GN
SC-HC3_GN (RQTX0293-B).indd 1

Operating Instructions

Compact Stereo System
Dear customer
Thank you for purchasing this product.
Before connecting, operating or adjusting this product, please read the
instructions completely.
Please keep this manual for future reference.
Operations in these instructions are described using remote
control, but you can do the operations with the main unit if the
controls are the same.
Your unit may not look exactly as illustrated.
Supplied accessories
Please check and identify the supplied
accessories.
1 Remote control
(N2QAYB000394)
1 AM loop antenna
1 FM indoor antenna
2 Batteries
1 AC mains lead
Note
•
The included AC mains lead is for use with this unit only. Do
not use it with other equipment.
•
Do not use an AC mains lead from other equipment.
SC-HC3
Model No.
RQTX0293-B
3/2/2009 3:40:20 PM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC-HC3 and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic SC-HC3

Summary of Contents for Panasonic SC-HC3

  • Page 1: Operating Instructions

    Operating Instructions Compact Stereo System SC-HC3 Model No. Dear customer Thank you for purchasing this product. Before connecting, operating or adjusting this product, please read the instructions completely. Please keep this manual for future reference. Operations in these instructions are described using remote control, but you can do the operations with the main unit if the controls are the same.

  • Page 2: Table Of Contents

    Table of contents Safety precautions Placement Supplied accessories Set the unit up on an even surface away from direct sunlight, Safety precautions high temperature, high humidity, and excessive vibration. These Connections conditions can damage the cabinet and other components, thereby shortening the unit’s service life. Preparing the remote control Place it at least 15 cm away from wall surfaces to avoid Demo function...
  • Page 3 CAUTION! THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS OR AC IN PERFORMANCE OF PROCEDURES OTHER THAN THOSE 75Ω LOOP LOOP ANT FM ANT AM ANT GROUND SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.

  • Page 4: Connections

    Connections Portable audio equipment (Cords and equipment not included) REMOTE CONTROL MAIN UNIT Plug type: Start playback from the ➡ Ø3.5 mm portable audio source. stereo Portable audio player Note • Adjust the volume and sound quality of this unit and the other equipment. Reduce the level of input signal (for example, by switching off the equalizer or reducing the volume) of the other equipment before connection.

  • Page 5: Preparing The Remote Control

    Connections (continued) Optional antenna connections FM outdoor antenna AM outdoor antenna AM outdoor antenna (not included) FM outdoor antenna (not included) 75 Ω coaxial cable (not included) • Never use an outdoor antenna during a lightning storm. • You can connect the FM outdoor antenna for better reception. Please consult your dealer for installation. •...

  • Page 6: Control Guide

    Control guide Remote Control • Refer to the numbers in parentheses for page reference. • [u/t] and [y/i] described in the operations have the same controls as [w] and [q] respectively. Standby/on switch [^], [8] (8, 10) (10) [z, PLAY] Press to switch the unit from on to standby Play timer on/off mode or vice versa.

  • Page 7: Main Unit

    Control guide (continued) Main Unit • Buttons such as function the same as the remote control. Front View Display Remote control signal sensor Top View (Top Panel) DEMO VOLUME [iPod ;, OPEN/CLOSE] (12) Open and close sliding door for Sliding door Operation iPod operation.

  • Page 8: Disc Operations

    Disc operations Basic play Play Mode function  Press [CD q/h].  Press [^] to turn the unit on.  Press [PLAY MODE] to select the desired mode.  Press [CD ;, OPEN/CLOSE] to open the sliding door and then set the CD in place.

  • Page 9: Radio Operations

    Radio operations Disc operations (continued) Repeat play Manual tuning You can repeat program play or other selected play mode.  Press [FM/AM] to select “FM” or “AM”. Press [REPEAT] before or during play.  Press [TUNE MODE] to select “MANUAL”. &...

  • Page 10: Timer

    Setting the clock This is a 24-hour clock.  Press [CLOCK/TIMER] to set the clock.  Press [u/t] or [y/i] to select the time within 5 seconds. (Press and hold to change the time faster.)  Press [CLOCK/TIMER] again. Press [CLOCK/TIMER] g To display the clock for few seconds when the unit is on or in standby mode...

  • Page 11: Sound Adjustment

    Timer (continued) The SLEEP timer can turn the unit off after a set time. Press [SLEEP] to turn the SLEEP function on/off. • Each time you press the button: OFF (Canceled) Press [SLEEP] once g To check the remaining time The play timer and sleep timer can be used together.

  • Page 12: External Unit

    External unit g Playing the iPod Enjoying audio from iPod Preparation: • Reduce the volume of the main unit to minimum before connecting/ g Inserting the iPod disconnecting the iPod. • Confirm the iPod connection. (➡ left)  Press [iPod ;, OPEN/CLOSE] to open the sliding door. ...

  • Page 13: Troubleshooting Guide

    External unit (continued) To return to “REMOTE 1” mode Changing the main unit and remote Perform steps 1 to 3 but use [1] instead of [2] for steps 2 and 3. control mode (“REMOTE 1” appears on the main unit during step 2.) The remote control cannot work with the main unit if their modes The remote control and main unit are factory-set to “REMOTE 1”...
  • Page 14 Troubleshooting guide (continued) iPod • Verify that the iPod battery is not depleted before connecting it to the unit. iPod does not turn on. • Before inserting your iPod into the dock, turn off both the unit and iPod. Turn power back on and select the appropriate source.

  • Page 15: Specifications

    Specifications g AMPLIFIER SECTION g DISC SECTION g GENERAL RMS Output Power Stereo mode Disc played [8 cm or 12 cm] Power supply AC 220 to 240 V, 50 Hz Front Ch (both ch driven) Power consumption (1) CD-Audio (CD-DA) 28 W 20 W per channel (6 Ω), 1 kHz, 10% THD (2) CD-R/RW (CD-DA, MP3)

  • Page 16: Sc-Hc3_Gn (Rqtx0293-B).Indd

    Panasonic Corporation Web Site: http://panasonic.net RQTX0293-B H0309VC0 SC-HC3_GN (RQTX0293-B).indd 16 3/2/2009 3:40:32 PM...
