Digital colour imaging systems
Hide thumbs Also See for DP-C322:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Function Manual, Operating Instructions Manual

Table of Contents

Installation Overview
General Installation Overview ........................ 2
Setting Your Machine
Network Configuration ................................... 4
Installing Printer/Fax Driver
Printer Driver ................................................. 7
●
System requirements ............................ 7
(Direct Connection) ................................... 8
●
.............................................................. 8
●
Printer Setup Procedure ...................... 11
●
Network Print Server ........................... 11
●
(Windows NT Server) .......................... 15
●
(Windows 2000 Server) ....................... 17
●
(Windows Server 2003) ....................... 19
●
Setting up your client PC ..................... 21
●
............................................................ 22
Before operating this machine, please read this manual completely
and keep this manual for future reference.
(Illustration shows optional accessories that may not be installed on your machine.)
Digital Colour Imaging Systems
Operating Instructions
Model No.
Fax Driver .................................................... 28
●
System Requirements ......................... 28
●
Installing the Fax Driver ....................... 28
Installing Application Softwares
●
Management System ........................... 32
Setting up Optional Accessories
●
Scanner Setup Procedure ................... 36
●
●
●
Procedure ............................................ 40
●
Configurations ..................................... 40
●
Function Setting List (Example) ................... 46
IMPORTANT INFORMATION ...................... 60
(For Setting Up)
DP-C262/C322
English
