Rear view

4
5
No. Name Function
1. Power button Press quickly to enter sleep mode or wake from sleep mode; press
and hold to power down or up
2. Rear-facing camera 5.0 MP rear camera
3. Microphone Internal microphone
4. Volume up/down Press the top to increase the volume; press the bottom to decrease
the volume
5. Speaker Two built-in speakers (disabled when you connect headphones)
1
3
2
5
8

Left side view

1 2
No. Name Function
1. Power connector Plug in the AC adapter to charge your tablet
2. Headphone connector Connect headphones or external speakers (shuts off the internal
speaker)
3. MicroSD card slot Insert a microSD card for additional storage
TM
4. Micro-HDMI port Use a micro-HDMI-to-HDMI cable to connect to a TV or interactive
®
whiteboard
5. Micro USB port Connect an external keyboard
3 4 5
