SPECIFICATIONS OF WIEGAND CONNECTORS (FOR CARD READER)

Pin No. Port Name
1 POWER
2 GND
3 DATA 0
4 DATA 1
SPECIFICATIONS OF RS-485 CONNECTORS (FOR CARD READER)
Pin No. Port Name
13 RS-485 (A)
14
RS-485 (B)

SPECIFICATIONS OF WIEGAND CONNECTORS (FOR ACCESS CONTROL PANEL)

Pin No. Port Name
5 ACCEPT-LED
6 POWER
7 GND
8 DATA 0
9 DATA 1
10 REJECT-LED
* This port is for wiring designation convenience only.
I/O Signal Description
OUT Wiegand 5 V
– Wiegand GND
IN Wiegand DATA 0
IN Wiegand DATA 1
I/O Signal Description
IN/OUT RS-485 (A)
IN/OUT RS-485 (B)
I/O Signal Description
IN Wiegand ACCEPT-LED
IN* Wiegand 5 V
– Wiegand GND
OUT Wiegand DATA 0
OUT Wiegand DATA 1
IN Wiegand REJECT-LED
(A)
To the RS-485B
terminal of
(B)
RWK400
(A)
To the RS-485A
terminal of (B)
RWK400
Remarks
5 V, 100 mA (Max)
0 V
0 V to 5 V, 24 mA (Max), Wiegand I/F
Active low
0 V to 5 V, 24 mA (Max), Wiegand I/F
Active low
Remarks
Differential input: ± 0.2 V or more
Differential output: ± 2 V or more
(When termination is ON)
Differential input: ± 0.2 V or more
Differential output: ± 2 V or more
(When termination is ON)
Remarks
0 V to 5 V, 24 mA (Max), Wiegand I/F
Active low,Pulse width: 200 ms or more
5 V
0 V
0 V to 5 V, 24 mA (Max), Wiegand I/F
Active low
0 V to 5 V, 24 mA (Max), Wiegand I/F
Active low
0 V to 5 V, 24 mA (Max), Wiegand I/F
Active low, Pulse width: 200 ms or more
15
