Page 1: User Manual
SBC-AVL User Manual Version 2.4 SBC-AVL / SBC-AVL Power... -
Page 2: Table Of Contents
dfdfdsf Table of Contents Overview _________________________________________________________________________ 5 Applicable Products ________________________________________________________________ 5 Delivery Content ___________________________________________________________________ 6 SBC-AVL Components _______________________________________________________________ 7 Operating Set up ___________________________________________________________________ 8 Operating the device ___________________________________________________________________ 8 Insert the SIM Card_____________________________________________________________________ 8 Close the cover _______________________________________________________________________ 10 Powering up the device ________________________________________________________________ 10 5.4.1 Wiring description ____________________________________________________________________________ 11 LED behavior_________________________________________________________________________ 12... - Page 3 dfdfdsf 10.1 General Battery handling _______________________________________________________________ 20 10.2 Battery storage _______________________________________________________________________ 20 10.3 Battery disposal ______________________________________________________________________ 21 11 General Terms and Conditions _______________________________________________________ 22 12 Documentation change LOG_________________________________________________________ 23...
- Page 4 Table Overview Table 1: The different versions of the SBC-AVL ....................5 Table 2: Accessories ............................6 Table 3: Components of SBC-AVL and SBC-AVL Power ..................7 Table 4: SBC-AVL Cable Color description ...................... 11 Table 5: LED Behaviour ........................... 12 Table 6: The device cannot connect to a GSM network.................
-
Page 5: Overview
Overview The SBC-AVL family of products from Telic is an innovative telematics unit offering a wide range of tracking and monitoring configuration options. The extremely small form factor combined with high quality performance enables the user to deploy the SBC-AVL in a variety of applications. The SBC-AVL is designed for deployment in passenger cars, any type of commercial vehicles, fleets of taxis, rental cars or in public transportation vehicles. -
Page 6: Delivery Content
dfdfdsf Delivery Content In addition to the SBC-AVL, the following accessories can be part of the shipment, if previously ordered. Accessory Name Order code Functionality Picture Connection cable SBC AVL 16032 Automotive molex cable for on vehicle installation Cigarette lighter charger 17024 Charger cable for SBC-AVL... -
Page 7: Sbc-Avl Components
Recharging temperature 0°C to +45°C Table 3: Components of SBC-AVL and SBC-AVL Power This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference; (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 8: Operating Set Up
Please take proper ESD protection measures (e.g. electrical connection of the body to ground) to make sure you don’t destroy internal electronics! Repair of ESD damages caused by user’s negligence will not be covered by Telic’s warranty. Electrostatic discharge (ESD) is the sudden and momentary electric current that flows between two objects at different electrical potentials normally caused by static electricity. -
Page 9: Figure 3: How To Insert The Sim Card
dfdfdsf If the SIM card is not PIN free, it has to be ensured that the PIN is set to “0000”. To speed up the log-in process into the GSM network, the SIM card should contain no or only a few phone book entries. The messages of the SBC-AVL are transmitted via the mobile GSM network. -
Page 10: Close The Cover
GND the GPS and GSM modules will remain switched off, even when the device is connected to the USB port, it will not go into any kind of sleep mode. The SBC-AVL Power version else is able to power up GPS and GSM modules also while just connected to the USB port, without main power. -
Page 11: Wiring Description
dfdfdsf 5.4.1 Wiring description This side up Figure 7: SBC-AVL Connector Figure 6: SBC-AVL Cable Pin allocation Signal Cable Color Connection SBC-AVL SBC-AVL Power VCC /IN 3 Red (pin 1) Required Black (pin 6) Required IGNITION INPUT (1) Yellow (pin 5) Recommended DIG_IN 2 (ANA_IN1) Violet (pin 4) -
Page 12: Led Behavior
dfdfdsf 5.5 LED behavior Left indicator: Power supply Middle Indicator: GSM status Right Indicator: GPS status status The left indicator consists of a red The orange LED reflects the GSM This LED blinks green and indicates one. status and also whether the device is the status of the GPS receiver switching on When the LED is off, the GSM... -
Page 13: Troubleshooting Hints
On-board power supply failure or defective protect the device and the periphery and only get damaged internal fuse by extensive surcharge. You have to send the device to Telic or to your supplier. Table 6: The device cannot connect to a GSM network 6.2 The device doesn’t log into the GPRS network... -
Page 14: The Device Doesn't Receive Gps Data
dfdfdsf 6.3 The device doesn’t receive GPS data Possible issue source Troubleshooting The GPS internal antenna has no free sight Please be aware, that a GPS internal antenna needs always to the sky. clear view to the sky. Look for a better installation place of the device inside the vehicle. -
Page 15: Basic Features
Basic features The device can be configured via serial cable by using the Telic Configuration tool otherwise remotely via SMS and GPRS. Please contact Telic GmbH to have more details about the configuration procedure. 7.1 Event Types The SBC-AVL’s primarily task is to transmit GPS position data, including additional status information via a TCP/IP connection to the tracking server. -
Page 16: Table 9: Content Description
dfdfdsf Content Description Event/Log -Code Reason for the status message Event/Log Timestamp Time at which the event has happened GPS Timestamp GPS timestamp at the moment of fetching longitude and latitude Longitude Degree of longitude (default: in 100µ degrees; can be decreased to 1µ... -
Page 17: Advanced Features
dfdfdsf Advanced Features In this paragraph are described some advanced features supported by the device, which might be requirement for different use cases. 8.1 Geofencing Figure 8: Geofencing Geofencing (an electronic safety fence) provides the opportunity to set a geographic square around a defined location. -
Page 18: Gsm Jamming Detection Feature
8.6 Glonass enabling The SBC-AVL Power obtains the fix per default based on GPS system. It is possible to send a command in order to force the device to use the GLONASS positioning system instead of GPS. 8.7 1-Wire A 1-wire interface is available on the SBC-AVL Power, which allows ID-Button for driver recognition and the connection of up to 8 temperature probes. -
Page 19: Connect To The Vehicle
If the Telic SBC-AVL remote control unit is configured to use a motion dependent power mode, the device can detect and report that it is moving (e.g. if it is stolen or being transported via a second... -
Page 20: Safety
Do not weld or solder to the battery’s body It is very important that only authorized official Telic replacement batteries be used in the SBC-AVL. Also the batteries included with the devices are only tested or authorized for use in the SBC-AVL. -
Page 21: Battery Disposal
dfdfdsf 10.3 Battery disposal The disposal or recycling of batteries is regulated by each European country. In each country, the manufacturers, importers and users are responsible for the proper disposal. The European Community (EC) has issued two directives, 91/157/EEC and 93/86/EEC. These directives are implemented by each member country of the EC independently and in a different way. -
Page 22: General Terms And Conditions
11 General Terms and Conditions All information in this documentation has been carefully assembled and checked, but should not be considered as a guaranteed feature set. The copyright of the related documentation is with Telic GmbH. The Telic Logo and the terms Telic, and Telic SBC-AVL are brands of Telic GmbH. -
Page 23: Documentation Change Log
dfdfdsf 12 Documentation change LOG Revision Date Changes Rev. 2.0 06/02/14 First release on new layout Rev. 2.1 26/05/14 Layout Update Rev. 2.2 25/08/14 Updated SBC-AVL specific information Updated Sections 1, 4 and 5.4.1. Rev. 2.3 01/01/15 New Chapter 2 to identify applicable products. Rev.
