1.1 ELEMENTS

The Director 2 CL telephone consists of the following elements:
1
14
13
12
11
10
9
Id. DESCRIPTION
1 HANDSET SUPPORT
2 LCD
3 SWITCHBOARD SERVICES AND
SPECIAL FUNCTIONS BUTTONS
4 DIAL PAD
5 CALL MANAGEMENT BUTTONS
6 MENU NAVIGATION BUTTONS
7 FUNCTION BUTTONS 2 AND 3
6
2
8 7 6
Id. DESCRIPTION
8 NUMBER CARD
9 HANDSET GRIP
10 HANDFREE SPEAKER
11 PROGRAMMABLE BUTTONS
12 CUSTOMISABLE BUTTON LEDS
13 HANDSET HOOK
14 HOOK LEVER
3
4
5
Id.
1 WALL-MOUNTING SUPPORTS
2 SPACER ANCHORING HOLES
(TABLE-TOP ARRANGEMENT)
3 RESERVED USE CONNECTOR
4 HANDSET/HEADPHONE WIRE CONNECTOR
5 SPACER ANCHORING HOLES
(WALL-MOUNTED ARRANGEMENT)
6 RUBBER FEET
7 HANDFREE MICROPHONE
8 LINE WIRE CONNECTOR
DS4091-002 DS4091-002
1 2
8
4091/14
7
SPACER
TELEPHONE
DESCRIPTION
1
3
4
5
6
SOCKET
7
