ing assist monitor) will be displayed, and the screen will switch every time the VIEW switch is pressed.
Page 259 2-4. Using other driving systems ■ Automatic display mode In this mode, the screen is switched automatically in response to vehicle speed and shift lever operation, in addition to screen switching by operating the VIEW switch. Touch “AUTO” on the front or wide view front &...
Page 260 2-4. Using other driving systems Range covered by each camera Front monitor Side-front simultaneous dis- play monitor Side-rear simultaneous dis- play monitor Rear monitor :Range of wide view front & side monitor display (The monitor for side displays right side only.) The illustration shown here is an example.
Page 261 2-4. Using other driving systems Display ■ Front monitor The image from the front camera is displayed. Use this monitor to help check the area in front of the vehicle for safety. Guidelines are shown to help determine the course. ■...
Page 262 ■ Rear monitor (Toyota parking assist monitor) The image from the rear camera is displayed. For information regarding the Toyota parking assist monitor, refer to “Naviga- tion System Owner’s Manual”.
Page 263 2-4. Using other driving systems Using the monitor ■ Front monitor Vehicle icon Displays the image being shown by the front monitor. Trajectory line (outside) Indicates the outer path of the tire. Trajectory line (inside) Indicates the inner path of the tire.
Page 264 2-4. Using other driving systems Wide view front & side monitor display Projected course line switch- ing button The course line display mode will change as follows each time the switch is touched. When the shift lever is in “R”, dis- play mode can not be changed.
Page 265 2-4. Using other driving systems Minimum projected turning cir- cle (blue) Displays the smallest turning cir- cle projected by the system if the steering wheel is turned to full lock. Displayed when the steering wheel is turned to the right (fur- ther than 90...
Page 266 2-4. Using other driving systems ■ Side-front simultaneous display monitor Vehicle icon Displays the image being shown by the side-front simultaneous display monitor. Vehicle front edge line Shows the position of the vehi- cle’s front edge. Vehicle width line Indicates the width of the vehicle including the outside rear view mirror.
Page 267 Rear wheel contact point Shows the position of the vehi- cle’s rear tire. Vehicle rear edge line Shows the position of the vehi- cle’s rear edge. ■ Rear monitor (Toyota park assist monitor) Refer to “Navigation System Owner’s Manual”. LC200_OM_OM60L09U_(U)
Page 268 2-4. Using other driving systems Projected course line display mode (Wide view front & side mon- itor display) No course lines mode Vehicle width line displayed. Minimum projected turning circle display mode The minimum projected turning circle line is added to the no course lines mode.
Page 269 2-4. Using other driving systems ■ Switching projected course line display mode Touch Turning course line display mode Minimum projected turning circle display mode No course lines mode ■ Using the vehicle width line & course line Vehicle width line Use the vehicle width line to check the vehicle’s distance from objects such as curbstones etc.
Page 270 2-4. Using other driving systems Minimum projected turning circle & projected course line Use the minimum projected turn- ing circle & projected course line (when displayed) to check the vehicle’s path with relation to obstacles. If the minimum projected turning circle line (blue) is over the obstacle as shown in the illustra- tion, or the obstacle falls within...
Page 271 2-4. Using other driving systems ■ The Multi-terrain Monitor can be operated when Normal display mode The vehicle speed is less than approximately 7 mph (12 km/h). Automatic display mode ●When automatic display mode is selected ●When the shift lever is shifted to “D”, “S” or “N” ●When the shift lever is in “D”, “S”...
Page 272 2-4. Using other driving systems ■ Displayed area The area covered by the camera is limited. Objects which are close to either corner of the bumper or under the bumper cannot be seen on the screen. The area displayed on the screen may vary depending on vehicle orientation or road conditions.
Page 273 2-4. Using other driving systems Side camera (Wide view front & side monitor display) Camera’s field of view Objects visible to the camera Right side of vehicle LC200_OM_OM60L09U_(U)
Page 274 2-4. Using other driving systems Side camera (side-front simultaneous display monitor) Camera’s field of view Objects visible to the camera Right side of vehicle Left side of vehicle LC200_OM_OM60L09U_(U)
Page 275 2-4. Using other driving systems Side camera (side-rear simultaneous display monitor) Camera’s field of view Objects visible to the camera Right side of vehicle Left side of vehicle Rear camera Refer to the “Navigation System Owner’s Manual” LC200_OM_OM60L09U_(U)
Page 276 2-4. Using other driving systems ■ Multi-terrain Monitor cameras Side cameras Front camera Rear camera In the following cases, it may be difficult to see images on the screen even when the system is functioning correctly: ● The vehicle is in a dark area, such as at night. ●...
Page 277 2-4. Using other driving systems ■ Smear effect If a bright light, such as sunlight reflected off the vehicle body, is picked up by the camera, a smear effect characteristic to the camera may occur. : Smear effect  A phenomenon that occurs when a bright light is picked up by the camera;...
Page 278 On the system initial- ization screen, touch the “?” button to display the operating procedure. If this does not resolve the symptom, have the vehicle inspected by your Toyota dealer. LC200_OM_OM60L09U_(U)
Page 279 If the front or the rear of the vehicle or the outside rear view mirror has been hit, the camera’s position and mounting angle may have changed. Have the vehicle inspected by your Toyota dealer. ● As the camera has a water proof construction, do not detach, disassemble or modify it.
Page 280 Conditions which may affect the Multi-terrain Monitor system ● If the tires are changed, the position of the guide lines displayed on the screen may be incorrect. When changing the tires, consult your Toyota dealer. ● Depending on the circumstances of the vehicle (number of passengers, amount of luggage, etc.), the position of the guide lines displayed on the...
Page 281: Driving Assist Systems
2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ■...
Page 282 2-4. Using other driving systems ■ Trailer Sway Control Helps the driver to control trailer sway by selectively applying brake pressure for individual wheels and reducing engine torque when trailer sway is detected. Trailer Sway Control is part of the VSC system and will not operate if VSC turned off or experiences a malfunction.
Page 283 2-4. Using other driving systems To disable Active TRAC and/or VSC and Trailer Sway Control If the vehicle gets stuck in fresh snow or mud, Active TRAC, VSC and Trailer Sway Control may reduce power from the engine to the wheels.
Page 284 TRAC has been disabled even if the VSC OFF switch has not been pressed Active TRAC, hill-start assist control, Crawl Control cannot be operated. Contact your Toyota dealer. ■ Automatic reactivation of Active TRAC, VSC and Trailer Sway Control Turning the “ENGINE START STOP”...
Page 285 2-4. Using other driving systems ■ Sounds and vibrations caused by the Multi Terrain ABS, brake assist, Active TRAC, VSC, Trailer Sway Control, hill-start assist control and VGRS ● A sound may be heard from the engine compartment when the engine is started or just after the vehicle begins to move.
Page 286 2-4. Using other driving systems CAUTION Any of the following conditions may result in an accident which could cause death or serious injury: ■ The Multi Terrain ABS does not operate effectively when ● The limits of tire gripping performance have been exceeded (such as excessively worn tires on a snow covered road).
Page 287 The Multi Terrain ABS, Active TRAC, VSC and Trailer Sway Control will not function correctly if different tires are fitted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■...
Page 288 In the following situations, there is the possibility that a system malfunction has occurred, and drive comfort and the vehicle’s ability to travel on poor road surfaces may be reduced. Take the vehicle to your Toyota dealer imme- diately. ●...
Page 289: Pre-Collision System
2-4. Using other driving systems  Pre-Collision System When a frontal collision seems likely, the system attempts to lessen vehicle’s damage. Two types of pre-collision system are available. The brake-linked pre-collision system operates in conjunction with the braking operation of the driver. The radar type pre-collision sys- tem has a sensor that is used to detect an unavoidable frontal colli- sion.
Page 290 2-4. Using other driving systems Radar sensor (radar type only) Detects vehicles or other obsta- cles on or near the road ahead and determines whether a colli- sion is imminent based on the position, speed, and heading of the obstacles. When traveling on a road with very light traffic and very little to reflect the radar waves emitted by the radar sensor, the system may decide that the radar sensor is dirty, even if the sensor is not actually dirty.
Page 291 2-4. Using other driving systems ■ Obstacles not detected (radar type only) The sensor cannot detect plastic obstacles such as pylons. There may also be occasions when the radar sensor cannot detect pedestrians, animals, bicycles, motorcycles, trees, or snowdrifts. ■ The pre-collision system is operational when ●...
Page 292 2-4. Using other driving systems ■ Conditions that may trigger the system even if there is no possibility of collision ● When there is an object by the roadside at the entrance to a curve ● When passing an oncoming vehicle on a curve ●...
Page 293 2-4. Using other driving systems ■ Situations in which the pre-collision system does not function properly The system may not function effectively in situations such as the following: ● On roads with sharp bends or uneven surfaces ● If a vehicle suddenly moves in front of your vehicle, such as at an inter- section ●...
Page 294 2-4. Using other driving systems ■ Certification (radar type only) FCC ID: HYQDNMWR005 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 295 If the sensor moves even slightly off position, the system may become inaccurate or malfunction. If the sensor or surrounding area are subject to a strong impact, always have the area inspected and adjusted by your Toyota dealer. ● Do not disassemble the sensor.
Page 296: Driving Information Off-Road Precautions
2-5. Driving information Off-road precautions This vehicle belongs to the utility vehicle class, which has higher ground clearance and narrower tread in relation to the height of its center of gravity to make it capable of performing in a wide variety of off-road applications.
Page 297 2-5. Driving information CAUTION ■ Off-road vehicle precautions Always observe the following precautions to help minimize the risk of serious personal injury or damage to your vehicle: ● In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt.
Page 298 2-5. Driving information Off-road driving When driving your vehicle off-road, please observe the following pre- cautions to ensure your driving enjoyment and to help prevent the closure of areas to off-road vehicles. ● Drive your vehicle only in areas where off-road vehicles are permit- ted to travel.
Page 299 2-5. Driving information CAUTION ■ Off-road driving precautions Always observe the following precautions to help minimize the risk of serious personal injury or damage to your vehicle: ● Drive carefully when off the road. Do not take unnecessary risks by driving in dangerous places.
Page 300 2-5. Driving information NOTICE ■ To prevent the water damage Take all necessary safety measures to ensure that water damage to the engine or other components does not occur. ● Water entering the engine air intake will cause severe engine damage. ●...
Page 301: Cargo And Luggage
2-5. Driving information Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load. ● Stow cargo and luggage in the luggage compartment when- ever possible. ● Be sure all items are secured in place. ●...
Page 302 2-5. Driving information Adjusting the position of cross rails (if equipped) Turn the knobs counterclockwise STEP to release the cross rails. ITY25C040 Slide the cross rails to the appro- STEP priate position for loading lug- gage turn knobs clockwise to tighten the cross rails securely.
Page 303 2-5. Driving information Capacity and distribution Cargo capacity depends on the total weight of the occupants. (Cargo capacity) = (Total load capacity) - (Total weight of occupants) Steps for Determining Correct Load Limit— (1) Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs.”...
Page 304 2-5. Driving information Calculation formula for your vehicle Cargo capacity Total load capacity (vehicle capacity weight) (P. 668) When 2 people with the combined weight of A lb. (kg) are riding in your vehicle, which has a total load capacity (vehicle capacity weight) of B lb.
Page 305 2-5. Driving information CAUTION ■ Things that must not be carried in the luggage compartment The following things may cause a fire if loaded in the luggage compart- ment. ● Receptacles containing gasoline ● Aerosol cans ■ Storage precautions Observe the following precautions. Failing to do so may result in death or serious injury.
Page 306 Roof luggage carrier precautions To use the roof rails as a roof luggage carrier, you must fit the roof rails with two or more genuine Toyota cross rails or their equivalent. When you load cargo on the roof luggage carrier, observe the following: ●...
Page 307 2-5. Driving information CAUTION ■ Cross rail adjustment Make sure the cross rails are locked securely by pushing forward and rearward them. Failure to do so may cause an accident or serious injury in the event of emergency braking or a collision. NOTICE ■...
Page 308: Vehicle Load Limits
2-5. Driving information Vehicle load limits Vehicle load limits include total load capacity, seating capacity, TWR (Trailer Weight Rating) and cargo capacity. Total load capacity (vehicle capacity weight): P. 668 ■ Total load capacity means the combined weight of occupants, cargo and luggage.
Page 309: Winter Driving Tips
2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. ■ Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tem- peratures.
Page 310 2-5. Driving information ■ Before driving the vehicle Perform the following according to the driving conditions. ● Do not try to forcibly open a window or move a wiper that is frozen. Pour warm water over the frozen area to melt the ice. Wipe away the water immediately to prevent it from freezing.
Page 311 2-5. Driving information Selection tire chains Use the correct tire chain size when mounting the tire chains. Chain size is regulated for each tire size. Side chain (0.20 in. [5 mm] in diameter) Cross chain (0.25 in. [6.3 mm] in diameter) ITY25C045 Regulations on the use of tire chains ●...
Page 312 2-5. Driving information CAUTION ■ Driving with snow tires Observe the following precautions to reduce the risk of accidents. Failing to do so may result in a loss of vehicle control and cause death or serious injury. ● Use tires of the size specified for your vehicle. ●...
Page 313 NOTICE ■ Repairing or replacing snow tires Request repairs or replacement of snow tires from Toyota dealers or legitimate tire retailers. This is because the removal and attachment of snow tires affects the operation of the tire pressure warning valves and transmitters.
Page 314: Trailer Towing
To tow a trailer safely, use extreme care and drive the vehicle in accordance with your trailer’s characteristics and operating condi- tions. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Contact your Toyota dealer for further information about additional requirements such as towing kits, etc.
Page 315 2-5. Driving information Towing related terms ■ GCWR (Gross Combination Weight Rating) The maximum allowable gross combination weight. The gross combination weight is the sum of the total vehicle weight (including the occupants, cargo and any optional equipment installed on the vehicle) and the weight of the trailer being towed (including the cargo in the trailer).
Page 316 2-5. Driving information ■ GAWR (Gross Axle Weight Rating) The maximum allowable gross Front GAWR axle weight. The gross axle weight is the load placed on each axle (front and rear). Rear GAWR ■ TWR (Trailer Weight Rating) The maximum allowable gross (With brakes) trailer weight.
Page 317 2-5. Driving information ■ Unbraked TWR (Unbraked Trailer Weight Rating) The trailer weight rating for tow- (Without brakes) ing a trailer without a trailer ser- vice brake system. ■ Tongue Weight The load placed on the trailer hitch ball. (P. 320) LC200_OM_OM60L09U_(U)
Page 318 2-5. Driving information Weight limits ● The gross trailer weight must never exceed 8100 lb. (3670 kg) ● The gross combination weight must never exceed 14400 lb. (6532 kg) ● The gross vehicle weight must never exceed the GVWR indi- cated Certification Label.
Page 319 2-5. Driving information GCWR, TWR, Unbraked TWR, Fifth wheel and Gooseneck towing Confirm that the gross trailer weight, gross combination weight, gross vehicle weight, gross axle weight and tongue weight are all within the limits. ■ GCWR 14400 lb. (6532 kg) ■...
Page 320 2-5. Driving information Trailer Tongue Weight ● A recommended tongue weight varies in accordance with the types of trailers or towing as described below. ● To ensure the recommended values shown below, the trailer must be loaded by referring to the following instructions. •...
Page 321 Toyota hitch/bracket for your vehicle. For details, contact your Toyota dealer. ● If you wish to install a trailer hitch, contact your Toyota dealer. ● Use only a hitch that conforms to the gross trailer weight require- ment of your vehicle.
Page 322 2-5. Driving information Selecting trailer ball Use the correct trailer ball for your application. Trailer ball load rating Matches or exceeds the gross trailer weight rating of the trailer. Ball diameter Matches the size of the trailer coupler. Most couplers stamped with the required trailer ball size.
Page 323 2-5. Driving information Positions for towing hitch receiver Hitch receiver pin hole posi- tion: 45.3 in. (1151 mm) Connecting trailer lights Use the wire harness stored in the rear end under the vehicle body. Please consult your dealer when installing trailer lights, as incor- rect installation may cause dam- vehicle’s lights.
Page 324 ● Speed limits for towing a trailer vary by state or province. Do not exceed the posted towing speed limit. ● Toyota recommends that the vehicle-trailer speed limit is 65 mph (104 km/h) on a flat, straight, dry road. Do not exceed this limit, the posted towing speed limit or the speed limit for your trailer as set forth in your trailer owner’s manual, whichever is lowest.
Page 325 2-5. Driving information ● Avoid jerky starts or sudden acceleration. ● Avoid jerky steering and sharp turns, and slow down before mak- ing a turn. ● Note that when making a turn, the trailer wheels will be closer than the vehicle wheels to the inside of the turn. Compensate by making a wider than normal turning radius.
Page 326 2-5. Driving information ● Always place wheel blocks under both the vehicle’s and the trailer’s wheels when parking. Apply the parking brake firmly, and put the transmission in “P”. Avoid parking on a slope, but if unavoidable, do so only after performing the following: STEP Apply the brakes and keep them applied.
Page 327 2-5. Driving information ■ Matching trailer ball height to trailer coupler height No matter which class of tow hitch applies, for a more safe trailer hookup, the trailer ball setup must be the proper height for the coupler on the trailer. Coupler Trailer ball ■...
Page 328 Break-in schedule If your vehicle is new or equipped with any new power train components (such as an engine, transmission, differential or wheel bearing), Toyota rec- ommends that you do not tow a trailer until the vehicle has been driven for over 500 miles (800 km).
Page 329 2-5. Driving information If you cannot find any problems, the speed at which trailer swaying occurred is beyond the limit of your particular vehicle-trailer combination. Drive at a lower speed to prevent instability. Remember that swaying of the towing vehicle-trailer increases as speed increases. CAUTION ■...
Page 330 ■ When towing a trailer Toyota recommends trailers with brakes that conform to any applicable fed- eral and state/provincial regulations. ● If the gross trailer weight exceeds unbraked TWR, trailer brakes are required.
Page 331 2-5. Driving information NOTICE ■ When installing a trailer hitch Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. ■ Do not directly splice trailer lights Do not directly splice trailer lights.
Page 332: Dinghy Towing
2-5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with four wheels on the ground. LC200_OM_OM60L09U_(U)
Page 333 2-5. Driving information LC200_OM_OM60L09U_(U)
Page 334: Interior Features
Interior features 3-1. Using the air conditioning system and defogger Front air conditioning system ......336 Rear air conditioning system ......347 Rear window and outside rear view mirror defoggers ....... 351 Windshield wiper de-icer ......352 3-2. Using the audio system Audio system type....
Page 335 Interior features ® 3-3. Using the Bluetooth 3-6. Using the storage features audio system List of storage features ..466 ® • Glove box....... 467 Bluetooth audio • Console box ....468 system ......402 • Overhead console..469 ® Using the Bluetooth •...
Page 336: Using The Air Conditioning System And Defogger Front Air Conditioning System
3-1. Using the air conditioning system and defogger Front air conditioning system Airflow and outlets are automatically adjusted according to the tem- perature setting. With navigation system Owners of models equipped with a navigation system should refer to the “Navigation System Owner’s Manual”. Without navigation system Driver’s side temperature control Passenger’s side temperature control...
Page 337 3-1. Using the air conditioning system and defogger Using the automatic mode STEP Press The air conditioning system will begin to operate. Air outlets and fan speed are automatically adjusted according to the temperature set- ting. STEP Press “” to increase the temperature and “” to decrease the temperature on The temperature for the driver’s and front passenger’s seats can be set separately.
Page 338 3-1. Using the air conditioning system and defogger Adjusting the settings ■ Adjusting the temperature setting Press “” to increase the temperature and “” to decrease the tem- perature on The air conditioning system switches between individual and simul- taneous modes each time is pressed.
Page 339 3-1. Using the air conditioning system and defogger ■ Changing the air outlets Press For driver’s seat For front passenger’s seat The air outlets switch each time the button is pressed. Different air outlets for the driver’s and front passenger’s seats can be chosen.
Page 340 3-1. Using the air conditioning system and defogger Air flows to the feet. : Depending on the rear air con- ditioning setting. Air flows to the feet and the windshield defogger operates. ITY31C014 ■ Switching between outside air and recirculated air modes Vehicles with windshield wiper de-icer Press The mode switches between outside air mode (indicator off) and...
Page 341 3-1. Using the air conditioning system and defogger Changing the rear seat settings from the front seat ■ Adjusting the temperature setting STEP Press STEP Press “” to increase the temperature and “” to decrease the temperature on (for left-hand rear seat) and (for right-hand rear seat).
Page 342 3-1. Using the air conditioning system and defogger Defogging the windshield Press The air conditioning system con- trol operates automatically. Recirculated air mode will auto- matically switch to outside air mode. FRONT REAR ITY31C023 Micro dust and pollen filter Press Outside air mode switches to recirculated air mode.
Page 343 3-1. Using the air conditioning system and defogger Adjusting the position and opening and closing the air outlets Front center outlets Direct air flow to the left or right, up or down. Turn the knob to open or close the vent. ITY31C030 Front side outlets Direct air flow to the left or...
Page 344 3-1. Using the air conditioning system and defogger ■ Using the automatic mode Fan speed is adjusted automatically in accordance with the temperature set- ting and ambient conditions. As a result, the following may occur. ● Immediately after is pressed, the fan may stop for a while until warm or cool air is ready to flow.
Page 345 ■ Air conditioning filter  P. 560 ■ Customization that can be configured at Toyota dealer Settings (e.g. A/C Auto switch operation) can be changed. (Customizable features P. 694) LC200_OM_OM60L09U_(U)
Page 346 3-1. Using the air conditioning system and defogger CAUTION ■ To prevent the windshield from fogging up Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 347: Rear Air Conditioning System
3-1. Using the air conditioning system and defogger Rear air conditioning system Airflow and outlets are automatically adjusted according to the tem- perature setting. Fan speed display Airflow display Left side temperature setting display Right side temperature setting display Right side temperature control Left side temperature control Changes the air...
Page 348 3-1. Using the air conditioning system and defogger Adjusting the settings ■ Adjusting the temperature setting Press “” to increase the temperature and “” to decrease the tem- perature on The temperature for the right-hand and left-hand rear seats can be set separately.
Page 349 3-1. Using the air conditioning system and defogger ■ Changing the air outlets Press The air outlets switch each time the button is pressed. Air flows to the upper body. ITY31C020 Air flows to the upper body and feet. Air flows to the feet. LC200_OM_OM60L09U_(U)
Page 350 3-1. Using the air conditioning system and defogger Adjusting the position and opening and closing the air outlets Direct air flow to the left or right, up or down. Turn the knob fully to the back of the vehicle to close the vent.
Page 351: Rear Window And Outside Rear View Mirror Defoggers
3-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers These features are used to defog the rear window, and to remove raindrops, dew and frost from the outside rear view mirrors. With navigation system On/off The operation time changes according to the ambient tem-...
Page 352: Windshield Wiper De-Icer
3-1. Using the air conditioning system and defogger  Windshield wiper de-icer This feature is used to prevent ice from building up on the wind- shield and wiper blades. With navigation system On/off The windshield wiper de-icer will automatically turn off after approximately minutes.
Page 353: 3-2. Using The Audio System
3-2. Using the audio system Audio system type With navigation system Owners of models equipped with a navigation system should refer to the “Navigation System Owner’s Manual”. Without navigation system CD player with changer and AM/FM radio. ● Type A LC200_OM_OM60L09U_(U)
Page 354 3-2. Using the audio system ● Type B Title Page Using the radio P. 356 Using the CD player P. 365 Playing back MP3 and WMA discs P. 373 Operating an iPod P. 380 Operating a USB memory P. 387 Optimal use of the audio system P.
Page 355 3-2. Using the audio system ■ Using cellular phones Interference may be heard through the audio system’s speakers if a cellular phone is being used inside or close to the vehicle while the audio system is operating. CAUTION ■ For vehicles sold in the U.S.A. ●...
Page 356: Using The Radio
3-2. Using the audio system Using the radio Type A Station selector Traffic information Seeking the frequency Adjusting the frequency Scanning for receivable stations AM·FM/SAT mode buttons Changing the program type Power Volume LC200_OM_OM60L09U_(U)
Page 357 3-2. Using the audio system Type B Station selector Traffic information Seeking the frequency Adjusting the frequency Scanning for receivable stations AM·FM mode buttons Changing the program type Power Volume LC200_OM_OM60L09U_(U)
Page 358 3-2. Using the audio system ® Setting station presets (excluding XM Satellite Radio) STEP Search for desired stations by turning or pressing “” or “” on STEP Press and hold the button (from ) the sta- tion is to be set to, and you hear a beep. ®...
Page 359 3-2. Using the audio system ® Satellite Radio (type A) ■ ® Receiving XM Satellite Radio STEP Press The display changes as follows each time the button is pressed. “SAT1”  “SAT2”  “SAT3” STEP Turn to select a desired channel from all the categories or press “”...
Page 360 3-2. Using the audio system RDS (Radio Data System) This feature allows your radio to receive station identification informa- tion and program information (classical, jazz, etc.) from radio stations which broadcast this information. ■ Receiving RDS broadcasts STEP Press “” or “” on the during FM reception.
Page 361 3-2. Using the audio system ■ Displaying radio text messages Press If MSG is shown on the display, a text message will be displayed. If the text continues past the end of the display, is displayed. Press and hold until you hear a beep. ■...
Page 362 3-2. Using the audio system ■ ® Receiving XM Satellite Radio ® An XM Satellite Radio is a tuner designed exclusively to receive broadcasts provided under a separate subscription. Availability is limited to the 48 con- tiguous states and some Canadian provinces. ●...
Page 363 XM antenna cable is attached securely. ANTENNA There is a short-circuit in the antenna or the sur- rounding antenna cable. See a Toyota certified dealer. ® You have not subscribed to XM Satellite Radio. The radio is being updated with the latest encryp- ®...
Page 364 3-2. Using the audio system There is no song/program title or artist name/fea- ----- ture associated with the channel at that time. No action needed. The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to CH UNAVL the previous channel or “CH001”.
Page 365: Using The Cd Player
3-2. Using the audio system Using the CD player Display text message Playback/pause Repeat play CD slot CD insert CD eject Random playback Playback Search playback Selecting a track, fast forwarding CD selection or reversing Power Volume Loading a CDs ■...
Page 366 3-2. Using the audio system ■ Loading multiple CDs STEP Press and hold until you hear a beep. “WAIT” appears on the display. STEP Insert a CD when the indicator on the slot turns from amber to green. The display changes from “WAIT” to “LOAD”. The indicator on the slot turns to amber when the CD is inserted.
Page 367 3-2. Using the audio system Selecting a CD ■ To select a CD to play Press “” or “” on until the desired CD number appears on the display. ■ To scan loaded CDs STEP Press and hold until you hear a beep. The first 10 seconds of the first track on each CD will be played.
Page 368 3-2. Using the audio system Random playback ■ Current CD Press (RAND). Tracks are played in random order until the button is pressed once again. ■ All CDs Press and hold (RAND) until you hear a beep. Tracks on all loaded CDs are played in random order until the button is pressed once again.
Page 369 3-2. Using the audio system ■ Display Up to 12 characters can be displayed at a time. If there are 13 characters or more, pressing and holding for 1 sec- ond or more will display the remaining characters. A maximum of 24 characters can be displayed. is pressed for 1 second or more again or has not been pressed for 6 seconds or more, the display will return to the first 12 characters.
Page 370 3-2. Using the audio system ■ Discs that can be used Discs with the marks shown below can be used. Playback may not be possible depending on recording format or disc fea- tures, or due to scratches, dirt or deterioration. CDs with copy-protect features may not play correctly.
Page 371 3-2. Using the audio system NOTICE ■ CDs and adapters that cannot be used Do not use the following types of CDs. Also, do not use 3 in. (8 cm) CD adapters, DualDiscs or printable discs. Doing so may damage the player and/or the CD insert/eject function. ●...
Page 372 3-2. Using the audio system NOTICE ■ Player precautions Failure to follow the precautions below may result in damage to the CDs or the player itself. ● Do not insert anything other than CDs into the CD slot. ● Do not apply oil to the player. ●...
Page 373: Playing Back Mp3 And Wma Discs
3-2. Using the audio system Playing back MP3 and WMA discs Display text message Folder selection Repeat play CD slot CD eject CD insert Playback/pause Random playback Playback File selection Selecting a file, Search playback CD selection fast forwarding or reversing Power Volume Loading and ejecting MP3 and WMA discs...
Page 374 3-2. Using the audio system Selecting and scanning a folder ■ Selecting folders one at a time Press () or () to select the desired folder. To return to the first folder, press and hold () until you hear a beep.
Page 375 3-2. Using the audio system Random playback ■ To play files from a particular folder in random order Press (RAND). ■ To play all of the files on a disc in random order Press and hold (RAND) until you hear a beep. Repeating a file or a folder ■...
Page 376 3-2. Using the audio system ■ Display P. 369 ■ Canceling random, repeat and scan playback Press (RAND), (RPT) or again. ■ Error messages “ERROR”: This indicates a trouble either in the CD or inside the player. The CD may be dirty, damaged or inserted up-side down. “NO MUSIC”: This indicates that the MP3/WMA file is not included in the ■...
Page 377 3-2. Using the audio system ■ Lens cleaners Do not use lens cleaners. Doing so may damage the CD player. ■ MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression.
Page 378 3-2. Using the audio system ● Compatible media Media that can be used for MP3 and WMA playback are CD-Rs and CD- RWs. Playback in some instances may not be possible, depending on the status of the CD-R or CD-RW. Playback may not be possible or the audio may jump if the disc is scratched or marked with fingerprints.
Page 379 3-2. Using the audio system ● MP3 and WMA playback When a disc containing MP3 or WMA files is inserted, all files on the disc are first checked. Once the file check is finished, the first MP3 or WMA file is played.
Page 380: Operating An Ipod
3-2. Using the audio system Operating an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. ■ Connecting an iPod Open the cover and connect STEP an iPod using an iPod cable. Turn on the power of the iPod if it is not turned on.
Page 381 3-2. Using the audio system Selecting a play mode STEP Press to select iPod menu mode. STEP Turning changes the play mode in the following order: “PLAYLISTS”“ARTISTS”“ALBUMS”“SONGS” “PODCASTS”“GENRES”“COMPOSERS” “AUDIOBOOKS” STEP Press to select the desired play mode. LC200_OM_OM60L09U_(U)
Page 382 3-2. Using the audio system ■ Play mode list First Second Third Fourth Play mode selection selection selection selection Playlists Songs “PLAYLISTS” select select Albums Songs “ARTISTS” Artists select select select Albums Songs “ALBUMS” select select Songs “SONGS” select Albums Songs Albums “PODCASTS”...
Page 383 3-2. Using the audio system Selecting songs Turn or press “” or “” on to select the desired song. Playing and pausing songs To play or pause a song, press Fast-forwarding and rewinding songs  To fast-forward or rewind, press and hold “ ”...
Page 384 3-2. Using the audio system Switching the display Press Each time the button is pressed, the display changes in the following order: Elapsed time  Album title  Track title  Artist name Adjusting sound quality and volume balance STEP Press to enter iPod menu mode.
Page 385 3-2. Using the audio system ■ iPod problems To resolve most problems encountered when using your iPod, disconnect your iPod from the vehicle iPod connection and reset it. For instructions on how to reset your iPod, refer to your iPod Owner’s Man- ual.
Page 386 3-2. Using the audio system CAUTION ■ While driving Do not connect iPod or operate the controls. NOTICE ■ To prevent damage to iPod ● Do not leave iPod in the vehicle. The temperature inside the vehicle may become high, resulting in damage to the player. ●...
Page 387: Operating A Usb Memory
3-2. Using the audio system Operating a USB memory Connecting a USB memory enables you to enjoy music from the vehicle speakers. ■ Connecting a USB memory Open the cover and connect a STEP USB memory. Turn on the power of the USB memory if it is not turned on.
Page 388 3-2. Using the audio system Selecting and scanning a folder ■ Selecting folders one at a time Press () or () to select the desired folder. ■ Returning to the first folder Press and hold () until you hear a beep. ■...
Page 389 3-2. Using the audio system Fast-forwarding and rewinding files  To fast-forward or rewind, press and hold “ ” or “” on until you hear a beep. Random playback ■ Playing files from a folder in random order Press (RAND). To cancel, press (RAND) again.
Page 390 3-2. Using the audio system Switching the display Press Each time the button is pressed, the display changes in the following order: Elapsed time  Folder name  File name  Album title  Track title  Artist name ■ When using the USB port You may be unable to use the instrument panel power outlet if a device is connected to the USB port at the same time.
Page 391 3-2. Using the audio system ■ USB memory ● Compatible devices USB memory that can be used for MP3 and WMA playback ● Compatible device formats The following device formats can be used: • USB communication formats: USB2.0 FS (12mbps) •...
Page 392 3-2. Using the audio system ● MP3 file compatibility • Compatible standards MP3 (MPEG1 AUDIO LAYERII, III, MPEG2 AUDIO LAYERII, III, MPEG2.5) • Compatible sampling frequencies MPEG1 AUDIO LAYERII, III: 32, 44.1, 48 (kHz) MPEG2 AUDIO LAYERII, III: 16, 22.05, 24 (kHz) MPEG2.5: 8, 11.025, 12 (kHz) •...
Page 393 3-2. Using the audio system ● MP3 and WMA playback • When a device containing MP3 or WMA files is connected, all files in the USB memory device are checked. Once the file check is finished, the first MP3 or WMA file is played. To make the file check finish more quickly, we recommend that you do not include any files other than MP3 or WMA files or create any unnecessary folders.
Page 394 3-2. Using the audio system NOTICE ■ To prevent damage to USB memory ● Do not leave USB memory in the vehicle. The temperature inside the vehi- cle may become high, resulting in damage to the player. ● Do not push down on or apply unnecessary pressure to the USB memory while it is connected as this may damage the USB memory or its terminal.
Page 395: Optimal Use Of The Audio System
3-2. Using the audio system Optimal use of the audio system Displays the current mode Changes the following set- tings • Sound quality and vol- ume balance The sound quality and bal- ance setting changed to produce the best sound. •...
Page 396 3-2. Using the audio system ■ Adjusting sound quality Turning adjusts the level. Sound quality Mode Turn to the Turn to the Level mode displayed left right Low-pitched -5 to 5 tones Mid-pitched -5 to 5 High tones High pitched -5 to 5 tones Front/rear...
Page 397: Using The Aux Port
3-2. Using the audio system Using the AUX port This port can be used to connect a portable audio device and listen to it using the vehicle’s speakers. Open the cover and connect STEP the portable audio device. STEP Press ■...
Page 398: Using The Steering Switches
3-2. Using the audio system Using the steering switches Some audio features can be controlled using the switches on the steering wheel. Operation may differ depending on the type of audio system or navi- gation system. For details, refer to the manual provided with the audio system or navigation system.
Page 399 3-2. Using the audio system Changing the audio source Press when the audio system is turned on. The audio source changes as follows each time the button is pressed. If a mode cannot be used, it will be skipped. Type A: FM1 ...
Page 400 3-2. Using the audio system Selecting a track/file or song ® STEP Press to select CD, Bluetooth audio, iPod or USB memory mode. STEP Press “” or “” on to select the desired track/file or song. Selecting an album ® STEP Press to select Bluetooth...
Page 401 3-2. Using the audio system ■ Canceling automatic selection of a radio station Press again. CAUTION ■ To reduce the risk of an accident Exercise care when operating the audio switches on the steering wheel. LC200_OM_OM60L09U_(U)
Page 402: Using The Bluetooth
® 3-3. Using the Bluetooth audio system ® Bluetooth audio system ® The Bluetooth audio system enables you to enjoy music played on a portable digital audio player (portable player) from the vehicle speakers via wireless communication. ® This audio system supports Bluetooth , a wireless data system capable of playing portable audio music without cables.
Page 403 Bluetooth audio system. However, please note that some functions may be limited depending on the type of portable player. ® Please go to “http://www.toyota.com/bluetooth” to find approved Bluetooth phones for this system. ■ ® Certification for the Bluetooth...
Page 404 ® 3-3. Using the Bluetooth audio system CAUTION ■ FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radio Frequency Radiation Exposure. This equipment complies with FCC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65.
Page 405 ® 3-3. Using the Bluetooth audio system NOTICE ■ To prevent damage to portable players Do not leave portable players in the vehicle. The temperature inside the vehicle may become high, resulting in damage to the player. LC200_OM_OM60L09U_(U)
Page 406: Using The Bluetooth Audio System
® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio system ■ Audio unit Display A message, name, number, etc. is displayed. Lower-case characters and special characters cannot be displayed. Displays information that is too long to be displayed at one time on the display (press and hold) Selects items such as menu...
Page 407 ® 3-3. Using the Bluetooth audio system Operating the system using voice commands By following voice guidance instructions output from the speaker, ® voice commands enable to the operation of the Bluetooth audio sys- tem without the need to check the display or operate ■...
Page 408 ® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio system for the first time ® Before using the Bluetooth audio system, it is necessary to register ® a Bluetooth enabled portable player in the system. Follow the proce- dure below to register (pair) a portable player: STEP Press...
Page 409 ® 3-3. Using the Bluetooth audio system STEP Select “Confirm” using a voice command or A passkey is displayed and heard, and a voice guidance instruction for inputting the passkey into the portable player is heard. STEP Input the passkey into the portable player. Refer to the manual that comes with the portable player for the oper- ation of the portable player.
Page 410 ® 3-3. Using the Bluetooth audio system ® Menu list of the Bluetooth audio system ■ Normal operation Second First menu Third menu Operation detail menu “Pair Audio” Registering a portable player Selecting a portable player to “Connect” be used Changing the registered “Change Name”...
Page 411 ® 3-3. Using the Bluetooth audio system ■ When using a voice command For numbers, say a combination of single digits from zero to nine. Say the command correctly and clearly. ■ Situations that the system may not recognize your voice ●...
Page 412: Operating A Bluetooth ® Enabled Portable Player
® 3-3. Using the Bluetooth audio system ® Operating a Bluetooth enabled portable player Repeat play Random playback Playback/pause Text button Selecting an album Search playback Playback Selecting a track BT•A menu knob Power Volume Selecting an album To select the desired album, press () or ().
Page 413 ® 3-3. Using the Bluetooth audio system Playing and pausing tracks To play or pause a track, press Fast-forwarding and rewinding tracks  To fast-forward or rewind, press and hold “ ” or “” on until you hear a beep. Random playback Press (RAND).
Page 414 ® 3-3. Using the Bluetooth audio system Switching the display Press Each time the button is pressed, the display changes in the following order: Elapsed time  Album title  Track title  Artist name Using the steering wheel audio switches P.
Page 415: Setting Up A Bluetooth ® Enabled Portable Player
® 3-3. Using the Bluetooth audio system ® Setting up a Bluetooth enabled portable player ® Registering a portable player in the Bluetooth audio system allows the system to function. The following functions can be used for reg- istered portable players: ■...
Page 416 ® 3-3. Using the Bluetooth audio system Pattern B STEP Press to select “BT•A MENU”. STEP Press the talk switch or select “BT•A Setup” using STEP Select one of the following functions using a voice com- mand or ● Registering a portable player “Pair Audio Player (Pair Audio)”...
Page 417 ® 3-3. Using the Bluetooth audio system Registering a portable player Select “Pair Audio Player (Pair Audio)” using a voice command or , and perform the procedure for registering a portable player. (P. 408) Selecting a portable player to be used STEP Select “Connect Audio Player (Connect)”...
Page 418 ® 3-3. Using the Bluetooth audio system Pattern A STEP Press the talk switch and say “From Car” or “From Audio player”, and select “Confirm” by using a voice command or Pattern B STEP Select “From Car” or “From Audio”, using If “From Car”...
Page 419 ® 3-3. Using the Bluetooth audio system Pattern B STEP Select the desired portable player name to be changed using STEP Press the talk switch or select “Record Name” using and say the new name. STEP Select “Confirm” using a voice command or Listing the registered portable players Select “List Audio Players (List Audios)”...
Page 420 ® 3-3. Using the Bluetooth audio system Changing the passkey STEP Select “Set Passkey” using a voice command or Pattern A STEP Press the talk switch, say a 4 to 8-digit number, and select “Confirm” using a voice command or Pattern B STEP Select a 4 to 8-digit number using...
Page 421 ® 3-3. Using the Bluetooth audio system Pattern A STEP Select the portable player to be deleted by either of the follow- ing methods and select “Confirm” using a voice command or a. Press the talk switch and say the name of the desired por- table player.
Page 422: Bluetooth ® Audio System Setup
® 3-3. Using the Bluetooth audio system ® Bluetooth audio system setup ■ System setup items and operation procedures Pattern A To enter the menu for each function, follow the steps below using a voice command or (P. 447) Pattern B STEP Press to select “BT•A MENU”.
Page 423: Using The Hands-Free System (For Cellular Phone)
3-4. Using the hands-free system (for cellular phone) Hands-free system (for cellular phone) The hands-free system is a function that allows you to use your cel- lular phone without touching it. ® This system supports Bluetooth , which allows you to make or receive calls without using cables to connect a cellular phone and the system, and without operating the cellular phone.
Page 424 3-4. Using the hands-free system (for cellular phone) ■ Conditions under which the system will not operate ● ® If using a mobile phone that does not support Bluetooth ● If the mobile phone is switched off ● If you are outside service range ●...
Page 425 If your cellular phone supports OPP alone, you cannot use the ® Bluetooth phone. ® Please go to “http://www.toyota.com/bluetooth” to find approved Bluetooth phones for this system. ■ Certification for the hands-free system FCC ID: AJDK018 MADE IN JAPAN This device complies with Part 15 of the FCC Rules.
Page 426 3-4. Using the hands-free system (for cellular phone) CAUTION ■ FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radio Frequency Radiation Exposure. This equipment complies with FCC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65.
Page 427 3-4. Using the hands-free system (for cellular phone) NOTICE ■ To prevent damage to a cellular phone Do not leave a cellular phone in the vehicle. The temperature inside may become high resulting in damage to the phone. LC200_OM_OM60L09U_(U)
Page 428: Using The Hands-Free System
3-4. Using the hands-free system (for cellular phone) Using the hands-free system ■ Audio unit Display A message, name, phone number, etc. is displayed. Lower-case characters and special characters cannot be displayed. Displays information that is too long to be displayed at one time on the display (press and hold) Selects speed dials...
Page 429 3-4. Using the hands-free system (for cellular phone) ■ Steering wheel Volume The voice guidance volume cannot be adjusted by using this button. Off-hook switch Turns the hands-free sys- tem on/start a call On-hook switch Turns the hands-free sys- tem off/ends a call/refuse a call Talk switch Turns the voice command...
Page 430 3-4. Using the hands-free system (for cellular phone) Operating the system by using a voice command By following voice guidance instructions output from the speaker, voice commands enable to the operation of the hands-free system without need to check the display or operate ■...
Page 431 3-4. Using the hands-free system (for cellular phone) STEP Press the off-hook switch or the talk switch. The introductory guidance and phone name registration instructions are heard. STEP Select “Pair Phone” using a voice command or STEP Register a phone name by either of the following methods. a.
Page 432 3-4. Using the hands-free system (for cellular phone) Menu list of the hands-free system ■ Normal operation Second First menu Third menu Operation detail menu Dialing a number stored in   Callback the incoming call history memory Dialing a number stored in ...
Page 433 3-4. Using the hands-free system (for cellular phone) Second First menu Third menu Operation detail menu Set PIN Setting a PIN code Security Phbk Lock Locking the phone book Phbk Unlock Unlocking the phone book Registering a cellular phone Pair Phone to be used Selecting a cellular phone to Connect...
Page 434 3-4. Using the hands-free system (for cellular phone) ■ Using a short cut key First menu Second menu Operation detail Dialing a number registered  Dial “XXX (name)” in the phone book Phone book add  Adding a new number entry Phone book change Changing a name of a phone...
Page 435 3-4. Using the hands-free system (for cellular phone) ■ Automatic volume adjustment When vehicle speed reaches 50 mph (80 km/h) or more, the volume auto- matically increases. The volume returns to the previous volume setting when vehicle speed drops to 43 mph (70 km/h) or less. ■...
Page 436: Making A Phone Call
3-4. Using the hands-free system (for cellular phone) Making a phone call ■ Making a phone call ● Dialing by inputting a number “Dial by number” ● Dialing by inputting a name “Dial by name” ● Speed dialing ● Dialing a number stored in the outgoing history memory “Redial”...
Page 437 3-4. Using the hands-free system (for cellular phone) Dialing by inputting a number STEP Press the talk switch and say “Dial by number”. STEP Press the talk switch and say the phone number. STEP Dial by one of the following methods: a.
Page 438 3-4. Using the hands-free system (for cellular phone) Speed dialing STEP Press the off-hook switch. STEP Press the preset button in which the desired number is regis- tered. STEP Press the off-hook switch. When receiving a phone call ■ Answering the phone Press the off-hook switch.
Page 439 3-4. Using the hands-free system (for cellular phone) Call waiting When a call is interrupted by an incoming call from a third party, the following options will become available: ● Answer the incoming call: Press the off-hook switch. (Press the off- hook switch again as necessary to switch back and forth between calls.) ●...
Page 440 3-4. Using the hands-free system (for cellular phone) STEP The following operations can be performed: Dialing: Press the off-hook switch or select “Dial” using a voice command or Storing the number in the phone book: Select “Store” and then “Confirm” using a voice command or Deleting: Select “Delete”...
Page 441: Setting A Cellular Phone
3-4. Using the hands-free system (for cellular phone) Setting a cellular phone Registering a cellular phone in the hands-free system allows the system to function. The following functions can be used for regis- tered cellular phones: ■ Functions and operation procedures To enter the menu for each function, follow the steps below.
Page 442 3-4. Using the hands-free system (for cellular phone) Registering a cellular phone Select “Pair Phone” using a voice command or , and perform the procedure for registering a cellular phone. (P. 430) Selecting a cellular phone to be used STEP Select “Connect Phone (Connect)”...
Page 443 3-4. Using the hands-free system (for cellular phone) Changing the registered name of a cellular phone STEP Select “Change Name” using a voice command or Pattern A STEP Select a name of cellular phone to be changed by either of the following methods, and select “Confirm”...
Page 444 3-4. Using the hands-free system (for cellular phone) Listing the registered cellular phones Selecting “List Phones” using a voice command or . The list of registered cellular phones to be read aloud. When listing is complete, the system returns to “Phone Setup”. Pressing the talk switch while a name of cellular phone is being read selects the cellular phone, and the following functions will become available:...
Page 445 3-4. Using the hands-free system (for cellular phone) Changing the passkey STEP Select “Set Passkey” using a voice command or Pattern A STEP Press the talk switch, say a 4 to 8-digit number, and select “Confirm” using a voice command or Pattern B STEP Select a 4 to 8-digit number using...
Page 446 3-4. Using the hands-free system (for cellular phone) Deleting a registered cellular phone STEP Select “Delete Phone” using a voice command or Pattern A STEP Select the cellular phone to be deleted by either of the follow- ing methods and select “Confirm” using a voice command or a.
Page 447: Security And System Setup
3-4. Using the hands-free system (for cellular phone) Security and system setup ■ Security setting items and operation procedure To enter the menu for each function, follow the steps below. STEP Press the off-hook switch and select “Setup” using voice command or STEP Select “Security”...
Page 448 3-4. Using the hands-free system (for cellular phone) ■ System setup items and operation procedure To enter the menu for each function, follow the steps below. STEP Press the off-hook switch and select “Setup” using STEP Select “System Setup” using STEP Select one of the following items using ●...
Page 449 3-4. Using the hands-free system (for cellular phone) Setting or changing the PIN ■ Setting a PIN STEP Select “Set PIN” using a voice command or STEP Enter a PIN using a voice command or When using , input the code 1 digit at a time. ■...
Page 450 3-4. Using the hands-free system (for cellular phone) Locking or unlocking the phone book STEP Select “Phonebook Lock (Phbk Lock)” or “Phonebook Unlock (Phbk Unlock)” using a voice command or STEP Input the PIN by either of the following methods and select “Confirm”...
Page 451 3-4. Using the hands-free system (for cellular phone) ® Displaying the Bluetooth device address and name STEP Select “Device Name” using ® STEP Turn to display the Bluetooth device address and name. STEP Select “Go Back” using to return to “System Setup”. Initializing the system STEP Select “Initialize”...
Page 452 3-4. Using the hands-free system (for cellular phone) ■ Initialization ● The following data in the system can be initialized: • Phone book • Outgoing and incoming call history • Speed dials • Registered cellular phone data • Security code ®...
Page 453: Using The Phone Book
3-4. Using the hands-free system (for cellular phone) Using the phone book To enter the menu for each function, follow the steps below. STEP Press the off-hook switch and select “Phonebook” using voice command or STEP Select one of the following items using voice command or ●...
Page 454 3-4. Using the hands-free system (for cellular phone) Adding a new phone number The following methods can be used to add a new phone number: ● Inputting a phone number using a voice command ● Transferring data from the cellular phone ●...
Page 455 3-4. Using the hands-free system (for cellular phone) Transferring data from the cellular phone STEP2-1 Select “By Phone” and then “Confirm” using a voice command or STEP2-2 Transfer the data from the cellular phone. Refer to the manual that comes with the cellular phone for the details of transferring data.
Page 456 3-4. Using the hands-free system (for cellular phone) Selecting a phone number from outgoing or incoming call history STEP2-1 Select “Call History” using a voice command or STEP2-2 Select “Outgoing” or “Incoming” using a voice com- mand or STEP2-3 Select the data to be registered by either of the fol- lowing methods: a.
Page 457 3-4. Using the hands-free system (for cellular phone) STEP Select “Confirm” using a voice command or again. STEP , selecting “Set Speed Dial (Speed Dial)” instead of “Con- firm” registers the newly added phone number as speed dial. Changing the registered name in the phone book STEP Select “Change Name”...
Page 458 3-4. Using the hands-free system (for cellular phone) Listing the registered data Select “List names” using a voice command or . The list of the registered data will be read aloud. When listing is complete, the system returns to “Phonebook”. Pressing the talk switch while the desired data is being read aloud selects the data, and the following function will become available.
Page 459 3-4. Using the hands-free system (for cellular phone) Pattern A STEP Select the data to be registered as a speed dial by either of the following methods, and select “Confirm” using a voice command or a. Press the talk switch, say desired name. b.
Page 460 3-4. Using the hands-free system (for cellular phone) Deleting the registered data STEP Select “Delete Entry” using a voice command or Pattern A STEP Select the data to be deleted by either of the following meth- ods, and select “Confirm” using a voice command or a.
Page 461 3-4. Using the hands-free system (for cellular phone) Deleting speed dials STEP Select “Delete Speed Dial (Del Spd Dial)” using a voice com- mand or STEP Press the preset button in which the desired speed dial is reg- istered, and select “Confirm” using a voice command or ■...
Page 462: 3-5. Using The Interior Lights
3-5. Using the interior lights Interior lights list Rear interior lights (P. 463) Rear personal lights (P. 464) Front interior light (P. 463) Front personal lights (P. 464) “ENGINE START STOP” switch light Door courtesy lights LC200_OM_OM60L09U_(U)
Page 463: Interior Lights
3-5. Using the interior lights Interior lights Interior lights Front Door position on/off On/off Rear Door position ITY33C008 LC200_OM_OM60L09U_(U)
Page 464: Personal Lights
3-5. Using the interior lights Personal lights Personal lights Front On/off Rear (type A) On/off Rear (type B) On/off ITY33C014 LC200_OM_OM60L09U_(U)
Page 465 3-5. Using the interior lights ■ Illuminated entry system The lights automatically turn on/off according to “ENGINE START STOP” switch mode, the presence of the electronic key, whether the doors are locked/unlocked, and whether the doors are open/closed. ■ To prevent battery discharge If the interior lights remain on when the “ENGINE START STOP”...
Page 466: 3-6. Using The Storage Features
3-6. Using the storage features List of storage features Card holders Door pockets Overhead console Auxiliary boxes Glove box Console box Cool box Bottle holders Cup holders CAUTION ■ Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: ●...
Page 467: Glove Box
3-6. Using the storage features Glove box Glove box Open (push button) Lock with the mechanical key Unlock with the mechanical ■ Glove box light The glove box light turns on when the tail lights are on. ■ Removing the separate tray Pull out the separate tray.
Page 468: Console Box
3-6. Using the storage features Console box Console box Your vehicle is equipped with either a lower console box or cool box. For vehicles with the cool box, refer to page 475. Upper console box Press the tab to open. ITY34C005 Lower console box (if equipped) Lift the lever to open.
Page 469: Overhead Console
3-6. Using the storage features Console box and overhead console CAUTION ■ While driving Keep the console box closed. Injuries may result in the event of sudden braking, sudden swerving or an accident. Overhead console Press the button. The overhead console is useful temporarily storing small...
Page 470: Cup Holders
3-6. Using the storage features Cup holders Cup holders Front (type A) Press down and release the lid. You can adjust or remove the separator inside. ITY34C011 Front (if equipped with type B) Open the lower console box lid. Rear STEP Pull the armrest down.
Page 471 3-6. Using the storage features Cup holders ■ Removing the holder (front cup holders type A) Pull up the holder. CAUTION ■ Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 472: Bottle Holders
3-6. Using the storage features Bottle holders Bottle holders Front seats ITY34C016 Second seats ITY34C024 Third seats LC200_OM_OM60L09U_(U)
Page 473 3-6. Using the storage features Bottle holders NOTICE ■ Items that should not be stowed in the bottle holders Put the cap on before stowing a bottle. Do not place open bottles in the bot- tle holders, or glasses and paper cups containing liquid. The contents may spill and glasses may break.
Page 474: Card Holders
3-6. Using the storage features Card holders and auxiliary boxes Card holders Sun visor Instrument panel Auxiliary boxes ITY34C023 LC200_OM_OM60L09U_(U)
Page 475: 3-7. Other Interior Features
3-7. Other interior features  Cool box While the engine is running, the cool box, which is cooled by the air conditioning, can be used. Lift the lever to open. STEP ITY34C029 On/off STEP When on, the indicator light COOL comes on.
Page 476 3-7. Other interior features CAUTION ■ While driving Keep the cool box closed. Injuries may result in the event of sudden braking, sudden swerving or an accident. NOTICE ■ To prevent battery discharge Do not leave the cool box on longer than necessary when the engine is stopped.
Page 477: Sun Visors
3-7. Other interior features Sun visors Main sun visor Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. Side extender: Place in side position, then slide backwards. Sub-sun visor Flip down with the main sun visor in position LC200_OM_OM60L09U_(U)
Page 478: Vanity Mirror
3-7. Other interior features Vanity mirror Slide the cover. The light turns on when the cover is opened. NOTICE ■ To prevent battery discharge Do not leave the vanity lights on for extended periods while the engine is off. LC200_OM_OM60L09U_(U)
Page 479: Clock
3-7. Other interior features Clock With navigation system Refer to “Navigation System Owner’s Manual”. Without navigation system The clock can be adjusted by pressing the buttons. Adjust hours. Adjust minutes. Round the nearest hour. :e.g. 1:00 to 1:291:00 1:30 to 1:592:00 ■...
Page 480: Outside Temperature Display
3-7. Other interior features Outside temperature display The displayed temperature ranges from -22°F (-30°C) up to 122°F (50°C). Center panel (vehicles with navigation system) Center panel (vehicles without navigation system) LC200_OM_OM60L09U_(U)
Page 481 The “ENGINE START STOP” switch is in IGNITION ON mode. ■ When --- is displayed The system may be malfunctioning. Take your vehicle to your Toyota dealer. ■ Display In the following situations, the correct outside temperature may not be dis- played, or the display may take longer than normal to change.
Page 482: Ashtrays
3-7. Other interior features Ashtrays Front Press in and release the lid to open. Press down on the lock spring plate to remove. Press the lid to close. Rear Pull the ashtray lid to open. Pull the ashtray upwards to remove.
Page 483 3-7. Other interior features CAUTION ■ When not in use Keep the ashtray closed. Injuries may result in the event of sudden braking, sudden swerving or an accident. ■ To prevent fire ● Fully extinguish matches and cigarettes before putting them in the ashtray, then make sure the ashtray is fully closed.
Page 484: Cigarette Lighter
3-7. Other interior features Cigarette lighter Push the cigarette lighter in. The cigarette lighter will pop up when ready for use. ■ The cigarette lighter can be used when The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode.
Page 485: Power Outlets
3-7. Other interior features Power outlets The power outlets can be used for a following component. 12 V: Accessories that run on less than 10 A 120 V AC: Accessories that use less than 100 W Front (12V) Rear (12V) Luggage compartment (120V AC) LC200_OM_OM60L09U_(U)
Page 486 3-7. Other interior features ■ The power outlets can be used when 12V: The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode. 120V: The “ENGINE START STOP” switch is in IGNITION ON mode. ■ When using the instrument panel power outlet You may be unable to use the USB port if a device is connected to the instru- ment panel power outlet at the same time.
Page 487: Heated Steering Wheel
Press the switch to turn the heated steering wheel off and then press the switch again. If the indicator light still flashes, a malfunction may be occur- ring. Turn the heated steering wheel off and have the vehicle inspected by your Toyota dealer.  : If equipped...
Page 488 3-7. Other interior features CAUTION ■ Burns ● Only appropriately qualified and capable non-impaired persons should operate the vehicle. However, care should be taken to prevent injury if anyone in the following categories comes into contact with the steering wheel when the heated steering wheel is on: •...
Page 489: Seat Heaters And Ventilators
3-7. Other interior features Seat heaters and ventilators The seat heaters and ventilators heat the seats and maintain good airflow by blowing air from the seats. ■ Front seat heaters/ventilators Press the knob to release it. Press the knob back in when finished adjusting the tempera- ture or the seat air flow.
Page 490 The seat heaters and ventilators can be used when The “ENGINE START STOP” switch is in IGNITION ON mode. ■ Replacing the air filters Filters are installed in the seat ventilators. For replacement of the filters, con- tact your Toyota dealer. CAUTION ■ Burns ●...
Page 491: Armrest
3-7. Other interior features Armrest Fold down the armrest while pulling the strap. ITY35C052 NOTICE ■ To prevent damage to the armrest Do not place too much strain on the armrest. LC200_OM_OM60L09U_(U)
Page 492: Assist Grips
3-7. Other interior features Assist grips An assist grip (Type A) installed on the ceiling can be used to sup- port your body while sitting on the seat. An assist grip (Type B) installed on the pillar can be used when get- ting in or out of the vehicle and others.
Page 493: Floor Mats
3-7. Other interior features Floor mats Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks STEP (clips) into the floor mat eye- lets.
Page 494 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
Page 495: Luggage Compartment Features
3-7. Other interior features Luggage compartment features ■ Cargo hooks Cargo hooks are provided for securing loose items. ■ Cargo net hooks To hang the cargo net, use the cargo net hooks and rear tie- down hooks. The cargo net itself is not included as an original equip- ment.
Page 496 3-7. Other interior features ■ Warning reflector holder Remove the cover. Hold the warning reflector with bands. The warning reflector itself is not included as an original equipment. ■ First-aid kit holder Remove the cover. Hold the first-aid kit with a band. The first-aid kit itself is not included as an original equip- ment.
Page 497: Garage Door Opener
3-7. Other interior features Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, secu- rity systems, and other devices.  The garage door opener (HomeLink Universal Transceiver) is manufac- ...
Page 498 3-7. Other interior features  ■ Programming HomeLink Point the remote control trans- STEP mitter for the device 1 to 3 in. (25  to 75 mm) from the HomeLink buttons.  Keep the HomeLink indicator light in view while programming. Press and hold one of the STEP ...
Page 499 3-7. Other interior features  Test the HomeLink operation STEP by pressing the newly pro- grammed button.  If a HomeLink button has been programmed for a garage door, check to see if the garage door opens and closes. If the garage door does not operate, see if your remote control transmitter is of the rolling code type.
Page 500 3-7. Other interior features ■ Programming a rolling code system If your device is rolling code equipped, follow the steps under the  heading “Programming HomeLink ” before proceeding with the steps listed below. STEP Locate the learn button on the ceiling mounted garage door opener motor.
Page 501  the remaining HomeLink buttons. ■ Programming other devices To program other devices such as home security systems, home door locks or lighting, contact your authorized Toyota dealer for assistance. ■ Reprogramming a button  The individual HomeLink buttons cannot be erased but can be reprogrammed.
Page 502 3-7. Other interior features  Operating HomeLink   Press the appropriate HomeLink button. The HomeLink indicator light should come on.  The HomeLink compatible transceiver in your vehicle continues to send a signal for up to 20 seconds as long as the button is pressed. ...
Page 503 3-7. Other interior features ■ Before programming ● Install a new battery in the remote control transmitter. ● The battery side of the remote control transmitter must be pointed away  from the HomeLink button. ■ Certification for the garage door opener FCC ID:NZLOBIHL4 FCC ID:NZLWZLHL4 NOTE:...
Page 504: Safety Connect
Telematics Subscription Service Agreement and its Terms and Conditions, as in effect and amended from time to time, a current copy of which is available at Toyota.com. All use of the Safety Con- nect service is subject to such then-applicable Terms and Condi- tions.
Page 505 After you have signed the Telematics Subscription Service Agreement and are enrolled, you can begin receiving services. A variety of subscription terms is available for purchase. Contact your Toyota dealer, call 1-800-331-4331, or push the “SOS” but- ton in your vehicle for further subscription details. LC200_OM_OM60L09U_(U)
Page 506 Safety Connect. ● Safety Connect is available beginning Fall 2009 on select Toyota models. Contact with the Safety Connect response center is dependent upon the telematics device being in operative condition, cellular connection avail- ability, and GPS satellite signal reception, which can limit the ability to reach the response center or receive emergency service support.
Page 507 ● Green indicator light flashing = Safety Connect call in process ● Red indicator light (except at vehicle start-up) = System malfunc- tion (contact your Toyota dealer) ● No indicator light (off) = Safety Connect service not active Safety Connect services ■...
Page 508 In addition to assisting law enforcement with recovery of a stolen vehicle, Safety-Connect-equipped vehicle location data may, under certain circumstances, be shared with third parties to locate your vehicle. Further information is available at Toyota.com. ■ Emergency Assistance Button (“SOS”) In the event of an emergency on the road, push the “SOS”...
Page 509 3-7. Other interior features Safety information for Safety Connect Important! Read this information before using Safety Connect. ■ Exposure to radio frequency signals The Safety Connect system installed in your vehicle is a low-power radio transmitter and receiver. It receives and also sends out radio frequency (RF) signals.
Page 510 3-7. Other interior features ■ Certification for Safety Connect FCC ID: O9EGTM1 FCC ID: O6Y-CDMRF101 FCC ID: N7NGTM2 NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 511: Maintenance And Care
Maintenance and care 4-1. Maintenance and care Cleaning and protecting the vehicle exterior..512 Cleaning and protecting the vehicle interior..515 4-2. Maintenance Maintenance requirements ....518 General maintenance..521 Emission inspection and maintenance (I/M) programs......524 4-3. Do-it-yourself maintenance Do-it-yourself service precautions ....
Page 512: The Vehicle Exterior
4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 513 4-1. Maintenance and care ■ Aluminum wheels ● Remove any dirt immediately by using a neutral detergent. Do not use hard brushes or abrasive cleaners. Do not use strong or harsh chemical cleaners. Use the same mild detergent and wax as used on the paint. ●...
Page 514 4-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 515: Cleaning And Protecting The Vehicle Interior
4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: ■ Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
Page 516 4-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 517 4-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces. • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, or bleach.
Page 518: Maintenance Maintenance Requirements
It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 519 ■ Allow inspection and repairs to be performed by a Toyota dealer ● Toyota technicians are well-trained specialists and are kept up to date with the latest service information.
Page 520 4-2. Maintenance CAUTION ■ If your vehicle is not properly maintained Improper maintenance could result in serious damage to the vehicle and possible death or serious injury. ■ Handling of the battery ● Engine exhaust, some of its constituents, and a wide variety of automobile components contain or emit chemicals known to the State of California to cause cancer and birth defects and other reproductive harm.
Page 521: General Maintenance
“Owner’s Warranty Informa- tion Booklet” “Owner’s Manual Supplement”/Scheduled Maintenance Guide. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items Check points Battery • Maintenance-free (P.
Page 522 4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven Accelerator pedal pedal effort or catching)? • Can the vehicle be hold securely Automatic transmission “Park” on an incline with the shift lever in mechanism “P”? • Moves smoothly? •...
Page 523 4-2. Maintenance Vehicle exterior Items Check points Doors • Operate smoothly? Engine hood • The lock system works properly? • Is there any leakage after park- Fluid leaks ing? • Inflation pressure is correct? • Tire surfaces not worn or dam- aged? Tire •...
Page 524: Emission Inspection And Maintenance (I/M) Programs
If the malfunction indicator lamp comes on The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. ■...
Page 525: Do-It-Yourself Maintenance Do-It-Yourself Service Precautions
Brake fluid level (P. 537) • Rag or paper towel • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid Engine coolant level (P.
Page 526 4-3. Do-it-yourself maintenance Items Parts and tools Headlight aim (P. 580) • Phillips-head screwdriver • Bulb with same number and watt- age rating as original Light bulbs (P. 582) • Phillips-head screwdriver • Flathead screwdriver • Wrench • Automatic transmission fluid ®...
Page 527 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury. ■ When working on the engine compartment ● Keep hands, clothing and tools away from the moving fan and engine drive belt.
Page 528: Hood
4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. STEP The hood will pop up slightly. Lift the hood catch and lift the STEP hood. CAUTION ■ Pre-driving check Check that the hood is fully closed and locked.
Page 529: Engine Compartment
4-3. Do-it-yourself maintenance Engine compartment Power steering fluid reser- Brake fluid reservoir voir (P. 539) (P. 537) Engine oil level dipstick Fuse box (P. 566) (P. 531) Washer fluid tank Engine coolant reservoir (P. 543) (P. 535) Battery (P. 540) Cooling fans Condenser (P.
Page 530 4-3. Do-it-yourself maintenance Engine compartment cover ■ Removing the engine compartment cover ■ Installing the clips Push up center portion Insert Press NOTICE ■ After installing an engine compartment cover Make sure that the cover is securely installed in its original position. LC200_OM_OM60L09U_(U)
Page 531 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil STEP Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 532 4-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. (P. 671) ITY43C011 Make sure to check the oil type and prepare the items needed before adding oil.
Page 533 4-3. Do-it-yourself maintenance ■ Engine oil consumption A certain amount of engine oil will be consumed while driving. In the follow- ing situations, oil consumption may increase, and engine oil may need to be refilled in between oil maintenance intervals. ●...
Page 534 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. ●...
Page 535 If the coolant level drops within a short time after replenishing Visually check the radiator, hoses, reservoir cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer pressure test the cap and check for leaks in the cooling system. ■...
Page 536 Radiator and condenser Check the radiator and condenser and clear any foreign objects. If either of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION ■...
Page 537 4-3. Do-it-yourself maintenance Brake fluid ■ Checking fluid level The brake fluid level should be between the “MAX” and “MIN” lines on the tank. ITY43C069 Make sure to check the fluid type and prepare the necessary items. ■ Adding fluid Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items...
Page 538 4-3. Do-it-yourself maintenance ■ Brake fluid can absorb moisture from the air Excess moisture in the fluid can cause a dangerous loss of braking effi- ciency. Use only newly opened brake fluid. CAUTION ■ When filling the reservoir Take care because brake fluid can harm your hands or eyes and damage painted surfaces.
Page 539 4-3. Do-it-yourself maintenance Power steering fluid ■ Fluid level The fluid level should be within the appropriate range. Full (when hot) Add fluid (when hot) Full (when cold) Add fluid (when cold) ITY43C070 Hot: Vehicle has been driven around 50 mph (80 km/h) for 20 min- utes, or slightly longer in frigid temperatures.
Page 540 4-3. Do-it-yourself maintenance CAUTION ■ When checking the reservoir Take care, as the reservoir may be hot. NOTICE ■ When adding fluid Avoid overfilling, or the power steering may be damaged. ■ After replacing the reservoir cap Check the steering box case, vane pump and hose connections for leaks or damage.
Page 541 4-3. Do-it-yourself maintenance ■ Before recharging When recharging, the battery produces hydrogen gas which is flammable and explosive. Therefore, before recharging: ● If recharging with the battery installed on the vehicle, be sure to discon- nect the ground cable. ● Make sure the power switch on the charger is off when connecting and disconnecting the charger cables to the battery.
Page 542 4-3. Do-it-yourself maintenance CAUTION ■ Where to safely charge the battery Always charge the battery in an open area. Do not charge the battery in a garage or closed room where there is not sufficient ventilation. ■ How to recharge the battery Only perform a slow charge (5A or less).
Page 543 4-3. Do-it-yourself maintenance Washer fluid If any washer does not work or the warning message appears on the multi-information display, the washer tank may be empty. Add washer fluid. CAUTION ■ When refilling the washer fluid Do not refill the washer fluid when the engine is hot or running, as the washer fluid contains alcohol and may catch fire if spilled on the engine etc.
Page 544: Tires
■ The tire pressure warning system Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. (P. 611) LC200_OM_OM60L09U_(U)
Page 545 ID codes must be registered in the tire pressure warning computer and tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (P. 547) Initializing the tire pressure warning system ■...
Page 546 4-3. Do-it-yourself maintenance ■ How to initialize the tire pressure warning system STEP Park the vehicle in safe place and turn the “ENGINE START STOP” switch to OFF. While the vehicle is moving, initialization is not performed. STEP Adjust the tire inflation pressure to the specified cold tire infla- tion pressure level.
Page 547 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly.
Page 548 4-3. Do-it-yourself maintenance ■ Maximum load of tire Check that the number given by dividing the maximum load by 1.10 of the replacement tire is greater than 1/2 of the Gross Axle Weight Ratings (GAWR) of either the front axle or the rear axle, whichever is greater. For the GAWR, see the Certification Label.
Page 549 Initialization can be completed in a few minutes. However, in the follow- ing cases, the settings have not been recorded and the system will not operate properly. If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. ●...
Page 550 4-3. Do-it-yourself maintenance ■ Tire pressure warning system certification FCC ID: PAXPMV107J FCC ID: HYQ13BCX NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 551 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 552 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 553: Tire Inflation Pressure
4-3. Do-it-yourself maintenance Tire inflation pressure ■ Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (P. 676) LC200_OM_OM60L09U_(U)
Page 554 4-3. Do-it-yourself maintenance ■ Inspection and adjustment procedure Tire valve Tire pressure gauge STEP Remove the tire valve cap. STEP Press the tip of the tire pressure gauge onto the tire valve. STEP Read the pressure using the graduations of the gauge. STEP If the tire inflation pressure is not within the recommended levels, adjust tire pressure.
Page 555 Reduced driving comfort and tire life ● Reduced safety ● Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ●...
Page 556 4-3. Do-it-yourself maintenance CAUTION ■ Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. ● Excessive wear ● Uneven wear ●...
Page 557: Wheels
● Bent wheels that have been straightened ■ Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 558 4-3. Do-it-yourself maintenance ■ When replacing wheels The wheels of your Toyota are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advanced warning in the event of a loss in tire inflation pressure.
Page 559 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 560: Air Conditioning Filter
4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be cleaned or changed regularly to maintain air conditioning efficiency. ■ Removal method STEP Turn the “ENGINE START STOP” switch IGNITION ON mode and switch to recirculated air mode, then turn the “ENGINE START STOP”...
Page 561 2 minutes at 72 psi (500 kPa, 5.0 kgf/cm bar). If it is not available, have the filter cleaned by your Toyota dealer. ■ Replacement method Remove the air conditioning filter and replace it with a new one.
Page 562 4-3. Do-it-yourself maintenance ■ Checking interval Inspect, clean and replace the air conditioning filter according to the mainte- nance schedule. In dusty areas or areas with heavy traffic flow, more fre- quent cleaning or early replacement may be required. (For scheduled maintenance information, read the “Scheduled Maintenance Guide”, “Owner’s Manual Supplement”.) ■...
Page 563: Electronic Key Battery
4-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is discharged. ■ You will need the following items: ● Flathead screwdriver (To prevent damage to the key, cover the tip of the screwdriver with rag.) ●...
Page 564 ● The operational range is reduced. ■ Use a CR1632 lithium battery ● Batteries can be purchased at your Toyota dealer, jewelers, or camera stores. ● Replace only with the same or equivalent type recommended by a Toyota dealer. ●...
Page 565 4-3. Do-it-yourself maintenance CAUTION ■ Removed battery and other parts These parts are small and if swallowed by a child, they can cause choking. Keep away from children. Failure to do so could result in death or serious injury. NOTICE ■...
Page 566: Checking And Replacing Fuses
4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. STEP Turn the “ENGINE START STOP” switch OFF. STEP Open the fuse box cover.
Page 567 4-3. Do-it-yourself maintenance Passenger’s side instrument panel Remove the cover. ITY43C033 Remove the lid. ITY43C034 STEP After a system failure, see “Fuse layout and amperage rat- ings” (P. 570) for details about which fuse to check. Remove the fuse with the pull- STEP out tool.
Page 568 4-3. Do-it-yourself maintenance STEP Check if the fuse has blown. Type A and B Normal fuse Type A Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. ITY42C012 Type B ITY42C013...
Page 569 4-3. Do-it-yourself maintenance Type C and D Normal fuse Type C Blown fuse Contact your Toyota dealer. ITY42C014 Type D ITY42C015 LC200_OM_OM60L09U_(U)
Page 570 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings ■ Engine compartment (fuse box on the left side) Fuse Ampere Circuit 15 A A/F heater HORN 10 A Horn EFI MAIN 25 A EFI, A/F heater, fuel pump IG2 MAIN 30 A INJ, IGN, MET RR A/C 50 A...
Page 571 4-3. Do-it-yourself maintenance Fuse Ampere Circuit HWD4 30 A No circuit HWD3 30 A No circuit 50 A No circuit PTC-1 50 A PTC heater PTC-2 50 A PTC heater PTC-3 50 A PTC heater RH-J/B 50 A RH-J/B SUB BATT 40 A Towing VGRS...
Page 572 4-3. Do-it-yourself maintenance Fuse Ampere Circuit ABS2 30 A 30 A Starter system ID code box, smart key system, 7.5 A Main body ECU Vanity lights, overhead module, DOME2 7.5 A rear interior light ECU-B2 Driving position memory system AMP 2 30 A Audio system 7.5 A...
Page 573 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Smart key system, overhead mod- ule, tilt and telescopic steering, ECU-B1 meter, cool box, gateway ECU, steering sensor DOME1 10 A Illuminated entry system, clock HEAD LH 15 A Headlight high beam (left) HEAD LL 15 A Headlight low beam (left) 10 A...
Page 574 4-3. Do-it-yourself maintenance ■ Engine compartment (fuse box on the right side) Fuse Ampere Circuit HWD1 30 A No circuit TOW BRK 30 A Brake controller RR P/SEAT 30 A No circuit PWR HTR 7.5 A No circuit DEICER 20 A Windshield wiper de-icer ALT-CDS 10 A...
Page 575 4-3. Do-it-yourself maintenance ■ Driver’s side instrument panel Fuse Ampere Circuit 15 A Cigarette lighter BK/UP LP 10 A Back-up lights, trailer Audio system, multi-display assembly, main body ECU, 7.5 A mirror ECU, rear seat enter- tainment, smart key system, clock Four-wheel drive system, ash- tray, cigarette lighter, brake...
Page 576 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Air conditioning system, heater, overhead module, ABS, VSC, steering sensor, ECU-IG NO.2 10 A yaw rate & G sensor, main body ECU, stoplights, moon roof, clock, EC mirror WINCH No circuit Cool box, condenser fan, cooler compressor, rear win- A/C IG 10 A...
Page 577 4-3. Do-it-yourself maintenance Fuse Ampere Circuit RR DOOR RH 20 A Power windows Mirror ECU, outside rear view 15 A mirror defoggers RR DOOR LH 20 A Power windows FR DOOR LH 20 A Power windows FR DOOR RH 20 A Power windows RR FOG 7.5 A...
Page 578 4-3. Do-it-yourself maintenance ■ Passenger’s side instrument panel Fuse Ampere Circuit RSF LH 30 A No circuit B/DR CLSR RH 30 A No circuit B/DR CLSR LH 30 A No circuit RSF RH 30 A No circuit DOOR DL 15 A No circuit AHC-B 20 A...
Page 579 Never use a fuse of a higher amperage rating than indicated, or use any other object in place of a fuse. ● Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix. ●...
Page 580: Headlight Aim
4-3. Do-it-yourself maintenance Headlight aim ■ Vertical movement adjustment bolts Adjustment bolt A (Vertical adjustment) Adjustment bolt B (Horizontal adjustment) ■ Before checking the headlight aim STEP Make sure the vehicle has a full tank of gasoline and the area around the headlight is not deformed. STEP Park the vehicle on level ground.
Page 581 Turn bolt B the same number STEP of turns and in the same direc- STEP tion as If the headlight cannot be adjusted using this procedure, take the vehicle to your Toyota dealer to adjust the headlight aim. LC200_OM_OM60L09U_(U)
Page 582: Light Bulbs
You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
Page 583 4-3. Do-it-yourself maintenance ■ Rear bulb locations Rear turn signal Back-up light light License plate lights LC200_OM_OM60L09U_(U)
Page 584 4-3. Do-it-yourself maintenance Replacing light bulbs ■ Headlight high beam and daytime running light Turn the bulb base counterclock- STEP wise. Unplug connector while STEP depressing the lock release. ITY43C041 LC200_OM_OM60L09U_(U)
Page 585 4-3. Do-it-yourself maintenance Replace the light bulb, and install STEP the bulb base. Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the bulb base. STEP Shake the bulb base gently to check that it is not loose, turn the headlights on once and visually confirm that no light is leaking through the mounting.
Page 586 4-3. Do-it-yourself maintenance ■ Fog light Remove the fender liner bolts, STEP loose the fender liner nut and pull down the fender liner. Fender liner bolts Fender liner nut Unplug connector while STEP depressing the lock release. Turn the light bulb counterclock- STEP wise.
Page 587 4-3. Do-it-yourself maintenance Replace the light bulb. STEP Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the light bulb. STEP Install the bulb base. STEP Shake the bulb base gently to check that it is not loose, turn the fog lights on once and visually confirm that no light is leaking through the mounting.
Page 588 4-3. Do-it-yourself maintenance ■ Front turn signal light For the left side only: Remove STEP the securing bolt and move the washer fluid filler opening. ITY43C012 Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP STEP When installing, reverse the steps listed. LC200_OM_OM60L09U_(U)
Page 589 4-3. Do-it-yourself maintenance ■ Front side marker light For the left side only: Remove STEP the securing bolt and move the washer fluid filler opening. ITY43C012 Turn the bulb base counterclock- STEP wise. ITY43C050 Remove the light bulb. STEP ITY43C051 STEP When installing, reverse the steps listed.
Page 590 4-3. Do-it-yourself maintenance ■ Back-up light Open the back door and remove STEP the nuts and lamp assembly. Remove the cover. STEP Unclip the connector wire and STEP turn the bulb bases counter- clockwise. LC200_OM_OM60L09U_(U)
Page 591 4-3. Do-it-yourself maintenance Remove the light bulb. STEP ITY43C054 STEP When installing, reverse the steps listed. LC200_OM_OM60L09U_(U)
Page 592 4-3. Do-it-yourself maintenance ■ Rear turn signal light Open the back door and remove STEP the bolts and lamp assembly. Use a cloth to prevent scratches. Unclip the connector wire. STEP Turn the bulb bases counter- STEP clockwise. LC200_OM_OM60L09U_(U)
Page 593 4-3. Do-it-yourself maintenance Remove the light bulb. STEP STEP When installing, reverse the steps listed. LC200_OM_OM60L09U_(U)
Page 594 4-3. Do-it-yourself maintenance ■ License plate light Open the back door and remove STEP the license plate light unit. Turn the bulb base counterclock- STEP wise. ITY43C067 Remove the light bulb. STEP ITY43C068 STEP When installing, reverse the steps listed. LC200_OM_OM60L09U_(U)
Page 595 The parking light, side turn signal light, stop/tail lights, tail lights, high mounted stoplight and rear side marker lights consist of a number of LEDs. If any LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced.
Page 596 4-3. Do-it-yourself maintenance CAUTION ■ Replacing light bulbs ● Turn off the headlights. Do not attempt to replace the bulb immediately after turning off the headlights. The bulbs become very hot and may cause burns. ● Do not touch the glass portion of the light bulb with bare hands. When it is unavoidable to hold the glass portion, use and hold with a clean dry cloth to avoid getting moisture and oils on the bulb.
Page 597 4-3. Do-it-yourself maintenance CAUTION ■ Discharge headlights ● Contact your Toyota dealer before replacing high-intensity discharge headlights (including light bulbs). ● Do not touch the high-intensity discharge headlight’s high voltage socket when the headlights are turned on. An extremely high voltage of 30000 V will be discharged and could result in serious injury or death by electric shock.
Page 598 4-3. Do-it-yourself maintenance LC200_OM_OM60L09U_(U)
Page 599 When trouble arises 5-1. Essential information 5-2. Steps to take in an emergency Emergency flashers ..600 If a warning light turns on If your vehicle needs to or a warning buzzer be towed ......601 sounds......608 If you think something If a warning message is wrong ......
Page 600: Essential Information Emergency Flashers
5-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.
Page 601: If Your Vehicle Needs To Be Towed
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
Page 602 5-1. Essential information ■ Emergency towing procedure STEP The engine must be in ACCESSORY mode (engine off) or IGNI- TION ON mode (engine running). STEP Put the four-wheel drive control switch in “H4”. (The center differen- tial is unlocked.) STEP Put the shift lever in “N”.
Page 603 5-1. Essential information Towing with a sling-type truck NOTICE ■ To prevent body damage Do not tow with a sling type truck, either from the front or rear. LC200_OM_OM60L09U_(U)
Page 604 5-1. Essential information Towing with a wheel lift-type truck From front Use a towing dolly under the rear wheels. From rear Use a towing dolly under the front wheels. NOTICE ■ To prevent causing serious damage to the transmission Never tow this vehicle wheels on the ground. ■...
Page 605 5-1. Essential information Using a flat bed truck If your Toyota is transported by a flat bed truck, it should be tied down at the locations shown in the illustration. When attaching the hooks to the rear of the vehi- cle, make sure to attach them to the inside of the vehicle.
Page 606: If You Think Something Is Wrong
5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. ■ Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 607: Fuel Pump Shut Off System
5-1. Essential information Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or an air- bag inflates upon collision, the fuel pump shut off system stops sup- plying fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 608: 5-2. Steps To Take In An Emergency
If a light turns on or flashes, but then turns off, this does not necessarily indicate a malfunction in the system. However, if this continues to occur, have the vehicle inspected by your Toyota dealer. Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous.
Page 609 Charging system warning light Indicates a malfunction in the vehicle’s charging system. Have the vehicle inspected by your Toyota dealer immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident.
Page 610 5-2. Steps to take in an emergency Warning light Warning light/Details ABS warning light Malfunction in: • The Multi Terrain ABS; or • The brake assist system. Pre-collision system warning light (if equipped) Indicates: • Malfunction in the pre-collision system if the light comes (Comes on or flashes) •...
Page 611 • Flat tire (P. 635) even if the tire inflation pressure is adjusted, have the system checked by your Toyota dealer. When the light comes on after blinking for 1 minute: Have the system checked Malfunction in the tire by your Toyota dealer.
Page 612 5-2. Steps to take in an emergency Warning light Warning light/Details Correction procedure Low fuel level warning light Indicates that remaining Refuel the vehicle. fuel is about 4.0 gal. (15.0 L, 3.3 Imp. gal.) or less. Master warning light A buzzer sounds and the warning light comes on P.
Page 613 In this case, you may not be able to transfer between “H4” and “L4” modes, and the center differential lock may not be able to be locked or unlocked. Have the vehicle inspected by your Toyota dealer imme- diately.
Page 614 5-2. Steps to take in an emergency ■ SRS warning light This warning light system monitors the following: ● The airbag sensor assembly ● Front impact sensors ● Side impact sensors (rear) ● Side impact sensors (front door) ● Safing sensor (rear) ●...
Page 615 If there is a lot of snow or ice on the vehicle, in particular around the wheels or wheel housings. ● If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ●...
Page 616 1 minute If the tire pressure warning light frequently comes on after blinking for 1 minute when the “ENGINE START STOP” switch is turned to IGNITION ON mode, have it checked by Toyota dealer. CAUTION ■ If the tire pressure warning light comes on Be sure to observe the following precautions.
Page 617 5-2. Steps to take in an emergency CAUTION ■ Maintenance of the tires Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
Page 618 5-2. Steps to take in an emergency CAUTION Your vehicle has also been equipped with a TPMS (tire pressure warning system) malfunction indicator to indicate when the system is not operat- ing properly. The TPMS (tire pressure warning system) malfunction indi- cator is combined with the low tire pressure telltale (tire pressure warning light).
Page 619: If A Warning Message Is Displayed
Multi-information display If any of the warning messages is shown again after its correction procedure has been performed, contact your Toyota dealer. LC200_OM_OM60L09U_(U)
Page 620 Have the vehicle inspected immediately. Failure to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning message Details Indicates a malfunction in the automatic transmission system A buzzer also sounds.
Page 621 5-2. Steps to take in an emergency Warning message Details Indicates a malfunction in the intuitive parking assist The site of malfunction is shown flashing on the display. Indicates a malfunction in the cruise control system Press the “ON-OFF” button once to deactivate the system, and then press the button again to reactivate the system.
Page 622 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning message goes off. Warning message Details Correction procedure Indicates that one or more of the doors is not fully closed The system also indi- cates which doors are...
Page 623 If the light goes off, sion fluid temperature you may start the vehi- is too high cle again. If the light A buzzer also sounds. does not go off, con- tact your Toyota dealer. LC200_OM_OM60L09U_(U)
Page 624 5-2. Steps to take in an emergency Warning message Details Correction procedure Check the level of engine oil, and add if necessary. This message may Indicates that engine appear if the vehicle is oil level is low stopped on a slope. A buzzer also sounds.
Page 625 5-2. Steps to take in an emergency Warning message Details Correction procedure Indicates that all main- tenance according to the driven distance on the maintenance schedule should be If necessary, perform performed soon. maintenance. Comes on approxi- mately 4500 miles (7200 km) after the maintenance data has been reset.
Page 626 5-2. Steps to take in an emergency Warning message Details Correction procedure Indicates that the pre- collision system is not • Check the grille and the currently functional sensor and clean them because the grille or if they are dirty. the sensor is dirty •...
Page 627 5-2. Steps to take in an emergency Warning message Details Correction procedure Indicates that the dynamic radar cruise Clean the sensor. control sensor is dirty or covered with ice (If equipped) • Switch driving mode to Indicates that the either normal or power. dynamic radar cruise •...
Page 628 5-2. Steps to take in an emergency Have the malfunction repaired immediately. After taking the specified steps to correct the suspected problem, check that the warning message and light go off. Interior Exterior Correction Warning message Details buzzer buzzer procedure The electronic key was carried out- side the vehicle...
Page 629 5-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure An attempt was made to start the engine without the electronic key being present, or Start the the electronic key engine with  Once was not function- the elec- ing normally.
Page 630 5-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure The driver’s door was opened when the shift lever was Shift the Contin-  not in “P” and the shift lever uous “ENGINE START to “P”.
Page 631 5-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure • When the doors were unlocked with the mechanical key and then the “ENGINE START Touch the STOP” switch was electronic pressed, the elec- key to the tronic key could “ENGINE...
Page 632 5-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure A door was opened and closed Press the with the “ENGINE “ENGINE START STOP” START switch turned off STOP” and then the  Once switch “ENGINE START while...
Page 633 5-2. Steps to take in an emergency Other messages If the following message is displayed, take appropriate action and confirm that the message has disappeared. (P. 245) Message Correction procedure Select the four-wheel drive control switch in L4 and shift the shift lever to “D” or “R”. Confirm the operating conditions.
Page 634 Resetting the tire pressure warning data After adjusting the tire inflation pressure, be sure to initialize the data. (P. 545) If the message remains on, the system may have malfunctioned. Have the vehicle inspected by your Toyota dealer as soon as possible. LC200_OM_OM60L09U_(U)
Page 635: If You Have A Flat Tire
5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. ■ Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ● Set the parking brake. ●...
Page 636 5-2. Steps to take in an emergency Taking out the jack Remove the cover. STEP Unhook the rubber band and STEP take out the jack. Loosen Tighten Loosen and remove the jack. LC200_OM_OM60L09U_(U)
Page 637 5-2. Steps to take in an emergency Taking out the tool box Remove the cover. STEP Take out the tool box. STEP LC200_OM_OM60L09U_(U)
Page 638 5-2. Steps to take in an emergency Taking out the spare tire STEP Assembling the jack handle. Remove the jack handle and the jack extension bar from the tool box and assemble by following these steps. Loosen the screw using a screwdriver.
Page 639 5-2. Steps to take in an emergency Open the cover. STEP Insert the jack handle extension STEP into the lowering screw. Lower Raise Place a rag under the jack han- dle extension to protect the back door. Lower the spare tire completely STEP to the ground.
Page 640 5-2. Steps to take in an emergency Pull out the spare tire and STEP remove the holding bracket. Replacing a flat tire Chock the tires. STEP Flat tire Wheel chock position Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side...
Page 641 5-2. Steps to take in an emergency Pry off the wheel ornament, STEP using the beveled end of the wheel ornament remover as shown. Slightly loosen the wheel nuts STEP (one turn). LC200_OM_OM60L09U_(U)
Page 642 5-2. Steps to take in an emergency STEP Assembling the jack handle. Remove the jack handle, jack extension bar and jack handle bar from the tool box and assemble by following these steps. Loosen the bolts and the screw using either the jack handle or a screwdriver.
Page 643 5-2. Steps to take in an emergency Position the jack at the jack STEP points as shown. Front - Under the chassis frame side rail Rear - Under the rear axle hous- Raise the vehicle until the tire is STEP slightly raised off the ground.
Page 644 5-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- STEP ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
Page 645 5-2. Steps to take in an emergency Firmly tighten each nut two or STEP three times in the order shown in the illustration. Tightening torque: 97 ft•lbf (131 N•m, 13.4 kgf•m) Reinstall the wheel ornament. STEP Stowing the flat/spare tire, jack and tools Lay down the tire with the outer STEP side facing up, and install the...
Page 646 5-2. Steps to take in an emergency ■ After completing the tire change The tire pressure warning system must be reset. (P. 545) CAUTION ■ Using the tire jack Improper use of the tire jack may lead to death or serious injuries due to the vehicle suddenly falling off the jack.
Page 647 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • Do not attach a heavily damaged wheel ornament, as it may fly off the wheel while the vehicle is moving.
Page 648 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 649: If The Engine Will Not Start
5-2. Steps to take in an emergency If the engine will not start If the engine still does not start after following the correct starting procedure (P. 166) or releasing the steering lock (P. 168), confirm the following points. ■ The engine will not start when the starter motor operates normally One of the following may be the cause of the problem.
Page 650 ● One or both of the battery terminals may be disconnected. ● The battery may be discharged. (P. 656) ● There may be a malfunction in the steering lock system. Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function When the engine does not start, the following steps can be used as an interim measure to start the engine if the “ENGINE START STOP”...
Page 651: If The Shift Lever Cannot Be Shifted From P
(a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
Page 652: If You Lose Your Keys
5-2. Steps to take in an emergency If you lose your keys New genuine Toyota keys can be made by your Toyota dealer using the other key and the key number stamped on your key number plate. LC200_OM_OM60L09U_(U)
Page 653: If The Electronic Key Does Not Operate Properly
(turn and hold) Unlocks all doors Turning rearward unlocks driver’s door. Turning the key once again unlocks the other doors. Opens the windows/moon roof (turn and hold) : This setting must be customized at your Toyota dealer. LC200_OM_OM60L09U_(U)
Page 654 5-2. Steps to take in an emergency Starting the engine STEP Shift the shift lever to “P” and apply the brakes. Touch the Toyota emblem side of STEP electronic “ENGINE START STOP” switch. An alarm will sound to indicate that the start function cannot detect the electronic key that is touched to the “ENGINE START...
Page 655 5-2. Steps to take in an emergency ■ Stopping the engine Shift the shift lever to “P” and press the “ENGINE START STOP” switch as you normally do when stopping the engine. ■ Replacing the key battery As this above procedure is a temporary measure, it is recommended that the electronic key battery be replaced immediately when the battery depletes.
Page 656: If The Battery Is Discharged
You can also call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12 volt battery, you can jump start your Toyota following the steps below.
Page 657 Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. ■ Starting the engine when the battery is discharged The engine cannot be started by push-starting.
Page 658 5-2. Steps to take in an emergency CAUTION ■ Avoiding battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery. ● Make sure the jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any part other than the intended termi- nal.
Page 659: If Your Vehicle Overheats
If you do not see steam: Carefully lift the hood. After the engine has cooled STEP down sufficiently, inspect the hoses and radiator core (radia- tor) for any leaks. Radiator Cooling fans If a large amount of coolant leaks, immediately contact your Toyota dealer. LC200_OM_OM60L09U_(U)
Page 660 (The fans may not operate in freezing temperatures.) STEP If the fans are not operating: Stop the engine immediately and contact your Toyota dealer. If the fans are operating: Have the vehicle inspected at the nearest Toyota dealer. LC200_OM_OM60L09U_(U)
Page 661 5-2. Steps to take in an emergency CAUTION ■ To prevent an accident or injury when inspecting under the hood of your vehicle ● If steam is seen coming from under the hood, do not open the hood until the steam has subsided. The engine compartment may be very hot, caus- ing serious injury such as burns.
Page 662: If The Vehicle Becomes Stuck
5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. STEP Stop the engine. Set the parking brake and shift the shift lever to “P”.
Page 663 5-2. Steps to take in an emergency CAUTION ■ When attempting to free a stuck vehicle If you choose to push the vehicle back and forth to free it, make sure the sur- rounding area is clear, to avoid striking other vehicles, objects or people. The vehicle may also lunge forward or lunge back suddenly as it becomes free.
Page 664: If Your Vehicle Has To Be Stopped In An Emergency
5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: STEP Steadily step on the brake pedal with both feet and firmly...
Page 665 5-2. Steps to take in an emergency CAUTION ■ If the engine has to be turned off while driving Power assist for the brakes and steering wheel will be lost, making the brake pedal harder to depress and the steering wheel heavier to turn. Decelerate as much as possible before turning off the engine.
Page 666 5-2. Steps to take in an emergency LC200_OM_OM60L09U_(U)
Page 667 Vehicle specifications 6-1. Specifications Maintenance data (fuel, oil level, etc.) ..668 Fuel information ....678 Tire information ....682 6-2. Customization Customizable features ..694 6-3. Initialization Items to initialize ....703 LC200_OM_OM60L09U_(U)
Page 668: Maintenance Data (Fuel, Oil Level, Etc.)
6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights Overall length 196.5 in. (4990 mm) Overall width 77.6 in. (1970 mm) 74.0 in. (1880 mm) Overall height 76.2 in. (1935 mm) Wheelbase 112.2 in. (2850 mm) Front 64.6 in. (1640 mm) Tread Rear 64.4 in.
Page 669 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 670 6-1. Specifications Engine Model 5.7L V8 (3UR-FE) Type 8-cylinder V type, 4-cycle, gasoline 3.70  4.02 in. (94.0  102.0 mm) Bore and stroke Displacement 345.6 cu.in. (5663 cm Valve clearance Automatic adjustment Drive belt tension Fuel Fuel type Unleaded gasoline only Octane rating 87 (Research octane number 91) or higher Fuel tank capacity...
Page 671 ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil...
Page 672 6-1. Specifications Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 673 6-1. Specifications Cooling system Capacity 17.6 qt. (16.7 L, 14.7 Imp.qt.) Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol- based non-silicate, non-amine, non- Coolant type nitrite, and non-borate coolant with long-life hybrid organic acid technol- Do not use plain water alone.
Page 674 Oil type and viscosity 75W-85 or equivalent Your Toyota vehicle is filled with “Toyota Genuine Differential Oil” at the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equivalent of matching quality to satisfy the above specification. Please contact your Toyota dealer for further details.
Page 675 Recommended oil viscosity SAE 75W : Your Toyota vehicle is filled with “Toyota Genuine Transfer Gear oil LF” at the factory. Use Toyota approved “Toyota Genuine Transfer Gear oil LF” or an equivalent of matching quality to satisfy the above specification. Please contact your Toyota dealer for further details.
Page 676 6-1. Specifications Steering Free play Less than 1.18 in. (30 mm) ® Automatic transmission fluid DEXRON Power steering fluid type or III Tires and wheels Tire size P285/60R18 114V Front tires: 33 psi (230 kPa, 2.3 kgf/cm or bar) Tire inflation pressure Rear tires: (Recommended cold tire 33 psi (230 kPa, 2.3 kgf/cm...
Page 677 6-1. Specifications Light bulbs Light bulbs Bulb No. Type Headlights  Low beam High beam 9005 Front turn signal lights 7444NA  Front side marker lights Exterior  Fog lights  Rear turn signal lights Back-up lights  License plate lights ...
Page 678: Fuel Information
ASTM D4814 in the U.S.A. ■ Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. ■ If your engine knocks ●...
Page 679 EPA’s lowest additives con- centration program. ● Toyota strongly recommends the use of Top Tier Detergent Gasoline. For more information on Top Tier Detergent Gasoline and a list of marketers, please go to the official website www.toptiergas.com.
Page 680 10% ethanol). (85% ethanol) ● If you use gasohol in your Toyota, be sure that it has an octane rating no lower than 87. ● Toyota DOES NOT recommend the use of gasoline containing methanol.
Page 681 6-1. Specifications NOTICE ■ Notice on fuel quality ● Do not use improper fuels. If improper fuels are used the engine will be damaged. ● Do not use leaded gasoline. Leaded gasoline can cause damage to your vehicle’s three-way catalytic converters causing the emission control system to malfunction.
Page 682: Tire Information
6-1. Specifications Tire information Typical tire symbols Tire size (P. 684) Summer tire or all season tire (P. 548) An all season tire has “M+S” on the sidewall. A tire not marked “M+S” is a summer tire. Uniform tire quality grading For details, see “Uniform Tire Quality Grading”...
Page 683 6-1. Specifications Maximum cold tire inflation pressure (P. 687) This means the pressure to which a tire may be inflated. TUBELESS or TUBE TYPE A tubeless tire does not have a tube and air is directly filled in the tire. A tube type tire has a tube inside the tire and the tube main- tains the air pressure.
Page 684 6-1. Specifications Tire size ■ Typical tire size information The illustration indicates typical tire size. Tire use P285/60R18 114V (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio ITY61C011 (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 or 3 digits)
Page 685 U.S.A. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Requirements in addition to these grades.
Page 686 6-1. Specifications ■ Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and a half (1 - 1/2) times as well on the government course as a tire graded 100.
Page 687 6-1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either sepa- rately or in combination, can cause heat buildup and possible tire fail- ure.
Page 688 6-1. Specifications Tire related term Meaning 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 that weight follows Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below The combined weight of installed regular pro- duction options weighing over 5 lb.
Page 689 6-1. Specifications Tire related term Meaning The load on an individual tire that is determined by distributing to each axle its share of curb Vehicle normal load weight, accessory weight, and normal occu- on the tire pant weight (distributed in accordance with Table 1 below), and dividing by two The surface area of the rim not covered by the...
Page 690 6-1. Specifications Tire related term Meaning A tire designed to operate at higher loads and Extra load tire at higher inflation pressures than the corre- sponding standard tire Groove The space between two adjacent tread ribs The layer(s) forming the inside surface of a Innerliner tubeless tire that contains the inflating medium within the tire...
Page 691 6-1. Specifications Tire related term Meaning The linear distance between the exteriors of the sidewalls of an inflated tire, including eleva- Overall width tions due to labeling, decorations, or protective bands or ribs A tire intended for use on passenger cars, mul- tipurpose passenger vehicles, and trucks, that Passenger car tire have a gross vehicle weight rating (GVWR) of...
Page 692 6-1. Specifications Tire related term Meaning A tire that attains a traction index equal to or greater than 110, compared to the ASTM E- 1136 Standard Reference Test Tire, when using the snow traction test as described in ASTM F-1805-00, Standard Test Method for Snow tire Single Wheel Driving Traction in a Straight Line on Snow-and Ice-Covered Surfaces, and which...
Page 693 6-1. Specifications : Table 1  Occupant loading and distribution for vehicle normal load for various designated seating capacities Designated seating Occupant distribution in Vehicle normal load, capacity, Number of a normally loaded Number of occupants occupants vehicle 2 through 4 2 in front 2 in front, 1 in second 5 through 10...
Page 694: Customization Customizable Features
Customizable features Your vehicle includes a variety of electronic features that can be per- sonalized to your preferences. Programming of these preferences can be performed by your Toyota dealer. For vehicles with the navigation system, it is also possible to cus- tomize certain vehicle features yourself using the touch screen.
Page 695 6-2. Customization Customizable features Vehicle customization settings can be changed at your Toyota dealer. For vehicles with the navigation system, some settings can be changed using the touch screen. Settings that can be changed using the touch screen Settings that can be changed using the vehicle switches Settings that can be changed by your Toyota dealer Definition of symbols: O= Available, —...
Page 696 6-2. Customization Default Customized Item Function setting setting Wireless remote — — O control Open door warn- ing function — — O Wireless (when locking the remote vehicle) control Driver’s door (P. 44) unlocked in All doors Unlocking opera- one step, all unlocked in O —...
Page 697 6-2. Customization Default Customized Item Function setting setting Driver’s door unlocked in All doors Unlocking using a one step, all unlocked in O — O mechanical key doors one step unlocked in two steps Speed-detecting automatic door O O O lock function Door lock Shifting the shift...
Page 698 6-2. Customization Default Customized Item Function setting setting Mechanical key linked operation — — O (open) Mechanical key linked operation — — O (close) Linked operation of components Slide only Tilt only — — O when door key is used Moon roof Wireless remote (P.
Page 699 6-2. Customization Default Customized Item Function setting setting Time period before the interior 15 seconds 7.5 seconds O — O lights turn off 30 seconds Operation after the “ENGINE START STOP” — — O switch is turned Operation when the doors are —...
Page 700 6-2. Customization Default Customized Item Function setting setting Light sensor sen- Standard -2 to 2 O — O sitivity Daytime running O — O Automatic light system light control system Time elapsed before head- (P. 196) lights automati- 30 seconds 60 seconds O —...
Page 701 6-2. Customization : The settings can be changed when the mechanical key linked operation of the power window is set to ON. : The settings can be changed when the wireless remote control linked oper- ation of the power window is set to ON. : The settings can be changed when the entry function linked operation of the power window is set to ON.
Page 702 6-2. Customization CAUTION ■ During customization As the engine needs to be running during customization, ensure that the vehicle is parked in a place with adequate ventilation. In a closed area such as a garage, exhaust gases including harmful carbon monoxide (CO) may collect and enter the vehicle.
Page 703: Initialization Items To Initialize
6-3. Initialization Items to initialize The following items must be initialized for normal system operation in cases such as after the battery is reconnected, or maintenance is performed on the vehicle. Item When to initialize Reference Maintenance data After the maintenance is performed P.
Page 704 6-3. Initialization LC200_OM_OM60L09U_(U)
Page 705: For U.s. Owners
For U.S. owners Reporting safety defects for U.S. owners ....706 LC200_OM_OM60L09U_(U)
Page 706: Reporting Safety Defects For U.s. Owners
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 707: Index
Index Abbreviation list ..... 708 Alphabetical index....710 What to do if......720 For vehicles with a navigation system, refer to the “Navigation System Owner’s Manual” for information regarding the equipment listed below. • Navigation system • Air conditioning •...
Page 708: Abbreviation List
Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Four Wheel Drive Air conditioning Anti-lock Brake System AI-SHIFT Artificial Intelligence Shift control Automatic Locking Retractor Auxiliary Child Restraint System DISP Display Electronic Controlled Transmission Event Data Recorder Emergency Locking Retractor GAWR Gross Axle Weight Rating GCWR Gross Combination Weight Rating Global Positioning System...
Page 709 Abbreviation list ABBREVIATIONS MEANING Mud and Snow MTBE Methyl Tertiary Butyl Ether Pre-Collision System Power Radio Data System RSCA Roll Sensing of Curtain Shield airbag Supplemental Restraint System Tire Identification Number TPMS Tire Pressure Warning System TRAC Traction Control Trailer Weight Rating Vehicle Identification Number Vehicle Stability Control LC200_OM_OM60L09U_(U)
Page 710: Alphabetical Index
Alphabetical index Alphabetical index Alarm......... 107 Air conditioning filter....560 Antenna ........361 Automatic air conditioning Anti-lock brake system ... 281 system (vehicles without Armrest ........491 navigation system)....336 Ashtrays ........482 Automatic air conditioning Assist grips ......492 system (vehicles with Audio input.......
Page 711 Alphabetical index Back door Care Back door ....... 51 Exterior........512 Wireless remote control key ... 44 Interior ........515 Back-up lights Seat belts ......516 Replacing light bulbs .... 582 Card holder.......474 Wattage ........ 677 Cargo capacity ......301 Battery Cargo net hooks.......495 If the vehicle has discharged CD player /changer...
Page 712 Alphabetical index Child safety Daytime running light Airbag precautions ....122 system ........199 Battery precautions ..542, 565 Defogger Child-protectors.......47 Rear window ......351 Child restraint system....135 Side mirror ......351 How your child should wear Dimension ........ 668 the seat belt ......81 Dinghy towing ......332 Installing child restraints..140 Display...
Page 713 Alphabetical index Eco driving....... 156 Engine coolant Electronic key Capacity ........673 If your electronic key Checking .......535 battery is discharged.. 563, 653 Preparing and checking Emergency flashers before winter .......309 Switch........600 Engine coolant temperature Emergency, in case of gauge ........179 If a warning message is Engine immobilizer system..105 displayed......
Page 714 Alphabetical index Front turn signal lights Hooks Replacing light bulbs .....582 Cargo hook ......495 Wattage.........677 Tie-down hooks..... 495 Fuel Horn .......... 178 Capacity ........670 Fuel gauge ......179 I/M test ........524 Fuel pump shut off system ..607 Identification Gas station information ..724 Engine........
Page 715 Alphabetical index Keys Maintenance Electronic key ......30 Do-it-yourself maintenance ...525 If you lose your keys..... 652 General maintenance....521 If your electronic key Maintenance data....668 battery is discharged.. 563, 653 Maintenance requirements..518 Ignition switch....... 166 Reset the maintenance Keyless entry......32 data........519 Key number ......
Page 716 Alphabetical index Parking brake ......177 Safety Connect......504 Parking lights Seat belts Switch........196 Adjusting the seat belt.....79 PCS..........289 Automatic Locking Personal lights Retractor.......80 Personal lights.......464 Child restraint system Switch........464 installation......140 Wattage.........677 Cleaning and maintaining Power outlet ......485 the seat belts ...... 516 Power steering Emergency Locking Fluid ........539...
Page 717 Alphabetical index Side airbags......113 Switch Side marker lights DISP switch......190 Replacing light bulbs .... 582 ECT switch ......172 Switch........196 Driving mode select switch..172 Wattage ........ 677 Emergency flasher switch ..600 Side mirror Engine switch ......166 Adjusting and folding ....90 Fog light switch .....201 Mirror position memory...
Page 718 Alphabetical index Tires Vanity lights Chains ........309 Vanity lights......478 Checking .......544 Wattage......... 677 If you have a flat tire....635 Vanity mirrors ......478 Inflation pressure....553 Vehicle data recordings ....24 Information ......682 Vehicle identification Pressure warning system..544 number ........669 Replacing ......635 Vehicle stability control ..
Page 719 Alphabetical index Warning buzzers Windshield wiper de-icer..352 Brake system......608 Windshield wipers ....202 Open door ......610 Wireless remote control key Seat belt reminder ....611 Replacing the battery ....563 Warning lights Wireless remote control key..44 Anti-lock brake system ..610 WMA disc........373 Brake system......
Page 720: What To Do If
What to do if... What to do if... A tire punctures If you have a flat tire P. 635 P. 105 Engine immobilizer system The engine does not start P. 649 If the engine will not start P. 656 If the battery is discharged The shift lever cannot be If the shift lever cannot be shifted P.
Page 721: Warning Lights
What to do if... ■Warning lights Brake system warning Driver’s seat belt reminder light light P. 608 P. 611 Front passenger’s seat ABS warning light belt reminder light P. 610 SRS warning light P. 609 P. 611 Open door warning light Tire pressure warning P.
Page 722 What to do if... LC200_OM_OM60L09U_(U)
Page 723 What to do if... LC200_OM_OM60L09U_(U)
Page 724: Gas Station Information
GAS STATION INFORMATION Fuel filler door Auxiliary catch lever P. 101 P. 528 Tire inflation pressure Fuel filler door opener Hood lock release lever P. 676 P. 101 P. 528 Fuel tank capacity 24.5 gal. (93 L, 20.4 Imp.gal.) (Reference) Fuel type Unleaded gasoline only P.
