Page 3
OREWORD How To Obtain Warranty Service A copy of the Vari-Lite Limited Warranty was included in the shipping package for this VARI❋LITE® product. To obtain warranty service, please contact customer service at 1-877-VARI-LITE (1-877-827-4548) or customerservice@genlytecontrols.com and request a Return Material Authorization (RMA) for warranty service.
Page 4
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Compliance Notice This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when this equipment is operated in a commercial environment.
Page 5
OREWORD Safety symbols used throughout this manual are as follows: CAUTION advising of potential damage to product. WARNING advising of potential injury or death to persons. GENERAL INFORMATION PERTAINING TO PROTECTION AGAINST ELEC- TRICAL SHOCK, FIRE, EXPOSURE TO EXCESSIVE UV RADIATION, AND INJURY TO PERSONS CAN BE FOUND BELOW.
Page 6
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL WARNING: INSTRUCTIONS FOR CONTINUED PROTECTION AGAINST EXCESSIVE EXPOSURE TO UV RADIATION 1. Many VARI❋LITE® luminaires use an HID type lamp that produces UV radiation. DO NOT look directly at lamp. 2. It is hazardous to operate luminaires without lens or shield. Shields, lenses, or ultraviolet screens shall be changed if they have become visibly damaged to such an extent that their effectiveness is impaired.
Page 7
OREWORD Sicherheitshinweise Es ist äußerst wichtig, ALLE Sicherheitsinformationen und -hinweise in diesem Handbuch und dem beiliegenden Informationsmaterial zu lesen, bevor Sie die hierin beschriebenen Produkte installieren bzw. bedienen. Halten Sie bei der Installation und dem Einsatz dieses Produkts alle Warnhinweise und Vorsichtsmaßnahmen ein. Folgende Sicherheitssymbole werden in diesem Handbuch verwendet: VORSICHT - weist auf möglichen Produktschaden hin.
Page 8
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL 2. Es ist gefährlich, Leuchten ohne Linsen oder Blenden zu bedienen. Blenden, Linsen oder Ultraviolettschirme müssen ausgetauscht werden, sofern deren Schutzwirkung durch sichtbare Beschädigung (z. B. Sprünge oder Schrammen) eingeschränkt ist. WARNUNG: HINWEISE ZUM SCHUTZ GEGEN KÖRPERVERLETZUNGEN 1.
Page 9
OREWORD Notes de sécurité Avant de procéder à l’installation des produits décrits dans ce guide et de les mettre en marche, il est extrêmement important de lire TOUS les renseignements et TOUTES les directives de sécurité contenues dans ce guide ainsi que toute documentation jointe. Tenir compte de tous les avertissements et suivre toutes les précautions pendant l’installation et l’utilisation de cet appareil.
Page 10
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL 2. L’utilisation des luminaires sans lentille ou blindage pose des risques. Tous blindages, lentilles ou écrans ultraviolet visiblement endommagés au point que leur efficacité en est affectée doivent être remplacés, par exemple s’il y a des fissures ou de profondes rayures.
Page 11
OREWORD Aviso sobre Seguridad Es muy importante leer TODA la información e instrucciones sobre seguridad que se indica en este manual así como en los documentos adjuntos antes de instalar y operar los productos descritos. Se debe prestar atención a todos los avisos y advertencias durante la instalación y uso de este producto.
Page 12
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL ADVERTENCIA: INSTRUCCIONES PARA PROTECCIÓN CONTINUA CONTRA LA EXPOSICIÓN EXCESIVA DE RADIACIÓN ULTRA VIOLETA 1. Muchas luminarias VARI❋LITE® usan un tipo de lámpara HID que produce radiación UV. NO mire directamente a la lámpara.
ABLE OF ONTENTS Table of Contents Chapter 1. Introduction About This Manual ...................... 1 Additional Documentation................... 1 Customer Service ......................2 Technical Bulletins / Technical Notices............... 2 Chapter 2. Description Features Overview........................4 Features ......................... 4 Major Components External Components....................5 Menu Display ......................
Page 16
Chapter 4. Illustrated Parts Breakdown Drawing Tree VL2500™ Wash Luminaire ..................46 Top Assembly VL2500 Wash Included Items Kit ................48 VL2500 Wash Luminaire ................... 49 VL2500 Generic Luminaire ..................51 Front Wash Assembly....................53 Concave/Diffuser Front Lens Assembly ..............55 Convex Lens Assembly....................
Page 17
Ballast to Controller Cable Assembly..............113 Lamp Supply to Relay Cable Assembly ..............114 DC Output Cable Assembly..................115 Appendix A. Technical Bulletins and Notices 117 VL2500™ Wash Luminaire Technical Bulletins and Notices......... 117 02.96 76.002 2 A 04-June-2009 xvii...
About This Manual This manual provides descriptions, repair procedures, and illustrated parts breakdowns for all configurations of the VL2500™ Wash Luminaire. The manual is intended for use by Vari-Lite personnel and by Vari-Lite’s customers/clients. WARNING: It is important to read ALL accompanying safety and installation instructions to avoid damage to the product and potential injury to yourself or others.
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Customer Service Our Goal At Vari-Lite, we are committed to providing you the highest quality in customer service. Our comprehensive resources are available to help your business succeed and ensure you get the full benefit of being a Vari-Lite customer. Whether your needs are telephone/troubleshooting assistance, product training or technical service, our full- time staff of experienced professionals are on-hand to provide support.
HAPTER Description This chapter provides an overview of luminaire features, components and operations. • Features • Major Components • Principles of Operation 02.96 76.002 2 A 04-June-2009...
ERVICE ANUAL Features Overview The VL2500™ Wash Luminaire comes complete with all of the qualities and options designers love from the original Series 2000™ fixtures. It is still small, lightweight, and fast with a 700-watt short arc lamp, impressive lumen output, and a variable field angle from 14°...
ESCRIPTION AJOR OMPONENTS Major Components External Components The following illustration shows major luminaire components and controls. Truss Hook Bracket Assembly Removable Lamp Assembly (to access lamp for replacement) Upper Enclosure Assembly AC Input Cable Head Assembly Yoke Assembly Vertical Captive Knob Horizontal for lamp access (does not adjust...
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Menu Display The menu system is a programmable set of commands used to configure, address, operate, and test the luminaire. The menu system is controlled at the Menu Display available at the enclosure input panel.
Fixed Color Bulkhead Fan Assembly Removable Cover Front Assembly - includes beam spreader Nose Cover Note: This illustration shows current VL2500 components. For information on older models, please refer to the previous versions of this manual. 02.96 76.002 2 A 04-June-2009...
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Yoke Components The following illustration shows the major sub-assemblies that are located in the luminaire yoke assembly. (Head and enclosure not shown for clarity.) Yoke Arm Cover Fan Assembly Relay Ignitor PCB Yoke Structure...
ESCRIPTION AJOR OMPONENTS Enclosure Components The following illustration shows the major sub-assemblies that are located in the luminaire enclosure assembly. (Yoke and head assembly not shown for clarity.) Enclosure Top Covers 700W Arc Ballast Module 150W +24V/6.3A Power Supply Fan Assembly Input Panel Assembly containing DMX Input PCB and Menu Display...
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Principles of Operation Power and Data Flow Diagram The following diagram shows how data and power are distributed in the luminaire. Fix Color UV / IR Back Cap OT Sw OT Sw Switch...
HAPTER Maintenance This chapter contains test, service, and standard maintenance procedures. • Testing • Troubleshooting • Maintenance Procedures WARNING: All maintenance procedures are to be performed with power removed from the luminaire. Never remove cover or backcap while lamp is in operation.
Testing software is available in all Series 2000 luminaires through the luminaire’s menu system TEST function. For information on specific tests and test parameters, see the VL2500™ Wash Luminaire User’s Manual (VL Part no. 02.9676.0021). Note: After 10 seconds of inactivity, the menu display will change to the default state showing the address.
AINTENANCE ROUBLESHOOTING Troubleshooting Error Messages If a problem occurs during luminaire calibration, at the end of the calibration sequence the Menu Display will cycle through any applicable error message(s), one at a time until the end of the list is reached. To review the error messages again, it will be necessary to access them using the Status function.
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Troubleshooting Guide If a problem is suspected, try recalibrating the luminaire to prompt an error message. Refer to the Troubleshooting Guide table (below) for more information. This table provides possible causes and remedies for each message.
Page 33
AINTENANCE ROUBLESHOOTING Table 2-2: Troubleshooting Guide (Continued) Message Symptom Description Possible Cause and Remedy Pan No Luminaire will not pan or Pan Sensor Not Found EOT flag attached to large pulley is not engaging the Sens hits against stop EOT sensor... - ensure flag is attached to the large pulley.
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Maintenance Procedures Head Assembly This section provides removal and replacement procedures for components found in the luminaire head assembly. Lamp Replacement Parts: 71.2528.0700 WARNING: Remove power from luminaire before performing any maintenance. To remove and replace lamp: Step 1.
Page 35
Step 6. Align guide rods in guide holes and slide backcap into head assembly. Re- tighten captive knob. Step 7. If required, reset lamp hour counter as follows. (Refer to "Menu System" in VL2500™ Wash Luminaire User’s Manual for more information.) a. Power up luminaire. b. At Menu Display, press [Menu].
Wear protective gloves and/or use tools to prevent burns. To align lamp: Step 1. Using internal menus select Lamp test to set beam. Refer to VL2500™ Wash Luminaire User’s Manual for more information. (If using console, set intensity to 100% and adjust diffusion to produce a tight beam.) Step 2.
AINTENANCE AINTENANCE ROCEDURES Fixed Color Bulkhead Replacement Parts: 21.9676.1120 To remove and replace fixed color bulkhead assembly: Step 1. Disconnect luminaire AC input cable from power source. Step 2. At head cover, gradually loosen two 8-32 x 1/2" PPB captive screws and remove cover (it will remain attached by tether) as shown in Figure 2-4.
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Standard Color Filter Replacement Parts: Color Filter as required To remove and replace a standard color filter: Step 1. Disconnect luminaire AC input cable from power source. Step 2. At head cover, gradually loosen two 8-32 x 1/2" PPB captive screws and...
AINTENANCE AINTENANCE ROCEDURES Strobe Bulkhead Replacement Parts: 22.9676.0016 To remove and replace strobe bulkhead assembly: Step 1. Disconnect luminaire AC input cable from power source. Step 2. At luminaire, remove top and bottom head covers as follows: a. At top head cover, gradually loosen two 8-32 x 1/2" PPB captive screws and remove cover (it will remain attached by tether) as shown in Figure on page 19.
Page 40
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Strobe Bulkhead Replacement (continued) Step 9. Install replacement assembly by performing Steps 2 through 8 in reverse order. Captive Screws Removable Top Head Cover Strobe Bulkhead Assembly Removable Bottom Head Cover Figure 2-6: Strobe Bulkhead Replacement 04-June-2009 02 .9 676 .00 22 A...
AINTENANCE AINTENANCE ROCEDURES Front Assembly Removal Parts: 21.9676.1006 Note: This procedure may be necessary to gain access to other components. To remove and re-install front assembly: Step 1. Disconnect luminaire AC input cable from power source. Step 2. At luminaire, remove top and bottom head covers as follows: a.
Page 42
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Front Assembly Removal (continued) Step 4. At junction connector, disconnect edge motor wiring. Step 5. Face head nose upward. At front of bulkhead, using #2 Phillips long handle screwdriver, remove four 6-32 X 3/8" PPB screws, and pull front assembly out of head assembly.
AINTENANCE AINTENANCE ROCEDURES Beam Spreader Motor Assembly Replacement Parts: 22.9671.0468 To remove and replace beam spreader motor assembly: WARNING: All maintenance procedures are to be performed with power removed from the luminaire. Step 1. Disconnect luminaire AC input cable from power source. Step 2.
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Concave Lens Assembly Replacement Parts: 21.9671.0492 To remove and replace concave lens assembly: WARNING: All maintenance procedures are to be performed with power removed from the luminaire. Step 1. Disconnect luminaire AC input cable from power source.
AINTENANCE AINTENANCE ROCEDURES Convex Lens Assembly Replacement Parts: 22.9671.0414 To remove and replace convex lens assembly: WARNING: All maintenance procedures are to be performed with power removed from the luminaire. Step 1. Disconnect luminaire AC input cable from power source. Step 2.
Page 46
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Convex Lens Assembly Replacement (continued) CAUTION: Do not touch lens with bare fingers. Wear cotton gloves or other covering while replacing. Step 4. Remove convex lens assembly from lens shafts. Step 5. In replacement convex lens assembly, using 1/4" Allen Wrench, adjust 8-32 x 2"...
AINTENANCE AINTENANCE ROCEDURES 100MM Condenser Lens Assembly Replacement Parts: 22.9671.0402 To remove and replace 100MM condenser lens assembly: WARNING: All maintenance procedures are to be performed with power removed from the luminaire. Step 1. Disconnect luminaire AC input cable from power source. Step 2.
AINTENANCE AINTENANCE ROCEDURES Yoke Assembly This section provides removal and replacement procedures for components found in the luminaire yoke assembly. Tilt Motor Assembly Replacement Parts: 22.9676.0610 To remove and replace tilt motor assembly: Step 1. Disconnect luminaire AC input cable from power source. Step 2.
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Main Control Board (MCB) PCB Replacement Parts: 24.9676.3730 To remove and replace an MCB PCB: Step 1. Disconnect luminaire AC input cable from power source. Step 2. At board-side leg, remove yoke leg cover by removing four 6-32×5/16" PTB...
AINTENANCE AINTENANCE ROCEDURES Ignitor PCB Replacement Parts: 24.9661.3126 To remove and replace ignitor PCB: Step 1. Disconnect luminaire AC input cable from power source. Ignitor PCB Screws Yoke Leg Cover Yoke cross member Figure 2-14: Ignitor PCB Replacement Step 2. At each yoke leg, remove yoke leg cover by removing four -32×5/16"...
Page 52
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Ignitor PCB Replacement (continued) Step 8. Remove two 1/4" hex standoffs from ignitor PCB by removing one 6-32×5/ 16" PPZ screw and #6 lock washer. Install in same place on new ignitor PCB.
AINTENANCE AINTENANCE ROCEDURES Enclosure Assembly This section provides removal and replacement procedures for components found in the luminaire enclosure assembly. Removing Enclosure Covers To gain access to enclosure components, it will be necessary to remove the top and bottom covers. To remove and replace enclosure covers: Step 1.
Page 54
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Removing Enclosure Covers (continued) CAUTION: Be careful not to damage lens during next step. Step 4. Carefully lay luminaire on its side as shown in Figure 2-17. Make sure that lens does not come into contact with any surface..
AINTENANCE AINTENANCE ROCEDURES Ballast Module Assembly Replacement Parts: 69.9676.0700 To remove and replace ballast module assembly: Step 1. Disconnect luminaire AC input cable from power source. Step 2. At enclosure, remove ballast-side and ventilation covers. Refer to “Removing Enclosure Covers” on page Note: Throughout this procedure, please note different size screws and their respec- tive locations Step 3.
Page 56
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Ballast Module Assembly Replacement (continued) Step 6. At ballast, disconnect the following cable assemblies: a. Lamp wires b. AC input a. Control wiring Step 7. Pull lamp wires through ferrite core. Step 8. At bottom of enclosure, remove three 8-32x3/8" PFZ screws and four 8/ 32x3/8"...
AINTENANCE AINTENANCE ROCEDURES Pan Motor / Pan Belt Assembly Replacement Parts: 21.9678.0864 - Pan Motor Assembly 54.2055.0001 - Pan Motor Belt To remove and replace pan motor assembly: Step 1. Using console or internal menus, run lens as far to the rear as possible. Step 2.
Page 58
SCB Cap screws that mount Pan Motor Assembly, you must tighten in a CLOCKWISE pattern starting with screw in lower left-hand side from spring. Enclosure Bottom View Pan Belt Pan Motor Assembly Bottom Cover NOTE: Head not shown for clarity. Figure 2-20: VL2500 Pan Motor Assembly Replacement 04-June-2009 02 .9 676 .00 22 A...
AINTENANCE AINTENANCE ROCEDURES Pan Encoder Replacement Parts: 24.9678.9729 To remove and replace pan encoder: Step 1. Using console or internal menus, run lens as far to the rear as possible. Step 2. Disconnect luminaire AC input cable from power source. CAUTION: Be careful not to damage lens during next step.
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Pan EOT (End of Travel) Sensor Replacement Parts: 86.7002.0003 To remove and replace pan EOT sensor: Step 1. Using console or internal menus, run lens as far to the rear as possible. Step 2. Disconnect luminaire AC input cable from power source.
AINTENANCE AINTENANCE ROCEDURES LVS (Low-Voltage Supply) Power Supply Replacement Parts: 69.3177.0151 To remove and replace LVS power supply: Step 1. Disconnect luminaire AC input cable from power source. Step 2. At enclosure, remove two 6-32 x 1/4" LG PPZ screws from display side cover and remove cover.
HAPTER Illustrated Parts Breakdown This chapter contains illustrated parts breakdowns for assemblies in the VL2500™ Wash Luminaire. • Drawing Tree • Top Assembly • Yoke • Enclosure • Cables WARNING: All maintenance procedures are to be performed with power removed from the luminaire. Never remove cover or backcap while lamp is in operation.
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Drawing Tree VL2500™ Wash Luminaire VL2500 Wash Luminaire 20.9676.0002 Rev L Front Wash Assembly VL2500 Generic Luminaire 21.9676.1006 Rev A 21.9676.0010 Rev J Concave/Diffuser Front Lens Connector Panel Assembly Assembly 21.9676.0800 Rev T 21.9671.0492 Rev D...
Page 65
Ballast to Controller Cable OT Switch to Reflector Assy. Cable Assembly Assembly 25.9678.0816 Rev A 25.9676.0719 Rev A Lamp Supply to Relay Cable VL2500 Wash Included Items Kit Assembly 28.9676.0002 Rev E 25.9678.0829 Rev A 02.96 76.002 2 A 04-June-2009...
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Wash Fan Assembly 22.9676.1090 Rev C Refer to Figure 3-11. Item Qty. Description 10.9676.1068 AIR DUCT, FRONT FAN, WASH 22.9676.0091 ASSY, FAN BULKHEAD 22.9676.0095 AIR DUCT, REAR FAN 25.8007.2212 CABLE ASSY, GROUND STRAP, #6 RING 3" LG 40.7113.0002...
Page 81
LLUSTRATED ARTS REAKDOWN SSEMBLY Wash Fan Assembly (continued) Direction of Air Flow (x8) (x2) (x2) (x3) 20, 21, 8, 9 7, 10 (x5) Figure 3-11: Wash Fan Assembly 02.96 76.002 2 A 04-June-2009...
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Crossfade Color Assembly 21.9676.1201 Rev F Refer to Figure 3-13. Item Qty. Description 10.9676.0230.01 SPACER, COLOR WHEEL 10.9676.0230.02 SPACER, COLOR MOTOR 10.9676.0234 AFT BULKHEAD, CROSSFADE COLOR SYSTEM 10.9676.0235 SPACER, BULKHEAD, COLOR SYSTEM 10.9676.0284 SHAFT, COLOR SYSTEM 10.9678.0238...
Page 85
LLUSTRATED ARTS REAKDOWN SSEMBLY Item Qty. Description 55.2110.0002 WASHER, .400" OD X .260" ID X .010 THK 55.6545.0007 SCREW, 8-32 X 3/8" PFB (x2) (x2) (x2) (x4) (x2) (x5) (x4) (x2) Amber (x2) Cyan Cyan (x2) Detail A Magenta Dimmer 2 29 (x2) (x2)
LLUSTRATED ARTS REAKDOWN Tilt Motor Assembly 22.9676.0610 Rev C Refer to Figure 3-19. Item Qty. Description PLATE, TENSION ADJUST, PAN MOTOR 10.9676.7298 ASSY, DRIVE PULLEY 22.9661.0608 CODEWHEEL, 90 COUNT - 10.9661.8640 TIMING PULLEY, 2MM GT, 17 TOOTH - 10.9661.0649 - 53.5561.0250 SCREW, 6-40 X 1/4"...
Page 94
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Tilt Motor Assembly (continued) Detail A Detail A (x2) (x2) (x2) (x2) (x2) (x2) Pulley Height Detail & Installation 0.080" (x4) Step 1. Apply one drop of Loctite 603 to motor shaft. Step 2.
LLUSTRATED ARTS REAKDOWN Yoke Fan Assembly 22.9676.0609 Rev A Refer to Figure 3-20. Item Qty. Description 10-9676.0646 FAN TRAY, YOKE ARM 40.7113.0001 FAN, +24V 80 X 80 X 25 MM 32CFM RECPT, 2POS MTA100 W/ POL TAB RED CLSD END 52.6396.2202 NUT, 6-32 KEPS SS 53.2200.0006...
LLUSTRATED ARTS REAKDOWN NCLOSURE Pan Tube Assembly 21.9678.0880 Rev C Refer to Figure 3-26. Item Qty. Description 10.9678.0809 PAN TOGGLE STOP 10.9678.0847 WASHER, SILICONE FOAM 10.9678.0848 WASHER, PAN TEFLON 12.9678.0891 PAN TUBE, MACHINED 54.1206.0021 RING, RETAINING 1.562" SHAFT 1.468" GRV DIA 54.1255.0002 BEARING ASSY, FLUSH MOUNT HOUSING LARGE Figure 3-26: Pan Tube Assembly...
VARI❋LITE® - VL2500™ W UMINAIRE ERVICE ANUAL Pan Motor Assembly 21.9678.0864 Rev E Figure 3-27 Refer to Item Qty. Description 10.9678.0865 PLATE, PAN MOTOR MOUNT 21.9678.0828 ASSY, DRIVE PULLEY, PAN - 10.9686.8720 CODEWHEEL, 120 COUNT LARGE ID - 10.9678.0749 TIMING PULLEY, 2MM GT 17 TOOTH - 53.5560.0250...
Page 107
LLUSTRATED ARTS REAKDOWN NCLOSURE Pan Motor Assembly (continued) Detail A Pressure-Sensitive Adhesive See Detail A (x2) (x2) (x2) (x4) Drive Pulley Detail & Installation (x4) 0.875" Step 1. Apply one drop of Loctite 603 to motor shaft. Step 2. Install drive pulley on motor shaft using twisting motion to insure coverage of shaft with loctite.
LLUSTRATED ARTS REAKDOWN ABLES Cables Note: Cables are only available as complete assemblies. The information contained in this section is for reference only. Ground Strap Cable Assembly 25.8007.2212 Rev 0 Refer to Figure 3-48. Item Qty. Description 52.8329.0001 TERM, RING # 6 22-16 AWG NON-INS 73.7130.0002 0.33 WIRE, 7/64"...
LLUSTRATED ARTS REAKDOWN ABLES Data I/O Link Cable Assembly 25.9678.0813 Rev A Refer to Figure 3-62 Item Qty. Description 52.6396.2904 RECEPT, 4 POS MTA100 W/POL TAB RED CLSD END 52.6396.2905 RECEPT, 5 POS MTA100 W/POL TAB RED CLSD END 73.5122.0259 2.17 CBL, 22AWG STRND 4COND PVC INSUL Figure 3-62: Data I/O Link Cable Assembly...
Technical Bulletins and Notices VL2500™ Wash Luminaire Technical Bulletins and Notices The following table identifies the current technical bulletins and notices associated with the VL2500™ Wash Luminaire. If applicable, these improvements have been incorporated into this manual. Technical Bulletin Description...
