‡ SIGNET 5600 Batch Controller
*3-5600.090-1*
3-5600.090-1 (Rev. D-6/03) English
Contents
1. Wiring terminals
2. Power Connection
3. Compatible Sensor Wiring
4. Batch Contact Wiring
1. Wiring terminals
•
Remove terminal blocks for easy wiring.
2. Power Connection
CAUTION!
Never connect 115 VAC or 230 VAC to rear power
terminals. High voltage AC will damage instrument and
void warranty.
Technical Notes:
•
Maximum 4-20 mA loop impedance (sec. 8A) is affected by the
supply voltage.
•
To reduce the possibility of noise interference, isolate AC
power lines from signal lines.
3. Compatible Sensor Wiring
Std. Sensor
Technical Notes:
• To reduce the possibility of noise interference, route sensor
cable )away from AC power lines.
• *Vortex sensor or system frequency output
5600 Batch Controller
ÐSIGNET
1.
1 2 3 4 5 6
Std. Sensor
U L
LISTED
77CJ
+ GF + SIGNET Sensors:
Red
515
525
Black
2517
Shld.
2000
Red
2507
Black
2536
2540
Shld.
2550
Vortex*
5600
Terminals
Open Collector
Sensor
CAUTION!
•
•
15. Troubleshooting
2.
1 2 3 4
+
+
Gnd
Gnd
1
2
PLS
AUX
Total
output
output
reset
Open Collector
Sensor
12-24 V
10 W
+
-
= Double Insulated
= DC or AC power
4. Batch Contact Wiring
See section 9 for simple and advanced mode configuration
options.
flow
Technical Notes:
• Maximum alarm contact ratings: 5 A @ 30 VDC, 5 A @ 125
VAC, or 3 A @ 250 VAC
• To reduce the possibility of noise interference, isolate AC power
lines from signal lines.
Remove power to unit before wiring input and
output connections.
Follow instructions carefully to avoid personal
injury.
3.
1 2 3 4 5 6
Std. Sensor
U L
LISTED
77CJ
5600
Terminals
12-24 V
10 W
External power
supply
-
+
-
12 - 24 VDC
+
12 - 24 VAC
5600
Terminals
Batch
Option
NO
C
NC
NO
C
NC
AC or DC
power
valve
ENGLISH
1 2 3 4
+
+
Gnd
Gnd
1
2
PLS
AUX
Total
output
output
reset
Open Collector
Sensor
12-24 V
10 W
+
-
OR
1 of 12
Advertisement
Table of Contents
Related Manuals for Signet GF 5600
Summary of Contents for Signet GF 5600
-
Page 1: Table Of Contents
‡ SIGNET 5600 Batch Controller ENGLISH CAUTION! *3-5600.090-1* • Remove power to unit before wiring input and output connections. 3-5600.090-1 (Rev. D-6/03) English • Follow instructions carefully to avoid personal injury. Contents 8. Current Output Wiring Options 1. Wiring terminals 9. -
Page 2: Remote Control Wiring
22P positioner models: EA 20, EA 30, EA 41 VAC, or 3 A @ 250 VAC and EA 50 • To reduce the possibility of noise interference, isolate AC power lines from signal lines. 5600 Batch Controller ÐSIGNET 2 of 12... -
Page 3: Operation Modes
During the next batch cycle, the batch contact de-energizes early, thus closing the flow control valve early and eliminating batch overrun. 5600 Batch Controller ÐSIGNET 3 of 12... - Page 4 START input for a second batching stage. When the batch starts, the current output remains at 0 mA until the end of the batch, then jumps to 20 mA for 500 milliseconds. The 500 millisecond current pulse triggers the second 5600's remote START terminal to start the second batch stage. 5600 Batch Controller ÐSIGNET 4 of 12...
-
Page 5: Menu Functions
To exit without changes: Overrun: Manual Shown only when "advanced" mode is chosen 2. Enter volume 0.00000 Gallons (sec. 10.4E) quick Overrun compensation press Save ENTER To step C → ← To step A) 5600 Batch Controller ÐSIGNET 5 of 12... - Page 6 (sec.10.4G) ENTER is selected. D. Overrun comp. number of pulses generated by the + GF + SIGNET flow sensor for each engineering unit of fluid measured (published in the flow To step D → sensor manual). To restore original value:...
- Page 7 End of Batch Batch display Count Direction: Count Direction: count direction: Up Down > Up or Down Batch display count ←To step A To return To restore original value: to VIEW: quick quick press press 5600 Batch Controller ÐSIGNET 7 of 12...
-
Page 8: Parts And Accessories
5600 instruction sheet #3-5600.090-1 (code 198 869 929) 12. Specifications Agency Approvals General Sensor compatibility: All + GF + SIGNET flow sensors • CE, CSA, UL listed Accuracy: ±0.5% of batch reading • Manufactured under ISO 9001 and ISO 14001... -
Page 9: Quick Reference Menu Parameters
( 3 . 6 2 x 3 . 6 2 12-24 V i n . ) 10 W Option Batch + GF + SIGNET Model #3-5600 Rear View Panel cutout 13. Quick Reference Menu Parameters 13.1 VIEW Menu Setup Parameters (sec. 10.1) - Page 10 Delay: 30.0 sec > Current Output: Batch Completion, Valve Batch Current output mode control, or Completion BatchCompletion> End of Batch Count Direction: Count up or Count Batch count direction Down > down 5600 Batch Controller ÐSIGNET 10 of 12...
-
Page 11: Maintenance
The reversible dial scales are 0 to100%, or 100 to 0%. • The instrument is shipped with the 0 to 100% scale installed. • Reverse the face plate for either scale. • Meter deflection is fixed from left to right. 5600 Batch Controller ÐSIGNET 11 of 12... - Page 12 ‡ SIGNET Signet Scientific Company, 3401 Aerojet Avenue, El Monte, CA 91731-2882 U.S.A. • Tel. (626) 571-2770 • Fax (626) 573-2057 For Worldwide Sales and Service, visit our website: www.gfsignet.com • Or call (in the U.S.): (800) 854-4090 GEORGE FISCHER ‡ Piping Systems 3-5600.090-1 (D-6/03) English...
