- Page 1 MX6 iBrid ™ Multi-Gas Monitor Operation Guide Ex-Ox-Tox Gasdetectie Westerdreef 5V Part Number: 17130279-1 2152 CS Nieuw-Vennep Telefoon: 0252 620885 Revision: E-mail: info@exoxtox.nl Release Date: 03.01.2013 Website: www.exoxtox.nl...
-
Page 2: Table Of Contents
MX6 iBrid™ Multi-Gas Monitor Table of Contents CERTIFICATIONS ..............................3 WARNINGS AND CAUTIONARY STATEMENTS ....................3 KEY FEATURES ................................ 8 QUICK START MENU FLOWCHARTS ......................10 CHARGING THE BATTERY ..........................11 MENU OPERATION BASICS ..........................13 ... -
Page 3: Certifications
MX6 iBrid Multi-Gas Monitor Operation Guide CERTIFICATIONS Directive/Code Certification Marking Standard ATEX Ex ia IIC T4 Ga / Ex ia I Ma; IP65 (IP64 pump EN 60079-0: 2009 version) EN 60079-1: 2007 Equipment Group and Category: II 1G/ I M1 (I... - Page 4 Operation Guide MX6 iBrid™ Multi-Gas Monitor IMPORTANT: Read and understand this manual before operating. IMPORTANT: The instrument must be charged before its first use. IMPORTANT: Be sure to turn off the instrument before (1) servicing the unit or (2) replacing the battery.
- Page 5 ISC recommends that clear urethane tubing, part number 17065970, be used with the pumped versions of the MX6 iBrid when sampling for the following gases: Ammonia (NH3), Chlorine (Cl2), Chlorine Dioxide (ClO2), Hydrogen Chloride (HCl), Hydrogen Cyanide...
- Page 6 CAUTION: For compliance determinations required by 30 CFR 75, Subpart D, the monitor must display "CH4" and “%VOL” during the monitor's start-up sequence. CAUTION: The Model MX6 iBrid Multi-Gas Monitor must be configured to include a catalytic sensor, Model 4L-LEL, P/N 1710-5081, (CH4, 0-5% v/v).
- Page 7 Operation Guide Hardware Overview The MX6 multi-gas monitor is Industrial Scientific Corporation’s next-generation handheld, “dockable,” multiple gas monitoring instrument. It includes up to five temperature-compensated sensors to monitor up to six ambient gases across the full temperature range of the instrument.
-
Page 8: Key Features
Operation Guide MX6 iBrid™ Multi-Gas Monitor Key Features Audio Used for alarming, warnings, and the optional confidence indicator. There are Indicator two levels of audio gas alarms based on the frequency of the beeps and the length of delay between beeps. - Page 9 MX6 iBrid™ Multi-Gas Monitor Operation Guide Color LCD The STN color graphic liquid crystal display (LCD) uses a 256-color palette (including a gray scale) and graphics for displaying information. Menu-Driven The user interface is menu-driven and contains the LCD, Navigation Button, User Audio Indicator, Vibrating Alarm, and Visual Alarm.
-
Page 10: Quick Start Menu Flowcharts
Operation Guide MX6 iBrid™ Multi-Gas Monitor Quick Start Menu Flowcharts INDUSTRIAL SCIENTIFIC... -
Page 11: Charging The Battery
MX6 iBrid™ Multi-Gas Monitor Operation Guide Charging the Battery The MX6 multi-gas instrument is powered using an internal alkaline or Lithium-ion (Li-ion) rechargeable battery. The Li-ion battery is partially charged before it leaves the factory, but must be fully recharged prior to use. To charge the battery, follow the steps listed below. - Page 12 Operation Guide MX6 iBrid™ Multi-Gas Monitor Under the main menu [View] option, there is a [Battery] menu option. The menu provides a link to the Battery Status screen. The Battery Status screen shows approximately how much run-time is left on the instrument.
-
Page 13: Menu Operation Basics
MX6 iBrid™ Multi-Gas Monitor Operation Guide Menu Operation Basics The actions that are initiated by pressing the five-way navigation button may vary significantly based on (1) the user’s location within the menu structure, and on (2) a particular action item of interest (of many) on one individual screen. -
Page 14: Power Up And Shut Down
Operation Guide MX6 iBrid™ Multi-Gas Monitor Power Up and Shut Down Two key operation basics are powering up the Enter instrument and shutting it down. To power up the MX6 instrument, locate, press and hold the center [ENTER] navigation button for at least 3 seconds. - Page 15 MX6 iBrid™ Multi-Gas Monitor Operation Guide Display Component Attribute Normal Mode Alarm Mode Color Black Black Sensor Name State Solid Solid Color Black Sensor Reading State Solid Solid Color Black Black Sensor Units State Solid Solid NOTE: For over range conditions, a blinking “OR” is displayed in red as the sensor value. If the alarm is a STEL or TWA, the word “STEL”...
-
Page 16: View Menu Options
Operation Guide MX6 iBrid™ Multi-Gas Monitor View Menu Options INDUSTRIAL SCIENTIFIC... -
Page 17: Configuration Menus
MX6 iBrid™ Multi-Gas Monitor Operation Guide Configuration Menus Under the main menu [View] option, there is a [Configure] menu option. This menu provides access to the Configuration screens of the instrument. The user must enter a password to get to the Configuration Menus (if a password has been set). -
Page 18: Calibration Policy
The frequency of testing is best determined by company policy or local regulatory agencies. Industrial Scientific further recommends that a full instrument calibration be performed using a certified concentration(s) of Industrial Scientific branded calibration gas(es) monthly to ensure maximum accuracy. -
Page 19: Zero All Option
MX6 iBrid™ Multi-Gas Monitor Operation Guide Zero All Option Under the main menu [Sensor] option, there is a [Zero All] menu option. If [Zero All] is selected, the MX6 displays the verification question. At this time, the focus is on the OK button. - Page 20 Operation Guide MX6 iBrid™ Multi-Gas Monitor If the user selects OK, all the installed sensors are zeroed first (following the Zero All steps) and then calibrated. After the zero, the results are shown, for 5 seconds and then the calibration of the first sensor begins.
-
Page 21: Bump Test Option
MX6 iBrid™ Multi-Gas Monitor Operation Guide Bump TEST Option Under the main menu [Sensor] option, there is a [Bump Test] menu option. If the [Bump Test] option is selected, a confirmation screen is displayed. If Cancel is selected, the user is returned to the NRS. -
Page 22: Datalog Menu Options
Operation Guide MX6 iBrid™ Multi-Gas Monitor Datalog Menu Options INDUSTRIAL SCIENTIFIC... -
Page 23: Configuration Menus
MX6 iBrid™ Multi-Gas Monitor Operation Guide Configuration Menus These are similar to the earlier menus, but these menus provide a deeper layer of access for detailed operational configuration of the device. As such, the settings presented in these three chapters should only be adjusted by experienced personnel, as inadvertent or accidental changes to these settings could alter the devices operation significantly. - Page 24 Operation Guide MX6 iBrid™ Multi-Gas Monitor If any two of these alarms are disabled and the user checks the box to disable the third alarm, a screen is displayed to verify this action. Selecting OK disables the third and final alarm. A screen is displayed, notifying the user of the action.
-
Page 25: Sensor Specifications And Correlation Factors
MX6 iBrid™ Multi-Gas Monitor Operation Guide SENSOR SPECIFICATIONS AND CORRELATION FACTORS Sensor specifications Sensor properties Accuracy Response time (typical) Sensor Category Gas Names Seconds (s) (%vol, %LEL, or ppm) degrees (°) Oxygen -20°C to 55°C 5 to 95 ± 0.5 ±... - Page 26 Operation Guide MX6 iBrid™ Multi-Gas Monitor Sensor specifications Sensor properties Accuracy Response time (typical) Sensor Category Gas Names Seconds (s) (%vol, %LEL, or ppm) degrees (°) Chlorine 0 to 50 0.10 ppm -20°C to 40°C 15 to 90 ± 10.0...
- Page 27 MX6 iBrid™ Multi-Gas Monitor Operation Guide LEL and LEL correlation factors for combustible gases Sample gas* LEL correlation factors (% vol) Calibration gas Butane Hexane Hydrogen Methane Pentane Propane Acetone 2.5% 1.00 0.70 1.70 1.70 0.90 1.10 Acetylene 2.5% 0.70 0.60...
-
Page 28: Warranty
MX6 iBrid™ Multi-Gas Monitor WARRANTY Industrial Scientific Corporation’s MX6 iBrid™ portable gas monitors are warranted to be free from defects in material and workmanship under normal and proper use and service for as long as the instrument is supported by Industrial Scientific Corporation. - Page 29 It is expressly agreed by the parties that any technical or other advice given by Industrial Scientific with respect to the use of the goods or services is given without charge and at Buyer’s risk; therefore, Industrial Scientific assumes no obligations or liability for the advice given or results obtained.
- Page 30 Operation Guide MX6 iBrid™ Multi-Gas Monitor wykorzystania jako skrócony kurs obsługi detektora. INDUSTRIAL SCIENTIFIC...
- Page 31 Corporation accepts no responsibility for its use by any means or in any way whatsoever Industrial Scientific Corporation shall not be liable for any expenses, costs by damage that may result from the use of the information contained within this document.
- Page 32 Operation Guide MX6 iBrid™ Multi-Gas Monitor Ex-Ox-Tox Gasdetectie Westerdreef 5V 2152 CS Nieuw-Vennep Telefoon: 0252 620885 E-mail: info@exoxtox.nl Website: www.exoxtox.nl INDUSTRIAL SCIENTIFIC...
