Summary of Contents for ECS TA80CA1
- Page 1 TA80CA1 Quick Start Guide ...
- Page 2 TA80CA1 Quick Start Guide Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 3: Package Contents
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. FOR PORTABLE DEVICE USAGE Radiation Exposure Statement: The product comply with the FCC portable RF exposure limit set... -
Page 4: Tablet Layout
Tablet layout Name Name Touchscreen Headphone plug Front facing camera Micro SD card slot Light sensor Mini HDMI port Mobile network Microphone card slot Micro USB port... - Page 5 Name Name Rear facing camera Power Button Speaker Volume up/down Mobile network card slot ...
-
Page 6: Charging Your Tablet
Charging your tablet If your tablet is just being unpacked from the box, you need to charge the tablet first. It will take around 4 to 5 hours to be fully charged. 1. Plug the USB head of the cable into the adapter. 2. - Page 7 Inserting your mobile network card (optional) For the optional mobile network card, follow the steps below to install it. 1. Turn off your tablet. 2. Flip open and remove the cover of the card slot. 3. Insert your mobile network card. 4.
- Page 8 Powering ON/OFF your tablet To power on your tablet Press and hold the power button down until the screen turn on. To power off your tablet 1. Press and hold the power button until the power options menu appears on the screen. 2.
-
Page 9: Inserting A Storage Card
Inserting a storage card Your tablet supports micro-SD cards with storage space ranging from 128M to 32G. You can insert the micro SD card and pull it out without powering down the tablet. To do so, follow the steps below. Install your Micro SD Card 1. -
Page 10: Specifications
Specifications Processor l Intel Clovertrail+ Z2560 l 1 GB or 2 GB (optional) Memory LPDDR2 Storage l 16GB l WLAN, Bluetooth Wireless l Mobile Network l 8-inch 800x1280 screen Display l Support10-pointsmulti-touch l Front camera: 2.0 M Cameras l Rear camera: 5.0 M l... -
Page 11: Mobile Network
l HSUPA/HSDPA/WCDMA: 2100(900/850) Mobile Network l GSM: 1800, 900 (optional) l HSDPA: 14.4Mbps(DL)/5.76Mbps(UL) l Data only l DC Output: 5V/2A l Input Voltage: 100 ~ 240VAC AC-Adapter l Input Frequency: 47 ~ 63Hz. l Chicony: W12-010N3A, W12-010N3B W12-010N3C, W12-010N3D W12-010N3E Dimension (mm) l...
