This manual deals with the operation and care of your Volvo.
Welcome to the worldwide family of Volvo owners. We trust that you will enjoy many years of safe driving in your
Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this
vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and
maintenance requirements/recommendations in this manual. We also urge you and your passengers to wear seat belts
at all times in this or any other automobile. And, of course, please do not operate a vehicle if you may be affected by
alcohol, medication or any impairment that could hinder your ability to drive.
Your Volvo is designed to meet all applicable safety and emission standards, as evidenced by the certification labels
attached to the driver's door opening and on the left wheel housing in the engine compartment.
For further information please contact your retailer, or:
In the USA:
2 0 0 3
VOLVO
V70
In Canada:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2003 V70 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Volvo 2003 V70

Summary of Contents for Volvo 2003 V70

  • Page 1 This manual deals with the operation and care of your Volvo. Welcome to the worldwide family of Volvo owners. We trust that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and maintenance requirements/recommendations in this manual.
  • Page 2 Volvo Cars of North America Volvo Canada Ltd. Customer Relations 175 Gordon Baker Road P.O. Box 914 North York, Ontario M2H 2N7 Rockleigh, New Jersey 07647-0914 800-663-8255 800-458-1552 We also invite you to visit our Home Page on the Internet at: http://www.volvocars.com...
  • Page 3 State of California to cause cancer, and birth defects or other reproductive harm. Volvo and the environment Volvo is committed to the well being of our customers. As a natural part of this commitment, we care about the...
  • Page 4 After Volvo cars and parts have fulfilled their use, recycling is the next critical step in completing the life cycle. The metal content is about 75% of the total weight of a car, which makes the car among the most recycled industrial products.
  • Page 5 Top of Page...

  • Page 6: Seat Belts

    Volvo also believes no child should sit in the front seat of a car.
  • Page 7 Always fasten the seat belts before you drive or ride. A chime will sound several times if the driver's seat belt is not fastened. To buckle: Pull the belt out far enough to insert the latch plate into the receptacle until a distinct click is heard. The seat belt retractor is normally "unlocked"...
  • Page 8 Never repair the belt on your own; have this work done by an authorized Volvo retailer only. Any device used to induce slack into the shoulder belt portion of the three-point belt system will have a detrimental effect on the amount of protection available to you in the event of a collision.
  • Page 9 As an enhancement to the three-point seat belt system, your Volvo is equipped with a Supplemental Restraint System (SRS). The Volvo SRS consists of an airbag (2) on both the driver's and passenger's sides and seat belt tensioners in both front door pillars (4). The system is designed to supplement the protection provided by the three-point seat belt system.
  • Page 10 SRS yourself. Attempting to do so may result in serious personal injury. If a problem arises, take your car to the nearest authorized Volvo retailer for inspection as soon as possible. pg. 5 Front airbags - SRS A self-diagnostic system incorporated in the sensor monitors the SRS.
  • Page 11 There is no maintenance to perform on the SRS yourself. The month and year shown on the decal on the door pillar indicate when you should contact your Volvo retailer for specific servicing or replacement of airbags and seat belt tensioners.
  • Page 12 Collisions can occur where only one of the airbags deploys. NOTE: Volvo's dual-stage airbags: If the impact is less severe, but severe enough to present a clear injury risk, the dual-stage airbags are triggered at just 70% of its total capacity. If the impact is more severe, the dual-stage airbags are triggered with full capacity.
  • Page 13 Seat belts - the heart of the Volvo safety system The heart of the Volvo safety system is the three-point seat belt (a Volvo invention)! In order for the SRS system to provide the protection intended, seat belts must be worn at all times by everyone in the car. The SRS system is a supplement to the seat belts.
  • Page 14 Never try to open or repair any components of the SIPS airbag system. This should be done only by an authorized Volvo service technician. In order for the SIPS airbag to provide its best protection, both front seat occupants should sit in an upright position with the seat belt properly fastened.
  • Page 15 This may cause airbag deployment which could result in personal injury. Have the car towed to an authorized Volvo retailer for repairs. pg. 9 Volvo Inflatable Curtain (VIC)
  • Page 16 The IC system is a supplement to the Side Impact Protection System. It is not designed to deploy during collisions from the front or rear of the car or in rollover situations. Never try to open or repair any components of the IC system. This should be done only by an authorized Volvo service technician.
  • Page 17 If your car has been involved in a collision, the front seat backrests must be inspected by an authorized Volvo retailer even if the seats appear to be undamaged. Certain components in the WHIPS system may need to be replaced.

  • Page 18: Table Of Contents

    2 0 0 3 VOLVO Chapter 2 - Instruments, switches and controls pg. 23 Instruments, switches and controls Interior 24 Exterior 25 Instruments 26 Instrument panel 27 Indicator and warning lights 28 Text information window 30 Switches in the center console 31...

  • Page 19: Exterior

    pg. 25 Exterior pg. 26 Instruments...
  • Page 20 pg. 27 Instrument panel 1 Turn signals 2 Text window 3 Temperature gauge The pointer should be approximately midway on the gauge when driving. Do not drive the car if the warning light is on. The text window will provide you with additional information. If the engine temperature remains high, check coolant level - see page 131.
  • Page 21 7 General warning light (see page 28). 8 High beam indicator light 9 Tachometer Indicates engine speed in thousands of rpm. Do not drive for long with the needle in the red section. The engine has an built-in function preventing too high an engine speed. When this function operates, you may discern some pulsation, which is normal.

  • Page 22: Oil Pressure Warning Light

    135. If the light stays on after restart, have the car towed to the nearest authorized Volvo retailer. After hard driving, the light may come on occasionally when the engine is idling. This is normal, provided it goes off when the engine speed is increased.

  • Page 23: Indicator And Warning Lights

    On-Board Diagnostic II (OBDII): As you drive, a computer called "OBDII" monitors your car's engine, transmission, electrical and emission systems. The CHECK ENGINE light will light up if the computer senses a condition that potentially may need correcting. When this happens, please have your car checked by a Volvo retailer as soon as possible.

  • Page 24: Text Information Window

    STOP ENGINE: Stop and switch off the engine - to help prevent serious risk of damage. SERVICE URGENT: Take your car to an authorized Volvo retailer for inspection as soon as possible. SEE MANUAL: Refer to your owner's manual. For additional information, please contact your Volvo retailer.

  • Page 25: Switches In The Center Console

    This 12 volt socket can be used to plug in certain accessories such as cellular telephones, etc. The ignition key must be in position 1 (or higher) for the auxiliary socket to function. NOTE: The auxiliary sockets can also be used for cigarette lighters, which are available at your Volvo retailer. * Standard on all models except the T5 turbo.

  • Page 26: Trip Computer

    Trip computer The trip computer stores information gathered from several systems in your car and has four menus that can be displayed in the text window. Driving distance on current fuel reserve Average fuel consumption Current fuel consumption Average speed Current speed in mph (Canadian models only) NOTE: Warning messages from the car's monitoring systems will override the trip computer function.
  • Page 27 *Five functions on Canadian models **A sixth time on Canadian models Contents Top of Page...

  • Page 28: Climate Control System

    2 0 0 3 VOLVO Chapter 3 - Climate control system pg. 45 Climate control system Ventilation 46 Climate control system - general information 47 Electronic Climate Control (ECC) 48 pg. 46 Ventilation Air vents in dash Air vents (dash)

  • Page 29: General Information

    Air flow The air that is drawn into the passenger compartment is distributed from 14 ventilation points. Air vents in door pillars Air vents in door pillars A Open B Closed C Horizontal air flow D Vertical air flow Direct the air vents toward the rear side windows to demist. Direct the air vents toward the rear seat for the best heating/cooling effect.

  • Page 30: Sun Roof

    The air conditioning is momentarily disengaged during full-throttle acceleration. ECC maintenance All maintenance on the climate control systems should be carried out by an authorized Volvo service technician only. Refrigerant Volvo cares about the environment. The air conditioning system in your car contains a CFC-free refrigerant - R134a.
  • Page 31 pg. 49 Electronic Climate Control (ECC) AUTO This function automatically regulates the Electronic Climate Control system so that the selected temperatures are maintained. The blower, heating, air distribution (air flow) and air conditioning are controlled. If you prefer to manually set any of these functions, the remaining functions will still be controlled automatically. Pressing the AUTO button overrides any settings that were previously made manually.

  • Page 32: Interior

    that the heating function is engaged. See page 38 for additional information on this function. CAUTION: Never use ice scrapers made of metal as they can easily scratch the mirror surface. pg. 50 Electronic Climate Control (ECC) - manual settings Recirculation (see also page Press this switch to engage the recirculation function (air in the passenger compartment recirculates - no fresh air...
  • Page 33 is switched on or off. Other functions will still be regulated automatically (if the AUTO switch is on). The air conditioning functions only at temperatures above 32° F (0° C). While the Defroster function is selected, the air conditioning is temporarily activated to dehumidify the air, even if you have manually switched the air conditioning off.
  • Page 34 You can switch between these three functions by repeatedly pressing Keep the following in mind: Make it a rule to have the Air quality sensor activated at all times. Recirculation is limited in cold climates to avoid misting up. If misting occurs, you should deactivate the Air quality sensor. If the windows mist up, you can also use the windshield and side window defroster functions.
  • Page 35 CAUTION: Never use ice scrapers made of metal as they can easily scratch the mirror surface. Recirculation Recirculation can be used to shut out stale air, exhaust, etc. from the passenger compartment. The air in the passenger compartment is then recirculated, i. e. no air from outside the car is taken into the car when this function is activated. Recirculation (together with the air conditioning system) cools the passenger compartment more quickly in warm weather.
  • Page 36 Contents Top of Page...
  • Page 37 2 0 0 3 VOLVO Chapter 4 - Interior pg. 55 Interior Front seats (electrically operated) 56 Front seats (manually operated) 58 Storage compartments 59 Storage compartment, front 60 Rear seat and cargo area 63 Spare tire 72 Auxiliary seat in cargo area, Extra handgrip - XC70 73 Interior lighting 74 pg.
  • Page 38 Electrically operated seats with memory function (option)* Power seat control panel A Front edge of seat (raise/lower) B Forward - rearward C Rear edge of seat (raise/lower) D Backrest tilt WARNING! Because the driver's seat can be adjusted with the ignition off, children should never be left unattended in the car. Movement of the seat can be STOPPED at any time by pressing any button on the power seat control panel.

  • Page 39: General Information

    pg. 57 Front seats Electrically operated seats - general information Adjusting the front seats: The passenger's seat can only be adjusted if the ignition key is in position I or II. Driver's seat: The driver's seat can be adjusted if the ignition key is in position I or II (see page 35).
  • Page 40 WARNING! Cover sharp edges on the load to help prevent injury to occupants. Secure the load to help prevent shifting during sudden stops. pg. 58 Front seats Manual height adjustment - front seat The front edges of the driver and passenger seat cushions can be adjusted to seven different settings and the rear edges to nine different settings.

  • Page 41: Cup Holders

    WARNING! Make sure that no hard, sharp or heavy objects lie on or in any of the storage places where they might cause injury during heavy braking. Ashtray (option) To empty the ashtrays: Front seat, open the ashtray, pull out the insert. Rear seat, as above. Cup holders Some models are equipped with cup holders for the front and rear seat occupants.
  • Page 42 pg. 60 Cup holders, Glove compartment Cup holder in the center console for rear seat passengers (XC70 only) This cup holder is only available on the XC70 with a 3-section rear seat. To use the cup holder, open the cover on the center console and fold it rearward. The cup holder and the cover open together.

  • Page 43: Coat Hanger

    Pen holder on the center console Coat hanger Use the coat hanger for clothes of normal weight. pg. 62 Folding Table in rear seat Folding Table (option) Pull the tab and fold the table section forward. Fold the armrest in the backrest forward. Fold out the table so that it rests on the armrest. Press to release the cup holder.
  • Page 44 To close: Fold the table section upward into place. Fold the arm under the table inward being careful not to pinch your hand. Pull the handle and fold the table section back into place. Contents Top of Page...

  • Page 45: Keys, Locks, Alarm

    2 0 0 3 VOLVO Chapter 5 - Keys, Locks, Alarm pg.75 Keys, Locks, Alarm Keys, Exterior courtesy lights, Locking and unlocking the car 76 Remote keyless entry system 77 Unlocking the tailgate, Central locking buttons, "Trunk lock" function 79...
  • Page 46 The headlights, parking lights, license plate lights and the lights in the sideview mirrors will now come on and remain on for 30, 60 or 90 seconds (the time interval is at your discretion and can be changed by an authorized Volvo retailer).

  • Page 47: Remote Keyless Entry System

    The remote transmitter will also activate or deactivate the your car's alarm system(s). The car can also be locked/unlocked with the key. If one of the transmitters is misplaced, contact your nearest authorized Volvo retailer for assistance. Buttons in remote control 1 - Lock, 2 - Unlock, 3 - Open tailgate 4 - "Panic"...
  • Page 48 WARNING! Volvo does not recommend using the transmitter to lock the doors from inside the car. The alarm would be activated and would sound when one of the doors is opened. The doors must not be locked using the remote transmitter while the vehicle is occupied.
  • Page 49 Unlocking the tailgate The tailgate lock is incorporated in the central locking system and is locked or unlocked when the driver's door is locked/unlocked. The tailgate can be unlocked by: Pressing UNLOCK on the remote control twice. Using the central locking button on the driver's door. Pressing twice on the remote control's tailgate unlock button.

  • Page 50: Arming The Alarm

    The alarm is automatically armed whenever you lock your car. When armed, the alarm continuously monitors a number of points on the car. The following conditions will set off the alarm: The hood is forced open. The tailgate is forced open. A door is forced open.
  • Page 51 LED flashes rapidly before the ignition is switched on - the alarm has been triggered Fault in the alarm system: If a fault has been detected in the alarm system, a message will be displayed in the text window. Contact a Volvo retailer. Automatic re-lock/re-arm system If the car is unlocked with the remote, the car will re-lock and the alarm will re-arm after 2 minutes unless a door or the tailgate has been opened.
  • Page 52 Child safety lock control in left rear door Child safety lock control in right rear door Child safety locks - rear doors The controls are located on the rear door jambs. Use a screwdriver to adjust these controls. A The door cannot be opened from the inside. Normal operation from the outside. B The door lock functions normally.

  • Page 53: Starting And Driving

    Detachable trailer hitch 102 Jump starting 103 Winter driving 104 Long distance trips 105 Three-way catalytic converter 106 pg. 84 Fuel requirements Fuel requirements Octane rating: Volvo engines are designed for optimum performance on unleaded premium gasoline with an octane...

  • Page 54: Fuel Requirements

    To meet seasonal air quality standards, some areas require the use of "oxygenated" fuel. Volvo allows the use of the following "oxygenated fuels; however, the octane ratings listed on this page must still be met.

  • Page 55: Refueling

    Do not use gasoline that contains lead as a knock inhibitor, and do not use lead additives. Besides damaging the exhaust emission control systems on your car, lead has been strongly linked to certain forms of cancer. Many fuels contain benzene as a solvent. Unburned benzene has been strongly linked to certain forms of cancer. If you live in an area where you must fill your own gas tank, take precautions.

  • Page 56: Starting The Engine

    * If the fuel filler cap is not closed tightly or if the engine is running when the car is refueled, the Check Engine light (malfunction indicator lamp) may indicate a fault. However, your vehicle's performance will not be affected. Use only Volvo original or approved fuel filler caps. pg. 87 Starting the engine Starting the engine 1.

  • Page 57: Manual Transmission

    When starting in cold weather, the transmission may shift up at slightly higher engine speeds than normal until the automatic transmission fluid reaches normal operating temperature. * Your car is equipped with an electronic start inhibitor (immobilizer). The keys you received with your car are specially coded.

  • Page 58: Automatic Transmission Aw5

    Depress the clutch pedal completely when changing gears*. Remove your foot from the clutch pedal while driving. The shift pattern should be followed. Overdrive (5th gear) should be used as often as possible to help improve fuel economy. This gear should be engaged at speeds above approx.

  • Page 59: Shiftlock

    P (Park) Use this position when starting the engine or parking the car. Never use P while the car is in motion. The parking brake should be set whenever the car is parked. The gear selector is mechanically locked in the P position (SHIFTLOCK). To release the gear selector from this position, the engine must be running (or the ignition key must be in position II) and the brake pedal must be depressed.
  • Page 60 Automatic transmission -adaptive system The automatic transmission is controlled by an adaptive control system that constantly monitors the way in which the transmission functions. It senses and adapts each gear shift for optimal performance. The system also monitors your particular driving style and adapts gear shifting accordingly. pg.

  • Page 61: Automatic Transmission (Geartronic)

    upshift will occur when approaching the top speed for a particular gear or by releasing the accelerator pedal slightly. Kickdown can be used for maximum acceleration or when passing at highway speeds. Cold starts When driving before the engine has reached its normal operating temperature, the transmission will shift up at slightly higher engine speeds to heat the three-way catalytic converter as quickly as possible.
  • Page 62 Kickdown Automatic shift to a lower gear (kickdown) is achieved by depressing the accelerator pedal fully and briskly. An upshift will occur when approaching the top speed for a particular gear or by releasing the accelerator pedal slightly. Kickdown can be used for maximum acceleration or when passing at highway speeds. Kickdown does not function when the transmission is in the manual shift (geartronic) mode (see next page).

  • Page 63: All Wheel Drive

    Tire dimensions Volvo recommends that you always drive on tires of the same brand, size, construction (radial), tread pattern, load-, speed-, traction-, temperature-, and treadwear rating. Never drive on mixed tires, except for brief periods when the temporary spare tire is in use.

  • Page 64: Driving Economy

    Temporary Spare The temporary spare tire is for temporary, low-speed, short-distance use only. Replace it with a full-sized tire as soon as possible, in accordance with "Tire Rotation" above. Do not drive on the temporary spare at speeds above 50 m.p.h. (80km/h) or for distances greater than 50 miles (80 km).

  • Page 65: Points To Remember

    Handling, roadholding Vehicle load, tire design and inflation pressure all affect vehicle handling. Therefore, check that the tires are inflated to the recommended pressure according to the vehicle load. See "Tire pressure" section. Loads should be distributed so that capacity weight or maximum permissible axle loads are not exceeded. pg.

  • Page 66: Roof Racks/Load Carriers

    Volvo has developed especially for your car. Volvo-approved removable roof racks are designed to carry the maximum allowable roof load for this vehicle: 220 lbs (100 kg). For Non-Volvo roof racks, check the manufacturer's weight limits for the rack.
  • Page 67 Check periodically that the load carriers and load are properly secured. Reducing wind noise and improving fuel economy To maximize fuel efficiency and minimize wind noise, Volvo recommends that load carriers be removed when not in use. pg. 98 Load carriers (models with rails)
  • Page 68 Fitting the load carriers (accessory) Make sure that the load carrier is pressed firmly out against the roof rail. Screw the load carrier in place. Use the supplied torque wrench and tighten to the mark on the wrench (corresponding to 6 Nm). See illustration. Load carrier cover The car's ignition key or the stud on the edge of the supplied torque wrench can be used to undo or tighten the cover.

  • Page 69: Wheels And Tires

    2 0 0 3 VOLVO Chapter 7 - Wheels and tires pg.107 Wheels and tires General information, Wear indicator, Tire economy, Flat spots 108 Snow chains, Snow tires/studded tires 109 Inflation pressure, Vehicle loading, Spare tire 110 Uniform tire quality grading 111 Changing wheels 112 pg.

  • Page 70: Snow Chains

    Unbalanced wheels impair tire economy and driving comfort. Volvo does not recommend rotating the tires. However, if tires are rotated, they must be kept on the same side of the car so that they revolve in the same direction as before rotation.
  • Page 71 Failure to do so could reduce traction to an unsafe level or adversely affect handling. Volvo does not recommend tire rotation. However, as with any other radial tires, if rotated, the tires must be kept on the same side of the car so that they revolve in the same direction as before rotation.

  • Page 72: Vehicle Loading

    Vehicle loading The tires on your Volvo will perform to specifications at all normal loads when inflated as recommended on the tire information label located on the inside of the fuel filler door*. This label also lists vehicle load limits. Do not load your car beyond the indicated limits.

  • Page 73: Changing Wheels

    on a specified government test course. For example, a tire graded 150 would wear one and one half (1 1/2) times as well on the government course as a tire graded 100. The relative performance of tires depends upon the actual conditions of their use, however, and many depart significantly from the norm due to variation in driving habits, service practices and differences in road characteristics and climate.
  • Page 74 Engage the parking brake. Put the gear selector in (P)ark. Remove the wheel cap (where applicable) using the lug wrench in the tool kit. With the car still on the ground, use the lug wrench to loosen the wheel bolts 1/2 - 1 turn by exerting downward pressure.
  • Page 75 Attaching the jack NOTE: To avoid excessive wear and the necessity of rebalancing, mark and reinstall wheels in the same location and position as before removal. To lessen the chance of imbalance, each wheel hub is equipped with a guide stud to ensure that a removed wheel can be reinstalled in its original position (as when changing over to winter tires/wheels).
  • Page 76 Contents Top of Page...
  • Page 77 2 0 0 3 VOLVO HomeLink® Universal Transceiver (option) pg. 167 HomeLink® Universal Transceiver (option) HomeLink® Universal Transceiver HomeLink® is an advanced system that can be programmed to learn the codes of three different remote controlled- devices (e.g., garage door openers, remote lighting, entry door lock). HomeLink®'s sun visor-mounted transceiver, powered by your car's electrical system, may then be used in place of your hand-held remote controls.
  • Page 78 been successfully programmed. Release both buttons. 5. If you are programming a rolling code-equipped device (e.g., garage door opener or entry door lock), refer to "Programming rolling codes" on the next page to complete the programming process. Repeat steps 3 and 4 to program the other two transceiver buttons. If, after several attempts, you are unable to successfully train the HomeLink®...
  • Page 79 original hand-held transmitter can also be used, as desired, to operate the garage door. The remaining two HomeLink® buttons can be programmed in the same way. In the event of any problems in programming the HomeLink® Universal Transceiver, call toll-free 1-800-355-3515 (Internet: www.HomeLink.com). Operating the HomeLink®...
  • Page 80 Contents Top of Page...

  • Page 81: Maintenance/Servicing

    2 0 0 3 VOLVO Chapter 8 - Maintenance/Servicing pg. 115 Maintenance/Servicing Fuses 116 Replacing bulbs 120 Paint touch up 126 Washing the car 127 Cleaning the upholstery 128 Maintenance service, Warranty 129 Fuel/emissions systems 130 Drive belt, Air pump system, Coolant 131...

  • Page 82: Replacing Fuses

    If so, put in a new fuse of the same color and amperage (written on the fuse). Spare fuses are stored in the fuse box in the passenger compartment. If fuses burn out repeatedly, have the electrical system inspected by an authorized Volvo retailer. WARNING! Never use fuses with higher amperage that those stated on the following pages.
  • Page 83 Ordinary fuses Location Amperage 1 Accessories 2 Auxiliary lamps (option) 3 Vacuum pump 4 Oxygen sensors 5 Crankcase ventilation heater, solenoid valves 6 Mass airflow sensor, engine control module, injectors 7 Throttle module 8 AC compressor, accelerator pedal position sensor, E-box fan 9 Horn 10 Tailgate wiper 11 AC compressor, ignition coils...

  • Page 84: Shiftlock

    Location Amperage 1 Low beam headlights 2 High beam headlights 3 Power driver's seat 4 Power passenger's seat 7 Heated seat - front left (option) 8 Heated seat - front right (option) 9 ABS/STC/DSTC 10 - 11 - 12 Headlight wipers (certain models) 13 Electric socket 12 V 14 Power passenger's seat 15 Audio system, VNS...
  • Page 85 33 Fuel pump 34 Power sun roof 35 Central locking system, power windows - left door mirror 36 Central locking system, power windows - right door mirror 37 Rear power windows, power child safety 38 Alarm siren * Please be aware that if this fuse is not intact, or if it is removed, the alarm will sound. pg.
  • Page 86 18 - pg. 120 Replacing bulbs Replacing high/low beam headlight bulbs The headlight bulbs must be replaced from the engine compartment. CAUTION: Do not touch the glass on halogen bulbs with your fingers. Grease, oil or any other impurities can be carbonized onto the bulb and cause damage to the reflector.
  • Page 87 Reinstall the plastic cover and turn it clockwise until it is correctly in place (4). "TOP" must be upward. NOTE: If the vertical aim of your headlights needs to be adjusted for any reason (e.g., towing a trailer for extended periods), this should be done by an authorized Volvo retailer. pg. 121 Replacing bulbs To remove and install a high beam bulb (HB3): Switch off all lights and turn the ignition switch to position 0.
  • Page 88 Replacement of front parking light bulb Switch off all lights and turn ignition key to position 0. Remove the low beam cover by twisting counterclockwise. Pull out the bulb and its socket. Replace bulb. Press the bulb and its socket back into place. Check that the new bulb lights.
  • Page 89 Refit the sound insulation and put the access panel back in place. Replacement of rear turn signal and brake light bulbs Switch off all lights and turn the ignition switch to position 0. Using a screwdriver, carefully pry off the speaker grille. Pull out the red tab in the speaker.
  • Page 90 CAUTION: Avoid touching the glass on the bulb with your fingers. Switch off all lights and turn the ignition key to position 0. Turn the bulb holder slightly counterclockwise to release it. Replace the bulb. The shape of the base of the bulb corresponds to the shape of the bulb holder. Reinstall the bulb holder by turning it slightly clockwise.

  • Page 91: License Plate Lights

    License plate lights Switch off the ignition. Loosen the screws with a Torx screwdriver. Carefully pull out the lamp housing. Turn the bulb holder counterclockwise and pull it out. Pull out the defective bulb and insert a new one. Reinsert the bulb holder into the housing and turn it clockwise. Reinstall the housing and screw it in place.
  • Page 92 These bulbs may be difficult for you to replace yourself. We recommend that you let an authorized Volvo retailer replace these bulbs if necessary. NOTE: Other bulbs may be difficult for you to replace yourself. Let an authorized Volvo retailer replace these bulbs if necessary.

  • Page 93: Washing The Car

    Masking tape NOTE: When touching up the car, it should be clean and dry. The surface temperature should be above 60° F (15° C). Minor scratches on the surface If the stone chip has not penetrated down to the metal and an undamaged layer of paint remains, the touch-up paint can be applied as soon as the spot has been cleaned.

  • Page 94: Polishing And Waxing

    CAUTION: During high pressure washing, the spray mouthpiece must never be closer to the vehicle than 13" (30 cm). Do not spray into the locks. Special sun roof cautions: - Always close the sun roof and sun shade before washing your vehicle. - Never use abrasive cleaning agents on the sun roof.

  • Page 95: Specifications

    129 Maintenance service, Warranty Maintenance service Volvo advises you to follow the service program outlined in the Warranty and Service Records Information booklet. This maintenance program contains inspections and services necessary for the proper function of your car. The maintenance services contain several checks which require special instruments and tools and therefore must be performed by a qualified technician.
  • Page 96 Inspection and service should also be performed anytime a malfunction is observed or suspected. Page 128 provides information about maintenance of emission-related components. Applicable warranties - U.S. In accordance with applicable U.S. and Canadian regulations, the following list of warranties is provided. New Car Limited Warranty Parts and Accessories Limited Warranty Corrosion Protection Limited Warranty...
  • Page 97 6 Federal Motor Vehicle Safety Standards (FMVSS) specifications (USA) and Ministry of Transport (CMVSS) standards (Canada) Your Volvo is designed to meet all applicable safety standards, as evidenced by the certification label on the facing side of the driver's door. For further information regarding these regulations, please consult your Volvo retailer.
  • Page 98 7 Child safety latch label * The Vehicle Identification Number (VIN) should always be quoted in all correspondence concerning your vehicle with the retailer and when ordering parts. All specifications are subject to change without prior notice. pg. 143 Dimensions and weights Dimensions Length - 185.4 in.

  • Page 99: Engine Specifications

    *** The max permissible axle loads or the gross vehicle weight must not be exceeded. All specifications are subject to change without prior notice. pg. 144 Engine specifications Engine specifications Designation: Volvo B 5234 T3 Output 247 hp at 5200 rpm (184 kW/87 rps) Max. torque...
  • Page 100 3.54" (90 mm) Displacement 2.3 liters Compression ratio 8.5:1 Number of valves Designation: Volvo B 5254 T2 Output 208 hp at 5000 rpm (154 kW/83 rps) Max. torque 236 ft. lbs. at 1500-4500 rpm (320 Nm/25-75 rps) Number of cylinders 5 Bore 3.27"...

  • Page 101: Power Transmission

    Meeting or exceeding ILSAC specification GF-2, including ACEA A1, API SJ, SJ/CF, and SJ/Energy Conserving. Oil additives must not be used. Volume: Capacity (including oil filter): 6.1 US qts. (5.8 liters) Automatic Transmission Fluid AW5: Only Volvo gearbox oil (1161540-8). Do not mix with other oils. Volume: 7.9 US qts (7.5 liters) Cooling system...

  • Page 102: Power Steering Fluid

    Type: Positive pressure, closed system. The thermostat begins to open at 194 °F (90 °C) Coolant: Volvo original coolant/antifreeze All specifications are subject to change without prior notice. Power steering fluid ATF fluid Volume: 0.95 US qts (0.9 liters) Brake fluid DOT 4+ boiling point >536°F(280°C), P/N 9437433...

  • Page 103: Front Suspension

    Voltage: 12 Volt, capacity: 600 A/115 min reserve capacity. The battery contains corrosive and poisonous acids. It is of the utmost importance that old batteries are disposed of correctly. Your Volvo retailer can assist you in this matter. Generator Rated output: max. current: 140 A Starter motor: Output: 1.7 kW...
  • Page 104 All specifications are subject to change without prior notice. pg. 149 Volvo On Call Your new Volvo comes with a four year ON CALL road assistance. Additional information, features, and benefits are described in a separate information package in your glove compartment.
  • Page 105 Contents Top of Page...

  • Page 106: Audio Systems

    2 0 0 3 VOLVO INDEX pg. 171 - 174 Index ABS - warning light Accessory lights Adjusting the steering wheel Advanced User Mode (AUM) - radio Air conditioning 48 - 51 Air filter - engine Air pump system Air vents...

  • Page 107: General Information

    Automatic Locking Retractor (ALR) Automatic transmission - Geartronic 92, 93 - Kickdown 91, 92 Automatic transmission - cold starts Auxiliary socket - general information - using snow chains Backrest (center) - 3-section rear seat Battery 104, Battery maintenance 138, 139 - Replacing the battery - Ventilation hose Booster cushion...

  • Page 108: General Information

    Clutch interlock Coat hanger Coin compartment Cold weather driving Combination filter Coolant Cooling system - general information Courtesy light Courtesy lights (front) - replacing Courtesy lights - exterior Cruise control Cup holder Cup holder in the center console Detachable trailer hitch - installing Dimensions Direction indicators Distributor ignition system...
  • Page 109 Engine compartment Engine oil 104, 135, 136 Extension of cargo compartment Exterior courtesy lights Exterior features - overview Extra seat Fog light - rear Fog lights - front Folding passenger's seat backrest Foldtable Front airbags - SRS 4 - 7 Front airbags - SRS - warning light Front courtesy lights - replacing Front fog lights...

  • Page 110: Keylock

    Headlight bulbs - replacing Headlight wiper blades - replacing Headlights Heated front seats Heated rear window Heated sideview mirrors Heating 48-51 Hoisting the car Holder for grocery bags Home Safe System HomeLink® 167-169 Hood - opening Ignition switch Immobilizer (start inhibitor) Indicator lights 28, 29 Inflatable curtain (IC)
  • Page 111 Maintenance schedule Malfunction indicator lamp Manual climate control with air conditioning 52-54 Manual transmission Memory function - front seats Mirrors Mirrors, sideview - memory function Net - cargo Nylon cargo net Occupant safety Octane rating Odometer Oil - engine 104, 135, 136 Oil pressure warning light Opening the hood...

  • Page 112: Seat Belts

    Remote control - Homelink® Universal Transceiver Remote keyless entry system Remote keyless entry system - replacing batteries Remote keyless entry system and driver's seat Removing the seat cushion Replacing bulbs 120-125 Replacing fuses Replacing wiper blades Road assistance Roadholding Roof load - maximum Roof racks Safety locks - child Seat belt maintenance...
  • Page 113 Uniform tire quality grading Unlocking the tailgate Upholstery - cleaning Vanity mirror lights - replacing Vehicle Identification Number (VIN) Vehicle loading Ventilation Volvo On Call Volumes (oils and fluids) Warning flashers Warning light - center Warning lights 28, 29 Warranty...

  • Page 114: Whiplash Protection System (Whips)

    Washer fluid solvent Washing the car 127, 128 Waxing Weight distribution Wheels - changing 112, 113 Wheels and tires 108-113 Whiplash Protection System (WHIPS) Windows - electrically operated Windshield washer solvent Windshield wiper blades - replacing Windshield wipers/washers Winter driving Winter tires Winter/Wet driving mode 91, 93,...

  • Page 115: Back Cover

    When used properly and safely, they enrich the driving experience. Improperly used, any of these could cause a distraction. For all of these systems, we want to provide the following warning that reflects the strong Volvo concern for your safety: Never use these devices or any feature of your vehicle in a way that distracts you from the task of driving safely.
  • Page 116 the vehicle and others sharing the roadway. Avoiding distractions is part of that responsibility. The following should be checked regularly: * 1 Washer fluid reservoir should be filled with water and solvent (wintertime: windshield washer anti-freeze). See page 133. 2 Power steering - When cold, the level must not be above the COLD mark and when hot it must not be above the HOT mark.
  • Page 117 Bulbs Power Socket US no. Bulb Power Socket US no. 60 W HB 3 55 W 21 W BAU 15d - 21 W BA 15s 1156 55 W 5 W W W2.1x9.5d 1157NA 21/4 W BA 15d BA 15s Contents Top of Page...
