Summary of Contents for weBoost eqo
- Page 1 Cell Phone Signal Booster User Manual User Manual support.weboost.com 866.294.1660 NEED HELP? support.weboost.com 866.294.1660 NEED HELP?
-
Page 2: Table Of Contents
______ Index Package Contents Find The dBm Reading On Your Phone STEP 1: Place Booster In Strong Signal Location STEP 2: Place Antenna In Weak Signal Location STEP 3: Connect The System STEP 4: Troubleshooting Specifications Safety Guidelines Warranty... -
Page 3: Package Contents
________ Package Contents Coax Power Booster Antenna Cable Supply This device may be operated ONLY in a fixed location for in-building use. The signal booster unit is designed for use in an indoor, temperature controlled environment ( < 100 degrees Fahrenheit) CELL PHONE SIGNAL BOOSTER... -
Page 4: Step 1: Find The Dbm Reading On Your Phone
Apple Inc. Android is a trademark of Google Inc. All Other Phones & Alternate Methods • https://www.weboost.com/test-mode-instructions/ All Phones: • Keep track of the network (3G or 4G) phone is connected to. -
Page 5: Step 2: Place Booster In Strong Signal Location
______ Step 2: Place Booster In Strong Signal Location IMPORTANT: This is the most critical step of the installation process because it will determine the overall performance of the Booster system. You must determine the location of the best available cellular signal to maximize performance from your Booster. -
Page 6: Step 3: Place Antenna In Weak Signal Location
Never face to face Antenna Booster 15’ to 20’ The eqo Booster and Antenna should face the The eqo Booster and Antenna should face the Never back to back same direction 15 to 20 feet separation distance. same direction 15 to 25 feet separation distance. -
Page 7: Step 4: Connect The System
______ Step 4: Connect The System Connect the supplied Coax Cable and Coax Cable Power Supply on the side of the Booster. Power Cable Wall Mount Hole Connect the other end of the Coax Cable to the Antenna. Coax Cable Note: You can mount the Antenna on a wall by removing the soft cover. -
Page 8: Troubleshooting
Booster. A combination of vertical and horizontal separation distance also works to increase system gain. If you are having any difficulties while testing or installing your Booster, contact our weBoost Customer Support team for assistance at support.weboost.com or contact 866.294.1660. Fixing Orange Lights Issues This section is only applicable if the Booster light is orange and you are not experiencing the desired signal boost. - Page 9 Customer Support at support.weboost.com or contact 866.294.1660. Light Off If the eqo Booster’s light is off, verify your surge protected power strip has power. Note: The eqo Booster can be reset by un-plugging and re-plugging the power supply from the power strip.
-
Page 10: Specifications
______ Specifications eqo Booster Product Number U473020 Model Number 460032 FCC ID: PWO460032 4726A-460032 Connectors SMA-Female Antenna Impedance 50 Ohms Frequency 698-716 MHz, 729-756 MHz, 777-787 MHz, 824-894 MHz, 1850-1990 MHz, 1710-1755/2110-2155 MHz 700 MHz 700 MHz 800 MHz 1700/2100 MHz... -
Page 11: Safety Guidelines
(2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by weBoost could void the authority to operate this equipment. FOR MORE INFORMATION ON REGISTERING YOUR SIGNAL BOOSTER WITH YOUR WIRELESS PROVIDER, PLEASE SEE BELOW: Sprint: http://www.sprint.com/legal/fcc_boosters.html... -
Page 12: Warranty
______ Warranty 2 YEAR WARRANTY weBoost Signal Boosters are warranted for two (2) years against defects in workmanship and/or materials. Warranty cases may be resolved by returning the product directly to the reseller with a dated proof of purchase. Signal Boosters may also be returned directly to the manufacturer at the consumer’s expense, with a dated proof of purchase and a Returned Material...
