- Page 1 K-Phone ET401 Emergency Speakerphone Instruction Book Please read carefully before installation and operation Sentry (ET401A) Fortress (ET1401A) Commander (ET401A-OEM) Liberator (ET401A-LP)
- Page 2 Page 2...
-
Page 3: Table Of Contents
Wiring ................... 5 Telephone Lines ................5 Telephone Line Specifications ............5 Wiring Diagram ................6 Installation ..................7 Sentry (ET401A) ................7 Liberator (ET401A-LP) ..............8 Fortress (ET1401A) ..............9 Commander (ET401A-OEM) ............10 Settings ..................11 Programming ................12 Operation and Testing .............. -
Page 4: Introduction
Introduction Thank you for purchasing the K-Tech K-Phone ET401 Emergency Speakerphone. This vandal resistant speakerphone is designed to provide reliable communication in the event of an emergency. Each unit features a tone dialer capable of dialing five twenty-digit numbers, a voice activated location announcer with 10 second message, and remote, on-site, and off-site programming capabilities. -
Page 5: Wiring
Wiring We strongly recommend that the wires used to supply the telephone line to K-Tech emergency speakerphones be 20 AWG shielded, twisted pair. The shield must be continuous from the speakerphone through the traveling cable to the incoming telephone line termination. Make... -
Page 6: Wiring Diagram
Wiring Diagram K-Tech International Inc. Part # PCB009 Rev D. 12 - 30V ONLINE Connect PROG Telephone 2V 7mA Line shield to true earth Contacts ground at one end only! MICROPHONE RINGS Increase VOL. SPEAKER SERIAL # Page 6... -
Page 7: Installation
WHEN LIGHT FLASHES HELP IS ON THE WAY K-Tech International, Inc, Torrington, CT 5. Proceed to Settings on page 11. 6. Proceed to Programming on page 12. 7. Proceed to Operation and Testing on page 16. Page 7... -
Page 8: Liberator (Et401A-Lp)
4. Mount the rear enclosure placing the Ground Lug under one of these mounting screws. WHEN LIGHT FLASHES HELP IS ON THE WAY K-Tech International, Inc, Torrington, CT 5. Proceed to Settings on page 11. 6. Proceed to Programming on page 12. 7. Proceed to Operation and Testing on page 16. -
Page 9: Fortress (Et1401A)
3. Drill holes for four #8 security screws (included). WHEN LIGHT FLASHES HELP IS ON THE WAY K-Tech International, Inc, Torrington, CT 4. Remove the enclosure by removing the two nuts that secure it. 5. Proceed to Settings on page 11. -
Page 10: Commander (Et401A-Oem)
Commander (ET401A-OEM) 1. Using the faceplate as a template, align the microphone and speaker with the grill pattern; mark and install the mounting studs. 2. Mount the faceplate tightly against the back of the COP to avoid feedback between the microphone and speaker. -
Page 11: Settings
Settings Number of Rings Incoming The K-Phone ET401 Emergency Speakerphone will automatically answer an incoming call after either 5, 7, or 9 rings. You can easily set this number of rings by installing the jumper in the appropriate location. Factory default is 5 rings. Contacts MICROPHONE RINGS... -
Page 12: Programming
Programming Easy, voice prompted programming directs the entry of feature settings and plays back the information entered for confirmation. Programming is done via the built-in keypad, or remotely by any touch-tone telephone. NOTE: A 9 VDC battery is required for programming using the built-in keypad. -
Page 13: Voice Announcement
Voice Announcement 1 Voice Announcement 1 will automatically play when the emergency call is answered. Once the 10 second message has played, two- way communication is possible. For best results, record the announcement in a noise free environment. Speak clearly into the microphone or telephone handset. -
Page 14: Telephone Numbers
Voice Announcement 2 Voice Announcement 2 can be recorded to supply the called party with additional information. To play this announcement, the called party must hit “ * 2 ” (star two) on their telephone keypad. Activity Enter Voice Prompt Record Voice "Press pound to start Announcement 2... -
Page 15: Security Code
Timer Minutes This is the amount of time the K-Phone ET401 Emergency Speakerphone will remain on (unless the called party extends the timer). Activity Enter Voice Prompt Program Timer Minutes "Enter timer minutes" Enter time desired from 01 to "Zero five", beeps as number 99 minutes, or "0 0"... -
Page 16: Operation And Testing
Operation and Testing 1. Press the activating push-button. The visual indicator will turn on, dial tone will be heard for a few seconds, then the first programmed emergency telephone number will dial. If busy or there is no answer, the second number will be dialed, etc. -
Page 17: Troubleshooting
Troubleshooting When the activating push-button is pressed, there is no response from the K-Phone ET401 Emergency Speakerphone (i.e. no dial tone is heard, the visual indicator doesn’t light). 1. Check the connections to the microphone, speaker, LED, and button (N.O. contacts) 2. -
Page 18: Specifications
Enclosure 9 5/8" H x 6 1/2" D x 2 1/2" D (245 mm x 165 mm x 64 mm) Commander (ET401A-OEM) 9 1/2" H x 4 3/4" W x 1 3/4" D (241 mm x 121 mm x 45 mm) NOTE: The electronics in these products has been tested to Class B of Part 15 of the FCC rules. -
Page 19: Code Compliance
Code Compliance K-Tech has taken great care in ensuring that our telephone equipment meets all code requirements. There are however additional requirements that have to be met in order for the installation and operation to pass code. We will attempt to list requirements pertaining to the installation of our telephone equipment. -
Page 20: Fcc Notice For Part 68
If they do, you will be given advance notice so as to give you opportunity to maintain uninterrupted service. 6. If you experience with this equipment, please contact K-Tech International Customer Service at 1-800-993-9399 for repair/ warranty information. If your equipment is causing harm to the telephone network, the telephone company may request that you disconnect the equipment until the problem is resolved. -
Page 21: Fcc Notice For Part 15
FCC Notice for Part 15 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 22: Ic Notice
IC Notice NOTICE: The Industry Canada label identifies certified equipment. This certification means that the equipment meets telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Requirements document(s). The Department does not guarantee the equipment will operate to the user’s satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. -
Page 23: Service & Warranty Agreement
Service & Warranty Agreement To Order: notice. K-Tech will not be liable for any costs incurred by its customers in removal or • Mail your Purchase Order to: replacement of defective products. K-Tech International, Inc. P.O. Box 1025 K-Tech International, Inc.’s liability under this... - Page 24 Date Installed: Serial Number: Installer: Location: Phone Line Number: Phone Number(s) Dialed: Service/Security Company Dialed: K-Tech International, Inc. 56 Ella Grasso Avenue P.O. Box 1025 Torrington, Connecticut 06790 USA 1-800-993-9399 (860) 489-9399 – (860) 489-4399 Fax www.KTechOnline.com Sales@KTechOnline.com BOK029 020101...
