Summary of Contents for SOMFY Axovia-220B

  • Page 1 Axovia 220B InstallatIon guIde 5101723A 5101723A_Axovia-220B.indd 1 10/05/2011 15:37:50...
  • Page 2 5101723A_Axovia-220B.indd 2 10/05/2011 15:37:50...
  • Page 3: Table Of Contents

    CONTENTS GENErAl iNfOrmATiON ___________________________________________________ 2 SAfETy _________________________________________________________________ 2 Safety instructions PrOduCT dESCriPTiON ___________________________________________________ 3 Exploded diagram of the product Size of motor (in mm) Installation type Technical specifications Description of operation of the indicators PrE-iNSTAllATiON ChECkS _______________________________________________ 5 Gate Pillars Reinforcements Area of application PrEPArATiON ANd drilliNG Of PillArS ___________________________________ 6...
  • Page 4: General Information

    Any use outside the sphere of application specified by Somfy is forbidden. This invalidates the warranty and discharges Somfy of all liability, as does any failure to comply with the instructions given herein.
  • Page 5: Product Description

    PrOduCT dESCriPTiON Exploded diagram of the product Motor Cable clamp bolt Motor arm Earth bolt Gate leaf arm Earth washer Gate leaf bracket 12x27 clamp washer Electronic unit Shaft bolt / motor arm HM 10x40 Motor cover End stop cover bolt Motor cover bolt End stop cover Information card...
  • Page 6: Size Of Motor (In Mm)

    Size of motor (in mm) 166.12 938.83 installation type Technical data Power supply 230 V - 50/60 Hz Standby power consumption 4.5 W Max. power consumption 600 W Average frequency of movements per day 20 cycles/day Max. thrust force at 1.25 m <...
  • Page 7: Description Of Operation Of The Indicators

    description of operation of the indicators led 1 (On/Off) Off: Electronics off On continuously: Electronics on Slowly flashing: Gate heavy Flashing quickly: Motor thermal cut-out or short circuit on motor output led 2 (Auto) Off: Sequential mode On continuously: Sequential mode + timed close Slowly flashing: Storing closing time led 3 (Warning)
  • Page 8: Preparation And Drilling Of Pillars

    PrEPArATiON ANd drilliNG Of PillArS For the indicated values, the gate leaves and their hinge pins are taken to be on the same axis. If the hinge pins are offset, the maximum opening angle values will be reduced. [1]. Measure dimension A. [2].
  • Page 9: Mounting And Fixing Of The Motors

    mOuNTiNG ANd fixiNG Of ThE mOTOrS [1]. Open the upper cover using the specific key supplied. [2]. Unscrew the 2 bolts of the lower cover and remove. Info card: for improved legibility, use a permanent marker. [3]. Attach the motor, checking the level. [4].
  • Page 10 [5]. Unlock the motor arms using the button located under the motor. : arms locked : manual operation In unlocked position, move the arms slowly to avoid damaging the motors. [6]. To ensure correct closing of the gate, push the motor arm and the gate firmly: - the gate arm must be completely unfolded, - the mounting tab must be flat against the reinforcement,...
  • Page 11: Installing The Integrated Opening End Stop

    iNSTAlliNG ThE iNTEGrATEd OPENiNG ENd STOP [1]. Manually open the gate to the opened position α required. α [2]. Install the end stop on the bracket side, flush against the shoulder of the motor arm. Do not tighten the end stop. [3].
  • Page 12: Electrical Connections

    ElECTriCAl CONNECTiONS Cable guide fitting Fit the cable guides on the two motors. Connection of the two motors Motor M1 actuates the gate leaf that opens first and closes last, and opens for pedestrian access. [1]. With the gate closed, identify the location of motor M1 by identifying the gate leaf that will open first.
  • Page 13: Locking The Arms

    locking the arms [1]. Close the two gate leaves and lock the arms by pressing them. [2]. Turn the motor locking handles to the locked position . 5101723A_Axovia-220B.indd 11 10/05/2011 15:38:31...
  • Page 14: Quick Commissioning

    QuiCk COmmiSSiONiNG Storing the remote controls The remote controls can be programmed for full opening of the gate only or pedestrian or full opening: Full opening only: a brief or long press on the remote control will cause both gate leaves to open Pedestrian or full opening a brief press on the remote control will lead to a single gate leaf opening for pedestrian access a long press on the remote control will cause both gate leaves to open.
  • Page 15: Operation

    OPErATiON According to the programming of the remote controls, the gate will open either fully only (full opening only mode), or for pedestrian access or fully (pedestrian or full opening mode). The motor can operate in Sequential mode or Automatic Closure mode. Sequential mode: successive presses of the same remote control button will lead to the following movements: Open, Stop, Close, Stop, Open etc.
  • Page 16: Connecting Additional Devices

    CONNECTiNG AddiTiONAl dEviCES Connecting the photoelectric cells Photoelectric cells must be connected to use the motor in automatic closure mode. Before connecting the cells, remove the jumper between terminals 3 and 4. Photoelectric cells - 1 set TC: Transmitter cell RC: Receiver cell 24 V 0 V C NC NO...
  • Page 17: Orange Light

    Exterior aerial Orange light 5 mm 15 mm key lock interphone 5101723A_Axovia-220B.indd 15 10/05/2011 15:38:36...
  • Page 18: Backup Battery

    Backup battery Minimum charging time before first use: 48 hours Operation time: 10 continuous cycles or 24 hours with a gate in perfect working order Service life: 3 years (take worn batteries to the appropriate sites for proper disposal) If there is a power cut and the backup battery is not charged, you will not be able to open your gate.
  • Page 19: Diagnostic And Repairs

    diAGNOSTiC ANd rEPAirS Indicators Led 1, Led 2, Led 3 and Led 4, located under the motor cover, are used to give fault finding indications. Problems Solutions Led 1 does not come on when switching on Check the mains power supply. Check the supply cable.
  • Page 20 5101723A_Axovia-220B.indd 18 10/05/2011 15:38:40...
  • Page 21 Axovia 220B oPeratIng guIde CONTENTS GENErAl iNfOrmATiON ___________________________________________________ 2 About Somfy Assistance Declaration of Conformity SAfETy iNSTruCTiONS ___________________________________________________ 2 Caution Safety instructions relating to operation uSE ANd OPErATiON _____________________________________________________ 3 Default operation in sequential mode Operation in Automatic Closure mode...
  • Page 22 We guarantee all Somfy products will meet your expectations in terms of safety, comfort and time saving on a daily basis. At Somfy, the pursuit of quality is a continuous process of improvement. Somfy's reputation has been built upon the reliability of its products and the Somfy brand is synonymous with innovation and technological expertise worldwide.
  • Page 23 uSE ANd OPErATiON default operation in sequential mode By default, the gate will operate in sequential mode. Depending on the programming carried out by the installer, the gate can operate either in full opening mode only (systematic opening of both gate leaves), or in full or partial opening mode (pedestrian mode).
  • Page 24 rECyCliNG Do not throw away your scrapped equipment or used batteries with household waste. It is your responsibility to dispose of your electronic equipment in the relevant recycling points. 5101723A_Axovia-220B.indd 4 10/05/2011 15:38:43...
