We would you like to thank you for choosing an ezcap product. You have made an excellent decision.
The following contents guide you how to use the product. Hope this device will bring you nice digital experience
Overview
You now have all the options you need for watching your favorite TV shows on your computer. And record them,
so you can watch them any where and any time.
With the ezcap USB 2.0 ISDB-T Stick, you can record live TV or schedule recordings using the built-scheduler.
The Time-shift function also allows you to pause and instantly replay your favorite scenes.
Specification
Item Name
Interface
Recording Format
Input
Output
Receiving Frequency
TV System
Punctured Codes
Bandwidth
Power Supply
Consumed Power
TV Player Software
Dimension / Weight
Cable Length
System Requirements
Connection Guide
USB 2.0 ISDB-T Stick
USB 2.0 standard
MPEG-2
50 Ohm MCX connector
A type USB male connector
48.25
~ 863.25 MHz
Fully ISDB-T compliant - FullSeg
1/2, 2/3, 3/4, 4/5, 5/6 and 7/8
6MHz
De-Multiplexing
USB Bus
≤ 1.5W
Blaze Video HDTV Player 6.0
56(L)×20(W)×10(H)mm / 12g
120cm for Portable Antenna
One available USB 2.0 port
Pentium4 CPU or above
512MB RAM or above
Graphics card supports DirectX 9.0C
1GB free HDD space
CD-ROM for installation
Windows XP, Vista, Seven
ISDB-T stick device, Portable antenna, Remote Controller,
Quick installation guide, Software CD(includes driver,
application and manual)
USB 2.0 ISDB-T Stick
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for EzCAP CVMK-K188
Summary of Contents for EzCAP CVMK-K188
- Page 1 USB 2.0 ISDB-T Stick We would you like to thank you for choosing an ezcap product. You have made an excellent decision. The following contents guide you how to use the product. Hope this device will bring you nice digital experience Overview You now have all the options you need for watching your favorite TV shows on your computer.
- Page 2 USB 2.0 ISDB-T Stick Notice: 1, It is recommended to connect to a roof top aerial during the first time installation as this may provide a better signal quality than the provided portable antenna. 2, You need to ensure that you are located in an area that has Digital ISDB Terrestrial coverage. Quick Installation Chart Please read the all installation guide clearly.
-
Page 3: Hardware Installation
2，If your OS is 64-bit, please press F8 and select “Disable digital signature Enforcement” to enter the OS when you start the computer, Before you first connect the ezcap USB 2.0 ISDB-T Stick to your computer, please insert the “CD-ROM” into your CD drive. Then you should find a picture of software running. - Page 4 Please click the “Finish” button to complete the driver installation. Now, you need to plug ezcap USB 2.0 ISDB-T Stick into your computer’s USB2.0 port. Computer system will appear you “Found the new hardware” . Please select "No, not this time" and click "Next" button.
- Page 5 “SMS Digital Video”. If it has a yellow mark next to it then this means that the driver is not installed correctly. You will need to remove the driver and disconnect the ezcap USB 2.0 ISDB-T...
- Page 6 USB 2.0 ISDB-T Stick BlazeVideo BlazeDTV 6.0 Installation & Guide Please insert the “CD-ROM” into your CD drive. Then you should find a picture of software running. Please select the option “Install HDTV Player”. Select your language for the installation and Click “Next” or / and “Install”. Click “finish”...
- Page 7 Please enter your name, E-mail and software Serial Number(You can find it on the CD bag), then click "Register' button to start software setting. Now we can receive the ISDB-T digital TV programs with the ezcap USB 2.0 ISDB-T Stick and software. A box will pop up to enquire you whether to scan channels.
- Page 8 USB 2.0 ISDB-T Stick Please select "Brazil" for Country selection, and click "OK" to scan TV channels as below. Wait for scanning channels until software appears you "Scan finished", then click "OK" button to complete scanning channels. Now you can enjoy your favorite TV shows! Main Control Panel: Button/Icon Name Description...
- Page 9 USB 2.0 ISDB-T Stick TimeShift(DTV only); TimeShift/Paus or pause during the DVD playback ( A green bar appears on Main Control panel) Stop Stop the current playback. Click play to restart playback. Record Record TV show Previous Skip to previous TV channel or DVD chapter to play Browse Browse channel, the swift way to switch channels Next...
- Page 10 USB 2.0 ISDB-T Stick Open Floating Show Floating Panel Panel Show Advanced Show/Hide Advanced Panel Panel It is a standard windows icon. Click it, the control panel and the Minimize view window will be minimized and displayed as icons on system toolbar.
- Page 11 USB 2.0 ISDB-T Stick 1. The TimeShift function is only activated for HDTV program playback, not available for media file playback. 2. The paused duration time depends on your TimeShift Buffer Size, which can be set in DTV Setting. Real-time Record TV Show You can real-time record your favorite TV show while you are watching TV show.
- Page 12 USB 2.0 ISDB-T Stick In EPG_Schedule window, click to create a task. In EPG_Channels window, select a program with EPG guide and click In EPG_ Programs window, right click a program and select “Add to Schedule”. In EPG_ Favorite window, select a program with EPG guide and click Through one of above steps to create a task and eject below Task box: here you can set task name, task type and task time.
