- Page 1 Operating Instructions USB data logger for Testomat 808 USB data logger for connection to the Testomat 808 current interface...
-
Page 2: Table Of Contents
Contents Contents Contents ....................2 Important safety information ............. 3 Intended use ..................3 Qualification of the staff ................ 3 Warning notices in these instructions ........... 4 Further documents ................4 Pay particular attention to ..............5 General instructions ................5 Installation ..................... -
Page 3: Important Safety Information
Important safety information Important safety information Please read these operating instructions carefully and completely prior to working with the instrument. Ensure that the operating instructions are always available for all users. Always pass the data logger on to a third party together with these operating instructions. -
Page 4: Warning Notices In These Instructions
Important safety information Warning notices in these instructions The warning notices in these instructions warn the user about poten- tial dangers to individuals and property resulting from incorrect han- dling of the instrument. The warning notices are structured as follows: Description of the type or source of danger Description of the consequences resulting from non-observance SIGNAL WORD! -
Page 5: Pay Particular Attention To
Pay particular attention to Pay particular attention to General instructions Adhere to national health and safety regulations as well as envi- ronmental protection regulations in the country of use and at the WARNING installation site. Do not modify or tamper with the instrument. Do not carry out any actions at the instrument which are not de- scribed in these instructions;... -
Page 6: Scope Of Delivery
Scope of delivery Scope of delivery ® USB data logger for Testomat lithium battery, 3.6V, type ER14250 USB flash drive containing software and manual self-adhesive holder for the data logger USB extension cable package information leaflet Performance specifications The data logger stores the measurement values of the 20mA current interface at regular intervals. -
Page 7: Installation
Installation Installation Overview of controls and displays To read out the data or to replace the battery, remove the protective cap (1). At all other times the cap should be fitted to protect the unit from fluids. The type of the connecting cables can be different. Fitting or replacing the battery 1. -
Page 8: Connecting To The Testomat Unit
Installation Connecting to the Testomat unit ® Use the Testomat 808 manual as reference. This describes all the terminals. Open the upper housing door, run the cables through the cable grommet into the housing and connect the data logger cables to the 2-pin plug for the current interface on the main board. -
Page 9: Software Installation
Installation Software installation Requirement: PC with 2 USB ports for USB flash card and USB data logger Insert the USB flash card provided into a free USB port on the PC. Wait for the system to assign a drive letter (in this example E:) and then: ... -
Page 10: Using The Data Logger
*** HEYL USB DATA LOGGER - TESTOMAT 808 *** Datalogger (c)onfigure (r)ead, (H)elp, (D)river install?c Configure data logger: Input setting of switch S6 in Testomat 808 (0-9) or sample interval in seconds: 0 New name instead of 'T808Logger' (enter new name or '-')?-... - Page 11 Using the data logger - Start immediately These entries are explained below: : Position of rotary switch S6, as de- Input setting of switch S6 scribed in section Connecting to the Testomat. Enter directly the value set on the switch, between 0 and 9. This automatically selects the measurement interval as per the follow- ing table: Position...
-
Page 12: Accessing Data From The Usb Data Logger
The data access function is only available when the data logger is connected. To begin data access select A from the menu: *** HEYL USB DATA LOGGER - TESTOMAT 808 *** Datalogger (c)onfigure (r)ead, (H)elp, (D)river install? r Now the data reading process begins directly. Two files are generat- ed from the measurement data: ... -
Page 13: Troubleshooting
Troubleshooting Troubleshooting USB device not recognised Operating systems from Windows Vista onwards can auto- matically search the internet for drivers for new hardware. If the software installation has not been entirely completed, it may be that the wrong driver was installed for the data log- ger. - Page 14 Troubleshooting Try to identify the problem as accurately as possible and record the actions and conditions under which it occurred. A precise definition of the problem allows us to provide you with quick and effective help.
-
Page 15: Disassembly
Please proceed as follows: ® Disconnect the Testomat 808 unit from any power Unplug the measurement cable from the unit Remove the data logger ... - Page 16 Technical data...
