SyncMaster 732NPlus / 932BPlus
/ 732N / 932B
Downloaded from ManualMonitor.com Manuals

Advertisement

   Also See for Samsung SyncMaster 732NPlus

   Related Manuals for Samsung SyncMaster 732NPlus

   Summary of Contents for Samsung SyncMaster 732NPlus

  • Page 1 SyncMaster 732NPlus / 932BPlus / 732N / 932B Downloaded from ManualMonitor.com Manuals...
  • Page 2 Model Notation Failure to follow directions noted by this symbol could result in bodily harm or damage to the equipment. Prohibited Important to read and understand at all times Do not disassemble Disconnect the plug from the outlet Do not touch Ground to prevent an electric shock Power When not used for extended period of time, set your computer to DPMS.
  • Page 3 Do not pull the plug out by the wire nor touch the plug with wet hands. This may cause electric shock or fire. Use only a properly grounded plug and receptacle. An improper ground may cause electric shock or equipment damage. (Class l Equipment only.) Insert the power plug firmly so that it does not come loose.
  • Page 4 This may cause electric shock or fire. Installation Be sure to contact an authorized Service Center, when installing your monitor in a location with heavy dust, high or low temperatures, high humidity, and exposed to chemical substances and where it operates for 24 hours such as at airports, train stations etc.
  • Page 5 Keep any heating devices away from the power cable. A melted coating may cause electric shock or fire. Do not install the product in places with poor ventilation, for instance, a bookshelf, closet, etc. Any increase in the internal temperature may cause fire. Put down the monitor carefully.
  • Page 6: Cleaning And Use

    Do not use any chemicals such as wax, benzene, alcohol, thinners, insecticide, air freshener, lubricant or detergent. Contact the SAMSUNG customer care center or Customer Center for interior cleaning once a year. Keep the product's interior clean. Dust which has accumulated in the interior over an extended period of time may cause a malfunction or fire.
  • Page 7 This may cause electric shock or fire. Refer to a qualified servicing company. If your monitor does not operate normally - in particular, if there is any unusual sound or smell coming from the monitor - unplug it immediately and the Service Center.
  • Page 8 This may cause a malfunction, electric shock or fire. If a foreign substance enters the monitor, unplug the power cord and contact the Service Center. Keep the product away from combustible chemical sprays or inflammable substances. This may cause an explosion or fire. Never insert anything metallic into the monitor openings.
  • Page 9 Dropping the product may cause damage to the product or the person carrying it. Using the product in a location prone to vibrations may shorten the lifetime of the product or may cause the product to catch fire. When moving the monitor, turn off and unplug the power cord. Make sure that all cables, including the antenna cable and cables connected to other devices, are disconnected before moving the monitor.
  • Page 10 Correct Disposal of This Product (Waste Electrical & Electronic Equipment) - Europe only (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life.
  • Page 11: Product Information (image Retention Free)

    PRODUCT INFORMATION (Image Retention Free) LCD Monitors and TVs may have an image retention when switching from one image to another especially after displaying a stationary image for a long time. This guide is to demonstrate a correct usage of LCD products in order to protect them from Image retention.
  • Page 12 The best way to protect your monitor from Image retention is to set your PC or System to operate a Screen Saver program when you are not using it. Image retention may not occur when a LCD panel is operated under normal conditions. Normal conditions are defined as continuously changing video patterns.
  • Page 13: Package Contents

    SyncMaster 732NPlus / 732N Model Package Contents Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. Contact a local dealer to buy optional items. Unpacking Monitor Manual Warranty Card User's Guide, Monitor Driver,...
  • Page 14: Your Monitor

    Others Cleaning Cloth Will be applied to black and high gloss models only. Your Monitor Front MENU button [ ] Open the OSD menu. Also use to exit the OSD menu or return to the previous menu. MagicBright™ button MagicBright™ is a new feature providing optimum viewing environment depending on the contents of the image you are watching.
  • Page 15 1) Custom Although the values are carefully chosen by our engineers, the pre- configured values may not be comfortable to your eyes depending on your taste. If this is the case, adjust the brightness and contrast by using the OSD menu. 2) Text For documentations or works involving heavy text.
  • Page 16 POWER port Connect the power cord for your monitor to the power port on the back of the monitor. RGB IN port Connect the signal cable to the 15-pin, D-sub port on the back of your monitor. Kensington Lock The Kensington lock is a device used to physically fix the system to something when using it in a public place.
  • Page 17 SyncMaster 932BPlus / 932B Model Package Contents Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. Contact a local dealer to buy optional items. Unpacking Monitor Manual Warranty Card User's Guide, Monitor Driver, Quick Setup Guide (Not available in all Natural Color software,...
  • Page 18 Others Cleaning Cloth Will be applied to black and high gloss models only. Sold separately DVI Cable Your Monitor Front Downloaded from ManualMonitor.com Manuals...
  • Page 19 MENU button [ ] Open the OSD menu. Also use to exit the OSD menu or return to the previous menu. MagicBright™ button MagicBright™ is a new feature providing optimum viewing environment depending on the contents of the image you are watching. Currently seven different modes are available: Custom, Text, Internet, Game, Sport, Movie and Dynamic Contrast.
  • Page 20 Brightness button [ ] When OSD is not on the screen, push the button to adjust brightness. >> Click here to see an animation clip Adjust buttons [ Adjust items in the menu. Enter button [ ] / Activates a highlighted menu item. / SOURCE button Push the 'SOURCE/ ', then selects the video signal while the OSD is off.
  • Page 21: Connecting Cables

    SyncMaster 732NPlus / 732N Model Connecting Cables Connect the power cord for your monitor to the power port on the back of the monitor. Plug the power cord for the monitor into a nearby outlet. Use a connection appropriate to the computer you are using.
  • Page 22 Downloaded from ManualMonitor.com Manuals...
  • Page 23 SyncMaster 932BPlus / 932B Model Connecting Cables Connect the power cord for your monitor to the power port on the back of the monitor. Plug the power cord for the monitor into a nearby outlet. Use a connection appropriate to the computer you are using. Using the D-sub (Analog) connector on the video card.
  • Page 24 You can tilt the monitor upwards at an angle of 0° to18°. Downloaded from ManualMonitor.com Manuals...
  • Page 25: Monitor Driver

    Driver installation is slightly different from one operating system to another. Follow the directions appropriate for the operating system you have. Prepare a blank disk and download the driver program file at the Internet web site shown below. Internet web site :http://www.samsung.com/ (Worldwide) http://www.samsung.com/monitor (U.S.A) http://www.sec.co.kr/monitor...
  • Page 26 This monitor driver is under certifying MS logo, and this installation doesn't damage your system. The certified driver will be posted on Samsung Monitor homepage http://www.samsung.com/ Monitor driver installation is completed. Installing the Monitor Driver (Manual) Windows Vista Windows XP...
  • Page 27 This monitor driver is under certifying MS logo, and this installation doesn't damage your system. The certified driver will be posted on Samsung Monitor homepage http://www.samsung.com/ Click "Update Driver…" in the "Driver" tab. Check the "Browse my computer for driver software" checkbox and click "Let me pick from a list of device drivers on my computer".
  • Page 28 Click "Close" → "Close" → "OK" → "OK" on the following screens displayed in sequence. ® ® Microsoft Windows XP Operating System Insert the CD into the CD-ROM drive. Click "Start" → "Control Panel" then click the "Appearance and Themes" icon. Click "Display"...
  • Page 29 Click the "Properties" button on the "Monitor" tab and select "Driver" tab. Click "Update Driver." and select "Install from a list or." then click the "Next" button. Select "Don't search ,I will." then click "Next" and then click "Have disk". Click the "Browse"...
  • Page 30 "OK" button. This monitor driver is under certifying MS logo, and this installation doesn't damage your system. The certified driver will be posted on Samsung Monitor homepage http://www.samsung.com/ Click the "Close" button then click the "OK" button continually. Monitor driver installation is completed.
  • Page 31 How to install Click "Start," "Setting," and then "Control Panel." Double click the "Display" icon. Select the "Settings" tab and click the "Advanced Properties" button. Choose "Monitor." Case1 : If the "Properties" button is inactive, it means your monitor is properly configured. Please stop installation Case2 : If the "Properties"...
  • Page 32: Natural Color

    Samsung Electronics in association with Korea Electronics & Telecommunications Research Institute (ETRI). This is only available for Samsung monitors and ensures that the color of the images on the monitor are the same as the printed or scanned images.
  • Page 33 9. Click "Finish." 10. When the installation is complete, the MagicTune™ executable icon appears on your desktop. Double-click the icon to start the program. MagicTune™ execution icon may not appear depending on specification of computer system or monitor. If that happens, press F5 Key. Installation Problems (MagicTune™) The installation of MagicTune™...
  • Page 34: Control Buttons

    SyncMaster 732NPlus / 732N Model Control Buttons [MENU / ] Opens the OSD menu. Also use to exit the OSD menu or return to the previous menu. ] These buttons allow you to adjust items in the menu. [ ] Press this button to activate a highlighted menu item.
  • Page 35 Menu Description When the 'AUTO' button is pressed, the Auto Adjustment screen appears as shown in the animated screen on the center. Auto adjustment allows the monitor to self-adjust to the incoming Analog signal. The values of fine, coarse and position are adjusted automatically. (Available in Analog mode only) To make the automatic adjustment function sharper, execute the 'AUTO' function AUTO...
  • Page 36 MENU button Menu Description This is the function that locks the OSD in order to keep the current states of settings or prevent others from adjusting the current settings. Lock : Hold down the menu button for more than five seconds to activate the OSD adjustment lock function.
  • Page 37 MagicBright™ Menu Description Push the MagicBright™ button to circle through available preconfigured MagicBright™ modes. - Seven different modes: Custom, Text, Internet, Game, Sport, Movie and Dynamic Contrast. Brightness Menu Description Brightness When OSD is not on the screen, push the button to adjust brightness. Downloaded from ManualMonitor.com Manuals...
  • Page 38: Osd Function

    OSD Function Picture Brightness Contrast Color MagicColor Color Tone Color Control Gamma Image Coarse Fine Sharpness H-Position V-Position Language H-Position V-Position Transparency Display Time Setup Image Reset Color Reset Information Picture : Not available in MagicBright™ mode of Dynamic Contrast. Menu Description Play/Stop...
  • Page 39 Menu Description Play/Stop MagicColor is a new technology that Samsung has exclusively developed to improve digital image and to display natural color more clearly without disturbing image quality. Returns to the original mode. Demo The screen before applying MagicColor appears...
  • Page 40 Menu Description Play/Stop Removes noise such as vertical stripes. Coarse adjustment may move the screen image area. You may relocate it to the center using the horizontal control Coarse menu. MENU → → → → → MENU Removes noise such as horizontal stripes. If the noise persists even after fine tuning, repeat it after Fine adjusting the frequency (clock speed).
  • Page 41 Menu Description Play/Stop You can choose one of nine languages. The language chosen affects only the language of the OSD. It Language has no effect on any software running on the computer. MENU → → → → → MENU You can change the horizontal position where the OSD menu appears on your monitor.
  • Page 42 Menu Description Play/Stop Image parameters are replaced with the factory default values. Image Reset MENU MENU → → → → → Color parameters are replaced with the factory default values. Color Reset MENU → → → → → → MENU Information Menu Description...
  • Page 43 Shows a video source, display mode on the OSD screen. Information MENU → Downloaded from ManualMonitor.com Manuals...
  • Page 44 SyncMaster 932BPlus / 932B Model Control Buttons [MENU / ] Opens the OSD menu. Also use to exit the OSD menu or return to the previous menu. ] These buttons allow you to adjust items in the menu. [ ] Press this button to activate a highlighted menu item. [AUTO] When the 'AUTO' button is pressed, the Auto Adjustment screen appears as shown in the animated screen on the center.
  • Page 45 Menu Description When the 'AUTO' button is pressed, the Auto Adjustment screen appears as shown in the animated screen on the center. Auto adjustment allows the monitor to self-adjust to the incoming Analog signal. The values of fine, coarse and position are adjusted automatically. (Available in Analog mode only) To make the automatic adjustment function sharper, execute the 'AUTO' function AUTO...
  • Page 46 MENU button Menu Description This is the function that locks the OSD in order to keep the current states of settings or prevent others from adjusting the current settings. Lock : Hold down the menu button for more than five seconds to activate the OSD adjustment lock function.
  • Page 47 MagicBright™ Menu Description Push the MagicBright™ button to circle through available preconfigured MagicBright™ modes. - Seven different modes: Custom, Text, Internet, Game, Sport, Movie and Dynamic Contrast. Brightness Menu Description Brightness When OSD is not on the screen, push the button to adjust brightness. Downloaded from ManualMonitor.com Manuals...
  • Page 48 SOURCE Menu Description SOURCE Selects the Video signal while the OSD is off. (Analog/Digital) OSD Function Picture Brightness Contrast Color MagicColor Color Tone Color Control Gamma Image Coarse Fine Sharpness H-Position V-Position Language H-Position V-Position Transparency Display Time Setup Auto Source Image Reset Color Reset Information...
  • Page 49 Menu Description Play/Stop You can use the on-screen menus to change the brightness according to personal preference. Direct Access Feature : When OSD is not on the screen, Brightness push the button to adjust brightness. Click here to see an animation clip MENU →...
  • Page 50 Menu Description Play/Stop MagicColor is a new technology that Samsung has exclusively developed to improve digital image and to display natural color more clearly without disturbing image quality. Returns to the original mode. Demo The screen before applying MagicColor appears...
  • Page 51 Menu Description Play/Stop Removes noise such as vertical stripes. Coarse adjustment may move the screen image area. You may relocate it to the center using the horizontal control Coarse menu. MENU → → → → → MENU Removes noise such as horizontal stripes. If the noise persists even after fine tuning, repeat it after Fine adjusting the frequency (clock speed).
  • Page 52 Menu Description Play/Stop You can choose one of nine languages. The language chosen affects only the language of the OSD. It Language has no effect on any software running on the computer. MENU → → → → → MENU You can change the horizontal position where the OSD menu appears on your monitor.
  • Page 53 Menu Description Play/Stop Select Auto Source for the monitor to automatically select the signal source. Auto Source MENU MENU → → → → → Image parameters are replaced with the factory default values. Image Reset MENU → → → → →...
  • Page 54 Menu Description Shows a video source, display mode on the OSD screen. Information MENU → Downloaded from ManualMonitor.com Manuals...
  • Page 55: Check List

    SyncMaster 732NPlus / 732N Model Check List Before calling for assistance, check the information in this section to see if you can remedy any problems yourself. If you do need assistance, please call the phone number on the Information section or contact your dealer.
  • Page 56 I cannot see the Have you locked Unlock the OSD by pressing the [MENU / ] button for at On Screen the On Screen least 5 seconds. Display. Display (OSD) Menu to prevent changes? The screen shows Is the screen Check the signal cable connection.
  • Page 57 Some graphic cards may not support your monitor. When you have a problem with the graphic card, visit our website to check the compatible graphic card list provided. http://www.samsung.com/monitor/magictune MagicTune™ Have you changed Download the latest program. The program can be...
  • Page 58 Windows ME/2000 : Set the resolution in the Control Panel → Display → Screen Saver. Set the function in the BIOS-SETUP of the computer. Refer to the Windows / Computer Manual How can I clean the outer case/LCD Panel? Disconnect the power cord and then clean the monitor with a soft cloth, using either a cleaning solution or plain water.
  • Page 59 If there are any sub woofer speakers near the monitor, unplug and relocate the woofer to another room. Remove all electronic devices such as radios, fans, clocks and telephones that are within 3 feet (one meter) of the monitor. Useful Tips A monitor recreates visual signals received from the computer.
  • Page 60 SyncMaster 932BPlus / 932B Model Check List Before calling for assistance, check the information in this section to see if you can remedy any problems yourself. If you do need assistance, please call the phone number on the Information section or contact your dealer.
  • Page 61 indicator on the restore the image on the screen. monitor blinking at 1 second intervals? If there is still no image, press the 'SOURCE/ ' button. Then press any key on the keyboard again to activate the monitor and restore the image on the screen. Connected using You may get a blank screen if you boot the system the DVI cable?
  • Page 62 Some graphic cards may not support your monitor. When you have a problem with the graphic card, visit our website to check the compatible graphic card list provided. http://www.samsung.com/monitor/magictune MagicTune™ Have you changed Download the latest program. The program can be...
  • Page 63 Windows ME/2000 : Set the resolution in the Control Panel → Display → Settings. Contact the video card manufacturer for details. How can I set the Power Saving function? Windows XP : Set the resolution in the Control Panel → Appearance and Themes →...
  • Page 64 Environment The location and the position of the monitor may influence the quality and other features of the monitor. If there are any sub woofer speakers near the monitor, unplug and relocate the woofer to another room. Remove all electronic devices such as radios, fans, clocks and telephones that are within 3 feet (one meter) of the monitor.
  • Page 65: Specifications

    SyncMaster 732NPlus / 732N Model Specifications General Model Name SyncMaster 732NPlus/SyncMaster 732N LCD Panel Size 17 " Diagonal (43 cm) Display area 337.92 mm (H) x 270.336 mm (V) Pixel Pitch 0.264 mm (H) x 0.264 mm (V) Synchronization Horizontal...
  • Page 66 This monitor is EPA ENERGY STAR compliant and ENERGY2000 compliant when used with a computer equipped with VESA DPMS functionality. ® As an ENERGY STAR Partner, SAMSUNG has determined that this ® product meets the ENERGY STAR guidelines for energy efficiency. Downloaded from ManualMonitor.com Manuals...
  • Page 67: Preset Timing Modes

    Preset Timing Modes If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjust the screen as follows. Horizontal Vertical Sync...
  • Page 68 SyncMaster 932BPlus / 932B Model Specifications General Model Name SyncMaster 932BPlus/SyncMaster 932B LCD Panel Size 19 " Diagonal (48 cm) Display area 376.32 mm (H) x 301.056 mm (V) Pixel Pitch 0.294 mm (H) x 0.294 mm (V) Synchronization Horizontal 30 ~ 81 kHz Vertical 56 ~ 75 Hz...
  • Page 69 This monitor is EPA ENERGY STAR compliant and ENERGY2000 compliant when used with a computer equipped with VESA DPMS functionality. ® As an ENERGY STAR Partner, SAMSUNG has determined that this ® product meets the ENERGY STAR guidelines for energy efficiency. Downloaded from ManualMonitor.com Manuals...
  • Page 70 Preset Timing Modes If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjust the screen as follows. Horizontal Vertical Sync...
  • Page 71 Vertical Frequency Like a fluorescent lamp, the screen has to repeat the same image many times per second to display an image to the user. The frequency of this repetition is called the Vertical Frequency or Refresh Rate. Unit : Hz Downloaded from ManualMonitor.com Manuals...
  • Page 72 Model Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. North America U.S.A 1-800-SAMSUNG (7267864) http://www.samsung.com CANADA 1-800-SAMSUNG (7267864) http://www.samsung.com/ca MEXICO 01-800-SAMSUNG (7267864) http://www.samsung.com/mx Latin America ARGENTINE 0800-333-3733 http://www.samsung.com/ar...
  • Page 73 02 201 2418 http://www.samsung.com/be CZECH REPUBLIC 844 000 844 http://www.samsung.com/cz DENMARK 70 70 19 70 http://www.samsung.com/dk FINLAND 030-6227 515 http://www.samsung.com/fi 3260 SAMSUNG(7267864) (€ FRANCE http://www.samsung.com/fr 0,15/min) GERMANY 01805 - 121213 (€ 0,14/Min) http://www.samsung.de HUNGARY 06-80-SAMSUNG (7267864) http://www.samsung.com/hu ITALIA 800 SAMSUNG (7267864) http://www.samsung.com/it...
  • Page 74 TAIWAN 0800-329-999 http://www.samsung.com/tw VIETNAM 1 800 588 889 http://www.samsung.com/vn Middle East & Africa SOUTH AFRICA 0860 7267864 (SAMSUNG) http://www.samsung.com/za 800SAMSUNG (7267864) U.A.E http://www.samsung.com/mea 8000-4726 Terms Dot Pitch The image on a monitor is composed of red, green and blue dots. The closer the dots, the higher the resolution.
  • Page 75: For Better Display

    Reproduction in any manner whatsoever without the written permission of Samsung Electronics Co., Ltd. is strictly forbidden. Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
  • Page 76 MÉXICO IMPORTADO POR: SAMSUNG ELECTRONICS MÉXICO. S.A. de C.V. Vía Lopez Portillo No. 6, Col. San Fco. Chilpan Tultitlán, Estado de México, C.P. 54940 Tel: 01-55-5747-5100 / 01-800-726-7864 EXPORTADO POR: Samsung Electronics CO.,LTD. 416, Mae tan-3dong, Yeongtong - gu, Suwon City, Gyeonggi-do Korea...
