Operation Manual for SLKD-M801 Underground
Metal Detector / Underground Metal Pipe Detector
Product Introduction ......................................................................................................................2
Main Application.......................................................................................................................2
Operation Simulation Diagram .....................................................................................................3
Instrument Structure and Introduction .....................................................................................3-7
Names of Machine Parts............................................................................................................3-4
Introduction of Operating Button...............................................................................................4-6
Introduction of Signaling Display Device..................................................................................6-7
................................................................................................................ ... ...... .. ...8-10
How to Operate............................................................................................................... ... .... ..11-14
Troubleshooting............................................................................................................... ... ...... .14
Technical Parameters.............................................................................................................. 14-15
Safety Measures................................................................................................. ......................16
Guide for After-sale Services............................................................................................. .....16
Copyright Statement......................................................................................................... .......17
Contents
............................................................................................................15-16
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SLKD-M801 and is the answer not in the manual?

Questions and answers

Related Manuals for PQWT SLKD-M801

Summary of Contents for PQWT SLKD-M801

  • Page 1: Table Of Contents

    Operation Manual for SLKD-M801 Underground Metal Detector / Underground Metal Pipe Detector Contents Product Introduction ........................2 Main Application........................2 Operation Simulation Diagram .....................3 Instrument Structure and Introduction ..................3-7  Names of Machine Parts......................3-4  Introduction of Operating Button....................4-6  Introduction of Signaling Display Device..................6-7 How to Install ........................

  • Page 2: Product Introduction

     Product Introduction SLKD-M801 metal detector is the patented product which developed independently by Hunan Puqi Geologic Exploration Equipment Institute, patent number: 201230519707.5 . SLKD-M801 metal pipeline detector own better performance, more accurate.  Main Application...

  • Page 3: Operation Simulation Diagram

     Operation Simulation Diagram  Instrument Structure and Introduction  Names of Machine Parts 1. Detection disk 2. PVC bar...

  • Page 4: Introduction Of Operating Button

    3. Connecting device 4. Metal bar 5. Display table 6. Grab handle 7. Hand Bracket 8. Host Machine 9. Connecting rod and nut  Introduction of Operating Button Main Switch The instrument power switch 2. GBAL There exist trace metals more or less in the soil and rock or the mine area. Detector probe generates a signal when close to the ground, forming a mineralization reaction interference.
  • Page 5 This knob to adjust the instrument during use according to the actual situation, the reactions to adjust the instrument so that the instrument is in top working condition. This is what we want to be transferred to the balance point, the signal source is detected only when the instrument is issued until the valid alarm.

  • Page 6: Introduction Of Signaling Display Device

    Note : Manipulator must press reset button after adjusting SENS knob every time. Phone Out SLKD-M801 instrument can be equipped with headphones. After plug in headphones, external speakers sound interruption, the operator can hear the sound from the headset, so that operating in a noisy or night environment. Use the headset to get battery saving, meanwhile it is easy to determine the sound subtle changes, so as to achieve better detection results.
  • Page 7 3. Micro Signal indicator When this light display, the instrument is sensitive to detect small objects, on behalf of a small object buried deeper. 4. Signal Indicator When an object is detected or sensed electromagnetic signal source, the intensity of this light display will represent the size of the object to be detected or buried depth.

  • Page 8: How To Install

     How to Install 1. Connecting PVC bar with detection disk. First remove detection disk connecting rod and the nut, and then use connecting rod and nut fix PVC bar on the detection disk, as showed in Figure 1.
  • Page 9 2. Connect the host machine with detection disk using connecting device.
  • Page 10 3. Insert detection disk plug into detection disk interface of host machine. 4. Place 8 AA battery into the battery box , turn on the power switch, you can begin to detect preheating . Kindly Reminder: Please use the rechargeable AA battery to avoid the environmental pollution.

  • Page 11: How To Operate

     How to Operate SLKD-M801 detector is a simple, convenient and practical, superior performance of instrument . Operating methods as follows : First, we should note that whatever the detection method to use , should pay attention to keep the probe from the surface corresponding height, the probe should not be directly caused by friction with the ground to make equipment not work properly or damage to the instrument.
  • Page 12 In the face of metal, have a greater sound, there will be a clear response on the dashboard.  Mineral Prospecting With SLKD-M801 type instrument can detect buried mineral deposits which not very deep, including natural gold bullion, pulse gold deposit sand deposit, and so on all kinds of high-grade ore .
  • Page 13 For copper, iron, tin and other metal ore, composition and grade level cause different signal, the operator can do experiment with a standard ore, to see reactions of it to determine the distinction of ordinary rocks and minerals.  Detection Example The description above of the mode of instrument operation, the operator can use the instrument according to the specific circumstances.

  • Page 14: Troubleshooting

    3-5 minutes, if the local temperature is too low, please extend the warm-up time . 7. if boot , power light is off . Check the batteries if there is enough battery power.  Technical Parameters Model No. : SLKD-M801 Search Systems: Magnetoelectric Effect Operation Method: Detection Disk...

  • Page 15: Maintenance And Repair

    Power Consumption: 0.6W Power Supply: DC12V Working Temperature: -10℃—40℃  Maintenance and Repair SLKD-M801 is a instrument with sophisticated design and exquisite workmanship. The following suggestions will help you maintain the product well and prolong its service life. 1. Cleaning The part of the probe is the most easily soiled.

  • Page 16: Safety Measures

    4. Batteries The batteries should be placed as carved symbols, if long-term does not boot, please remove the batteries to avoid corruption in the machine box. 5. Magnetization Instrument should be placed in a moisture-proof and dry place. Can not be placed with other radiation source, electromagnetic products together to prevent the instrument from being magnetized, caused the instrument can not properly use and the program confusing.

  • Page 17: Copyright Statement

     Copyright Notice 1. Hunan Puqi Geologic Exploration Equipment Institute has the final interpretation of the operating instructions. 2. Hunan Puqi Geologic Exploration Equipment Institute reserves right to modify equipment specification without any advance notice. 3. All pictures for reference only in operation manual, please in kind prevail. 4.
