- Page 1 INSTALLATION, OPERATION AND SERVICE MANUAL GAS COOKER MODEL CPG Page 1 / 18...
-
Page 2: For Your Safety
CHAP 1 - INSTRUCTIONS TO PREVENT ACCIDENTS Keep this manual carefully to be able to refer to it in every case of need. • Keep appliance area clean and clear from combustibles. • The place where the machine is to be installed must be enough aerated, this is in order to supply the necessary air for combustion, to prevent reaching too high percentages of gas and to aid evacuation of the products of combustion. -
Page 3: Chap 2 - Installation
• If you cannot reach your gas supplier call the fire department. CHAP 2 - INSTALLATION 2.1 Preliminary instructions Installation must be carried out by following the instructions contained in this handbook and only by a licensed tradesman in accordance with local codes, or in absence of it, with the National Fuel Gas Code, ANSI Z 223.1 or with the Natural Gas Installation Code CAN/CGA-B149.1. - Page 4 3. Position the appliance level, adjusting the feet of the cooker. 4. Connect mains pipe to machine pipe (fig.1) using a mechanical filter and an interception cock. 5. Connect machine outlet pipe (fig. 1) to a suitable manifold that withstands high temperatures. 2.4 Connecting to the gas supply mains Before connecting up the gas consult the gas board, all the installation and maintenance operations should be carried out by the gas board or by authorized fitters.
-
Page 5: Technical Data
CHAP 4 - SPECIFICATION MODELS: CPG 1: Gas unit with a single tank of 10.56 gallons. CPG 2: Gas unit with two tanks of 10.56 gallons each. CPG 3: Gas unit with three tanks of 10.56 gallons each. - Page 6 CHAP 5 - PUTTING INTO OPERATION 5.1 Operations prior to starting WARNING: if you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Make sure the basin is clean, otherwise clean it as described in paragraph 7.1 If you are using the cooker for the first time, you need to thoroughly clean all the parts that can come into contact with foodstuffs.
- Page 7 After cooking, turn off the main burner by turning knob 1 of figure 3 onto position 1 of fig. 3a and turn off the pilot flame by turning it onto the off position (0 of fig. 3a), wait for at least five minutes before draining off the water by moving the lever into the open position and finally proceed with cleaning.
- Page 8 CHAP 7 - CLEANING AND MAINTENANCE Routine maintenance consists of daily cleaning all the parts that can come into contact with foodstuffs and of the periodical maintenance of the burners, nozzles and of the outlet pipes. The instructions to be followed for cleaning are listed below: ∗...
- Page 9 1. After making sure you have cut off the gas supply, open the door and unscrew the two screws fixing the pilot burner to the framework. 2. Unscrew the nuts fastening the thermocouple, the spark plug and the pipe of the pilot burner (pos.7 of fig.5).
- Page 10 A - water supply connection φ 1/2” B - water outlet connection φ 1” G - gas supply connection φ 1/2” Figure 1 - Overall dimensions and position of the piping CPG 1 – CPG 2 Page 10 / 18...
- Page 11 A - water supply connection φ 1/2” B - water outlet connection φ 1” G - gas supply connection φ 1/2” Figure 1 - Overall dimensions and position of the piping CPG 3 Figure 1b - Removable top flue grid assembly Page 11 / 18...
- Page 12 A - water supply connection φ 1/2” B - water outlet connection φ 1” G - gas supply connection φ 1/2” Figure 1 - Overall dimensions and position of the piping CPG 7/1 – CPG 7/2 Page 12 / 18...
- Page 13 4. Left panel 10. Under-panel 18. Door pivot 5. Rear panel 11. Front panel 6. Top 12. Water inlet knob Figure 2 - Gas cooker CPG 1 – 2 – 3 – 7/1 - 7/2 components Page 13 / 18...
- Page 14 1 Water supply jet 2 Cock to jet pipe 3 Water inlet cock 4 Water inlet knob 6 Water knob disk 7 Copper pipe from supply to cock Figure 2a – Water supply 1 Rubber overflow pipe 3 Outlet-cock pipe fitting 4 Outlet cock 5 Outlet-rubber pipe fitting 6 Outlet cock lever...
- Page 15 6 Outlet cock lever 7 Copper pipe from cock to jet 8 Lever extension 9 Rubber overflow pipe Figure 2b – CPG 2 – CPG 7/2 water outlet 1 - Water inlet knob 2 - Safety valve 3 - Valve reference...
- Page 16 1. Main burner 2. Union 3. Nozzle fixing nut 4. Main nozzle Figure 4 - Main burner 1. Pilot burner 3. Gas pipe 4. Thermocouple 5. Spacer 6. Pilot nozzle 7. Fixing nuts 8. Fixing plate Figure 5 – Pilot burner Page 16 / 18...
- Page 17 1. Gas supply pipe 2. Brass nut 3. Brass twin-cone 4. Pipe from valve to burner 5. Thermocouple 6. Pilot gas pipe 7. Pilot pipe-valve union 8. Valvle 9. Pressure tube screw 10. Pressure tube washer 11. Fixing washer 12. Fixing nut Figure 6 - Gas supply unit Figure 5a –...
