Wireless Speaker Bug
AFTER SALES SUPPORT
0333 200 5846
GB
accessionx-uk@teknihall.com
MODEL: 1451

User Manual

1890 917 060
IRE
PC: 71398
08/2016
• Wireless Speaker Bug
• USB cable
• Audio cable
• User manual
• Warranty card
YEAR WARRANTY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1451 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for envivo 1451

  • Page 1: User Manual

    User Manual Wireless Speaker Bug AFTER SALES SUPPORT • Wireless Speaker Bug • USB cable • Audio cable 0333 200 5846 1890 917 060 • User manual • Warranty card accessionx-uk@teknihall.com YEAR WARRANTY MODEL: 1451 PC: 71398 08/2016...
  • Page 3: Table Of Contents

    CONTENTS WELCOME ................ 4 CONTENTS ............... 5 AFTER SALES SUPPORT ..........6 OVERVIEW ............... 6 GETTING STARTED ............7 OPERATING THE SPEAKER ......... 8 SPEAKER CHARGING ..........14 SPECIFICATIONS ............15 SAFETY PRECAUTIONS ..........16 TROUBLE SHOOTING ..........17 DISCLAIMER ..............23 DISPOSAL...............24 WARRANTY..............25 WARRANTY CARD............27...
  • Page 4: Welcome

    EnVivo. We want you to be completely satisfied with your purchase, so this EnVivo product is backed by a comprehensive manufacturer’s 3 year warranty and an outstanding after sales...
  • Page 5: Contents

    service through our dedicated Helpline. We hope you will enjoy using your purchase for many years to come. Before installing and using the product, please read the instructions thoroughly, and retain them for future reference. Hope you have a pleasant experience. CONTENTS •...
  • Page 6: After Sales Support

    AFTER SALES SUPPORT Email: accessionx-uk@teknihall.com Tel. no. for the UK: 0333 200 5846 Tel. no. for Ireland: 1890 917 060 OVERVIEW...
  • Page 7: Getting Started

    GETTING STARTED Key functions Volume-/Previous song: Short press to go to previous song. Long press to turn down volume. Play/Pause: Short press to play or pause music. Long press to disconnect BT device. Volume+/Next song: Short press to skip to next song. Long press to increase volume.
  • Page 8: Operating The Speaker

    Power button: Long press for 3 seconds to power on and off. Micro USB: Use the provided USB cable for charging the unit. ‘Line in’: Aux input slot, use the provided Aux-in cable to connect your Mobile, Tablet, iPad, MP3 Player etc. to play music.
  • Page 9 After the speaker is turned on, the speaker will be ready to be paired, this is indicated by the blue light flashing. Activate bluetooth on your compatible device and set it to search for compatible devices. Select the speaker “ENV-1451” from the list of found devices.
  • Page 10 Note: If the speaker is already connected to another bluetooth device then the speaker will not appear in search list and you need to disconnect the current paired bluetooth device from the speaker and search again. If your device asks for a passkey, enter digits “0000”...
  • Page 11 Note: If the speaker has been paired to the bluetooth device before, you need to follow the pairing instructions below to connect the speaker to the bluetooth device: Activate bluetooth on your compatible device, turn on the speaker and the speaker will connect automatically to the compatible device.
  • Page 12 Short press `+` for next song and short press `-` for previous song. Long press `+` to increase volume and long press ` -` to decrease volume. E. Using the Speaker as Hands-free Wireless Speaker Phone When your device is paired with the speaker and you receive an incoming call or are making an outgoing call, the speaker will shift from music mode to call mode automatically.
  • Page 13 incoming call, hold down the button. F. Using the Speaker in AUX-In Mode Plug one end of the 3.5 mm Audio Cable into the headphone or line out of your MP3 Player, Mobile or computer and plug the other end of the cable into the Aux-In jack of the Speaker.
  • Page 14: Speaker Charging

    SPEAKER CHARGING The speaker comes with a built-in rechargeable battery. Connect the USB cable provided to a computer or into a DC 5V power adaptor (not included). When charging the red LED light will turn on. The charging time is approximately 2-3 hours. When the unit is fully charged, the red LED light will turn off.
  • Page 15: Specifications

    can protect and extend the battery life. SPECIFICATIONS • Wireless Speaker Bug with built-in 3.7V Lithium chargeable 600mAh battery • Bluetooth V4.1 • Transmission distance up to 10 m (this may vary according to environment and connected Bluetooth device) • USB charging voltage: DC 5V •...
  • Page 16: Safety Precautions

    • Handsfree function for call • Bluetooth name: ENV-1451 SAFETY PRECAUTIONS Do not use or store the unit in high temperature or hazardous location. Please do not expose the unit to moisture or rain. Please do not disassemble, repair or modify the unit.
  • Page 17: Trouble Shooting

    cause damage to your ears. Low battery power may result in a reduction in bluetooth transmission distance or disconnection. TROUBLE SHOOTING Should you experience any difficulty while using the speaker, please refer to the following. Not charging Reason The USB power adaptor (not included) is not plugged into a wall outlet or the USB cable (included) is not plugged into the micro USB jack on the side of the speaker.
  • Page 18 Solution Plug the USB power adaptor (not included) into a wall outlet and plug the USB cable (included) into the micro USB jack of the speaker. Reason Wall outlet is not functioning. Solution Plug another device into the same outlet to confirm the outlet is working.
  • Page 19 Solution Make sure your computer power is turned on and try another USB port. No Sound Reason The speaker battery is dead. Solution Recharge the speaker. Reason The speaker is not linked to the cell phone. Solution Go through “Speaker Operations” process to connect the speaker.
  • Page 20 Reason Volume is too low. Solution Increase the volume on your device. Increase the volume on the speaker. Increase the volume on the audio source. No Audio Signal via Bluetooth connection Reason Speaker is not paired to the audio source. Solution Check whether a connection exists.
  • Page 21 Reason 3.5mm audio cable is connected. Solution Unplug the audio cable. Speaker cannot be connected Reason Pairing does not work. Solution Check whether the audio source supports the A2DP protocol. Reason Audio source is switched off. Solution Switch on the audio source.
  • Page 22 Reason Bluetooth is switched off at the audio source. Solution Switch on the Bluetooth function in the audio source. Reason Bluetooth version is not supported. Solution Use a different playback unit. Poor Sound quality from a Bluetooth device Reason Bluetooth device is almost out of range of the speaker.
  • Page 23: Disclaimer

    Solution Move your Bluetooth device closer to the speaker. DISCLAIMER This Speaker Bug is designed for use only in conjunction with the appropriate mobile entertainment device. Please consult your device packaging to determine whether this Speaker Bug is compatible with your particular mobile entertainment device.
  • Page 24: Disposal

    DISPOSAL Batteries, electrical and electronic equipment (EEE) contain materials, parts and substances, which can be dangerous to the environment and harmful to human health if waste of electrical and electronic equipment (WEEE) are not disposed of correctly. Batteries, electrical and electronic equipment, which are marked with the WEEE logo (as shown below), should not be thrown away with your household waste.
  • Page 25: Warranty

    WARRANTY We want you to be completely satisfied with your purchase so this EnVivo product is backed by a comprehensive manufacturer’s 3 year warranty and an outstanding after sales service through our dedicated Helpline. If you require technical support or in the...
  • Page 26 affect your statutory rights. However, be aware that the warranty will become null and void if the product is found to have been deliberately damaged, misused or disassembled.
  • Page 27: Warranty Card

    WARRANTY CARD WIRELESS SPEAKER BUG - 71398 PLEASE KEEP YOUR PURCHASE RECEIPT TOGETHER WITH YOUR CARD. NAME ADDRESS DATE OF PURCHASE LOCATION OF PURCHASE...
  • Page 28 Accession ApS - Vandmanden 34 - DK - 9200 Aalborg SV www.accessionx.com accessionx-uk@teknihall.com AFTER SALES SUPPORT • Wireless Speaker Bug • USB cable • Audio cable 0333 200 5846 1890 917 060 • User manual • Warranty card accessionx-uk@teknihall.com YEAR WARRANTY MODEL: 1451 PC: 71398 08/2016...
