GEAppliances gdwt708vbb Installation Instructions Manual

Built-in dishwasher
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Installation
Instructions
If you have questions, call 800.GE.CARES (800.432.2737) or visit our website at: www.ge.com
BEFORE YOU BEGIN
Read these instructions completely and carefully.
IMPORTANT
codes and ordinances.
• Note to Installer – Be sure to leave these instructions
for the consumer's and local inspector's use.
• Note to Consumer – Keep these instructions with your
Owner's Manual for future reference.
• Skill Level – Installation of this dishwasher requires
basic mechanical, electrical and plumbing skills.
Proper installation is the responsibility of the
installer. Product failure due to improper installation
is not covered under the GE Appliance Warranty.
See warranty information.
• Completion Time – 1 to 3 Hours. New installations
require more time than replacement installations.
– Observe all governing
Built-In
Dishwasher
IMPORTANT
installed to allow for future removal from the enclosure
if service is required.
If you received a damaged dishwasher, you should
immediately contact your dealer or builder.
Optional Accessories – See the Owner's Manual for
available custom panel kits.
FOR YOUR SAFETY
Read and observe all CAUTIONS and WARNINGS
shown throughout these instructions. While performing
installations described in this booklet, gloves, safety
glasses or goggles should be worn.
READ CAREFULLY.
KEEP THESE INSTRUCTIONS.
– The dishwasher MUST be

Advertisement

Table of Contents
loading

Related Manuals for GEAppliances gdwt708vbb

Summary of Contents for GEAppliances gdwt708vbb

  • Page 1 Built-In Installation Dishwasher Instructions If you have questions, call 800.GE.CARES (800.432.2737) or visit our website at: www.ge.com BEFORE YOU BEGIN IMPORTANT – The dishwasher MUST be Read these instructions completely and carefully. installed to allow for future removal from the enclosure if service is required.

  • Page 2: Parts Supplied

    Installation Preparation Side and Top Trim Pieces on some models PARTS SUPPLIED: Two #8-18 x 5/8" Phillips special head screws, to secure dishwasher to underside of countertop Clamp or to side of cabinets. (Taped to top or side of Drain Hose dishwasher.) Side and top trim pieces on some models 2 Side-mounting brackets with four #8 Pan-head...

  • Page 3: Prepare Dishwasher Enclosure

    Installation Preparation PREPARE DISHWASHER ENCLOSURE • The dishwasher must be installed so that drain hose is no more than 10' in length for proper drainage. • The dishwasher must be fully enclosed on the top, sides and back, and must not support any part of the enclosure.

  • Page 4: Prepare Electrical Wiring

    Installation Preparation PREPARE ELECTRICAL WIRING FOR PERSONAL SAFETY: Remove Alternate Receptacle house fuse or open circuit breaker Location before beginning installation. Do not 18" use an extension cord or adapter plug with this appliance. 1-1/2" Dia. Hole (Max.) Receptacle Location 18"...

  • Page 5: Before You Begin

    Installation Instructions STEP 1 CHECK DOOR BALANCE PREPARE HOT WATER LINE • The line may enter from either side, rear or floor With dishwasher on wood skid, check the door balance within the shaded area shown in Figure F. by opening and closing the door. •...

  • Page 6: Step 3 Remove Toekick

    Installation Instructions STEP 3 REMOVE TOEKICK STEP 5A INSTALL DRAIN HOSE TO DISHWASHER • Remove the 2 toekick screws DRAIN PORT and toekick. Skip this step if drain hose has been pre-installed. In Set aside for use Remove 2 Figure I this step you will need the drain hose set aside prior in Step 18.

  • Page 7: Step 6 Position Water Line And House Wiring

    Installation Instructions STEP 6 POSITION WATER LINE STEP 8 SLIDE DISHWASHER AND HOUSE WIRING PARTIALLY INTO CABINET • Position water supply line and house wiring on the DO NOT PUSH AGAINST FRONT PANEL WITH KNEES. floor of the opening to avoid interference with base DAMAGE WILL OCCUR.

  • Page 8: Step 10 Push Dishwasher Into Final Position

    Installation Instructions STEP 9A INSTALL SIDE-MOUNT STEP 11 LEVEL DISHWASHER BRACKETS (included with some models) IMPORTANT – Dishwasher must be level for proper dish rack operation and wash performance. Skip this step if underside of countertop is wood or wood-like material. •...

  • Page 9: Step 13 Connect Water Supply

    Installation Instructions STEP 12 POSITION DISHWASHER, SECURE TO COUNTERTOP OR CABINET In this step you will need the 2 Phillips special head Method 2 screws set aside prior to Step 1. Secure dishwasher to cabinet sides The dishwasher must be secured to the countertop or •...

  • Page 10: Step 14 Connect Drain Line

    Installation Instructions STEP 14 CONNECT DRAIN LINE DRAIN LINE INSTALLATION • Connect drain line to air gap, waste tee or disposer FOLLOW ALL LOCAL CODES AND ORDINANCES. using either previously determined method. Identify the type of drain hose you have. The molded end of the drain hose will fit 5/8"...

  • Page 11: Step 15 Connect Power Supply

    Installation Instructions STEP 16 PRETEST CHECK LIST STEP 15 CONNECT POWER Review this list after installing your dishwasher to SUPPLY avoid charges for a service call that is not covered Skip this step if dishwasher is equipped with power by your warranty. cord.

  • Page 12: Step 17 Dishwasher Wet Test

    Installation Instructions STEP 17 DISHWASHER WET TEST STEP 18 REPLACE TOEKICK Turn on power supply (or plug power cord into • Place toekick against the legs of the dishwasher. outlet, if equipped). Latch door. Push “Rinse Only” button. Push start/reset pad once. Dishwasher should start. Check to be sure that water enters the dishwasher.
