A100/25 5E + A100AE/25
en
Assembly and Operating Instructions
Sectional door drives
Important information for:
• Fitters / • Electricians / • Users
Please forward accordingly!
These instructions must be kept safe for future reference.
Becker-Antriebe GmbH
Friedrich-Ebert-Straße 2-4
35764 Sinn/Germany
www.becker-antriebe.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Becker A100/25 5E
Summary of Contents for Becker A100/25 5E
- Page 1 A100/25 5E + A100AE/25 Assembly and Operating Instructions Sectional door drives Important information for: • Fitters / • Electricians / • Users Please forward accordingly! These instructions must be kept safe for future reference. Becker-Antriebe GmbH Friedrich-Ebert-Straße 2-4 35764 Sinn/Germany...
-
Page 2: Table Of Contents
Table of contents Contents ..................................... 3 General ....................................3 Warranty ..................................... 3 Intended use ..................................3 Safety instructions ................................4 Product overview and dimensions ............................5 Installation ..................................6 Emergency manual operation ............................... 7 Voltage switching ................................11 Electrical connection to the control unit and connection diagram ..................12 Checking the running direction ............................ -
Page 3: Contents
Contents General These drives are quality products with many features and advantages. ▪ Compact design ▪ Can be installed in any position ▪ Plug-in control cable ▪ Universal power supply 3~230 V/400 V/50 Hz ▪ TÜV type examination – Mark approval certificate in accordance with DIN EN 12453 Please observe these Assembly and Operating Instructions when installing and setting the equipment. -
Page 4: Safety Instructions
Safety instructions The following safety instructions and warnings are intended to avert hazards and to prevent property damage and personal injury. Please keep these instructions in a safe place. Caution Important safety instructions. Caution! Failure to observe these instructions can lead to serious injuries. Follow the safety instructions contained in EN 12453, EN 12445 and BGR 232. -
Page 5: Product Overview And Dimensions
Product overview and dimensions All dimensions in mm. Drives with a crank handle (HK) Drives with a light chain (LK) Hole pattern 6,35 M 8 x 10 Ø 25,4... -
Page 6: Installation
Installation Caution During installation of the drive, access to the danger zone must be blocked off. The drive must be properly mounted on a mounting or torque supporting plate (in accordance with the output of the drive) with adequate stability. In the case of directly operated door systems, the drive must be mounted using 4 fastening screws M8 (8.8) on a vibration reducing mounting. -
Page 7: Emergency Manual Operation
Emergency manual operation Emergency manual operation is only intended for commissioning the drive, maintenance work and emergency operation in order to open or close the door in the event of a short-term power failure. Emergency manual operation is solely intended for manual operation. - Page 8 Light chain (LK) In the case of horizontal drive installation Installation of the chain wheel Mount the chain on the chain wheel so that there is roughly the same number of chain links overhanging on both sides (1.). Then feed the two ends of the chain fully be‐ tween the deflection pulleys and the coupling shaft (2.).
- Page 9 Insertion of the chain ends Take the short chain strand and align it so that the chain links are not twisted (5.). Now insert the last link in the chain (6.) in the chain cross provided (7.) in accordance with its alignment. Pull the chain end which has just been inserted through the chain cross until approx.
- Page 10 Light chain (LK) Connection of the chain ends and operation Connection of the chain ends Before connecting the ends of the chain using the chain lock provided, it must be en‐ sured that the chain is not twisted when it is mounted. The chain lock must be fastened carefully.
-
Page 11: Voltage Switching
Voltage switching Caution Before voltage switching, the drive must be safely disconnected from the mains. The drives can be operated on a 3~ 400 V ( -star connection) or 3~ 230 V ( -delta connection) network. The drives are delivered pre-wired for operation on a 3~ 400 V network. -
Page 12: Electrical Connection To The Control Unit And Connection Diagram
Electrical connection to the control unit and connection diagram Caution The electrical connection may only be carried out by a qualified electrician! Please ensure adherence to all da‐ ta on the supplied control unit and all applicable EN standards! When all connection work is being carried out, the door system must be safely disconnected from the mains by removing the plug/switching off the main switch. - Page 13 AE-WU AE-S80 3~400 V 3~230 V Absolute value encoder electrical interface: Plugs (1-6) Terminals (7-12 wired by manufacturer) 1 - Safety chain input 7/8 - S4F thermoswitch 2 - RS485 B 9/10 - S3F safety limit switch HK/LK 3 - GND 11/12 - Jumper (possible connection point for external safety 4 - RS485 A elements)
-
Page 14: Checking The Running Direction
Checking the running direction The direction of drive rotation depends on the mains connection to the control unit and must be checked first. Proceed as follows: ▪ Move the door into the semi-opened position using the emergency manual operation function. ▪... -
Page 15: Maintenance
Maintenance Attention The door system must be regularly checked by an expert to ensure that it is in safe working order. The door manufacturer stipulates the frequency of maintenance and checks according to national regulations and the frequency of use. Counterweight (applies to sectional doors with spring compensation or a counterweight): The counterweight/spring tension must be checked. -
Page 16: Technical Data
Technical data Type Unit A100 5E A100AE Drive torque Drive speed Diameter of hollow shaft 25.4 Operating voltage 3~230 / 400 Frequency Nominal current 4.6/2.6 Performance factor 0.71 Insulation material class Thermoswitch °C Mode Degree of protection Limit switch range Revolutions Static holding torque On-site fuse protection... -
Page 17: Declaration Of Incorporation
Declaration of incorporation... - Page 20 2349 300 016 0b 27/01/2014...
