Qtum KDVR 1041 Installation And Operation Manual

Mpeg4 - 4/8/16 channel
Hide thumbs
Table of Contents

Advertisement

Quick Links

INSTALLATION/OPERATION

DIGITAL VIDEO RECORDER

(MPEG4 - 4/8/16 CHANNEL)
KD16-0205E

Advertisement

Table of Contents
loading

Related Manuals for Qtum KDVR 1041

Summary of Contents for Qtum KDVR 1041

  • Page 1: Digital Video Recorder

    INSTALLATION/OPERATION DIGITAL VIDEO RECORDER (MPEG4 - 4/8/16 CHANNEL) KD16-0205E...
  • Page 2 MPEG4-4/8/16Channel - Installation/ Operation Manual WARNING: To prevent a risk of fire of electric shock, do not expose this product to rain or moisture. • This installation should be made by a qualified service person and should conform to all local codes. •...

  • Page 3: Table Of Contents

    MPEG4-4/8/16Channel - Installation/ Operation Manual Contents FOR THE SAFETY OF CUSTOMERS…………………...………………………….…………………………4 DESCRIPTION OF PARTS AND FUNCTION…………...…………………………………………………..7 COMPOSITION OF UNIT…………………………………...……………………………………………………7 FEATURES …………………………………………………..……………………………….………………..8 DESCRIPTION OF PARTS AND FUNCTION ………………..…………….…………..……..……………….. 9 Front Panel……………………………………………………..………………………………..…………..9 Rear Panel………………………………………………………..………………………………………… …11 Connection diagram………………………………………………………………………………………….13 OSD Description..............................15 MENU………………………………………………………………...………………………………………..16 MENU TREE…………………………………………………………..…………………………………………16 Main Menu.…………………………………………………………..………………………………………..18 Display………………………………………………………………..………………………………………..18 Recording……………..………..……………………………………..………………………………………..19...

  • Page 4: For The Safety Of Customers

    MPEG4-4/8/16Channel - Installation/ Operation Manual 1. FOR THE SAFETY OF CUSTOMERS Caution before use Please read this manual for proper use. The cautions described in this manual contain very important information for the safe use, so, please follow the instructions. Please keep manual within reach for reference.
  • Page 5 MPEG4-4/8/16Channel - Installation/ Operation Manual Caution for proper usage During use In following cases, please turn off the power and remove the plug then, contact technical support. No picture being displayed. If smoke comes out of the device or when you smell something burning. If any substance is spilled into the device.
  • Page 6 MPEG4-4/8/16Channel - Installation/ Operation Manual Use the designated HDD Please use the designated HDD. Otherwise, recorder may operate improperly. Maker HDD Capacity 80GB, 160GB, 250GB, 320GB, 400GB Western Digital or Seagate Do not pull cable to disconnect from wall socket. It could damage the cable and cause fire.

  • Page 7: Description Of Parts And Function

    MPEG4-4/8/16Channel - Installation/ Operation Manual 2-1 COMPOSITION OF UNIT Standard Digital Video Recorder System Please read this manual before using Power User Remote Controller Battery ※ Accessories are subject to change without notice. 7/85...

  • Page 8: Features

    MPEG4-4/8/16Channel - Installation/ Operation Manual 2-2 FEATURES ● Convenience - User-friendly UI( Text Based User Interface) - Easy-to-use menu composition - Easy-to-use recorded data search (Time, Date, Motion, Alarm) ● Stability - Auto restart after power interruption DB structure offers data stabilization and best storage utilization ●...

  • Page 9: Description Of Parts And Function

    MPEG4-4/8/16Channel - Installation/ Operation Manual 2-3 DESCRIPTION OF PARTS AND FUNCTION 2-3-1 Front Panel (1) LED - REC : Recording status (When recording is on, the red light is blinking) - PWR : System Power On/Off (When power is on, the green light is lit up) (2) USB 2.0 PORT - USB2.0 connector (3) POWER BUTTON...
  • Page 10 MPEG4-4/8/16Channel - Installation/ Operation Manual (7) PLAY▶(▶) - Playback the recorded data. - Push two times to fast forward (8) REWIND (◀) - Playback in reverse PAUSE ( ▌▌) - To freeze picture on playback mode and live mode. 0) STOP / EJECT ( █ ) To stop playback and go back to live mode.
  • Page 12 MPEG4-4/8/16Channel - Installation/ Operation Manual (08) RS422 / 485 - 1 Serial Communication port for Pan / Tilt Camera (09) Alarm/Sensor - Alarm / 4 Sensor input / 1 output port (10) AC Power - AC 110~240 V (Free Voltage) ATTENTION When the video format is changed, the system should be re-booted The video format should be selected before booting...

  • Page 13: Connection Diagram

    MPEG4-4/8/16Channel - Installation/ Operation Manual 2-3-3 System Connection Diagram 13/85...

  • Page 14: Remote Controller

    MPEG4-4/8/16Channel - Installation/ Operation Manual 2-3-4. Remote Controller 1.Power : 2. Rec : Start & Stop Recording 3.ⓞ~⑨:Key for figure and character 4. PTZ: Controlling PTZ camera 5. OSD : Operating OSD ON/OFF 6. SEQ : Key for SEQ operation 7.

  • Page 15: Osd Description

    MPEG4-4/8/16Channel - Installation/ Operation Manual 2-3-5. OSD Description Recording on NORMAL: Shows the recording Mode. Shows “Alarm recording * 16/8channel doesn’t show recording icon as 4channel. mode / Motion recording If the user programmed “schedule recording” and current mode/ Power loss”/ Video time is out of range, “STANDBY”...

  • Page 16: Menu

    MPEG4-4/8/16Channel - Installation/ Operation Manual 3-1. Menu tree Monitor Adjustment (4CH Only) Main Menu Camera Covert Camera Name Display Set OSD On/Off Event Clear Audio Repeat Recording Watermark Record Resolution Save and exit Global Parameter Recording Set Frame Rate Normal Recording Recording Quality Alarm Recording Motion Recording...
  • Page 17 MPEG4-4/8/16Channel - Installation/ Operation Manual IP address Gate Way Network Set Use Dynamic IP-No Net Mask DNS Server DVR Port Web Server Port Save and Exit XDSL User ID XDSL Password DDNS User ID Use Dynamic IP-Yes DDNS Password Save and Exit Event Notification E-Mail Registration E-Mail Report...

  • Page 18: Main Menu

    MPEG4-4/8/16Channel - Installation/ Operation Manual 3-2 Main Menu The following menu will appear on OSD when you press the menu button. MAIN MENU ▶DISPLAY SET RECORDING SET SYSTEM SET NETWORK SET EVENT NOTIFICATION Use UP( ) or DOWN( ) on the front panel to move to next menu. To move to the submenu, press the “SELECT”...

  • Page 19: Recording Set

    MPEG4-4/8/16Channel - Installation/ Operation Manual Camera Name Camera title can be written on the screen. OSD On/Off OSD on/ off : Select the OSD display is on/off Set Display Sequence SET DISPLAY SEQUENCE ▶FULL DISPLAY SEQUENCE QUAD DISPLAY SEQUENCE START FULL DISPLAY SEQUENCE START QUAD DISPLAY SEQUENCE Sequence dwell time can be selected between 5,10,15,30,45,60 sec.

  • Page 20: Recording Parameter

    MPEG4-4/8/16Channel - Installation/ Operation Manual Global Parameter All the setup values for Audio/ Repeat/ Watermark / Resolution will be applied globally to all channels. Normal Recording Executes continuous recording according to the designated set-up value. Alarm recording Executes recording when sensor is tripped. Motion recording Executes recording when motion is captured.
  • Page 21 MPEG4-4/8/16Channel - Installation/ Operation Manual Audio Recording(4CH) 4CH : On/Off. When audio is “on”, the audio will be input globally. RECORDING PARAMETER ▶AUDIO 1 RECORDING: OFF / CH1 AUDIO 2 RECORDING: OFF / CH2 AUDIO 3 RECORDING: OFF / CH3 AUDIO 4 RECORDING: OFF / CH4 REPEAT RECORDING OFF WATERMARK OFF...

  • Page 22: Normal Recording

    MPEG4-4/8/16Channel - Installation/ Operation Manual Normal Recording NORMAL RECORDING (4channel Only) ▶CH1 FRAME RATE : 30FPS CH2 FRAME RATE : 30FPS CH3 FRAME RATE : 30FPS CH4 FRAME RATE : 30FPS CH1 RECORDING QUALITY : HIGH CH2 RECORDING QUALITY : HIGH CH3 RECORDING QUALITY : HIGH CH4 RECORDING QUALITY : HIGH SAVE AND EXIT...

  • Page 23: Alarm Recording

    MPEG4-4/8/16Channel - Installation/ Operation Manual Recording Quality Selects between High, Mid, Low . Save and Exit All set-up values will be stored and you will move to the next menu. Alarm Recording Either one is taken among 4 sensors, the recording will be activated as per set-up value. ALARM RECORDING (4channel Only) ▶CH1 FRAME RATE : 30FPS...
  • Page 24 MPEG4-4/8/16Channel - Installation/ Operation Manual ALARM RECORDING (8/16channel Only) ▶ PAGE : 1 (8/16CH Only) FRAME RATE : 8FPS FRAME RATE : 8FPS FRAME RATE : 8FPS FRAME RATE : 8FPS RECORDING QUALITY : HIGH RECORDING QUALITY : HIGH RECORDING QUALITY : HIGH RECORDING QUALITY : HIGH POST ALARM DURATION : 5sec...

  • Page 25: Motion Recording

    MPEG4-4/8/16Channel - Installation/ Operation Manual Motion Recording MOTION RECORDING (4channel Only) ▶CH1 FRAME RATE : 30FPS CH2 FRAME RATE : 30FPS CH3 FRAME RATE : 30FPS CH4 FRAME RATE : 30FPS CH1 RECORDING QUALITY : HIGH CH2 RECORDING QUALITY : HIGH CH3 RECORDING QUALITY : HIGH CH4 RECORDING QUALITY : HIGH SETUP MOTION...

  • Page 26: Motion Sensitivity

    MPEG4-4/8/16Channel - Installation/ Operation Manual Recording Quality Selects between High, Mid, Low . Setup Motion SETUP MOTION ▶PAGE : 1 (8/16CH Only) POST MOTION : 30 SEC MOTION AREA MOTIION AREA MOTION AREA MOTION AREA MOTION SENSITIVITY: HIGH MOTION SENSITIVITY: HIGH MOTION SENSITIVITY: HIGH MOTION SENSITIVITY: HIGH SAVE AND EXIT...

  • Page 27: Schedule Recording

    MPEG4-4/8/16Channel - Installation/ Operation Manual Schedule Recording SCHEDULE RECORDING (4channel Only) ▶CH1 FRAME RATE : 30FPS CH2 FRAME RATE : 30FPS CH3 FRAME RATE : 30FPS CH4 FRAME RATE : 30FPS CH1 RECORDING QUALITY : HIGH CH2 RECORDING QUALITY : HIGH CH3 RECORDING QUALITY : HIGH CH4 RECORDING QUALITY : HIGH SETUP SCHEDULE...
  • Page 28 MPEG4-4/8/16Channel - Installation/ Operation Manual Recording Quality Selects between High, Mid, Low . Setup Schedule SCHEDULE SETUP SAVE AND EXIT “SEL” button is used for selecting relevant time and day. Arrow Key will be used to move setting. NOTE To change recording settings (resolution, mode, frame rate, etc), “Recording” must be “off”.

  • Page 29: System Set

    MPEG4-4/8/16Channel - Installation/ Operation Manual Recording Priority RECORDING PRIORITY PRIORITY: NORMAL ▶1 PRIORITY: MOTION PRIORITY: SCHED PRIORITY: ALARM SAVE AND EXIT Sets the priority between 4 types of recording methods. If Normal is 1 priority, the recording is proceeded as per normal recording’ setup value . System Set SYSTEM SET ▶BASIC...

  • Page 30: Date Format

    MPEG4-4/8/16Channel - Installation/ Operation Manual Initialization All the menu settings will be returned to the factory default. To initialize the system, “recording off” is required. Date Format Can select among the formats, mm-dd-yyyy / dd-mm-yyyy, yyyy-mm-dd. If date format needs to be changed, “Recording off”...

  • Page 31: Client Account

    MPEG4-4/8/16Channel - Installation/ Operation Manual Client Account CLIENT ACCOUNT ▶ADD NEW ACCOUNT DELETE ACCOUNT SAVE AND EXIT CLIENT LIST Client on the network will be registered at “Add New Account” . User ID & Password has to be registered at the system first to connect with a ‘user level’ . But, administrator can access without registering.
  • Page 32 MPEG4-4/8/16Channel - Installation/ Operation Manual PTZ Menu ▶PAN / TILT / ZOOM ▶FOCUS ▶SETUP SETUP Channel : 1 ~16 ID : OFF, 1 ~15 Protocol : Pelco-D ~ P Baud Rate : 2400, 4800, 9600BPS Save and Exit Protocol is available for Pelco D, P / Baud Rate can be selected among 2400, 4800, 9600BPS. 32/85...

  • Page 33: Network Set

    MPEG4-4/8/16Channel - Installation/ Operation Manual 3. Network Set NETWORK SET ▶USE DYNAMIC IP: NO IP ADDRESS :000.000.000.000 GATEWAY :000.000.000.000 NETMASK :000.000.000.000 DNS SERVER :000.000.000.00 DVR PORT 2000 WEBSERVER PORT 80 SAVE AND EXIT To enter Network Set menu, system ask for password (default is 00000000). When user is using the fixed IP, each address is required to be filled out as per network environment.

  • Page 34: Evnt Notification

    MPEG4-4/8/16Channel - Installation/ Operation Manual Event Notification EVENT NOTIFICATION ►E-MAIL REGISTRATION E-MAIL REPORT NOTIFICATION OUT SAVE AND EXIT E-MAIL REGISTRATION ►USER1 USER2 USER3 SENDER MAIL ID SENDER DOMAIN SEND TEST MAIL SAVE AND EXIT At E-Mail registration menu, user must register the e-mail address to receive several “Event Notification “. To register the e-mail address, 1) input the address 2) push “Save and Exit”...

  • Page 35: Search

    MPEG4-4/8/16Channel - Installation/ Operation Manual 4. Search SEARCH ▶DATE/TIME SEARCH CALENDAR SEARCH BACKUP Date / Time Search If you select date/time search, the following will be shown. DATE/TIME SEARCH ▶EVENT : ALL : INTERNAL DATE : 11-12-2004 13:10:50 PLAY the (▲),(▼) buttons select the clause . When you select the specific time/date, then select “Play”, which executes the playback.
  • Page 36 MPEG4-4/8/16Channel - Installation/ Operation Manual It shows where the recorded data is located at a sight . Using “→, ←”buttons, it is available to move specific time/date . To enter sub-menu(Time), please use “SEL” button. Day(11, eleven) will be changed ‘up and down(↑↓)’ key. Buttons “Search”...

  • Page 37: Backup

    MPEG4-4/8/16Channel - Installation/ Operation Manual Back Up 1. INTERNAL BACKUP ▶BACKUPDEVICE: CD-R DEVICE FORMAT FILE FORMAT: EXCLUSIVE/AVI FROM: 12-07-2004 12:46:30 :12-07-2004 12:47:30 CHANNEL : 1 CALCULATING BACKUP SIZE TRANSFER FREE/TOTAL SPACE 49M/245M REQUIRED SPACE 60M: Backup Device Internal CD-R. > Note : 1.
  • Page 38 MPEG4-4/8/16Channel - Installation/ Operation Manual Channel When you select exclusive, all channels can be downloaded at the same time. But, only one channel can be selected in case of AVI file. Transfer Downloading the backup data to internal disk . Percentage during downloading will be shown. >...

  • Page 39: File Format

    MPEG4-4/8/16Channel - Installation/ Operation Manual File Format Exclusive or Avi file is available . Avi file is played with window media player (codec required) and exclusive file will be played with our own player. Player is downloaded automatically together with video data when exclusive is selected. From/ To You can set up the time which is required to be backed up to the memory stick .
  • Page 40 MPEG4-4/8/16Channel - Installation/ Operation Manual * PC Playback 1. Insert USB device 2. Folders & Files on device: Download, BK_Play, Index, Kerberos, KW Client 3. Double Click “BK_Play” 4. Player opens, click “play” button NOTE For system stability, we highly recommend that the recording is turned off during downloading the data to USB device.

  • Page 41: Client Program

    MPEG4-4/8/16Channel - Installation/ Operation Manual 5. CLIENT PROGRAM 5-1. Network Connection Minimum PC specification (4, 8/16CH) CPU : 4CH- Pentium III 750MHz over, 8/16CH- Pentium Ⅳ 7GHz over. Graphic Memory : 4CH- 32M over, 8/16CH – 64M over. IP Insertion Connection will be done just writing DVR IP address on the Internet Explorer window.
  • Page 42 MPEG4-4/8/16Channel - Installation/ Operation Manual Termination of Live monitoring Live monitoring will be terminated when user pushes “Live Off” button. Live monitoring will be re-started when user pushes “Live On” button.. System & Local System means the DVR. Local means Remote PC as client Recording &...
  • Page 43 MPEG4-4/8/16Channel - Installation/ Operation Manual System & Local recording 1) system recording To start the recording on the DVR via client PC, press the recording button, when the system icon is on green. Shadow bottom is shown as seen in blue circle. Please check system is on the recording mode.
  • Page 44 MPEG4-4/8/16Channel - Installation/ Operation Manual Local playback When “Local” button is activated (green one), it will be operated . When push the Play (▶), the window besides is shown. On clicking the “OK” button then set the start & end time. Please check either ‘Download’ or ‘Live Backup’.
  • Page 45 MPEG4-4/8/16Channel - Installation/ Operation Manual Select the number and push ‘start’ button. Then, local playback will be done as above. 45/85...
  • Page 46 MPEG4-4/8/16Channel - Installation/ Operation Manual Remote playback It works when system button is in green. When push the Play button(▶), the window is shown besides. After input “start” and “end” time, push “OK” button. Then, list will be shown above. 46/85...
  • Page 47 MPEG4-4/8/16Channel - Installation/ Operation Manual Select the number and push ‘start’ button. Then, remote playback will be done as above. 47/85...
  • Page 48 MPEG4-4/8/16Channel - Installation/ Operation Manual Setup Setup menu is composed of 1) Remote Setup 2) Local Setup 3) Firmware Upgrade menu. Remote setup Note: When the main system is entering “ menu OSD”, remote setup doesn’t work. “OSD updating failure” message will be displayed. That’s the reason priority is at the system operator.
  • Page 49 MPEG4-4/8/16Channel - Installation/ Operation Manual Among ‘System Set’ menu, PTZ Camera & Schedule Backup menu are unavailable for 4channel DVR. If is designed for 8,16channel only. Others are the same as local system configuration. ‘Event Set’ menu has 1) E-Mail registration 2) E-Mail report 3) Notification out . The menu is same as local menu tree.
  • Page 50 MPEG4-4/8/16Channel - Installation/ Operation Manual Local setup The detail will be shown when you click the ‘Local Setup’ menu. 1) Draw Mode: User can select between YUV format using Direct X or RGB. 2)Date Format: Select the time/ date format . 3)Save Format: Select the saving file format among JPEG or BMP.
  • Page 51 MPEG4-4/8/16Channel - Installation/ Operation Manual Firmware Upgrade When user select ‘Firmware Upgrade’ menu, if higher version exits in C:\KWClient\Upgrade fold, ‘New Program Found!’ message will be shown besides. If higher version in C:\KWClient\Upgrade fold, ‘New Program Not Found’ message will be displayed.
  • Page 52 MPEG4-4/8/16Channel - Installation/ Operation Manual When firmware Upgrade is done successfully, ‘Firmware Upgrade success!’ message will be displayed. The local system should be re-booted . 52/85...
  • Page 53 MPEG4-4/8/16Channel - Installation/ Operation Manual Download, Image Save, Two-Way audio, Stop, Connect Download It is for transmitting the recorded data on HDD to client PC. When ‘download’ button is pushed, User select ‘Start time’ and ‘End time’ to download and push ‘OK’ button. 53/85...
  • Page 54 MPEG4-4/8/16Channel - Installation/ Operation Manual Select the number among list for ‘Start Time’ . Select the number among list for ‘End Time’. 54/85...
  • Page 55 MPEG4-4/8/16Channel - Installation/ Operation Manual Processing bar will be shown above and wait till downloading is finished. When downloading is finished, push ‘Local’ button, which turns in green color. And, push play(▶) button. Select ‘Start Time’ & ‘End Time’ and check (∨) ‘Download’.
  • Page 56 MPEG4-4/8/16Channel - Installation/ Operation Manual Then, the download list will be shown besides. Select the number which you want to play. Local Play (from downloaded files) will be done like above. 56/85...
  • Page 57 MPEG4-4/8/16Channel - Installation/ Operation Manual Image Save It stands for saving format. Either JPEG or BMP . The file will be stored C:\KWClient\Save . Stop It is for stopping Downloading. Connect Re-connecting when access is failed P an/Tile, Zoom/Focus, OSD 1) Pan / Tilt Using arrow key, controls the Pan/Tilt ( 4 channel doesn’t support P/T/Z control) 2) Zoom / Focus...
  • Page 58 MPEG4-4/8/16Channel - Installation/ Operation Manual Event Clear The relevant OSD turns to green color when DVR has an event like Alarm, Motion, Video loss. Reset for event button (event clear) Timer It shows the client PC timer when monitoring is working. On the other hand, it shows the time the recording data belongs to during playback.

  • Page 59: Q & A

    MPEG4-4/8/16Channel - Installation/ Operation Manual Q & A Q : The message “ Can’t display the page” is shown and failed to connect to DVR , though input the IP address or domain name on the internet explorer window. A : 1) DVR is out of work or 2) a problem on the network connection. Please check the DVR is working properly and , if it does, check the connection both DVR and PC .
  • Page 60 MPEG4-4/8/16Channel - Installation/ Operation Manual Q : Client program(internet explorer) was disappeared when I have entered new several web site. A : Since some web site is possible to remove the existing explorer , please disable “ re-use the window in executing shortcut” under “ Tools-> Internet Option-> advance( advance is located under “Search”.

  • Page 61: Appendix 1

    MPEG4-4/8/16Channel - Installation/ Operation Manual Appendix 1. 1. HDD INSTALLATION 1) Components The attached components are as follows, ① 0.8“ Round Screw : 4 ② 0.6“ Round Screw : 2 ③ Left Complementary Device : 1 ④ 40 Pin Connector Cable : 1 ⑤...
  • Page 62 MPEG4-4/8/16Channel - Installation/ Operation Manual ① 0.8“ Round Screw ② 0.6“ Round Screw ③ Left Complementary Device for fixing the HDD ④ HDD ⑤ 40 Pin Connector ⑥ HDD Power Connector ⑦ KERBEROS Main Board ⑧ HDD Power Cable ⑨ HDD Connector Cable 2.

  • Page 63: Appendix 2

    MPEG4-4/8/16Channel - Installation/ Operation Manual Appendix 2 SENSOR INSTALLATION 1. Components 1) External Sensor : 1 (You should prepare one set) 2) DVR System : 1 2. Inner Circuit for Sensor Input The inner circuit of Mpeg 4 DVR is as follows, ①...
  • Page 64 MPEG4-4/8/16Channel - Installation/ Operation Manual Absolute Maximum Ratings Parameter Symbol Rating Unit Forward current *1Peak forward current I FM Input Reverse voltage Power dissipation Collector-emitter voltage V CEO Emitter-collector voltage V ECO Output Collector current Collector power dissipation Total power dissipation P tot *2Isolation voltage V iso...
  • Page 65 MPEG4-4/8/16Channel - Installation/ Operation Manual 3. SENSOR Install Processing ① Please refer the below block diagram. SENSOR 12V DC ?? V DC 2.2k 3.3k Or 10k PC817 SENSOR IN Outlet Point 65/85...

  • Page 66: Appendix 3

    MPEG4-4/8/16Channel - Installation/ Operation Manual Appendix 3 INSTALLING KERBEROS WEB CLIENT ON WINDOW XP SERVICE PACK 2. 1) Security Setup Tools-> Internet Options-> Security -> Select “Customer Level” Select “ Allow script-initiated windows without Size or position constraints”-> Enable. 66/85...
  • Page 67 MPEG4-4/8/16Channel - Installation/ Operation Manual Select “ Download unsigned Active controls”-> Prompt Select “ Automatic Prompting for Active X controls”-> Disable 67/85...
  • Page 68 MPEG4-4/8/16Channel - Installation/ Operation Manual 2) Connection Click here as described Select “ Temporary Allow Pop-ups” Click “ To help protect security, Internet Explorer stopped this site from installing an Active X control on your computer. Click here for options…” 68/85...
  • Page 69 MPEG4-4/8/16Channel - Installation/ Operation Manual Select “Install Active X Control “ Select “Install” and then ‘Log-In’ box will be shown. 69/85...

  • Page 70: Appendix 4

    MPEG4-4/8/16Channel - Installation/ Operation Manual Appendix 4 DYNAMIC IP ( Supporting DDNS Server) 1. visit www.dyndns.org to get the DDNS user ID & PW as well as domain name. 2. Click “Dynamic DNS” menu . 70/85...
  • Page 71 MPEG4-4/8/16Channel - Installation/ Operation Manual 3. Select “How To” menu. 71/85...
  • Page 72 MPEG4-4/8/16Channel - Installation/ Operation Manual 4. Select “account” menu. 72/85...
  • Page 73 MPEG4-4/8/16Channel - Installation/ Operation Manual mark ∨ “I have read and agree to the Acceptable Use Policy above” Input “Username” & “Password”. ( for exam. Username : eddydvr, PW: kerberosdvr) Check account registration is done successfully. 73/85...
  • Page 74 MPEG4-4/8/16Channel - Installation/ Operation Manual 7. Select “ Add Host Form” to create the domain name. 74/85...
  • Page 75 MPEG4-4/8/16Channel - Installation/ Operation Manual 1) Input “Hostname” . Hostname is the same one as “username” ( for exam: eddydvr) 2) You should select “ dyndns.org”, which is limited on our system. 3) Current dynamic IP will be shown below 4) After checking 1)~3), select “Add Host”...

  • Page 76: Appendix 5

    MPEG4-4/8/16Channel - Installation/ Operation Manual Appendix 5 SETUP FOR DVR PORT/ WEB SERVER PORT USING IP SHARING ROUTER NETWORK SET ▶USE DYNAMIC IP: NO IP ADDRESS :000.000.000.000 GATEWAY :000.000.000.000 NETMASK :000.000.000.000 DNS SERVER :000.000.000.00 DVR PORT 2000 WEBSERVER PORT 2001 SAVE AND EXIT 1) To use IP sharing Router, “Use Dynamic IP”...
  • Page 77 MPEG4-4/8/16Channel - Installation/ Operation Manual (3) ‘DDNS’ Setup on IP sharing router DDNS configuration is no needed in case of fixed IP. (4) Address and port number input on the internet explorer window. Please input the following format , http://address:web server port. If the system is on the dynamic IP environments and the address configured (3) is abc.dyndns.org and the same address and port is designated like (2), To connect DVR1, http://abc.dyndns.org:2501, to connect DVR2 , http://abc.dyndns.org:2601.

  • Page 78: Appendix 6

    MPEG4-4/8/16Channel - Installation/ Operation Manual Appendix 6 MAKING PARTITION ON EXTERNAL USB HDD To back up to USB HDD, the USB HDD should be formatted first on PC. We are supporting FAT32 file system of which maximum size is 30GB at one partition. Please refer to the following procedure to make a partition and format on PC.
  • Page 79 MPEG4-4/8/16Channel - Installation/ Operation Manual 2. Select “Computer Management” 3. Select “Disk Management”. 79/85...
  • Page 80 MPEG4-4/8/16Channel - Installation/ Operation Manual 4. Click right mouse button and select “New Partition”. 5. Follow “New Partition Wizard” procedure as below. 80/85...
  • Page 81 MPEG4-4/8/16Channel - Installation/ Operation Manual 7. Maximum is 30GB at FAT32 file format. 81/85...
  • Page 82 MPEG4-4/8/16Channel - Installation/ Operation Manual 82/85...
  • Page 83 MPEG4-4/8/16Channel - Installation/ Operation Manual 10. At this stage, New Partition has been made. 11.Check New partition was created correctly.(Format will be executed automatically) 83/85...
  • Page 84 MPEG4-4/8/16Channel - Installation/ Operation Manual 12. Check New Partition was created correctly 84/85...

  • Page 85: Appendix 7 (Specification)

    MPEG4-4/8/16Channel - Installation/ Operation Manual Appendix 7 SPECIFICATION *Design and product specifications subject to change without notice # 913, Byucksan/ Kyungin Digital Valley II, 481-10 Gasan-dong, Geumcheon-gu, Seoul, Korea Tel: 82-2-2113-2081 / Fax: 82-2-2113-2089 / Website: www.digital-qtum.com 85/85...
