Summary of Contents for AEG S63300KDW0
-
Page 2: Table Of Contents
CONTENTS 4 SAFETY INFORMATION 6 PRODUCT DESCRIPTION 7 CONTROL PANEL 9 DAILY USE 11 HELPFUL HINTS AND TIPS 12 CARE AND CLEANING 13 TROUBLESHOOTING 16 INSTALLATION 20 NOISES 21 TECHNICAL DATA ENVIRONMENT CONCERNS Recycle the materials with the symbol . - Page 3 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
-
Page 4: Safety Information
SAFETY INFORMATION GENERAL SAFETY In the interest of your safety and to ensure the correct use, before installing and first WARNING! using the appliance, read this user manual Keep ventilation openings, in the carefully, including its hints and warnings. - Page 5 Make sure that the power plug is • Adequate air circulation should be not squashed or damaged by the around the appliance, lacking this leads back of the appliance. A squashed to overheating. To achieve sufficient or damaged power plug may over- ventilation follow the instructions rele- heat and cause a fire.
-
Page 6: Product Description
PRODUCT DESCRIPTION Glass shelf Glass shelf Glass shelf Glass shelf Glass shelf Dynamic Air-cooling Control panel Butter shelf Door shelf Door shelf Bottle shelf Fruit drawer Rating plate... -
Page 7: Control Panel
CONTROL PANEL Display The temperature indicators show the set default temperature. Temperature warmer button To select a different set temperature refer Temperature colder button to "Temperature regulation". OK button SWITCHING OFF Mode button ON/OFF button To switch off the appliance do these It is possible to change predefined sound steps: of buttons to a loudly one by pressing to-... -
Page 8: Holiday Function
Press the Timer regulator button to Press the OK button to confirm. change the Timer set value from 1 to The COOLMATIC indicator is shown. 90 minutes. The COOLMATIC function shuts off auto- Press the OK button to confirm. -
Page 9: Daily Use
DAILY USE DYNAMICAIR The refrigerator compartment is equip- ped with a device that allows for rapid cooling of foods and more uniform tem- perature in the compartment. This device activates by itself when nee- ded, for example for a quick temperature recovering after door opening or when the ambient temperature is high. -
Page 10: Positioning The Door Shelves
10 www.aeg.com POSITIONING THE DOOR SHELVES To permit storage of food packages of various sizes, the door shelves can be placed at different heights. To make these adjustments proceed as follows: gradually pull the shelf in the direction of the arrows until it comes free, then reposi-... -
Page 11: Helpful Hints And Tips
HELPFUL HINTS AND TIPS NORMAL OPERATING Meat (all types) : wrap in polythene bags and place on the glass shelf above the SOUNDS vegetable drawer. For safety, store in this way only one or • You may hear a faint gurgling and a two days at the most. -
Page 12: Care And Cleaning
12 www.aeg.com CARE AND CLEANING CLEANING THE INTERIOR • rinse and dry thoroughly. Do not pull, move or damage any Before using the appliance for the first pipes and/or cables inside the time, wash the interior and all internal ac- cabinet. -
Page 13: Troubleshooting
TROUBLESHOOTING During operation of the appliance some The appliance operates discontin- smaller but annoying trouble can often uously, so the stopping of com- occur, which does not require calling a pressor does not mean being no technician out. In the following chart infor- current. - Page 14 14 www.aeg.com Problem Possible cause Solution Food prevent that water Make sure that food do not flows into the water collec- touch the rear plate. tor. Water flows on the The melting water outlet Attach the melting water ground. does not flow in the evap-...
-
Page 15: Replacing The Lamp
REPLACING THE LAMP The appliance is equipped with a longlife LED interior light. Only service is allowed to replace the lighting device. Contact your Service Cen- ter . CLOSING THE DOOR Clean the door gaskets. If necessary, adjust the door. Refer to "Installation". -
Page 16: Installation
16 www.aeg.com INSTALLATION WARNING! Cli- Ambient temperature Read the "Safety Information" mate carefully for your safety and cor- class rect operation of the appliance before installing the appliance. +10°C to + 32°C +16°C to + 32°C POSITIONING +16°C to + 38°C Install this appliance at a location where +16°C to + 43°C... -
Page 17: Electrical Connection
ELECTRICAL CONNECTION CAUTION! Any electrical work required to in- stall this appliance should be car- ried out by a qualified electrician or competent person. WARNING! This appliance must be earthed. The manufacturer declines any lia- bility should these safety meas- ures not be observed. -
Page 18: Rear Spacers
18 www.aeg.com REAR SPACERS You can find the two spacers in the bag with documentation. Do these steps to install the spacers: Release the screw. Engage the spacer below the screw. Turn the spacer to the right position. Tighten again the screws. - Page 19 • Unscrew the upper pin and screw it on the opposite side. • Refit the door. • Make sure the edge of the door is par- allel with the edge of the top. • Unscrew the pin (A) and screw it on the opposite side.
-
Page 20: Noises
20 www.aeg.com NOISES There are some sounds during normal running (compressor, refrigerant circula- tion). HISSS! BRRR! BRRR! BRRR! BLUBB! BLUBB! -
Page 21: Technical Data
HISSS! HISSS! SSSRRR! SSSRRR! CRACK! CRACK! TECHNICAL DATA Dimension Height 1540 mm Width 595 mm Depth 658 mm Voltage 230 - 240 V Frequency 50 Hz The technical information are situated in the rating plate on the internal left side of the appliance and in the energy label. - Page 22 22 www.aeg.com...
- Page 24 www.aeg.com/shop...
