Audio Input Preparations
(The viewfinder shown in the illustration is the optional AJ-VF10P.)
Mounting the AJ-MH700P Microphone Holder (Option)
1
Remove the microphone holder mounting screws.
2
Mount the AJ-MH700P microphone adaptor (option) to the main unit.
3
Mount the microphone to the microphone holder and tighten the screws.
4
Connect the microphone connecting cable to the MIC IN jack.
5
Set the AUDIO IN switch to FRONT [MIC] in accordance with the audio channel to be re-
corded.
To the MIC IN Connector
– 39 –
Mount the microphone
adaptor using the
accessory screws.
