KX-TG7200
This unit is Caller ID compatible. To display the caller's
phone number, you must subscribe to Caller ID service.
Charge the batteries for about 7 hours before initial use.
Please read these operating instructions before using the unit and save
them for future reference.
Operating Instructions
Digital Cordless Phone
KX-TG7200HK
Model No.
KX-TG7202HK
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Panasonic KX-TG7200HK
Summary of Contents for Panasonic KX-TG7200HK
-
Page 1: Operating Instructions
Caller ID service. Charge the batteries for about 7 hours before initial use. Please read these operating instructions before using the unit and save them for future reference. Operating Instructions Digital Cordless Phone KX-TG7200HK Model No. KX-TG7202HK... -
Page 2: Table Of Contents
Table of Contents Preparation Introduction ..... 3 Accessory information ... . . 4 Important information . -
Page 3: Introduction
Introduction Thank you for purchasing a new Panasonic digital cordless phone. For your future reference Keep original receipt and guarantee card to assist with any repair under warranty. Serial No. (found on the bottom of the base unit) Date of purchase... -
Page 4: Accessory Information
Charger (Part No. PQLV30055Z) AC adaptor for charger (Part No. PQLV209E) *1 The handset cover comes attached to the handset. Additional/replacement accessories Please contact your nearest Panasonic dealer for sales information. Model No. Description KX-TGA721HM Additional Digital Cordless Handset KX-A272... -
Page 5: Important Information
Important information General L Use only the AC adaptor supplied with this product, noted on page 4. L Do not connect the AC adaptor to any AC outlet other than a standard 220–240 V AC outlet. L This product is unable to make calls when: –... - Page 6 Preparation Battery caution L We recommend using the battery(ies) noted on page 4. Use only rechargeable battery(ies). L Do not mix old and new batteries. L Do not dispose of the battery(ies) in a fire, as they may explode. Check with local waste management codes for special disposal instructions.
-
Page 7: Controls
Controls Base unit A Charge contacts B {x} (Page) Handset A Speaker B {j/OK} (Menu/OK) C {k} (Phonebook) D {C} (Talk) E Navigator key ({^}/{V}/{>}/{<})/ ? (Receiver volume: {^}{V}) F {s} (Speakerphone) G {R} (Flash) H Receiver I Display J {R} (Redial/Pause) K {ih} (Off/Power) L {C/T} (Clear/Mute) M Dial keypad... -
Page 8: Displays
Preparation Displays Display icons Icon Meaning Within range of a base unit L When flashing: Handset is searching for base unit. (page Handset is accessing base unit. (intercom, paging, changing base unit settings, etc.) Handset is on an outside call. Battery level Call privacy mode is on. -
Page 9: Battery Installation And Replacement
L Wipe the battery ends (S, T) with a dry cloth. L When installing the batteries, avoid touching the battery ends (S, T) or the unit contacts. L When replacing batteries, we recommend using the Panasonic rechargeable batteries noted on page 4, 6. Preparation... -
Page 10: Battery Charge
Preparation Press the notch on the handset cover firmly and slide it in the direction of the arrow. Insert the batteries negative (T) end first. Close the handset cover. Rechargeable Ni-MH ONLY Note: L When replacing batteries, remove the old batteries. Battery charge Place the handset on the base unit or charger for about 7 hours before... -
Page 11: Turning The Power On/Off
Battery level Battery icon Battery level High Medium L When flashing: Needs to be charged. Panasonic Ni-MH battery performance (supplied batteries) Operation Operating time In continuous use 17 hours max. In continuous 180 hours standby mode max. Note: L It is normal for batteries not to reach full capacity at the initial charge. -
Page 12: Date And Time
Preparation Dialling mode (tone/pulse) Changing the dialling mode depending on your telephone line service. “Tone”: Select when you have a touch- tone service. “Pulse”: Select when you have rotary/pulse service. {j/OK} Press {^} or {V} to select “Base Unit Setup”. i {>} Press {^} or {V} to select “Call Options”. -
Page 13: Making/Answering Calls
Making calls Lift the handset and dial the phone number. L To correct a digit, press {C/T}. When finished talking, press {ih} or place the handset on the base unit or charger. Speakerphone During a conversation, press {s} to turn on the speakerphone. L Speak alternately with the caller. -
Page 14: Useful Features During A Call
Making/Answering Calls Handset locator Using this feature, you can locate the handset if it has been misplaced. Press {x} on the base unit. To stop paging, press {x} on the base unit or press {ih} on the handset. Useful features during a call Mute While mute is turned on, you will be able... -
Page 15: Call Privacy
Call privacy Call privacy allows you to prevent other users from joining your conversations with outside callers. To allow other users to join your conversations, leave this feature off. The default setting is “Off”. Press {j/OK} during an outside call. {^}/{V}: “On”... -
Page 16: Phonebook
Phonebook Handset phonebook The handset phonebook allows you to make calls without having to dial manually. You can add 50 names and phone numbers. Adding entries {k} i {j/OK} {^}/{V}: “New Entry” i {>} Enter the party’s name (16 characters max.; page 24). i {j/OK} Enter the party’s phone number (24 digits max.). -
Page 17: Handset Settings
Handset settings To customise the handset: {j/OK} Press {^} or {V} to select “Handset Setup”. i {>} Press {^} or {V} to select the desired item in the handset settings menu. i {>} Press {^} or {V} to select the desired item in the sub-menu. i {>} Press {^} or {V} to select the desired setting then press {>}. -
Page 18: Base Unit Settings
*2 If you change the PIN, please make note of your new PIN. The unit will not reveal the PIN to you. *3 If you forget your PIN, consult your nearest Panasonic service centre. Details (default setting) (“Tone”): page 12 Flash time (“400 msec.”) -
Page 19: Caller Id Service
Using Caller ID service Important: L This unit is Caller ID compatible. To use Caller ID features (such as displaying caller phone numbers), you must subscribe to Caller ID service. Consult your service provider/telephone company for details. Caller ID features When an outside call is received, the caller’s phone number will be displayed. -
Page 20: Erasing Caller Information
Caller ID Service Erasing caller information {j/OK} {^}/{V}: “Caller List” i {>} {^}/{V}: Select the desired entry. i {j/OK} {^}/{V}: “Erase” or “Erase All” i {>} {^}/{V}: “Yes” i {>} i {ih} Storing caller information into the handset phonebook {j/OK} {^}/{V}: “Caller List”... -
Page 21: Multi-Unit Operation
Wait until “Enter Base PIN” is displayed. i Enter the base unit PIN (default: “0000”). i {j/OK} L If you forget your PIN, consult your nearest Panasonic service centre. L When the handset has been registered successfully, w will stop flashing. If the key tone is turned on (page 17), a confirmation tone will be heard. -
Page 22: Intercom Between Handsets
Increasing the range of the base unit You can increase the signal range of the base unit by using a DECT repeater. Please use only the Panasonic DECT repeater noted on page 4. Consult your Panasonic dealer for details. Important:... - Page 23 Transferring a call without speaking to the other handset user During an outside call, press {INT}. i Press the desired handset number. L k flashes to indicate the outside call is on hold. {ih} L The outside call rings at the other handset.
-
Page 24: Useful Information
Useful Information Character entry The dial keys are used to enter characters and numbers. Each dial key has multiple characters assigned to it. The available character entry modes are Alphabet (ABC), Numeric (0-9), Greek (F), Extended 1 (G), Extended 2 (H), and Cyrillic (I). - Page 25 Useful Information Extended 1 character table (N) L The following are used for both uppercase and lowercase: Extended 2 character table (O) L The following are used for both uppercase and lowercase: Cyrillic character table (P)
-
Page 26: Error Messages
Useful Information Error messages Error message Cause & solution L The handset’s phonebook memory is full. Erase Memory Full L The handset has lost communication with the base No link to base. Move closer to base, try again. L Unplug the base unit’s AC adaptor to reset the unit. L The handset’s registration may have been L You must subscribe to Caller ID service. - Page 27 Problem Cause & solution I have changed the L Change the display language (page 11). display language to a language I cannot read. I cannot make or L The base unit AC adaptor or telephone line cord is receive calls. not connected.
- Page 28 (page 28). registered to the base unit. Cancel unused handset registrations from the base unit (page 21). consult your nearest Panasonic service centre. other electrical appliances. them using the following method. {j/OK} {^}/{V}: “Caller List” i {>} Press {V} to search from the most recent call, or press {^} to search from the oldest call.
-
Page 29: Specifications
Specifications ■ Standard: DECT (Digital Enhanced Cordless Telecommunications), GAP (Generic Access Profile) ■ Number of channels: 120 Duplex Channels ■ Frequency range: 1.88 GHz to 1.90 GHz ■ Duplex procedure: TDMA (Time Division Multiple Access) ■ Channel spacing: 1,728 kHz ■... -
Page 30: Index
Index Index Additional handsets: 21 Answering calls: 13 Auto talk: 13, 17 Base unit Settings: 18 Battery: 9, 11 Caller ID service: 19 Call privacy: 15 Call share: 14 Call waiting: 14 Chain dial: 16 Character entry: 24 Date and time: 12 Dialling mode: 12 Display Contrast: 17... - Page 31 Notes...
- Page 32 1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka 812-8531, Japan Copyright: This material is copyrighted by Panasonic Communications Co., Ltd., and may be reproduced for internal use only. All other reproduction, in whole or in part, is prohibited without the written consent of Panasonic Communications Co., Ltd.
