Hyperlan-Pack
High throughput, outdoor, point-to-point
Ethernet networks bridging between buildings
Up to 40 Mbps TCP throughput across 5 km
Secure connection, tight radio beam
10/100 Base Tx network interface
IP66 housing, powered from the Ethernet (POE)
Please check the product kit parts against the following list:
2 x identical Hyperlan-Pack modules
-
1 x this documentation, printed
-
2 x M12 to RJ45, male, POE, Ethernet cat. 5 cable, 25 m long
-
2 x directional antennas, 28 dBi (/L version)
-
4 x waterproof plastic caps for M12 connectors
-
2 x lightning arrestors
-
2 x male-to-male N-type coaxial extenders, 60 cm long
-
-
2 x 50 ohms N-type terminator caps
-
1 x CD ROM with drivers and documentations for all ACKSYS
products
and contact immediately your dealer if any item listed above is missing or
damaged.
A detailed reference manual about the software complement this quick
installation guide.
Before continuing, check for the latest documentation on the
web site and read if necessary the software user's manuals.
10, rue des Entrepreneurs
Z.A Val Joyeux
78450 VILLEPREUX - France

Quick installation guide

Ethernet bridge
Documentation ref. DTUS063 rev A0 12/09/09
Phone:
Fax:
Web:
Hotline:
Sales:
-1-
www.acksys.fr
+33 (0)1 30 56 46 46
+33 (0)1 30 56 12 95
www.acksys.fr
support@acksys.fr
sales@acksys.fr

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DTUS063 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Acksys DTUS063

  • Page 1: Quick Installation Guide

    2 x male-to-male N-type coaxial extenders, 60 cm long 2 x 50 ohms N-type terminator caps 1 x CD ROM with drivers and documentations for all ACKSYS products and contact immediately your dealer if any item listed above is missing or damaged.
  • Page 2 - 2 -...
  • Page 3: Hardware Installation

    HARDWARE INSTALLATION The Hyperlan-Pack is made up of two identical and interchangeable subsets, containing an antenna and a Hyperlan-Pack module fixed to it. The following instructions are to be carried out for both subsets. Fix the HF head to the center of the antenna A parabolic antenna is used.
  • Page 4: Software Configuration

    Hyperlan-Pack, the IP address of one of the two systems should be changed the following way: From any P.C. of the network, run the ACKSYS NDM multi-platform application (found on the CD ROM). Select the device and click on the « Configure IP » button.
  • Page 5: Final Installation

    (30 m) to make sure that it is working correctly. The products should associate together shortly after switching them on. This can be verified using the ACKSYS NDM software. The RSSI level returned by the two products must be 100% as soon as the two antennas are correctly aligned.
  • Page 6 A tutorial (in English) is available here: http://www.pizon.org/radio-mobile-tutorial/index.html. The Hyperlan-Pack antenna models for ‘Radio Mobile’ can be downloaded from the ACKSYS website, under ‘Downloads’: http://www.acksys.fr Mast Installation: The Hyperlan-Pack comes with a mounting kit made up of two clamping U- bolt and a stopping U-bolt.
  • Page 7 Should the line not appear, check the azimuth settings and the tilt of both antennas, and that the ‘ACKSYS RF Quality Tester’ is running correctly.
  • Page 8: Troubleshooting

    Radio channel to use (in the 802.11a range) SNMP Administration The two Hyperlan-Pack modules can be configured and monitored using the SNMP protocol (V1 or V2c). The ACKSYS enterprise MIB is available at: http://www.acksys.fr/Logiciels%20&%20Drivers/ACKSYS-WLG-MIB.zip TROUBLESHOOTING All 8 LEDs indicators are OFF Verify the power supply (Voltage, cabling).
  • Page 9: Specifications

    How to restore factory settings If the built-in web-based interface is reachable, you can use your browser to restore factory settings. Open the case of the unit, and reset unit back to factory default by holding down the reset button for at least 2 seconds while the unit is powered on.
  • Page 10 Power supply Number of external power inputs Wide DC power range, from 9V to Type 75V, 7W max, polarity protection. Connector A single 5-pins M12 connector POE source From LAN2 connector Ethernet interface Number of ports 10 BASE T or 100 BASE Tx Type of ports Automatic negotiation (HDX/FDX, 10/100 Mbps), auto MDI/MDI-X...
  • Page 11 Software Automatic device discovery Built in web based utility for easy Device configuration configuration from any web browser (username/password protection) Firmware upgrade Yes (via web browser or NDM) SNMP SNMP V1, V2C AP (Access Point)/ Repeater or Operating mode Bridge/Client AP mode only Network topology infrastructure mode with or without WDS...
  • Page 12 CONNECTORS The module contains 5 connectors: One male M12 connector for the two power supply sources, DC 9-75V, 7 W min 5-point M12 Male Signal Name connector Power 1 Power 2 Two M12 connectors for LAN1 and LAN2 interfaces. Ethernet connector 8-point M12 male Signal Name Connector...
  • Page 13: Hyperlan Pack Mounting

    HYPERLAN PACK MOUNTING The Hyperlan-Pack comes with a mounting kit made up of two clamping U- bolt and a stopping U-bolt. The antenna can be easily fixed to the mast using the provided clamping U- bolts (see picture below). The diameter can be set up to 50 mm. Note: It is advisable to fix the antenna with the stopping U-bolt when adjustments are being made.
  • Page 14 LEDs definition Each module has 8 status LED indicating: Color Description This led is ON when a power supply is connected to Power 1 Green pin 3/pin 4 of the power connector. This led is ON when a power supply is connected to Power 2 Green pin 1/pin 2 of the power connector.
  • Page 15 ADDENDUM HYPERLAN-PACK/LR Power supply connector pin-out 6-pins connector, size 10 Signal VDC POWER1 GND POWER1 VDC POWER2 GND POWER2 Earth - 15 -...
  • Page 16 Ethernet Lan1 and Lan2 interface connectors pin-out. 10 pins connector, size 12 Signal Color (T568B) Green White/Green POE- Brown POE- White/Brown POE+ White/Blue POE+ Blue Orange White/Orange RJ45 connector as T568B (front view) - 16 -...
