Fire / CO Alarm Interface
Model: Ei414
Instruction Manual
Read and retain carefully for as long as the product is being used. It contains vital information on the operation and installation of your
Fire / CO Alarm Interface. The booklet should be regarded as part of the product.
If you are just installing the unit, the booklet must be given to the householder. The booklet is to be given to any subsequent user.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ei414 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ei Electronics Ei414

Summary of Contents for Ei Electronics Ei414

  • Page 1 Fire / CO Alarm Interface Model: Ei414 Instruction Manual Read and retain carefully for as long as the product is being used. It contains vital information on the operation and installation of your Fire / CO Alarm Interface. The booklet should be regarded as part of the product.

  • Page 2: Table Of Contents

    Contents Page 1. Introduction & Connection Diagrams ..................2. Typical Installation Examples ......................3. Installation ............................4. House Coding ............................5. Testing ..............................6. Service Relay ............................7. User Information ..........................8. Troubleshooting the RadioLINK ..................... 9. Technical Specification ........................10.

  • Page 3: Introduction & Connection Diagrams

    The Ei414 has 3 output relays for Fire, CO & Service that can be triggered by an Ei Electronics RF Alarm System. These relays can be directly connected to the other Systems or alternatively can be used to trigger one of the other Systems RF transmitters.
  • Page 4 Wireless Smoke Alarm System Wireless Smoke & Carbon Monoxide Alarm System RF Smoke Alarm RF Smoke Alarm RF CO Alarm RF Smoke Alarm Alarm Controller Alarm Interface Alarm Controller Alarm Interface RF Smoke Alarm RF Smoke Alarm Model No. - Alarms Comment Ei140RC, Ei160RC &...
  • Page 5 Fire / CO Alarm Controller (Fire / Telecare etc.) Ei208WRF Ei650RF Ei168RC Ei262 Ei450 RF Signal Input from Ei Alarm System 11 - 30VDC service TEST 230VAC Fire / CO Alarm Interface Ei414 For connection to External Panel see Manufacturers instructions...
  • Page 6 (Fire / Telecare etc.) Ei208WRF Ei650RF Ei168RC Ei262 Ei450 RF Signal Input from Ei Alarm System Transmitter 11 - 30VDC service Transmitter TEST 230VAC Fire / CO Alarm Interface Transmitter Ei414 For connection to External Panel & RF Transmitter see Manufacturers instructions...
  • Page 7 Fire / CO Alarm Controller (Strobe etc.) Ei208WRF Ei650RF Ei168RC Ei262 Ei450 External Fire Panel RF Fire Signal Output service TEST External Device 230VAC (sprinkler flow valve) Fire / CO Alarm Interface Ei414 For connection to External Devices see Manufacturers instructions...

  • Page 8: Typical Installation Examples

    / Ei164RC will detect Smoke / Heat and the Ei168RC base will transmit an RF fire signal TEST to the Ei414. The Ei414 will then trigger the external panel. N.B. The Ei450 Alarm Controller MUST be Fire / CO Alarm Interface...
  • Page 9 Heat Alarm In the event of a fire, the Ei650RF / Ei603TYCRF service will detect Smoke / Heat and transmit an RF fire signal to the Ei414. The Ei414 will TEST then trigger the RF transmitter and alert the external panel.
  • Page 10 In the event of a fire / CO event, the relevant service Smoke / Heat / CO Alarm will transmit an TEST RF signal to the Ei414. fire Ei166RC Ei164RC The Ei414 will then Fire / CO Alarm Interface Smoke Alarm...

  • Page 11: Installation

    3. Installation Dip Switch (default) Screw Fixings Antenna Fire Relay Service Relay CO Relay Screw Fixings Battery Backup Switch RadioLINK LED...
  • Page 12 Screw Fixings Trigger inputs to send fire Voltage Input 12 - 24V signal to the RF Alarm system. These inputs will Volt Free Contacts also activate fire relay DC Power In 11 - 30V Power inputs AC Mains Input 230V Screw Fixings Power LED Battery Backup Switch...
  • Page 13 Warning: To prevent injury, this apparatus must be securely attached to the wall in accordance with the installation instructions. 1. Remove the cover (see page 3). Mount the Ei414 in a suitable location on a wall using the fixings provided, away from any objects that may block the RF signal (i.e away from metal surfaces).
  • Page 14 9. Insert and turn the key supplied to the ‘TEST’ position to begin system testing (see ‘TESTING’ section). For a 11-30V DC external source 1. The Ei414 should be located next to DC external source. Rear View: optional wiring 2. Locate the auxiliary power output in the DC external source and wire using surface trunking it to the DC Power Input connector on the Ei414.
  • Page 15 (Uninterruptible Power Supply) inverters RF Transmitter installation Knockout segments or Light Dimmer Circuits. The Ei414 must not be connected when the house wiring insulation is being checked with high voltages, i.e. do not use a high voltage insulation tester on the...
  • Page 16 DIP Switch Operation (for delayed transmission) = Switch The Ei414 contains a dip switch which specifies whether the device will work in continuous mode or = Switch through a pulsed operation. It is also used to delay the output action.
  • Page 17 Keyswitch Orientations TEST TEST TEST The Ei414 will be shipped In the ‘ON’ position the In the ‘TEST’ position the in the ‘OFF’ position. Ei414 responds to a fire Ei414 responds to a button alarm signal (activates test signal (will activate When ‘OFF’...

  • Page 18: House Coding

    4. House Coding It is essential to House Code the Ei414 to all the other RadioLINK Alarms and devices in the system to ensure they will not communicate with nearby systems. Failure to House Code the system may also result in a system malfunction.
  • Page 19 RadioLINK Alarms and devices in the system. A system with 2 x Smoke Alarms, 1 x CO Alarm, 1 x Alarm Controller and 1 x Ei414 will result in 5 blue flashes. It may take up to 10 minutes before all 5 flashes are seen.
  • Page 20 House Coded group. To manually exit House Code press the House Code button on the Ei414. When the RadioLINK LED lights up blue, release the button. This unit will then send an exit House Code signal to all the other RadioLINK Alarms and devices to exit House Code.
  • Page 21 House Code all RadioLINK Alarms and devices in the system again. To reset the Ei414 press and hold the House Code button. The RadioLINK LED will flash blue briefly and then go solid. After 5 seconds approx. the blue LED will start flashing slowly. At this point release the House Code button.

  • Page 22: Testing

    2. Using an Ei450 Alarm Controller, press the test button and the Alarms in the system will be tested and sound (It is important to keep the Test button pressed until the Fire relay is activated). Only the fire relay in the Ei414 will activate when testing the system with an Ei450.

  • Page 23: Service Relay

    2. Turn the keyswitch to the ‘TEST’ mode position and then button test any Smoke/Heat/CO Alarm head. This will reset the Service Relay on the Ei414, while setting the Fire/CO relay. When the button is released the Fire/CO relay will be reset . This will also work when pressing the Test button on the Ei450 Alarm Controller.

  • Page 24: User Information

    7. User Information Having an Ei414 Fire/CO Alarm Interface installed in conjunction with an other manufacturer’s system gives the user additional protection. However it is essential that all Smoke/Heat/CO Alarms are tested weekly. If an Ei168RC RadioLINK Base is installed in the system then the system must be tested using an Ei450 Alarm Controller.
  • Page 25 When the alarm system sounds N.B. If there has been an emergency evacuation procedure put in place by the Alarm Monitoring Centre (or equivalent), please follow those instructions in case of an emergency. If there has not been any specific instructions issued by the Alarm Monitoring Centre, please follow the basic responses in the instance of a fire or CO event.

  • Page 26: Troubleshooting The Radiolink

    If, when checking the RadioLINK interconnection, some of the Alarms do not respond, repeat the steps in the ‘Housecode’ procedure: (i) Ensure the Ei414 has been activated correctly. Check that the power on procedure operates as described in the ‘Installation’ section.

  • Page 27: Technical Specification

    9. Technical Specification Power Required: Mains 230VAC or 11-30VDC RF Range: Over 100 meters in free space RF Visual Indicator: Blue light indicates RF activity Power Indicator: Green light indicates mains or DC power connected Alarm Indicator: Red light for Fire (marked) - Red light for CO (marked) Service Indicator: Red light (marked) RF Frequency:...

  • Page 28: Service & Guarantee

    10. Service & Guarantee If for any reason the Ei414 needs to be replaced, it must only be disconnected by a qualified engineer or electrician. The device should then be returned for repair or replacement to the nearest address given on the device or in this leaflet.
  • Page 29 0889 Hereby, Ei Electronics declares that this Ei414 Fire / CO Alarm Interface is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. The Declaration of Conformity may be consulted at www.eielectronics.com/compliance...
  • Page 30 Block E1 The crossed out wheelie bin symbol that is on your product indicates that this product should not be disposed of via the normal household waste stream. Proper disposal will prevent possible harm to the environment or to human health. When disposing of this product please separate it from other waste streams to ensure that it can be recycled in an environmentally sound manner.

  • Page 32: Contact Us
