Page 1: Installation Instructions
Katherm NX 3.45 Trench Heating with natural convection Installation instructions Keep these instructions in a safe place for future use! Kampmann.de/installation_manuals 459/04/14/1 GB I Sap-Nummer 1146161... -
Page 2: Table Of Contents
3.45 Kath rm NX - Natural Convection Table of Contents Table of Contents Key to symbols: 1. Intended Use ..........Caution! Danger! 2. -
Page 3: Intended Use
Intended Use 1. Intended Use Kampmann Katherm NX are built in line with the state of the art and recognised safety regulations. Nevertheless their use may result in danger to people or damage to the unit or other material property if they are not properly installed or properly used. -
Page 4: Safety Information
Modifications to the unit Do not undertake any modifications, refurbishments or upgrades on the Katherm NX unit without discussing these with the manufacturer as these may impair the safety and operation of the unit. Do not carry out any action on the unit that is not described in these instructions. On-site... -
Page 5: Levelling/Water Connection
Remove the outer stretch wrapping and cardboard box. Caution: Do not remove the struts during installation and operation. Place the Katherm NX with the PowerKon heat exchanger near the window. Caution: The height-adjustment feet are already fitted to the floor duct. -
Page 6: Screed Work
3.45 Kath rm NX - Natural Convection Screed Work 6. Screed Work Check the following before starting the screed work: The water is connected properly, The electricity is connected properly, The floor duct is the correct height and distance from the window, The grille is covered (Caution! Cement destroys the surface of the grille!), The sound insulation (not with raised floors) is installed beneath the floor duct,... -
Page 7: Water Connection/Pipe Conduits
194000346911 (presettable) Thermoelectric actuator, type 194000146905 Return shut-off valve, straight, type 194000145952 Unit shown with roll-up grille Pipe conduits, cut-out Cable conduits Connection side, right Katherm NX 130 Duct height 92 mm All dimensions in mm Duct height 120 mm 91... -
Page 8: Valve Body, Straight
194000146905 Return shut-off valve, straight, type 194000145952 Unit shown with roll-up grille Pipe conduits, cut-out Cable conduits Katherm NX 175 Duct height 92 mm All dimensions in mm Duct height 120 mm 91 Duct height 150/200 mm Flow Return Valve body, straight 1/2”,... -
Page 9: Type 194000146909 Or
194000146905 Return shut-off valve, straight, type 194000145952 Unit shown with roll-up grille Pipe conduits, cut-out Cable conduits Katherm NX 225 Duct height 92 mm All dimensions in mm Duct height 120 mm 91 Duct height 150/200 mm Flow Return Valve body, straight 1/2”,... -
Page 10: And Raised Floor Mounting Feet
3100 10. Maintenance Information Maintenance on Katherm NX floor ducts should only be carried out by qualified personnel trained in compliance with the installation and operating instructions as well as any regulations currently in force. Regular maintenance and inspections are required in order to permanently guarantee the function and performance of the Katherm NX. -
Page 11: Thermoelectric Actuator
194000346909 type 194000346911 Example shown: Example shown: Katherm NX 225 Katherm NX 225 with linear grille with linear grille The number of connecting wires required with cable diameters (e.g 3 x 1.5) incl. fuses is given on the individual control units. -
Page 12: Duct Height 92 Mm
3.45 Kath rm NX - Natural Convection Model Overview - Valve Bodies/Return Shut-off Valves 12. Model Overview - Valve Bodies/Return Shut-off Valves Katherm NX NX 130 NX 175 NX 225 Duct height [mm] Flow, 1/2” Return, 1/2” Flow, 1/2” Return, 1/2”... - Page 13 Kath rm NX - 3.45 Natural Convection Notes...
- Page 14 3.45 Kath rm NX - Natural Convection Notes...
- Page 15 Kath rm NX - 3.45 Natural Convection Notes...
- Page 16 Kampmann.de Kampmann GmbH Kampmann UK Ltd. Friedrich-Ebert-Str. 128 - 130 Dial House, Govett Avenue 49811 Lingen (Ems) Shepperton, Middlesex, TW17 8AG Germany Great Britain T +49 591 7108-0 T +44 (0)1932 228592 F +49 591 7108-300 F +44 (0)1932 228949 E info@kampmann.de...
