7) Each router is identified using a node identifier. This is a unique single digit number clearly
marked on the underside of the router. Open a web browser and visit http://192.168.3.1 to
connect to node 1
8) When prompted for sign in credentials , please input the following:
Username: admin Password: Bonding123 ( )
we recommend you change this password
9 In the menu positioned at the left of the displayed web page, select 'Quick Setup'
10) In the 'Country' drop down, select your country
11) In the 'ISP' drop down, select the Internet Service Provider associated with the line that
you are connecting this node to
12) In the 'PPP Username' field and 'PPP Password' field, input the corresponding ADSL logon
credentials provided by your ISP. You should have received these credentials directly from
your ISP when they processed your internet access subscription. If you're unable to locate
them, please request them from your ISP
13) Click the 'Next' button
14) Click the 'Confirm' button and then wait for 30 seconds to elapse
15) After 30 seconds has elapsed, click 'Management'
16) Click the reboot button towards the middle of the screen
17) Repeat above steps 7-16 for each of the remaining nodes. Each node has a different IP
address which corresponds with the number marked on the underside of the router. For
example router two can be accessed by visiting http://192.168.3.2, router 3 (if applicable)
can be accessed by visiting http://192.168.3.3, etc...
