1.4 TELEPHONE DIAL PAD

The dial pad may be used as a normal telephone
dial pad and to enter letters and numbers in the
PHONE BOOK. Press the buttons repeatedly to
select the associated characters and digits.

1.5 CALL MANAGEMENT BUTTONS

BUTTON FUNCTION DESCRIPTION
The FLASH function is used to activate/deactivate specific PABX services and to
FLASH
activate/deactivate the services offered by some telephone companies.
The RP button is used to repeat the last dial number or enter one or more PAUSES
REPEAT/PAUSE
during dialling.
TELEPHONE This button is used to pick-up and hang up the dial line when a headset is used.
HEADSET
Press this button to put one or more dial line on-hold to perform other operations.
The corresponding pictogram will appear on the display when one or more lines are
DIAL LINE PARK
parked.
The HANDFREE function allows to use the telephone without the handset
HANDFREE (FREE-HANDS mode). The corresponding pictogram will appear on the display when
the HANDFREE function is on.

1.6 MENU NAVIGATION BUTTONS

The menu navigation buttons are used to select functions and set values in the USER MENU.
BUTTON FUNCTION DESCRIPTION
Cancels the last entry, cancels the selected operation or goes to the previous level
CANC
menu.
Access the USER MENU, increase numeric data, go to the next level menu, increase
UP
menu.
Access the USER MENU, decrease numeric data, go to the previous level menu,
DOWN
decrease volume.
OK Confirm an entered value or selection.
10
Button > character correspondence table
1
A B C 2
D E F 3
G H I 4
J K L 5
M N O 6
P Q R S 7
T U V 8
W X Y Z 9
*
white
0
space
#
DS4091-002
1.7 PROGRAMMABLE BUTTONS AND SECOND AND THIRD FUNCTION BUTTONS
The PROGRAMMABLE BUTTONS are confi gured with default settings for using the 1362/624 PABX
switchboard and allow to pick-up the fi rst three lines (buttons F1, F3 and F5) and to recall the fi rst 12
extensions (41 ÷ 52). Refer to the BUTTON PROGRAMMING paragraph to reconfi gure the DIRECT
FUNCTIONS buttons. The functions associated to the buttons are shown in the following table.
BUTTON DIRECT FUNCTION
(DEFAULT SETTING)
Fn BUTTON
PICK-UP LINE 1 - This allows to
engage a dial line for making a call
or pick-up a parked line.
CALL EXTENSION 5 - This function
allows to directly call the telephone
connected to extension 5 of the
switchboard (default setting: 45).
PICK-UP LINE 2 - This allows to
engage a dial line for making a call
or pick-up a parked line.
CALL EXTENSION 6 - This function
allows to directly call the telephone
connected to extension 5 of the
switchboard (default setting: 46).
PICK-UP LINE 3 - This allows to
engage a dial line for making a call
or pick-up a parked line.
CALL EXTENSION 7 - This function
allows to directly call the telephone
connected to extension 5 of the
switchboard (default setting: 47).
DIAL LINE R - This function is used
to output a FLASH on the dial line
for accessing supplementary
services offered by the telephone
company.
CALL EXTENSION 8 - This function
allows to directly call the telephone
connected to extension 5 of the
switchboard (default setting: 48).
CALL EXTENSION 1 - This function
allows to directly call the telephone
connected to extension 5 of the
switchboard (default setting: 41).
CALL EXTENSION 9 - This function
allows to directly call the telephone
connected to extension 5 of the
switchboard (default setting: 49).
DS4091-002
SECOND FUNCTION THIRD FUNCTION
BUTTON + Fn BUTTON
TIMED DIVERT - This function will divert QUERY TIMED DIVERT
the calls reaching your extension after five This queries the status of
rings. the service.
DIVERT NOW - This function is used to QUERY DIVERT NOW
divert all calls routed to your extension. This queries the status of
the service.
DIVERT OUT - This function is used to DIVERT OUT OFF -
immediately divert all calls routed to your This is used to switch the
extension to a previously programmed service off.
external number using another telephone
line configured as private (DISA must be
enabled).
CALL DIVERT - It can be used to divert DIVERT OFF -
external calls not routed to a specific This is used to switch the
extension after the fifth ring towards a service off.
previously programmed external number
using another telephone line configured as
private (DISA enabling is required).
FOLLOW-ME - The function is used to QUERY FOLLOW-ME -
divert all calls routed to your extension to This queries the status of
another extension. This function is the service.
activated from the extension where you
want to receive the calls.
DO-NOT-DISTURB - This function is used DO-NOT-DISTURB OFF
to cut off the ringer for internal calls, This function is used to
external calls and door phone calls. switch the ringer for
internal calls, external
calls and door phone calls
back on.
-
DIAL LINE R - This function is used to
output a FLASH on the dial line for
accessing supplementary services offered
by the telephone company.
CONFERENCE - This function is used to -
establish a conversation between three
users.
CENTRAL DIRECTORY - This allows to -
access the switchboard directory
telephone numbers.
-
PICK-UP CALL - This function is used to
pick-up a call directed to another extension
from your extension.
BUTTON +
Fn BUTTON
11
