HD Video Deserializer/ SER-800D Serializer SER-810E Guide to Installation and Operation M398-9900-101 Copyright 2002 Miranda Technologies Inc. Specifications may be subject to change. Printed in Canada August 2002 Miranda Technologies inc. 3499 Douglas-B.-Floreani St-Laurent, Québec, Canada H4S 1Y6 Tel. 514-333-1772 Fax.
Page 2
Miranda, at its sole dis- cretion. In no event shall Miranda Technologies Inc. be liable for any incidental or consequential damages, including loss of profits.
Page 3
SER-800D/810E - Guide to Installation and Operation for the delivery of the loaner or exchange products or parts. Freight and insurance charges for the return of the defective product or part will also be paid by Miranda Technologies. Out-Of-Warranty Repair Policy Miranda will repair equipment which is out of Warranty.
Page 4
SER-800D/E - Guide to Installation and Operation How to contact us: Head Office Miranda Europe Miranda Technologies Inc. 222, 226 Rue De Rosny 3499 Douglas-B.-Floreani 93100 Montreuil St. Laurent (Montreal), Que. H4S 1Y6 France Canada +1 (514) 333-1772 +33 1 55 86 87 88...
Page 5
SER-800D/810E - Guide to Installation and Operation...
SER-800D/810E - Guide to Installation and Operation 1 SER-800D/810E HD Video Deserializer/Serializer 1.1 Introduction Part of Miranda's family of SER serial coders are the SER-800D High Definition Video Deserializer and the SER-810E High Definition Video Serializer. The SER-800D converts HD serial digital video to HD parallel video, while the SER-810E converts HD parallel video to HD serial digital video.
Page 9
SER-800D/810E - Guide to Installation and Operation...
SER-800D/810E - Guide to Installation and Operation 2 Installation 2.1 SER-800D Overview Figure 2.1 illustrates the SER-800D’s major parts and their loca- tions. The HD-SDI video input signal is connected to the IN BNC connector and the decoded HD Parallel video signal is output through the D-SUB 50 connector.
SER-800D/810 E - Guide to Installation and Operation Figure 2.1 illustrates the SER-810E’s major parts and their loca- tions. The HD parallel video input signal is connected to the male 50-pin connector and the encoded HD SDI video signal is output through the two OUT BNCs.
1.485/1.001 Gbps). Parallel HD Output The decoded HD parallel video signal is output by the D-SUB 50 connector. You can attach the SER-800D directly to the destina- tion equipment by securing the mounting screws to the destina- tion equipment female connector.
Figure 3.1 indicates the location of the miniature slide switch on the SER-800D/810E. Figure 3.1 SER-800D/810E Slide Switch location Mode slide switch Mode A (Panasonic pinout) Set the SER-800D/810E to this mode when connecting to equip- ment that uses the Panasonic D-SUB 50 pin-out: Pin # Signal* Pin#...
SER-800D/810E - Guide to Installation and Operation Mode B (Philips pinout) Set the SER-800D/810E to this mode when connecting to equip- ment that uses the Philips D-SUB 50 pin-out: Pin # Signal* Pin# Signal* Pin# Signal* CLK+ CLK- Data9+ Data9-...
Page 15
SER-800D/810E - Guide to Installation and Operation...
4.1 SER-WSU Power Supply The power supply SER-WSU, for 110V and 220V operation, is used to power the SER-800D/810E. The SER-WSU provides a regulated -5.1VDC@2.4A power source. Plug the power supply into a wall or power bar outlet. The SER-WSU comes with two outlet adapters;...
SER-800D/810E - Guide to Installation and Operation 4.2.1 SER-CPS Front Panel Figure 4.2 describes the SER-CPS front panel. Figure 4.2 SER-CPS Front Panel SER Power Frame POWER ON POWER FAIL Rack mount holes Power On indicator Power Fail indicator The front panel consists of the following parts: Power On Indicator This indicator lights up when AC power is connected to the frame.
SER-800D/810E - Guide to Installation and Operation The rear panel consists of the following parts: DC Power Outputs Ten DC power outputs are available to power any member of the SER coder family. AC Power Connector AC power cord to be connected here. Both 110 VAC and 220 VAC standards supported.
SER-800D/810 E - Guide to Installation and Operation 4.2.4 Locating and replacing a defective power supply In the event that the Power Fail indicator turns on, follow the steps below to locate and replace the defective power supply: 1- Ensure that the SER-CPS is powered. Remove the top cover, preventing contact with any internal AC wiring.
The DB-SUB 50 connectors should have #4-40 screw locks with a conductive backshell to maintain proper shielding. If the connector end installed on the SER-800D/810E coder is male, use the female-to-female cable adapter provided. For cables longer than a few meters, twisted pairs should be used for each signal and its return.
Page 21
SER-800D/810E - Guide to Installation and Operation...
SER-800D/810E - Guide to Installation and Operation 5 Specifications Inputs SER-800D HD-SDI video signal: HD-SDI (SMPTE-292M, 1.485 and 1.485/1.001 Gb/S) with active loop- through Max. cable length: 100m (350’) Connector: BNC (75 ohm) SER-810E HD parallel video signal: 720p @ 23.98/24/25/29/29.97/30/50/59.94/60 Hz frame freq.
Page 23
SER-800D/810E - Guide to Installation and Operation Connector: D-SUB 50 Panasonic or Philips pin-out, user- selectable SER-810E HD SDI video signal (2): HD SDI (SMPTE-292M, 1.485 and 1.485/1.001 Gbps) Connector: BNC (75 ohm) Mechanical Dimensions: Width: 67mm (2.63") Height: 20 mm (0.8") Depth: 85 mm (3.35")
Page 24
SER-800D/E Copyright 2002 Miranda Technologies Inc. Specifications may be subject to change. Printed in Canada August 2002 Miranda Technologies inc. 3499 Douglas-B.-Floreani St-Laurent, Québec, Canada H4S 1Y6 Tel. 514-333-1772 Fax. 514-333-9828 www.miranda.com...
Page 25
Miranda, at its sole dis- cretion. In no event shall Miranda Technologies Inc. be liable for any incidental or consequential damages, including loss of profits.
Page 26
SER-800D/E - Guide to Installation and Operation for the delivery of the loaner or exchange products or parts. Freight and insurance charges for the return of the defective product or part will also be paid by Miranda Technologies. Out-Of-Warranty Repair Policy Miranda will repair equipment which is out of Warranty.
Page 27
SER-800D/E - Guide to Installation and Operation How to contact us: Head Office Miranda Europe Miranda Technologies Inc. 222, 226 Rue De Rosny 3499 Douglas-B.-Floreani 93100 Montreuil St. Laurent (Montreal), Que. H4S 1Y6 France Canada +1 (514) 333-1772 +33 1 55 86 87 88...
Page 28
SER-800D/E - Guide to Installation and Operation...
SER-800D/E - Guide to Installation and Operation 1 SER-800D/E HD Video Deserializer/Serializer 1.1 Introduction Part of Miranda's family of SER serial coders are the SER-800D High Definition Video Deserializer and the SER-800E High Definition Video Serializer. The SER-800D converts HD serial digital video to HD parallel video, while the SER-800E converts HD parallel video to HD serial digital video.
Page 32
SER-800D/E - Guide to Installation and Operation...
SER-800D/E - Guide to Installation and Operation 2 Installation 2.1 SER-800D Overview Figure 2.1 illustrates the SER-800D major parts and their loca- tions. The HD-SDI video input signal is connected to the IN BNC connector and the decoded HD Parallel video signal is output through the D-SUB 50 connector.
SER-800D/E - Guide to Installation and Operation 2.3 SER-800E Overview Figure 2.1 illustrates the SER-800E major parts and their loca- tions. The HD parallel video input signal is connected to the male 50-pin connector and the encoded HD SDI video signal is output through the two OUT BNCs.
1.485/1.001 Gbps). Parallel HD Output The decoded HD parallel video signal is output by the D-SUB 50 connector. You can attach the SER-800D directly to the destina- tion equipment by securing the mounting screws to the destina- tion equipment female connector.
Figure 3.1 indicates the locations of the miniature slide switch on the SER-800D/E. Figure 3.1 SER-800D/E Slide Switch location Mode slide switch Mode A (Panasonic pinout) Set the SER-800D/E to this mode when connecting to an equip- ment that uses Panasonic D-SUB 50 pin-out: Pin # Signal* Pin#...
SER-800D/E - Guide to Installation and Operation Mode B (Philips pinout) Set the SER-800D/E to this mode when connecting to an equip- ment that uses Philips D-SUB 50 pin-out: Pin # Signal* Pin# Signal* Pin# Signal* CLK+ CLK- Data9+ Data9-...
Page 38
SER-800D/E - Guide to Installation and Operation...
4.1 SER-WSU Power Supply The power supply SER-WSU, for 110V and 220V operation, is used to power the SER-800D/E. The SER-WSU provides a reg- ulated -5.1VDC@2.4A power source. Plug the power supply into a wall or power bar outlet. The SER-WSU comes with two outlet adapters;...
SER-800D/E - Guide to Installation and Operation 4.2.1 SER-CPS Front Panel Figure 4.2 describes the SER-CPS front panel. Figure 4.2 SER-CPS Front Panel SER Power Frame POWER ON POWER FAIL Rack mount holes Power On indicator Power Fail indicator The front panel consists of the following parts: Power On Indicator This indicator lights up when AC power is connected to the frame.
SER-800D/E - Guide to Installation and Operation The rear panel consists of the following parts: DC Power Outputs Ten DC power outputs are available to power any member of the SER coder family. AC Power Connector AC power cord to be connected here. Both 110 VAC and 220 VAC standards supported.
SER-800D/E - Guide to Installation and Operation 4.2.4 Locating and replacing a defective power supply In the event where the Power Fail indicator turns on, follow the steps below to locate and replace the defective power supply: 1- Ensure that the SER-CPS is powered. Remove the top cover, preventing contact with any internal AC wiring.
The DB-SUB 50 connectors should have #4-40 screw locks with a conductive backshell to maintain proper shielding. If the connector end installed on the SER-800D/E coder is male, use the female-to-female cable adapter provided. For cables longer than a few meters, twisted pairs should be used for each signal and its return.
Page 44
SER-800D/E - Guide to Installation and Operation...
SER-800D/E - Guide to Installation and Operation 5 Specifications Inputs SER-800D HD-SDI video signal: HD-SDI (SMPTE-292M, 1.485 and 1.485/1.001 Gb/S) with active loop- through Max. cable length: 100m (350’) Connector: BNC (75 ohm) SER-800E HD parallel video signal: 720p @ 23.98/24/25/29/29.97/30/50/59.94/60 Hz frame freq.
Page 46
SER-800D/E - Guide to Installation and Operation Connector: D-SUB 50 Panasonic or Philips pin-out, user- selectable SER-800E HD SDI video signal (2): HD SDI (SMPTE-292M, 1.485 and 1.485/1.001 Gbps) Connector: BNC (75 ohm) Mechanical Dimensions: Width: 67mm (2.63") Height: 20 mm (0.8") Depth: 85 mm (3.35")
