Operation Manual for SLKD-M802 Underground
Metal Detector / Underground Metal Pipe Detector
Product Introduction .............................................................................................................................2
Main Application....................................................................................................................... ... . . . 2
Operation Simulation Diagram ............................................................................................................3
Instrument Structure and Introduction ........................................................................................4-10
Names of Machine Parts...................................................................................................................4
Introduction of Operating Button................................................................................................5-7
Introduction of Signaling Display Device.....................................................................................7-8
Introduction of external power supply................................................................ ........................8-10
................................................................................................................ ... ...... .. .. 10-12
How to Operate................................................................................................................. .. . ... ..13-16
Troubleshooting............................................................................................................... ... ...... .17
Technical Parameters...............................................................................................................17-18
Safety Measures...................................................................................................................... .. . .19
Guide for After-sale Services............................................................................................. .... . . .19
Copyright Statement......................................................................................................... .... . . . . 20
Contents
.......................................................................................................... ..18
1
Advertisement
Table of Contents
Related Manuals for PQWT SLKD-M802
Summary of Contents for PQWT SLKD-M802
-
Page 1: Table Of Contents
Operation Manual for SLKD-M802 Underground Metal Detector / Underground Metal Pipe Detector Contents Product Introduction ..........................2 Main Application..........................2 Operation Simulation Diagram ......................3 Instrument Structure and Introduction ..................4-10 Names of Machine Parts........................4 Introduction of Operating Button....................5-7 ... -
Page 2: Product Introduction
Product Introduction SLKD-M802 underground metal pipe detector is the patented product which developed independently by Hunan Puqi Geologic Exploration Equipment Institute, patent number: 201230519707.5 .SLKD-M802 underground metal pipe detector is a built-in automatic sensitivity adjustment, metal sort discrimination, easier to use , high-performance equipment. -
Page 3: Operation Simulation Diagram
Operation Simulation Diagram... -
Page 4: Instrument Structure And Introduction
Instrument Structure and Introduction Names of Machine Parts 1. Detection disk 2. PVC bar 3. Connecting device 4. Metal bar 5. Display table 6.Grab handle 7. Hand Bracket 8. Host Machine 9. Connecting rod and nut... -
Page 5: Introduction Of Operating Button
Introduction of Operating Button 1. Main Switch The instrument power switch 2. GBAL There exist trace metals more or less in the soil and rock or the mine area. Detector probe generates a signal when close to the ground, forming a mineralization reaction interference. - Page 6 5. Phone Out SLKD-M802 instrument can be equipped with headphones. After plug in headphones, external speakers sound interruption, the operator can hear the sound from the headset, so that operating in a noisy or night environment. Use the headset to get battery saving, meanwhile it is easy to determine the sound subtle changes, so as to achieve better detection results.
-
Page 7: Introduction Of Signaling Display Device
Sometimes we choose the detection mode corresponding to select the working mode , an effective response to the detection of cognitive pattern generation, so that the instrument is more accurate and effective work . (1) Under CONVE state, the instrument will response no matter the GROBAL mode or RECOG mode when detecting the object. - Page 8 There are two buttons at the bottom of indicating meter - Reset Button , also known as zero button. If you hold the button down , the instrument will always be in reset state , will not be reacted for any signal.
-
Page 9: Introduction Of External Power Supply
Introduction of external power supply 1. Battery Level Indicator This light that represents the battery cartridge capacity situation will affect the normal use of the instrument when the power is low . 2. Battery Test Button This button can test our battery power is sufficient and can be used normally or not. When we press this button, from the four battery indicator light to know battery condition, to determine whether they should be charged . -
Page 10: How To Install
Power Line Jack Here is used to connect the instrument host, and should be properly connected and keep the jack clean and dry. How to Install 1. Connecting PVC bar with detection disk. First remove detection disk connecting rod and the nut (Figure 1 ), and then use connecting rod and nut fix PVC bar on the detection disk ( Figure 2). - Page 11 2. Connect the host machine with detection disk using connecting device.
- Page 12 3. Insert detection disk plug into detection disk interface of host machine. 4. Place 8 AA battery into the battery box , turn on the power switch, you can begin to detect preheating . Kindly Reminder: Please use the rechargeable AA battery to avoid the environmental pollution.
-
Page 13: How To Operate
How to Operate SLKD-M802 Underground Metal Detector is a simple, convenient and practical, superior performance of instrument . Operating methods as follows : First, we should note that whatever the detection method to use, should pay attention to keep the probe from the surface corresponding height, the probe should not be directly caused by friction with the ground to make equipment not work properly or damage to the instrument. - Page 14 the ground will not change the critical sound, only in the face of the metal target , the signal will send out. 6. If the probe is close to the ground sounds small, raised the probe, hold the reset button down, rotate the RECOG knob to the right < clockwise >, and then release the button close to the ground to try again, if still small voice, adjust once again until probe lift -and-drop voice became unchanged.
- Page 15 . Mineral Prospecting With SLKD-M802 type instrument can detect buried mineral deposits which not very deep, including natural gold bullion, pulse gold deposit sand deposit, and so on all kinds of high-grade ore .
- Page 16 case , we should first put metal furniture moved out of the house, a slight decrease of the sensitivity of the instrument and carefully adjusted the balance . When the probe found that there is a small metal debris will be cleared out, by over- meticulous cleanup, after the shallow soil layer of metal objects dug up, then search of the deeper site.
-
Page 17: Troubleshooting
3-5 minutes, if the local temperature is too low, please extend the warm-up time . 7. if boot , power light is off . Check the batteries if there is enough battery power. Technical Parameters Model No. : SLKD-M802 Search Systems: Magnetoelectric Effect Operation Method: Detection Disk Maximum Detection Depth: 3 Meters Power Supply System: 8*1.5VAA—NIH/R6P... -
Page 18: Maintenance And Repair
Working Temperature: -10℃—40℃ Maintenance and Repair SLKD-M802 is a instrument with sophisticated design and exquisite workmanship. The following suggestions will help you maintain the product well and prolong its service life. 1. Cleaning The part of the probe is the most easily soiled. You can use a towel soaked in clean... -
Page 19: Safety Measures
Safety Measures 1. Do not surpass specified voltage of power supply system. Please use specified peripheral equipment. 2. Do not detach the prospecting instrument or charger under any circumstance. It is strictly forbidden to modify the equipment. If warranty label of the instrument is damaged, warranty service voids. -
Page 20: Copyright Statement
Copyright Notice 1. Hunan Puqi Geologic Exploration Equipment Institute has the final interpretation of the operating instructions. 2. Hunan Puqi Geologic Exploration Equipment Institute reserves right to modify equipment specification without any advance notice. 3. All pictures for reference only in operation manual, please in kind prevail. 4.
