Page 1: Power Supply
CIRCUIT-TEST Switching Mode Power Supply PSC-6916 1-16VDC @ 60A PSC-6932 1-32VDC @ 30A PSC-6960 1-60VDC @ 15A OPERATION MANUAL... - Page 2 PSC-6916 / 6932 / 6960 08R14...
-
Page 3: Table Of Contents
WARRANTY ..................... 6 CONTROLS AND INDICATORS ................7 CONTROL MODE SELECTION ................8 OPERATING INSTRUCTIONS ................10 REMOTE SENSING (only PSC-6916) ..............13 ANALOGUE REMOTE CONTROL MODE ............14 FAULTS AND TROUBLE SHOOTING ..............17 SPECIFICATIONS .................... 19 PC INTERFACE CONTROL ................20... - Page 4 Keep this manual in a safe place for quick reference at all times. This manual contains important safety and operation instructions for correct use of the power supply. Read through the manual and pay special attention to the markings and labels of this unit and equipment to be connected. Pay special attention to these two types of notices used in this manual WARNING: Failure to observe this warning may cause injury to persons and damage to power supply or connected equipment.
-
Page 5: Warning
1. Warning • Do not use this power supply near water. • Do not operate or touch this power supply with wet hands. • Do not open the casing of the power supply when it is connected to AC mains. •... -
Page 6: Introduction
The 3 user defined presets facilitate quick access to frequently used VI settings. 4. Warranty Circuit-Test Electronics warrants to the original purchaser that this product be free of defect in material or workmanship for a period of 2 years from the date of purchase. -
Page 7: Controls And Indicators
Note: PSC-6916: The total rated current (Aux.+Main) is 60A PSC-6932: The total rated current (Aux.+Main) is 30A PSC-6960: The total rated current (Aux.+Main) is 15A (7) Output Terminal (Rated 60A for PSC-6916/ Rated 30A for PSC-6932/ Rated 15A for PSC-6960) -
Page 8: Control Mode Selection
(8) Remote Sensing Terminal (for model PSC-6916 only) Warning • Do not short the remote sensing terminals • Connecting the remote sensing terminals in reverse polarity will damage the power supply. (9) Mode Selection Switch (Normal, Preset, Remote Control, Set Modes) - Page 9 Recall No. Output Voltage Output Current Maximum 13.8V Maximum PSC-6916: 15V Maximum PSC-6932: 25V PSC-6960: 55V 6.3 Set Mode - First enter into the Set Mode by pushing Switch (9) to Set Mode slot. The power supply is then ready to be preset.
-
Page 10: Operating Instructions
This series has 3 models. Make sure you have used the correct one. They have different output voltage range and current as following: Model Number Output Voltage Range Total Rated Current PSC-6916 1 ~ 16V 0 ~ 60A PSC-6932 1 ~ 32V... - Page 11 Table indicating the self test sequence Self test display and Sequence Test contents To show software version Segment check C.V. Indicator check C.C. Indicator check Rear control indicator check Return to C.V. Start to check Over voltage protection check Over load protection check Over temperature protection check Fan check Output off (remote control mode)
-
Page 12: Using The Control Knobs
7.4 Using the control knobs The rotary encoder control knobs have fine and coarse tuning with clicking move- ment. Push the knobs to toggle between coarse and fine tuning, notice the subtle changes in brightness of related LED. Adjust the knobs to your desired values by trying coarse and fine tuning. -
Page 13: Remote Sensing (Only Psc-6916)
8. Remote Sensing (Only PSC-6916 has this function) Warning • Never short the Remote Sensing Terminal • Always disconnect Remote Sensing Terminal first. • Never connect the Remote Sensing Terminal in reverse polarity Connection: 1. First complete the power connections between power supply and equipment. -
Page 14: Analogue Remote Control Mode
9. Analogue Remote Control Mode There are two methods for remote control of current and voltage adjustment. NOTE: Both methods require both the current remote control part and the volt- age remote control part to be set up and be in-use at the same time in order for analogue remote control mode to be functional. - Page 15 9.2 Method B: Using two 0 – 5K Ohm variable resistors Two variable resistors must be set up at the same time in order for the remote control to be functional. Remote Socket Pin Assignment for variable resistor FUNCTIONS REMARKS Internal DC +5V Resistor end Voltage Adjust...
- Page 16 9.3 Remote Output ON/OFF Control This remote output on/off control can be activated in any of the modes Normal, Preset, Remote and Set mode. A. By default, Pin 5 is open and output is ON. B. Shorting Pin 5 to Pin 4 (ground) and output is off. C.
-
Page 17: Faults And Trouble Shooting
10. Faults and Trouble Shooting 10.1 OUP: Over Voltage Protection This unit has a built-in tracking over voltage protection feature. In the event of output voltage becoming greater than the set value (see specified range from specifications table), protection will be triggered and the output power will be cut off and OUP warning appears as below. - Page 18 10.3 OLP: Over Load Protection Normally the overload protection is sustained by the CC constant current mode. When the CC mode fails and goes undetected, it may cause serious damage to your test piece or load. The OLP is meant to minimize the extent of damage to your loads as power supplies do fail some day.
-
Page 19: Specifications
Fuse T12A / 250V (5 x 20 mm) Special Features 3 User defined VI preset, Remote control V, I and output on-off, Remote Sens- ing (for PSC-6916 only) Accessory User Manual, Application Software, USB cable Dimensions (WxHxD) 200 x 90 x 275 mm 7.9 x 3.5 x 10.8 inch... -
Page 20: Pc Interface Control
12. PC Interface Control Support OS: Windows XP/Vista/7 (32bits/64bits) Driver: Silicon Lab CP210x USB driver (Included in CDROM folder “USB CP210x Drivers V6.5 for Win_XP_ S2K3_Vista_7”) Execute Program: run “<CDROM Drive>:\hcs\hcs.bat” A. Main Display The Main interface is divided into 7 panels. 1. - Page 21 B. Display Panel The display show following information - Output Voltage value - Output Current value - Output Power value - Output On/Off status - C.V./ C.C. Model - Setting values C. Set Output Value and On/Off Status You can directly type the desired output voltage & output current and then click “Set”...
- Page 22 D. External Timed Program External Timed Program is completely controlled by PC, PC counts the time and changes voltage and current of power supply. Select External Timed Program tab to switch to the External Timed Program tab. - Double click on the cell that you would like to set value. e.g. Step 2 voltage. - Slide the bar to configure the value.
- Page 23 - Set time for this step to be running. The time range is between 0 to 9hours 59 minutes 59 seconds. You can click up/down button to change value or directly input value. If the time value is set to 0, this step will be skipped. - Select running cycle between 0-999.
- Page 24 E. Internal Preset Memory The PC interface remote mode really eliminates the tedious process of keying in groups of entries on the power supply. Because all the data are displayed together in the monitor, possibility of wrong entry is greatly reduced. Data of different groups can be classified, stored, exported and retrieved for use at any time.
- Page 25 F. Data Log Data Log window Data log window is used to display output Voltage, Current and Power against time in graphical view. You can move the diagram left and right by adjust “Move:” slide bar. You can zoom in/out the diagram by adjust “Zoom:” slide bar. You can save the data in CSV file for analysis later.
- Page 26 G. Save, Load and Print Setting In previous session, the above 3 buttons are used to save, load and print log data. In addition, these buttons can used to save, load and print setting for External Timed Program and Internal Preset Memory. First, select tab in Main configure and data log display panel.
- Page 27 H. Setting In the setting page, you can do general setting for the program. You can select language for the program You can select the COM Port for power supply connected You can set sampling time for data log by adjust slide bar You can set your output voltage upper limit (UVL) value to further safeguard your low current applications.
- Page 28 I. Command Set Command line format COMMAND<parameter1><parameter2>... [CR] NOTE: One decimal place for current value: PSC-6118, 6318, 6336, 66xx, 69xx Two decimal places for current value: PSC-6136, 6360 Command code & return value Function Example Input Command: Get PS maximum Voltage & Input command: GMAX[CR] Current value...
- Page 29 Command code & return value Function Example Input Command: Get PS Display values of Volt- Input command: GETD[CR] GETD[CR] age, Current and Status of CC/CV Return value: Return value: <voltage><current><status>[CR] <voltage>=???? 150016001[CR] OK[CR] <current>=???? OK[CR] <status>=0/1 (0=CV, 1=CC) Meaning: The PS Display value is 15V and 16A.
-
Page 30: Appendix
13. Appendix USB configuration for remote programming This application note describes the procedure to configure the USB port for remote programming application. The remote programmable power supply with USB can be connected to PC through USB cable. USB to serial bridge design is used. When connected to PC, it will be converted as COM port shown in the following picture. - Page 31 Notes:...
- Page 32 CIRCUIT-TEST E L E C T R O N I C S Division of R.P. Electronic Components Ltd. BURNABY, BC CANADA V5J 5M8...
