Pedal Unit - Logitech G920 User Manual

Pedal unit

1 2
Logitech® G920 Driving Force™
3
4
5
6
7
9 English
1. Clutch pedal
2. Brake pedal
3. Throttle pedal
4. Textured heel rest
5. Bolt mounting points (uses M6X1 bolts)
6. Patented carpet grip system
7. Carpet grip release clip
Push towards rear or pedal unit
to release
8. Change pedal face position
(requires 2.5mm hex key)
8
