Radiant convector gas fire

Advertisement

FIRENZA
RADIANT CONVECTOR GAS FIRE
Installation and Maintenance Instructions
Hand these instructions to the user
Model No's FFIRZ1MN & FFIRR0MN are for use on Natural Gas (G20)
at a supply pressure of 20 mbar in G.B. / I.E.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Firenza FFIRR0MN and is the answer not in the manual?

Questions and answers

Summary of Contents for Flavel Firenza FFIRR0MN

  • Page 1 FIRENZA RADIANT CONVECTOR GAS FIRE Installation and Maintenance Instructions Hand these instructions to the user Model No’s FFIRZ1MN & FFIRR0MN are for use on Natural Gas (G20) at a supply pressure of 20 mbar in G.B. / I.E.
  • Page 2: Table Of Contents

    CONTENTS Contents Installation Instructions Page Appliance Data Section 1 Conditions of Installation. Flue & Chimney Suitability Fireplace/Surround Suitability Shelf Position Side Clearance Closure Plate Flue & Chimney inspection Chimney Catchment space 1.8.1 Brick Built Chimney 1.8.2 Fitting to Pre-Fab. Twin Wall Metal Flueboxes 1.8.3 Fitting to Pre-Cast Flue Installations Hearth Fitting...
  • Page 3: Appliance Data

    APPLIANCE DATA Main injector (1 off) Bray Elbow size 320, Cat 82 Pilot Type. Copreci Single Flame Type 21100 / 178 Max. Gross Heat Input : 5.2 kW Min. Gross Heat Input : 1.8 kW Cold Pressure : 20.0 +/- 1.0 mbar (8.0 +/- 0.4 in w.g.) Ignition : Rotary piezo, integral to gas valve Electrode Spark Gap :...
  • Page 4: Conditions Of Installation

    CONDITIONS OF INSTALLATION In Great Britain :- It is law that all gas appliances are installed only by a CORGI registered installer in GB, in accordance with these installation instructions and the Gas Safety (Installation and use) Regulations 1998. Failure to install appliances correctly could lead to prosecution.
  • Page 5: Fireplace/Surround Suitability

    FIREPLACE / SURROUND SUITABILITY The fire is suitable for hearth mounting or wall mounting. It must not be fitted directly onto a carpet or other combustible material. It must not be fitted to combustible walls. This fire is suitable for the following hearth / surround types: Non-combustible hearths / surrounds.
  • Page 6: Chimney Catchment Space

    Brick / stone built chimneys and any chimney or flue which has been used for an appliance burning fuel other than gas must be thoroughly swept. The base of the chimney/flue must also be thoroughly cleared of debris etc. Any under floor air supply to the fireplace must be completely sealed off. Ensure that the inside of the chimney/flue is in good condition along its length and check that there is no leakage of smoke through the structure of the chimney during and after the smoke pellet test.
  • Page 7: Metal Flueboxes

    The front opening of the fireplace must be between 305mm and 440mm wide, and between 510mm and 650mm high. If the opening is larger than this, then a surround must be constructed in a suitable non-com bustible material to create an opening to these limits. Allow a minimum flat surface of 20mm (10mm each side) around the opening to ensure that the closure plate can be sealed to the fireplace opening.
  • Page 8: Fitting To Pre-Cast Flue Installations

    1.8.3 Fitting to Pre-Cast Flue Installations. The pre-cast opening must be a minimum of 122.7cm 2 or equivalent cross-sectional area and have a minimum effective flue height of 3 metres. The flue spigot restrictor must be removed when installing into pre-cast flue applications. This appliance has been test ed for use in a pre-cast flue block complying with BS 1289.
  • Page 9: Packing Check List

    PACKING CHECK LIST 1 off Firebox / Burner Assembly 1 off Flue Spigot 1 off Closure Plate 1 off Literature / Loose Items Pack 4 off Ceramic Radiants – Packed inside combustion chamber of fire INSTALLATION OF FIRE 2.2.1 Preparation. Remove the dress guard by springing the location wires out at the top and lifting away.
  • Page 10 Closure plate. Fit the closure plate to the fireplace opening and ensure that it has a flat sealing area of at least 10mm sealed on all sides. See Fig. 3 below Dimensions stated are for closure plate supplied Fig. 3 Closure Plate Dimensions...
  • Page 11: Hearth Fixing

    HEARTH FIXING With the closure plate fitted as described on page 10, loosen the locknuts on the front feet. If a side gas connection is to be used, reverse the rear foot on that side, to clear the supply pipe. Place the fire into position and adjust level by rotating the feet, then re-tighten the locknuts.
  • Page 12: Completing The Assembly

    GAS TIGHTNESS Remove the pressure test point screw from the inlet elbow and fit a manometer. Turn on the main gas supply and light the fire as described in section 3.2 and carry out a gas tightness test. Check that the gas pressure is 20.0 mbar (± 1.0 mbar), 8.0 in w.g. +/- 0.4 in w.g.
  • Page 13: Checking For Clearance Of Combustion Products

    Checking for Clearance of Combustion Products Close all doors and windows in the room. Remove the dress guard. Light the fire and turn to the maximum position. After 5 minutes hold the smoke match as shown in Fig. 5. Whilst hold ing the smoke match in the correct position, approximately 5mm below and inside the lower edge of the centre of the canopy.
  • Page 14: Final Checks

    IF SPILLAGE IS DETECTED The cause must be discovered and the fault corrected. If the fault cannot be cor- rected disconnect the appliance from the gas supply and seek expert advice. Possible causes of spillage from the appliance are:- chimney restriction, down draught or insufficient air supply to the room.
  • Page 15: Maintenance Instructions

    MAINTENANCE INSTRUCTIONS Servicing Notes Servicing should be carried out annually by a competent person such as a Corgi registered engineer. The service should include visually checking the chimney and fire opening for accumulations of debris and a smoke test to check for positive up-draught in the chimney.
  • Page 16: Removal Of The Burner Assembly

    Fig. 7 Lifting the case out of the rear locating slots Fixing slots REMOVING THE BURNER ASSEMBLY FROM THE FIRE Remove the case as described in section 4.1.1. Disconnect the pilot and remove. Remove the four burner fixing screws as shown below in Fig.
  • Page 17: Removal Of The Gas Valve

    REMOVING THE GAS VALVE FROM THE FIRE Disconnect the appliance from the gas supply. Remove the case as described in section 4.11 Disconnect the main pipe, inlet pipe & pilot pipe from the valve, then remove the push fit thermocouple and ignition lead, as shown below in fig.
  • Page 18: Removal Of The Ods

    REMOVING THE ODS- PILOT ASSEMBLY Note : Because this appliance is fitted with an atmosphere sensing ODS-pilot it is not possible to replace the thermocouple separately, because the thermocouple position is factory set to a tight tolerance. Any replacement of parts on the pilot requires a complete new pilot assembly.
  • Page 19 PARTS SHORTLIST Replacement of any other parts must be carried out by a competent person such as a CORGI registered gas installer. The part numbers of the user replaceable parts are as follows, these are available from specialist spares stockists whose details can be found on our web site, www.cfm-europe.com, in the ‘stockist’...
  • Page 20 FIRENZA RADIANT CONVECTOR GAS FIRE User Instructions This section of the instructions should be read by the user before operating the appliance and retained for future reference Model No’s FFIRZ1MN & FFIRR0MN are for use on Natural Gas (G20) at a supply pressure of 20 mbar in G.B. / I.E.
  • Page 21: Installation Information

    INSTALLATION INFORMATION CONDITIONS OF INSTALLATION It is the law that all gas appliances are installed only by a competent (e.g. CORGI Registered) Installer, in G.B. in accordance with the installation instructions and the Gas Safety (Installation and Use) Regulations 1998. Failure to install appliances correctly could lead to prosecution.
  • Page 22 ABOUT YOUR NEW FLAVEL FIRENZA GAS FIRE The Flavel Firenza gas fire incorporates a unique and highly developed heat exchanger which combined with the radiant plaques gives maximum heat whilst maintaining reasonable running costs Please take the time to fully read these instructions as you will then be able to obtain the most effective and safe operation of your fire.
  • Page 23 OPERATING THE FIRE Light the pilot by depressing the control knob at the “off” position and turn anti-clockwise (with the control depressed) to the second position marked *. When the pilot lights, (pilot can be seen through the central ceramic plaque) hold the control knob down for 10 seconds.
  • Page 24 LIGHTING WITH A SPILL Important do not light with a wax taper In the unlikely event of the piezo ignition unit failing to light the fire, turn the control knob to the OFF position, and wait a minute or so for the gas to disperse. The fire can then be lit by using a spill.
  • Page 25 Fig. 2 CLEANING & RE-ASSEMBLING THE RADIANTS The ceramics may discolour slightly over a period of time, this is normal for radiant fires. Any dust or small soot deposits that accumulate on the ceramics can easily be cleaned. Carefully remove the ceramics and brush gently with a soft brush. To remove the ceramic, remove the dress-guard as shown in fig.
  • Page 28 REPLACING THE RADIANTS When replacing the radiants, always ensure that they are correctly located as shown in Fig. 4 below, with the front bottom face of the radiant plaque sitting against the support bracket as shown. Fig. 4 Ceramic Plaques correctly located Support Bracket Due to our policy of continual improvement and development the exact...
