Assembling the pedestal

Fix securely with assembly screws
Tighten screws firmly.
[TC-P50G20 (TBLX0147)]
(3 screws)
A
Pole
■
Set-up
Carry out work on a horizontal and level surface.
Tighten screws firmly.
[TC-P50G20]
B
Pole
[TC-P54G20]
B
Arrow
mark
Pole
Attaching the pedestal to TV
.
A
[TC-P54G20 (TBLX0157)]
Pole
R
Base
Front
Bottom view
Rear side
Arrow
Hole for pedestal
mark
installation
Pole
Fix securely with assembly
screws
Base
Bottom view
Rear side
Hole for pedestal
installation
Pole
Base
(4 screws)
A
Pole
L
Front
Base
. (Total 4 screws)
B
Fix securely with assembly
screws . (Total 4 screws)
B
Accessories
Assembly screws
A
XYN5+F18FN (for 50")
M5 × 18 (Silver) (3)
XYN5+F25FN (for 54")
M5 × 25 (Silver) (4)
B
THEL079N (for 50")
THEL073N (for 54")
M5 × 30 (Black) (4)
Pole
(for 50") (1)
Poles
(for 54") (2)
L
R
or is printed at the
L R
bottom of the poles.
Base (1)
(for 50")
(for 54")
9
