Connecting the DSL-504 Connecting the DSL-504
Now connect the phoneline cable from the DSL-504 to your phone jack.
When you have completed all the connections, your DSL-504 will look
like this:
Power Cord
(Plug the other
end of the power
cord into
power outlet.)
2 2

Setting up the Computer

Setting up the Computer
Right-Click the Network
Neighborhood (Win 98/98SE) or
My Network Places (Win ME/2000)
icon on your desktop.
Select Properties
Ethernet Cable
(Plug the other end of the
Ethernet cable into the
the
Ethernet port on the NIC,
which is installed in your
computer.)
continued
Phone line cable
(Plug the other end of
the phone line cable
into the phone jack.)
