Summary of Contents for AWA IR706
- Page 1 DAB+ Internet Clock Radio IR706...
-
Page 2: Safety Information
Safety Information 9. Do not defeat the safety purpose of the polarized or grounding - type plug. a polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. -
Page 3: Table Of Contents
Contents Safety Information Package Content Unit Top Overview ......................3 Unit Front and Back Overview ....................4 Internet Radio Quick start Guide What you need before you can use your Internet Radio ............5 Chapter 1 Internet Mode 1.1 Setup Wizard .........................6 1.2 Access Wireless Network ....................7 1.3 Local Stations ........................8 1.4 Choose a Station ......................8 1.5 Select a Station through Podcasts ..................9... - Page 4 6.3 Factory Reset .......................21 6.4 Software Update ......................22 6.5 Setup Wizard .......................22 6.6 The way to get SW Version and Radio ID..............22 6.7 Backlight........................23 Chapter 7 Troubleshooting Chapter 8 Specification...
-
Page 5: Package Content
Package Content Main Unit Power Adapter The configuration not match with submitted sample Instruction Manual... -
Page 6: Unit Top Overview
Unit Top Overview Control All mode Music player mode use only: Press to previous track, press to Play/Pause, Press to next Track Press to set Alarms ALARM Internet, DAB and FM mode: PRESET Press and hold to store current playing program as preset station; Short press to load preset stations. -
Page 7: Unit Front And Back Overview
Unit Front and Back Overview... -
Page 8: Internet Radio Quick Start Guide
Internet Radio Quick Start Guide What you need before you can use your Internet Radio ☺ Thanks for your buying! Before use it, you need to know followings: Wireless LAN Setting: • A broadband Internet connection. • A wireless access point (Wi-Fi) connected to your broadband Internet, preferably via a router. •... -
Page 9: Chapter 1 Internet Mode
Chapter 1 Internet Mode 1.1 Setup Wizard Step 1 - Power up 1. Connect DC adapter to your Internet Radio. Press to switch your radio on (press again can switch your radio off). For initial use, a ‘Setup wizard’ dialog appears on the display. Step 2 –... -
Page 10: Access Wireless Network
Press to cycle through the alphanumeric character list, press SELECT/SNOOZE to select an appointed character. Note: WEP/WPA pass codes are case-sensitive. If a wrong character is being input while entering your password, select ‘ ’ to delete that character. Note: a.> = Backspace. -
Page 11: Local Stations
3. Then refer following section to choice stations. Or if failed to connect to network, please follow: a. Check your Router, see it working normally or not; b. Relocate your radio to a stronger signal position is necessary! c. Make sure your password is correct input. 1.3 Local Stations •... -
Page 12: Select A Station Through Podcasts
a. While cursor point to < Location >, press SELECT/SNOOZE to confirm. b. Press to the region you wanted, press SELECT/SNOOZE to confirm. c. Using the same method to choose country, station in turn, radio will now loading. • ‘GENRE’ enables you to choose stations according to their content, for example Classic Rock, Sport, News, etc. Note: a. -
Page 13: Add Station To 'My Favourites
1.8 Add Station to ‘My Favourites’ 1. Visit website: http://www.wifiradio-frontier.com 2. Click on the register link. 3. Create account login, you need an Access code to complete it, for how to get this code, please refer previous page. Note: want to member login? Therefore save your registered ‘Email address’ and ‘Password’. 4. -
Page 14: Add Station To 'My Added Stations
1.9 Add Station to ‘My Added Stations’ Even though the Internet radio portal contains thousands of stations, you may want to listen to stations not listed. You can add your own stations via the portal. 1. Visit website: http://www.wifiradio-frontier.com 2. Login as a member(at previous page, you registered). 3. -
Page 15: Chapter 2 Music Player Mode
Chapter 2 Music Player Mode 2.1 Setting up a Music Server • In order for your radio play music files from a computer, the computer must be set up to share files or media. • UPnP media sharing allows devices like this radio to play music from a shared media library, navigating through tag menus such as Artist, Album or Genre. -
Page 16: Play Shared Media
2.3 Play Shared Media 1. Press MODE repeatedly until < Music player > is showing up. SELECT/SNOOZE Note: Or, enter < Main menu >, and then press to < Music player >, press confirm. 2. While cursor point to < Shared media >, press SELECT/SNOOZE to confirm, and then step by step to your selecting Music. -
Page 18: Chapter 3 Dab Mode
Chapter 3 DAB Mode 3.1 Shift to DAB mode 1. Press MODE repeatedly until < DAB radio > is shows up. For initial use, it will carry up a full scan and store stations list in memory. Note: a. or press MENU to enter < Main menu >, and then press to <... -
Page 19: Drc (Dynamic Range Control)
3.5 DRC (Dynamic Range Control) You can set the level of the compression of stations to eliminate the differences in dynamic range or sound level between radio stations. Note: a. Set DRC to off indicates no compression. b. set DRC to low indicates little compression. c. -
Page 20: Chapter 4 Fm Mode
Chapter 4 FM Mode 4.1 General operation Press MODE repeatedly until < FM Radio > is showing up. For initial use, it will start at the beginning of the FM frequency range (87.50MHz). Otherwise, the last listened FM station will be selected. SELECT/SNOOZE Note: or enter <... -
Page 21: Chapter 5 General Operation
Chapter 5 General Operation 5.1 Setting Station Presets Your radio can store 10 Internet, 10 DAB and 10 FM stations preset. To store the current station: 1. Press and hold PRESET until it shows ‘Save Preset’, and then press to your purpose one. 2. -
Page 22: Setting Clock
Note: At this step, and sleep icon shows up, as well as shows how long it will be expired. 4. Radio will now automatically put itself into standby mode after sleep time has elapsed. 5. To continue enjoying your program by pressing 5.4 Setting Clock 1. - Page 23 • Preset: this option depends on which alarm mode you have setting, this option won’t be available unless you choice Internet radio, DAB, FM as alarm sound mode • Volume: Press to your like volume level, press SELECT/SNOOZE to confirm ...
-
Page 24: Chapter 6 System Settings
Chapter 6 System settings 6.1 Network setup Note: Users experienced with networking may find these options useful for diagnosing and fixing network problems. 1. There are some options for viewing and manually altering network settings from pressing MENU < Main menu > <... -
Page 25: Software Update
• Internet radio favourites therefore remain unless you re-register your radio with another account on the portal website. It can be reached by pressing MENU < Main menu > < System settings > < Factory Reset > Proceed? YES or NO. Press SELECT/SNOOZE to confirm ‘YES’. -
Page 26: Backlight
2. Press SELECT/SNOOZE to confirm, this information may be requested when dealing with technical support issues. 6.7 Backlight Note: Here, High brightness level can get you pretty easy to view the station information. Set to Low can let you feel comfortable while you do not want to light bother you. ·... -
Page 27: Chapter 7 Troubleshooting
Chapter 7 Troubleshooting If you experience any trouble with your wireless Internet Radio, then you may find it useful to visit the help section on our webpage: http://www.wifiRadio-frontier.com If you have trouble connecting the Radio to your wireless network, these steps may help to resolve the problem: 1. -
Page 28: Chapter 8 Specification
Chapter 8 Specification ITEMS DESCRIPTION Specifications: DAB+ Internet Radio DC Adapter: Input: 100-240 Vac, 50-60 HZ Power Requirements: Output: 9Vdc/1000mA Output Power: 2Wrms x 2 Speaker: 8 ohm Dimension: 226 x 111 x 105mm This symbol on the product or in the instructions means that your electrical and electronic equipment should be disposed at the end of its life separately from your household waste.
