MIDI CC Implemention Chart
Function CC Joystick
Mod Wheel 1 2
OSC1 - Wave 2 10
OSC1 - PW 3 -
OSC1 - Note 4 23
KEYB - Glide 5 20
- 6 -
VCA - Amount 7 16
OSC2 - Detune 8 22
OSC2 - PW 9 -
OSC - Sync 10 -
OSC - SubWav 11 -
OSC - DeRez 12 -
MIX - Drive 13 25
MIX - Osc1 14 26
MIX - Sub1 15 28
MIX - Osc2 16 27
MIX - Sub2 17 29
MIX - Ext In 18 30
VCF - Resonance 19 8
VCF - Velo 20 -
VCF - EG 21 12
VCF-EG - Attack 22 13
VCF-EG - Decay 23 14
VCF-EG - Sustain 24 -
VCF-EG - Release 25 15
VCA-EG - Attack 26 17
VCA-EG - Decay 27 18
Sequence Animator Values
- - 0 - 127
9 8 0 - 55 (0 - 63 in PW)
26 25 OFF = 0 - ON = 127
24 23 0 - 48 (-24 OFFSET)
21 20 0 - 127
- - -
16 15 0 - 127
23 22 0 - 127
27 26 OFF = 0 - ON = 127
29 28 OFF = 0 - ON = 127
30 29 OFF = 0 - ON = 127
28 27 OFF = 0 - ON = 127
31 30 0 - 127
32 31 0 - 127
33 32 0 - 127
34 33 0 - 127
35 34 0 - 127
36 35 0 - 127
7 6 0 - 127
38 37 0 - 127 (-63 OFFSET)
11 10 0 - 127 (-63 OFFSET)
12 11 0 - 127
13 12 0 - 127
14 13 0 - 127
15 14 0 - 127
17 16 0 - 127
18 17 0 - 127
