Panasonic TC-P42S2 Quick Setup Guide (English, Spanish) Operating Instructions Manual page 10
42”/46”/50”/54” class 1080p plasma hdtv
Hide thumbs
Also See for TC-P42S2 Quick Setup Guide (English, Spanish):
- Manual de instrucciones (52 pages) ,
- Operating instructions manual (56 pages) ,
- Service manual (112 pages)
Table of Contents
Advertisement
Accessories/Optional Accessory
Reference of connection
Antenna terminal
Firmly tighten by hand.
10
AC cord connection
To attach
Insert it firmly until the
tabs on both sides click
into place.
Pin terminals
red
blue
green
green
Match colors of plugs and terminals.
Insert firmly.
(Continued)
To remove
Keep pushing both
sides until they snap
and pull.
HDMI terminal
Insert firmly.
