- Page 1 CM-505 5” TFT LCD COLOR MONITOR INSTRUCTION MANUAL Thank you for purchasing this product. For proper usages and application, Please read this instruction manual thoroughly. ver. 1.1 * Design and specifications are subject to change without notice. PRINTED IN KOREA...
-
Page 2: Table Of Contents
CONTENTS SAFEGUARD INSTRUCTIONS ........3 FEATURE ................5 CONTENTS ................5 FUNCTION OF EACH PART ..........6 FUNCTION ................. 8 CONNECTIONS ............... 12 INSTALLATION ............... 13 Changing REMOTE CONTROL Battery ....14 SPECIFICATION .............. 15... -
Page 3: Safeguard Instructions
SAFEGUARD INSTRUCTIONS 5” TFT LCD COLOR MONITOR Please read the “Safety Rules” carefully before using this product. Following the safety rules pre- vents users from damages related with the misuse of the product. It is very important to follow these safety rules. We state “Caution” and “Warning” to clarify any potential risk for a damage associated with the misuse of the product. - Page 4 WARNING Do not put the product in place where sudden temperature increasing and should use on optimum voltage, temperature and humidity. - It may cause to electronic shock or malfunction. Take care that the product doesn’ t get wet. - It may cause electronic shock or malfunction. Do not place near of air bag effective range.
-
Page 5: Feature
FEATURE 5” TFT LCD COLOR MONITOR • Application of TFT LCD with high resolution and low reflection • All functions are displayed on screen (OSD function) • PWM volume control • Mode selection function • Low energy consuming rate • Language Display Selection (ENG-DEU-ITA-FRA-SPA-KOR-JPN) •... -
Page 6: Function Of Each Part
FUNCTION OF EACH PART 5” TFT LCD COLOR MONITOR MONITOR 1. MODE CAM1 / CAM2 / AV Select function 2. DIMMER DAY / NIGHT 3. POWER POWER ON / OFF Button 4. HEADPHONE Headphone jack 5. REMOTE SENSOR Sensor for receiving signal from the remote control... - Page 7 REMOTE CONTROL 1. POWER Power ON/OFF key 2. MODE CAM1 / CAM2 / AV selection function 3. MENU Selecting MENU and changing functions 4. VOLUME UP/DOWN Adjust volume level Moving and Adjusting in menu 6. MUTE Mute mode ON/OFF 7. RECALL Displaying the current mode and volume level 8.
-
Page 8: Function
FUNCTIONS 5” TFT LCD COLOR MONITOR * This manual is written based on remote controller. POWER ON / OFF 1. Push POWER button to on the power. (Stand-by LED is OFF) 2. Push Power button again to off the power. MODE - It is a function to change video signal. - Page 9 VOLUME CONTROL VOLUME 30 1. Press VOL+/- (or VOL / ) button. 2. The monitor shows volume on the screen and volume is UP/DOWN. AUTO PIC When press the AUTO PIC button, PICTURE SETUP menu is displayed on screen. CONTRAST BRIGHTNESS COLOR TINT...
- Page 10 MENU This button is for SETUP, PICTURE SETTING. SETUP PICTURE CAM1, 2 1. Use MENU button to change MAIN MENU, Changed color in red when it is selected. 2. Use button to select SUB MENU, use button to adjust. DIMMER DIMMER LANGUAGE ENGLISH...
- Page 11 PICTURE 1. Use button to select CONTRAST, BRIGHT- NESS, COLOR, TINT menu. (Selected menu is in red.) CONTRAST 2. Press button and BAR and number are BRIGHTNESS changed and screen is adjusted. COLOR TINT (BAR sign is in red.) CAMERA(option) Press button to select NORMAL / MIR- CAM1...
-
Page 12: Connections
CONNECTIONS 5” TFT LCD COLOR MONITOR... -
Page 13: Installation
INSTALLATION 5” TFT LCD COLOR MONITOR 1. Choose a location where you install the monitor. Clean the place for the Stand with cleaner and remove the protective tape. And then attach it exactly where you want. 2. Fasten the monitor with tapping screw. 3. -
Page 14: Changing Remote Control Battery
Changing REMOTE CONTROL Battery 5” TFT LCD COLOR MONITOR 1. Pull the battery cover to the direc- tion of the arrow. 2. Place a battery with the (+) sign upward. (No. CR2025) 3. Put the battery case back into the remote control in the direction of the arrow. -
Page 15: Specification
SPECIFICATION 5” TFT LCD COLOR MONITOR Screen size 5 inch Resolution QVGA (320x234) LCD Panel Brightness 400cd/m² Contrast ratio 400:1 View angle(L/R/U/D) 70˚ / 70˚ / 40˚ / 60˚ Voltage DC 12V ~ 24V Power Supply Current 450mA (DC 12V, monitor set only) Input System AUTO (NTSC / PAL) NTSC... - Page 16 INSTRUCTION MANUAL...
